DATALOGIC DL GD4132 User guide [de]

Download

Gryphon™ Family

Product Reference Guide

General Purpose Handheld

Linear Imager Bar Code Readers

Gryphon I GD4132/GM4102

Gryphon BT4102

Datalogic USA, Inc.

959 Terry Street Eugene, OR 97402 USA Telephone: (541) 683-5700 Fax: (541) 345-7140

An Unpublished Work - All rights reserved. No part of the contents of this documentation or the procedures described therein may be reproduced or transmitted in any form or by any means without prior written permission of Datalogic USA Inc. or its subsidiaries or affiliates (“Datalogic” or “Datalogic USA”). Owners of Datalogic products are hereby granted a non-exclusive, revocable license to reproduce and transmit this documentation for the purchaser's own internal business pur

poses. Purchaser shall not remove or alter any proprietary notices, including copyright notices, contained in this documentation and shall ensure that all notices appear on any reproductions of the documentation. Should future revisions of this manual be published, you can acquire printed versions by contacting your Datalogic representative. Electronic versions may either be downloadable from the Datalogic website (www.datalogic.com) or provided on appropriate media. If you visit our website and would like to make comments or suggestions about this or other Dat alogic publications, please let us know via the "Contact Datalogic" page..

Disclaimer

Datalogic has taken reasonable measures to provide information in this manual that is complete and accurate, however, Datalogic reserves the right to change any specification at any time without prior notice. Datalogic and the Datalogic logo are registered trademarks of Datalogic S.p.A. in many countries, including the U.S. and the E.U. Gryphon is a trademark of Datalogic S.p.A. and/or its affiliates registered in the U.S. All other brand and product names may be trademarks of their respective owners.

Patents

See www.patents.datalogic.com for patent list.

INTRODUCTION........................................................................................................................................................................................... 9

About this Manual ................................................................................................................................................................................................... 9

Overview ........................................................................................................................................................................................................... 9

Manual Conventions ..................................................................................................................................................................................... 10

References .............................................................................................................................................................................................................. 10

Technical Support ................................................................................................................................................................................................... 10

Support Through the Website ...................................................................................................................................................................... 10

Reseller Technical Support ........................................................................................................................................................................... 10

About the Reader ................................................................................................................................................................................................... 11

The BC40xx™ Radio Base ....................................................................................................................................................................................... 12

Base LEDs ...................................................................................................................................................................................................... 12

Base Button ...................................................................................................................................................................................................12

Battery Safety .........................................................................................................................................................................................................13

Programming the Reader ......................................................................................................................................................................................15

Configuration Methods .................................................................................................................................................................................15

SETUP........................................................................................................................................................................................................ 17

Unpacking ............................................................................................................................................................................................................... 17

Setting Up the Reader ........................................................................................................................................................................................... 17

Installing the Interface Cable ................................................................................................................................................................................ 18

Configuring the Base Station ................................................................................................................................................................................ 20

Changing the Base Station Position ........................................................................................................................................................... 21

Connecting the Base Station ....................................................................................................................................................................... 23

Connecting the Base when Security Pin is Enabled .................................................................................................................................. 26

Linking the Reader to a Base Station ......................................................................................................................................................... 26

Linking a BT Reader to a PC ......................................................................................................................................................................... 27

Gryphon™ I System and Network Layouts ........................................................................................................................................................... 28

Interface Selection ................................................................................................................................................................................................. 30

Setting the Interface .....................................................................................................................................................................................30

Customizing Configuration Settings .................................................................................................................................................................... 34

Configure Interface Settings ....................................................................................................................................................................... 34

Global Interface Features ............................................................................................................................................................................. 34

Configuring Other Features .........................................................................................................................................................................34

Software Version Transmission .................................................................................................................................................................. 34

Resetting the Product Configuration to Defaults ...................................................................................................................................... 35

Replacing the Battery ................................................................................................................................................................................... 36

CONFIGURATION USING BARCODES ...................................................................................................................................................... 39

Configuration Parameters ............................................................................................................................................................................ 39

Reading Configuration Barcodes ................................................................................................................................................................. 40

GLOBAL INTERFACE FEATURES .......................................................................................................................................................... 41

Host Commands — Obey/Ignore .............................................................................................................................................. 41

USB Suspend Mode ..................................................................................................................................................................... 41

RS-232 ONLY Interface ................................................................................................................................................................... 43

Baud Rate ..................................................................................................................................................................................... 44

Data Bits ....................................................................................................................................................................................... 45

Stop Bits ....................................................................................................................................................................................... 45

Parity ............................................................................................................................................................................................ 46

Handshaking Control .................................................................................................................................................................. 47

RS-232/USB-Com Interfaces......................................................................................................................................................... 48

Intercharacter Delay .................................................................................................................................................................... 49

Beep On ASCII BEL ....................................................................................................................................................................... 50

Beep On Not on File .................................................................................................................................................................... 50

ACK NAK Options ......................................................................................................................................................................... 51

Product Reference Guide

Contents

ACK Character .............................................................................................................................................................................. 52

NAK Character ............................................................................................................................................................................. 52

ACK NAK Timeout Value ............................................................................................................................................................. 53

ACK NAK Retry Count .................................................................................................................................................................. 54

ACK NAK Error Handling ............................................................................................................................................................. 55

Indicate Transmission Failure ................................................................................................................................................... 55

Disable Character ........................................................................................................................................................................ 56

Enable Character ......................................................................................................................................................................... 56

Keyboard Interface .......................................................................................................................................................................... 57

Country Mode .............................................................................................................................................................................. 58

Caps Lock State ........................................................................................................................................................................... 61

Numlock ....................................................................................................................................................................................... 61

Send Control Characters ............................................................................................................................................................. 62

Wedge Quiet Interval .................................................................................................................................................................. 63

Intercharacter Delay .................................................................................................................................................................... 64

Intercode Delay ............................................................................................................................................................................ 65

USB Keyboard Speed ................................................................................................................................................................... 66

USB Keyboard Numeric Keypad ................................................................................................................................................. 68

USB-OEM Interface

(available with special cable) ......................................................................................................................................................... 69

IBM 46XX Interface

(AVAILABLE WITH SPECIAL CABLE) ............................................................................................................................................... 71

Wand Emulation Interface ............................................................................................................................................................. 75

Data Format ..................................................................................................................................................................................... 79

Reading Parameters ...................................................................................................................................................................... 95

LED AND BEEPER INDICATORS ......................................................................................................................................................... 100

SCANNING FEATURES ........................................................................................................................................................................ 105



USB-OEM Device Usage ............................................................................................................................................................. 70

Interface Options ......................................................................................................................................................................... 70



46xx Number of Host Resets ..................................................................................................................................................... 72

Transmit Labels in Code 39 Format .......................................................................................................................................... 74

Interface Options ......................................................................................................................................................................... 74

Wand Signal Speed ..................................................................................................................................................................... 76

Wand Polarity .............................................................................................................................................................................. 76

Wand Idle State ........................................................................................................................................................................... 77

Transmit Noise ............................................................................................................................................................................ 77

Label Symbology Conversion ..................................................................................................................................................... 78

Global Prefix/Suffix ..................................................................................................................................................................... 80

Global AIM ID ................................................................................................................................................................................ 81

GS1-128 AIM ID ........................................................................................................................................................................... 82

Label ID ......................................................................................................................................................................................... 83

Label ID: Pre-loaded Sets ........................................................................................................................................................... 83

Label ID: Set Individually Per Symbology .................................................................................................................................. 84

Label ID Control ........................................................................................................................................................................... 84

Label ID Symbology Selection .................................................................................................................................................... 85

Set Global Mid Label ID Characters ........................................................................................................................................... 92

Case Conversion .......................................................................................................................................................................... 93

Character Conversion .................................................................................................................................................................. 94

Double Read Timeout ................................................................................................................................................................. 96

Label Gone Timeout .................................................................................................................................................................... 97

Sleep Mode Timeout ................................................................................................................................................................... 98

Power On Alert .......................................................................................................................................................................... 100

Good Read: When to Indicate ................................................................................................................................................... 100

Good Read Beep Type ............................................................................................................................................................... 101

Good Read Beep Frequency ..................................................................................................................................................... 101

Good Read Beep Length ........................................................................................................................................................... 102

Good Read Beep Volume .......................................................................................................................................................... 103

Good Read LED Duration .......................................................................................................................................................... 104

Scan Mode .................................................................................................................................................................................. 105

Stand Mode Triggered Timeout ............................................................................................................................................... 106

Stand Detection ......................................................................................................................................................................... 107

Gryphon™ I GD4132/GM4102/GBT 4102

Contents

Stand Mode Sensitivity ............................................................................................................................................................. 108

Scanning Active Time ................................................................................................................................................................ 108

Flash On Time ............................................................................................................................................................................ 109

Flash Off Time ........................................................................................................................................................................... 109

Green Spot Duration ................................................................................................................................................................. 110

Code Selection................................................................................................................................................................................ 111

DISABLE ALL SYMBOLOGIES ............................................................................................................................................................. 113

CODE EAN/UPC .................................................................................................................................................................................. 114

Coupon Control .......................................................................................................................................................................... 114

UPC-A ......................................................................................................................................................................................... 114

UPC-A Enable/Disable .............................................................................................................................................................. 114

UPC-A Check Character Transmission .................................................................................................................................... 115

Expand UPC-A to EAN-13 ........................................................................................................................................................ 115

UPC-A Number System Character Transmission .................................................................................................................. 116

UPC-A Minimum Reads ............................................................................................................................................................ 116

UPC-E .................................................................................................................................................................................................. 117

UPC-E Enable/Disable .............................................................................................................................................................. 117

UPC-E Check Character Transmission .................................................................................................................................... 117

Expand UPC-E to EAN-13 ......................................................................................................................................................... 118

Expand UPC-E to UPC-A ........................................................................................................................................................... 118

UPC-E Number System Character Transmission .................................................................................................................. 119

UPC-E Minimum Reads ............................................................................................................................................................ 119

GTIN FORMATTING ............................................................................................................................................................................. 120

EAN 13 (JAN 13) .................................................................................................................................................................................. 121

EAN 13 Enable/Disable ............................................................................................................................................................ 121

EAN 13 Check Character Transmission ................................................................................................................................... 121

EAN-13 Flag 1 Character .......................................................................................................................................................... 122

EAN-13 ISBN Conversion ......................................................................................................................................................... 122

EAN 13 Minimum Reads .......................................................................................................................................................... 123

ISSN ...................................................................................................................................................................................................... 124

ISSN Enable/Disable ................................................................................................................................................................. 124

EAN 8 (JAN 8) ....................................................................................................................................................................................... 125

EAN 8 Enable/Disable .............................................................................................................................................................. 125

EAN 8 Check Character Transmission ..................................................................................................................................... 125

Expand EAN 8 to EAN 13 .......................................................................................................................................................... 126

EAN 8 Minimum Reads ............................................................................................................................................................. 126

UPC/EAN GLOBAL SETTINGS ............................................................................................................................................................ 127

UPC/EAN Decoding Level ......................................................................................................................................................... 127

UPC/EAN Correlation ................................................................................................................................................................ 128

UPC/EAN Price Weight Check .................................................................................................................................................. 128

In-Store Minimum Reads ......................................................................................................................................................... 129

ADD-ONS ............................................................................................................................................................................................. 130

Optional Add-ons ...................................................................................................................................................................... 130

Optional Add-On Timer ............................................................................................................................................................. 131

Optional GS1-128 Add-On Timer ............................................................................................................................................. 134

P2 Add-Ons Minimum Reads .................................................................................................................................................. 137

P5 Add-Ons Minimum Reads .................................................................................................................................................. 138

GS1-128 Add-Ons Minimum Reads ........................................................................................................................................ 139

CODE 39 ............................................................................................................................................................................................... 140

Code 39 Enable/Disable ........................................................................................................................................................... 140

Code 39 Check Character Calculation ...................................................................................................................................... 140

Code 39 Check Character Transmission .................................................................................................................................. 141

Code 39 Start/Stop Character Transmission ......................................................................................................................... 142

Code 39 Full ASCII ...................................................................................................................................................................... 142

