Page 1
Your Imagination, Our Creation
GL640USB
GL640USB-A
IEEE-1284 to USB Bridge
SPECIFICATION 1.1
June 7, 1999
Genesys Logic, Inc.
10F, No.11, Ln.3, Tsao Ti Wei, Shenkeng, Taipei, Taiwan
Tel: +886-2-2664-6655 Fax: +886-2-2664-5757
http://www.genesyslogic.com
Page 2
GL640USB, GL640USB-A
Index
1. Features..................................................................................................................2
2. Description..............................................................................................................3
3. IEEE 1284 Interface................................................................................................3
4. Pin Configuration ....................................................................................................4
5. Pin Descriptions......................................................................................................5
6. Block Diagram......................................................................................................... 7
7. 8-BIT RISC MCU INSTRUCTION...........................................................................9
7.1 MEMORY ORGANIZATION..............................................................................9
7.2 MCU FUNCTION REGISTERS ....................................................................... 11
7.3 I/O Register Summary.....................................................................................15
7.4 USB Register Summary................................................................................... 22
8. INSTRUCTION SET SUMMARY..........................................................................27
9. Advantages of GL640USB.................................................................................... 30
10. EPP Timing...........................................................................................................31
10.1 EPP Burst Data Write....................................................................................31
10.2 EPP Burst Data Read.................................................................................... 32
11. Electrical Characteristics.......................................................................................33
11.1 Absolute Maximum Ratings (Voltages referenced to GND)........................... 33
11.2 DC Characteristics (Digital Pins)....................................................................33
11.3 DC Characteristics (VCP/D+/D-).................................................................... 34
11.4 Switching Characteristics...............................................................................35
12. Package...............................................................................................................36
Revision 1.1 Jun. 7, 1999
-1-
Page 3
GL640USB, GL640USB-A
1.
Features
Ø Low-cost solution for full-speed USB device
Ø Applications – Printer, Scanner, PC Camera, External Storage Device, CD-ROM
Ø IEEE 1284 interface supports bi-directional communication
Ø On-chip EPP engine
Ø On-chip 8-bit micro-controller
Ø USB Specification Compliance
− Conforms to USB 12Mbps Specification, Version 1.0
− Supports 1 device address and 4 endpoints
Ø 2 sets of 64-byte FIFO with dynamic allocation
− a. 64-In/64-Out
− b. 64-In0/64-In1 ping pong buffer
− c. 64-Out0/64-Out1 ping pong buffer
Ø Integrated USB transceiver
Ø On-chip 3.3v regulator
Ø Improved output drivers with slew-rate control to reduce EMI
Ø 12MHz external clock
Ø On-chip PLL to support 48MHz internal clock
Ø Internal power-on reset(POR)
Ø Supports suspend/normal mode power management
Ø Customized firmware/driver for scanner application
Ø The driver allows current Win98/Win95 OSR-2 printer drivers to print seamlessly to USB
Ø Fully plug & play compatible
Ø Single-chip solution in cost saving 40-pin SOJ(GL640USB) / 48-pin LQFP(GL640USB-A)
Ø Special pad-design to support EPP/USB dual-interface application
Revision 1.1 Jun. 7, 1999
-2-
Page 4
GL640USB, GL640USB-A
2.
Description
The GL640USB is a low-cost, single-chip embedded controller designed for connecting an IEEE 1284 parallel port
peripheral to USB. It is suitable for applications where the IC is mounted on a PCB inside a product or stand-alone
applications where the chip resides in a cable connecting a standard parallel port device to an USB-capable computer.
The GL640USB firmware/driver will allow peripheral vendors to easily migrate parallel port device to USB.
IEEE 1284 Interface
33..
GPI1-4
EPP
DEVICE
ASIC
GPIO1-7
INIT#
WR#
WAIT#
ASTRB#
DSTRB#
AD[7:0]
INT#
CLKOUT
HRST
GL640USB
VCP
D+
D-
3.3V output
USB Port
OSCSEL
Revision 1.1 Jun. 7, 1999
CLK12/48
-3-
Page 5
GL640USB, GL640USB-A
Pin Configuration
44..
40-SOJ
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
CLKOUT
HRST
WR#
WAIT#
D0
D1
D2
D3
DVCC
DGND
D4
D5
D6
D7
VCP
D+
DAVCC
AGND
GPI1
ASTRB#
DSTRB#
INIT#
GPIO7
GPIO6
GPIO5
GPIO4
GPIO3
DGND
DVCC
GPIO2
GPIO1
INT#
TEST#
GPI4
OSCSEL
X1
X2
GPI3
GPI2
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
48-LQFP
30
31
32
33
34
35
36
DVCC
DGND
DGND
DVCC
GPIO2
37
38
39
40
41
42
43
44
45
46
47
48
GPIO7
INIT#
NC
DSTRB#
ASTRB#
NC
CLKOUT
NC
HRST
NC
WR#
WAIT#
GPIO5
GPIO6
GPIO3
GPIO4
29
GPIO1
28
27
INT#
D6
25
26
GPI4
TEST#
VCP
X1
OSCSEL
NC
X2
GPI3
GPI2
NC
NC
GPI1
AGND
NC
AVCC
D-
D+
24
23
22
21
20
19
18
17
16
15
14
13
Revision 1.1 Jun. 7, 1999
6
5D34D23D12D01
9D58D47
12
11D710
-4-
Page 6
GL640USB, GL640USB-A
uit, this pin can be left unconnected or
3.3 V output. This output voltage is used to pull up D+ line to indicate
Pin Descriptions
55..
GL640USB
Pin No.
1 43 CLKOUT O Clock output to external device
2 45 HRST I High active hardware reset, internal pull low
3 47 WR# O This active low signal indicates the EPP write operation.
