Dbtechnologies OPERA 112, TWIN 208, OPERA 415, OPERA 302, OPERA 201 BROCHURE

OPERA LYRIC ACTIVE

Speakers

19

OPERA ACTIVE

OPERA. One of the most successful active box series throughout Europe. More than 200000 sold units say this clearly, just like the opera loudspeaker itself.

Intelligent Speaker.

All models in the OPERA series are fitted with high grade BiAmp Class H output stages and have intelligent electronics, such as for example the active phase-optimised diplexer or the dynamic soft clip limiter, which protects the system from overload and allows reliable operation right up to the power limit. BiAmp means that there is an individual output stage channel provided for each loudspeaker, which with the active separation allows excellent performance and high sound pressure.

More Bass. More Punch, More Pressure.

Along with the latest output stage technology, the 12” and 15” woofers, developed and produced by dB Technologies themselves, are responsible for the impressive professional sound of the current LYRIC models. An extremely light diaphragm material, generously dimension magnets and oscillation coils with low gap size provide high efficiency and convert the available power perfectly into sound pressure.

Moulded by Sound.

Due to its optimal shape, the integral 90° x 60° tweeter with 1” fittings, achieves a clean sound distribution with broad, uniform radiation of the trebles. The low resonance multi-function casing made of extremely stable polypropylene, has a standard stand flange (35 mm Ø) with fixing screw. The bevelled rear side also allows it to be used as a floor monitor. The system can easily and safely be installed permanently or hung up using the optional wall bracket WB02.

Flexibility.

Neutrik Combo XLR jack input with switched mic/ line sensitivity plus an XLR parallel out, ensure the right connection anywhere.

Ultra-lightweight!

Easy to Operate.

OPERA ACTIVE.
