OPERATOR’S MANUAL
SERIES 3000
TRACTOR
Model GT 3235
IMPORTANT: READ SAFETY RULES AND INSTRUCTIONS CAREFULLY
Warning
near any unimproved forest-covered, brush-covered or grass-covered land unless the engine’s
exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any). If a
spark arrester is used, it should be maintained in effective working order by the operator. In the State
of California the above is required by law (Section 4442 of the California Public Resources Code).
Other states may have similar laws. Federal laws apply on federal lands. A spark arrester for the
muffler is available through your nearest engine authorized service dealer or contact the service
department, P.O. Box 361131 Cleveland, Ohio 44136-0019.
: This unit is equipped with an internal combustion engine and should not be used on or
CUB CADET LLC P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 [www.cubcadet.com]
FORM NO. 770-10520C
(10/03)
TABLE OF CONTENTS
TRACTOR PREPARTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
IMPORTANT SAFE OPERATION PRACTICES . . . . . . . . . . . . . . . . . . . . . 3
CALLING SERVICE INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
FINDING YOUR MODEL & SERIAL NUMBER . . . . . . . . . . . . . . . . . . . . . . 7
SAFETY LABELS FOUND ON YOUR UNIT . . . . . . . . . . . . . . . . . . . . . . . . 8
CONTROLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
LUBRICATION ILLUSTRATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
ENGINE INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
TROUBLE SHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
OPTIONAL EQUIPMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
SLOPE GAUGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
LIMITED WARRANTY — COMMERCIAL USE . . . . . . . . . . . . . . . . . . . . . 39
LIMITED WARRANTY — RESIDENTIAL USE . . . . . . . . . . . . . . . . . . . . . 41
QUICK REFERENCE PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
SECTION 1: TRACTOR PREPARATION
PAGE
Connect the Battery
Battery posts, terminals and
related accessories contain
lead and lead compounds.
Wash hands after handling.
The tractor is shipped with a sealed
battery, with the positive battery cable
factory connected. The negative cable
must be connected.
Note: Make sure the ignition switch is
in the "OFF" position before attaching
the battery cables.
• Open the tractor hood. Remove the
upper bulkhead baffle from the front of
the dash panel by lifting upward on
the baffle locking tab on each side.
• Remove the protective cap from the
negative terminal of the battery.
• Connect the black battery cable to
the negative battery post. Slide
terminal cover over the connection
and reinstall the upper baffle.
Positon the High Back Seat
For shipping purposes the seat is
installed sideways. Reposition the seat
as follows:
• Remove from the seat the two
screws NOT fastening the seat to
the hinge brackets.
• Loosen the RH screw and remove
the LH screw from the seat and
hinge bracket.
• Rotate the rear of the seat to the
right and align the four front seat
holes with matching holes in the LH
and RH hinge brackets.
• Temporarily install the three previously removed screws into the three
open front seat holes.
• See Section 8: Adjustments for final
seat adjustment procedures.
Rotate
Remove Screw
Loosen Screw
2
SECTION 2: IMPORTANT SAFE OPERATION PRACTICES
WARNING: THIS SYMBOL POINTS OUT IMPORTANT SAFETY
INSTRUCTIONS WHICH, IF NOT FOLLOWED, COULD ENDANGER
THE PERSONAL SAFETY AND/OR PROPERTY OF YOURSELF AND
OTHERS.READ AND FOLLOW ALL INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE YOUR UNIT. FAILURE TO
COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL
INJURY. WHEN YOU SEE THIS SYMBOL, HEED ITS WARNING.
WARNING: The engine exhaust, some of its constituents, and
certain vehicle components contain or emit chemicals known to the State
of California to cause cancer, birth defects or other reproductive harm.
DANGER: Your lawn mower was built to be ope rated according to the
rules for safe operation in this manual. As with any type of power
equipment, carelessness or error on the part of the operator can result in
serious injury. This lawn mower is capable of amputating hands and feet
and throwing objects. Failure to observe the following safety instructions
could result in serious injury or death.
