Danby DFF282SLDB User Manual
Model • Modèle • Modelo
V2 08.11 DM
• Owner’s Use and Care Guide
• Guide d’utilisation et soin de Propriètaire
• Manual de Instructions Pare el Uso y el
Cuidado de su Unidad
FROST FREE REFRIGERATOR
REFRIGÉRATEUR SANS GIVRE
REFRIGERADOR SIN ESCARCHA
DFF282WDB
DFF282SLDB
Danby Products Limited, Ontario, Canada N1H 6Z9
Danby Products Inc., Findlay, Ohio, USA 45840
FROST FREE REFRIGERATOR
Owner’s Use and Care Guide .............................
• Safety Instructions
• Installation Instructions
• Operating Instructions
• Care and Maintenance
• Troubleshooting
• Warranty
REFRIGÉRATEUR SANS GIVRE
Guide d’utiliser et soin de propriètaire .............
• Consignes de Sécurité Important
• Instructions d’installation
• Consignes d’utilisation
• Soins et entretien
• Dépannage
• Garantie
Contents
2- 10
11-19
REFRIGERADOR SIN ESCARCHA
Guide d’utiliser et soin de propriètaire .............
• Instrucciones de Seguridad Importantes
• Instrucciones D’Instalacion
• Operación
• Limpieza y Mantenimiento
• Solución Sugerida
• Garantia
20-28
CAUTION:
PRECAUTION:
PRECAUCION:
Read and follow all safety rules and
operating instructions before first use of this
product.
Veuillez lire attentivement les consignes de
sécurité et les instructions d’utilisation avant
l’utilisation initiale de ce produit.
Lea y observe todas las reglas de seguridad
y las instrucciones de operación antes de
usar este producto por primera vez.
Model • Modèle • Modelo DFF282WDB / DFF282SLDB
Welcome
Welcome to the Danby family. We’re proud of our quality products, and we believe in dependable service; like you will
find in this owner’s use and care guide, and like you will receive from our friendly customer service department. Best of
all, you will experience these values each and every time you use your Danby Refrigerator. That’s important, because
your new appliance will be a part of your family for a long time.
For easy reference, may we suggest that you attach a copy of your sales receipt to this page, and note the information
below; you will need this information to obtain service under warranty.
Model No:
Serial No:
Date Purchased:
Before you call for service, there are a few things you can do to help us
serve you better.
Read this Owner’s Use and Care Guide:
It contains instructions to help you use and maintain your appliance
properly.
If you received a damaged appliance:
Immediately contact the builder (or dealer) that sold you the
refrigerator.
Save time and money:
Check the Trouble shooting section before calling. This section helps you
solve common problems that may occur.
If you do need service, you can relax knowing help is only a phone call
away.
Need Help?
Tel: 1-800-26-
(1-800-263-2629)
2
Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
ELECTRICAL
REQUIREMENTS
This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of
electrical shock by providing an escape wire for the electrical current.
This appliance is equipped with a cord having a grounding wire with a
grounding plug. The plug must be plugged into an outlet that is properly
installed and grounded.
An empty refrigerator is a very dangerous attraction to children.
Remove either the gasket or lid from unused appliances, or take
some other action that will guarantee it harmless.
IMPORTANT WARNING
WARNING
Improper use of the grounding plug can result in a risk of electric
shock. Consult a qualified electrician or serviceman if the grounding instructions are not completely understood, or if doubt exists
as to whether the appliance is properly grounded.
Installation Instructions
Remove exterior and interior packings, wipe the outside thoroughly with a
soft dry cloth and the inside with a wet, lukewarm cloth. Avoid placing the
unit in a narrow recess or near any heat source, direct sunlight, or moisture. Let air circulate freely around the unit. Keep the rear of the refrigerator 5 inches away from the wall.
LOCATION
1) Select a place with a strong, level floor.
2) Allow 5 inches of space between the back of the refrigerator and any
adjacent wall.
3) Avoid direct sunlight and heat. Direct sunlight may affect the acrylic
coating. Heat sources nearby will cause higher electricity consumption.
The refrigerating system in this refrigerator is a “Frost Free” system. This
type of system requires no user intervention (i.e. defrosting) other than
selecting required cooling temperatures and the usual care and
maintenance.
To avoid vibration, the unit must be set level. This is accomplished by
adjusting the (2) front leveling legs, located under the refrigerator. To
begin the cooling process, turn the graduated dial to the desired
temperature. The minimum cooling setting is 1, and the maximum setting
is Max. We recommend setting the thermostat at 4, our medium setting,
and adjust as required.
DANGER:
Risk off child entrapment. Before you throw away your old
refrigerator or freezer:
• Take off the doors.
• Leave the shelves in place so that children may not easily climb in.
DON’T WAIT DO IT NOW!
DO NOT USE AN EXTENSION CORD
Use an exclusive wall outlet. Do not connect your refrigerator to extension cords or together with any other appliance in the same wall outlet.
3
Installation Instructions
The refrigerator temperature will vary depending on the quantity of food
stored and the frequency with which the door is opened.
