G1332, G1336, G1548
Walk-Behind Commercial
Rotary Mowers
Professional Turf Equipment
OPERATOR’S AND SERVICE MANUAL
INDEX
Foreword............................................................................................................................................................... 3
Safety Precautions.............................................................................................................................................4
A.
General..........................................................................................................................................................4
B.
Related to Fuel........................................................................................................................................... 4
C.
When Mowing............................................................................................................................................. 4
Safety Decals................................................................................................................................................... 5-6
Specifications...................................................................................................................................................... 7
Operating Instructions....................................................................................................................................7-9
A.
Controls......................................................................................................................................................... 7
1.
Ignition Switch............................................................................................................................................ 7
2.
Fuel Shutoff Valve....................................................................................................................................7
3.
Engine Throttle.......................................................................................................................................... 7
4.
Recoil Starter.............................................................................................................................................7
5.
Transmission Shift Lever........................................................................................................................ 7
6.
Blade Clutch...............................................................................................................................................8
7.
Steering/Brake Lever............................................................................................................................... 8
8.
Neutral Latch Levers................................................................................................................................8
9.
Operator Presence Levers..................................................................................................................... 8
B.
Initial Adjustments....................................................................................................................................... 8
C.
Break-ln and Operation..........................................................................................................................8-9
Cutting Height Adjustment Table..................................................................................................................10
Maintenance..................................................................................................................................................10-14
A.
General Maintenance...............................................................................................................................10
B.
Daily Maintenance After Mowing...........................................................................................................10
C.
Maintenance Every 40 Hours.................................................................................................................10
D.
Lubrication Chart....................................................................................................................................... 11
E.
Engine Maintenance................................................................................................................................11
F.
Mower Maintenance..................................................................................................................................11
1.
To Change a Blade..................................................................................................................................11
2.
To Sharpen a Blade.................................................................................................................................11
3.
To Change the Blade Drive Belts........................................................................................................11
4.
To Change the Transmission Drive Belt............................................................................................12
5.
To Change Either Traction Drive Belt.................................................................................................12
6.
To Change a Spindle Assembly...........................................................................................................13
7.
To Adjust the Lite Touch (Manually)...................................................................................................13
Suggested Replacement Parts - Mower....................................................................................................14
Suggested Replacement Parts - Engine ...................................................................................................14
Warranty.............................................................................................................................................................BC
2
FOREWORD
The Cub Cadet Commercial, Walk-Behind, Rotary Mowers have been developed
for use by professional landscapers, commercial lawn service companies, professional
turf managers and golf course superintendents. The machines incorporate many safety
features that should be studied by all operators and maintenance personnel before use.
The list of safety precautions should receive particular attention. This manual presents
the operating and maintenance instructions necessary to keep your Cub Cadet
Commercial mower at peak efficiency. If properly operated and maintained, your Cub
Cadet Commercial mower will give dependable and trouble-free service.
Although hazard control and accident prevention partially are dependent upon the
design and configuration of the equipment, these factors are also dependent upon the
awareness, concern, prudence, and proper training of the personnel involved in the
operation, transport, maintenance and storage of the equipment.
CAUTION: THE Cub Cadet Commercial, Walk-Behind, Rotary Mowers should
only be operated and maintained by thoroughly trained individuals. The
machines could cause serious injury to anyone who misuses them or does not
understand their operation. All operators and maintenance personnel are urged
to read this entire manual for their personal safety.
WARNING: The Engine Exhaust from this product contains chemicals known to the
State of California to cause cancer, birth defects or other reproductive harm.
NOTE: The engine manufacturer is responsible for all engine-related issues with
regards to performance, power-rating, specifications, warranty and service.
Please refer to the engine manufacturer’s owner’s/operator’s manual, packed
seperately with your unit, for more information.
This product may be covered by one or more of the following patents:
D415,503; 5,928,097; 6,012,274; 5,355,665; 6,226,966; 6,266,949
3
SAFETY PRECAUTIONS
A. General:
1. Read this Operator’s Manual completely before starting
the mower. Study the controls and learn the proper
sequence of operation. Retain Operator’s Manual in a
safe place for future reference.
2. Do not allow anyone to operate or maintain this machine
who has not read the manual. Never permit children
under the age of 16 to operate this machine.
3. Always have your feet and hands clear of the cutter
deck when starting the engine.
4. Do not remove any shields, guards, decals or safety
devices. If a shield, guard, decal or safety device is
damaged or does not function, repair or replace it b efore
operating the mower.
5. Always wear safety glasses, long pants and safety
shoes when operating or maintaining this mower. Do not
wear loose-fitting clothing.
6. Never run the engine indoors without adequate
ventilation. Exhaust fumes are deadly.
7. To avoid serious burns, do not touch the engine or
muffler while the engine is running or until it has cooled
for at least 30 minutes after it has been shut off.