1. GENERAL OPERATION
• Read, understand, and follow all
instructions in the operator’s manual
and on the machine before starting.
Keep this manual in a safe place for
future and regular reference and for
ordering replacement parts.
• Only allow responsible individuals
familiar with the instructions to operate the machine. Know controls and
how to stop the machine quickly.
• Do not put hands or feet under
cutting deck or near rotating parts.
• Clear the area of objects such as
rocks, toys, wire, etc., which could
be picked up and thrown by the
blade. A small object may have
been overlooked and could be
accidentally thrown by the mower in
any direction and cause injury to
you or a bystander. To help avoid a
thrown objects injury, keep children,
bystanders and helpers at least 75
feet from the mower while it is in
operation. Always wear safety
glasses or safety goggles during
operation or while performing an
adjustment or repair, to protect eyes
from foreign objects. Stop the
blade(s) when crossing gravel
drives, walks or roads.
• Be sure the area is clear of other
people before mowing. Stop
machine if anyone enters the area.
• Never carry passengers.
• Disengage blade(s) before shifting
into reverse and backing up. Always
look down and behind before and
while backing.
• Be aware of the mower and
attachment discharge direction and
do not point it at anyone. Do not
operate the mower without either
the entire grass catcher or the chute
guard in place.
• Slow down before turning. Operate
the machine smoothly. Avoid erratic
operation and excessive speed.
3
• Never leave a running machine
unattended. Always turn off blade(s),
place transmission in neutral, set
park brake, stop engine and remove
key before dismounting.
• Turn off blade(s) when not mowing.
• Stop engine and wait until blade(s)
comes to a complete stop before (a)
removing grass catcher or
unclogging chute, or (b) making any
repairs, adjusting or removing any
grass or debris.
• Mow only in daylight or good
artificial light.
• Do not operate the machine while
under the influence of alcohol or
drugs.
• Watch for traffic when operating
near or crossing roadways.
• Use extra care when loading or
unloading the machine into a trailer
or truck. This unit should not be
driven up or down a ramp onto a
trailer or truck under power,
because the unit could tip over,
causing serious personal injury. The
unit must be pushed manually on a
ramp to load or unload properly.
• Never make a cutting height
adjustment while engine is running if
operator must dismount to do so.
• Wear sturdy, rough-soled work shoes
and close-fitting slacks and shirts. Do
not wear loose fitting clothes or
jewelry. They can be caught in
moving parts. Never operate a unit in
bare feet, sandals, or sneakers.
• Check overhead clearance carefully
before driving under power lines,
wires, bridges or low hanging tree
branches, before entering or leaving
buildings, or in any other situation
where the operator may be struck or
pulled from the unit, which could
result in serious injury.
• Disengage all attachment clutches,
thoroughly depress the brake pedal,
and shift into neutral before
attempting to start engine.
• Your mower is designed to cut
normal residential grass of a height
no more than 10". Do not attempt to
mow through unusually tall, dry grass
(e.g., pasture) or piles of dry leaves.
Debris may build up on the mower
deck or contact the engine exhaust
presenting a potential fire hazard.
• Use only accessories approved for
this machine by the manufacturer.
Read, understand and follow all
instructions provided with the
approved accessory.
2. SLOPE OPERATION
Slopes are a major factor related to
loss of control and tip-over accidents
which can result in severe injury or
death. All slopes require extra caution.
If you cannot back up the slope or if
you feel uneasy on it, do not mow it.
For your safety, use the slope gauge
included as part of this manual to
measure slopes before operating this
unit on a sloped or hilly area. If the
slope is greater than 15° as shown on
the slope gauge, do not operate this
unit on that area or serious injury
could result.
DO:
• Mow up and down slopes, not
across.
• Remove obstacles such as rocks,
limbs, etc.
• Watch for holes, ruts or bumps.
Uneven terrain could overturn the
machine. Tall grass can hide
obstacles.
• Use slow speed. Choose a low
enough gear so that you will not
have to stop or shift while on the
slope. Always keep machine in gear
when going down slopes to take
advantage of engine braking action.
