Table of Contents |
|
|
|
Important Information .......................................................................................... |
2 |
|
Precautions ............................................................................................................ |
3 |
1. |
Product overview .................................................................................................. |
4 |
|
Important battery information .............................................................................. |
5 |
|
Getting started ...................................................................................................... |
6 |
|
Minimum system requirement .............................................................................. |
6 |
|
Eye-Q Easy package contents................................................................................ |
6 |
|
Learning the LCD display ...................................................................................... |
7 |
|
Warning Signal ...................................................................................................... |
7 |
|
Loading the batteries ............................................................................................ |
8 |
|
Turning the camera on/off .................................................................................... |
9 |
|
The battery level.................................................................................................... |
9 |
2. |
Taking Pictures .................................................................................................... |
10 |
|
Setting the Photo Quality and Changing Modes ................................................ |
10 |
|
Taking a picture with flash.................................................................................... |
11 |
|
Taking a movie clip .............................................................................................. |
12 |
|
Using the Self-timer ............................................................................................ |
12 |
|
Deleting pictures and video ................................................................................ |
13 |
3. |
Installing the drivers and software .................................................................... |
14 |
|
Installing the software ........................................................................................ |
14 |
|
Installing the Camera driver – Concord Eye-Q Easy ............................................ |
14 |
|
Uploading your pictures to your PC .................................................................... |
15 |
|
Working with your pictures.................................................................................. |
15 |
|
Uploading your video clips to your PC .............................................................. |
16 |
|
Using the camera as a web cam ........................................................................ |
16 |
|
Uninstalling the software on a Windows PC ...................................................... |
17 |
|
Uninstalling the driver on a Windows PC............................................................ |
17 |
4. |
Cleaning and maintenance .................................................................................. |
18 |
|
Places to Avoid .................................................................................................... |
18 |
|
Storing the camera .............................................................................................. |
19 |
|
Cleaning your Camera .......................................................................................... |
19 |
|
When traveling overseas...................................................................................... |
19 |
5. |
Troubleshooting .................................................................................................. |
20 |
6. |
Getting Help ........................................................................................................ |
22 |
7. |
Warranty Information .......................................................................................... |
23 |
1
IMPORTANT INFORMATION
FCC Statement
This device complies with 15 the FCC Rules. Operation is subject to the following two conditions: (i) This device may not cause harmful interference, and (ii) this device must accept any interference received, including interference that may cause undesired operation.
CAUTION
This equipment has been tested and found to comply with limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. The equipment generates, use, and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures :
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
You are cautioned that any changes or modifications not expressly approved in this manual could void your warranty.
For customers in Canada:
CAUTION
This class B digital apparatus complies with Canadian ICES-003.
2
PRECAUTIONS
Test Shots
Always take a test photograph to check that the camera is functioning normally. The liability for any incidental losses ( such as the cost of photography or the loss of income from photography ) incurred as a result of fault with this product cannot be accepted.
Notes on Copyright
Images recorded using your digital camera system cannot be used in ways that infringe copyright laws without the consent of the owner unless intended only for personal use. Note that some restrictions apply to photographing stage performances, entertainment and exhibits, even when intended purely for personal use. Users are also asked to note that the transfer of memory cards containing images or data protected under copyright laws is only permissible within the restrictions imposed by those copyright laws.
Liquid Crystal
If the LCD monitor or LCD panel is damaged, take particular care with the liquid crystal in the monitor or panel. If any of the following situations arise, take the action indicated.
•If the liquid crystal comes in contact with your skin wipe the area with a cloth and then thoroughly wash with water and soap.
•If the liquid crystal gets into your eyes flush the eye with clean water for at least 15 minutes and then seek medical assistance.
•If liquid crystal is swallowed flush your mouth thoroughly with water. Drink large quantities of water and induce vomiting. Seek medical assistance.
Notes on Electrical Interference
If the camera is used in hospital or aircrafts, please note that it may cause interference with other equipment in the hospital or aircraft. For details, please check with the applicable regulation in that area.
3
1. Product overview
FRONT
1 2 3
1. Shutter button
2. Flash unit
3. Viewfinder
4. Lens
5. USB connector port
5
4
1 2
BACK
1. Green LED (On/Ready)
2.Red LED (Low light/Busy)
3.Status LCD
4.Flash On/Off button
5.Delete button
6.Power/Select button
7.Tripod mount
8.Battery door
3 |
7 |
8 |
4
5
6
4
Important battery information
The Eye-Q Easy camera uses a type of memory that continually draws power to retain the pictures in the camera’s internal memory even if the camera is powered off. If the battery power is depleted and you have not transferred your images to the computer, you will lose them. It is strongly recommended that you transfer your images to the computer promptly and then remove the batteries to extend their life.
If you have not transferred your pictures to your computer and you receive a battery low warning, connect your camera to the computer via USB. While connected to the PC you can change the batteries and transfer the images.
Always use fresh batteries to optimize the performance of your camera.
5
Getting started
Congratulations on your purchase of the Concord Eye-Q Easy digital camera. This camera features 8 MB of internal memory allowing you to store still images or short 30 second movie clips in the camera. Please read this manual before operating the camera to become more familiar with the features of this versatile digital camera.
Minimum system requirement
•Windows 98 Second Edition, 2000 Professional, ME or XP
•Pentium 233MHz or higher
•32MB of Ram or higher
•USB port
•200 MB of free hard disk space
Eye-Q Easy package contents
1.Eye-Q Easy camera
2.2 AA Alkaline batteries
3.USB cable
4.Wrist strap
5.User’s guide (also on the CD)
6.Software CD
6
Learning the LCD display
By default, the 3 digit LCD screen displays the number of images taken. It is also used in conjunction with the Power / Select button and Shutter button to access and display the Eye-Q Easy settings.
Normal |
|
Video |
|
compression |
Self-timer mode |
||
mode |
|||
mode |
|
||
|
|
||
High |
No compression |
|
|
compression |
|
||
mode |
|
||
mode |
|
||
|
|
Warning Signal
Low battery warning
When your camera has full power, the Battery indicator on the
LCD display will be fully illuminated. When the power is low, the empty battery icon will flash with 5 beep sounds and then the
camera will shut down automatically. This indicates that the
batteries are weak and need to be replaced. The pictures will remain in the camera’s memory for approximately 2 days after the camera automatically powers off. Please transfer your images to the computer promptly and replace the batteries before taking more pictures.
Full memory warning
When your camera’s memory is full, the image counter mode icon (still picture or video) on the LCD will flash together. If only the image counter flashes, the memory is almost full.
Note: Be sure to upload all images to your computer before changing the batteries. All images will be lost if there is insufficient battery power inside the camera.
Note: The counter in each mode will show the number of pictures captured. To see the number of remaining pictures, hold the power button down for 1 second.
7
