DRAGON™ M SERIES
1
USING DRAGON™ M
The DRAGON™ M series laser gun can be used with either an OM-DRAGON™
cradle or STARGATE™ radio base station to build a Cordless Reading System
for the collection, decoding and transmission of barcoded data.
DRAGON™ M laser guns automatically scan barcodes at a distance. Simply
aim and pull the trigger.
SCAN LINE POSITION
Code scanning is performed along the scan line emitted from the reading
window. This line must cross the entire code.
ÌqdbefjLÎ
OK
ÌqdbefjLÎ
NO
AIMING SYSTEM
DRAGON™ M provides a programmable aiming system. If enabled, the scan
line emitted from the reading window is preceded by a red spot which must
illuminate the code center to get the best reading performance (see figure
above, c). Once the defined timeout is reached, the red spot disappears and is
followed by the scan line to start the code scanning.
DATALOGIC
2
After Dragon™ M Setup, read one of the following codes to set desired aiming
system timeout.
aiming system disabled
Ì$+BX0$-AÎ
300 ms
Ì$+BX1$-FÎ
500 ms
Ì$+BX2$-KÎ
1 sec
Ì$+BX3$-PÎ
READING ANGLE
Successful scanning is obtained by tilting the reader with respect to the barcode
to avoid direct reflections that impair the reading performance, see the figure
below.
OK Not Advised
DRAGON™ M SERIES
3
SETUP
DRAGON™ M/OM-DRAGON™ Stand Alone Configuration
1. Connect an OM-DRAGON™ cradle to the Host. For installation and
connection information see the OM-DRAGON™ Quick Reference
Manual.
2. Charge the DRAGON™ M battery using an OM-DRAGON™ or the
C-DRAGON™ charger as described in this Quick Reference manual. A
full charge takes 2 hours with NiMh battery models.
3. Configure the laser gun as described in this Quick Reference DRAGON™ M/OM-DRAGON™ Stand Alone Setup.
4. Configure the OM-DRAGON™ cradle. See OM-DRAGON™
Configuration in the OM-DRAGON™ Quick Reference.
or
DRAGON™ M/STAR-System™ Configuration
1. Charge the DRAGON™ M battery using an OM-DRAGON™ or the
C-DRAGON™ charger as described in this Quick Reference manual. A
full charge takes 2 hours with NiMh battery models.
2. Configure the laser gun as described in this Quick Reference DRAGON™ M/STAR-System™ Setup.
Loading...
