Compaq DL580 User Manual

QuickSpecs

Overview

What's New

• Intel Pentium

MHz Processor s (up to 4) with
1-MB, or 2-MB L2 Cache

• ServerWorks Enterprise

ServerSet

• 512 MB PC100 Advanced ECC

SDRAM Memory standard,
expandable to 16 GB

• Integrated Smart Array Controller

(Embedded on system board)

• Integraged Compaq NC3134 Fast

Ethernet NIC 64 PCI Dual Base
10/100 in a slot (upgradabl e to
Gigabit)

• 64-bit/66-M H z slots for 64- bit/

66-MHz expans ion card support

• Improved Serviceability and

Intelligent Manageability

At A Glance

• Rack optimiz ed (4U = 7″) 4-way

computing power for your data
center or ISP/ASP environments

• Six PCI slots, 4 Hot Pluggable:

Two 64-bit/6 6-MHz Hot Plug
Two 64-bit/3 3-MHz Hot Plug
One 64-bit/33-MHz Non-Hot
Plug
One 32-bit/33-MHz Non-Hot
Plug

• Standard Wide Ultra2/Ultra3-

ready Drive Cage (4 x 1”)

• Internal Hot Plug Drive Stor age of

up to 145.6 GB with 36.4-GB 1″
Wide Ultra2/Ultr a3 har d dri ves

• Uncompromising reliability

features:

Industry-Standard PCI Hot Plug
with push button functionality
7 x 24 cooling provided by 8
Hot Plug Redundant System
Fans
Hot Plug 450-Watt Power
Supply with optional redundant
hot plug power supplies

• Automatic Server Recovery 2

(ASR-2 ), Integrated Remote
Console (IRC), Compaq Insight
Manager and SmartStart

• Toolless internal design for easy

access to system components

• Protected by Compaq Servi ces,

including a limited three-year
parts, labor and on-site w arranty
with optional four-hour response.
Pre-Failure War ranty and Co mpaq
Service and Support Progra ms
available on a Worldwi de bas i s —
Certain restrictions and exclusions
apply. Consul t the Compaq
Customer Su pport Center at 1­800-345-1518 for details.

®

III XeonTM 700

TM

III HE chipset

Compaq ProLiant DL580

DA-10635 North America — Version 13 — December 18, 2000 1

QuickSpecs

y

y

Standard Features

Compaq ProLiant DL580

Processor

Cache Memor y

One of the following

Upgradabili ty

Memory

Network Con troller

Expansion Slots

Intel Pentium III Xeon processor 700 MHz

(Note: One or two processors ship standard depending on model.)

2-MB level 2 writeback cache per processor standard
1-MB level 2 writeback cache per processor standard

Upgradable to quad processing
Support for future processor upgrades

Standard 512 MB (PC100-MHz Advanced ECC SDRAM Memory)
Maximum 16 GB

Note: Advanced ECC Memory Technology protects the data even in the event of an entire SDRAM component

failure. Embedded in the chipset design, this feature allows the use of Industry-Standard Registered DIMMs.

Integraged Compaq NC3134 Fast Ethernet NIC 64 PCI Dual Base 10/100 in a slot (upgradable to Gigabit)

I/O (Total) 6, 5 available

64-bit/66-MHz PCI Hot Plug 2, 1 available
64-bit/33-MHz PCI Hot Plug 2, 2 available
64-bit/33-MHz PCI 1, 1 available

Non-Hot Plug
32-bit/33-MHz PCI 1, 1 available

Non-Hot Plug

Storage Con troller

Storage

Interfaces

Graphics

Form Factor

Compaq Softw are

Integrated Smart Array Controller (supports Internal RAID 0, 1, 0+1, 5 and external tape devices)

Note: The Integrated Smart Array Controller is embedded on the system board.

