QuickSpecs
Overview
At A Glance
•
The Compaq iPAQ Desktop is a sleek,
affordable, easy to deploy and manage
business PC—ideal for mainstream
computing, Internet / intranet access,
and Windows 2000 deployments.
•
There are two iPAQ™ Desktop
versions. The Compaq iPAQ Desktop
with Legacy Ports has traditional
legacy ports (parallel, s erial, and PS/2)
for existing peripherals, running
Windows 2000, 98, or NT4. The
Compaq iPAQ Desktop Legacy-Free
features Win dows 2000 or ME a nd six
USB ports for the new wave of USB
peripherals.
•
Order iPAQ directly from Compaq at
www.compaq.com/products/desktops
•
iPAQ Desktops deliver ease of
deployment, support, and usability by
eliminating ISA/PCI slots and focusing
on USB with Windows 2000 or
Windows ME.
•
Compaq Intelligent Manageability
provides solutions for remote cloning,
deployment , installatio n, configuration,
and backup/restore; single-click
scheduling for all management tasks;
and powerful brokering agents to
handle requests automatically and
communicate status to the
management console (Intelligent
Manageability is not supported under
Windows ME).
•
Innovative Compaq MultiBay
technology enables hot-s wapping of
slimline CD-ROM, DVD-ROM,
SuperDisk LS-120 drive, Zip 250 drive,
and hard drive without the need to
reboot. The breakthrough i ndustrial
design features a sleek, s mall footprint,
leaving the user more works pace.
•
Protected by Compaq Services,
including a limit ed on e-y e ar warranty
for parts and o nsite labor — Certain
restrict ions and exclusi ons apply.
Consult the Compaq Customer
Support Center for details.
Compaq iPAQ Desktop
DA-10832 North Americ a — Version 8 — September 14, 2001
1
QuickSpecs
Favorable Configurations
Compaq iPAQ Desktop
Models
iPAQ Desktop Legacy Free
iPAQ/C800/20e/m/64
iPAQ/C800/20e/2/64
iPAQ/P1000/20e/2/128
iPAQ Desktop with Legacy Ports
iPAQL/C800/20e/8/64
iPAQL/C800/20e/8/128
iPAQL/C800/20e/6/128*
iPAQL/P1000/20e/6/128*
Note: * End-user must make a one-time selection between Windows 2000 and Windows NT Workstation. If end-user desires rejected product after
selection is made, end-user must purchase and acquire rejected product(s) separately.
PN
470018-137
470018-140
470018-156
470018-160
470018-162
470018-163
470018-164
DA-10832 North Americ a — Version 8 — September 14, 2001
2
QuickSpecs
Standard Features
Processor
Network Con troller Integrated Intel PRO/100VM Network Connection
Cache Memor y
One of the following:
Memory
One of the following:
Standard
Storage Hard Drive Smart II Ultra ATA 100 – 20 GB
Audio
Graphics Integrated Intel 3D Direct AGP Graphics
Interfaces USB 6
VGA 1
Parallel 1 (iPAQ Desktop with Legacy Ports models only)
Serial 1 (iPAQ Desktop with Legacy Ports models only)
PS/2 Easy Access Keyboard 1 (iPAQ Desktop with Legacy Ports models only)
PS/2 Easy Access Mouse 1 (iPAQ Desktop with Legacy Ports models only)
USB Easy Access Keyboard 1 (Legacy Free models only)
USB Easy Access Mouse 1 (Legacy Free models only)
RJ-45 (LAN) 1
Microphone 1
Headphone 1
Line In 1
Line-out 1
Power Conservation ‘Energy
Saver’
Suspend to RAM
APM Support
Screen Blanking
Hard Disk ‘Idle’ Mode
Clock Slow Down
System Idle Mode
Cache Memory Power-Down
CD-ROM and Audio Board Support
Power-Down
Computer Setup Utility
Boot Support
Pentium III 1.0 GHz with 133-MHz FSB
Intel
Intel Celeron™ 800 MHz with 100MHz FSB
256K Advanced Transfer Cache (Pentium III models)
128K Integrated L2 Cache (Celeron models)
Standard
Maximum
Maximum
Integrated Intel Audio with Premium Internal Speaker
4MB video cache standard on Pentium III models, optional on Celeron models
Energy Star Compliant
Instantly Available PC Compliant
Diagnostics for Windows – preloaded
Local MultiBay and USB Diskette Boot
Network Service Boot (PXE) – with appropriate remote application
