MP Nova

Direct Thermal Th ermal Tran sf er

M P Nova4 DT MP Nova4 TT

M P Nova6 DT MP Nova6 TT

M P Nova8 DT

Table of Contents

User Manual

1. Introduction

2. Safety

3. Product Presentation

4. Product Overview

5. Getting Started

4.1 In the Box

4.2 Printer Parts MP Nova4, 6 & 8 DT

4.3 Openin g and Closing the Cover of MP Nova4, 6 & 8 DT

4.4 Printer Parts MP Nova4 & 6 TT

4.5 Opening and Closing the Cover of MP Nova4 & 6 TT

5.1 Overview

5.2 Overview Peel-Off

5.3.1 Inserting Media MP Nova4 & 6

5.3.2 Inserting Media MP Nova8

5.4 Inserting Media - Peel-Off Kit

5.5 Inserting Ink Ribbon

5.6 Connecting

5.7 Test Print & Sensor Auto Adjustment

6. Operation

7. Maintenance

8. Troubleshooting

9. Changeable Parts

10. Pri nter Options and Spare Parts

11. Cons uma b les ( Media Gene ra l )

12. Technical Specification

6.1 Tearing the Media

6.2 Interpreting the Status Lamp – LED

6.3 Media Positioning Sensor Settings

6.4 Adjusting the Print Head

9.1 Replacing the Roller

9.2 Replacing the Print Head

10.1 Pell-Off Kit, LTS & 215 mm Kit

10.2 Consumables & Spare Parts

1. Introduction

Conditions

The MP Nova printers with their unique technology have been developed to offer a range of different applications. Thank you for choosing an Datamax printer for your business needs . T he hig h quality , user-frie ndli ness and simple maintenance procedures of the MP Nova direct thermal (DT) and thermal transfer (TT) printers make them the perfect choice.

Manufacturer Address:

Datamax Corporation

4501 Parkway Commerce Boulevard Orlando, Florida USA 32808 Phone (407) 578-8007 Fax (407) 578-8377

http://www.datamaxcorp.com

Conditions

Datamax reserves the right to change specifications in both the text and illustrations without prior notice. The contents of the publica tion may not be cop ied, either wholly or in part, withou t permission from Datamax.

Datamax is not responsible for any direct, indirect, specific, accidental or resultant injuries caused by a fault with the machine system or softwa re, or by an error in the accompanying documentation. In particular, Datamax cannot be h eld responsi ble for any program or data s tored or used with Datamax’s products, including the cost of recovering such programs or data.

Item number: 540430

2. Safety

Safety & Certification

Safet y Requirements

Datamax disclaims all responsibility regarding the CE directive if t he printer is used, altered or installed in any way oth er than described in this manual.

This symbol is used to indicate circumstances that may be dangerous to the user or that cause damage to the equipment.

Please Note the Following Warnings:

• Never use sharp or pointed tools when cleaning or replaci ng the pri nt head.

• Remember to handle the print head with care.

• Don't use any sharp objects to remove labels from the

print roller.

• The MP Nova printers have double fuses. The fuses are rated at 250 volt, 4.0 A, AT-type. Fuses must be ULapproved.

• The circuit board contains a battery. Used batteries should be disposed of in accordance with the manufacturer’s instruct ions.

• Please read all instructions before using the printer for the first time.

2. Safety

Safety & Certification

• The printer should be connected to the power supply indicated on the voltage plate. If you are unsure of the type of power supply available, please contact Datamax service personnel.

• The printer is equipped with a plug suitable for earthed sockets. This is a safety measure. If the plug does not fit the power socket, a qualified electrician must replace it.

• We do not recommend the use of extension cables.

The power cable must not be subjected to pressure. Ensure that the printer is not placed anywhere where the cable can be st ood on .

• Check that the power switch is off (in the ‘0’ position) before connecting the power cable.

• Do not use liquids or aerosols when cl eaning this printer. Always use Datamax’s special cleaning cloths.

• Do not attempt to open the electronic unit or other sealed parts! The user cannot service these parts.

• Never use sharp or pointed tools when cleaning or replaci ng the pri nt head.

• Do not use cables that exceed 5 meters in length for RS232-communication. Signals may be corrupted or lost as a result. This is particularly important in enviro nme nts where there are hig h levels of electrica l interference.

• Disconnect the power to the printer and call in qualified personnel under the following conditions:

 The power cable or plug is damaged or worn.  Liquid has been spilled on the printer.  Rain or water has got into the printer.  The printer is not functioning correctly despite that

the user has followed the instructions for use.