4 48 WAIT# I this signal acts as the acknowledge from external EPP device, internal
5-8 1-4 D0-D3 I/O Address/Data bus bit 0 to bit 3
9 5 DVCC - Digital 5V input
10 6 DGND - Digital ground
11-14 7-10 D4-D7 I/O Address/Data bus bit 4 to bit 7
15 11 VCP -
GL640USB-A
Pin No.
SYMBOL I/O
The clock frequency is selected by setting DEVCTL register.
With internal power-on reset circ
pulled low.
pull up
the full-speed device.
DESCRIPTION
16 12 D+ I/O USB differential data
17 13 D- I/O USB differential data
18 14 AVCC - Analog 5V input
19 16 AGND - Analog ground
20 17 GPI1 I General purpose input 1
21 20 GPI2 I General purpose input 2
22 21 GPI3 I General purpose input 3
23 22 X2 I/O Crystal output
24 24 X1 I 12/48 MHz crystal or external clock input
25 25 OSCSEL I Oscillator Select, internal pull down
0=12MHz 1=48MHz
26 26 GPI4 I General purpose input 4, internal pull up
Revision 1.1 Jun. 7, 1999
-5-
Page 7
GL640USB, GL640USB-A
27 27 TEST# I Mode select, internal pull up
1=Normal Mode 0=Chip Test Mode
28 28 INT# I this is an input pin to accept the interrupt signal from external EPP
controller, internal pull up
29 29 GPIO1 I/O this signal is served as an general purpose I/O pin, internal pull up
30 30 GPIO2 I/O this signal is served as an general purpose I/O pin, internal pull up
31 31 DVCC - Digital 5V input
32 32 DGND - Digital ground
33 33 GPIO3 I/O this signal is served as an general purpose I/O pin, internal pull up
34 34 GPIO4 I/O this signal is served as an general purpose I/O pin, internal pull down
35 35 GPIO5 I/O this signal is served as an general purpose I/O pin
36 36 GPIO6 I/O this signal is served as an general purpose I/O pin
37 37 GPIO7 I/O this signal is served as an general purpose I/O pin
38 38 INIT# O output signal to initialize the EPP device.
39 40 DSTRB# O EPP data strobe
40 41 ASTRB# O EPP address strobe
Revision 1.1 Jun. 7, 1999
-6-
Page 8
GL640USB, GL640USB-A
Block Diagram
66..
Register
EPP
Engine
I/O
GL640USB
Micro Controller
USB Control
Register
ENDP0
FIFO
USB
SIE
FIFO0
(64 bytes)
FIFO1
(64 bytes)
This USB controller contains 3 sets of FIFO. The ENDP0 FIFO is an 8-byte FIFO to store/transmit the
endp0 control packet. The FIFO0 and FIFO1 are a set of 64-byte ping-pong FIFO for endp1 and endp2. FIFO0
is used for DATA0 packet and FIFO1 is for DATA1 packet. When they are served as the endp1 FIFO, the
LINKFF bit of FFCFG should be set and LINKDIR bit of FFCFG should be cleared. It they are allocated as the
endp1 FIFO, then LINKDIR should be set.
An EPP engine is included to automatically accessing data to/from external device ASIC. Firmware can set
the data length and hardware will count down to decide the last byte.
There are two sets of registers : I/O register and USB register. The USB register is controlled by
micro-controller to implement the USB endpoint 0 functions. The I/O register is the main register to interface the
data accessing between this controller and external device.
Revision 1.1 Jun. 7, 1999
-7-
Page 9
GL640USB, GL640USB-A
The internal micro-controller is a proprietary RISC-like, Harvard-architecture 8-bit micro-controller.
Revision 1.1 Jun. 7, 1999
-8-
Page 10
GL640USB, GL640USB-A
8-BIT RISC MCU INSTRUCTION
77..
7.1 MEMORY ORGANIZATION
The memory in the microcontroller is organized into user program memory in program ROM and
data memory in SRAM space.
Program Memory Organization
The 11-bit Program Counter (PC) is capable of addressing 2.25K x 14 of program space.
However, the program space of the GL640USB is 2K x 14. The program memory space is
divided into two functional groups: Interrupt Vectors and program code. After a reset, the
Program Counter points to location zero of the program space. After a timer interrupt, the
Program Counter points the location 0x0004 of the program space.
After Reset
0x0000 Reset Vector
After Timer
Interrupt
0x0005
0x07FF
Figure 7-1 Program Memory Space
Address
→
0x0004 Timer Interrupt Vector
→
2K x 14 ROM
Revision 1.1 Jun. 7, 1999
-9-
Page 11
GL640USB, GL640USB-A
Data Memory Organization
The data memory is partitioned into two Banks which contain the General Purpose Registers,
MCU Function Registers and USB Function Registers. Bit RP0 is the bank select bit.
RP0 (STATUS<5>) = 1 → Bank 1
RP0 (STATUS<5>) = 0 → Bank 0
The lower locations of each Bank are reserved for MCU Function Registers. Above the MCU
Function Registers are the USB Registers, I/O Registers and General Purpose Registers
implemented as SRAM. Both Bank 0 and Bank 1 contain MCU Function Registers. USB
Registers are located in Bank 0, and I/O Resgiters are located in Bank 1. Some “high use” MCU
Function Registers from Bank 0 are mirrored in Bank 1 for code reduction and quicker access.