8. Do not allow anyone to ride on this mower. No
passengers.
9. Do not operate this mower under the influence of
alcohol and or drugs.
B. Related To Fuel:
1. Gasoline is highly flammable. Respect it.
2. Do not smoke or permit others to smoke while handling
gasoline.
3. Always use approved containers for gasoline.
4. Always shut off the engine and permit it to cool before
removing the cap of the fuel tank.
5. If the fuel container spout will not fit inside the fuel tank
opening, use a funnel.
6. When filling the fuel tank, stop when the gasoline
reaches one inch from the top. This space must be left
for expansion. Do not overfill.
7. Wipe up any spilled gasoline.
C. When Mowing:
WARNING: Never mow in fourth gear
(transport speed).
1. Keep adults, children and pets away from the area to be
mowed.
2. Never use this mower without the discharge chute
installed and set in the down position.
3. Mow only in daylight or proper artificial light.
4. Always remove debris and other objects from the area
to be mowed.
5. Watch for holes, sprinkler heads and other hidden
hazards.
6. Reduce speed when making sharp turns.
7. Always have proper footing on slopes and hill sides and
never operate when conditions are slippery.
8. Always keep both hands on the handles when mowing.
Always walk, never run.
9. Never engage the blade clutch when the engine is
running unless you are on grass that you intend to mow.
10. Be careful when crossing gravel paths or road- ways.
Always disengage the blade clutch and wait until the
blades stop rotating.
11. Never leave the mower unattended without disengaging
the blade clutch, shifting the transmission into neutral,
placing the neutral latch levers in the neutral lock
position, shutting off the engine, removing the key from
the ignition switch and closing the fuel shutoff valve.
12. Always park the mower and start the engine on a level
surface with the transmission in neutral, the blade clutch
disengaged and the neutral latch levers in the neutral
lock position.
13. Shut off the engine and wait for the blades to stop
rotating before removing the grass catcher.
14. If you hit a solid object while mowing, disengage the
blade clutch, shift the transmission into neutral, place
the neutral latch levers in the neutral lock position and
stop the engine. Disconnect the spark plug wire(s) and
inspect for damage. Repair any damage a nd make sure
the blades are in good condition and the blade bolts are
tight before restarting the engine.
15. Do not mow excessively steep slopes (No more than 17
degrees or a 30% grade). Mow across the slope, not up
and down the slope.
16. Never raise the mower deck while the blades are
rotating.
17. Never walk or stand on the discharge side of a mower
with the engine running. Disengage the blade clutch if
another person approaches while you are operating a
mower.
18. Always disconnect the spark plug wire and negative
battery cable to prevent the engine from accidentally
starting before performing any maintenance on this
mower.
19. Keep the mower and especially the engine clean and
free of grease, grass and leaves to reduce the chance
of fire and to permit proper cooling.
20. The operator presence control levers located at each
handle are designed for your safety. Do not try to defeat
their operation. If the blade clutch is engaged or the
transmission is in gear, releasing both handles will shut
off the mower’s engine.
4
SAFETY DECALS
Keep safety decals clean. Replace any safety decal that is damaged, destroyed, missing,
painted over or can no longer be read. Replacement safety decals are available through your
dealer. (Left and right sides are determined standing behind the unit in the operating position.)
WARNING
OPEN BELT DRIVE
STOP ENGINE BEFORE
REACHING UNDERNEA TH
- TURN OFF ENGINE AND ALLOW
WARNING
TO COOL BEFORE REFUELING.
- DO NOT SMOKE NEAR FUEL.
CLOSE FUEL VALVE
WHEN MACHINE IS
NOT IN USE
DANGER
ROTATING BLADE
Do not put hands or feet
under or into mower when
engine is running.
IF VALVE IS LEFT OPEN,
SEVERE ENGINE DAMAGE
OR HARD STARTING MAY
RESULT FROM FLOODING
WARNING
SHIELD MISSING
DO NOT OPERATE
5
DANGER
SAFETY DECALS
To Avoid Injury:
Always connect the “ground”
•
(Black) cable last and
remove it first whenever
performing any battery
maintenance.
Do not contact battery
•
terminals or tools used to
loosen the terminals with
metal parts.
Avoid contact with battery
•
acid.
Keep sparks and flames
•
away from the battery.
CAUTION
Serious bodily injury may result from failure
to follow safe operating procedures.
1. Read the Operators Manual before
operating this machine.
2. Clear area of debris before mowing.
3. Do not remove or disable any shield,
guard or safety device.
4. Always chock the wheels when parking
the machine on a slope.
5. Stop engine, disconnect the spark plug
and disengage blade drive before
adjusting or servicing.
6. Keep people and pets a safe distance
away from machine.
7. Do not add fuel while engine is warn or
running.