• Follow the manufacturers
recommendations for wheel weights
or counterweights to improve
stability.
4
• Use extra care with grass catchers
or other attachments. These can
change the stability of the machine.
• Keep all movement on the slopes
slow and gradual. Do not make
sudden changes in speed or
direction. Rapid engagement or
braking could cause the front of the
machine to lift and rapidly flip over
backwards which could cause
serious injury.
• Avoid starting or stopping on a
slope. If tires lose traction,
disengage the blade(s) and proceed
slowly straight down the slope.
DO NOT:
• Do not turn on slopes unless
necessary; then, turn slowly and
gradually downhill, if possible.
• Do not mow near drop-offs, ditches
or embankments. The mower could
suddenly turn over if a wheel is over
the edge of a cliff or ditch, or if an
edge caves in.
• Do not mow on wet grass. Reduced
traction could cause sliding.
• Do not try to stabilize the machine
by putting your foot on the ground.
• Do not use grass catcher on steep
slopes.
3. CHILDREN
• Tragic accidents can occur if the
operator is not alert to the presence
of children. Children are often
attracted to the machine and the
mowing activity. Never assume that
children will remain where you last
saw them.
• Keep children out of the mowing
area and in watchful care of an adult
other than the operator.
• Be alert and turn machine off if
children enter the area.
• Before and when backing, look
behind and down for small children.
• Never carry children, even with the
blades off. They may fall off and be
seriously injured or interfere with the
safe machine operation.
• Never allow children under 14 years
old to operate the machine. Children
14 years and over should only
operate machine under close
parental supervision and proper
instruction.
• Use extra care when approaching
blind corners, shrubs, trees or other
objects that may obscure your vision
of a child or other hazard.
• Remove key when machine is
unattended to prevent unauthorized
operation.
4. SERVICE
• Use extreme care in handling
gasoline and other fuels. They are
extremely flammable and the vapors
are explosive.
• Use only an approved container.
• Never remove fuel cap or add fuel
with the engine running. Allow
engine to cool at least two minutes
before refueling.
• Replace fuel cap securely and wipe
off any spilled fuel before starting
the engine as it may cause a fire or
explosion.
• Extinguish all cigarettes, cigars,
pipes and other sources of ignition.
• Never refuel the machine indoors
because fuel vapors will accumulate
in the area.
• Never store the fuel container or
machine inside where there is an
open flame or spark, such as a gas
hot water heater, space heater or
furnace.
• Never run a machine inside a closed
area.
5
• To reduce fire hazard, keep the
machine free of grass, leaves or
other debris build-up. Clean up oil or
fuel spillage. Allow machine to cool
at least 5 minutes before storing.
• Before cleaning, repairing or
inspecting, make certain the blade
and all moving parts have stopped.
Disconnect the spark plug wire, and
keep the wire away from the spark
plug to prevent accidental starting.
• Check the blade and engine
mounting bolts at frequent intervals
for proper tightness. Also, visually
inspect blade for damage (e.g.,
excessive wear, bent, cracked).
Replace with blade which meets
original equipment specifications.
• Keep all nuts, bolts and screws tight
to be sure the equipment is in safe
working condition.
• Never tamper with safety devices.
Check their proper operation
regularly. Use all guards as
instructed in this manual.
• After striking a foreign object, stop
the engine, remove the wire from
the spark plug and thoroughly
inspect the mower for any damage.
Repair the damage before restarting
and operating the mower.
• Grass catcher components are
subject to wear, damage and
deterioration, which could expose
moving parts or allow objects to be
thrown. For your safety protection,
frequently check components and
replace with manufacturer’s
recommended parts when
necessary.
• Mower blades are sharp and can
cut. Wrap the blade(s) or wear
gloves and use extra caution when
servicing blade(s).
• Check brake operation frequently.
Adjust and service as required.
• Muffler, engine and belt guards
become hot during operation and
can cause a burn. Allow to cool
down before touching.
• Do not change the engine governor
settings or overspeed the engine.
Excessive engine speeds are
dangerous.
