Danby DFF311WDD User Manual
Model • Modèle • Modelo
DFF311WDD
FROST FREE REFRIGERATOR
REFRIGÉRATEUR SANS GIVRE
REFRIGERADOR SIN ESCARCHA
Owner’s Use and Care Guide
Guide d’utilisation et soins de Propriètaire
Manual de Instructions pare el Uso y Cuidado de su Unidad
•
•
•
V4.1.07.10 DM
FROST FREE REFRIGERATOR
Owner’s Use and Care Guide
• Safety Instructions
• Installation Instructions
• Features
• Operating Instructions
• Care and Maintenance
• Troubleshooting
• Warranty
REFRIGÉRATEUR SANS GIVRE
Guide d’utiliser et soin de propriètaire
• Consignes de sécurité
• Consignes de Installation
• Caracteristiques
• Opération
• Soins et entretien
• Dépannage
• Garantie
REFRIGERADOR SIN ESCARCHA
Guía para utilizar y cuidar del Proprietario
• Instruciónes de Seguridad Importantes
• Instrucciones d’instalación
• Caracteristicas
• Instruciónes Operadoras
• Limpieza y Mantenimiento
• Solución Sugeridad
• Garantia
1-6
7-12
CONTENTS
13-18
CAUTION
Read and follow all safety rules and
operating instructions before first use of this
product.
Veuillez lire attentivement les consignes de
sécurité et les instructions d’utilisation avant
l’utilisation initiale de ce produit.
PRECAUTION
Lea y observe todas las reglas de seguridad y
las instrucciones de operación antes de usar
este producto por primera vez.
PRECAUCION
READ ALL SAFETY INFORMATION BEFORE USING
IMPORTANT SAFETY INFORMATION
INSTALLATION INSTRUCTIONS
LOCATION
1
Improper use of the grounding plug can result in a risk of
electric shock. Consult a qualified electrician or serviceman
if the grounding instructions are not completely understood,
or if doubt exists as to whether the appliance is properly
grounded.
WARNING
This appliance must be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electrical shock by
providing an escape wire for the electrical current. This appliance is equipped with a cord having a grounding wire with a
grounding plug. The plug must be plugged into an outlet that
is properly installed and grounded.
DO NOT USE AN EXTENSION CORD
Use an exclusive wall outlet. Do not connect your refrigerator
to extension cords or together with any other appliance in the
same wall outlet.
IMPORTANT WARNING
An empty refrigerator can pose a threat to children. To render
the unit harmless we strongly recommend removing the door
prior to disposal. Before you throw away your old refrigerator
or freezer:
• Take off the doors.
• Leave the shelves in place so that children may not easily
climb inside.
SAVE THESE INSTRUCTIONS!
GROUNDING INSTRUCTIONS
Remove exterior and interior packaging, wipe the
outside thoroughly with a soft dry cloth and the inside with a
wet, lukewarm cloth. Avoid placing the unit in a narrow recess
or near any heat source, direct sunlight, or moisture. Let air
circulate freely around the unit. Keep the rear of the refrigerator 5 inches away from the wall.
LOCATION
1) Select a place with a strong, level floor.
2) Allow 5 inches of space between a wall and the back of the
refrigerator, and 1 to 2 inches of space between a wall and
a refrigerator side.
3) Avoid direct sunlight and heat. Direct sunlight
may affect the acrylic coating on the refrigerator exterior.
Heat sources nearby will cause higher electricity consumption.
The refrigeration system in this refrigerator is a “Frost Free”
system. This type of system requires no user intervention (i.e.
defrosting) other than selecting required cooling temperatures
and the usual care and
maintenance.
To avoid vibration, the unit must be leveled. This is accomplished by adjusting the 2 front leveling legs located under the
refrigerator. (see Figure on the right)
NOTES:
• This appliance is intended for FREE-STANDING
INSTALLATION ONLY, and is NOT intended to be built-in.
• This appliance is approved for INDOOR USE ONLY and is
NOT intended for outdoor operation. Do not place the
refrigerator in your garage or other places that are not within
the operating temperature range.
IMPORTANT: Install this appliance in an area where the ambient temperature is between 55°F (13°C) and 90°F (32°C). If
the temperature around the
appliance is too low or high, cooling ability will be affected.
Bottom of Unit
Leveling Legs
Turn clockwise to
lower the unit
Turn counterclockwise to
raise the unit.
Use pliers or wrench to adjust the
leveling legs
INSTALLATION INSTRUCTIONS
DOOR REVERSAL
INSTRUCTIONS
If you find the direction of opening the door on your
appliance inconvenient, you can change it by following
the steps shown in the below diagrams.