 You have dropped the printer or the casing has been

damaged.

 The printer is not functioning correctly and requires

service.

2. Safety

Safety & Certification

Machi ne S ign

Cert ification and Approvals

2. Safety

Safety & Certification

The MP Nova printers are certified in accordance with the requirements for CE marking. CE = European Commission

The MP Nova printers are UL-approved. UL = Underwriter Laboratories USA

CE Standards & Direct ives

MP Nova printers are subject to the following standards:

In accordance with European directives applicable to the products, that is to say:

• With the electromagnetic compatibility directive

EMC Directive 89/336/CEE with the European standards which are its technical answer.

• With the Low Voltage Directive 93/68/CEE and

with the European standards which are its technic al answer.

The above referenced product bears the CE mark.

3. Product Presentation

The MP Nova Series

Datamax achieves diversity with its thermal printers, the MP series. Powerful and intelligent with a multitude of functionality you would not expect from one of the smallest printers on the market.

They are built on a platform with advanced software, offering wide possibilities from simple local solutions to integrated solutions working over Internet.

Typical Applications:

Manufacturing

Warehousing

Healthcare

Transport

Ticketing

Printer Models

MP Nova4 DT, 200 dpi Item number: 745130. MP Nova4 DT, 300 dpi Item number: 745160.

MP Nova4 TT, 200 dpi Item number: 745140. MP Nova4 TT, 300 dpi Item number: 745165.

MP Nova6 DT, 200 dpi Item number: 765130.

MP Nova6 TT, 200 dpi Item number: 765140.

MP Nova8 DT, 200 dpi Item number: 785130.

4. Product Overview

4.1 In the Box

MP Nova4 DT & MP Nova6 DT

The following items should be included in the box when you receive your new MP Nova4 DT or MP Nova6 DT printer:

1. 1 x MP Nova4 DT or MP Nova6 DT

2. 1 x Cl eaning cloth

3. 1 x Communication cable (Serial RS 232)

4. 1 x Power cable

5. 1 x Media roll

6. 1 x Getting Started CD

4. Product Overview

4.1 In the Box

MP Nova4 TT & MP Nova6 T T

The following items should be included in the box when you receive your new MP Nova4 TT or MP Nova6 TT printer:

1. 1 x MP Nova4 TT or MP Nova6 TT

2. 1 x Cl eaning cloth

3. 1 x Communication cable (Serial RS 232)

4. 1 x Power cable

5. 1 x Media roll

6. 1 x Getting Started CD

7. 1 x Ink ribbon, loaded in the machine

4. Product Overview

4.1 In the Box

MP Nova8 DT

The following items should be included in the box when you receive your new MP Nova8 DT prin ter:

1. 1 x MP Nova8 DT

2. 1 x Cl eaning cloth

3. 1 x Communication cable (Serial RS 232)

4. 1 x Power cable

5. 1 x Fan-folded media

6. 1 x Getting Started CD

7. 1 x Allen key (2 mm) mounted underneath the fan-fold steering

4. Product Overview

4.2 MP Nova4, 6 & 8 DT – Printer Parts

1. Print button

2. Status lamp (LED)

3. Cover

4. Media roll

5. Roll steering

6. Roll guide lock

7. Media track

8. Handle

9. Communication ports

10. Unroll shaft

11. Power connection

12. Power switch

13. Fan-fold steering (MPNova8)

14. Allen Key (2 mm), mounted

underneath the fan-fold steering (MPNova8)

4. Product Overview

4.2 MP Nova4, 6 & 8 DT – Printer Parts

15. Print head

16. Print roll

17. Media P ositioning Sensor

(MPS)

18. Paper guide

19. Outer plate holder

4. Product Overview

4.3 Opening and Closing the Cover

Open M P Nova4, 6 & 8 DT

1. Pull handle.

2. Open cover.

4. Product Overview

4.3 Opening and Closing the Cover

Close MP Nov a4, 6 & 8 DT

1. Close cover.

2. Fol d han dle . ( Pr int hea d w ill

be engaged.)

Note: Make sure the handle is folded all the way down.

4. Product Overview

4.4 MP Nova4 & 6 TT – Printer Parts

Print button

2. Status lamp (LED)

3. Front cover

4. Rear cover

5. Media roll

6. Roll guide lock

7. Roll steering

8. Media track

9. Handle

10. Ink ri bbon guide

11. Rewind spool

12. Unwind spool

4. Product Overview

4.4 MP Nova4 & 6 TT – Printer Parts

13. Communication ports

14. Unroll shaft

15. Power connection

16. Power switch

4. Product Overview

4.5 Opening and Closing the Cover

Open M P Nova4 & 6 TT

Open cover. The inner cover

slides automatically up together with the cover.