NOTES:
• This appliance is intended for FREE-STANDING INSTALLATION ONLY,
and is NOT intended to be built-in.
• Before connecting this appliance to electrical power supply, leave it to
stand for approx. 24 hours, which will reduce the possibility of
malfunction in the cooling system due to transport handling.
• This appliance is approved for INDOOR USE ONLY and is NOT
intended for outdoor operation.
IMPORTANT
Install this appliance in an area where the ambient temperature is
between 55°F (13°C) and 110°F (43°C). If the temperature around
the appliance is too low or high, cooling ability may be affected.
DOOR REVERSAL
INSTRUCTIONS
Your refrigerator is built with a reversible door. You have the choice of
either opening it from the left or the right side. In order to reverse the
opening direction of your door, please follow these simple instructions:
IMPORTANT
Before you begin, unplug refrigerator or disconnect power.
Remove food and any adjustable door or utility bins from doors.
DOOR AND HINGE REMOVAL
1. Unplug refrigerator or disconnect power.
2. Keep both doors closed until you are ready to lift them free from the
cabinet.
NOTE: Provide additional support for the doors while the hinges are being
moved. Do not depend on the door magnets to hold the doors in place
while you are working.
3. Remove the parts for the top hinge as shown in Top Hinge graphic. Lift
the freezer door from the cabinet.
4. Remove the parts for the center hinge as shown in the Center Hinge
graphic. Lift the refrigerator door free from the cabinet.
5. Remove the parts for the bottom hinge as shown in the Bottom Hinge
graphic.
DOOR REVERSAL CABINET
1. Remove the cover of upper hinge hole from left side and move them to
opposite side (see Graphic 1).
2. Remove hole plugs from left side and move them to opposite side
(see Graphic 2)
DOORS
1. Remove door hinge hole plug from the top of freezer and refrigerator door
(see graphic 4)
2. Remove the door stop from refrigerator door and move to the other side
(see graphic 5)
3. Take out the left door stop of freezer door and screw from the accessory
bag and fix it on the handle (see graphic 3)
4
Installation Instructions
DOOR REVERSAL
INSTRUCTIONS
NOTE: The left door and the right door stop of the freezer door are different.
They can’t replace each other.
DOOR AND HINGE REPLACEMENT
1. Replace the parts for the bottom hinge as shown (see Bottom Hinge
graphic). Tighten screws. Replace the refrigerator door.
NOTE: Provide additional support for the doors while the hinges are being
moved. Do not depend on the door magnets to hold the doors in place
while you are working.
2. Assemble the parts for the center hinge as shown and tighten all
screws (see Center Hinge graphic). Replace the freezer door.
3. Assemble the parts for the top hinge as shown (see Top Hinge graphic).
Do not tighten screws completely.
4. Line up the doors so that the bottom of the freezer door aligns evenly
with the top of the refrigerator door. Tighten all screws.
FINAL STEPS
1. Check all holes to make sure that hole plugs and screws are in place.
2. Plug in refrigerator or reconnect power.
3. Reset the controls (see “ temperature control” section).
4. Return all removable door parts to doors and food to product.
Top Hinge
1. Top hinge Cover
2. Top Hinge Spindle
3. Top Hinge
1
2
3
1
1.Cover Of Upper Hinge Hole
2
1.Hole Plugs
3
1
1
1
2
1.Left Door Stop
2.Door Stop Screw
Accessory
Bag
4
1
1.Door Hinge Hole Plug
5
1
2
1.Door Stop
2.Door Stop Screw
Bottom Hinge
1.Door Stop
2.Door Stop Screw
3.Door Stop Pole
4.Bottom Hinge
5.Bottom Hinge Screws
6.Adjustable Foot
1
2
3
4
5
6
Center Hinge
1.Center Hinge Spacer
2.Center Hinge
3.Screws
4.Bush
1
2
3
4
5
Installation Instructions
FEATURES
1) FREEZER BINS
2) REFRIGERATOR BINS - Not adjustable.
3) FREEZER SHELF
4) FREEZER TEMPERATURE CONTROL KNOB
5) LAMP COVER
6) REFRIGERATOR TEMPERATURE CONTROL
PANEL
7) REFRIGERATOR SHELVES - Removable
shelves lift up and pull towards you to remove.
8) CRISPER COVER
9) CRISPER
10) LEVELING LEG
ICE CUBE TRAY
The Ice Cube Tray is flexible. Twist tray to remove the ice cubes. If the ice
cube tray is frozen solid to the evaporator surface, run a little water over
the tray. Never use a knife or other metal instruments to remove the ice
cube tray, as this may damage the evaporator.
Operating Instructions
OPERATING YOUR
REFRIGERATOR
Temperature Control
• Your refrigerator has one control for regulating the temperature. The
temperature control is located on the top left hand corner of the
refrigerator compartment.
• The first time you turn the unit on, adjust the temperature control knob to
“MAX” and run for at least 2 hours before putting foods inside. This will
ensure the cabinet is thoroughly chilled before food is put in.