• Observe proper disposal laws and
regulations. Improper disposal
offluids and materials can harm the
environment and the ecology.
• Prior to disposal, determine the
proper method to dispose of waste
from your local Environmental
Protection Agency. Recycling
centers are established to properly
dispose of materials in an
environmentally safe fashion.
• Use proper containers when
draining fluids. Do not use food or
beverage containers that may
mislead someone into drinking from
them. Properly dispose of the
containers immediately following the
draining of fluids.
• DO NOT pour oil or other fluids into
the ground, down a drain or into a
stream, pond, lake or other body of
water. Observe Environmental
Protection Agency regulations when
disposing of oil, fuel, coolant, brake
fluid, filters, batteries, tires and other
harmful waste.
• We do not recommend the use of a
pressure washer or garden hose to
clean your unit. They may cause
damage to electrical components;
spindles; pulleys; bearings; or the
engine. The use of water will result
in shortened life and reduce
serviceability.
WARNING - YOUR RESPONSIBILITY: Restrict the use of
this power machine to persons who read, understand an d follow
the warnings and instructions in this manual and on the machine.
6
SECTION 3: CALLING SERVICE INFORMATION
The engine manufacturer is responsible for all engine-related issues with
regards to performance, power-rating, and specifications.
If you have difficulties with the unit, have any question regarding the operation
or maintenance of this equipment, or desire additional information not found in
this manual, contact your dealer. If you need help locating a dealer in your a rea,
contact the Customer Dealer Referral Line by calling:
1-877-282-8684
Or you may contact Cub Cadet via the internet by logging on to our Wed Site at:
www.cubcadet.com
Before calling your local dealer, make sure that you have your model and serial
numbers ready.
SECTION 4: FINDING YOUR MODEL & SERIAL NUMBER
This Operator’s Manual is an important part of you r new tractor. It will help you
prepare, maintain and safely operate your tractor. Please read and understand
what it says.
Before you prepare your tractor for its first use, please loca te the tractor and
engine model plates and copy the information from them into the spaces
provided below. The information on the model plates is very important if you
need help from your dealer or the Cub Cadet customer support department.
Refer to Figure 1.
• The tractor model plate is located on the right frame rail behind the right front
tire.
• The engine identification numbers appear on a decal (or decals) affixed to the
engine shrouding.
XXXXXXXXXXX XXXXXXXXXX
Model Number Mfg. Date
CUB CADET LLC
P. O. BOX
www.cubcadet.com
DEALER LOCATOR PHONE NUMBER:
Model Number
361131
CLEVELAND, OH 44136
877-282-8684
Figure 1
Mfg. Date (Serial No.)
Engine Model No. Engine Spec. No. Engine Serial No.
7
SECTION 5: SAFETY LABELS FOUND ON YOUR UNIT
DECK HEIGHT
ADJUSTMENT
(360 Turn Equals 1/2" Adjustment)
RAISE DECK LIFT LEVER UNTIL THE
1.
NUMBER 6 APPEARS IN WINDOW.
POSITION INDICATOR
2.
TURN KNOB COUNTER CLOCKWISE
TO LOWER DECKST OP.
3.
TURN KNOB CLOCKWIS E TO RAISE
DECKSTOP.
4.
LOWER DECK LIFT LEVER UNTIL
POSITION INDICATOR STOPS.
5.
REPEAT PROCESS IF NECESSARY.
Running Board - Left
P
T
S
IGNITION
STARTING INSTRUCTIONS
1.BE FAMILIAR WITH CONTROLS
BEFORE STARTING ENGINE
AND OPERATING.
2.SET CHOKE, MOVE THROTTLE
TO MID POSITION AND
DEPRESS BRAKE PEDAL.
3.TURN KEY TO THE START
POSITION.
4.AFTER ENGINE STARTS
OPEN CHOKE.
STOPPING INSTRUCTIONS
1.DISENGAGE PTO AND SET
PARKING BRAKE.
2.MOVE THROTTLE CONTROL
TO MID POSITION AND TURN
KEY OFF
O
Running Board - Center
WARNING
AVOI D SERIOUS INJURY
OR DEATH
GO UP AND DOWN
•
SLOPES, NOT ACROSS.