8. Use caution on slopes.
9. Before leaving the operators position:
- Disengage the cutter blades.
- Shift transmission to neutral and engage
neutral locks.
- Wait for all movement to stop.
TO REDUCE THE RISK OF INJURY,
DO NOT OPERATE MOWER UNLESS
DISCHARGE CHUTE COVER OR GRASS
CATCHER IS IN ITS PROPER PLACE.
DANGER
KEEP HANDS and FE ET AW AY
6
SPECIFICATIONS
Engine: 13 or 15 HP Kawasaki.
Type: 4-cycle, single-cylinder, recoil start.
Air Cleaner: Dual element, dry-type.
Lube System: Pressurized.
Fuel Tank: 5 gallons, polyethylene.
Transmission: 5 speeds forward and 1 speed reverse.
Traction Drive: Double V-belts.
Ground Speed: 2 to 4.5 MPH maximum.
Drive Wheels: 13 x 6.50-6 pneumatic tires mounted on steel wheels with ball bearings.
Brakes: Two 6-inch drum, external band type.
Controls: Right and left steering/brake levers; over-center blade clutch; transmission shift lever;
engine throttle; cutter blade,transmission neutral and operator presence safety
group; key-type ignition switch.
Frame Steel Plate. All welded construction.
Handles 1-1/4" diameter, tubular steel, adjustable.
Cutting Width: 32" 36" 48" 52"
Overall Width: 33" 37" 49" 53"
Number of Blades: 2 2 3 3
Height of Cut: 2 to 4 inches in 1/4" increments.
Deck Material: 10 gauge steel top with 7 gauge steel skirt.
Casters 9 x 3.50-4, 4-ply tires with inner tubes.
Wheels have open-cage roller bearings.
POWER UNIT
CUTTING DECK
OPERATING INSTRUCTIONS
A. Controls
1. Ignition Switch:
(Recoil Start)
Located in the center of the control panel between the
handles. When the key is inserted and turned clockwise
90 degrees, the engine can be started if the
transmission shift lever is in neutral and the blade clutch
is disengaged.
(Electric Start)
Located in the center of the control panel between the
handles. When the key is inserted and turned clockwise
90 degrees, the engine will start if the transmission shift
lever is in neutral and the blade clutch is disengaged.
2. Fuel Shutoff Valve:
Located under the fuel tank in the opening of the handle
mount frame. The handle turns 90 degrees. When the
handle is in a horizontal position, it will shut off the flow
of fuel to the engine. When it is turned to a vertical
position, it will open and allow fuel to flow to the engine.
Anytime the mower is being trailered or, if the mower will
not be in use for 30 minutes or more, close the fuel
shutoff valve to prevent flooding the engine.
3. Engine Throttle:
Located on the right side of the control panel between
the handles. Moving the throttle lever from the fro nt to
the rear will increase the engine speed from slow to fast.
To start the engine, set the throttle all the way to the
rear in the “Choke” position. After the engine starts,
move the throttle halfway between slow and fast.
4. Recoil Starter:
Located on the top of the engine. To start the engine,
7
set the throttle on “Choke” and grasp the starter grip and
pull slowly until the starter engages. Then pull the cord
rapidly to overcome compression, prevent kickback and
start the engine. Repeat if necessary with the throttle
pushed halfway back to the “Slow” position.
9
7
Figure 1 The Control Panel
1. Ignition Switch 3. Engine Throttle
6. Blade Clutch Lever or
Electric Blade Clutch
8. Neutral Latch Levers 9. Right Operator Presence Lever
5. Transmission Shift Lever:
Located under the control panel. The lever has seven
positions moving from the left to the right:
Reverse Gear, Neutral, First Gear, Second Gear, Third
Gear, Fourth Gear and Fifth Gear. The lever must be in
the Neutral position in order to start the engine. Never
attempt to mow in Fifth Gear. Fifth Gear should be used
for transport only.
from one forward gear to another while m oving.
8
1
3
7. Right Steering Brake Lever
Note: DO NOT shift the transmission
6
OPERATING INSTRUCTIONS
Figure 2 View Looking Under The Fuel Tank
2. Fuel Shutoff Valve 5. Transmission Shift Lever
6. Blade Clutch (Manual and Electric):
Located on the left handle below the control panel. T his
is an over-center belt clutch. When the handle is pushed
forward it snaps to rest and forces the idler pulley into
the blade drive belt causing the blades to rotate. Pull
back the handle and the pressure on the belt is relieved
and the blades stop rotating. Electric: Located on the
left side of the control panel, this is an on/off toggle
switch that controls the electric blade clutch which
supplies power to the cutting blades. See Handle
Assembly with Electric Blade Clutch in Parts List.