Data
Memory
Address
Data
Memory
Address
00h INDR 80h INDR
01h TIMER 81h PSCON
02h PCL 82h PCL
03h STATUS 83h STATUS
04h INDAR 84h INDAR
05h 85h
06h PORT1 86h PORT1CO
N
07h PORT2 87h PORT2CO
N
08h 88h
09h 89h
0Ah PCHBUF 8Ah PCHBUF
0Bh INTEN 8Bh INTEN
10~1Fh
20h
Revision 1.1 Jun. 7, 1999
USB
Registers
General
90h~9Fh
-10-
I/O
Registers
Page 12
GL640USB, GL640USB-A
5Fh
Purpose
Registers
(64 bytes)
Figure 7-2 Data Memory Space
7.2 MCU FUNCTION REGISTERS
Address
00h INDR Addressing this location will use the content of INDAR to
01h TIMER Timer register
02h PCL Program Counter’s low byte
03h STATUS Status register
Name Function
address data memory (not a physical address)
04h INDAR Indirect address register
06h PORT1 Port 1 data register
07h PORT2 Port 2 data register
0Ah PCHBUF Write buffer of Program Counter’s bit 10-8
80h INDR Addressing this location will use the content of INDAR to
address data memory (not a physical address)
81h PSCON Prescaler control register
82h PCL Program Counter’s low byte
83h STATUS Status register
84h INDAR Indirect address register
86h PORT1CON Port 1 direction control register
87h PORT2CON Port 2 direction control register
8Ah PCHBUF Write buffer of Program Counter’s bit 10-8
Table 7-1 MCU Function Register Summary
INDR (Address 00h/80h)
INDR is not a physical register. Addressing INDR register will cause indirect addressing. Any
Revision 1.1 Jun. 7, 1999
-11-
Page 13
GL640USB, GL640USB-A
instruction using the INDF register actually accesses the register pointed by the INDAR register.
TIMER (Address 01h, Timer register)
R/W R/W R/W R/W R/W R/W R/W R/W
TIMER7 TIMER6 TIMER5 TIMER4 TIMER3 TIMER2 TIMER1 TIMER0
After timer is enable, the timer will start to count up. The Timer Interrupt is generated when the
TIMER register overflows from FFh to 00h.
Value on POR: “0 0 0 0 0 0 0 0”
PCL (Address 02h/82h, Program Counter’s low byte)
R/W R/W R/W R/W R/W R/W R/W R/W
PCL7 PCL6 PCL5 PCL4 PCL3 PCL2 PCL1 PCL0
The Program Counter (PC) is 11-bit wide. The low byte comes from the PCL register, which is a
readable and writable register. The high byte is not directly readable or writable and comes from
PCHBUF. The GL600USB has a 4 level deep x 11-bit wide hardware stake. The stake space is
not part of either program or data space and the stack pointer is not readable or writable. The PC
is pushed onto the stack when a CALL instruction is executed or an interrupt causes a branch. The
stack is poped in the event of a RETIA, RETI or a RET instruction execution. PCHBUF is not
affected by a push or pop operation.
Value on POR: “0 0 0 0 0 0 0 0”
Status (Address 03h, Status register)
R/W R/W R/W R/W
BS ZO HC CA
BS: Bank Select
1: Bank 1 (80h-FFh)
0: Bank 0 (00h-7Fh)
ZO: Zero bit
1: The result of an arithmetic or logic operation is zero
0: The result of an arithmetic or logic operation is not zero
HC: Half Carry/Borrow bit
1: A carry-out from the 4th low order bit
Revision 1.1 Jun. 7, 1999
-12-
Page 14
GL640USB, GL640USB-A
0: No carry-out from the 4th low order bit
CA: Carry/Borrow bit
1: A carry-out from the most significant bit
0: No carry-out from the most significant bit
Value on POR: “- - 0 - - 0 0 0”
INDAR: (Address 04h/84h, Indirect address register)
R/W R/W R/W R/W R/W R/W R/W R/W
INDAR7 INDAR6 INDAR5 INDAR4 INDAR3 INDAR2 INDAR1 INDAR0
Any instruction using the INDF register actually accesses the register pointed by the INDAR
register.
Value on POR: “x x x x x x x x”
[1]
Note 1: “x” means unknown
PORT1 (Address 06h, Port 1 data register)
R/W R/W R/W R/W R/W
PORT1.4 PORT1.3 PORT1.2 PORT1.1 PORT1.
0
PORT1 is a 5-bit latch for Port 1. Reading the PORT1 register reads the status of the pins whereas
writing to it will write to the port latch. All write operations are read-modify-write operations.
Value on POR: “- - - x x x x x”
PORT2 (Address 07h, Port 2 data register)
R/W R/W R/W R/W R/W R/W R/W R/W
PORT2.7 PORT2.6 PORT2.5 PORT2.4 PORT2.3 PORT2.2 PORT2.1 PORT2.
0
PORT2 is an 8-bit latch for Port 2. Reading the PORT2 register reads the status of the pins
whereas writing to it will write to the port latch. All write operations are read-modify-write
operations.
Value on POR: “x x x x x x x x”
PCHBUF (Address 0Ah/8Ah, Write buffer of Program Counter’s bit 10-8)
R/W R/W R/W
Revision 1.1 Jun. 7, 1999
-13-
Page 15
GL640USB, GL640USB-A
PCHBU
F2
PCHBU
F1
PCHBU
F0
Write buffer for upper 3-bit of Program Counter. The upper byte of Program Counter is not
directly accessible. PCHBUF is a holding register for the PC[10:8] whose contents are transferred
to the upper byte of the Program Counter.
Value on POR: “- - - - - 0 0 0”
INTEN (Address 0Bh/8Bh, Interrupt enable register)
R/W R/W R/W
GIE TMROE
TMROF
N
GIE: Global interrupt enable bit
1: Enable all interrupts
0: Disable all interrupts
TMROEN: Timer overflow interrupt enable bit
1: Enable timer interrupt
0: Disable timer interrupt
TMROF: Timer overflow interrupt flag bit
1: Timer register has overflowed
0: Timer register did not overflow
Value on POR: “0 - 0 - - 0 - -“
PSCON (Address 81h, Prescaler control register)
R/W R/W R/W R/W
PSDIS PS2 PS1 PS0
PSEN: Prescaler disable bit
1: Disable prescaler for timer
0: Enable prescaler for timer
PS[2:0]: Prescaler rate select bits
Bit Value Timer Rate
000 1:2
001 1:4
Revision 1.1 Jun. 7, 1999
-14-
Page 16
GL640USB, GL640USB-A
010 1:8
011 1:16
100 1:32
101 1:64
110 1:128
111 1:256
Value on POR: “- - - - 1 1 1 1”
PORT2CON (Address 86h, Port 1 direction control register)
R/W R/W R/W R/W
P1CON3 P1CON2 P1CON1 P1CON0
All Port 1 pins have data direction control bits which can configure these pins as output or input.