Code 39 Quiet Zones ................................................................................................................................................................. 143

Code 39 Minimum Reads ......................................................................................................................................................... 144

Code 39 Decoding Level ............................................................................................................................................................ 145

Code 39 Length Control ............................................................................................................................................................ 146

Code 39 Set Length 1 ................................................................................................................................................................ 147

Code 39 Set Length 2 ................................................................................................................................................................ 148

Code 39 Interdigit Ratio ............................................................................................................................................................ 149

Code 39 Character Correlation ................................................................................................................................................. 151

Product Reference Guide

Contents

Code 39 Stitching ....................................................................................................................................................................... 151

CODE 32 (ITAL PHARMACEUTICAL CODE) ........................................................................................................................................ 152

Code 32 Enable/Disable ........................................................................................................................................................... 152

Code 32 Feature Setting Exceptions ....................................................................................................................................... 152

Code 32 Check Char Transmission .......................................................................................................................................... 153

Code 32 Start/Stop Character Transmission ......................................................................................................................... 153

CODE 39 CIP (FRENCH PHARMACEUTICAL) ..................................................................................................................................... 154

Code 39 CIP Enable/Disable ..................................................................................................................................................... 154

CODE 128 ............................................................................................................................................................................................. 155

Code 128 Enable/Disable ......................................................................................................................................................... 155

Expand Code 128 to Code 39 .................................................................................................................................................... 155

Code 128 Check Character Transmission ............................................................................................................................... 156

Code 128 Function Character Transmission .......................................................................................................................... 156

Code 128 Sub-Code Change Transmission ............................................................................................................................. 156

Code 128 Quiet Zones ............................................................................................................................................................... 157

Code 128 Minimum Reads ....................................................................................................................................................... 158

Code 128 Decoding Level .......................................................................................................................................................... 159

Code 128 Length Control .......................................................................................................................................................... 159

Code 128 Set Length 1 .............................................................................................................................................................. 160

Code 128 Set Length 2 .............................................................................................................................................................. 161

Code 128 Character Correlation ............................................................................................................................................... 162

Code 128 Stitching .................................................................................................................................................................... 162

GS1-128 ............................................................................................................................................................................................... 163

GS1-128 Enable ......................................................................................................................................................................... 163

CODE ISBT 128 .................................................................................................................................................................................... 164

ISBT 128 Concatenation ............................................................................................................................................................ 164

ISBT 128 Force Concatenation ................................................................................................................................................. 164

ISBT 128 Concatenation Mode ................................................................................................................................................. 165

ISBT 128 Dynamic Concatenation Timeout ............................................................................................................................ 166

ISBT 128 Advanced Concatenation Options ........................................................................................................................... 166

CODABLOCK F ..................................................................................................................................................................................... 167

Codablock F Enable/Disable .................................................................................................................................................... 167

Codablock F EAN Enable/Disable ............................................................................................................................................ 167

Codablock F AIM Check ............................................................................................................................................................. 168

Codablock F Length Control ..................................................................................................................................................... 168

Codablock F Set Length 1 ......................................................................................................................................................... 169

Codablock F Set Length 2 ......................................................................................................................................................... 170

INTERLEAVED 2 OF 5 (I 2 OF 5) ......................................................................................................................................................... 171

I 2 of 5 Enable/Disable ............................................................................................................................................................. 171

I 2 of 5 Check Character Calculation ........................................................................................................................................ 172

I 2 of 5 Check Character Transmission .................................................................................................................................... 173

I 2 of 5 Minimum Reads ............................................................................................................................................................ 173

2 of 5 Decoding Level ................................................................................................................................................................ 174

I 2 of 5 Length Control .............................................................................................................................................................. 175

I 2 of 5 Set Length 1 .................................................................................................................................................................. 176

I 2 of 5 Set Length 2 .................................................................................................................................................................. 177

I 2 of 5 Character Correlation ................................................................................................................................................... 178

I 2 of 5 Stitching ......................................................................................................................................................................... 178

FOLLETT 2 OF 5 .................................................................................................................................................................................. 179

Follett 2 of 5 Enable/Disable ................................................................................................................................................... 179

INTERLEAVED 2 OF 5 CIP HR ............................................................................................................................................................ 179

Interleaved 2 of 5 CIP HR Enable/Disable .............................................................................................................................. 179

STANDARD 2 OF 5 .............................................................................................................................................................................. 180

Standard 2 of 5 Enable/Disable .............................................................................................................................................. 180

Standard 2 of 5 Check Character Calculation ......................................................................................................................... 180

Standard 2 of 5 Check Character Transmission ..................................................................................................................... 181

Standard 2 of 5 Minimum Reads ............................................................................................................................................. 181

Standard 2 of 5 Decoding Level ............................................................................................................................................... 182

Standard 2 of 5 Length Control ............................................................................................................................................... 182

Standard 2 of 5 Set Length 1 ................................................................................................................................................... 183

Standard 2 of 5 Set Length 2 ................................................................................................................................................... 184

Standard 2 of 5 Character Correlation .................................................................................................................................... 185

Gryphon™ I GD4132/GM4102/GBT 4102

Contents

Standard 2 of 5 Stitching .......................................................................................................................................................... 185

INDUSTRIAL 2 OF 5 ............................................................................................................................................................................. 186

Industrial 2 of 5 Enable/Disable .............................................................................................................................................. 186

Industrial 2 of 5 Check Character Calculation ........................................................................................................................ 186

Industrial 2 of 5 Check Character Transmission .................................................................................................................... 187

Industrial 2 of 5 Length Control ............................................................................................................................................... 187

Industrial 2 of 5 Set Length 1 ................................................................................................................................................... 188

Industrial 2 of 5 Set Length 2 ................................................................................................................................................... 189

Industrial 2 of 5 Minimum Reads ............................................................................................................................................ 190

Industrial 2 of 5 Stitching ......................................................................................................................................................... 190

Industrial 2 of 5 Character Correlation .................................................................................................................................... 191

CODE IATA ........................................................................................................................................................................................... 192

IATA Enable/Disable ................................................................................................................................................................. 192

IATA Check Character Transmission ....................................................................................................................................... 192

DATALOGIC 2 OF 5 .............................................................................................................................................................................. 193

Datalogic 2 of 5 Enable/Disable .............................................................................................................................................. 193

Datalogic 2 of 5 Check Character Calculation ......................................................................................................................... 193

Datalogic 2 of 5 Minimum Reads ............................................................................................................................................ 194

Datalogic 2 of 5 Decoding Level ............................................................................................................................................... 194

Datalogic 2 of 5 Length Control ............................................................................................................................................... 195

Datalogic 2 of 5 Set Length 1 ................................................................................................................................................... 196

Datalogic 2 of 5 Set Length 2 ................................................................................................................................................... 197

Datalogic 2 of 5 Character Correlation .................................................................................................................................... 198

Datalogic 2 of 5 Stitching .......................................................................................................................................................... 198

CODABAR ............................................................................................................................................................................................ 199

Codabar Enable/Disable ........................................................................................................................................................... 199

Codabar Check Character Calculation ..................................................................................................................................... 199

Codabar Check Character Transmission ................................................................................................................................. 200

Codabar Start/Stop Character Transmission ......................................................................................................................... 200

Codabar Start/Stop Character Set .......................................................................................................................................... 201

Codabar Start/Stop Character Match ..................................................................................................................................... 201

Codabar Quiet Zones ................................................................................................................................................................ 202

Codabar Minimum Reads ......................................................................................................................................................... 203

Codabar Decoding Level ........................................................................................................................................................... 204

Codabar Length Control ............................................................................................................................................................ 205

Codabar Set Length 1 ................................................................................................................................................................ 206

Codabar Set Length 2 ................................................................................................................................................................ 207

Codabar Interdigit Ratio ........................................................................................................................................................... 208

Codabar Character Correlation ................................................................................................................................................. 210

Codabar Stitching ...................................................................................................................................................................... 210

ABC CODABAR .................................................................................................................................................................................... 211

ABC Codabar Enable/Disable ................................................................................................................................................... 211

ABC Codabar Concatenation Mode .......................................................................................................................................... 211

ABC Codabar Dynamic Concatenation Timeout ..................................................................................................................... 212

ABC Codabar Force Concatenation .......................................................................................................................................... 213

CODE 11 ............................................................................................................................................................................................... 214

Code 11 Enable/Disable ........................................................................................................................................................... 214

Code 11 Check Character Calculation ...........................................................................................

Code 11 Check Character Transmission .................................................................................................................................. 215

Code 11 Minimum Reads ......................................................................................................................................................... 215

Code 11 Length Control ............................................................................................................................................................ 216

Code 11 Set Length 1 ................................................................................................................................................................ 217

Code 11 Set Length 2 ................................................................................................................................................................ 218

Code 11 Interdigit Ratio ............................................................................................................................................................ 219

Code 11 Decoding Level ............................................................................................................................................................ 221

Code 11 Character Correlation ................................................................................................................................................. 222

Code 11 Stitching ....................................................................................................................................................................... 222

GS1 DATABAR™ OMNIDIRECTIONAL ................................................................................................................................................. 223

GS1 DataBar™ Omnidirectional Enable/Disable .................................................................................................................... 223

GS1 DataBar™ Omnidirectional GS1-128 Emulation ............................................................................................................. 223

GS1 DataBar™ Omnidirectional Minimum Reads .................................................................................................................. 224

GS1 DATABAR™ EXPANDED .............................................................................................................................................................. 225

........................................... 214

Product Reference Guide

Contents

GS1 DataBar™ Expanded Enable/Disable ............................................................................................................................... 225

GS1 DataBar™ Expanded GS1-128 Emulation ........................................................................................................................ 225

GS1 DataBar™ Expanded Minimum Reads ............................................................................................................................. 226

GS1 DataBar™ Expanded Length Control ................................................................................................................................ 226

GS1 DataBar™ Expanded Set Length 1 .................................................................................................................................... 227

GS1 DataBar™ Expanded Set Length 2 .................................................................................................................................... 228

GS1 DATABAR™ LIMITED .................................................................................................................................................................... 229

GS1 DataBar™ Limited Enable/Disable ................................................................................................................................... 229

GS1 DataBar™ Limited GS1-128 Emulation ............................................................................................................................ 229

GS1 DataBar™ Limited Minimum Reads ................................................................................................................................. 230

CODE 93 ............................................................................................................................................................................................... 231

Code 93 Enable/Disable ........................................................................................................................................................... 231

Code 93 Check Character Calculation ...................................................................................................................................... 231

Code 93 Check Character Transmission .................................................................................................................................. 232

Code 93 Length Control ............................................................................................................................................................ 232

Code 93 Set Length 1 ................................................................................................................................................................ 233

Code 93 Set Length 2 ................................................................................................................................................................ 234

Code 93 Minimum Reads ......................................................................................................................................................... 235

Code 93 Decoding Level ............................................................................................................................................................ 236

Code 93 Quiet Zones ................................................................................................................................................................. 237

Code 93 Stitching ....................................................................................................................................................................... 238

Code 93 Character Correlation ................................................................................................................................................. 238

MSI ....................................................................................................................................................................................................... 239

MSI Enable/Disable .................................................................................................................................................................. 239

MSI Check Character Calculation ............................................................................................................................................. 239

MSI Check Character Transmission ......................................................................................................................................... 240

MSI Length Control ................................................................................................................................................................... 240

MSI Set Length 1 ....................................................................................................................................................................... 241

MSI Set Length 2 ....................................................................................................................................................................... 242

MSI Minimum Reads ................................................................................................................................................................. 243

MSI Decoding Level ................................................................................................................................................................... 244

PLESSEY .............................................................................................................................................................................................. 245

Plessey Enable/Disable ............................................................................................................................................................ 245

Plessey Check Character Calculation ...................................................................................................................................... 246

Plessey Check Character Transmission .................................................................................................................................. 246

Plessey Length Control ............................................................................................................................................................. 247

Plessey Set Length 1 ................................................................................................................................................................ 248

Plessey Set Length 2 ................................................................................................................................................................ 249

Plessey Minimum Reads .......................................................................................................................................................... 250

Plessey Decoding Level ............................................................................................................................................................ 251

Plessey Stitching ....................................................................................................................................................................... 252

Plessey Character Correlation .................................................................................................................................................. 252

CODE 4 ................................................................................................................................................................................................. 253

Code 4 Enable/Disable ............................................................................................................................................................. 253

Code 4 Check Character Transmission .................................................................................................................................... 253

Code 4 Hex to Decimal Conversion .......................................................................................................................................... 254

CODE 5 ................................................................................................................................................................................................. 254

Code 5 Enable/Disable ............................................................................................................................................................. 254

Code 5 Check Character Transmission ...........................................................................................