Diskette Drives 1.44 MB
CD-ROM High Speed IDE CD-ROM Drive (slim line)
Hard Drives None
Maximum Internal Storage 145.6 GB (4 x 36.4 GB 1″ drives) (internal hot plug drive cage)

Parallel 1
Serial 1 (Note: You can configure a second serial device to your ProLiant DL580 server

Pointing Device (Mouse) 1
Graphics 1
Hot Plug Keyboard 1
External Wide Ultra2 SCSI 1
Network RJ-45 1

Integrated 1280 x 1024, 256 color on PCI local bus, 2-MB video memory

Rack (4U = 7″), ships with sliding rails and cable management

Compaq Insight Manager™ The comprehensive system management tool that monitors the operation of

installing the auxiliary serial connector that ships with the server. The auxiliar

b
connector attaches to a serial port B on the peripheral board and exits the rear of
the server through the auxiliary serial knockout located directly above the
redundant power feeds.)

Compaq servers, workstations and clients
Compaq SmartStart™ The server configuration and software integration tool from Compaq
Array Configuration Utility (ACU) Same easy to use yet po werful graphical user interface (GUI) configuration utility

with Smart Array Controllers and easy to navigate wizards for all Smart Array Controllers

DA-10635 North America — Version 13 — December 18, 2000 2

QuickSpecs

Standard Features

Compaq ProLiant DL580

Intelligent M anageability

Availability

Serviceability

Compaq Remote Insight Lights Out Edition support
Automatic Server Recovery-2 (ASR-2)
Compaq Insight Manager
Compaq Insight Manager XE
Integrated Remote Console-IRC (with an internal modem)
Integrated Management Log (IML)
Server Health logging
Off-Line Backup Processor capability
Dynamic sector repairing and drive parameter tracking (with Smart Array controllers)
Redundant/adaptive load balancing NIC Support

PCI Hot Plug with push button functionality
7 x 24 cooling provided by 8 Hot Plug Redundant System Fans
Integrated Smart Array Controller for RAID data protection/performance and maximum data bandwidth
Advanced Error Checking and Correcting (ECC) SDRAM Technology
Hot Plug Ultra2/Ultra3 Drive Bays
Redundant Hot Plug Power Supplies (optional)
Redundant NIC support
Pre-Failure Warranty (covers processors, hard drives, and memory)

Internal Diagnostics Display (IDD) indicates specific DIMM or processor failure.
LED display on front panel indicates interlock, fan, and power failures.
Spring-loaded memory board release latches prevent unseating incidents.
PCI Card Guide holds long PCI cards in place during transit.
Customer driven interior system fan design (all system fans interior to chassis)
Removable, internal center panel eases access to the power supply and hard drive backplane boards.
Optional High Voltage PDU cable exits chassis at a right angle to simplify cable management at rear of chassis.

Security

Power Supply

Required Cabl ing

Power-on password
Hot plug keyboard password
Diskette drive control
Diskette boot control
Network Server Mode
Security Provision
Parallel and serial interface control
Administrator’s password
Disk configuration lock
Hot plug access security

One 450-Watt Hot Plug Power Supply (optional Redundant Hot Plug Power Supply Option Kit)

For required cabling information, refer to the Compaq Web site at

http://www.compaq.com/products/servers/proliantDL580/.

Note: This Web site is available in English only.

DA-10635 North America — Version 13 — December 18, 2000 3

QuickSpecs

Standard Features

Compaq ProLiant DL580

OS Support

Service and Support

Microsoft Windows NT Server
Microsoft Windows 2000
Novell NetWare
SCO OpenServer
SCO UnixWare
IBM OS/2 Warp Family
LINUX (RedHat, S.U.S.E., TurboLinux Server, Caldera eServer)
Sun Solaris Intel Platform Edition
Banyan VINES

Note: For a more complete and up-to-date listing of supported OSs and versions, please visit our OS Support

Matrix at: ftp://ftp.compaq.com/pub/products/servers/os-support-matrix-310.pdf.

Note: For an up-to-date listing of the latest drivers available for the Compaq ProLiant DL580, please see:

http://www.compaq.com/support/files/server/us/index.html.

Compaq Services provides a wide range of service offerings, including a three-year, limited warranty that is fully
supported by a worldwide network of resellers and service providers, lifetime, toll-free 7 x 24 hardware technical
phone support and Pre-Failure Warranty coverage of hard drives, memory and processors. Disaster recovery
services are available through partnership with Comdisco.

