Cub Cadet G 1236 User Manual
G1236
Walk-Behind Commercial
Rotary Mowers
Professional Turf Equipment
ES
OPERATOR’S AND SERVICE MANUAL
TABLE OF CONTENTS
Foreword 3
Safety Instructions 4
Slope Guide 7
Safety Labels 8
Product Specification 10
Assembly 11
Operation 12
Maintenance 17
Service and Adjustments 21
Off-Season Storage 24
Accessories and Attachments 24
Troubleshooting 25
MODEL NUMBER
Model Number.........................................................
Serial Number...........................................................
Date of Purchase......................................................
Record the model number, serial number and date of
purchase above.
2
FOREWORD
The Cub Cadet Commercial, Walk-Behind, Rotary Mowers have been developed
for use by professional landscapers, commercial lawn service companies, professional
turf managers and golf course superintendents. The machines incorporate many safety
features that should be studied by all operators and maintenance personnel before
use. The list of safety precautions should receive particular attention. This manual
presents the operating and maintenance instructions necessary to keep your Cub
Cadet Commercial mower at peak efficiency. If properly operated and maintained, your
Cub Cadet Commercial mower will give dependable and trouble-free service.
Although hazard control and accident prevention partially are dependent upon the
design and configuration of the equipment, these factors are also dependent upon the
awareness, concern, prudence, and proper training of the personnel involved in the
operation, transport, maintenance and storage of the equipment.
CAUTION: THE Cub Cadet Commercial, Walk-Behind, Rotary Mowers
should only be operated and maintained by thoroughly trained individuals.
The machines could cause serious injury to anyone who misuses them or
does not understand their operation. All operators and maintenance
personnel are urged to read this entire manual for their personal safety.
WARNING-For the State of California
• The engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals
known to the State of California to cause cancer, birth defects or other reproductive harm.
• This unit is equipped with an internal combustion engine and should not be used on or near any unimproved
forest-covered, brush-covered, or grass-covered land unless the engine’s exhaust system is equipped with a
spark arrester meeting applicable local or state laws (if any). If a spark arrester is used, it should be maintained in effective working order by the operator.
• In the State of California, the above is required by law (Section 4442 of the California Public Resources
Code). Other States may have similar laws. Federal laws apply to federal lands. A spark arrester muffler
may be available.
WARNING-For the State of California
• A person shall not sell, offer for sale, lease, or rent to a person any equipment that is powered by an internal
combustion engine subject to Section 4442 or 4443, and not subject to Section 13005 of Health and Safety
Code, unless that equipment has a permanent writing label attached that is in plain view to the operator that
states, ‘WARNING-Operation of This Equipment May Create Sparks That Can Start Fires Around Dry
Vegetation. A Spark Arrestor May be Required. The Operator Should Contact Local Fire Agencies For
Laws or Regulations Relating to Fire Prevention Requirements.’
NOTE: The engine manufacturer is responsible for all engine-related issues with
regards to performance, power-rating, specifications, warranty and
service. Please refer to the engine manufacturer’s owner’s/operator’s
manual, packed separately with your unit, for more information.
This product may be covered by one or more of the following patents:
D415,503; 5,928,097; 6,012,274; 5,355,665; 6,226,966; 6,266,949
3
SAFETY
WARNING: This symbol points out important safety instructions which, if not followed, could
endanger the personal safety and/or property of yourself and others. Read and follow all
instructions in this manual before attempting to operate this machine. Failure to comply with these
instructions may result in personal injury. When you see this symbol - heed its warning.
DANGER: This machine was built to be operated according to the rules for safe operation in this
manual. As with any type of power equipment, carelessness or error on the part of the operator can
result in serious injury. This machine is capable of amputating hands and feet and throwing objects.
Failure to observe the following safety instructions could result in serious injury or death.
GENERAL
1. Read this Operator’s Manual completely before
starting the mower. Study the controls and learn
the proper sequence of operation. Retain
Operator’s Manual in a safe place for future
reference.
IMPORTANT: If the operator cannot read English or
Spanish, the owner is responsible for explaining the
information in this manual.
2. Do not allow anyone to operate or maintain this
machine who has not read the manual. Never
permit children under the age of 16 to operate
this machine.