4. Product Overview

4.5 Opening and Closing the Cover

Close MP Nova4 & 6 TT

Close cover. The inner cover

slides automatically down together with the cover.

5. Getting Started

5.1 Overview

MP Nova4, 6 & 8 DT MP Nova4 & 6 TT

1. Insert media, MPNova4 & 6 DT,

see chapter 5.3.1

1. Insert media. See MP Nova4 & 6 DT

(no 1) in th e left column.

2. Insert ink ribbon, see chapter 5.5.

Insert media, MPNova8 DT, see

chapter 5.3.2

2. Conn ecting, see chapter 5.6.

3. Run a test print, see chapter 5.7.

3. Conn ecting, see chapter 5.6.

Run a test print. See MP Nova4 & 6 DT

(no 3) in the left column.

5. Getting Started

5.2 Overview Peel-Off

MP Nova4 & 6 DT Peel-Of f MP Nova4 & 6 TT Peel- Off

1. Insert peel-off media, see chapter 5.4 1. Insert peel-off media. See MP Nova4

2. Conn ecting, see chapter 5.6.

& 6 DT Peel-off (no 1) in the left column.

2. Insert ink ribbon, see chapter 5.5.

Conn ecting, see chapter 5.6.

3. Run a test print, see chapter 5.7.

4. Run a test print. See MP Nova4 & 6

DT Peel -off (no 3) in the left column.

5. Getting Started

5.3.1 Inserting Media MP Nova4 & 6

Note:

The pictures shown describe an M P Nova4 DT. The process works just the same for MP

Nova6 DT and MP Nova4 & 6 TT.

1. Un do the roll guide lock.

2. Remove the roll guide from

the media shaft.

3. Pull handle to lift the print

head from the roller.

4. Po si tion a new media ro ll

onto the spool and insert the media from the side into the pri nter’s media trac k.

5. Check that the media is

aligned with the internal printer wall.

! Make sure the outer roll guide

suits the width of the media. If necessary, open the cover and adjust the outer roll guide. (Only necessary when changing media type.)

6. Put the roll guide on the

unroll shaft. Push it against the roll for optimum control.

5. Getting Started

5.3.1 Inserting Media MP Nova4 & 6

7. Lock the roll guide lock (turn the handle clockwise). The roll steering shall guide the roll, but shall not be tight.

! Note:

If the roll guide lock cannot be properly tightened (Note: no t too tight), lift the lock upwards, rotate it back half a turn, lower it and retighten.

8. Fold the handle (the print

head folds automatically onto the roller).

9. Press the print button a few

times until the printer automatically finds the correct position of the media.

Note: If necessary, make a test pri ntout and auto adj ust the media positioning sensor as described in chapter 5.7.

10. If you have an :

MP Nova4 or 6 DT : go to Test Print, chapter 5.7.

MP Nova4 or 6 DT Peel Off: go to Inserting Media Peel-Off Kit, chapter 5.4.

MP Nova4 or 6 TT: go to Inserting Ink Ribbon, chapter

5.5. MP Nova4 or 6 TT Peel Off:

go to Inserting Media Peel-Off Kit, chapter 5.4.

5. Getting Started

5.3.2 Inserting Media MP Nova8 DT

Adjusting the Fan-Fol d S teering

Note:

It is only n e cessary to adjust the fan-fold steering when changing media type.

1. An Allen key (2 mm) is

2. Loosen the Allen screw to

3. Position the fan-fold steering

4. Tighten the Allen screw to lock

5. Replace the Allen key.

mounted underneath the fanfold steering.

unlock the fan-fold steering.

to fit the width of the media.

the fan-fold steering in its new position.

5. Getting Started

5.3.2 Inserting Media MP Nova8 DT

Inser ting Media

1. Pull handle to lift the print

head from the roller.

2. Insert the media through the

fan-fold steering and through the printer.

Note:

Make sure the fan-fold st eering suits the width of the media. To adjust the steering se previous page.

Make sure the media is placed so that it will feed easily into the printer.

5. Getting Started

5.3.2 Inserting Media MP Nova8 DT

3. Pull out some of the media.

4. Fold the handle (the print

head folds automatically onto the roller).

5. Press the print button a few

times until the printer automatically finds the correct position of the media.