To avoid personal injury to yourself and/or property, we
recommend someone assist you during the door reversal
process.
CAUTION
1) To access the lower hinge assembly, tilt back the
refrigerator cabinet. (Fig. A)
2) Remove both leveling legs located at the front of the
cabinet.
3) Remove the screws holding the lower hinge
assembly to the cabinet. (Fig. A)
4) Remove the main door assembly from the
refrigerator cabinet (open door and pull down).
5) Remove the screws from the middle hinge assembly,
then remove the hinge and freezer door.
6) Remove (unscrew) the top hinge pin. (Fig. B)
7) Re-install the main door top hinge pin on the
opposite side of the cabinet. (Fig. B)
8) Remove the door plug and door bushing located on
the top and bottom of each cabinet. (Fig. B)
9) Interchange positiones (i.e., door plug right side, door
bushing left side).
10) Re-install freezer door assembly on cabinet.
11) Re-install the middle hinge assembly on the
opposite side. (Fig.C)
12) Make sure the door assembly is properly aligned on the
cabinet before tightening the hinge screws.
13) Re-install the main door assembly on the cabinet.
14) Re-install the lower hinge assembly on the
opposite side, making sure to change the bushing
and screw on the opposite sides on the bottom
of unit.
15) Make sure the door assembly is properly aligned on the
cabinet before tightening lower hinge screws.
16) Re-install both leveling legs.
THIS PROCEDURE IS NOW COMPLETE.
2
Fig. C
Center Hinge
Fig. A
Fig. B
FEATURES
3
The Ice Cube Tray is flexible. Twist tray to remove the ice cubes. If the ice cube
tray is frozen solid to the evaporator surface, run a little water over the tray.
Never use a knife or other metal instruments to remove the ice cube tray from
freezer compartment, as this may damage the evaporator.
To replace the refrigerator light bulb:
1) Remove the screw from the light bulb cover.
2) Pull the light bulb cover downward
3) Unscrew the bulb.
4) Replace with standard 40 watt appliance bulb ONLY.
5
1) THERMOSTAT DIAL: For controlling the
temperature inside the refrigerator/freezer.
2) SEPARATE FREEZER SECTION: Holds ice
cube tray and storage for frozen food.
3) ICE CUBE TRAY: Tray is flexible for easy ice
cube removal.
4) PLASTIC COATED SHELVES: Odor resistant,
rustproof, and removable for easy cleaning.
5) MAGNETIC GASKET: Tight fitting door seal
keeps all the cooling power locked inside. No
hooks or latches.
6) CRISPER WITH TEMPERED-GLASS SHELF:
Easy interior viewing.
7) GALLON DOOR STORAGE / 2 LITER TALL
BOTTLE STORAGE: Holds 1 gallon or 2 liter
tall bottles.
1
4
5
6
2
7
3
ICE CUBE TRAY
LIGHT BULB REPLACEMENT
CARE AND MAINTENANCE
4
COOLING SYSTEM
This refrigerator is equipped with a “Frost Free” type cooling
system, which means you never have to defrost the freezer
compartment. Defrosting is done automatically. The defrost
water is routed into a defrost pan located directly above the
compressor, where it then evaporates.
CLEANING
Before cleaning the refrigerator or freezer, always
disconnect the refrigerator from the power supply. To clean the
inside, use a soft cloth and a solution of a tablespoon baking
soda to one quart (4 cups) of water, or a mild soap suds solution or mild detergent. Wash ice cube tray, drip tray, and glide
out shelves in a mild detergent solution, then wipe dry with a
soft cloth. Clean the outside with a damp soft cloth and some
mild detergent or appliance cleaner.
SETTING THE THERMOSTAT
The thermostat setting can be adjusted from 1
(minimum setting) through Maximum (coldest
setting). We recommend setting the thermostat at 4 (medium
setting). However, if you find this setting inadequate for your
cooling requirements, adjust as needed by rotating the thermostat dial. The thermostat dial is located on the front top section of the refrigerator compartment.The thermostat controls
temperature for both the freezer and refrigerator compartments. After making adjustment, wait 24 hours for new temperature to stabilize before making another adjustment. You
will also see another temperature dial in the freezer compartment; leave it in the middle (FREEZER) as that is the factory
recommended setting.
VACATION TIME
For short vacation periods, leave the control knob at the usual
setting. During longer absences;
a) remove all food,
b) disconnect from electrical outlet,
c) Tape rubber or wood blocks to the top of the door to
prop it open far enough for air to get in. This stops odor
and mold from building up.