128-MB SDRAM (PC 133)
512-MB SDRAM
64-MB SDRAM (PC 133)
512-MB SDRAM
Compaq iPAQ Desktop
DA-10832 North Americ a — Version 8 — September 14, 2001
3
QuickSpecs
Standard Features
Compaq iPAQ Desktop
Initial Configuration and
Deployment
Asset Contro l
Standard Security Features
Software Updating and
Management
Fault Noti fication and
Recovery
Other Features
Power Supply
One of the following required:
Remote System Installation
Replicated Setup
Compaq OS Restore CD
Asset Tag
DIMM Serial Presence Detect
Hard drive serial number, model &
manufacturer
Monitor serial number, model &
manufacturer
System serial number, model &
manufacturer
ROM revision levels
Systemboard revision level
Compaq Fingerprint Identification
DMI BIOS
Memory Change Alert
Ownership Tag
Smart Cover Lock
Kensington Lock Support
Compaq Lock Bracket Support
Smart Cover Sensor
Boot Integrity Services (BIS) – Secure PXE
Master Boot Record Security
Power-On Password
Serial, Parallel & USB Port Control
Removable Media Write / Boot Control – with supported devices
Setup Password
Remote Security Management - supported in BIOS
Remote ROM Flash – supported in BIOS
Remote Wakeup / Remote Shutdown – Wake-on-LAN supported via NIC
ROM Based Setup
DMI BIOS
Hard Drives - Power on Self Test (POST) only
Surge Tolerant Power Supply
SMART III Ultra ATA Integrity Monitoring – DPS is supported in BIOS
Version of PCI Bus Supported – PCI Revision 2.2
Wake-on-LAN supported – with PCI PME# Signal
AOL Support – "No Boot" and "Processor Over Temp" signal are supported.
ACPI Compliant
Dual-State Power Button
Fast Boot
Wired for Management 2.0 support
90 Watts
No (DMI 2.0 compliant)
No (DMI 2.0 compliant)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
Optional
Yes
Yes
Yes
No
Yes
No
No
DA-10832 North Americ a — Version 8 — September 14, 2001
4
QuickSpecs
Standard Features
Security Easily-installed security bracket to prevent theft of memory modules and internal hard drive
Intelligent M anageability*
Operating System
One of the following:
Service and Support One-year parts and on-site labor standard
Tracking and security
Fault notification and recovery
Remote ROM flash
Software deployment tools
Wake-on-LAN support
Note: * = Intelligent Manageability is not supported under Windows ME.
Microsoft Windows 98 Second Edition (iPAQ Desktop with Legacy Ports only)
Microsoft Windows NT4 Service Pack 4 (iPAQ Desktop with Legacy Ports only)
Microsoft Windows 2000 (Service Pack 1)
Microsoft Windows ME (iPAQ Desktop Legacy Free only)
Compaq iPAQ Desktop
DA-10832 North Americ a — Version 8 — September 14, 2001
5
QuickSpecs
Options
Compaq iPAQ Desktop
Memory 256-MB SDRAM 133MHz
128-MB SDRAM 133MHz
64-MB SDRAM 133MHz
Monitors S510 15-inch CRT Monitor (carbon)
S710 17-inch CRT Monitor (carbon)
TFT5004 15-inch Flat Panel Monitor (carbon)
TFT5015 15-inch Flat Panel Monitor (carbon/silver)
TFT8020 18-inch Flat Panel Monitor (carbon)
Hard Drive
Multimedia
Removable Storage
External USB 1.44MB Floppy Drive
Security Devices
Other
MultiBay 10-GB Hard Drive
MultiBay 24X CD-ROM Drive
MultiBay 8X DVD-ROM Drive
MultiBay 4/4/20X CD-RW Drive
ACS21 Altec-Lansing Speakers
MultiBay SuperDisk LS-120 Drive
MultiBay 250 Zip Drive
Compaq Security Lock
Legacy Module 229038-B21
174225-B21
174224-B21
174223-B21
168636-002
154499-002
202416-001
23404-001
159244-001
218949-B21
165864-B21
202994-B21
201808-B21
222848-B21
165866-B21
219091-B21
230942-B21
294316-B21
DA-10832 North Americ a — Version 8 — September 14, 2001
6
QuickSpecs
Memory
Compaq iPAQ Desktop 64 MB
S
TANDARD MEMORY
64 MB SDRAM standard
Standard 64 MB 64 MB
S
TANDARD MEMORY
LUS OPTIONAL MEMORY
P
Support for up to 320 MB of SDRAM memory is available with the installation of optional memory kits.