Note: If necessary, make a test pri ntout and auto adj ust the media positioning sensor as described in chapter 5.7.

5. Getting Started

5.4 Insert ing Media – Peel-Off Kit

Note:

The pictures shown describe an MP Nova4 DT Peel-Off. The process works just the same for

MP Nova4 & 6 TT Peel -Off & MP Nova6 DT Peel-Off.

First insert media. The peel-off media inserts in the same way as the media described in chapter 5.3.1 .

1. Lift the handle and then

pull, 40 cm of the label roll, out of the p rinter.

2. Fold the handle.

3. Remove all the labels on

the exposed section.

4. Pull the backi ng paper

under the printer.

5. Fold 2 cm of the backing

paper to make it slide more easily into the rewind unit slot

5. Getting Started

5.4 Insert ing Media – Peel-Off Kit

6. Open the rewind unit slot by

turning the knob clockwise while holding the cylinder firmly.

7. Slide the backing paper into

the rewind unit slot.

5. Getting Started

5.4 Insert ing Media – Peel-Off Kit

8. Close the rewind unit slot by

turning the knob counterclockwise w hile holdi ng the cylinder and backing paper firmly.

9. Roll the backing paper

around the rewi nd unit by turning the knob counterclockwise. This increases the tension of the backing paper.

10. Press the print button a

few times until t he printer automatically finds the correct position of the media.

Note: If necessary, make a test printout and auto adjust the media positioning sensor as described in chapter 5.7.

5. Getting Started

5.5 Inserting Ink Ribbon – MP Nova4 & 6 TT

1. Undo the handle and open

the cover.

2. Remove the old ink ribbon.

3. Slide the new ink ribbon on

to the spool.

4. Feed the ink ribbon under

the print head.

Note: Check that the inked side of the ribbon is facing downwards.

5. Getting Started

5.5 Inserting Ink Ribbon – MP Nova4 & 6 TT

5. Note: The ink ribbon must

not pass under the MPS (Media Positioning Sensor).

6. Move the empty roll, wh ich

will collect the used ink ribbon, up and around the pri nt head.

7. Slide the roll onto the take

up spool.

5. Getting Started

5.5 Inserting Ink Ribbon – MP Nova4 & 6 TT

8. Fold the handle.

9. Press the print button. The

ink ribbon will automaticall y wind around the rewind spool, thus tensioning the ink ribbon.

10. Close the cover.

5. Getting Started

5.6 Connecting

Note: This process works for all the MP Nova printers.

1. Make sure the printer is

switched off (the power switch is set to ‘0’).

2. Connect the communication

cable from th e PC to the printer. The connection cable enclosed is designed for communication port COM 1 and COM 2.

Note: Check that the cable is connected to the correct communication port (COM1, COM2, USB or LAN).

3. Connect the printer to the

mains supply.

4. Switch on the printer .

5. Wait until the lamp has

turned gree n.

5. Getting Started

5.7 Test Print & Sensor Auto Adjus tment

To be sure the printer is working, and to adjust the media positioning sensor, MPS, to the media, make a test printout:

1. Switch off the printer.

2. Press the print button.

Switch on the printer and keep pressing the print button unti l the whole printout is printed and then for another 7 seconds. This will start the sensor auto adjustment. Release the print button when auto adju stment starts.

3. Restart the printer to exit test

print mode. The new settings are saved automatically.

Note: If the patterns at the bottom of the test printout are missing, you released the print button too soon. Repeat the process.

4. If the text and the patterns

look nice, the printout is ok.

5. To skip the test print, turn off

the printer and wait 15 seconds before switching it on again.

In case of any trouble, go to Troubleshooting, chapter 8, for further information.

4. Operation

4.1

6. Operation

6.2 Interpreting the Status Lamp - LED

 Red

End of media roll, end of ink ribbon or the handle is not folded down. Note: The handle has to be folded all the way down.

 Red (flashing)

System temperature too high, printer has entered cool down state

 Yellow

Printer is starting up or is in test print mode. Note: Restart the printer to exit test print mode.

 Green

Ready to print

6. Operation

6.3 Media Positioning Sensor Settings

The MP Nova printers are equipped

with media pos iti o ning sensors (MPS). The MPS detects the media and can be set to three different modes depending on how and where gaps and marks are positioned on the media:

1. Outer sensor mode – detects label

gaps about 16 mm from the edge of the media. Note: This is the default setting.

2. Inner sensor mode – detects label

gaps about 5 mm from the edge of the media.