Code 5 Hex to Decimal Conversion .......................................................................................................................................... 255

CODE 4 AND CODE 5 COMMON CONFIGURATION ITEMS ............................................................................................................... 256

Code 4 and 5 Decoding Level ................................................................................................................................................... 256

Code 4 and Code 5 Minimum Reads ....................................................................................................................................... 257

WIRELESS FEATURES........................................................................................................................................................................... 259

WIRELESS BEEPER FEATURES ......................................................................................................................................................... 261

Good Transmission Beep .......................................................................................................................................................... 261

Beep Frequency ......................................................................................................................................................................... 261

Beep Duration ............................................................................................................................................................................ 262

Beep Volume .............................................................................................................................................................................. 263

Disconnect Beep ........................................................................................................................................................................ 263

Base Station Beep ..................................................................................................................................................................... 264

......................................... 255

Gryphon™ I GD4132/GM4102/GBT 4102

Contents

Leash Alarm ............................................................................................................................................................................... 264

CONFIGURATION UPDATES ............................................................................................................................................................... 266

Automatic Configuration Update ............................................................................................................................................. 266

Copy Configuration to Scanner ................................................................................................................................................ 266

Copy Configuration to Base Station ........................................................................................................................................ 267

Automatic Flash Update ........................................................................................................................................................... 267

Request Flash Update .............................................................................................................................................................. 268

Powerdown Timeout ................................................................................................................................................................. 268

BATCH FEATURES .............................................................................................................................................................................. 270

Batch Mode ................................................................................................................................................................................ 270

Send Batch ................................................................................................................................................................................. 271

..................................................................................................................................................................................................... 271

Erase Batch Memory ................................................................................................................................................................ 271

RF Batch Mode Transmit Delay ............................................................................................................................................... 272

DIRECT RADIO AUTOLINK .................................................................................................................................................................. 273

RF ADDRESS STAMPING .................................................................................................................................................................... 273

Source Radio Address Transmission ...................................................................................................................................... 273

Source Radio Address Delimiter Character ............................................................................................................................ 274

FEATURES FOR STAR MODELS ONLY .............................................................................................................................................. 275

STAR Radio Protocol Timeout .................................................................................................................................................. 275

STAR Radio Transmit Mode ..................................................................................................................................................... 276

Bluetooth-Only Features.............................................................................................................................................................. 277

BT SECURITY FEATURES .................................................................................................................................................................... 278

BT Security Mode ....................................................................................................................................................................... 278

BT Pin Code ................................................................................................................................................................................ 279

Select PIN Code Length ............................................................................................................................................................ 279

Set PIN Code .............................................................................................................................................................................. 279

BT HID FEATURES ............................................................................................................................................................................... 280

BT HID Variable PIN Code ......................................................................................................................................................... 280

BT HID ALT Mode ....................................................................................................................................................................... 280

BT HID Send Unkown ASCII Char ............................................................................................................................................. 280

OTHER BT FEATURES ......................................................................................................................................................................... 281

BT Poll Rate ................................................................................................................................................................................ 281

REFERENCES......................................................................................................................................................................................... 283

RS-232 Parameters ............................................................................................................................................................................................. 283

RS-232 Only .................................................................................................................................................................................................283

RS-232/USB COM Parameters ..................................................................................................................................................................284

Keyboard Interface ...............................................................................................................................................................................................291

Wedge Quiet Interval ..................................................................................................................................................................................291

Intercharacter Delay ...................................................................................................................................................................................292

Intercode Delay ............................................................................................................................................................................................ 293

Symbologies .........................................................................................................................................................................................................294

Decoding Level .............................................................................................................................................................................................294

Set Length ....................................................................................................................................................................................................294

Data Editing ..........................................................................................................................................................................................................296

Global Prefix/Suffix .....................................................................................................................................................................................297

Global AIM ID ................................................................................................................................................................................................298

Label ID .........................................................................................................................................................................................................299

Character Conversion .................................................................................................................................................................................. 303

Reading Parameters ............................................................................................................................................................................................304

Label Gone Timeout .................................................................................................................................................................................... 304

Good Read LED Duration ............................................................................................................................................................................305

Scanning Features ...............................................................................................................................................................................................306

Scan Mode .................................................................................................................................................................................................... 306

Scanning Active Time ..................................................................................................................................................................................307

Flash On Time .............................................................................................................................................................................................. 308

Flash Off Time ............................................................................................................................................................................................. 309

RF Features ...........................................................................................................................................................................................................310

Configuration Update ..................................................................................................................................................................................310

RF Address Stamping .................................................................................................................................................................................310

BT-Only Features ........................................................................................................................................................................................ 313

Product Reference Guide

Contents

LED and Beeper Control .............................................................................................................................................................................314

TECHNICAL SPECIFICATIONS ............................................................................................................................................................... 315

Standard Cable Pinouts .......................................................................................................................................................................................318

LED and Beeper Indications ................................................................................................................................................................................ 319

Error Codes ...........................................................................................................................................................................................................320

Base Station Indications (Cordless Models ONLY) .................................................................................................................................. 321

Base Station Button Indicators .................................................................................................................................................................321

TECHNICAL SPECIFICATIONS ............................................................................................................................................................... 323

SAMPLE BAR CODES............................................................................................................................................................................. 335

1D Bar Codes .............................................................................................................................................................................. 335

GS1 DataBar™ (RSS) ................................................................................................................................................................... 336

GS1 DataBar™-14 ....................................................................................................................................................................... 336

KEYPAD.................................................................................................................................................................................................. 337

SCANCODE TABLES............................................................................................................................................................................... 341

Control Character Emulation ..............................................................................................................................................................................341

Single Press and Release Keys ..................................................................................................................................................................341

Interface Type PC AT PS/2, USB-Keyboard or USB-Keyboard for APPLE ......................................................................................................342

Interface Type PC AT PS/2, USB-Keyboard or USB-Keyboard for APPLE — cont. ........................................................................................343

Interface type PC AT PS/2 Alt Mode or USB-Keyboard Alt Mode ................................................................................................................... 344

Interface type PC AT PS/2 Alt Mode or USB-Keyboard Alt Mode — cont. ....................................................................................................345

Digital Interface .................................................................................................................................................................................................... 346

IBM31xx 102-key .................................................................................................................................................................................................347

IBM XT ................................................................................................................................................................................................................... 348

Microsoft Windows Codepage 1252 ..................................................................................................................................................................349

Gryphon™ I GD4132/GM4102/GBT 4102

About this Manual

This Product Reference Guide (PRG) is provided for users seeking advanced technical information, including connection, programming, maintenance and specifications. The Quick Reference Guide (QRG) and other publications associ ated with this product are downloadable free of charge from the website listed on the back cover of this manual.

Overview

Chapter 1, (this chapter) presents information about manual conventions, and an overview of the reader, its features and operation.

Chapter 2, Setup presents information about unpacking, cable connection

information and setting up the reader.

Chapter 3, Configuration Using Barcodes provides instructions and barcode

labels for customizing your reader. There are different sections for interface types, general features, data formatting, symbology-specific and model-spe cific features.

Chapter 4, Wireless Features describes options and programming related to

radio communication features for the RF variants of the Gryphon family.

Chapter 5, References provides background information and detailed instruc-

tions for more complex programming items.

Chapter 6, Message Formatting provides details for programming options.

Appendix A, Technical Specifications lists physical and performance character-

istics, as well as environmental and regulatory specifications. It also provides standard cable pin-outs and LED/Beeper functions.

Appendix B, Standard Defaults references common factory default settings for

reader features and options.

Appendix C, Sample Bar Codes offers sample barcodes of several common

symbologies.

Appendix D, Keypad includes numeric barcodes to be scanned for certain

parameter settings.

Appendix E, Scancode Tables lists control character emulation information for

Wedge and USB Keyboard interfaces.

Chapter 1

Introduction

Product Reference Guide

Introduction

Manual Conventions

The following conventions are used in this document:

The symbols listed below are used in this manual to notify the reader of key i

ssues or procedures that must be observed when using the reader:

CAUTION

References

Current versions of this Product Reference Guide (PRG), Quick Reference Guide (QRG), the Datalogic Aladdin™ Configuration application, and any other manuals, instruction sheets and utilities for this product can be downloaded from the

bsite listed below. Alternatively, printed copies or product support CDs for

we most products can be purchased through your Datalogic reseller.

Notes contain information necessary for properly diagnosing, repairing and operating the reader.

The CAUTION symbol advises you of actions that could damage equ

ipment or property.

Technical Support

Support Through the Website

Datalogic provides several services as well as technical support through its website. Log on to (www.datalogic.com).

For quick access, from the home page click on the search icon , and type in the name of the product you’re looking for. This allows you access to download Da

ta Sheets, Manuals, Software & Utilities, and Drawings.

Hover over the Support & Service menu for access to Services and Technical Support.

Reseller Technical Support

An excellent source for technical assistance and information is an authorized Datalogic reseller. A reseller is acquainted with specific types of businesses, application software, and computer systems and can provide individualized assistance.

10 Gryphon™ I GD4132/GM4102/GBT4102

About the Reader

Typically, units are factory-programmed for the most common terminal and communications settings. If you need to modify any programmable settings, custom configuration can be accomplished by scanning the programming bar codes within this guide.

Several models of the Gryphon are available, and are covered in this manual:

• Gryphon I GD4132 - Corded linear imager barcode reader

• Gryphon I GM4102 - Cordless linear imager barcode reader with Datalogic STAR™.

• Gryphon I BT 4102 - Model with Bluetooth options.

Programming can alternatively be performed using the Datalogic Aladdin™ Configuration application which is downloadable from the Datalogic website listed on the back cover of this manual. This multi-platform utility program allows device configuration using a PC. It communicates to the device using a serial or USB cable and can also create configuration barcodes to print.

Advancements in the LED technology used in the imager-based readers significantly improve the illumination of the target field of view, resulting in higher scan efficiency. Whether used in Single Trigger or Continuous Mode, the ergo nomic design of the reader will help to promote comfortable handling during extended periods of use.

See "Interface Selection" on page 30 for a listing and descriptions of available interface sets by model type.

About the Reader

Product Reference Guide

Introduction

YELLOW LED

RED LED / GREEN LED

BUTTON

The BC40xx™ Radio Base

Base LEDs

LEDs on the Gryphon I Base provide information about the Base’s status, as shown in Figure 1.

Figure 1

The following table describes the significance of each LED:

. Gryphon I Base LEDs

LED STATUS

Yellow On = Base is powered

Power on / Data

Yellow Blinking = Base receives data and commands from the Host or the Reader.



Charging Red On = Battery charging is in progress.

Charge completed Green On = the Battery is completely charged.

Charging + Charge completed

See "Base Station Indications (Cordless Models ONLY)" on page 347 for more specific details on the LEDs.

Red and Green Blinking together = the Reader is n

ot correctly placed onto the Base.

Base Button

The Base contains a button which is used primarily to perform a paging function. Pressing the button causes a sound signal to be emitted by all scanners

nked with this Base, as long as the scanner is awake (see "P

eep Mode Timeout" on page

out" on page 268) and reception is enabled (see "Sl

98). The button can also be used to "fo

Aladdin Software tool (available for free download from the Datalogic website). See

the Aladdin Online Help for details.

See "Base Station Indications (Cordless Models ONLY)" on page 347 for further information on Base Button functions.

rce device connection" via the Datalogic

12 Gryphon™ I GD4132/GM4102/GBT4102

owerdown Time-

Battery Safety

To reinstall, charge and/or perform any other action on the battery, follow the instructions in this manual.