7. Steering Brake Levers:
There is a right-hand lever located beneath the outer
end of the right handle and a left-hand lever located
beneath the outer end of the left handle. Each lever
operates independently and when squeezed against
spring tension, lifts the idler pulley from applying
pressure to the traction drive belt on the right or left side
and applies the right or left side brake. When the levers
are released, the mower will move ahead in a straight
line if the engine is running and the transmission is
engaged in a forward gear. Steering is accomplished by
squeezing the steering/brake lever on the side to which
the turn is to be made.
8. Neutral Latch Levers:
Pivoted inside each handle there is a neutral latch lever
which works with each of the steering/brake levers.
When either of the steering/brake levers is squeezed
and its neutral latch lever pushed forward and engaged
in the neutral lock position, the steering/brake lever is
held in a position where the idler pulley is not applying
pressure to the traction drive belt and the brake is not
quite engaged. The neutral latch levers should be
engaged in the neutral lock position before starting th e
engine.
9. Operator Presence Levers:
Located above the outer ends of the right and left
handles, these levers must be held down on the handles
against spring pressure in order to shift the transmission
shift lever into gear or engage the blade clutch.
Releasing the operator presence levers with either the
transmission shift lever in gear or the blade clutch
engaged will shut off the engine.
B. Initial Adjustments
1. Disconnect the spark plug wire.
2. Check the tire pressure. Drive Wheels should be inflated
to 25 psi. Caster Wheels should be inflated to 15 psi.
Note: New tires are overinflated in order to properly seat
the bead to the rim.
3. Check that all nuts, bolts and screws are tight.
4. Check the tension of the deck drive belts:
a. Remove the deck cover shield and engage the
blade clutch.
b. Make sure the belts clear the belt guides by 1/8" to
1/4".
c. The tension of the deck drive belts should be
adjusted so that a ten-pound pull between two
pulleys deflects each belt about 1/2". Do not
overtighten these belts. The blade clutch should
engage with only moderate force.
d. Replace the deck cover shield and disengage the
blade clutch.
5. The tension of the transmission drive belt should be
adjusted so that a five-pound pull between the engine
traction drive pulley and the transmission drive pulley
deflects the belt about 3/16".
6. The two drive wheel belts are self-adjusting.
7. The steering control rods on each side of the handle
assembly should initially be adjusted so that there is
about a 1/4" space between the rod and the bottom of
the slot in the neutral latch lever with the latch in the
drive position. To make this adjustment, remove the
large hairpin from the swivel joint at the bottom of each
steering control rod and thread the swivel joint up or
down the rod as needed.
8. The brake rods (above each drive wheel) should be
adjusted so that when the steering/brake levers are
squeezed and the mower is pulled backward, the brakes
lock the drive wheels. The machine should roll freely
when the neutral latch lever is in the neutral lock
position. To adjust the brake rods, remove the large
hairpin from the swivel joint at the top of each brake rod
and thread the swivel joint up or down the rod as
needed.
9. Adjusting the cutting height: The mower is shipped with
the cutting height set at 3 inches ±1/4 inch depending
on the air pressure in the tires. To change the cutting
height, blade spacers and/or caster spacers must be
moved according to the table on page 6.
10. Lubricate all fittings listed in the maintenance section.
C. Break-In and Operation:
1. Make certain you thoroughly understand all of the safety
precautions before you attempt to operate this machine.
2. Check the engine oil level. Fill to the proper level with
10W-40 engine oil rated for service SE or SF.
8
OPERATING INSTRUCTIONS
3. Move the mower outdoors. Check the engine gasoline
level. When filling the tank, stop when the gasoline
reaches one inch from the top. This space must be left
for expansion. Use fresh, clean, unleaded, regular
gasoline.
4. Move the mower to a “test area” where you can operate
the mower for about half an hour without being
disturbed.
5. To start the engine:
a. Shift the transmission to neutral.
b. Disengage the blade clutch.
c. Place the neutral latch levers in the neutral lock
position.
d. Connect the spark plug wire.
e. Open the fuel shutoff valve.
f. Move the throttle lever to the “Choke” position.
g. Put the key in the ignition switch and turn the switch
on. (For electric-start engines: Turn the key to “Start”.
Do not hold the key in the start position for more than
10 seconds or you may damage the starter.)
h. For recoil-start engines: Grasp the starter grip and
pull slowly until the starter engages and then pull the
cord rapidly to overcome compression, prevent
kickback and start the engine. Allow the cord to recoil
slowly. Repeat if necessary.
i. Set the throttl e at 50% of full engine RPM and allow
the engine to warm up. Then, adjust the throttle to ful l
engine RPM.
6. After the engine has warmed up, shut off the ignition
and check the operation of the safety switches. Make
certain that the engine will not start unless the ignition
switch is turned on, the transmission is in neutral and
the blade clutch is disengaged. If the engine will start
with the transmission in any gear other than neutral,
immediately shut off the engine and replace the ne utral
safety switch on top of the transmission. If the engine
will start with the blade clutch engaged, immediately
shut off the engine and adjust or replace, if necessary,
the blade safety switch mounted on the engine deck.