3. Black mark sensor – detects black

marks on the reverse side of the media, about 5 mm from the edge

Sensor mode Approximate sensor reading

point, from edge of media.

1. Outer (default) 16 mm

2. Inner 5 mm

3. Black mark 5 mm

of the media.

4. To change the settings, see the

Printer settings menu on the Getting started CD.

Note: Changes in the printer settings should be made by qualified personnel.

For more information about ticket, tag and label specifications, see the Media specification sheet.

6. Operation

6.4 Adjusting the Print Head

Adjusting Print Head Positi on

Note:

These adju stments ar e only necessary when changing to media with different thickness or width. The pictures shown describe an MP Nova4 DT. The process works the same for all MP Nova printers.

Changing the position of the adjustment screws can be necessary if the labels are very narrow

1. Check that the printer is turned

off. Open the cover and fold the handle.

2. Loosen the upper nut of the

adjustment screw you want to move by turning it counterclockwise.

3. Slide the adjustment screw into a

new position and tighten the upper nut. Pull the handle if sliding the adjustment screw past the finger nut.

4. Note: When tightening the upper

nut. Make sure it is pressing the sliding rail against the bottom of the notch and not against the lo wer n ut .

5. The adjustment screws should

make the print head press evenly onto the media. Make test prints to find the correct positions.

6. Operation

6.4 Adjusting the Print Head

6. Note: MP Nova4 DT only. On the MP Nova4 DT the position of the print head itself can be changed. As default there is a 3 mm non-printable area on the left side. To be able to print all the way to the edge of the label the margin has to be set to 0 mm. Pull the handle. Loosen the finger nut and slide the print head into position. Tighten the fi nger nut.

Adjusting Print Head Pr es s ure

7. To increase the pressure on the

pri nt head, tur n the lower nuts downwards (clockwise). This will tighten the spring.

8. To decrease the pressure on the

pri nt head, tur n the lower nuts upwards (counter-cloc kwise ).

Note:

To much pressure might damage the print head or make it wear out faster. The pressure should be as light as poss ible while mai ntaini ng high quality printing. Make test prints to find correct pressure.

7. Maintenance

Cleaning the Print Head and Roller

Only use cleaning cloths from Imaje. These are specially designed for cleaning Imaje thermal printers. See chapter 10.2 for correct type.

Note:

Frequent cleaning prevents print head and roller damage, and is especially important in demanding environments .

• Do not use liquids or aerosols when

cleaning this printer.

• Never use sharp or pointed tools

when cleaning or replacing the print head.

• Don't use any sharp object to

remove labels from the print roller.

Remove all media before starting:

1. Tear the bag.

2. Pull out the cleaning cloth.

3. Pull the handle and feed the cloth

into the printer in the same way as inserting the media (described in chapter 5.3). Fold the handle and press the printkey.

4. Keep the printkey pressed and let

the cloth pass through the printer. (This cleans the print head.)

Note: If the roller is clogged with

labels it can easily be removed for cleaning (see 9.1).

8. Troubleshooting

To Begin W ith

When troubleshooting the Nova printer, it is necessary to narrow down the various possible causes of faults: does the printer, the media or the application software cause the fault? A simple way of beginning your troubleshooting is to carry out a test print, which provides valuable information about the printer, for example if:

• The printer can feed the media

• The printer can print

• It shows which program version, typeface, etc. is

installed.

• It shows communication parameters and settings

• It shows the quality of printouts.

Test Print

The printer has two different test modes for test printouts. We recommend you to use continuous paper (minimum width 100 mm) for the test printouts.

Preparations

Before you request a test printout, check that:

• The printer is loaded with paper (preferably continuous paper)

• The printer has been turned off for at lea st 15 seconds.

Interpretation of the Test Labels

The values shown in the test printout are default values set at delivery. It may be necessary to alter some values before final installation. The procedures for changing values are found in the Labelpoint manual.

8. Troubleshooting

Test Met hod 1

A printout using test method 1 shows the printer’s parameters and settings, for example: date, ti me, pro gram vers io n, commun ication settings and which typefaces are available.

1. Switch off the printer.

2. Press the print button, but d o not

release it.

3. Switch on the printer without releasing

the print button.

4. Keep the print button depressed until

the printer starts printing the test pattern.

5. Then, releas e the print butto n.

Test Pattern

The method 1 test print produces a pattern with three different fields. These fields

rovide information about:

• Whether all the dots on the print head are functioning correctly. If one or more dots are missing, a distinct white line appears in the test pattern .

