OWNER’S MANUAL

Before operating this oven, please read these manual completely.

MICROWAVE CONVECTION/GRILL OVEN

KOC-9Q1T7A

TABLE OF CONTENTS

• IMPORTANT SAFETY INSTRUCTIONS ....................................................................................................................................... 2

• FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT.............................. 3

• GROUNDING INSTRUCTIONS...................................................................................................................................................... 3

• INSTALLATION .................................................................................................................................................................................4

• SPECIFICATIONS............................................................................................................................................................................ 5

• FEATURE DIAGRAM........................................................................................................................................................................6

• FEATURES DIAGRAM (CONTINUED)..........................................................................................................................................7

• ACCESSORIES.................................................................................................................................................................................8

• BEFORE OPERATION.................................................................................................................................................................... 9

SETTING THE CLOCK.....................................................................................................................................................................9

CHILD LOCK AND POWER SAVE MODE...................................................................................................................................10

• OPERATION....................................................................................................................................................................................11

MICROWAVE COOKING...............................................................................................................................................................12

GRILL COOKING............................................................................................................................................................................13

CONVECTION COOKING(WITH PRE-HEAT).............................................................................................................................14

CONVECTION COOKING(TRADITIONAL COOKING)...............................................................................................................15

COMBINATION COOKING............................................................................................................................................................16

(1) WEIGHT DEFROST MODE.....................................................................................................................................................17

(2) TIME DEFROST MODE ...........................................................................................................................................................18

AUTO COOK...................................................................................................................................................................................19

SPEEDY COOK..............................................................................................................................................................................20

DISH WARMER (FOR PREMIUM OPTION MODEL ONLY)......................................................................................................20

WARM..............................................................................................................................................................................................21

STEAM CLEANING........................................................................................................................................................................22

• TO STOP THE OVEN WHILE THE OVEN IS OPERATING.......................................................................................................23

• BEFORE YOU CALL FOR SERVICE............................................................................................................................................23

• CARE AND CLEANING..................................................................................................................................................................23

• CARE OF YOUR MICROWAVE OVEN........................................................................................................................................24

• QUESTIONS AND ANSWERS......................................................................................................................................................25

• COOKING INSTRUCTIONS...........................................................................................................................................................26

• USE YOUR MICROWAVE OVEN SAFELY..................................................................................................................................27

• ARCING ...........................................................................................................................................................................................27

• MICROWAVING PRINCIPLES ......................................................................................................................................................28

• HOW MICROWAVES COOK FOOD.............................................................................................................................................28

• CONVERSION CHARTS................................................................................................................................................................28

• COOKING TECHNIQUES..............................................................................................................................................................29

• DEFROSTING GUIDE....................................................................................................................................................................30

• COOKING & REHEATING CHART...............................................................................................................................................31

• VEGETABLE CHART .....................................................................................................................................................................32

• RECIPES .........................................................................................................................................................................................33

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE

TO EXCESSIVE MICROWAVE ENERGY

(a) Do not attempt to operate this oven with the door open since open-door

operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.

(b) Do not place any object between the oven front face and the door or allow soil or

cleaner residue to accumulate on sealing surfaces.

oven door close properly and that there is no damage to the: (1) door (bent), (2) hinges and latches (broken or loosened), (3) door seals and sealing surfaces.

(d) The oven should not be adjusted or repaired by anyone except properly qualified

service personnel.

IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliances, basic safety precautions should be followed, including the following:

WARNING - To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave

energy:

SAVE THESE INSTRUCTIONS

11. Read all instructions before using the appliance.

12. Read and follow the specific “PRECAUTIONS TO AVOID

POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY” found on page 1.

13. This appliance must be grounded. Connect only to properly

grounded outlet. See “GROUNDING INSTRUCTIONS” found on page 3.

14. Install or locate this appliance only in accordance with the

provided installation instructions.

15. Some products such as whole eggs and sealed containers -

for example, closed glass jars-are able to explode and should not be heated in this oven.

16. Use this appliance only for its intended use as described in

this manual. Do not use corrosive chemicals or vapors in this appliance. This type of oven is specifically designed to heat, cook, or dry food. It is not designed for industrial or laboratory use.

17. Only allow children to use the oven without supervision when

adequate instructions have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use.

