Concord Camera PZ3300, PZ3300 AFD Instruction Manual

5S1085-00
3007111B

35mm Fully Automatic Camera

With LCD

Instruction Manual

Thanks for buying this camera. Before using the camera, please read this
instruction manual thoroughly to ensure correct use.

This camera satisfies the requirements of the EU (European Union)
regarding safety, public and consumer protection. This product is in
conformity with the standards of BS EN 61000-6-3:2001: CISPR22: 1998
Class B. BS EN 61000-6-1: 2001:IEC 61000-4-2: 1995, IEC 61000-4-3:1997.

1

Introduction

24

Red-eye reduction
DX setting
Self-timer
Night scene mode
Date Imprinting
Film winding
Film rewinding

Power Source
Dimension
Weight

High light LED
ISO 50 - ISO 3200
10 seconds delay
Yes
Built-in type
Automatic winding
(1) Automatic rewinding
(2) Power mid-roll rewinding
3V CR123 lithium battery x 1 pc
116mm (W) x 66.7mm (H) x 44.2mm (D)
approx. 197g

Specifications and designs are subject to change without notice.

23

Specifications

Type
Film format
Focusing
Focusing range
Lens

Exposure control
Viewfinder
Shutter speed
Flash

135mm 3.3X zoom compact camera with LCD display
24 x 36mm
Active infrared auto focus system
Auto mode: 0.9m~infinity
38mm (F6.3) to 125mm (F12.7) 5 element 5 groups zoom lens
"Step Zoom, 3 retractable barrel sections"
Programmed AE shutter
Real image big zoom finder with AF mark
1/2~ 1/500 second
Four-way Flash (Auto, on/off, red -eye reduction) Recycle
time arround 5 seconds
Flash range W:0.9-3m T:0.9-2m GNO W:11.5 T:15

2

o Contents P2
o Precaution / Care and Storage P3
o Nomenclature (Description of parts) P4~8
o Operations:

Attaching the strap / Loading the batteries P9
Power On/Off / Battery check P10
Date / Time adjustment P11

o Taking pictures

©Loading the film P12
©Auto Focus P14

Mode selection---------Auto Flash mode / Flash on / Flash off P16

Landscape / Night scene P17
Red-eye Reduction / Self-timer P18
Remote Control (Optional) P19

©Auto rewinding / Mid-Roll Rewinding P20
©Troubleshooting P21~22
©Specifications P23~24

Contents

3

Precaution / Care and Storage

In order to get the best performance from this sophisticated designed
camera and keep safe-use of it, the following needs to be specially noticed:

1. The camera is not water resistant, and should not be used outdoors if it's raining or
snowing.

2. Protect the camera from dust, moisture, sudden impact, and excessive heat.

3. Don't attempt to disassemble the camera yourself, since there is high-voltage
circuitry inside.

4. Please use a lintless cloth to clean gently in one direction the surface of lens when
cleaning. Do not use chemically treated tissues intended for cleaning eyeglasses.

5. The battery may be shorted when exposed to high temperature, or disposed of in
fire.

6. Remove the battery when the camera is not used in a long time.

7. Keep batteries away from children.

8. Keep the auto-focus windows clean to ensure accurate focusing. If they get dirty,
wipe them clean with soft cloth.

9. Pad the button of the camera with foam-rubber when traveling in a car, ship, or
airplane. Violent vibration could cause damage to the camera.

10.Make sure the tripod screw fits the camera before installing.

5

AF Lamp

Finder eyepiece

Spool

Film Tip top

Tripod bush

Film cartridge
chamber

Back cover

Battery cover

Battery switch

strap eyelet

22

Problem

Self-timer mode does not
work
The picture is blurred

Possible cause

.If the camera is now on the

Date setting mode

.You did not aim the

autofocus spot correctly.
.The lens glass is not clean
.You jiggled the camera

when you pressed the

shutter release button.
.You did not use a tripod

when shooting in the night-

scene mode.

Solution

.cancel the date setting

mode

.Make sure that the

autofocus spot is on your
subjects, or use the
autofocus lock to take the

picture.
.Clean the lens
.Hold the camera still with

both hands and press the

shutter release button

gently.
.use a tripod.

20

Auto film re-wind

Automatic start at end of film, automatically stop upon completion of rewinding. The
power will shut off automatically

1. After the end of the film has been reached, the film will automatically rewind.

2. When the film starts to rewind, the frame counter starts to counter down and "E" will
display on the LCD panel when the film rewinding is completed.

3. Open the back door to unload the film.

Mid-roll rewind

The film may be rewound before the roll of the film is finished. Press the " " button
to mid-roll rewind the film if you don't want to continue taking the remaining film.