Before installing the Battery, read “Battery Safety” on this and the following pages. Datalogic recommends annual replacement of recharg performance.

Battery Safety

eable battery packs to ensure maximum

WARNING

CAUTION

Do not discharge the battery using any device exc

ept for the scanner. When the battery is used in devices other than the designated product, it may damage the battery or reduce its life expectancy. If the device causes an abnormal current to flow, it may cause the battery to become hot, explode or ignite and cause serious injury.



Lithium-ion battery packs may get hot, explode or ignite and cause serious injury if exposed to abusive conditions. Be sure to follow the safety warnings listed below:

• Do not place the battery pack in fire or heat.

• Do not connect the positive terminal and negativ with any metal object (such as wire).

• Do not carry or store the battery pack together with metal objects.

• Do not pierce the battery pack with nails, strike it ject it to strong impacts or shocks.

• Do not solder directly onto the battery pack.

• Do not expose the battery pack to liquids, or allow the battery to get wet.

• Do not apply voltages to the battery pack contacts.

e terminal of the battery pack to each other

with a hammer, step on it or otherwise sub-

In the event the battery pack leaks and the fluid gets into your eye, do not rub the eye. Rinse well with water and immediately seek medical care. If left untreated, the battery fluid could cause damage to the eye.

• Always charge the battery at 32° – 104°

• Use only the authorized power supplies, battery pack, chargers, and docks supplied by your Datalogic reseller. The use of any other power supplies c

• Do not disassemble or modify the battery. The battery con which, if damaged, may cause the battery to generate heat, explode or ignite.

• Do not place the battery in or near fire, on stov

• Do not place the battery in direct sunlight, or use or store Doing so may cause the battery to generate heat, explode or ignite. Using the battery in this manner may also result in a loss of perform

• Do not place the battery in microwave ovens, high-pressure containers or on induction cookware.

• Immediately discontinue use of the battery if, while usin tery emits an unusual smell, feels hot, changes color or way.

• Do not replace the battery pack when

• Do not remove or damage the battery pack’s label.

• Do not use the battery pack if it is damaged in any part.

• Battery pack usage by children should be supervised.

As with other types of batteries, Lithium-Ion (LI) batteries will lose capacity over time. Capacity deterioration is noticeable after one year of service whether the battery is in use or not. It is difficult to precisely predict the finite life of a LI battery, but cell manufacturers rate them at 500 charge cycles. In other words, the batteries should be expected to take 500 full discharge / charge cycles before needing replacement. This number is higher if partial discharging / recharging is adhered to rather than full / deep discharging.

F (0° - 40°C) temperature range.

an damage the device and void your warranty.

tains safety and protection devices,

es or other high temperature locations.

the battery inside cars in hot weather.

ance and a shortened life expectancy.

g, charging or storing the battery, the bat-

shape, or appears abnormal in any other

the device is turned on.

Product Reference Guide

Introduction

Storage of batteries for long time at fully charged status or at fully discharged status should be avoided.

Only in case of long storage, to avoid deep discharge of the battery it is recommended to partially recharge the battery every three months to keep the charge status at a medium level.

As a reference, run a fast rec

harge for 20 minutes every three months on unused products

to avoid any performance deterioration of the cell.

The useful life of LI batteries depends on usage and number of charges, etc., after which they should be removed from service, especially in mission critical applications. Do not continue to use a battery showing excessive loss of capacity, it should be properly recycled / dispos

Collect and recycle waste batteries separately from the device in compliance wi

th European Directive 2006/66/EC, 2011/65/EU, 2002/96/EC and 2012/19/ EU and subsequent modifications, US and China regulatory and others laws and regulations about the environment.

ed of and replaced.

14 Gryphon™ I GD4132/GM4102/GBT4102

Programming the Reader

Configuration Methods

Programming Barcodes

The reader is factory-configured with a standard set of default features. After scanning the interface barcode, you can select other options and customize your reader through use of the instructions and programming barcode labels available in the corresponding features section for your interface. Customizable settings for many features are found in "Configuration Using Barcodes" starting on page 39.

Some programming labels, like "Restore Custom Defaults" on page 35, require only the scan of the single label to enact the change. Most, however, require the

er to be placed in Programming Mode prior to scanning them. Scan an

read ENTER/EXIT barcode once to enter Programming Mode. Once the reader is in Programming Mode, scan a number of parameter settings before scanning the ENTER/EXIT barcode a second time, which will then accept your changes, exit Programming Mode and return the reader to normal operation.

Programming the Reader

There are some exceptions to the typical programming sequence described above. Please read the description and setting instructions carefully when configuring each programmable feature.

Datalogic Aladdin™

Datalogic Aladdin™ is a multi-platform utility program providing a quick and user-friendly configuration method via the RS-232/USB-COM interface. Aladdin is available on the CD-ROM provided wi Datalogic website. Aladdin allows you to program the reader by selecting configuration commands through a user-friendly graphical interface running on a PC. Th interface, or they can be printed as barcodes to be scanned.

Aladdin also provides the ability to perform a software upgrade for the connected device (see the Datalogic Aladdin™ Help On-Line for more details).

ese commands are sent to the reader over the selected communication

th your product, and also from the

Product Reference Guide

Introduction

NOTES

16 Gryphon™ I GD4132/GM4102/GBT4102

Unpacking

Check carefully to ensure the reader and any accessories ordered are present and undamaged. If any damage occurred during shipment, contact Datalogic Technical Support. Information is shown on

KEEP THE PACKAGING. Should the unit ever require service, it should be returned in its original shipping container.

Setting Up the Reader

Depending on whether you are using a Corded or Mobile version of the Gryphon, follow the steps provided in this section to connect and get your reader

up and communicating with its host.

1. Begin by Installing the Interface Cable (Corded) or Connecting the Base

Station (Mobile)

Chapter 2

Setup

page 11.

2. Go to Interface Selection and set the desired interface.

3. Configure Interface Settings (only if not using factory settings for that interface)

4. Go to Configuring Other Features (if modifications are needed from factory settings)

Product Reference Guide

Setup

Installing the Interface Cable

For Corded versions, connect the reader cable by inserting the cable into the

handle as shown in Figure 2. To remove it, insert a paper clip into the release aperture, then unplug the cable.

Figure 2. Connect/disconnect the cable

RS-232 Serial Connection

Turn off power to the terminal/PC and connect the reader to the terminal/PC serial port via the RS232 cable as shown in Figure 3. If the terminal will not support POT (Power Off the Terminal) to supply reader power, Adapter). Plug the AC Adapter barrel connector into the socket on the RS-232 cable connector and the AC Adapter plug into a standard power outlet.

use the approved power supply (AC

Figure 3. RS-232 Connection

18 Gryphon™ I GD4132/GM4102/GBT 4102

Installing the Interface Cable

Keyboard Wedge Connection

The Keyboard Wedge cable has a ‘Y’ connection from the reader. Connect the female to the male end from the keyboard and the remaining end at the keyboard port at the terminal/PC. Reference Figure 4.

Figure 4. Keyboard Wedge Interface connection

USB Connection

Connect the reader to a USB port on the terminal/PC using the correct USB cable for the interface type you ordered. Reference Figure 5.

Figure 5. USB connection

Other connection types are described below and illustrated in Figure 6.

Product Reference Guide

Setup

Standing

Horizontal

Figure 6. Other Interface Connections

or...

Specific cables are required for connection to different hosts. The connectors illustrated above are examples only. vary from those illustrated, but the steps to connect the reader remain the same.

or...

Actual connectors may

RF Models

The power supply connects directly to the base (not on the cable's jack) for all configurations. For all interfaces (except RS-232) a power supply is recommended but not necessary, because the base can be powered from the Host. When

the base is powered from the Host, select a slow charge rate.

Configuring the Base Station

The base charger/station may be configured in desk application to hold the reader in two different positions, either a horizontal or standing position, in order to provide the most comfortable use depending on needs.

20 Gryphon™ I GD4132/GM4102/GBT 4102

Changing the Base Station Position

Horizontal

Only

Standing,

or Vertical

Horizontal

The base station is configured by installing one of two sets of mechanical parts that come with the cordless kit. The default mounts (shown below) provide three options: vertical (wall) mounting, standing (45°), or horizontal mounting with a higher mechanical retention of the scanner. Use the other mounts only for horizontal mounting, with lower retention of the scanner. The different parts may be interchanged to customize retention preferences.

A tool such as a rigid pen or a flat screwdriver can be used to change the mounts. Do not allow it to touch the contacts.

1. Insert the appropriate parts for the desired base station position, as shown below.

Configuring the Base Station

Product Reference Guide

To ensure best contact and performance, do not intermix the parts of the two different mount sets.

CAUTION

Setup

Tab

Horizontal

Standing

2. Using your thumbs, push open the plastic tabs on the bottom of the base to free the wing holders.

3. The stand can now be repositioned in either horizontal or standing position.

22 Gryphon™ I GD4132/GM4102/GBT 4102

Connecting the Base Station

Base

Station

I/F Cable

AC/DC Adapter

DC Power Cord

Wall plug Connector

Figure 7 shows how to connect the Base Station to a terminal, PC or other host device. Turn off the host before connection and consult the manual for that equipment (if neces applying power to the Base Station.

The Gryphon GBT4102 can be set up to require a PIN code when connecting to the host. To connect to a system that uses a custom security PIN, follow the procedure in "

page 26 Mode, starting on page 278

sary) before proceeding. Connect the interface cable before

. For information on how to configure this feature, see

Configuring the Base Station

Connecting the Base when Security Pin is Enabled" on

BT Security

Base Station Connection and Routing:

F) Cable connectors into their respective ports in the underside of the Base Station (see Figure 7). Then connect to an AC Adapter, and plug the AC power cord into the (wall) outlet.

Fully insert the Power Cable and Interface (I/

Gryphon Mobile can also be Powered by the Terminal. The external power supply is recommended but not necessary. W

hen powered by the Terminal, the

battery charger is automatically set as Slow charge.

For some specific interfaces or hosts or l nal power supply may be recommended for full rec

Technical Specifications, starting on page 315

engths of cable, the use of an exter-

harging capability (see

" for more details).

Figure 7. Connecting the Base Station

Product Reference Guide

Setup

Securing the DC Power Cord (Optional)

The DC power cord for the adapter can be secured to the bottom of the base in order to maximize the mechanical retention of the cable itself. The routing of the power cord can be changed to accommodate the base station positioning: horizontal, stand or wall mounting. The cables can be looped around to the front of the Base Station, or fed directly out the back of the Base Station, as shown in Figure 8.

Figure 8. Options for routing the DC cord

Please refer to the arrows depicted on the bottom of the base when placing the cables, detailed in Figure 9.

Figure 9. Arrows showing routing

24 Gryphon™ I GD4132/GM4102/GBT 4102

Configuring the Base Station

or...

Host Connection:

patible with your host equipme

Verify before connection that the reader’s cable type is com-

nt. Most connections plug directly into the host device as shown below. Keyboard Wedge interface cables have a ‘Y’ connection where its female end mates with the male end of the cable from the keyboard and the remaining end at the keyboard port on the terminal/PC.

Figure 10. Connecting to the Host

Power Connection :

the cable facing downwards (as shown in Figure 7) to prevent undue strain on the socket.

Plug the AC Adapter in to an approved AC wall socket with

Gryphon Mobile can also be Powered by the Terminal. The external power supply is recommended but not necessary. When powered by the Terminal, the battery charger is automatically set as Slow charge.

Disconnecting the Cable:

To detach the cable, insert a paper clip or similar object

into the hole on the base, as shown in Figure 11.

Figure 11. Disconnecting the Cable

Insert

Paper Clip

Product Reference Guide

Setup

Unlink

Connecting the Base when Security Pin is Enabled

When connecting the Base to a system that has a custom Security Pin enabled, follow the steps

below in the order shown:

1. Power down the host system.

2. Connect the appropriate interface cable into the Base as shown in Figure 10 on page 25.

3. Place the reader in the Base.

4. Power up the host. The reader will link to the Base.

5. When the host completely powers up, be sent to the

reader and Base, depending on host configuration. Contact Datalogic Technical Support for more information.