Setting a PORT1CON register bit put the corresponding output driver in a hi-impedance mode.
Clearing a bit in the PORT1CON register puts the contents of the output latch on the selected pin.
Value on POR: “- - - - 1 1 1 1”
PORT2CON (Address 87h, Port 2 direction control register)
R/W R/W R/W R/W R/W R/W R/W R/W
P2CON7 P2CON6 P2CON5 P2CON4 P2CON3 P2CON2 P2CON1 P2CON0
All Port 2 pins have data direction control bits which can configure these pins as output or input.
Setting a PORT2CON register bit put the corresponding output driver in a hi-impedance mode.
Clearing a bit in the PORT2CON register puts the contents of the output latch on the selected pin.
Value on POR: “1 1 1 1 1 1 1 1”
7.3 I/O Register Summary
Mnemonic Address
Description
(Hex)
IODEVCTL 90 device control for I/O
ENDPCTL 91 endpoint control
GPI 92 GPI3-1 register
Revision 1.1 Jun. 7, 1999
-15-
Page 17
GL640USB, GL640USB-A
INTFLG 93 interrupt flag
UINTEN 94 USB interrupt enable
USBFLG 95 USB interrupt flag
CTLDAT/
96 Control/status data buffer
STSDAT
CTLLEN/
97 Control/status data length
STSLEN
FFCFG 98 FIFO configuration register
FFCTL 99 FIFO control
FF0DAT 9A data port for FIFO0
FF1DAT 9B data port for FIFO1
LINE_L 9C Read : max. length of TX data packet
Write : line size (low byte)
LINE_H 9D Read : received data length /
Write : line size (high byte)
EPPCTL 9E EPP control / status
EPPAD 9F EPP interface AD0-7
IODEVCTL (offset 90h)
R/W R/O R/O R/O R/W R/W R/W R/O
EXTCLK
EN
CLKTYP - select crystal frequency, this bit reflects the OSCSEL pin
ENDPCTL (offset 91h)
Revision 1.1 Jun. 7, 1999
NC NC GPI4 CKSEL2 CKSEL1 CKSEL0 CLKTYP
0 - 12MHz, 1 - 48MHz
CKSEL[2:0] - select CLKOUT frequency, default=8MHz
000 - stop CLKOUT 100 - 8MHz
001 - 24MHz 101 - 6MHz
010 - 16MHz 110 - 12KHz
011 - 12MHz
GPI4 - this bit reflects the status of GPI4 input pad
EXTCLKEN - Enable EXTCLK output
0 – set EXTCLK to tri-state 1- enable EXTCLK
-16-
Page 18
GL640USB, GL640USB-A
R/W R/W R/W R/W
EP3STL EP2STL EP1STL EP0STL
Default=8’h00
EPnSTL - Endpoint n is stalled
By setting EPnSTL to ‘1’, endpoint n will respond with a STALL to incoming
USB packet.
GPI (offset 92h)
R/O R/O R/O
GPI3 GPI2 GPI1
INTFLG ( offset 93h )
R/O R/W1C R/W1C R/W1C R/O R/O R/W1C R/W1C
Reserved RESUME SUSPND EPPINT Reserved EP3TX DATARX DATATX
Default=8’h00
This register is used to identify the exact interrupt event. When the external controller receives an interrupt, it
should first read this register to check the interrupt event. Writing ‘1’ to clear the individual interrupt bit.
DATATX - The endp1 transmits a data packet completely
DATARX - The endp2 receives a data packet
EP3TX - Endp3 transaction is detected
EPPINT - This bit means external EPP interrupt is detected.
The EPPTXEN/EPPRXEN is cleared by hardware when this bit is set.
SUSPND - USB suspend request is detected.
RESUME - USB resume request is detected.
UINTEN ( offset 94h )
R/W R/W R/W R/W R/O R/W R/W R/W
FFINT REMINT SUSINT DMAINT Reserved UINTEN DRXINT DTXINT
These are the interrupt enable bits of INTFLG register.
Default = 8’h00
USBFLG ( offset 95h )
R/W1C R/O R/O
Revision 1.1 Jun. 7, 1999
-17-
Page 19
GL640USB, GL640USB-A
STSTX Reserved Reserved
Default=8’h00
STSTX - The interrupt endpoint 3 transmits a status packet completely
CTLDAT/STSDAT ( offset 96h )
R/W R/W R/W R/W R/W R/W R/W R/W
CTLDAT7 CTLDAT6 CTLDAT5 CTLDAT4 CTLDAT3 CTLDAT2 CTLDAT1 CTLDAT0
Read: Pop data from endp0/endp3 FIFO.
Write: Push data into endp0/endp3 FIFO.
CTLLEN/STSLEN ( offset 97h )
R/O R/O R/W R/W R/W R/W R/W
RXSETUP RXOUT
DATOG
CTLLEN3 CTLLEN2 CTLLEN1 CTLLEN0
For the received OUT/SETUP transaction on endp0/endp3, read this register to check the data size and data
toggle, and then read the received data from CTLDAT/STSDAT register. To transmit data on endp0/endp3, first
push data into endp0/endp3 FIFO, and then write this register to set data size and data toggle. Finally, turn on
CTLTXEN or STSTXEN bit to enable the data transmission.