Start the engine and hold the left operator presence
control lever down against the left handle and move the
transmission shift lever into first gear. Now take your
hand off the operator presence control lever and the
engine should die. If it does not, immediately shut off the
engine and adjust or replace, if necessary, the operator
presence switch under the control panel. Shift the
transmission into neutral, restart the engine, hold the left
operator presence control down against the left handle
and engage the blade clutch. Now take your hand off of
the operator presence lever and the engine should die.
If it does not, immediately shut off the engine and adjust
or replace, if necessary, the operator presence switch
under the control panel. Disengage the blade clutch.
7. Restart the engine.
8. Push the blade clutch lever forward until it engages and
the cutter blades start rotating.
9. Shift the transmission into first gear. (It is suggested that
you practice mowing in first gear.)
10. Squeeze both steering/brake levers with both hands and
release the neutral latch levers from the neutral lock
position.
11. Slowly release the steering/brake levers and the mower
will move ahead in a straight line. To turn the mower,
squeeze the steering/brake lever on the side to which
you want to turn.
12. To stop the mower’s forward motion, squeeze both
steering/brake levers until the mower stops and place
the neutral latch levers into the neutral lock position.
13. Before shifting into reverse gear, the mower’s forward
motion must be completely stopped. For maximum
traction in reverse, the steering/brake levers should be
pushed downward.
WARNING: To avoid possible bodily injur y
and to prevent damage to the transmission,
the mower must be completely stopped before
attempting to shift from forward to reverse or
reverse to forward.
14. Practice operating the mower and as you gain
confidence, shift the transmission from first to second
and mow for a while and then shift from second to third.
Mow for at least one-half hour and then return the
mower to the shop.
15. To stop and shut off the mower, squeeze both steering/
brake levers and place the neutral latch levers into the
neutral lock position, disengage the blade clutch, shift
the transmission into neutral, turn off the ignition to stop
the engine, close the fuel shutoff valve and disconnect
the spark plug wire.
16. Check that all nuts, bolts and screws are still tight.
17. Check, and adjust if necessary, the tension of the deck
drive belts and the transmission drive belt as described
in items 4 and 5 of the Initial Adjustment section.
18. Readjust the steering control rods and the brake rods.
They may require frequent adjustment until the belts
and brake bands have properly seated. These
adjustments are described in items 7 and 8 of the Initial
Adjustment section.
19. After the first full day of mowing, all nuts, bolt and
screws should be rechecked for proper tightness and
the belts should be rechecked for proper tension.
9
CUTTING HEIGHT ADJUSTMENT TABLE
Note: The front edge of the cutting deck should be 1/8” - 1/4” below the rear edge of the deck so that the blades are cutting
grass in only the front half of their circular path. This decreases friction and reduces the drive power requi red.
1/4: Blade Spacers
Approximate
Cutting Height
Inches Above Below Above Below
2
2-1/8
2-3/8
2-1/2
2-3/4
3
3-1/4
3-1/2
2-3/4
3
3-1/4
3-1/2
3-3/4
3-1/4
3-1/2
3-3/4
4
Above and Below The
Spindle Assemblies
0
1
2
1
2
3
4
5
0
1
2
3
4
0
1
2
3
5
4
3
4
3
2
1
0
5
4
3
2
1
5
4
3
2
1/2” Caster Spacers Above
and Below The Caster
Bracket
3
3
3
2
2
2
2
2
2
2
2
2
2
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
2
2
3
3
3
3
Engine Deck bolted to
upper holes on cutting
deck.
Engine Deck bolted to
lower holes on cutting
deck.
MAINTENANCE
WARNING: Disconnect the spark plug wire
to prevent the engine from accidentally
starting before performing any maintenance
on this mower.
A. GENERAL MAINTENANCE:
1. If the mower must be tipped on its side for maintenance,
first drain the fuel from the fuel tank and the oil from the
engine’s crankcase.
2. Be careful not to spill lubricant on the drive belts.
3. Do not tamper with the engine’s governor settings. They
are adjusted to provide the proper maximum engine
speed.
4. If the mower is to be in storage for more than 30 da ys,
drain the fuel tank, run the engine to drain the
carburetor dry, change the oil, remove the spark plug
and pour a teaspoonful of oil into the cylinder. Pull the
starter cord slowly to crank the engine and distribute the
oil then replace the spark plug.
B. DAILY MAINTENANCE AFTER MOWING:
1. Park the mower outside the storage facility with the
engine shut off.