18. Do not operate this appliance if it has a damaged cord or

plug, if it is not working properly, or if it has been damaged or dropped.

19. This appliance should be serviced only by qualified service

personnel. Contact nearest authorized service facility for examination, repair or adjustment.

10. Do not cover or block any openings on the appliance.

11. Do not store this appliance outdoors. Do not use this product near water — for example, near a kitchen sink, in a wet basement, or near a swimming pool, or similar locations.

12. Do not immerse cord or plug in water.

13. Keep cord away from heated surfaces.

14. Do not let cord hang over edge of table or counter.

15. Either: a) When cleaning surfaces of door and oven that comes

together on closing the door, use only mild, non-abrasive soaps or detergents applied with a sponge or soft cloth , or

b) When separate cleaning instructions are provided, See

door surface cleaning instructions on.

16. To reduce the risk of fire in the oven cavity: a) Do not overcook food. Carefully attend appliance when

paper, plastic, or other combustible materials are placed inside the oven to facilitate cooking.

b) Remove wire twist-ties from paper or plastic bags before

placing bag in oven.

c) If materials inside the oven ignite, keep oven door closed,

turn oven off, and disconnect the power cord, or shut off power at the fuse or circuit breaker panel.

d) Do not use the cavity for storage purposes. Do not leave

paper products, cooking utensils, or food in the cavity when not in use.

17. Do not use this microwave oven to heat corrosive chemicals (for example, sulfides and chlorides). Vapours from such corrosive chemicals may interact with the contact and springs of the safety interlock switches thereby rendering them inoperable.

18. Keep the waveguide cover clean at all times. Wipe the oven interior with a soft damp cloth after each use. If you leave grease or fat anywhere in the cavity it may overheat, smoke or even catch fire when next using the oven.

19. Never heat oil or fat for deep frying as you cannot control the temperature and doing so may lead to overheating and fire.

20. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point without appearing to be boiling due to surface tension of the liquid. Visible bubbling or boiling when the container is removed from the microwave oven is not always present. THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN A SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID. To reduce the risk of injury to persons:

1 Do not overheat the liquid. 2 Stir the liquid both before and halfway through heating it 3 Do not use straight-sided containers with narrow necks. 4 After heating, allow the container to stand in the microwave

oven for a short time before removing the container.

5 Use extreme care when inserting a spoon or other utensil

into the container.

21. Oversized foods or oversized metal utensils should not be inserted in a thicrowave oven as they may create a fire or risk of electric shock.

22. Do not clean with metal scouring pads. Pieces can bum off the pad and touch electrical parts involving a risk of electric shock.

23. Do not store any materials, other than manufacturer’s recommended accessories, in this oven when not in use.

24. Do not cover racks or any other part of the oven with metal foil. This will cause overtheating of the oven.

25. Do not operate the oven without the glass tray in place. Be sure it is properly sitting on the rotating base.

Prior to use(If your oven has a grill element)

In order to protect your oven during transportation and storage, the grill element is covered with a protective coating. To remove this coating the grill element must be heated for 5 minutes. This procedure will produce some bad odors as the protective coating on the element disappears.

FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT

GROUNDING INSTRUCTIONS

This appliance must be grounded. In the event of an electrical short circuit, the grounding plug reduces the risk of electric shock by providing an escape wire for electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded.

WARNING:

This equipment generates and uses ISM frequency energy and if not installed and used properly, that is in strict accordance with the manufacturer's instructions, may cause interference to radio and television reception. It has been type-tested and found to comply with limits for an ISM Equipment pursuant to part 18 of FCC Rules, which are designed to provide reasonable protection against such interference in a residential installation. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the followings.

• Reorient the receiving antenna of radio or television.

• Relocate the Microwave oven with respect to the receiver.

• Move the microwave oven away from the receiver.

• Plug the microwave oven into a different outlet so that microwave oven and receiver are on different branch circuits.

THE MANUFACTURER is not responsible for any radio or TV interference caused by UNAUTHORIZED MODIFICATION to this microwave oven. It is the responsibility of the user to correct such interference.

WARNING:

Improper use of the grounding can result in a risk of electric shock. Consult a qualified electrician or serviceman if the grounding instructions are not completely understood, or if doubt exists as to whether the appliance is properly grounded, and either : (1) If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-blade grounding plug, and a 3-slot

receptacle that will accept the plug on the appliance. The marked rating of the extension cord shall be equal to or greater than the electrical rating of the appliance. or

(2) Do not use an extension cord, if the power supply cord is too short, have a qualified electrician or serviceman install an

outlet near the appliance.