Standard 64 MB 64 MB
128 MB 64 MB 64 MB
192 MB 64 MB 128 MB
320 MB 64 MB 256 MB
Memory Slot 1 Slot 2
Empty
Memory Slot 1 Slot 2
Empty
Compaq iPAQ Desktop
S
TANDARD MEMORY REPLACED
WITH OPTIONAL MEMORY
Support for up to 512 MB of SDRAM memory is available with the removal of the standard 64-MB SDRAM module and the installation of optional
Memory Upgrades.
Memory Slot 1 Slot 2
Standard 64 MB 64 MB
512 MB 256 MB 256 MB
Following are memory options available from Compaq:
•
64-MB SDRAM Memory Upgrade 174223-B21
•
128-MB SDRAM Memory Upgrade 174224-B21
•
256-MB SDRAM Memory Upgrade 174225-B21
Empty
DA-10832 North Americ a — Version 8 — September 14, 2001
7
QuickSpecs
Memory
Compaq iPAQ Desktop 128 MB
S
TANDARD MEMORY
128 MB SDRAM standard
Standard 128 MB 128 MB
S
TANDARD MEMORY
LUS OPTIONAL MEMORY
P
Support for up to 384 MB of SDRAM memory is available with the installation of optional memory upgrades.
Standard 128 MB 128 MB
192 MB 128 MB 64 MB
256 MB 128 MB 128 MB
384 MB 128 MB 256 MB
Memory Slot 1 Slot 2
Empty
Memory Slot 1 Slot 2
Empty
Compaq iPAQ Desktop
S
TANDARD MEMORY REPLACED
WITH OPTIONAL MEMORY
Support for up to 512 MB of SDRAM memory is available with the removal of the standard 128-MB SDRAM module and the installation of
optional Memory Upgrades.
Memory Slot 1 Slot 2
Standard 128 MB 128 MB
512 MB 256 MB 256 MB
Following are memory options available from Compaq:
•
64-MB SDRAM Memory Upgrade 174223-B21
•
128-MB SDRAM Memory Upgrade 174224-B21
•
256-MB SDRAM Memory Upgrade 174225-B21
Empty
DA-10832 North Americ a — Version 8 — September 14, 2001
8
QuickSpecs
Storage
C
OMPAQ I
Quantity Supported Position Supported Controller
Media
MultiBay SuperDisk LS-120 Floppy Drive 1 MultiBay IDE
MultiBay Zip 250 Drive 1 MultiBay IDE
MultiBay 24X Max CD-ROM Drive 1 MultiBay IDE
MultiBay 4/4/20X Max CD-RW Drive 1 MultiBay IDE
MultiBay 8X Max DVD-R OM Drive 1 MultiBay IDE
Hard Drive s
20-GB 7200 rpm SMART III Ultra ATA Hard Drive 1 Internal Hard Drive Ultra ATA 100 (embedded)
10-GB (MultiBay) 1 MultiBay IDE
PAQ D
ESKTOP DRIVE SUPPORT
Compaq iPAQ Desktop
DA-10832 North Americ a — Version 8 — September 14, 2001
9
QuickSpecs
Technical Specifications
Compaq iPAQ Desktop
System Unit
Compaq Easy
Access Keyboard
Weight Approximately 2 lbs/0.9 kg
Electrical Operating Voltage +5VDC ± 5%
Power Consumption 50 mA maximum (with 3 LEDs on)
System Interface PS/2 mini-din connector
ESD CE level 4, 15 kV air discharge
EMI-RFI
PC98 Functionally compliant
Keycaps Low-profile design
Switch Actuation 55 g nominal peak force with tactile feedback
Switch Life 20 million keystrokes (using Hasco modified tester)
Switch Type Contamination resistant membrane
Key Leveling Mechanism For all double wide and greater length keys
Cable Length 6 ft/1.8 m