• The range of the REFRIGERATOR temperature control is from position
"MIN" the warmest to "MAX" the coldest. Adjust the temperature control
to the setting that best suits your needs. The setting of “MED” should be
appropriate for home or office refrigerator use.
6
1
2
3
4
5
6
7
8
9
10
OPERATING FREEZER
COMPARTMENT
TEMPERATURE CONTROL
• Your refrigerator has one control for regulating the temperature in the
freezer compartment(See below figure). The temperature control is
located on the center of the freezer compartment’s interior back panel.
• The first time you turn the unit on, adjust the temperature control knob to
“MAX” and let the unit run for at least 2 hours before putting foods inside.
That will ensure the cabinet is thoroughly chilled before food is put in.
• The range of the FREEZER temperature control is from position "MIN"
the warmest to "MAX" the coldest. Adjust this control to get the
temperature you want.
THE FREEZER COMPARTMENT
• This compartment is designed for the long-term storage of frozen food.
Storage time period is up to three months.
• The storage life of frozen foods varies and the recommended storage
time should not be exceeded.
• Place frozen food into the freezer as quickly as possible after purchase.
If there are instructions on the packet, carefully follow these instructions
regarding storage times.
Freezer Temperature Control
Care and Maintenance
COOLING SYSTEM
This refrigerator is inclusive of a “Frost Free” type cooling system, which
means you never have to defrost the freezer compartment. Defrosting is
done automatically by means of a defrost heating element and a defrost
timer factory-programmed to operate (cycle) approximately every 8 hours.
The defrost water is routed into a defrost pan located directly above the
compressor, where it then evaporates.
CLEANING
Before cleaning the refrigerator or freezer, always disconnect the refrigerator from the power supply. To clean the inside, use a soft cloth and a
solution of a tablespoon baking soda to one quart (4 cups) of water, or a
mild soap suds solution or mild detergent. Wash ice cube tray, drip tray,
and glide out shelves in a mild detergent solution, then wipe dry with a
soft cloth. Clean the outside with a damp soft cloth and some mild detergent or appliance cleaner.
MIN
MAX
Operating Instructions
NOTE;
• If the unit is unplugged, loses power; you must wait 3 to 5 minutes
before restarting the unit. If you attempt to restart before this time delay,
the refrigerator will not start.
• Large amounts of food will lower the cooling efficiency of the appliance.
• Do not place the foods on the air outlet. Please leave space for airflow.
• If you choose to change the thermostat setting, adjust thermostat control
by one increment at a time. Allow several hours for temperature to
stabilize between adjustments.
• Adjusting the temperature control in the refrigerator compartment will
affect the temperature in both the refrigerator and the freezer
compartment.
7
OPERATING YOUR
REFRIGERATOR
VACATION TIME
For short vacation periods, leave the control knob at the usual setting.
During longer absences;
a) remove all food.
b) disconnect from electrical outlet.
c) leave the door open to avoid possible formations of condensation,
mold, or odors.
POWER FAILURE
Most power failures are corrected within an hour or two, and will not affect
your refrigerator temperatures. However, you should minimize the number
times you open the door while the power is off. During power failures of
longer duration, take steps to protect your food, for example, by placing
dry ice on top of packages.
IF YOU MOVE
Remove, or securely fasten down, all loose items inside the refrigerator.
To avoid damaging the leveling legs, turn them all the way into the base.
Some Important Rules for the Correct Use of the Refrigerator
• Never place hot foods in the refrigerator
• Beverages should be stored in sealed containers
• Foods to be stored for a long time should be wrapped in cellophane or
polyethylene, or kept in glass containers. Never place spoiled food in
the refrigerator.
• Don’t overload the refrigerator.
• Don’t open the door unless necessary.
• Should the refrigerator be stored without use for long periods, it is
suggested, after careful cleaning, to leave the door ajar to allow the air
to circulate inside the unit in order to avoid the possible formations of
condensation, mold, or odors.
FOOD STORAGE SUGGESTIONS:
Fresh Food Compartment
• Never cover food compartment shelves with aluminum foil or any other
shelf covering material which may prevent air circulation.
• Always remove porous store wrapping paper from meats, poultry, and
fish. Meats should be wrapped individually and placed in a dish for
storage.Wrap fish and poultry in foil or heavy waxed paper. Most fish
should be used the same day of purchase. Packaged meats such as
ham, bacon, dried beef, or frankfurter, store best in their original
packages.
• Allow warm foods to cool to room temperature before placing them in
the refrigerator.
• Always cover open dishes of food, especially leftovers. Use leftovers
within 2 or 3 days.
VEGETABLE CRISPER
The tray at the bottom of the refrigerator is covered to retain moisture. The
crisper compartment will enable you to store vegetables and fruits which
would otherwise dry out rapidly. The humidity level inside the crisper drawer can be controlled by adjusting the “damper” control (white slider) located on the front of the drawer.
Care and Maintenance
8
Loading...