WARNING:

Do not cut or remove the third (ground) prong from the power cord under any circumstances.

INSTALLATION

1. Examine the oven after unpacking. Check for damage such as a misaligned door, broken door or dent in the cavity.

If any damage is visible, DO NOT INSTALL, and notify your dealer immediately.

2. Level, flat location. Install the microwave oven on a level, flat surface.

3. Ventilation. Do not block air vents. If they are blocked during operation, the oven may overheat and eventually cause a failure. For proper ventilation, allow 4 inches of space between oven top, sides, rear and adjacent surfaces.

4. Away from radio and TV sets. Poor television reception and radio interference may result if the oven is located close to a TV, radio, antenna, feeder, etc. Place the oven as far from them as possible.

5. Away from heating appliances and water taps. Keep the oven away from heat, steam or splashing liquids. These things can adversely affect oven wiring and contacts.

6. Power supply.

• Check your local power source.

This microwave oven requires a current of approximately 14 amperes, 120Volts, 60Hz grounded outlet.

1. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord.

2. Longer cord sets or extension cords are available and may be used if care is exercised in their use.

3. If a long cord or extension cord is used:

• The marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating of the appliance.

• The extension cord must be a grounding type 3-wire cord.

• The longer cord should be arranged so that it will not drape over the counter top or tabletop where it can be pulled on by children or tripped over unintentionally.

7. The minimum height of free space necessary above the top surface of the oven is about 4 inches.

When use 3-pronged plug

3-prong Receptacle

Receptacle Box cover

3-prong plug

When use grounding adaptor, make sure the receptacle box is fully grounded.

Receptacle Box Cover

Receptacle

Grounding Lead

Grounding Adaptor

“THE CANADIAN ELECTRICAL CODE DOES NOT ALLOW THE USE OF THE GROUNDING ADAPTOR”

SPECIFICATIONS

POWER SUPPLY 120V AC, 60Hz SINGLE PHASE WITH GROUNDING

INPUT POWER 1400 W

MICROWAVE ENERGY OUTPUT 900 W

FREQUENCY 2,450MHz GRILL INPUT POWER 1250 W CONVECTION INPUT POWER 1250 W COMBINATION INPUT POWER 1500 W OUTSIDE DIMENSIONS (W D H) 20.2 x 15.8 x 12.2 in. CAVITY DIMENSIONS (W D H) 13.9 x 13.4 x 9.1 in. CAVITY VOLUME 0.99 cu.ft NET WEIGHT APPROX. 36.6 lbs. TIMER 99 minutes 99 seconds POWER SELECTIONS 10 Levels

* Specifications are subject to change without notice.

20.2 15.8

12.2

FEATURE DIAGRAM

1 DOOR HOOK

Hook automatically locks and holds the door when the door shuts. If the door opens while the oven is operating, the oven will stop operating immediately.

2 DOOR SEAL

Door seal prevents the microwave leakage from the oven cavity.

3 DOOR VIEWING SCREEN

Food, inside of oven, can be observed through the door viewing screen. It is designed that the microwave cannot pass through the screen.

4 TOP HEATER

Top heater turns on if any of heater related mode operates.

5 OVEN FRONT PLATE

6 CONVECTION INLET

7 OVEN LAMP

Oven lamp turns on anytime the door opens and oven operates.

8 SAFETY INTERLOCK SYSTEM

9 CONTROL PANEL

0 METAL RACK

q COUPLER

Coupler located at the center of the oven cavity and it couples between the motor and the glass tray.

w ROLLER GUIDE

Roller guide must be used anytime with the glass tray.

e GLASS TRAY

Glass tray is made of special heat resistant glass material. It must be always properly fitted with the coupler and the roller guide.