PC98-99 Mechanically compliant
Acoustics 50 dBA maximum sound pressure level
Dimensions (HxWxD) 13.8 x 5.4 x 10.43 in/34.9 x 13.8 x 26.4 cm
Weight
Power Supply
Temperature
Humidity
Maximum Altitude
Maximum Rate of Change
Memory
Dimensions (HxWxD) 1.4 x 18.3 x 6.3 in/36 x 465 x160 mm
Mechanical
Environmental Operating Temperature 50° to 122° F/10° to 50° C
Non-operating Temperature −22° to 140° F/−30° to 60° C
Operating Humidity 10% to 90% (non condensing at ambient)
Non-operating Humidity 20% to 80% (non condensing at ambient)
Operating Shock 40 g, 6 surfaces
Non-operating Shock 80 g, 6 surfaces
Operating Vibration 2 g peak acceleration
Non-operating Vibration 4 g peak acceleration
10.3lbs/4.68kg (without MultiBay device, keyboard, or mouse)
Operating Voltage Range
Rated Voltage Range
Rated Line Frequency
Rated Input Current
Maximum Rated Power
Operating
Non-operating
Operating
Non-operating
Operating
Non-operating
1500 feet per minute/457 meters per minute
64 MB or 128MB SDRAM standard
Languages 30+ available
90 to 132 VAC/180 to 264 VAC
100 to127 VAC/200 to 240 VAC
47-63 Hz
4A / 2A
90W
50° to 95°F/10° to 35°C
–4° to 140°F/–20° to 60°C
20% to 80%
10% to 90%
10,000 ft/3,048 m
30,000 ft/9,144 m
Conforms to FCC rules for a Class B computing
device
DA-10832 North Americ a — Version 8 — September 14, 2001
10
QuickSpecs
Technical Specifications
Compaq iPAQ Desktop
Compaq 2-Button Scroll Mouse
Electrical
Scroll Wheel
Environmental
Mechanical Resolution
Regulatory Approvals
Operating Temperature
Non-operating Temperature
Operating Humidity 10% to 90% (non condensing at ambient)
Non-operating Humidity 20% to 80% (non condensing at ambient)
Operating Shock 40g, 6 surfaces
Non-operating Shock 80g, 6 surfaces
Operating Vibration 2g peak acceleration
Non-operating Vibration 4g peak acceleration
Drop (Out of Box) 26 in/660 mm on carpet, 6 drop sequence
Drop (Out of Box) One meter on asphalt tile over concrete,
Operating Voltage
Power Consumption 15mA
System Consumption PS/2 mini-din connector
ESD CE level 4, 15kV air discharge
EMI-RFI Conforms to FCC rules for a Class B computing
PC98 Functionally compliant
Tracking Speed 10 in/s Maximum
Acceleration 100 in/s/s
Switch Actuation 75 gram nominal peak force
Switch Life 1,000,000 operations (using Hasco modified
Switch Type Micro-switches
Tracking Mechanism Life 155 miles/250 km at average speed of 10 in/s
Cable Length 6 in/1.8 m
PC98-99 Mechanically compliant
Width
Maximum Rotation Speed
Switch Type
Switch Life
Mechanical Life
Compliant UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI,
50° to 122° F/10° to 50° C
–22° to 140° F/–30° to 60° C
6 drop sequence
+5VDC ±10%
device
400 ± 20% DPI
tester)
8 mm
30 mm/s
Light force micro-switch
1 million operations
Minimum 200,000 revolutions