• Whether the roller is perfectly cylindrical and is in the correct position.

• Whether the print head is com ple t ely p ar al lel wi th t he r ol le r. The test pattern is lighter in those areas where the roller is not perfectly cylindrical or where the print head is not completely parallel with the roller.

8. Troubleshooting

Test Met hod 2

Note: This method is only for advanced troubleshooting by service technicians.

This shows all information sent to the printer in hex-code and the function is used to determine possible communication faults, since it is possible to see exactly what data the printer receives.

1. Switch off the printer.

2. Press the print button, but d o not

release it.

Switc h on the pri nte r wit hout releasi ng

the print button.

Release the pri nt butto n when the

printer starts printing.

The printer starts by printing information as in test method 1. It then stops and will continue printing once the data is sent to the printer. By checking the received data, you can determine whether character received agree with the Label pointcommands and the transferred ASCIIcharacters.

Differences between the received signals and the transferred characters may be due to incorrect parameters (e.g. Baud rate) or the presence of electrical inference during the transfer. Check the communication cable, the length of the cable and whether or not the cable is close to power cables.

Cancelling Test Methods

To cancel the test methods, turn the printer off and wait 15 seconds before switching it on again.

8. Troubleshooting

Troubleshooting Schedule

Status Error Measure No printou t

Status lamp is red

Status lamp is flashing red

The print head is not in position (status lamp is red)

Incorrect media

Incorrect or no data

TT- instead of DT- media

Ink ribbon is inserted with inked side facing upwards

End of media roll, end of ink ribbon or the handle is not folded down

System temperature too high, printer has entered cool down state

Check the level, fold down the print head (DT, TT)

Check the media, rep lace media (chapter 5.3)

Check all cables

Replace media (5.3 or 5.4)

Load the Ink ribbon correctly (inked side facing downwards) (chapter 5.5)

Check the media, the ink ribbon and that the handle is folded

Wait

Smudged pri nto ut Black or wh ite lines Faint printout

Uneve n white lines

Printout too dark

Damaged roller

Damaged print head

Dirty print head

Incorrect parameter settings

Incorrect media

Incorrec t head pres s ure

Ink ribbon is creased

Incorrect Ink ribbon

Incorrect parameter settings

Replace roller (chapter 9.1)

Replace print head (9.2)

Clean print head (chapter 7)

See ‘Printer settings’ on the Getting Started CD

Replace media (5.3 or 5.4)

Adjust Print Head (6.4)

Have the printer serviced to adjust the Ink ribbon mechanism

Replace wit h correct type of Ink ribbon (chapter 5.5)

See ‘Printer settings’ on the Getting Started CD

9. Changeable Parts

9.1 Replacing the Roller

Note:

The pictures shown describe an MP Nova4 DT. The process works just the same for all MP Nova printers.

1. Check that the printer is

turned off and open the cover (chapter 4.3 DT or

4.5 TT).

2. Pull the roller and the roller

bearing support to the right (use the rubber surface when pulling right).

3. Lift the left-hand end of the

roller towards the interior of the printer.

4. Lift out the right-hand end of

the roller.

5. Remove the entire roller

from th e p rinter.

9. Changeable Parts

9.1 Replacing the Roller

6. Pay carefully attention to the drive belt when removing the left- hand end of the roller from the printer.

7. Unpack the new roller.

9. Changeable Parts

9.1 Replacing the Roller

8. Insert the left-hand end of the roller (the end with the cog wheel). Check that it fits inside the drive belt.

9. Changeable Parts

9.1 Replacing the Roller

9. Insert the right-hand end of

the roller into position.

. Push the left-hand end of

the roller downwards into the notch until the roller is parallel with the edge of the printer.

9. Changeable Parts

9.1 Replacing the Roller

11 and 12 Push the roller

slightly to the left so that the left-hand end slots into the groove.

13. Close the cover (chapter

4.3 DT or 4.5 TT).

14. Switch on the printer.

9. Changeable Parts

9.2 Replacing the Print Head

Note:

The pictures shown describe an MP Nova4 DT. The process works just the same for all MP Nova printers.

1. Make sure the printer is

turned off and open the cover.

2. Check and remembe r the

current lateral position of the print head. 3 mm is the default position.

Note : Only adju stable on

MP Nova 4 DT.

3. Carefully push the prin t

head downwards until the finger nut becomes visible. Unscrew the finger nut.

Note: Take care not to loose the finger nut.

9. Changeable Parts

9.2 Replacing the Print Head

4. Carefully remove the print

head.