POWER FAILURE
Most power failures are corrected within an hour or two, and
will not affect your refrigerator temperatures. However, you
should minimize the number times you open the door while
the power is off. During power failures of longer duration, take
steps to protect your food, for example, by placing dry ice on
top of packages.
IF YOU MOVE
Remove, or securely fasten down, all loose items inside the
refrigerator. To avoid damaging the leveling legs, turn them all
the way into the base.
SOME IMPORTANT RULES FOR THE CORRECT USE OF
THE REFRIGERATOR
• Never place hot foods in the refrigerator
• Beverages should be stored in sealed containers
• Foods to be stored for a long time should be wrapped in
cellophane or polyethylene, or kept in glass containers.
Never place spoiled food in the refrigerator.
• Don’t overload the refrigerator.
• Don’t open the door unless necessary.
• Should the refrigerator be stored without use for long
periods, it is suggested, after careful cleaning, to leave the
door ajar to allow the air to circulate inside the unit in order to
avoid the possible formations of condensation, mold, or
odors.
FOOD STORAGE SUGGESTIONS: Fresh Food Compartment
• Never cover food compartment shelves with aluminum foil or
any other shelf covering material which may prevent air
circulation.
• Always remove porous store wrapping paper from meats,
poultry, and fish. Meats should be wrapped individually and
placed in a dish for storage. Wrap fish and poultry in foil or
heavy waxed paper. Most fish should be used the same day
of purchase. Packaged meats such as ham, bacon, dried
beef, or frankfurter, store best in their original packages.
• Allow warm foods to cool to room temperature before
placing them in the refrigerator.
• Always cover open dishes of food, especially leftovers.
Use leftovers within 2 or 3 days.
VEGETABLE CRISPER
The tray at the bottom of the refrigerator is covered to retain
moisture. The crisper compartment will enable you to store
vegetables and fruits which would otherwise dry out rapidly.
The humidity level inside the crisper drawer can be controlled
by adjusting the “damper” control (white slider) located on the
front of the drawer. For leafy vegetables, increase the humidity by closing the slide. For fruits, decrease the humidity by
opening the slide.
REFRIGERATOR
M
X
4
Recommended Setting
FREEZER
IN
CONGÉLATEUR
6
MA
TROUBLESHOOTING
Occasionally, a problem is minor and a service call may not be necessary- use this troubleshooting guide for a possible
solution. If the unit continues to operate improperly, call an authorized service depot or Danby’s Toll Free Number
1-800-263-2629 for assistance.
PROBLEM POSSIBLE CAUSE SOLUTION
1) Unit does not work.
2) Refrigerator running too
frequently.
3) Internal Temperature too
cold.
4) Internal Temperature not
cold enough.
5) Freezer not cold enough.
6) Light will not work.
• No power to unit.
• Power cord is unplugged.
• Wrong voltage is being used.
• Temperature control too high.
• Door not closed.
• Hot food inserted.
• Doors open too long/often.
• Close proximity to heat source or
direct sunlight.
• Temperature control too low.
• No power to unit.
• Power cord is unplugged.
• Wrong voltage is being used.
• Temperature control too low.
• Hot food inserted.
• Doors open too long/often.
• Air flow obstruction.
• Close proximity to heat source or
direct sunlight.
• Temperature control too high.
• Door not closed.
• Hot food inserted.
• Doors open too long/often.
• Wrong voltage is being used.
• No power to unit.
• Power cord is unplugged.
• Bulb is loose/needs replacing.
• Door switch is stuck.
• Check connection of power cord at
power source.
• Plug in unit.
• Use proper voltage.
• Check/adjust settings as needed.
• Close the door securely.
• Cool food before inserting.
• Minimize door openings/duration.
• DO NOT place unit close to heat
sources or in direct sunlight.
• Check/adjust settings as needed.
• Check connection of power cord at
power source.
• Plug in unit.
• Use proper voltage.
• Check/adjust settings as needed.
• Cool food before inserting.
• Minimize door openings/duration.
• Allow room for air to circulate around
the unit.
• DO NOT place unit close to heat
sources or in direct sunlight.
• Check/adjust settings as needed.
• Close door securely.
• Cool food before insterting.
• Minimize door openings/duration.
• Use proper voltage.
• Check connection of power cord to
power source.
• Plug in unit.
• Tighten or replace bulb.
• Check the switch for obstructions,
clean if necessary.
5
Loading...