2. Close the fuel shutoff valve.
3. Permit the mower to cool.
4. Disconnect the spark plug wire.
5. Wash the mower off with water. Be sure to clean out
grass clippings from under the cutter deck and also
under the deck cover. Allow the mower to dry before
storing.
6. Check that the blade mounting bolts are tight.
7. Check that the blades are sharp. NOTE: Never mow
with dull blades.
8. Check the fuel level, the engine oil level and clean the
cooling-air intake (the rotating screen).
9. Clean the air cleaner elements (foam and paper).
10. After the first 5 hours of use, change the engine oil.
(Change the oil every 40 hours thereafter.)
11. Follow the lubrication chart on page 7.
12. Place the mower in locked storage to avoid tampering or
use by an untrained operator.
C. MAINTENANCE EVERY 40 HOURS:
1. Change the engine oil and replace the oi l filter. (Change
the engine oil more frequently under severe operating
conditions.)
2. Check that all nuts, bolts and screws are tight.
3. Check the condition and tension of all belts.
4. Clean the spark plug and check the spark plug gap.
5. Follow the lubrication chart on page 7.
6. Check condition and operation of all safety switches.
10
MAINTENANCE
D. LUBRICATION CHART: See Figures 3, 4 & 5 for Item Location
NUMBER OF
GREASING
POSITIONS ITEM DESCRIPTION
32” & 36” 48” & 52”
DAILY 2 3 A Cutter Blade Spindle Bearings
Caster Wheel Bearing
2
2
2
2
2
1
2
EVERY
40
HOURS
2
2
1
2
2
1
2
E. ENGINE MAINTANENCE:
For detailed maintenance instructions for the engine on your
mower, see the separate engine manual packed with your
mower.
F. MOWER MAINTANENCE:
B
Caster Wheel Pivot Shafts
C
Deck Idler Pulley Pivot Arms
D
Drive Wheel Bearings
E
Brake Lever Pivots
F
Blade Clutch Bellcrank Pivot
G
Transmission-Jackshaft Couplers
H
Figure 3
1. TO CHANGE A BLADE: (See Figure 6.)
a. Remove the deck cover.
b. Tip the mower back and block up the front of the
deck.
c. Place one wrench on the hex head bol t under the
blade. Use a second wrench to remove the locknut
on top of the spindle pulley.
d. Remember the number of blade spacers both
above and below the spindle.
e. Remove the long (9-1/2") blade bolt, the flat
washer, the blade and the blade spacers.
f. To replace the blade, reverse the above procedure.
Be careful to replace the blade spacers correctly
above and below the spindle.
2. TO SHARPEN A BLADE:
a. To sharpen a blade, clamp the blade in a vise and,
using a flat mill file, carefully file the cutting surface
on each end of the blade to a sharp edge.
g. Blades with severe nicks or dents that cannot be
removed by filing should be replaced.
h. After sharpening, check the balance of the blade by
placing the blade on a blade balancer fulcrum
device.
i. If the blade dips on one end, file stock off of the
cutting surface on that end. NOTE: If a blade
cannot be easily balanced, replace it.
Figure 4
G
H
Figure 5
3. TO CHANGE THE DRIVE BELTS:
a. Make sure the blade clutch is disengaged.
b. Remove the deck cover.
c. Remove the cap screw which serves as a belt
guide and is mounted in the idler pulley arm.
(Item J, Figure 7.)
11
MAINTENANCE
Figure 6
d. Slip the long blade drive belt off of the pulleys.
e. (48" ONLY) Loosen the idler pull rod which holds the
idler pulley tight against the short blade drive belt.
(Item K, Figure 8.)
f. Remove the short blade drive belt from the pulleys.
g. Place a new short blade drive belt back on the
pulleys and tighten the idler pull rod to hold the idler
pulley tight against the belt.
h. Place a new long blade drive belt through the belt
guide and loop it around the engine pulley and then
around the two deck pulleys. The belt’s back side
should ride on the idler pulley.
i. Replace the cap screw, lock wash er and nut in the
idler pulley arm.
j. The idler pulleys should be adjusted so that when
the blade clutch is engaged, a ten-pound pull
between two pulleys deflects either belt about 1/2".
Do not overtighten these belts. The blade clutch
should engage with only moderate force.
k. Replace the deck cover.
4. TO CHANGE THE TRANSMISSION DRIVE BELT:
(See Figure 9)
a. Make sure the blade clutch is disengaged.
b. Working under the engine deck, take the long blade
drive belt off of the engine pulley.
c. Loosen the locknut holding the transmission drive
belt idler pulley in place and slide the pulley away
from the transmission drive belt.
d. Remove the old belt and mount a new belt on the
pulleys.
e. Slide the idler pulley back onto the belt and tighten
the locknut holding it in place. The idler pulley should
be adjusted so that a five-pound pull on the belt
between the engine pulley and the transmission
pulley deflects the belt about 3/16".
f. Replace the long blade drive belt on the engine
pulley.