3. Always have your feet and hands clear of the
cutter deck when starting the engine.
4. Do not remove any shields, guards, decals or
safety devices. If a shield, guard, decal or safety
device is damaged or does not function, repair or
replace it before operating the mower.
5. Always wear safety glasses, long pants and
safety shoes when operating or maintaining this
mower. Do not wear loose-fitting clothing, or have
loose long hair or jewelry.
6. Never run the engine indoors without adequate
ventilation. Exhaust fumes are deadly.
7. To avoid serious burns, do not touch the engine
or muffler while the engine is running or until it
has cooled for at least 30 minutes after it has
been shut off.
8. Do not allow anyone to ride on this mower. No
passengers.
9. Do not operate this mower under the influence of
alcohol and or drugs.
10. Do not operate or store the machine or fuel
container inside where there is an open flame,
spark or pilot light such as a water heater,
furnace, clothes dryer, etc.
11. The owner is responsible for training the users,
and is responsible for accidents or injuries
occuring to themselves or others.
OPERATION
WARNING: Never mow in fifth gear
(transport speed).
1. Keep adults, children and pets away from the
area to be mowed. (75 feet reccommended)
2. Never use this mower without the discharge
chute installed and set in the down position
(except when material collection system is used.)
3. Mow only in daylight or proper artificial light.
4. Always remove debris and other objects from the
area to be mowed.
5. Watch for holes, sprinkler heads and other
hidden hazards.
6. Reduce speed when making sharp turns.
7. Always have proper footing on slopes and hill
sides and never operate when conditions are
slippery.
8. Always keep both hands on the handles when
mowing. Always walk, never run.
9. Never engage the blade clutch when the engine
is running unless you are on grass that you intend
to mow.
10. Be careful when crossing gravel paths or roadways. Always disengage the blade clutch and
wait until the blades stop rotating.
11. Never leave the mower unattended without
disengaging the blade clutch, shifting the
transmission into neutral, placing the neutral latch
levers in the neutral lock position, shutting off the
engine, removing the key from the ignition switch
and closing the fuel shutoff valve.
12. Always park the mower and start the engine on a
level surface with the transmission in neutral, the
blade clutch disengaged and the neutral latch
levers in the neutral lock position.
13. Shut off the engine and wait for the blades to stop
rotating before removing the grass catcher.
14. If you hit a solid object while mowing, disengage
the blade clutch, shift the transmission into
neutral, place the neutral latch levers in the
neutral lock position and stop the engine.
Disconnect the spark plug wire(s) and inspect for
damage. Repair any damage and make sure the
4
blades are in good condition and the blade bolts are
tight before restarting the engine.
15. Do not mow excessively steep slopes (No more
than 15 degrees or a 26.8% grade). Mow across
the slope.
WARNING: Do not mow up and down
the slope. You could slip and slide into the
mower, or the mower could loose traction
and steering control.
16. Never raise the mower deck while the blades are
rotating.
17. Never walk or stand on the discharge side of a
mower with the engine running. Disengage the
blade clutch if another person approaches while
you are operating a mower.
18. Always disconnect the spark plug wire to prevent
the engine from accidentally starting before
performing any maintenance on this mower.
19. Keep the mower and especially the engine clean
and free of grease, grass and leaves to reduce the
chance of fire and to permit proper cooling.
20. The operator presence control levers located at
each handle are designed for your safety. Do not
try to defeat their operation. If the blade clutch is
engaged or the transmission is in gear, releasing
both handles will shut off the mower’s engine.
MAINTENANCE AND STORAGE
WARNING: Never let children or
untrained people operate or service this
mower.
Observe proper disposal laws and regulations for gas, oil, etc. to protect the environment.
RELATED TO FUEL
1. Fuel is highly flammable and its vapors can explode
if ignited. Please respect it.
2. Do not smoke or permit others to smoke while handling fuel.
3. Always use approved containers for fuel and fill
slowly to decrease the chance of static electricity
buildup and spillage.
4. Store fuel in well ventilated and unoccupied buildings away from sparks and flames.
5. When dispensing gasoline into approved containers, place the container on the ground when refueling to avoid a possible static electricity ignition of
fuel vapors.