5. Carefully remove the

cables from the back of the pri nt head.

Note: There is a “button” on top of the right cable. Push the “button” before removing the cable.

9. Changeable Parts

9.2 Replacing the Print Head

6. Unpack the new print head

and attach the cables to the new print head.

Remember to handle the print head with care!

7. Carefully insert the pr int

head into position.

9. Changeable Parts

9.2 Replacing the Print Head

8. Check t hat t he latera l

position has not changed. 3 mm is the default

position. Note : Only adju stable on MP Nova 4 DT.

9. Hold the print head in

place and tigh ten the fi nger nut.

10. Close the cover (chapter

4.3 DT or 4,5 TT).

1. Switch on the printer .

10. Printer Options and Spare Parts

10.1 Printer Options

Peel-Off Kit

MP Nova4 & 6 DT, MP Nova4 & 6 TT

Item number: 5335 41 Nova4 533542 Nova6

The peel-off device separates the labels from the backing paper, which is rolled up behind the printer.

LTS – Label Taken Sens or

MP Nova4 & 6 & 8 DT, MP Nova4 & 6 TT

Item number: 5336 25-0 1

The Label Taken Sensor (LTS) is often used in association with the Peel-Off Kit. Printin g is controlled by a photocell. A new label is only printed once the previo us labe l has been removed from the sensor .

10. Printer Options and Spare Parts

10.1 Printer Options

215 mm Kit

MP Nova4 & 6 DT, MP Nova4 & 6 TT

Item number: 5336 15

The 215 mm Kit makes it possible to use media rolls with diameters up to 215 mm.

10. Printer Options and Spare Parts

10.2 Spare Parts

Consumables

Part number Description

533616 MPS - Media Positioning Sensor 532089 Media guide – Lockable

Cables

502542 Cable – Serial - (RJ45) 000554 Power cable - Europe 001464 Power cable - UK 001463 Power cable – USA & Canada 502543 USB cable

Optional

533625-01 LTS Kit (Label Taken Sensor) 533541

533615 215mm Kit

501933 501934 501935 501936 501937 501938

1. 10 x Cleaning cloths (4")

1. 50 x Cleaning cloths (4")

1. 10 x Cleaning cloths (6")

50 x Cleaning cloths (6")

10 x Cleaning cloths (8")

50 x Cleaning cloths (8")

533529 533667 533529 533667 533640 533640 531675

533530 533636 533607

533542

2. Print head – 200 dpi – MP Nova4 DT

2. Print head – 300 dpi – MP Nova4 DT

2. Print head – 200 dpi – MP Nova4 TT

2. Print head – 300 dpi – MP Nova4 TT

2. Print head – 200 dpi – MP Nova6 DT

2. Print head – 200 dpi – MP Nova6 TT

2. Print head – 200 dpi – MP Nova8 DT

3. Print roll – MP Nova4

3. Print roll – MP Nova6

3. Print roll – MP Nova8

Peel-Off Kit – Nova4 Peel-Off Kit – Nova6

11. Consumables

Media General

Self-adhesive labels are backed with silicon-coated backing paper, from which the label is removed. There are different types of adhesive:

• Tickets are printed on non-adhesive paper, which means there is no need for backing paper.

• Both labels and tickets are available as rolls or as fan-folded continuous paper tracks. Fan-folded labels and tickets are supplied in boxes, in which labels are stored before passing through the printer.

• Perforations are used to divide labels and tickets. This makes them easier to tear after printing.

• In order to start and stop the media during the print process, the printer is equipped with a detector that senses any gaps or black marks.

For more detailed information about media and consumables, we recommend you read Datamax’s ‘CONSUMABLES’ document (currently only available in English).

MP Nova4 DT, Nova6 DT & N ov a8 DT

The MP Nova DT printers use direct thermal media, such as labels, paper and tickets.

Direct thermal media is made of special paper that reacts to heat and printouts are often black. Different paper qualities are available.

MP Nova4 TT, Nova6 TT

The MP Nova TT uses a special ink ribbon, which transfers ink to media (receiver) when subjected to heat. Labels printed using the thermal transfer method shows a greater resistance to heat and UV-light.