Figure 7
Figure 8
Figure 9
5. TO CHANGE EITHER TRACTION DRIVE BELT:
a. Remove the hex nuts which hold the belt guard in
place. Remove the belt guard.
b. Place the neutral latch lever in the neutral lock
position.
c. Remove the hairpin cotters from the two swivel j oints
which are inserted through the idler bracket and
remove the swivel joints from the idler bracket.
12
MAINTENANCE
Figure 10
d. Lift up on the idler bracket with one hand while
removing the belt from the jackshaft pulley with the
other hand. (See Figure 10.)
e. Prop up the side of the mower and slip the belt over
the drive wheel.
f. Slip the new traction drive belt over the drive wheel
and loop it over the jackshaft pulley while lifting up
on the idler bracket.
g. Insert the swivel joints in the holes in the idler
bracket and replace the hairpin cotters.
h. Replace the belt guard and the two nuts.
6. TO CHANGE A SPINDLE ASSEMBLY:
a. Make sure the blade clutch is disengaged.
b. Remove the deck cover.
c. Remove the blade. (See paragra ph 1. To Change a
Blade.)
d. Remove the blade drive belts. (See paragraph 3. To
Change the Blade Drive Belts.)
e. Remove the two bolts which hold the pulley bushing
tight in the spindle pulley and thread the bolts into
the other two holes in the bushing.
f. Alternately turn each bolt 1/2 turn clockwise until the
bolts force the pulley off of the bushing.
g. Remove the bushing by tapping a large screw driver
into the slot in the side of the bushing.
h. Remove the key and the pulley.
i. Tip the mower back and block up the front of the
deck.
j. Remove the four bolts and locknuts holding the
spindle assembly to the deck.
k. Remove the spindle assembly.
7. TO ADJUST THE LITE-TOUCH (MANUALLY)
a.rThree holes in the belt guard allow you to
reposition the hex cap screw to adjust the brake
lever. The top hole (lite tension), the middle hole
(medium tension) and the lower hole (hard
tension). The unit is shipped with the hex screw in
the top hole. SEE THE FIGURE BELOW FOR
REFERENCE. To adjust the bolt do the following:
b.With a spring puller, pull the spring and detach it
from the hex cap screw.
c.Remove the lock nut from the lite touch hole in
the belt guard.
d.Loosen (but do not remove) the remaining two
nuts on the belt guard.
e.Pull the belt guard away from the unit. This will
give clearance to remove the bolt. Note: If you are
having difficulty removing the bolt, continue to
loosen the two nuts on the belt guard (BUT DO
NOT REMOVE). Remove the bolt and nut.
f.Reposition the bolt and nut into the middle or
lower hole and retighten all three nuts.
g.Using a spring puller, reattach the spring to the
hex cap screw.
Lite
Medium
Hard
Belt Guard
Loosen remaining two nuts (DO NOT REMOVE)
Figure 11
13
MAINTENANCE
SUGGESTED MOWER REPLACEMENT PARTS
PART # Description 32" 36" 48"
00021871 Rotary Blade, 16-1/2" 2 3
00050125 Rotary Blade, 18" 2
01007591 Blade Bolt 2 2 3
00011807 Blade Nut 2 2 3
00021924 Blade Spacer 10 10 15
01007578 Drive Belt 1
00050441 Drive Belt 1
00021947 Long Drive Belt 1
00050480 Short Drive Belt 1
01000194 Transmission Drive Belt 1 1 1
01000151 Traction Drive Belt 2 2 2
SUGGESTED ENGINE REPLACEMENT PARTS
Air Filter
Engine Oil Filter Air Filter
01007290 Kawasaki, 13.0 HP KM-49065-2078 KM-11013-7017 KM-11013-7016 KM-92070-7003
01009794 Kaw. Kai., 13.0 HP KM-49065-2078 KM-11013-7031 KM-11013-7025 KM-92070-7003
01007291 Kawasaki, 15.0 HP KM-49065-2078 KM-11013-7017 KM-11013-7016 KM-92070-7003
01009795 Kaw. Kai., 15.0 HP KM-49065-2078 KM-11013-7031 KM-11013-7025 KM-92070-7003
Foam Wrap Spark Plug
14
Supplement Parking Instructions
All Gear Walk-Behind Mowers
Instructions
1. When parking mower on a hill,
position mower perpendicular to
the slope. DO NOT PARK
MOWER FACING DOWN
SLOPE.
2. Turn off the engine.
3. Place the Transmission Shift
Lever in First Gear.
4. Disengage the Neutral Latch
Levers.
5. Place chocks on both sides of the
traction drive wheels. Alternate
the chocks by placing one chock
on the rear side of the wheel and
another chock on the front side of
the opposite wheel.