6. Do not fill containers while it is inside a vehicle,
trunk, the bed of a pickup or floor of a trailer.
7. Always shut off the engine and permit it to cool
before removing the fuel tank cap.
8. Always fill the fuel tank outdoors.
9. If the fuel container spout will not fit inside the fuel
tank opening, use a funnel.
10. When filling the fuel tank, stop when the fuel reaches
one inch from the top. This space is necessary for tank
expansion.
11. Wipe up any spilled fuel.
12. Do not operate or store the machine or fuel
container inside where there is an open flame,
spark or pilot light such as a water heater, furnace,
clothes dryer, etc.
Do not overfill
.
1. Never tamper with safety devices. Check their
proper operation regularly.
2. Check bolts and screws for proper tightness at
frequent intervals to keep the machine in safe
working condition. Also, visually inspect machine
for any damage and repair, if needed.
3. Before cleaning, repairing, or inspecting, stop the
engine and make certain all moving parts have
stopped. Disconnect the spark plug wire and
ground it against the engine to prevent unintended
starting.
4. Do not change the engine governor settings or
overspeed the engine. The governor controls the
maximum safe operating speed of the engine.
5. Maintain or replace safety and instruction labels, as
necessary.
6. Follow this manual for safe loading, unloading,
transporting, and storage of this machine. (See
page 16 and page 24)
7. Never store the machine or fuel container inside
where there is an open flame, spark or pilot light
such as a water heater, furnace, clothes dryer, etc.
8. Always refer to the operator’s manual for proper
instructions on off-season storage. (See page 24)
9. If the fuel tank has to be drained, do this outdoors.
SLOPE OPERATION
DO:
• Mow across slopes, and exercise caution when
turning or changing direction.
• Watch for holes, ruts or bumps and hidden objects.
• Be sure of your footing. A slip could cause personal
injury.
• Check the area thoroughly before mowing.
• Slow down and use extra care.
DO NOT:
• Do not mow up and down slopes.
• Do not mow near drop offs, ditches, embankments,
etc. The mower could suddenly turn over if a wheel is
over the edge of a cliff or ditch, or if an edge caves in.
• Do not mow on wet or slippery grass. Reduced
traction could cause sliding.
• Do not mow on slopes greeater than 15 degrees as
shown on the slope gauge.
5
FIRST TIME OPERATORS
• Start off in a flat, open, area.
• Keep bystanders away.
• Set the throttle to low speed.
• Practice maneuvering (forward, turn left, turn right,
reverse), without the mower deck engaged.
6
SLOPE GUIDE
USE THIS PAGE AS A GUIDE TO DETERMINE SLOPES WHERE YOU MAY NOT OPERATE SAFELY.
Operate ZERO-TURN mowers across the face of slopes, never up and down slopes.
Operate WALK-BEHIND mowers across the face of slopes, never up and down slopes.
Do not mow on inclines with a slope in excess of 15 degrees (a rise of approximately 2-1/2 feet every 10 feet). A riding mower
could overturn and cause serious injury. If operating a walk-behind mower on such a slope, it is extremely difficult to maintain
your footing and you could slip, resulting in serious injury.
WARNING
F
O
L
D
ON
D
O
T
T
E
S
E
R
P
E
R
E
D
L
I
N
E
,
A CORNER OF A BUILDING
SIGHT AND HOLD THIS LEVEL WITH A VERTICAL TREE
A POWER POLE
15°
N
T
I
N
G
5
°
S
L
OP
A
1
OR A FENCE POST
E
7
WARNING
OPEN BELT DRIVE
STOP ENGINE BEFORE
REACHING UNDERNEATH
SAFETY LABELS
Part Number: 01001035
WARNING
Part Number: 01001036
Part Number: 777I22930
Part Number: 777I22931
- TURN OFF ENGINE AND ALLOW
TO COOL BEFORE REFUELING.
- DO NOT SMOKE NEAR FUEL.
Part Number: 777S30116
WARNING
SHIELD MISSING
DO NOT OPERATE
Part Number: 00030635
8
Part Number: 01006668
Part Number: 01006132
Part Number: 777S30503
Part Number: 01002166
Part Number: 777D12837
Part Number: 777I22929
9
Loading...