12. Technical Specifications

MP Nova4 DT & TT

Dimensions (H x W x L)

Weight DT: 5.8 kg (12 lbs), TT: 7.2 kg (15 lbs)

Power pack 100/240V AC 50-60 Hz, 325 VA

Printer technology Direct thermal and thermal transfer

Printing width 104 mm (4⅛”)

Printing speed DT: 80 – 250 mm/seco nd, TT: 80 – 250 mm/second

Printing resolution 200 dpi / 300 dpi

Media specifications

Media types

DT: 150 x 232 x 360 mm (6” x 9⅛” x 14⅛”) TT: 210 x 250 x 360 mm (8¼” x 9½” x 14⅛”)

Width: 40 mm – 115 mm (1½” – 4½”) Length: 10 mm (⅜”) – unlimited Thickness: 58 μm – 180 μm

Roll or fan-folded paper External diameter of roll: max 215 mm (8½”) Inner core of roll: min 37 mm (1½”) i n diameter

Max width of roll: 110 mm (4⅓”)

Ink ribbon, TT

Connections

Typefaces

Barcodes

Graphics Supports several file types

Settings program Internal program using web browser, Telnet or hyperterminal

Counters 10 internal counters

Memory 2 Mb standard RAM

Time and date Internal clock, real-time

Print head diagnostic PHD (Print Head Diagnostic)

Inner core diameter of roll: 25 mm (1”) Max length: 300 m (328 yards)

2 x RS232 ports (up to 115 kBps) USB-port Ethernet port (TCP/IP [LPD, R Telnet])

10 scalable typefaces 13 scalable, emulated typefaces Supports true type typefaces

Most common barcodes including two-dimensional. Examples: EAN128, Interleaved 2 of 5, Code 39 and PDF417

12. Technical Specifications

MP Nova6 DT & TT

Dimensions (H x W x L)

Weight DT: 6.8 kg (15 lbs) TT: 8,2 kg (16,5 lbs)

Power pack 100/240V AC 50-60 Hz, 325 VA

Printer technology Direct thermal and thermal transfer

Printing width 168 mm (6⅝”)

Printing speed DT: 80 – 200 mm/seco nd, TT: 80 – 200 mm/second

Printing resolution 200 dpi

Media specifications

Media types

DT: 150 x 292 x 360 mm (6” x 11½” x 14 ⅛”) TT: 210 x 310 x 360 mm (8⅓” x 11⅞” x 14 ⅛”)

Width: 40 mm – 175 mm (1½” – 6⅞”) Length: 10 mm (⅜”) – unlimited Thickness: 58 μm – 180 μm

Roll or fan-folded paper External diameter of roll: max 215 mm (8½“) Inner core of roll: min 37 mm (1½”) i n diameter

Max width of roll: 174 mm (6⅞”)

Ink ribbon, TT

Connections

Typefaces

Barcodes

Graphics Supports several file types

Settings program Internal program using web browser, Telnet or hyperterminal

Counters 10 internal counters

Memory 2 Mb standard RAM

Time and date Internal clock, real-time

Print head diagnostic PHD (Print Head Diagnostic)

Inner core diameter of roll: 25 mm (1”) Max length: 300 m (328 yards)

2 x RS232 ports (up to 115 kBps) USB-port Ethernet port (TCP/IP [LPD, R Telnet])

10 scalable typefaces 13 scalable, emulated typefaces Supports true type typefaces

Most common barcodes including two-dimensional. Examples: EAN128, Interleaved 2 of 5, Code 39 and PDF417

12. Technical Specifications

MP Nova8 DT

Dimensions (H x W x L) DT: 150 x 345 x 360 mm (6” x 13½” x 14⅛”)

Weight DT: 7.0 kg (15,5 lbs)

Power pack 100/240V AC 50-60 Hz, 325 VA

Printer technology Direct thermal

Printing width 216 mm (8½”)

Printing speed Up to 150 mm/second

Printing resolution 200 dpi

Width: 150 mm – 230 mm (5⅞” – 9”)

Media specifications

Media types Fan-folded paper

Connections

Length: 10 mm (⅜”) – unlimited Thickness: 58 μm – 180 μm

2 x RS232 ports (up to 115 kBps) USB-port Ethernet port (TCP/IP [LPD, R Telnet])

10 scalable typefaces

Typefaces

Barcodes

Graphics Supports several file types

Settings program Internal program using web browser, Telnet or hyperterminal

Counters 10 internal counters

Memory 2 Mb standard RAM

Time and date Internal clock, real-time

Print head diagnostic PHD (Print Head Diagnostic)

13 scalable, emulated typefaces Supports true type typefaces

Most common barcodes including two-dimensional. Examples: EAN128, Interleaved 2 of 5, Code 39 and PDF417

Datamax MP NOVA4 DT User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