INCORRECT
CORRECT
15
MAINTENANCE RECORD
DATE WORK PERFORMED DATE WORK PERFORMED
16
MAINTENANCE RECORD
DATE WORK PERFORMED DATE WORK PERFORMED
17
MAINTENANCE RECORD
DATE WORK PERFORMED DATE WORK PERFORMED
18
19
19
MANUFACTURER’S LIMITED WARRANTY - TURF EQUIPMENT
This warranty is specifi c t o the product manual to which it is atta ched.
For a complete list of products and warranties con ta ct your authorized Cub Cadet Commercial dealer.
Proper maintenance of the purchased Cub Cadet Commercial equipment is the owner’ s responsibility.
instructions in your owner’s manual for correct lubricants and maintenance schedule. Your Cub Cadet Commercial dealer
carries a complete line of quality l ubricants and filters for your equipment’s engine, transmission, chassis, and attachments.
What is Covered By This Warranty?
Cub Cadet Commercial equipment to the original owner for the following time periods:
A) First (1
associated
B) Second (2
covered under the terms of this limited warranty.
•
•
•
Accordingly, Cub Cadet Commercial will replace or repair any part or par ts wi thout charge through your authorized Cub
Cadet Commercial dealer subject to the above time and coverage limitations. Upon completion of your purchase, the
Serial Number/s of the unit will be registered with the Cub Cadet. This will initiate and validate your limited warranty and
the applicable Warranty Period.
st
) Year of Original Ownership:
Labor
nd
Limited Battery Warranty: 90-day free battery replacement in the case of defects in materials and/or
workmanship, thereafter prorated for the period from the fourth (4th) through the twelfth (12
ownership.
“No-Fault W arranty”: Cov ers the “No-F ault” to o wner replacement of damaged belts, tires, seats, and grass bags
(cutting blades are not included) for a period of One (1) month or One-Hundred (100) ho urs, whichever comes
first.
Limited Engine Warranty: Parts and Labor for defects in materials and/or workmanship are covered for the first
two (2) years of original equipment ownership. Refer to the Engine Manual for specific limitations and restrictions.
of the particular repair are covered under the terms of this limited warranty
) and Third (3rd) Year of Original Ownership:
This limited warranty covers any defect in materials and/or workmanship in your
Both Parts
found defective in materials and /or workmanship
Parts
found defective in materials and /or workmanship are
Follow the
and
th
) month of
the
What is Not Covered By this Warranty?
as lubricants, filters (oil, fuel, air and hydraulic), cleaning, tune-ups, brake or clutch inspections, adjustments made as part
of normal maintenance, blades, blade sharpening, equipment setup, and normal wear items; ( b ) incidental cost such as
transporting equipment to and from the dealer, telephone charges or renting product temporarily to r eplace a warranted
product; ( c ) damage caused by use of the equipment for purposes other than those for which it was designed; ( d )
damage caused by accident or Disasters such as fire, flood, wind and lighting: ( e ) damage ca used by unauthorized
attachments, modifications, alterations, improper servicing or maintenance, improper storage; or ( f ) any other abuse or
misuse of the equipment.
Exclusive Warranty.
oral or implied. Any and all implied warranties of merchantability, fitness for par ticular purpose, course of delaying or
usage of trade are hereby expressly disclaimed and excluded
of incidental or consequential damages, so the above exclusion or limitation may not apply to y ou.)
Limitation of Remedies.
shall Cub Cadet Commercial be liable for any loss or damage, direct or indirect, special, incidental or consequential
arising out of the use of or inability to use this equipment including but not limited to any claim for loss of profits, loss of
profits, loss of savings or revenue, loss of use of the equipment or any associated equipment, facilities or continued
service, downtime, the claims of costs of third parties in cluding customers and injury to proper ty. Some states do not
allow limitations on how long an implied warranty lasts of the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusion may not apply to you.
and you may also have other rights that vary from state to state.
Future Changes
its equipment or any component part or parts thereof without incurring the obligations to make such changes or modifications in present equipment.
How to Obtain Service:
obtain service or replacement parts.
The foregoing warranty is exclusive and in lieu of all other warranties or remedies, whether written,
Under no circumstances, except to the extent such exclusions are prohibited by applicable law,
: Cub Cadet Commercial reserves the right to reserve, change or modify the construction and design of
Contact the authorized Cub Cadet Commercial dealer at the point of original retail purchase to
Cub Cadet Commercial does not warrant ( a ) routine maintenance items such
. (Some states do not allow the exclusion or limitation
This warranty gives you specific legal rights,
Products purchased outside the USA are not covered by this warranty
Cub Cadet LLC
P.O. Box 361131
Cleveland, Ohio 44136-0019
1-877-282-8684
Form No. 01009882 Rev. 06-0 1/16/2006
Loading...