AVOID SUDDEN TURNS.
•
DO NOT OPERATE UNIT
WHERE IT COULD SLIP
OR TIP.
IF MACHINE STOPS
•
GO ING UPHILL, STOP PTO
AND BACK DOWN HILL
SLOWLY.
DO NOT MOW WHEN
•
CHILDREN OR OTHERS
ARE AROUND.
NEVER CARRY CHILDREN.
•
LOOK DOWN AND
•
BEHIND BEFORE AND
WHILE BACKING.
KEEP SAFETY DEVICES
•
[GUARDS, SHIELDS,
AND SWITCHES] IN
PLACE AND WORKING.
REMOVE OBJECTS THAT
•
COULD BE THROWN BY
THE BLADES.
KNOW LOCATION AND
•
FUNCTION OF ALL CONTROLS.
BE SURE THE BLADES AND
•
THE ENGINE ARE STOPPED
BEFORE PLACING HANDS
OR FEET NEAR BLADES.
BEFORE LEAVING
•
OPERATOR'S POSITION,
DISENGAGE PTO, ENGAGE
BRAKE LOCK, SHUT OFF
ENGINE AND REMOVE KEY.
READ OPERAT OR'S MANU AL
Running Board - Right
WARNING
TO ENSURE SAFE AND
PROPER OPERATION
OF TRANSMISSION,
ONLY USE CUB CADET
DRIVE SYSTEM
FLUID PLUS.
737-3120 - 1 QUART
737-3121 - 1 GALLON
READ OPERATOR'S
MANUAL
Rear Drawbar
WARNING
!
Front Grille
HOT AREAS
Hood Hinge Bracket
Figure 2
8
SECTION 6: CONTROLS
T
O
P
N
M
R
S
F
L
K
J
I
A
B
C
D
E
G
Q
(Not Shown)
H
Parking Brake Lever
A
PTO Switch
B
Brake Pedal
C
Reverse Pedal
D
Forward Pedal
E
Center Lift Height Indicator
F
Ignition/Light Switch
G
Transmission Release Rod
H
Transmission Oil Fill/Dipstick
I
Fuel Fill CapJ Indicator Light PodT
* Steering Wheel and Seat
Removed For Clarity
Figure 3
K
L
M
N
O
P
Q
R
S
9
Cup Holder
Hydraulic Lift Lever
Steering Wheel Tilt Lock
Cruise Control Lever
Choke Lever
Throttle Lever
Seat Adjustment Lever (Not Shown)
Differential Lock Pedal
Deck Height Adjustment Knob
NOTE: References to LEFT and
RIGHT indicate that side of the tractor
when facing forward while seated in
the drivers seat. Reference to FRONT
indicates the grille end of the tractor;
to REAR, the drawbar end.
Steering Wheel
The steering wheel, centered on the
dash panel, is used to turn the tractor
left or right while driving.
NOTE: This tractor is equipped with
hydraulic power steering. With this
feature, the center of the steering
wheel may not stay center aligned.
Parking Brake Lever
Figure 4
The parking brake lever is located to
the right of the steering wheel on the
dash panel. With the brake pedal
depressed fully, push the parking
brake lever and release the brake
pedal to lock the parking brake.
PTO Switch
The PTO switch is located on the right
side the dash panel. Pull upward on
the right edge of the switch handle to
engage the PTO clutch. Push the
switch downward to disengage the
PTO clutch.
Brake Pedal
switch when starting the tractor.
Depressing the brake pedal will also
engage the transmission differential
lock. Always make certain the diff. lock
disengages when the brake pedal is
released.
Reverse Pedal
Figure 6
NOTE: Check behind the tractor to
be sure the area is clear of people,
pets or obstacles and use a slower
speed to maintain control of the tractor
when traveling in reverse.
The reverse control pedal is located
on the right running board below the
brake pedal. Press the pedal down to
move in reverse.