To change security settings or set up a PIN, see

on page 278

Linking the Reader to a Base Station

RF Devices

For RF devices, before configuring the interface it is necessary to link the handheld with the base. To link the handheld and the base, press it and place it on the base. If the reader was previously linked to another base, you must first scan the Unlink action command before re-linking to the new base.

a new custom Security Pin Code may

BT Security Mode, starting

the trigger to wake

BT Models only

Remember: The mandatory condition for establishing a new linking between a BT handheld and a BT base is that the handheld is unlinked and they share the same security configuration. A successful link is indicated by three ascending tones from the reader. A high-low-high-low tone indicates the link attempt was unsuccessful. A single green LED flash after this tone indicates no Base Station was discovered. Two green LED flashes after this tone indicates that more than one Base Station was discovered and the reader did not link. Three LED flashes after this tone indicate a security error.

26 Gryphon™ I GD4132/GM4102/GBT 4102

Linking a BT Reader to a PC

Link to a PC in Server Mode

The reader can optionally be linked to a Bluetooth-enabled PC with the serial port profile, in either server mode or client mode, or with human interface device profile (HID).

Linking to a PC in Server Mode (BT Slave Mode)

To link a BT reader in server mode to a Bluetooth-enabled PC, follow these steps:

1. Install any drivers provided with the Bluetooth adapter.

Configuring the Base Station

2. Scan the

the host computer.

3. Use the host computer’s Bluetooth manager to “Discover new devices” and

select "Datalogic Scanner." If you receive an error message, it may be necessary to disable security on the device.

4. Select “connect” on the PC to link the reader to the P

minal program to see incoming data on puter's Bluetooth manager.

Link to a PC in Server Mode

barcode to make the scanner visible to

C. Use an RS-232 ter-

the port designated by the com-

Linking to a PC in Client Mode (BT Master Mode)

The reader can optionally be linked in client mode to a Bluetooth-enabled PC with the serial port profile. To do this, follow these steps:

1. Ensure the PC or terminal can network with Bluetooth devices and that it is

powered on.

Product Reference Guide

2. Ensure that a COM port is assigned under Services within the Bluetooth

setup menu.

3. Create a Link label that contains the address of the PC Bluetooth adapter.

The Bluetooth address can be found under "Properties" within in the Bluetooth setup menu.



The link label is a Code 128 function 3 label with the following format:

4. Scan the link label you created in step 3.



Setup

Linking to a PC in HID

1. Install any drivers provided with the Bluetooth adapter.

2. Scan the Link to a PC in HID barcode below to make the scanner visible to the ho

3. Use the host computer's Bluetooth manager to "Discover new devices" and select "Datalogic Scanner." If you receive an error message, it may be necessary to disable security on the device.

4. Select "connect" on the PC to link the reader to the PC. Use a text editing program to see

st computer.

Link to a PC in HID

incoming data from the reader.

Gryphon™ I System and Network Layouts

Stand Alone Layouts

Figure 12 - Single Reader Layout

28 Gryphon™ I GD4132/GM4102/GBT 4102

Figure 13 - Multiple Reader Layout

Gryphon M4102 only

(not valid for BT model)

Gryphon M4102 only

(not valid for BT model)

Gryphon™ I System and Network Layouts

In stand alone systems, each cradle is connected to a single Host.

Figure 14 - Multiple Stand Alone Layouts

Many stand alone connections can operate in the same physical area without interference, provided all readers and cradles in the system have different addresses.

Product Reference Guide

Setup

Interface Selection

Upon completing the physical connection between the reader and its host, proceed to Table 1 starting on page 31 to select the interface type the reader is connected to (for example: RS-232, Key appropriate barcode in that section to configure your system’s correct interface type.

Each reader model will support one of the following sets of host interfaces:

General Purpose Models Retail Point of Sale Models

•RS-232

• RS-232 OPOS

• USB

• Keyboard Wedge

•Wand Emulation

Setting the Interface

Scan the programming barcode from this section which selects the appropriate interface type matching the system the reader will be connected to. Next, proceed to the corresponding section in this manual (also listed in Table 1 starting

on page 31) to configure any desired settings a

interface.

board Wedge, USB, etc.). Scan the

•RS-232

• RS-232 OPOS

•USB

• IBM 46XX (available with special ble)

nd features associated with that

Unlike some programming features and options, interface selections require that you scan only one programming barcode label. DO NOT scan an ENTER/EXIT barcode prior to scanning an interface selection barcode.

Some interfaces require the scanner to start in the disabled state when powered up. If additiona state, pull the trigger and hold it for five seconds. The scanner will change to a state that allows programming with barcodes.

l scanner configuration is desired while in this

30 Gryphon™ I GD4132/GM4102/GBT 4102

Table 1. Available Interfaces

$P,HA05,P

Interface Selection

RS-232

RS-232 standard interface

Select RS232-WN

RS-232 for use with OPOS/UPOS/JavaPOS

FEATURES

Select RS232-STD

RS-232 Wincor-Nixdorf

Set RS-232

Interface Features

starting on

page 43

Select RS-232 OPOS

USB Com to simulate RS-232 standard interface

Select USB-COM-STD

IBM (available with special cable)

Select IBM-P5B

IBM-46xx Port 9B reader interface

USB-OEM

Select USB-OEM

IBM-46xx Port 5B reader interface

Select IBM-P9B

USB-OEM

(can be used for OPOS/UPOS/JavaPOS)

FEATURES

Set IBM Interface Features

starting on

page 71

FEATURES

Set USB-OEM

Interface Features

starting on

page 69

a. Download the correct USB Com driver from www.datalogic.com

Product Reference Guide

Setup

KEYBOARD

AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95 w/Standard Key Encoding

Select KBD-AT-NK

AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90

& 95 w/Alternate Key

Select KBD-AT-ALT-NK

Select KBD-AT

Keyboard Wedge for IBM AT PS2 with standard key encoding but without external keyboard

Select KBD-AT-ALT

Keyboard Wedge for IBM AT PS2 with alternate key encoding but without external keyboard

FEATURES

Set KEYBOARD

WEDGE Interface Features

starting on

page 57

PC/XT w/Standard Key Encoding

Select KBD-IBM-3153

Select KBD-XT

Keyboard Wedge for IBM Terminal 3153

32 Gryphon™ I GD4132/GM4102/GBT 4102

Interface Selection

KEYBOARD — cont.

Keyboard Wedge for IBM Terminals 31xx, 32xx, 34xx, 37xx make only keyboard

Select KBD-IBM-MB

Keyboard Wedge for DIGITAL Terminals V

T2xx, VT3xx, VT4xx

Select KBD-IBM-M

Keyboard Wedge for IBM Terminals 31xx, 32xx, 34xx, 37xx make break keyboard

Select KBD-DIG-VT

USB Keyboard with standard key encoding

FEATURES

Set KEYBOARD

WEDGE Interface Features

starting on

page 57

Select USB Keyboard

USB Keyboard with alternate key encoding

Select USB Alternate Keyboard

USB Keyboard for Apple computers

Select USB-KBD-APPLE

WAND EMULATION FEATURES

Set WAND

Interface

Wand Emulation

Features

starting on

Select WAND

page 75

Product Reference Guide

Setup

Transmit Software Version

Customizing Configuration Settings

Configure Interface Settings

If after scanning the interface barcode from the previous table, your installation requires you to select options to further customize your reader, turn to the appropriate section for your interface type in "Configuration Using Barcodes" starting on page 39.

• "RS-232 ONLY Interface" on page 43

• "RS-232/USB-Com Interfaces" on page 48

• "Keyboard Interface" on page 57

• "USB-OEM Interface (available with special cable)" on page 69

• "IBM 46XX Interface (AVAILABLE WITH SPECIAL CABLE)" on page 71 (ava

able with special cable)

• "Wand Emulation Interface" on page 75

Global Interface Features

il-

See "Global Interface Features" on page 41 for settings configurable by all interface types.

Configuring Other Features

If your installation requires different programming than the standard factory default settings, the following sections of this manual allow configuration of non-interface-specific settings you might require:

Reading Parameters

beeper and LED indicators and other universal settings.

Code Selection

gies). These settings allow you to enable/disable symbologies, set label le

ngths, require check digit, etc.

Wireless Features

only.

Reading Parameters include programming for scanning,

Includes options concerning the barcode label types (symbolo-

Contains programming options for RF and Bluetooth models

Software Version Transmission

The software version of the device can be transmitted over the RS-232 and Keyboard interfaces by scanning the following label.

34 Gryphon™ I GD4132/GM4102/GBT 4102

Customizing Configuration Settings

Restore Custom Default Configuration

Resetting the Product Configuration to Defaults

Restore Custom Defaults

If you aren’t sure what programming options are in your imager, or you’ve changed some options and want to restore the Custom Default Configuration that may have been saved in the scanner, scan the Restore Custom Default Configuration barcode below. This will restore the custom configuration for the currently active interface.

Custom defaults are based on the interface type. Configure the imager for the correct interface before scanning this label.

Restore Factory Configuration

If you want to restore the Factory Configuration for your imager, scan either the Restore USA Factory Configuration barcode or the Restore EU Factory Configuration barcode below. Both labels restore the scanner configuration to the factory settings, including the interface type. The USA label restores Label IDs to

ose historically used in the USA. The EU label restores Label IDs to those his-

th torically used in Europe. The Label ID sets for USA and EU are shown in the

“Label ID” section on page 83 of this manual.

Restore USA Factory Configuration

The programming items listed in the following sections show the factory default settings for each of the menu commands.

Product Reference Guide

Restore EU Factory Configuration

Setup

Screw

Connector

Screw

Replacing the Battery

Before replacing the Battery, read mends annual replacement of rechargeable battery packs to ensure maximum performance.

To change the battery of your reader, complete the following instructions.

1. With a screwdriver, unscrew the battery cover screw.

2. Unscrew and remove the three screws securing the battery holder, and unplug the white connector.

"Battery Safety"

starting on page 13. Datalogic recom-

36 Gryphon™ I GD4132/GM4102/GBT 4102

Customizing Configuration Settings

Pass-through hole

3. Carefully lift out the gold contacts circuit, and remove the battery holder

while letting the white connector pass through the hole in the battery holder (as shown in the picture below).

4. Remove the old battery from its place (if present), and insert the new bat-

tery in the same position.

5. Replace the battery holder and three screws,

return the contacts circuit to its previous location.

plug in the connector, and

When inserting the new battery into the handle, take care to position the battery and the connector as shown.

6. Insert the cover in the handle and screw it back into place.

Battery replacement is now complete.

Product Reference Guide

Setup

NOTES

38 Gryphon™ I GD4132/GM4102/GBT 4102

This and following sections provide programming barcodes to configure your reader by changing the default settings. For details about additional methods of programming, see

Configuration Parameters

Once the reader is set up, you can change the default parameters to meet your application needs. Refer to "Standard Defaults" starting on configuration in order to set the default values and select the interface for your a

pplication.

The following configuration parameters are applicable to all Gryphon models covered in this manual, unless otherwise indicated. The items are divided into logical groups, making it easy to find the desired function based on its reference group.

Chapter 3

Configuration Using Barcodes

"Configuration Methods" on page 15.

You must first enable your reader to read barcodes in order to use this section. If you have not done this, go to

page 17

and complete the appropriate procedure.

Setup, starting on

page 363 for initial

Interface Configuration:

• "RS-232 ONLY Interface" on page 43

• "RS-232/USB-Com Interfaces" on page 48

• "Keyboard Interface" on page 57

• "USB-OEM Interface (available with special cable)" on page 69

• "IBM 46XX Interface (AVAILABLE WITH SPECIAL CABLE)" on page 71 (avail-

able with special cable)

• "Wand Emulation Interface" on page 75

Parameters common to all interface applications:

• "Data Format" on page 79 gives options to control the messages sent to

the Host system.

• "Reading Parameters" on page 95 control various operating modes and

indicators status functioning.