CTLLEN3-0 - Length of the received/transmitted endp0/endp3 data
DATOG - Data toggle of the received/transmitted endp0/endp3 data
RXOUT - The received transaction is an OUT transaction
RXSETUP - The received transaction is a SETUP transaction
FFCFG ( offset 98h )
R/W R/W R/W R/W R/W R/W
TX64ONLY TXNULL DMARXEN/
EPPRXEN
DMATXEN/E
PPTXEN
LINKDIR LINKFF
Default=8’h00
This register is used to control TX/RX FIFO and DMA/EPP engine operation.
LINKFF - link RXFIFO to TXFIFO together to form ping-pong FIFO
LINKDIR - This bit is valid only when LINKFF is set to 1.
1: the ping-pong FIFO is used for end2
Revision 1.1 Jun. 7, 1999
-18-
Page 20
GL640USB, GL640USB-A
0: the ping-pong FIFO is used for end1
DMATXEN - enable DMA/EPP engine to access data into TXFIFO
DMARXEN - enable DMA/EPP engine to move data from RXFIFO into external
Device
TXNULL - Set this bit to transmit a zero-byte data on endp1
This bit will be cleared by hardware automatically.
TX64ONLY - Transmit 64-byte packet only
When this bit is set, data left in FIFO will not be sent if it is not
Note: When LINKFF is set and LINKDIR is gonna to change, LINKFF should be cleared to ‘0’ first and
then change LINKDIR and set LINKFF again.
FFCTL ( offset 99h )
64 bytes.
W/O W/O W/O R/W R/W R/W R/W R/W
FF0RST RXFFRST TXFFRST STSTXEN DRXDIS/
DTX1EN
DTX0EN CTLRXDIS CTLTXEN
CTLTXEN - enable endpoint 0 transmitting
This bit is cleared by hardware when CTLTX interrupt is set.
CTLRXDIS - disable endpoint 0 receiving
DTXEN - turn on this bit to enable endpoint 1 data packet transmission.
If LINKFF=1, it indicates the TXFIFO0 is ready.
This bit is cleared by hardware when DATATX interrupt is set.
DRXDIS - disable RXFIFO receiving
If this bit is set, NAK will be responded to the OUT token.
Data in RXFIFO is kept unchanged.
If LINKFF=1, this bit means the TXFIFO1 is ready.
STSTXEN - enable endpoint 3 transmitting
This bit is cleared by hardware when STSTX interrupt is set.
TXFFRST - reset TXFIFO, cleared by hardware itself.
RXFFRST - reset RXFIFO, cleared by hardware itself
FF0RST - reset CTL/STS FIFO, cleared by hardware itself
FF0DAT ( offset 9Ah )
Revision 1.1 Jun. 7, 1999
-19-
Page 21
GL640USB, GL640USB-A
R/W R/W R/W R/W R/W R/W R/W R/W
FFDAT7 FFDAT6 FFDAT5 FFDAT4 FFDAT3 FFDAT2 FFDAT1 FFDAT0
Read this register will pop data from FIFO0. Write this register will push data into FIFO0.
FF1DAT ( offset 9Bh )
R/W R/W R/W R/W R/W R/W R/W R/W
FFDAT7 FFDAT6 FFDAT5 FFDAT4 FFDAT3 FFDAT2 FFDAT1 FFDAT0
Read this register will pop data from FIFO1. Write this register will push data into FIFO1.
MAXLEN/LINE_L ( offset 9Ch )
R/W R/W R/W R/W R/W R/W R/W R/W
LINE7 LINE6 LINE5 LINE4 LINE3 LINE2 LINE1 LINE0
Read:
MAXLEN - Equal to 64
Write:
LINE_L - The low byte of EPP accessing length
DATLEN / LINE_H ( offset 9Dh )
R/W R/W R/W R/W R/W R/W R/W R/W
LINE15 LINE14 LINE13 LINE12 LINE11 LINE10 LINE9 LINE8
Read:
DATLEN - The length of data received by the RX endpoint
Write:
LINE_H - The high byte of EPP accessing length
EPPCTL ( offset 9Eh )
R/W R/W R/W R/W R/W R/W R/O R/W
GLTHFLT WRCHK ACTIVE A2CHK A1CHK A0CHK INT_ ADOE
This register is available only in EPP mode.
ADOE - Set this bit to ‘1’ can drive data in EPPAD register to
INT_ - This bit reflects the status of INT_ pin.
Revision 1.1 Jun. 7, 1999
pins D7-0
-20-
Page 22
GL640USB, GL640USB-A
AnCHK - This bit is used to select the type of EPP read engine
1 – EPP engine will check An pin before starting an EPP cycle.
0 – EPP engine doesn’t check An pin , n=0~2
ACTIVE - Select the An pin polarity
1 – active high for data ready 0 – active low for data ready
WRCHK - Select EPP check status during write or read
1- Check during EPP write cycle
0 – check during EPP read cycle
GLTHFLT - Filter glitches on WAIT_
1- Enable filter, performance maybe slow down
0 – Disable filter
EPPAD ( offset 9Fh )
R/W R/W R/W R/W R/W R/W R/W R/W
EPPAD7 EPPAD6 EPPAD5 EPPAD4 EPPAD3 EPPAD2 EPPAD1 EPPAD0
This register is used to set/read pins D7-0.
To set D7-0, except writing EPPAD, the ADOE bit of EPPCTL register is set to 1
Read this register can get the status of pins D7-0.