Forward Peda l
Figure 7
The forward control pedal is located
on the right running board below the
brake pedal. Slowly press down on the
pedal to start moving forward. The
forward ground speed of the tractor is
directly affected by the distance the
pedal is depressed.
Figure 5
The brake pedal is located at the front
of the right running board above the
forward and reverse pedals. Depress
to stop the tractor and disengage the
cruise control. Fully depress the brake
pedal to activate the safety interlock
Center Lift Height Indicator
The center lift height indicator is
located in the left running board. This
indicator shows the operator the
relative height position setting of the
hydraulic center lift system. The lower
number indicates a lower setting.
10
Ignition / Light Switch
To prevent accidental starting and/or
battery discharge, remove the key
from the ignition switch when the
tractor is not in use. The combination
lights and ignition switch has four
positions. See Figure 8 for a
description of each position.
Off
On/Lights
On
Start
Figure 8
Transmission Release Rod
The transmission release rod is
located at the back of the tractor in the
draw bar. This rod, when engaged,
allows the tractor to be pushed short
distances by hand.
To disengage the transmission, pull
back on the rod until its locking flange
is visible outside the drawbar, then
lower the rod into the slot and release.
To reengage the transmission, pull
back on the rod, lift out of the slot and
release.
Transmission Oil Fill/Dipstick
The transmission oil fill/dipstick is
located at the back of the tractor in the
rear draw bar. The handle of the
transmission oil dipstick serves as
the fill tube plug and should fit snugly
in the fill tube.
Fuel Fill Cap
The fuel fill cap is located on the
fender to the left of the seat.
Cup Holder
The cup holder is located on the
fender to the left of the seat.
Hydraulic Lift Lever
The hydraulic lift lever is located on
the fender to the left of the seat. This
lever is used to operate the tractor’s
center lift system.
Steering Wheel Tilt Lock
The steering wheel tilt lock is located
below the steering wheel in the dash
panel. Press downward to release.
Cruise Control Lever
Figure 9
The cruise control lever is located to
the left of the steering wheel. Push the
cruise control lever downward while
traveling at the desired forward speed
to engage the cruise control.
Choke Lever
The choke lever is located to the left of
the steering wheel in the throttle/choke
lever pod. Push the lever forward to
close the engine choke plate.
Throttle Lever
This symbol shows the fast
position.
This symbol shows the slow
position
The throttle lever is located to the left of
the steering wheel in the throttle/choke
lever pod. When set in a given position,
the throttle lever will maintain a uniform
engine speed. Push the lever forward to
increase the engine speed.
IMPORTANT: When using power
take-off operated equipment, best
performance is achieved with the
throttle lever in the “FAST” position.
11
Seat Adjustment Lever
The seat adjustment lever is located
below the seat. This lever is used to
adjust the seat forward or backward.
Differential Lock Pedal
Located at the front of the left running
board. Depressing the diff. lock pedal
engages the transmission differential
lock, which improves traction at the rear
wheels when operating on uneven terrain or in slippery conditions. However,
use care when engaging the diff. lock
on manicured turf where sharp turns
are required. Damage to the turf could
occur.
Depressing the brake pedal also actuates the diff. lock pedal. Make certain
the diff. lock disengages when the
brake pedal is released.
Deck Height Adjustment Knob
The deck height adjustment knob is
located on the left running board (See
Figure 10). Use this knob to set (and
hold) your desired deckstop position
for the mower deck, regardless of
whether the deck caster wheels
contact the ground.
Each full rotation of the adjustment
knob equals approximately a 1/4 inch
adjustment in the deck height setting,
and there are four detent positions per
rotation.
Always use the tractor lift system to
raise the deck before turning the
adjustment knob.
LOWER
RAISE
Height
Adjustment
Knob
Figure 10
Deck Front Lift Rod Assembly
For shipping purposes, the deck front
lift rod assembly has been installed on
the tractor. Cut the tie strap holding
the lift rod assembly to the tractor;
then pull downward on the quick latch
rod at the front of the tractor to remove
the lift rod assembly.