Product Reference Guide

Configuration Using Barcodes

Symbology-specific parameters:

• "Code Selection" on page 111 provides configuration of a personalized mix of codes, code famili

Model-specific parameters:

• "Wireless Features" on page 259 offers configuration of radio control parameters for RF and Bluetooth models.

Reading Configuration Barcodes

You must first enable your reader to read barcodes in order to use this section. If you have not done this, go to

page 17

To program features:

1. Scan the ENTER/EXIT PROGRAMMING barcode, available at the top of each programming

page, when applicable.

es and their options.

Setup, starting on

and complete the appropriate procedure.

2. Scan the barcode to set the desired pr to cover unused barcodes on the page, and possibly the facing page, to ensure that the reader reads only the barcode you intend to scan.

3. If additional input paramete scan the appropriate characters from the keypad.

rs are needed, go to Appendix D, Keypad, and

ogramming feature. You may need

Additional information about many features can be found in the “References” chapter.

If you make a mistake before the last cha code to abort and not save the entry

racter, scan the CANCEL bar-

string. You can then start again

at the beginning.

4. Complete the programming sequence by scanning the ENTER/EXIT PROGRAMMING barcode to exit Programming Mode.

For detailed descriptio selected configuration items, see References, starting on page 283.

ns, programming information and examples for setting

Gryphon™ I GD4132/GM4102/GBT 4102

ENTER/EXIT PROGRAMMING MODE

DEFAULT

GLOBAL INTERFACE FEATURES

The following interface features are configurable by all interface types.

Host Commands — Obey/Ignore

This option specifies whether the reader will obey or ignore host commands. When set to ignore, the reader will ignore all host commands except for those necessary for:

•service mode

• flash programming mode

•keeping the inte

• transmission of labels.

rface active

Host Commands = Obey

Host Commands = Ignore

USB Suspend Mode

This setting enables/disables the ability of USB interfaces to enter suspend mode.

USB Suspend Mode = Disable

USB Suspend Mode = Enable

Product Reference Guide

Configuration Using Barcodes

NOTES

Gryphon™ I GD4132/GM4102/GBT 4102

RS-232 ONLY INTERFACE

BAUD RAT E on page 44

DATA BITS on page 45

STOP BITS on page 45

PARITY on page 46

HANDSHAKING CONTROL on page 47

Use the programming barcodes in this section if modifications to the standard RS

-232 interface settings are necessary to meet your system’s requirements. Additional settings which apply to both the RS-232 and USB interfaces are available in the next section, "RS-232/USB-Com Interfaces" starting on page 48.

Reference Appendix B, Standard Defaults for a listing of standard factory settings.

Product Reference Guide

Baud Rate

DEFAULT

See page 283 for information on this feature.

Baud Rate = 2400

ENTER/EXIT PROGRAMMING MODE

Baud Rate = 1200

Baud Rate = 4800

Baud Rate = 9600

Baud Rate = 38,400

Baud Rate = 19,200

Baud Rate = 57,600

Baud Rate = 115,200

Gryphon™ I GD4132/GM4102/GBT 4102

ENTER/EXIT PROGRAMMING MODE

Data Bits

This parameter allows the reader to interface with devices requiring a 7-bit or 8-bit ASCII protocol for sending and receiving data.

8 Data Bits

7 Data Bits

DEFAULT

Stop Bits

Set the number of stop bits to match host device requirements. See page 283 for more information on this feature.

DEFAULT

1 Stop Bit

2 Stop Bits

Product Reference Guide

ENTER/EXIT PROGRAMMING MODE

Parity

This feature specifies parity required for sending and receiving data. Select the parity type according to host device requirements. See page 283 for more information.

DEFAULT

Parity = None

Parity = Even

Parity = Odd

Gryphon™ I GD4132/GM4102/GBT 4102

ENTER/EXIT PROGRAMMING MODE

Handshaking Control

See page 283 for more information about this feature.

DEFAULT

Handshaking Control = RTS/CTS

Handshaking Control = RTS

Handshaking Control = RTS On/CTS

Handshaking Control = RTS/XON/XOFF

Handshaking Control = RTS/CTS Scan Control

Product Reference Guide

RS-232/USB-COM INTERFACES

INTERCHARACTER DELAY on page 49

BEEP ON ASCII BEL on page 50

BEEP ON NOT ON FILE on page 50

ACK NAK OPTIONS on page 51

ACK CHARACTER on page 52

NAK CHARACTER on page 52

ACK NAK TIMEOUT VALUE on page 53

ACK NAK RETRY COUNT on page 54

ACK NAK ERROR HANDLING on page 55

INDICATE TRANSMISSION FAILURE on page 55

DISABLE CHARACTER on page 56

ENABLE CHARACTER on page 56

The programming barcodes in this chapter allow modifications to the standard

-232 and USB-Com interfaces. Reference Appendix B, Standard Defaults for a

RS listing of standard factory settings.

Product Reference Guide

ENTER/EXIT PROGRAMMING MODE

00 = No Intercharacter Delay

Intercharacter Delay

This parameter specifies the intercharacter delay between the end of one character and the beginning of the next. The delay can be set within a range of zero

) to 990 milliseconds in 10ms increments. A setting of zero specifies no

(0 delay.

See page 284 for more information.

Select Intercharacter Delay Setting

Intercharacter Delay = No Delay

Make a mistake? Scan the CANCEL barcode to abort and not

he entry string. You can then start again at the begin-

save t

ning.

DEFAULT

CANCEL

Product Reference Guide

ENTER/EXIT PROGRAMMING MODE

DEFAULT

Beep On ASCII BEL

When this parameter is enabled, the reader issues a beep when a <BEL> character is detected on the RS-232 serial l attention to an illegal entry or other important event.

ine. <BEL> is issued to gain a user's

DEFAULT

Beep On ASCII BEL = Disable

Beep On ASCII BEL = Enable

Beep On Not on File

This option enables/disables the action of the reader to sound a three beep sequence upon receiving a Not-On-File (NOF) host command.

Beep On Not On File = Disable

Beep On Not On File = Enable

Gryphon™ I GD4132/GM4102/GBT 4102

ENTER/EXIT PROGRAMMING MODE

ACK NAK Options

This enables/disables the ability of the reader to support the RS-232 ACK/NAK protocol.  See page 285 for more information.

DEFAULT

ACK/NAK Protocol = Enable for label transmission

ACK/NAK Protocol = Disable ACK/NAK

ACK/NAK Protocol = Enable for label transmission and host-

command acknowledge

ACK/NAK Protocol = Enable for host-command

acknowledge

Product Reference Guide

ENTER/EXIT PROGRAMMING MODE

0x06 ‘ACK’ Character

0x15 ‘NAK’ Character

ACK Character

This setting specifies an ASCII character or hex value to be used as the ACK character. ASCII characters or any hex value from 0 to 0xFF can be selected. See

page 285 for more info

Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters. 8-bit data is not recognized when the option Data Bits.

Select ACK Character Setting

rmation.

Data Bits

has been set as 7

DEFAULT

NAK Character

This setting specifies an ASCII character or hex value to be used as the NAK character. ASCII characters or any hex value from 0 to 0xFF can be selected.

Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters. 8-bit data is not recognized when the option Data Bits.

page 286 for more info

Select NAK Character Setting

rmation.

Data Bits

has been set as 7

DEFAULT

See

Gryphon™ I GD4132/GM4102/GBT 4102

ENTER/EXIT PROGRAMMING MODE

DEFAULT

01 ACK NAK Timeout value is 200ms

ACK NAK Timeout Value

This option specifies the amount of time the reader waits for an ACK character from the host following label transmission. The selectable timeout range is 200 milliseconds to 15,000ms (15 seconds) in 200ms increments. A selection of 0 disables the timeout.

See page 287 for more information on setting this feature.

Select ACK NAK Timeout Value Setting

Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning.

CANCEL

Product Reference Guide

ACK NAK Retry Count

003 = 3 Retries

This feature specifies the number of times the reader retries a label transmission due to a retry condition. The selectable range is from 1 to 254 retries. A

lection of 0 disables the count, and a selection of 255 specifies unlimited

se retries. See page 288 for more information.

Select ACK NAK Retry Count Setting

Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning.

ENTER/EXIT PROGRAMMING MODE

CANCEL

DEFAULT

Gryphon™ I GD4132/GM4102/GBT 4102

ENTER/EXIT PROGRAMMING MODE

ACK NAK Error Handling

This feature specifies the method the reader uses to handle receive errors detected while waiting for an ACK character from the host.

DEFAULT

ACK NAK Error Handling = Process Error as Valid ACK Charac-

ter

ACK NAK Error Handling = Ignore Errors Detected

Indicate Transmission Failure

This option enables/disables the reader’s ability to sound an error beep to indicate a transmission failure while in ACK/NAK mode

Indicate Transmission Failure = Enable Indication

ACK NAK Error Handling = Process Error as

Valid NAK Character

Indicate Transmission Failure = Disable Indication

DEFAULT

Product Reference Guide

ENTER/EXIT PROGRAMMING MODE

0x44 = Disable Character is ‘D’

0x45 = Enable Character is ‘E’

Disable Character

Specifies the value of the RS-232 host command used to disable the reader.

ASCII characters or any hex value from 0 to 0xFF can be selected.

Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters. 8-bit data is not recognized when the option has been set as 7 Data Bits.

See page 289 for more information on setting this feature.

Select Disable Character Setting

Data Bits

DEFAULT

Enable Character

Specifies the value of the RS-232 host command used to enable the reader.

ASCII characters or any hex value from 0 to 0xFF can be selected.

Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these char acters. 8-bit data is not recognized when the option has been set as 7 Data Bits.

See page 290 in “References” for more information on setting this feature.

Select Enable Character Setting

Data Bits

DEFAULT

Gryphon™ I GD4132/GM4102/GBT 4102

KEYBOARD INTERFACE

COUNTRY MODE on page 58

CAPS LOCK STATE on page 61

NUMLOCK on page 61

SEND CONTROL CHARACTERS on page 62

WEDGE QUIET INTERVAL on page 63

INTERCHARACTER DELAY on page 64

INTERCODE DELAY on page 65

USB KEYBOARD SPEED on page 66

USB KEYBOARD NUMERIC KEYPAD on page 68

Use the programming barcodes in this chapter to select options for USB Keyboard and Wedge Inter listing of standard factory settings.

Information about control character emulation which applies to keyboard interfaces is listed in Appendix E, Scancode Tables.

Product Reference Guide

faces. Reference Appendix B, Standard Defaults for a

ENTER/EXIT PROGRAMMING MODE

Country Mode

This feature specifies the country/language supported by the keyboard.

Only the following interfaces

• USB Keyboard (without alternate key encoding)

• AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95 w/Std Key Encoding

• Keyboard Wedge for IBM AT PS2 with standard key encoding but external keyboard

• AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95 without Alternate Key

• Keyboard Wedge for IBM AT PS2 without alte out external keyboard

• Bluetooth HID Profile

All other interfaces support ONLY the following Country Modes: U.S., Belgium,

itain, France, Germany, Italy, Spain, Sweden.

support ALL Country Modes.

without

rnate key encoding but with-

DEFAULT

Country Mode = Belgium

Country Mode = Croatia

Supports only the interfaces listed in the Country Mode fe

ature description.

Country Mode = U.S.

Country Mode = Britain

Supports only the interfaces listed in the Country Mode feature description.

Country Mode = Czech Republic

Gryphon™ I GD4132/GM4102/GBT 4102

ENTER/EXIT PROGRAMMING MODE

Country Mode — continued

Country Mode = Denmark

Country Mode = French Canadian

Supports only the interfaces listed in the Country Mode feature description.

Country Mode = France

Country Mode = Hungary

Country Mode = Japanese 106-key

Country Mode = Germany

Supports only the interfaces listed in the Country Mode feature description.

Country Mode = Italy

Supports only the interfaces listed in the Country Mode feature description.

Country Mode = Lithuanian

Product Reference Guide

Country Mode — continued

Supports only the interfaces listed in the Country Mode feature description.

Country Mode = Poland

Supports only the interfaces listed in the Country Mode fe

ature description.

ENTER/EXIT PROGRAMMING MODE

Country Mode = Norway

Supports only the interfaces listed in the Country Mode feature description.