BSMI, C-Tick
DA-10832 North Americ a — Version 8 — September 14, 2001
11
QuickSpecs
Technical Specifications
Compaq iPAQ Desktop
Intel 3D Direct AGP
Bus Type Integrated
Standard Memory Dynamic main memory allocation
Upgradable To Not upgradable
DAC Speed 230 MHz
MPEG Support (Software) N/A
Engine Acceleration 3 ROP bitBLT
Dual Monitor Support (using same controller) N/A
OS Support Microsoft Windows 95
Refresh Rate with Memory Indicated Dynamic main memory allocation
Colors
1280 x 1024
Line Draw
Text
Color Expansion
Basic Video Color Conversion and Scaling
Triangle Setup Engine
Microsoft Windows 98
Microsoft Windows NT 4.0
Microsoft Windows 2000
Microsoft Windows ME
256 65K 16.7M
85 85 85
DA-10832 North Americ a — Version 8 — September 14, 2001
12
QuickSpecs
Technical Specifications
Compaq iPAQ Desktop
Integrated Intel Audio with
Premier Internal Speakers
Card Type
Plug and Play
Stereo Codec
OPL3 FM Synthesis
Compatibility
Ports
Sampling
Compression
OS support
Wavetable Syntheses (software)
3D Positional Sound
Analog Audio
Number of Channels (mono/stereo)
Internal Audio Power Amp Rating
Number of Fixed Equalization Stages
Speaker (Internal)
PCI
Yes
Yes
128 WaveTable Synthesizer
Sound Blaster
Sound Blaster Pro
Full DOS Game Compatibility
Microphone in (10 Kohm)
Line-in (10 Kohm)
Line-out/Headphone-out (33 ohm)
(Note: Line out cannot drive external passive speakers.)
MIDI (playback only)
CD In
TAD
TV Tuner
48 KHz
ADPCM, CCITT A-law, CCITT u-law
Windows 95
Windows 98
Windows NT 4.0
Windows 2000
Windows ME
DOS
Yes
Yes
Premier•Sound
Mono
Nominal: 1.5 Watts RMS @ 8 ohms
Maximum: 5 Watts RMS @ 8 ohms
6
40 mm x 70 mm
DA-10832 North Americ a — Version 8 — September 14, 2001
13
QuickSpecs
Technical Specifications
Compaq iPAQ Desktop
Integrated Intel PRO/100 VM
Network Connection
Connectors RJ-45
Expansion Bus Architecture PCI 2.2
Network Transfer Rate 10Base-T (Half-Duplex) 10 Mb/s
10Base-T (Full-Duplex) 20 Mb/s
100Base-TX (Half-Duplex) 100 Mb/s
100Base-TX (Full-Duplex) 200 Mb/s
Standards Compliance IEEE VLAN Support (802.1A)
IEEE 802.2
IEEE 802.3 & IEEE 802.3u
(100-Mb/s Ethernet)
OS Driver Support Microsoft Windows NT 3.51 and 4.0
Remote Wakeup Yes, (PME# and WAKE signals) - no cable required on 810 or 820
Proactive Alert Technology Yes, alert on LAN (transmit functionality only) requires management
Boot PROM support Yes, Intel PRO/100 Boot Agent (PXE 2.0, RPL)
IEEE Intel Priority Packet (801.1p)
Microsoft Windows 95, 98
2000 and ME
Novell Netware 3.11,
3.12 & 4.1x,
5 Server Sun Solaris
SCO UnixWare
OpenDesktop
OpenServer
chipset platforms
console software, such as Compaq Insight Manager. It also
requires alert utilities for the management console, proxy client
software, and client configuration software.