Note: Certain restrictions and exclusions apply. Consult the Compaq Customer Support Center at 1-800-345-

1518 for details. In Canada consult the Product Information Center at 1-800-567-1616 for details.

DA-10635 North America — Version 13 — December 18, 2000 4

QuickSpecs

Standard Features

Compaq ProLiant DL580

DL580R01 X700- 2MB, 512MB

(2P)

155618-001

DL580R01 X700- 1MB, 512MB

(1P)

155617-001

Processor(s)

Cache Memory
Memory

Network Controller
Storage Controller
Hard Drive
Internal Storage
Optical Drive

Form Factor
Processor(s)

Cache Memory
Memory

Network Controller
Storage Controller
Hard Drive
Internal Storage
Optical Drive
Form Factor

(2) Intel Pentium III Xeon 700 MHz processors

2-MB Level 2 writeback cache per processor
512 MB (Standard ) to 16 GB (Maximum)

Integrated Compaq NC3134 Fast Ethernet NIC 64 PCI Dual Base 10/100 in a slot
Integrated Smart Array Controller
None

145.6 GB maximum
High Speed IDE CD-ROM Drive

Rack 4U
(1) Intel Pentium III Xeon 700 MHz

1-MB Level 2 writeback cache per processor
512 MB (Standard ) to 16 GB (Maximum)

Integrated Compaq NC3134 Fast Ethernet NIC 64 PCI Dual Base 10/100 in a slot
Integrated Smart Array Controller
None

145.6 GB maximum
High Speed IDE CD-ROM Drive
Rack 4U

DA-10635 North America — Version 13 — December 18, 2000 5

QuickSpecs

Options

Compaq ProLiant DL580

ProLiant DL580 Unique Options Compaq Hot Plug Redundant Power Supply Option Kit

Compaq High Voltage PDU Right Angled Cable Kit (IEC13-IEC14)

Note: The 10-Amp AC cord which ships standard with the Compaq ProLiant DL580

utilizes a right angle plug on the server side (the side that plugs into the server) to
avoid interference with the Cable Management Arm. Compaq High Voltage
PDUs ship standard with 15-Amp AC cords that incorporate straight plugs on the
server side. The optional Compaq High Voltage PDU Right Angled Cable Kit
(142257-004) provides a right angle version of the 15-Amp AC cord. When
deploying Compaq High Voltage PDUs with the Compaq ProLiant DL580, you
may choose to simplify cable management at the rear of the server chassis by
installing this option kit.

Processor Pentium III Xeon X7002MB Processor Option Kit

Note: This processor option kit (PN 174449-B21) supports the ProLiant DL580 and the
ProLiant ML570 servers.

Pentium III Xeon X700-1MB Processor Option Kit

Note: This processor option kit (PN 174448-B21) supports the ProLiant DL580 and the
ProLiant ML570 servers.

Note: The increasing power of new high-performance processor technology requires

increased cooling efficiency for rack-mounted servers. The new Compaq Rack
9000 series (120663-001 (42U), 120664-001 (36U), 120665-001 (22U)) provides
enhanced airflow for maximum cooling, allowing these racks to be fully loaded
with servers using the latest processors.
When installing a server with Pentium III Xeon processors running at speeds of
550 MHz or greater in Compaq Rack 7000 series racks (165753-001 (42U), and
163747-001 (22U)), the new processor technology requires the installation of
Compaq’s new High Airflow Rack Door Insert (327281-B21 (42U) or 157847-B21
(22U)).