Revision 1.1 Jun. 7, 1999
-21-
Page 23
GL640USB, GL640USB-A
7.4 USB Register Summary
Mnemonic Offset Description Remarks
DEVCTL 10h Device control register
EVTFLG 11h USB function interrupt flag
DEVADR 12h USB Device address
RXCTL0 13h Endpoint 0 RX control
TXCTL0 14h Endpoint 0 TX control
CTLDAT 15h Endpoint 0/3 FIFO data port
MISC 16h Miscellaneous register
GPIO 17h GPIO value
GPIOCTL 18h GPIO direction control
DEVCTL ( offset 10h )
R/W R/W R/W R/W R/W
DISGLUSB EP0STL WAKE WAKEDIS PWRDN
Default=8’h10
PWRDN - Power down mode
WAKEDIS - Disable remote wakeup capability
WAKE - Wake up host
If USB suspend is detected, firmware can set PWRDN to put the controller into
power down mode. Power down mode stops oscillator and freezes all clocks at
known states, and no more command can be executed.
Hardware will automatically clear PWRDN upon hardware reset or interrupt
event.
Write ‘1’ to this bit will place USB bus to K state.
EP0STL - Endpoint 0 stall
DISGLUSB - Disable GL640USB, and bypass all EPP signals
Revision 1.1 Jun. 7, 1999
Endpoint 0 will respond with a STALL to a valid transaction.
-22-
Page 24
GL640USB, GL640USB-A
EVTFLG ( offset 11h )
W/O R/W1C R/W1C R/W1C R/W1C R/W1C
S_CTLRX WAKEUP RESUME SUSPD EP0TX EP0RX
This register is the main USB interrupt flag for endpoint 0 and power management. The firmware
detects endpoint 0 transaction via EP0RX and EP0TX. If firmware can’t handle the received endpoint 0
control data, then firmware should write ‘1’ to S_CTLRX and EP0RX. By this, the interrupt will redirect to
the external DMA interrupt and the CTLRX bit of USBFLG register will be set. For power management,
when a USB suspend is detected, the SUSPD bit will be set to ‘1’. If the USB host put the bus to ‘K’ state
during suspend, then the RESUME bit will be set to ‘1’. If a remote-wake-up event is detected, then the
When this bit is set to ‘1’, D+ and D- pin will be driven to low so that no connect
will be detected on the host side.
WAKEUP bit will be set to ‘1’.
All those interrupt status bits can be written ‘1’ to clear.
EP0RX - Endpoint 0 receives a data packet.
EP0TX - Endpoint 0 transmits a data packet completely.
SUSPD - USB suspend detected
RESUME - USB resume detected
WAKEUP- remote-wake-up event is detected during suspend state
The event is
S_CTLRX- Write 1 to set CTLRX bit of USBFLG
All the data in endp0/endp3 FIFO are left unchanged.
DEVADR ( offset 12h )
R/W R/W R/W R/W R/W R/W R/W
DMA mode: WAKEVT bit is set
EPP mode: INT_ pin is asserted low
DEVADR6 DEVADR5 DEVADR4 DEVADR3 DEVADR2 DEVADR1 DEVADR0
This register is used to set USB device address.
Default=8’h00
Revision 1.1 Jun. 7, 1999
-23-
Page 25
GL640USB, GL640USB-A
RXCTL0 ( offset 13h )
R/W R/O R/O R/O R/O R/O R/O R/O
RXDIS RXSETUP RXOUT RXSEQ RXCNT3 RXCNT2 RXCNT1 RXCNT0
Default=8’h0e
This register is used to check the received data byte count, data toggle, and transaction token on endpoint
0. When the EP0RX interrupt is detected, firmware should first check this register to decide the received
data is valid or not. At this time, RXDIS bit is set by hardware to prevent the current data in endp0 FIFO
overwritten by next incoming data. After extracting data from endp0 FIFO, firmware should clear RXDIS to
enable receiving capability on endp0.
RXCNT[3:0] - Received data byte count.
RXSEQ - 1 - The received data is DATA1
0 - The received data is DATA0
RXOUT - 1 - The received token is OUT.
RXSETUP - 1 - The received token is SETUP.
RXDIS - Disable receiving capability on endpoint 0
Note: Firmware must take care the data toggle check and decide if current RX data is valid.
TXCTL0 ( offset 14h )
R/W R/W R/W R/W R/W R/W
TXOE TXSEQ TXCNT3 TXCNT2 TXCNT1 TXCNT0
Default=8’h00
This register is used to control the data byte count, data toggle of the transmitted data on endpoint 0. If
Upon successfully receiving a data packet on endpoint 0, hardware will
automatically set this bit to ‘1’. At this time, no more SETUP/OUT data on
endpoint 0 can be accepted, hardware will respond with NAK.
0 - Endp0 FIFO is available for data receiving.
1 – Endp0 FIFO is not available
there is data to be sent to endpoint 0, firmware should first push data into FFDAT0 register, and then set the
pushed byte count to TXCNT3-0, set the data toggle to TXSEQ, and finally turn on TXOE to enable the data
transmission.
Revision 1.1 Jun. 7, 1999
-24-
Page 26
GL640USB, GL640USB-A
TXCNT3-0 - number of bytes to send
TXSEQ - 0 - TX DATA0 1 - TX DATA1
TXOE - ready to transmit control data
CTLDAT ( offset 15h )
R/W R/W R/W R/W R/W R/W R/W R/W
FFDAT7 FFDAT6 FFDAT5 FFDAT4 FFDAT3 FFDAT2 FFDAT1 FFDAT0
This register is the window to push/pop data from endp0/3 FIFO. Write to push FIFO, read to pop.
MISC ( offset 16h )
R/O R/O R/O R/O R/O W/O R/W R/W
SUSPD ADDR DEFLT POWER Reserved FFRST0 SF SUS_DIS
Default = 8’h10
This register is mainly used in testing purpose.
SUS_DIS - Disable suspend detection
SF - Short frame mode, used in suspend detection
0=normal mode, needs 3ms bus idle to enter suspend mode
1=short frame mode, needs only 200us to enter suspend mode
FFRST0 - Reset endpoint 0 FIFO read/write pointer.