DA-10832 North Americ a — Version 8 — September 14, 2001
F12 BIOS Support Yes
Environmental Requirements
Humidity (non-condensing) 85% at 131° F/55° C
Altitude
Non-Operating Temperature –40° to 158° F/–40° to 70° C
Humidity (non-condensing)
Altitude
Operating Temperature 32° to 131° F/0° C to 55° C
10,000 ft/3,048 m
5,000 ft/15,240 m
14
QuickSpecs
Technical Specifications
Compaq iPAQ Desktop
iPAQ MultiBay 4X CD-RW Drive
Hard Drive
Rotational Speed 7200 rpm 19,485
Logical Blocks
Operating Temperature
Dimensions (HxWxD)
Weight
Maximum Transfer Rate
Operating System Support
Option Kit Contents
20 GB
Capacity
Height
Width
Interface
Transfer Rate Synchronous
(Maximum)
Seek Time (typical reads,
including settling)
0.5 x 5.22 x 4.96 in/1.27 x 13.25 x 12.61 cm
0.741 lb/336 grams
Write: minimum 4X (600 KB/s)
Re-write: minimum 4X (600 KB/s)
Windows 98/98SE, Windows 2000, Windows Millennium, Windows NT 4.0
CD-RW Drive, 1 CD-R media, 1 CD-RW media, Software, Documentation
20 GB
1 in/25.4 mm
3.5 in/88.9 mm
Ultra ATA/100
100 MB/s
Single Track 1.2 ms (2.7 ms quiet seek)
Average 8 ms (14.3 ms quiet seek)
Full-Stroke 18.0 ms (24.1 ms quiet seek)
39,102,336
41° to 131°F/5° to 55°C
DA-10832 North Americ a — Version 8 — September 14, 2001
15
QuickSpecs
Technical Specifications
Compaq iPAQ Desktop
iPAQ MultiBay 24X CD-ROM Drive
Disc Diameter 12 cm, 8 cm
Audio Output Level Line-out 0.7 Vrms
Normal PIO Mode 4
Applicable Disc CD-ROM (Mode 1, 2 and 3), CD-XA ready (Mode 2, Form 1 and 2), CD-I ready
(Mode 2, Form 1 and 2), CD-R (read only), CD Plus, Photo CD (Single and Multisession), CD-Extra, Video CD, CD-WO (fixed packets only), CD-Bridge
Form Factor 12.7 mm MultiBay
Center Hole Diameter 0.59 in/15 mm
Disc Thickness 1.2 mm
Track Pitch 1.6 µm
Access Times (typical reads,
including settling)
Cache Buffer 128 KB
Data Transfer Rate (typical,
including settling)
Start-up Time < 8 sec
Stop Time < 4 sec
Operating System Support Windows 98/98SE, Windows 2000, Windows Millennium, Windows NT 4.0
Option Kit Contents CD-ROM Drive, Documentation
Random < 150 ms
Full-Stroke < 300 ms
Sustained (16X) 150 KB/s (sustained 1X)
Variable 1500 to 3600 KB/s (10X to 24X)
16.66 MB/s
(single burst)
DA-10832 North Americ a — Version 8 — September 14, 2001
16
QuickSpecs
Technical Specifications
Compaq iPAQ Desktop
iPAQ MultiBay 8X DVD-ROM Drive
Disc Thickness
Audio Output Level
Form Factor
Center Hole Diameter
Disc Diameter
Track Pitch
Access Times (typical reads,
including settling)
Cache Buffer
Data Transfer Rate (typical,
including settling)
Start-up Time
Stop Time
Operating System Support
Option Kit Contents
12.7 mm MultiBay
0.59 in/0.39 cm
12 cm/8 cm
1.2 mm
0.74 µm
Random < 180 ms
Full-Stroke < 300 ms
Line out 0.7 Vrms
128 KB/s (minimum)
Sustained (16X) CD-ROM 2.4 MB/s
Sustained 8X DVD 10.08 MB/s
Normal PIO Mode 4
(single burst)
< 15 sec
< 4 sec
Windows 98/98SE, Windows 2000, Windows Millennium, Windows NT 4.0
Note: MPEG2 video playback is supported on all Driect 3D Graphic Cards with
Windows 98/98SE, Windows 2000, Windows Millennium. MPEG2 video
playback is not supported with Windows NT 4.0.