23 4

5678

q0w

FEATURES DIAGRAM (continued)

Display : Cooking time, power level, program

indicators and present time are displayed. MW ( ): When blinking, the oven is operating in MICROWAVE COOK mode. Grill ( ): When blinking, the oven is operating in GRILL mode. Combi ( ): When blinking, the oven is operating in COMBI mode. Convection ( ): When blinking, the oven is operating in CONVECTION mode. Defrost ( ): When blinking, the oven is operating in DEFROST mode. Auto-cook ( ): When blinking, the oven is operating in AUTO COOK mode. Warm ( ): When blinking, the oven is operating in WARM mode. Steam Cleaning ( ): When blinking, the oven is operating in STEAM CLEANING mode. gram ( ): When blinking, the oven is operating in weight input mode.

Auto cook : Used to cook or reheat.

MW : Used to set power level of the microwave.

Defrost : Used to defrost foods.

Grill : Used to select grill mode.

Combi : Used to select combi mode.

Convection : Used to select convection mode and

selected temp.

Clock : Used to set clock.

STEAM CLEANING : Used to clean the inside of

the oven

Warm : Used to keep the food warm.

Time set pad : Used to set time, weight and

quantity.

START/SPEEDY COOK : Used to start a program

or a speedy start(each press adds 30 seconds of microwave cooking time).

STOP/CLEAR : Used to stop the oven operation or

to delete the cooking data.

3 4 5 6

ACCESSORIES

This oven comes equipped with several accessories. They can be used in various ways to facilitate cooking.

Glass Turntable - Center the tray on the roller guide when using the microwave features. Place food or microwave-safe

cookware directly on the glass turntable.

Roller Guide - The roller guide must be in place when using the oven.

IMPORTANT : The roller guide must be placed at the center of the oven cavity.

Metal Rack - Center the rack on the glass tray when using the grill cooking, convection cooking, and auto cooking menus.

■ HOW TO USE THE ACCESSORIES FOR COOKING

NOTE : The Glass Turntable can be found attached to the left polystyrene packing material in the carton.

■ Glass Turntable ■ Metal rack ■ Dish-Warm rack

(Premium option model only)

• All Cooking modes. • Grill cooking

• Convection cooking

• Combination cooking

• Auto cooking menu 1~4.

• Dish warming

321

BEFORE OPERATION

When your oven is plugged in, the display will show “ :0” and a tone will sound. If the AC power goes off and comes back on, the display will show “:0”. Your oven has a multiple(12hr/24hr) clock system. To set the clock, follow the procedure below.

Example : To set 5:30 AM in a 24hr clock system.

1. Touch Clock pad once.

The display will show “ 12H ”. This is a 12 hour clock system.

2. Touch Clock pad once more, the display shows “24H”. This is a 24hour clock system. If you want 12hour clock system, omit this step.

3. Touch the pad ‘5’ to set the hour 5. The digit starts blinking, the colon will light. “ : 5” shows in display.

4. Touch the time set pad to set minutes, ‘3’, ‘0’ in sequence. “5:30” shows in display.

5. Touch Clock pad. The colon starts blinking. If you selected the 12hour clock system, this digital clock allows you to set the time from 1:00 to 12:59. If you selected the 24hour clock system, this digital clock allows you to set the time from 0:00 to 23:59.

SETTING THE CLOCK

Note : You can check the current time while cooking is in progress by

pressing the Clock pad.

Child lock : The Child Lock function helps to prevent accidents from children operating the oven without being monitored by the parents. Power save mode : This function is used for saving energy.

To set child lock

1. Touch the STOP/CLEAR pad.

“: 0” or clock appears in the display.

2. Touch and hold the STOP/CLEAR pad for 3 seconds.

A beep sounds and the display shows “ LOC ” for 3 seconds. Now the oven cannot be operated.

3. To cancel child lock simply repeat procedure 2.

The oven will beep. The oven is again available for normal use.

To set power save mode

1. Touch the STOP/CLEAR pad.

“: 0” or clock appears in the display.

2. Touch and then hold the Clock pad for 3 seconds.

The display will turn off and a beep sounds. To operate the oven in power save mode, touch any key or adjust the time set pad. Then “:0” or clock will be shown and the operation of all function keys will be the same as in the normal mode. But if there is no operation within 10 seconds in clear mode or while manipulating the key, all the contents of display will disappear.

3. To cancel the power save mode, simply repeat the setting procedure.

The power save mode will be canceled and a beep sounds. The oven is again available for normal use.

CHILD LOCK AND POWER SAVE MODE

+ 25 hidden pages

Daewoo KOC-9Q1T7A User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