Country Mode = Portugal

Country Mode = Romania

Supports only the interfaces listed in the Country Mode fe

ature description.

Country Mode = Spain

Supports only the interfaces listed in the Country Mode feature description.

Country Mode = Slovakia

Country Mode = Sweden

Supports only the interfaces listed in the Country Mode feature description.

Country Mode = Switzerland

Gryphon™ I GD4132/GM4102/GBT 4102

ENTER/EXIT PROGRAMMING MODE

Caps Lock State

This option specifies the format in which the reader sends character data. This applies to keyboard wedge interfaces and Bluetooth HID Profile. This does not apply when an alternate key encoding keyboard is selected.

DEFAULT

Caps Lock State = Caps Lock ON

Caps Lock State = Caps Lock OFF

Caps Lock State = AUTO Caps Lock Enable

Numlock

This option specifies the setting of the Numbers Lock (Numlock) key while in keyboard wedge interface. This only applies to alternate key encoding interfaces. It does not apply to USB keyboard.

DEFAULT

Numlock = Numlock key unchanged

Numlock = Numlock key toggled

Product Reference Guide

ENTER/EXIT PROGRAMMING MODE

Send Control Characters

This feature Specifies how the reader transmits ASCII control characters to the host. Reference Appendix E, Scancode Tables for more information about control characters.

Options are as follows:

Control Character 00 :

Ctrl+Keys, special keys are located from 0x80 to 0xA1.

Control Character 01 :

Ctrl+Capital Key, special keys are located from 0x80 to 0xA1.

Control Character 02 :

from 0x80 to 0xFE are intended as an extended ASCII table (Microsoft Windows Codepage 1252 — see "Microsoft Windows Codepage 1252" on

Characters from 00 to 0x1F are sent as control character

Special keys are located from 00 to 0x1F and characters

page 349).

DEFAULT

Wedge Send Control Characters = 00

Wedge Send Control Characters = 01

Wedge Send Control Characters = 02

Gryphon™ I GD4132/GM4102/GBT 4102

ENTER/EXIT PROGRAMMING MODE

10 = Quiet Interval of 100 ms

Wedge Quiet Interval

This option specifies the amount of time to look for keyboard activity before the reader breaks the keyboard connection in order to transmit data to host. The selectable range for this feature is from 0 to 990ms in 10ms increments.

This feature applies ONLY to the Keyboard Wedge interface.

See page 291 in “References” for detailed information and examples for setting this feature.

Select Wedge Quiet Interval Setting

Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning.

DEFAULT

CANCEL

Product Reference Guide

ENTER/EXIT PROGRAMMING MODE

00 = No Intercharacter Delay

Intercharacter Delay

This parameter specifies the intercharacter delay between the end of one character and the beginning of the next. The delay can be set within a range of zero

) to 990 milliseconds in 10ms increments. A setting of zero specifies no

(0 delay.

This feature applies ONLY to the Keyboard Wedge interface and Bluetooth HID Profile.

See page 292 in “References” for detailed information and examples for setting this feature.

Intercharacter Delay = No Delay

Select Intercharacter Delay Setting

Make a mistake? Scan the CANCEL barcode to abort and not

he entry string. You can then start again at the begin-

save t ning.

DEFAULT

CANCEL

Gryphon™ I GD4132/GM4102/GBT 4102

ENTER/EXIT PROGRAMMING MODE

DEFAULT

00 = No Wedge Intercode Delay

Intercode Delay

Specifies the delay between labels transmitted to the host for this interface. The selectable range for this feature is from 0 to 99 seconds.

See page 293 in “References” for detailed information and examples for setting this feature.

Set Intercode Delay

Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning.

CANCEL

Product Reference Guide

ENTER/EXIT PROGRAMMING MODE

USB Keyboard Speed

This option specifies the USB poll rate for a USB keyboard.

This feature applies ONLY to the USB Keyboard interface.

DEFAULT

USB Keyboard Speed = 1ms

USB Keyboard Speed = 2ms

USB Keyboard Speed = 4ms

USB Keyboard Speed = 6ms

USB Keyboard Speed = 3ms

USB Keyboard Speed = 5ms

Gryphon™ I GD4132/GM4102/GBT 4102

ENTER/EXIT PROGRAMMING MODE

USB Keyboard Speed — continued

USB Keyboard Speed = 8ms

USB Keyboard Speed = 7ms

USB Keyboard Speed = 9ms

USB Keyboard Speed = 10ms

Product Reference Guide

ENTER/EXIT PROGRAMMING MODE

USB Keyboard Numeric Keypad

This option Controls whether numeric characters will be sent using standard keys or the numeric keypad.

DEFAULT

Standard Keys

Numeric Keypad

Gryphon™ I GD4132/GM4102/GBT 4102

USB-OEM INTERFACE

(AVAILABLE WITH SPECIAL CABLE)

USB-OEM DEVICE USAGE on page 70

INTERFACE OPTIONS on page 70

Feature settings for USB interfaces differ depending upon which host type the

eader will be connected with. Use the feature settings in this chapter and "IBM

46XX Interface (AVAILABLE WITH SPECIAL CABLE)" on

configure for the USB-OEM interface. Other USB interfaces are included in the

ropriate chapter for their host type.

app

Reference Appendix B, Standard Defaults for a listing of standard factory settings.

page 71 to specifically

Product Reference Guide

ENTER/EXIT PROGRAMMING MODE

DEFAULT

USB-OEM Device Usage

The USB-OEM protocol allows for the reader to be identified as one of two different types of barcode scanners. Depending on what other scanners you may

lready have connected to a USB-OEM POS, you may need to change this setting

a to enable all devices to communicate.

Options are:

• Table Top Scanner

• Handheld Scanner

It may be necessary to switch device usage when connecting two readers/scanners of the same type to a POS system.

USB-OEM Device Usage = Handheld Scanner

Interface Options

This feature provides for an interface-specific control mechanism.

USB-OEM Device Usage = Table Top Scanner

Obey Scanner Configuration Host Commands

Ignore Scanner Configuration Host Commands

Gryphon™ I GD4132/GM4102/GBT 4102

IBM 46XX INTERFACE

(AVAILABLE WITH SPECIAL CABLE)

46XX NUMBER OF HOST RESETS on page 72

TRANSMIT LABELS IN CODE 39 FORMAT on page 74

INTERFACE OPTIONS on page 74

Use the barcodes in this section to configure programmable features for available IBM 46XX interfaces.

Reference Appendix B, Standard Defaults for a listing of standard factory settings.

Product Reference Guide

ENTER/EXIT PROGRAMMING MODE

DEFAULT

46xx Number of Host Resets

Specifies how many consecutive resets are processed before the reader starts a five-second period to allow the user to enter Programming Mode and configure the reader. The configurable range for this feature is 1 to 15 resets.

46xx Number of Host Resets = 1

46xx Number of Host Resets = 2

46xx Number of Host Resets = 4

46xx Number of Host Resets = 6

46xx Number of Host Resets = 3

46xx Number of Host Resets = 5

46xx Number of Host Resets = 7

Gryphon™ I GD4132/GM4102/GBT 4102

ENTER/EXIT PROGRAMMING MODE

46xx Number of Host Resets — cont.

46xx Number of Host Resets = 8

46xx Number of Host Resets = 10

46xx Number of Host Resets = 9

46xx Number of Host Resets = 12

46xx Number of Host Resets = 14

46xx Number of Host Resets = 11

46xx Number of Host Resets = 13

46xx Number of Host Resets = 15

Product Reference Guide

ENTER/EXIT PROGRAMMING MODE

DEFAULT

Transmit Labels in Code 39 Format

This feature enable/disables translation to Code 39 before transmitting label data to an IBM-46XX or a USB-OEM host. Only the symbology identifier is modified for the translation. The data is not converted to Code valid for Code 39.

Options are:

39 or verified to be

IBM Standard Format:

Code 39 Format:

Send labels in standard IBM format.

Translate the following symbologies to Code 39:

• USB-OEM: Code128, Code 93, and Codabar

• IBM-Port 5B: Code 128, Code 93, and Codabar

• IBM-Port 9B: Code 93 and Codabar

DEFAULT

Transmit Labels in Code 39 Format = Code 39 Format

Transmit Labels in Code 39 Format = IBM Standard Format

Interface Options

This feature provides for an interface-specific control mechanism.

Obey Scanner Configuration Host Commands

Ignore Scanner Configuration Host Commands

Gryphon™ I GD4132/GM4102/GBT 4102

WAND EMULATION INTERFACE

WAND SIGNAL SPEED on page 76

WAND POLARITY on page 76

WAND IDLE STATE on page 77

TRANSMIT NOISE on page 77

LABEL SYMBOLOGY CONVERSION on page 78

This chapter provides feature/settings co interface.

Reference Appendix B, Standard Defaults for a listing of standard factory settings.

nfiguration for the Wand Emulation

Product Reference Guide

ENTER/EXIT PROGRAMMING MODE

DEFAULT

Wand Signal Speed

This feature specifies the speed of the Wand output signal per nominal bar or space. Choices are:

• 330 microseconds

• 660 microseconds

Wand Signal Speed = 330ms

Wand Signal Speed = 660ms

Wand Polarity

This option specifies the polarity of the Wand output signal. Choices are:

• Quiet zones and spaces are high, bars are low

• Quiet zones and spaces are low, bars are high

TTL logic levels: 0V <= Low <= 0.7V

2.4V <= High <= 5.25V

Wand Polarity = Quiet Zones & Spaces Low, Bars High



Wand Polarity = Quiet Zones & Spaces High, Bars Low

76 Gryphon™ I GD4132/GM4102/GBT4102

ENTER/EXIT PROGRAMMING MODE

DEFAULT

Wand Idle State

This feature specifies the level of the Wand output signal when the reader is idle.

TTL logic levels: 0V <= Low <= 0.7V

2.4V <= High <= 5.25V



Wand Idle State = Low

DEFAULT

Wand Idle State = High

Transmit Noise

This option specifies the leading/trailing noise for the Wand interface.

Transmit Noise = Transmit leading noise

Transmit Noise = Transmit leading and trailing noise

Transmit Noise = Disable

Transmit Noise = Transmit trailing noise

Product Reference Guide

ENTER/EXIT PROGRAMMING MODE

Label Symbology Conversion

When this feature is enabled for the Wand Emulation interface, all barcode labels are converted to a single symbology. Options are:

• No conversion

• Convert to Code 39 symbology

• Convert to Code 39 Full ASCII

• Convert to Code 128 symbology

DEFAULT

Label Symbology Conversion = No conversion

Label Symbology Conversion = Convert to Code 39

Label Symbology Conversion = Convert to Code 128

Label Symbology Conversion =

Convert to Code 39 Full ASCII

78 Gryphon™ I GD4132/GM4102/GBT4102

DATA FORMAT

GLOBAL PREFIX/SUFFIX on page 80

GLOBAL AIM ID on page 81

GS1-128 AIM ID

on page 82

LABEL ID on page 83

• LABEL ID: PRE-LOADED SETS on page 83

• LABEL ID: SET INDIVIDUALLY PER SYMBOLOGY on page 84

• LABEL ID CONTROL on page 84

• LABEL ID SYMBOLOGY SELECTION on page 85

• SET GLOBAL MID LABEL ID CHARACTERS on page 92

CASE CONVERSION on page 93

CHARACTER CONVERSION on page 94

It is not recommended to use these features with IBM interfaces.

CAUTION

The features in this chapter can be used to build specific user-defined data into a message string. See “References” starting on page 296 for more detailed instructions on setting these features.

Product Reference Guide

ENTER/EXIT PROGRAMMING MODE

DEFAULT

No Global Prefix

Global Suffix = 0x0D (CR)

Global Prefix/Suffix

This option sets up to 20 characters each from the set of ASCII characters or any hex value from 00 to FF. The characters may be added as a prefix (in a position before the barcode data, also called a header) and/or as a suffix (in a position following the barcode data, also called a footer). See page 297 for more detailed instructions on setting this feature.