POWER - Device is in the powered state
DEFLT - Device is in the default state
ADDR - Device is in the address state
SUSPD - Device is in the suspend state
GPIO ( offset 17h )
R/W R/W R/W R/W R/W R/W R/W
GPIO7 GPIO6 GPIO5 GPIO4 GPIO3 GPIO2 GPIO1
Data in FIFO remain unchanged.
GPIOCTL ( offset 18h )
R/W R/W R/W R/W R/W R/W R/W
GPIO7OE GPIO6OE GPIO5OE GPIO4OE GPIO3OE GPIO2OE GPIO1OE
Revision 1.1 Jun. 7, 1999
-25-
Page 27
GL640USB, GL640USB-A
GPIO and GPIOCTL registers are available only in EPP mode. GPIOCTL register determines pin
GPIO1-7 is input mode or output mode, GPIO register is used to set the output data to pin GPIO1-7 or read
data from pin GPIO1-7 input.
GPIOnOE - 1= set pin GPIOn to output mode
0= set pin GPIOn to input mode
Revision 1.1 Jun. 7, 1999
-26-
Page 28
GL640USB, GL640USB-A
CA, HC,
8.
INSTRUCTION SET SUMMARY
Operand Field Descriptions
Field Description
r Register address
A Accumulator
i Immediate data
b Bit address within a 8-bit register
Instruction Set
Mnemonic,
Description
Cycle
Flags
Operands
s
Affected
Arithmetic Operations
ADDAR r, A Add r and A, r <- r + A 1 CA, HC,
ZO
ADDAR A, r Add A and r, A <- A + r 1 CA, HC,
ZO
ADDAI i Add A and i, A <- A + i 1 CA, HC,
ZO
INCR r Increment r, r <- r +1 1 ZO
INCR A, r Increment r, A <- r + 1 1 ZO
INCRSZ r Increment r, r <- r +1, skip if (r = 0) 1 or 2
INCRSZ A, r Increment r, A <- r +1, skip if (A =
1 or 2
0)
SUBAR r, A Subtract A from r, r <- r - A 1 CA, HC,
ZO
SUBAR A, r Subtract A from r, A <- r - A 1 CA, HC,
SUBIA i Subtract A from i, A <- i - A 1
Revision 1.1 Jun. 7, 1999
ZO
-27-
Page 29
GL640USB, GL640USB-A
ZO
DECR r Decrement r, r <- r -1 1 ZO
DECR A, r Decrement r, A <- r -1 1 ZO
DECRSZ r Decrement r, r <- r-1, skip if (r = 0) 1 or 2
DECRSZ A, r Decrement r, A <- r – 1, skip if (A =
1 or 2
0)
CLRR r Clear r, r <- 0 1 ZO
CLRA Clear A, A <- 0 1 ZO
NOP No operation 1
Logical Operations
ANDAR r, A And r and A, r <- r & A 1 ZO
ANDAR A, r And A and r, A <- A & r 1 ZO
ANDAI i And A and i, A <- A & i 1 ZO
CMPR r Complement r, r <- r ^ FF 1 ZO
CMPR A, r Complement r, A <- r ^ FF 1 ZO
ORAR r, A Inclusive OR r with A, r <- r | A 1 ZO
ORAR A, r Inclusive OR A with r, A <- A | r 1 ZO
ORIA i Inclusive OR i with A, A <- A | i 1 ZO
XORAR r, A Exclusive OR r with A, r <- r ^ A 1 ZO
XORAR A, r Exclusive OR A with r, A <- A ^ r 1 ZO
XORIA i Exclusive OR i with A, A <- A ^ i 1 ZO
Bit-wise Operations
BCR r, b Bit clear r, r.b <- 0 1
BSR r, b Bit set r, r.b <- 1 1
BTRSC r, b Bit test r, skip if (r.b = 0) 1 or 2
BTRSS r, b Bit test r, skip if (r.b =1) 1 or 2
Data Movement Operations
MOV r, A Move A into r, r <- A 1
MOV A, r Move r into A, A <- r 1 ZO
MOVIA i Move i into A, A <- i 1
Shift Operations
SWAPR r Swap high and low nibbles in r 1
Revision 1.1 Jun. 7, 1999
-28-
Page 30
GL640USB, GL640USB-A
RLR r Rotate r left through C 1 CA
RRR r Rotate r right through C 1 CA
Control Transfer Operations
CALL i Call subroutine 2
JUMP i Jump to address 2
RETIA Return and load i to A 2
RETI Return from interrupt 2
RET Return from subroutine 2
Revision 1.1 Jun. 7, 1999
-29-
Page 31
GL640USB, GL640USB-A
Provide clock output, no other crystal required. The clock frequency can be 24, 16, 12,
Isolation capability. With this capability, a device can be designed to
al 7 GPIO pins and 4 GPI pins. These pins can be used as testing
Customized firmware: Contains a RISC controller with 2K ROM, user can
tisfy special
pong FIFO, the performance
Out can achieve 1.1 Mbytes/sec
Advantages of GL640USB
99..
Advantage Description
EMI consideration
Cost Saving 1.
Flexibility 1. Provide self-
1. Operates at 12MHz frequency to reduce EMI radiation
2. Slew rate controlled output pads:
All the transition on output pads are well controlled to reduce the EMI radiation.
8, 6 MHz
2. Build in power-on reset circuit. No reset circuit required.
3. Provide 3.3V output to pull-up USB bus
support both EPP and USB interface.
2. Provide addition
purpose, status indication, product selection, …and so on.
3.
developing its own firmware to achieve best performance and sa
applications
4. Support 93C46 to provide external VID and PID
Performance 1. Build in hardware EPP engine and 2 sets of 64 byte ping-
2. Balanced architecture: Both the Bulk-In and Bulk-
Revision 1.1 Jun. 7, 1999
for Bulk transfer will be up to 1.1 Mbytes /sec
transfer rate.
-30-
Page 32
GL640USB, GL640USB-A
EPP Timing
1100..
