VERTICAL DEFLECTION BOOSTER
.
POWER AMPLIFIER
.
THERMAL PROTECTION
.
OUTPUT CURRENT UP T O 2. 0A
.
FLYBACK VOLTAGE UP TO 90V (on Pin 5)
.
SUITABLE FOR DC COUPLING APPLICATION
.
EXTER NAL FLYBA CK SUPPLY
DESCRIPTION
Designed for monitors and high performance TVs,
the STV9379F vertical def lection boos ter c an handle flyback voltage up to 90V. Further to this, it is
possible to have a flyback voltage which is more
than the double of the supply (Pin 2). This allows
to decrease the power consumption, or to decrease
the flyback time for a given supply voltage.
The STV9379F operates with supplies up to 42V
and provides up to 2.0A
the yoke.
The STV9379F is offered in HEPTAWATT package.
output current to drive
PP
PP
HEPTAWATT
(Plastic Package)
ORDER CODE :
STV9379F
STV9379F
PIN CONNECTIONS
Tab connected to pin 4
August 1998
7
6
5
4
3
2
1
Non-inverting Input
Output Stage Supply
Output
GND or Negative Supply
Flyback Supply
Supply Voltage
Inverting Input
9379F-01.EPS
1/5
Page 2
STV9379F
BLOCK DIAGRAM
OUTPUT
SUPPLY
VOLTAGE
STAGE
SUPPLY
2 6 3
FLYBACK
SUPPLY
INVERTING INPUT
NON-INVERTING INPUT
1
7
STV9379F
POWER
AMPLIFIER
THERMAL
PROTECTION
4
GROUND or NEGATIVE SUPPLY
5
OUTPUT
ABSOL UT E MAXIMUM RA T ING S
Symbol Parameter Value Unit
V
V
, V7Amplifier Input Voltage (Pins 1-7) (see note 1) - 0.3, + V
V
1
I
I
I
V
ESD
- V2Voltage Difference between Flyback Supply and Supply Voltage 50 V
V
3
T
oper
T
T
Notes :
Supply Voltage (Pin 2) (see note 1) 50 V
S
Flyback Peak Voltage (Pin 6) (see note 1) 100 V
6
S
Maximum Output Peak Current (see notes 2 and 3) 1.5 A
O
Maximum Sink Current (t < 1ms) 1.5 A
3
Maximum Source Current (t < 1ms) (in the diode, see Block Diagram)
3
(see note 2)
1.5 A
ESD susceptibility : EIAJ Norm (200pF discharged through 0Ω)300V
Operating Ambient Temperature - 20, + 75
Storage Temperature - 40, + 150
stg
Junction Temperature +150
j
1. Versus Pin 4.
2. The output current can reach 4A peak for t ≤ 10µs (up to 120Hz).
3. Provided SOAR is respected (see Figures 1 and 2).
9379F-02.EPS
V
o
C
o
C
o
C
9379F-01.TBL
THERMAL DATA
Symbol Parameter Value Unit
2/5
R
th (j-c)
T
∆
T
Junction-case Thermal Resistance Max. 3
Temperature for Thermal Shutdown 150
t
Hysteresis on T
T
t
Recommended Max. Junction Tempe rature 120
jr
t
10
o
C/W
o
o
o
C
C
C
9379F-02.TBL
Page 3
STV9379F
ELECTRICAL CHARACTERISTICS
= 42V, TA = 25oC, unless otherwise specified)
(V
S
Symbol Parameter Test Conditions Min. Typ. Max. Unit
V
V
I
V
∆
V
GV Voltage Gain 80 dB
V
V
V
D5 - 6
V
D3 - 6
V
Operating Supply Voltage Range Versus Pin 4 10 42 V
S
Operating Flyback Supply Voltage (V3M ≤ VS + 50V) Versus Pin 4 V
3M
Pin 2 Quiescent Current I3 = 0, I5 = 0 13 20 mA
I
2
Pin 6 Quiescent Current I3 = 0, I5 = 0 5 10 30 mA
I
6
Max. Operating Peak Output Current 1.0 A
O
Amplifier Bias Current V1 = 22V, V7 = 23V - 0.15 - 1
I
1
Amplifier Bias Current V1 = 23V, V7 = 22V - 0.15 - 1
I
7
Offset Voltage 7mV
IO
/dt Offset Drift versus Temperature - 10
IO
Output Saturation Voltage to GND (Pin 4) I5 = 1.0A 1 1.5 V
5L
Output Saturation Voltage to Supply (Pin 6) I5 = - 1.0A 1.6 2.1 V
5H
S
90 V
Diode Forward Voltage between Pins 5-6 I5 = 1.0A 1.5 2.0 V
Diode Forward Voltage between Pins 3-6 I3 = 1.0A 1.6 2.0 V
Voltage Drop between Pins 3-6 (2nd part of flyback) I3 = - 1.0A 2.6 3.0 V
3-6
µ
V/oC
µ
A
µ
A
9379F-03.TBL
APPLICATION CIRCUITS
AC COUPLING
Ly
< Rd <
(*)
m
s
50
+V
S
Flyback
2 6
R5
1
7
V
REF
STV9379F
Ly
m
s
20
POWER
AMPLIFIER
4
3
THERMAL
PROTECTION
R3
R2
5
R4
Supply
W
1.5
F
m
0.22
Rd (*)
C
L
R1
Ly
Yoke
9379F-03.EPS
3/5
Page 4
100
90
80
70
60
25 50 75 100 125
ISB (%)
T
case
(˚C)
STV9379F
APPLICATION CIRCUITS
DC COUPLING
+
V
REF
Vertical
Position
Adjustment
Ly
< Rd <
(*)
50
m
s
Figure 1 :
Output Transistors SOA
(for secondary breakdown)
I
(A)
C
10
@ T
case
= 25˚C
(continued)
R5
Ly
20
m
s
2 6
1
7
STV9379F
POWER
AMPLIFIER
-V
EE
4
+V
S
3
THERMAL
PROTECTION
Figure 2 :
Flyback
Supply
5
R2
W
Rd (*)
1.5
F
m
0.22
Ly
Yoke
R1
Secondary Breakdown Temperature
Derating Curve
(ISB = secondary breakdown current)
9379F-04.EPS
1
-1
10
t = 1ms
t = 10ms
t = 100ms
-2
10
11010
4/5
V(V)
CE
2
9379F-05.EPS
9379F-06.EPS
Page 5
STV9379F
PACKAGE MECHANICAL DATA :
7 PINS - PLASTIC HEPTAW ATT
Dimensions Millimeters Inches
Min. Typ. Max. Min. Typ. Max.
A 4.8 0.189
C 1.37 0.054
D 2.4 2.8 0.094 0.110
D1 1.2 1.35 0.047 0.053
E 0.35 0.55 0.014 0.022
F 0.6 08 0.024 0.031
F1 0.9 0.035
G 2.41 2.54 2.67 0.095 0.100 0.105
G1 4.91 5.08 5.21 0.193 0.200 0.205
G2 7.49 7.62 7.8 0.295 0.300 0.307
H2 10.4 0.409
H3 10.05 10.4 0.396 0.409
L 16.97 0.668
L1 14.92 0.587
L2 21.54 0.848
L3 22.62 0.891
L5 2.6 3 0.102 0.118
L6 15.1 15.8 0.594 0.622
L7 6 6.6 0.236 0.260
M 2.8 0.110
M1 5.08 0.200
Dia. 3.65 3.85 0.144 0.152