To configure this feature, scan the E above to place the unit in Programming Mode, then the “Set Global Prefix” or “Set Global Suffix,” barcode followed by the digits (in hex) from the Alphanumeric characters in Appendix D, Keypad representing your des If less than the expected string of 20 c EXIT barcode to terminate the string. Exit programming mode by scanning the ENTER/EXIT barcode again.

NTER/EXIT PROGRAMMING MODE barcode

ired character(s).

haracters are selected, scan the ENTER/

Set Global Prefix

Set Global Suffix

Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning.

CANCEL

80 Gryphon™ I GD4132/GM4102/GBT4102

ENTER/EXIT PROGRAMMING MODE

Global AIM ID

AIM label identifiers (as opposed to custom characters you select yourself as with label identifiers) can be included with scanned barcode data. AIM label identifiers consist of three characters as follows:

• A close brace character (ASCII ‘]’), followed by...

• A code character (see the table below), followed by...

• A modifier character (the modifier c

SYMBOLOGY CHAR SYMBOLOGY CHAR

This feature enables/disables addition of AIM IDs for all symbology types.

haracter is symbol dependent).

UPC/EAN

Code 39 and



Code 32

Codabar

Interleaved 2 of 5

Code 93

a. UPC-A and UPC-E labels are converted to EAN 13 when adding AIM IDs. b. ISBN (X with a 0 modifier character)

Code 128/GS1-128

DataBar Omnidirectional, DataBar Expanded

Standard 2 of 5

ISBN

Code 11

DEFAULT

Global AIM ID = Disable

Global AIM ID = Enable

Product Reference Guide

ENTER/EXIT PROGRAMMING MODE

DEFAULT

GS1-128 AIM ID

If Global AIM ID is disabled, the AIM ID for GS1-128 can be enabled/disabled independently. The AIM ID for GS1-128 is a ]C1, ]C2 or ]C3.

AIM IDs for other symbologies can be enabled/disabled independently Contact Customer Support for assistance

GS1-128 AIM ID = Disable

GS1-128 AIM ID = Enable

as well.

82 Gryphon™ I GD4132/GM4102/GBT4102

ENTER/EXIT PROGRAMMING MODE

Label ID

A Label ID is a customizable code of up to three ASCII characters (each can be one of hex 0x01-0xFF), used to identify a barcode (symbology) type. It can be appended previous to or following the transmitted barcode data depending upon how this option is enabled. This feature provides options for configuring custom Label IDs as a pre-loaded set (see "Label ID: Pre-loaded Sets" below) or individually per symbology (see "Label ID: Set Individually Per Symbology" on page 84). If you wish to program the reader to alway dard label identifier for ALL symbology types, see the previous feature "Global

AIM ID" on

See Label ID, starting on page 299 of “References” for more information on setting this feature.

page 81.

Label ID: Pre-loaded Sets

The reader supports two pre-loaded sets of Label IDs. See Label ID: Pre-loaded

Sets, starting on page 299 for details on the USA set and the EU set.

When changing from one Label ID set to another, all other reader configuration settings, including the host interface type, will be erased and s

CAUTION

custom defaults will be lost.

s include an industry stan-

et to the standard factory defaults. Any custom configuration or

DEFAULT

Label ID Pre-loaded Set = EU Set

Product Reference Guide

Label ID Pre-loaded Set = USA Set

ENTER/EXIT PROGRAMMING MODE

Label ID: Set Individually Per Symbology

This feature configures a Label ID individually for a single symbology. See Label

ID: Set Individually Per Symbology, starting on page 301 for detailed instruc-

tions on setting this feature.

Label ID Control

This option controls whether a Label ID is disabled, or sent as a prefix or suffix for a given symbology type.

DEFAULT

Label ID Transmission = Disable

Label ID Transmission = Enable as Prefix

CANCEL

Label ID Transmission = Enable as Suffix

Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning.

84 Gryphon™ I GD4132/GM4102/GBT4102

ENTER/EXIT PROGRAMMING MODE

Label ID Symbology Selection

This option selects the symbology for which a Label ID is to be configured. See

"Label ID" on page 83 or page 301 in “References” for more detailed instruc-

tions.

Set UPC-A/P2 Label ID Character(s)

Set UPC-A Label ID Character(s)

Set UPC-A/GS1-128 Label ID Character(s)

Set UPC-E/P2 Label ID Character(s)

Set UPC-A/P5 Label ID Character(s)

Set UPC-E Label ID Character(s)

Product Reference Guide

Set UPC-E/P5 Label ID Character(s)

Label ID Symbology Selection — continued

Set UPC-E/GS1-128 Label ID Character(s)

Set EAN 13/P2 Label ID Character(s)

ENTER/EXIT PROGRAMMING MODE

Set EAN 13 Label ID Character(s)

Set EAN 13/GS1-128 Label ID Character(s)

Set EAN 8/P2 Label ID Character(s)

Set EAN 13/P5 Label ID Character(s)

Set EAN 8 Label ID Character(s)

86 Gryphon™ I GD4132/GM4102/GBT4102

ENTER/EXIT PROGRAMMING MODE

Label ID Symbology Selection — continued

Set EAN 8/GS1-128 Label ID Character(s)

Set EAN 8/P5 Label ID Character(s)

Set GTIN Label ID Character(s)

Set GTIN/P2 Label ID Character(s)

Set GTIN/GS1-128 Label ID Character(s)

Set GTIN/P5 Label ID Character(s)

Set Code 39 Label ID Character(s)

Product Reference Guide

Label ID Symbology Selection — continued

Set Code 32 Label ID Character(s)

Set Code 128 Label ID Character(s)

ENTER/EXIT PROGRAMMING MODE

Set Code 39 CIP Label ID Character(s)

Set ISBT 128 Label ID Character(s)

Set Interleaved 2 of 5 Label ID Character(s)

Set GS1-128 Label ID Character(s)

Set Codablock F Label ID Character(s)

Set Follett 2 of 5 Label ID Character(s)

88 Gryphon™ I GD4132/GM4102/GBT4102

ENTER/EXIT PROGRAMMING MODE

Label ID Symbology Selection — continued

Set Interleaved 2 of 5 CIP HR Label ID Character(s)

Set Industrial 2 of 5 Label ID Character(s)

Set Standard 2 of 5 Label ID Character(s)

Set Datalogic 2 of 5 Label ID Character(s)

Set ABC Codabar Label ID Character(s)

Set IATA Label ID Character(s)

Set Codabar Label ID Character(s)

Product Reference Guide

Label ID Symbology Selection — continued

Set Code 11 Label ID Character(s)

Set DataBar Expanded Label ID Character(s)

ENTER/EXIT PROGRAMMING MODE

Set DataBar Omnidirectional Label ID Character(s)

Set Code 93 Label ID Character(s)

Set Plessey Label ID Character(s)

Set DataBar Limited Label ID Character(s)

Set MSI Label ID Character(s)

90 Gryphon™ I GD4132/GM4102/GBT4102

ENTER/EXIT PROGRAMMING MODE

Label ID Symbology Selection — continued

Set Anker Plessey Label ID Character(s)

Set Code 5 Label ID Character(s)

Set Code 4 Label ID Character(s)

Product Reference Guide

Set Global Mid Label ID Characters

No Mid Label ID

Character (00)

Specifies mid-label ID that is added for transmission between the labels of a two-label pair.

To configure this feature, scan the E above to place the unit in Programming Mode, then the “Set Global Mid Label ID Character(s)” barcode followed by the digits (in hex) from the Alphanumeric characters in Appendix D, Keypad representing your desire than the expected string of 20 characters are selected, scan barcode to terminate the string. Exit programming mode by scanning the ENTER/EXIT barcode again.

Set Global Mid Label ID Character(s)

Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning.

ENTER/EXIT PROGRAMMING MODE

NTER/EXIT PROGRAMMING MODE barcode

d character(s). If less

the ENTER/EXIT

CANCEL

DEFAULT

92 Gryphon™ I GD4132/GM4102/GBT4102

ENTER/EXIT PROGRAMMING MODE

Case Conversion

This feature allows conversion of the case of all alphabetic characters to upper or lower case.

Case conversion affects ONLY scanned barcode data, and does not affect Label ID, Prefix, Suffix, or other appended data.

DEFAULT

Case Conversion = Disable (no case conversion)

Case Conversion = Convert to upper case

Case Conversion = Convert to lower case

Product Reference Guide

ENTER/EXIT PROGRAMMING MODE

0xFFFFFFFFFFFFFFFF

(No character conversion)

Character Conversion

Character conversion is an eight byte configuration item. The eight bytes are 4 character pairs represented in hexadecimal ASCII values. The first character in the pair is the character that will be converted. The second character in the pair is the character to convert to. If the character to convert in a pair is FF, then no conversion is done.

If less than the expected string of 16 characters are selected, scan the ENTER/EXIT barcode twice to accept the selections and exit Programming Mode.

Configure Character Conversion

DEFAULT

94 Gryphon™ I GD4132/GM4102/GBT4102

READING PARAMETERS

DOUBLE READ TIMEOUT on page 96

LABEL GONE TIMEOUT on page 97

SLEEP MODE TIMEOUT on page 98

POWER ON ALERT on page 100

GOOD READ: WHEN TO INDICATE on page 100

GOOD READ BEEP TYPE on page 101

GOOD READ BEEP FREQUENCY on page 101

GOOD READ BEEP LENGTH on page 102

GOOD READ BEEP VOLUME on page 103

GOOD READ LED DURATION on page 104

SCAN MODE on page 105

STAN D MODE TRIGGERED TIMEOUT on page 106

STAN D DETECTION on page 107

STAN D MODE SENSITIVITY on page 108

SCANNING ACTIVE TIME on page 108

FLASH ON TIME on page 109

FLASH OFF TIME on page 109

GREEN SPOT DURATION on page 110

Product Reference Guide

ENTER/EXIT PROGRAMMING MODE

Double Read Timeout

Double Read Timeout prevents a double read of the same label by setting the minimum time allowed between reads of labels of the same symbology and data. If the unit reads a label and sees the same label again within the specified timeout, the second read is ignored. Double Read Timeout does not apply to scan modes that require a trigger pull for each label read.

Double Read Timeout = 0.1 Second

Double Read Timeout = 0.2 Second

Double Read Timeout = 0.4 Second

Double Read Timeout = 0.6 Second

Double Read Timeout = 0.3 Second

Double Read Timeout = 0.5 Second

DEFAULT

Double Read Timeout = 0.7 Second

96 Gryphon™ I GD4132/GM4102/GBT4102

ENTER/EXIT PROGRAMMING MODE

016 = Timeout of 160 ms

Double Read Timeout — continued

Double Read Timeout = 0.8 Second

Double Read Timeout = 1 Second

Double Read Timeout = 0.9 Second

Label Gone Timeout

This feature sets the time after the last label segment is seen before the reader prepares for a new label. The timeout can be set within a range of 10 milliseconds to 2,550 milliseconds (2.55 seconds) in 10ms increments. Label Gone

out does not apply to scan modes that require a trigger pull for each label

Time that is read. See page 304 in “References” for detailed instructions and examples for setting this feature.

Select Label Gone Timeout Setting

Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning.

CANCEL

Product Reference Guide

DEFAULT

ENTER/EXIT PROGRAMMING MODE

Sleep Mode Timeout

This feature sets the amount of time that the reader will be idle before it enters into a low power Sleep Mode. When in Sleep Mode the reader can no longer receive commands from the Host or base station until it is woken up again by a trigger pull or being placed into a base station.

In order for the reader to enter Sleep Mode, the following conditions must be

Corded version (GD4132 only):

ple or trigger pulse.

Mobile version (GM4102 only):

the base) when trigger single, trigger multiple or trigger pulse are set, and when the reader is not charging the battery.

This feature is not applicable to the Gryphon BT models

RS-232 interface and trigger single, trigger multi-

Sleep state is allowed only on the handheld (not on

DEFAULT

Sleep Mode Timeout = Disable

Sleep Mode Timeout = 1 Second

Sleep Mode Timeout = 2 Seconds

Sleep Mode Timeout = 3 Seconds

Sleep Mode Timeout = 4 Seconds

98 Gryphon™ I GD4132/GM4102/GBT4102