DVD Drive, Software, Documentation
16.6 MB/s
DA-10832 North Americ a — Version 8 — September 14, 2001
17
QuickSpecs
Technical Specifications
Compaq iPAQ Desktop
iPAQ MultiBay Iomega Zip 250
Access Time
Interface
Media Format Supported
Media Capacity
Drive Rotational Speed
Data Transfer Rate
(typical, including settling)
Operating Conditions
Operating Systems
Kit Contents
IDE (ATAPI)
Zip Disk
250 MB & 100 MB
29 ms (average)
2941 rpm
250 MB Cartridge 2.4 Mb/s
100 MB Cartridge
Read 1.4 Mb/s
Write 0.25 Mb/s
Burst (both cartridges) 11.11 Mb/s
Temperature 50° to 125°F/10° to 51.5°C
Humidity 20% to 80%
Windows 98/98SE, Windows 2000, Windows Millennium, Windows NT 4.0
Zip 250 Drive, Zip 250 Media, Installation Guide
DA-10832 North Americ a — Version 8 — September 14, 2001
18
QuickSpecs
Technical Specifications
Compaq iPAQ Desktop
iPAQ MultiBay SuperDisk
LS-120 Drive
Zones/Side 55
Data Tracks per Side 1736
Servo Tracks 900
Dimensions (HxWxD) 0.5 x 5.22 x 4.96 in/1.27 x 13.25 x 12.61 cm
Weight 0.61 lbs/276 g
Maximum Transfer Rate From Disk 896 KB/s
120 MB Physical Format
Access Times
(including setting)
Latency Average 41.67
Operating Conditions Temperature
Humidity 10% to 80% RH
Operating System Support
Note: Drivers for the SuperDisk 2X LS-120 Drive are standard in Windows 95/OSR2, Windows NT 3.51/SP5,
Windows NT 4.0 and Windows 2000. Use the SuperDisk LS-120 Drive Option Support Diskette (included in
option kit) with earlier releases of Windows 95 and NT 3.51.
Option Kit Contents
Sustained: 375 to 900 KB/s
Number of Heads 2
Bytes per Sector 512
Sectors per Track 51 to 92
Sector Interleave 1:1
Track–to–track 20 ms
Average 70 ms
41° to 131°F/5° to55°C
Windows 98/98SE, Windows 2000, Windows Millennium, Windows NT 4.0
SuperDisk LS-120 Drive, SuperDisk Media, Documentation
DA-10832 North Americ a — Version 8 — September 14, 2001
19
QuickSpecs
Technical Specifications
Compaq iPAQ Desktop
USB 1.44 External Floppy Drive
Dimensions (HxWxD) 0.7 x 4.0 x 5.5 in/17.6 x 103 x 140 mm
Weight 0.56 lbs/255 g
Disk used High density (2HD)
Maximum data transfer
rate
Cable length 17.0 in/43.2 cm
Disk rotational speed 300 RPM
Required power Supplied from a USB port
Option kit contents USB floppy disk drive, driver CD-ROM, installation guide
Operating position Horizontal only
Recording method MFM (modified frequency modulation)
Signal interface USB Specification, version 1.1
Ambient temperature Operating 39° to 125° F/4° to 51.7° C
Temperature gradient Operating 36° F/20° C or less per hour (no condensation)
Storage 54° F/30° C or less per hour (no condensation)
Relative humidity Operating 20% to 80% (no condensation)—maximum wet bulb
Storage 5% to 90% (no condensation)—maximum wet bulb
Suspend Initiates when continuously idle for 3.0 ms or more on
Resume Initiates when signal other than idle state is detected on
Operating System Support Microsoft Windows 2000, Microsoft Windows 98, Microsoft Windows NT SP4 or
Safety standards UL and CSA
500-Kbps internal FDD
Storage –8° to 140° F/–22° to 60° C
greater
Compaq PCs use genuine Microsoft Windows
www.Microsoft.com\piracy\howtotell
Microsoft and Windows are trademarks of Microsoft Corporation in the U.S. and other countries.
temperature of 85° F (29.4° C)
temperature of 104° F (40° C)
the bus line
the bus line
DA-10832 North Americ a — Version 8 — September 14, 2001
20
Loading...