Quick Latch Rod
Lift Rod Assembly
Figure 11
12
Indicator Light Pod
A
A
Oil Pressure Indicator
B
Low Fuel Indicator
C
Hour Meter
B
Figure 12
Hour Meter
The hour meter is part of the indicator
light pod in the dash panel. The hour
meter operates whenever the ignition
switch is in the “ON” or “ON/LIGHTS”
position. Record the actual hours of tractor operation to ensure all maintenance
procedures are completed according to
the schedule in this manual.
Oil Pressure Indicator
WARNING: Operating the
tractor with low oil level or
low pressure could result in
severe engine damage.
D
C
D
Not Used
E
Not Used
The oil pressure indicator is part of the
indicator light pod on the dash panel.
This indicator will illuminate when the
engine oil pressure is low. If this
indicator illuminates, stop the tractor
immediately and check the engine oil
level. If the oil level is within the
operating range, and the light remains
on, contact your Cub Cadet dealer.
E
Low Fuel Indicator
The Low Fuel indicator is part of the
indicator light pod on the dash panel.
This indicator will illuminate when the
tractor is low on fuel. If the gas tank is
full and the light stays on, contact your
Cub Cadet dealer.
13
SECTION 7: OPERATION
Safety Interlock Switches
This tractor is equipped with a safety
interlock system for the protection of
the operator. If the interlock system
should ever malfunction, do not
operate the tractor. Contact your
authorized Cub Cadet Dealer. The
safety interlock system prevents the
engine from cranking or starting
unless the brake pedal is fully
depressed, and the PTO is “OFF”.
• The safety interlock system will
automatically shut off the engine if
the operator leaves the seat before
engaging the brake lock.
• The safety interlock system will automatically shut off the engine if the
operator leaves the seat with the PTO
“ON”, regardless of whether the brake
lock is engaged. The PTO switch
must be “OFF” to restart the engine.
• The safety interlock system will
automatically shut off the PTO if the
reverse control pedal is depressed
with the PTO “ON”.
Fueling The Tractor
:Some fuels, called oxygen-
NOTE
ated or reformulated gasolines, are
gasoline blended with alcohols or
ethers. Gasolines blended with either
ethyl alcohol (Max. 10%) or methyl tertiary butyl ether (MTBE, Max. 15%)
are approved as fuels for this engine.
If any undesirable operating symptoms occur, use gasoline with a lower
percentage of these blends. Do not
use gasoline which contains Methanol
or other alcohol blends. For best
results use only clean, fresh,
unleaded gasoline with an octane rating of 87 or higher. Purchase fuel in a
quantity that can be used within 30
days to assure fuel freshness. Do not
use gasoline left over from the pevious season to minimize gum deposits
in the fuel system. Leaded gasoline is
NOT RECOMMENDED. Leaded gasoline may be used in areas where
unleaded is not available and exhaust
emissions are not regulated.
Do not fill the fuel tank when the
engine is running or while the engine
is hot. Tighten the fuel cap securely.
Unscrew the fuel cap and fill the fuel
tank from an approved gasoline
container.
Starting The Engine
• Operator must be sitting in the
tractor seat.
• Push choke lever to the full choke
position. Less choking may be
necessary due to variations in
temperature, grade of fuel, etc. Little
or no choking will be needed when
the engine is warm.
• Place the throttle midway between
the “SLOW” and “FAST” position.
• Make sure the PTO switch is in the
“OFF” position.
• Fully depress the brake pedal.
• Turn the ignition key clockwise to
the “START” position and release it
as soon as the engine starts;
however, do not crank the engine
continuously for more than 10
seconds at a time. If the engine
does not start within this time, turn
the key to “OFF” and wait a minute
to allow the engine’s starter motor to
cool. Try again after waiting.
• After the engine starts, slowly
release the brake pedal. As the
engine warms up, gradually pull the
choke lever all the way back. Do not
use the choke to enrich the fuel
mixture, except when necessary to
start the engine.
Stopping The Engine
NOTE: Remove the key from the
ignition switch to prevent accidental
starting or battery discharge if the
equipment is left unattended.
14
Loading...