10.1 EPP Burst Data Write
DSTRB#
WR#
WAIT#
PD7-0
NAME Description Min Max UNIT
TA Wait# de-assert to DSTRB# de-assert 42 83 ns
TB End of EPP write cycle to beginning of next EPP write
cycle
TC Wait# assert to WR# de-assert 42 83 ns
TD WR# assert to data available 0 10 ns
TE WR# de-assert to data invalid 2 ns
83 83 ns
Revision 1.1 Jun. 7, 1999
-31-
Page 33
GL640USB, GL640USB-A
10.2 EPP Burst Data Read
DSTRB#
WR#
WAIT#
PD7-0
NAME Description Min Max UNIT
TA Wait# de-assert to DSTRB# de-assert 42 83 ns
TB Wait# assert to next DSTRB# assert 83 124 ns
TC Data available to DSTRB# deasserted 5 ns
TD DSTRB# de-assert to data invalid 5 ns
Revision 1.1 Jun. 7, 1999
-32-
Page 34
GL640USB, GL640USB-A
Leakage current for pads with internal pull up or pull down
Electrical Characteristics
1111..
11.1 Absolute Maximum Ratings (Voltages referenced to GND)
SYMBOL Description MIN MAX
VCC DC supply voltage -0.5V +7V
VI DC input voltage -0.5V VCC+0.5V
V
DC input voltage range for I/O -0.5V VCC+0.5V
I/O
V
DC input voltage for USB D+/D- pins -0.5 VCC+0.5V
AI/O
V
DC voltage applied to outputs in High Z state -0.5V VCC+0.5V
I/OZ
V
static discharge voltage 4000V
ESD
11.2 DC Characteristics (Digital Pins)
SYMBOL Description MIN TYP MAX UNIT
PD Power Dissipation 9 10 11 mA
VDD Power Supply Voltage 4.5 5.0 5.5 V
IO DC output sink current excluding D+/D-/VCC/GND 4 mA
VIL LOW level input voltage 0.9 V
VIH HIGH level input voltage 2.0 V
V
LOW to HIGH threshold voltage 1.7 1.8 2.0 V
TLH
V
HIGH to LOW threshold voltage 0.9 1.1 1.3 V
THL
V
Hysteresis voltage 0.6 0.7 0.85 V
HYS
VOL LOW level output voltage when IOL=4mA 0.4 V
VOH HIGH level output voltage when IOH=4mA 2.4 V
I
OLK
resistor
38 µA
RDN Pad internal pulldown resister (Note 1) 20K 28K 41K Ohms
RUP Pad internal pullup resister (Note 2) 24K 33K 48K Ohms
Revision 1.1 Jun. 7, 1999
-33-
Page 35
GL640USB, GL640USB-A
Note 1 : Pins with internal pullup resister : PIN3, 4, 26, 27, 28, 29, 30, 33, 38, 39, 40
Note 2 : Pins with internal pulldown resister: PIN25, 34
11.3 DC Characteristics (VCP/D+/D-)
SYMBOL Description MIN TYP MAX UNIT
V
VCP regulator output 3.0 3.3 3.6 V
3.3
I
VCP maximum supply current 27 41 56 mA
3.3
VOL D+/D- static output LOW(RL of 1.5K to 3.6V ) 0.3 V
VOH D+/D- static output HIGH (RL of 15K to GND ) 2.8 3.6 V
VDI Differential input sensitivity 0.2 V
VCM Differential common mode range 0.8 2.5 V
VSE Single-ended receiver threshold 0.2 V
CIN Transceiver capacitance 20 pF
ILO Hi-Z state data line leakage -10 +10 µA
Z
Driver output resistance 28 43 Ohms
DRV
Revision 1.1 Jun. 7, 1999
-34-
Page 36
GL640USB, GL640USB-A
11.4 Switching Characteristics
SYMBOL Description MIN TYP MAX UNIT
FX1 X1 crystal frequency 11.97 12 12.03 MHz
T
X1 cycle time 83.3 ns
CYC
T
X1 clock LOW time 0.45T
X1L
T
X1 clock HIGH time 0.45T
X1H
T
Output pad rise time from 10% to 90% swing with 30pF
r30pf
loading
T
Output pad fall time from 10% to 90% swing with 30pF
f30pf
loading
T
Output pad rise time from 10% to 90% swing with50pF
r50pf
loading
ns
cyc
ns
cyc
6 8 12 ns
5.3 7 10.4 ns
9.5 13 19 ns
T
Output pad fall time from 10% to 90% swing with 50pF
f50pf
7.7 10 16 ns
loading
T
D+/D- rise time with 50pF loading 4 20 ns
rUSB
T
D+/D- fall time with 50pF loading 4 20 ns
fUSB
Revision 1.1 Jun. 7, 1999
-35-
Page 37
GL640USB, GL640USB-A
1122..
Package
40-SOJ
UNIT : MIL
E
A 130 134 138
A1 0.24 - -
10TYP
SYMBOLS MIN NOR MAX.
A2 106 110 114
E 400 BSC.
D 1025 BSC.
H 430 440 450
H
Revision 1.1 Jun. 7, 1999
A
A2
-36-
A1
50TYP
D
25TYP
18TYP
Page 38
GL640USB, GL640USB-A
48-LQFP
SYVBOIS MIN MAX
A 1.6
A1 0.05 0.15
A2 1.35 1.45
C1 0.09 0.16
D 9.00BSC
D1 7.00BSC
E 9.00BSC
E1 7.00BSC
e 0.5BSC
b 0.17 0.27
L 0.45 0.75
L1 1 REF
Revision 1.1 Jun. 7, 1999
-37-
Page 39
GL640USB, GL640USB-A
D
D1
E1
E
b
e
C1
A2
A
0.25
L
L1
A1
Revision 1.1 Jun. 7, 1999
-38-
Loading...