105739-001
142257-004

174449-B21

174448-B21

Memory (DIMMs) 4096-MB PC100 Advanced ECC SDRAM Memory Kit (4 x 1024 MB)

2048-MB PC100 Advanced ECC SDRAM Memory Kit (4 x 512 MB)
1024-MB PC100 Advanced ECC SDRAM Memory Kit (4 x 256 MB)
512-MB PC100 Advanced ECC SDRAM Memory Kit (4 x 128 MB)

Hard Drives

Storage Controllers

Wide Ultra3 SCSI – Universal Hot Plug

36.4-GB Wide Ultra3 SCSI 10,000 rpm Drive (1″)

18.2-GB Wide Ultra3 SCSI 10,000 rpm Drive (1″)

9.1-GB Wide Ultra3 SCSI 10,000 rpm Drive (1″)

18.2-GB Wide Ultra3 SCSI 15,000 rpm Drive (1″)

9.1-GB Wide Ultra3 SCSI 15,000 rpm Drive (1″)

Wide Ultra2 SCSI – Universal Hot Plug

18.2-GB Wide Ultra2 SCSI Drive (1″)

9.1-GB Wide Ultra2 SCSI Drive (1″)

Smart Array 431 Controller
Smart Array 3200 Controller
Smart Array 4200 Controller
Smart Array 5302/32 Controller
Smart Array 5302/64 Controller
Smart Array 5304/128 Controller
Ultra3 Channel Expansion Module for Smart Array 5300 Controller
64-bit/66-MHz Single Channel Wide Ultra3 SCSI Adapter
64-bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter

189083-B21
189082-B21
189081-B21
189080-B21

176496-B22
142673-B22
142671-B22
188122-B22
188120-B22

388144-B22
123065-B22

127695-B21
295643-B21
295636-B21
166207-B21
124992-B21
158939-B21
153507-B21
154457-B21
129803-B21

DA-10635 North America — Version 13 — December 18, 2000 6

QuickSpecs

Options

Compaq ProLiant DL580

Communications

Redundant Options

Management Options

Compaq NC3123 Fast Ethernet NIC PCI 10/100 WOL
Compaq NC3122 Fast Ethernet NIC PCI Dual 10/100
Compaq NC3134 Fast Ethernet NIC 64 PCI Dual Port 10/100
Compaq NC3135 Fast Ethernet Module Dual 10/100 Upgrade Module for NC3134 and

NC3131
Compaq NC6132 Gigabit Module 1000 SX Upgrade Module for NC3134 and NC3131
Compaq NC6133 Gigabit Module 1000 LX Upgrade Module for NC3134 and NC3131
Compaq NC3133 Fast Ethernet Module 100 FX Upgrade Module for NC3134 and

NC3131
Compaq NC6134 Gigabit NIC 64 PCI 1000 SX
Compaq NC4621 Token Ring NIC PCI 4/16 WOL
IBM 16/4 Token Ring PCI Special
ServerNet PCI Adapter
4M Cable
30M Cable
ServerNet II PCI Adapter Card Kit
ServerNet II 12-Port Copper Serial Switch Kit
ServerNet II 5-meter Copper Serial Cable Kit
ServerNet II 10-meter Copper Serial Cable Kit

Compaq Hot Plug Redundant Power Supply Option Kit

Compaq Remote Insight (PCI) LAN + NA Modem
Compaq Remote Insight Board (PCI) LAN/Serial without modem
Compaq Remote Insight Board (PCI) LAN only
Compaq Remote Insight Lights-Out Edition

174830-B21
317450-B21
138603-B21
138604-B21

338456-B23
338456-B24
338456-B25

174818-B21
379956-B21
133749-B21
309833-B22
309834-B23
309834-B22
174736-B21

174739-001
174737-B21
174738-B22

105739-001

294013-002
294013-B24
294013-B25

157866-001

Monitors TFT5010 15″ Flat Panel Monitor (Opal)

TFT5010 15″ Flat Panel Monitor (Carbon)
TFT5005 15″ Flat Panel Monitor (Opal)
TFT5005 15″ Flat Panel Monitor (Carbon)
TFT5000R Flat Panel
P710 Color Monitor
V710 Color Monitor
V500 Color Monitor
S510 Color Monitor
S710 Color Monitor

C R T C o d e K e y Dash # Description

-001

-002 Carbon model with U.S. Power Cord

-003 Touch Screen model with US Power Cord

-004 NAFTA model with U.S. Power Cord

-005 NA Kit with Powered Speakers

-006 GSA model with U.S. Power Cord

-007 NH MPR model with U.S. power cord

-B24

Note: All models above are NH

NA Kit with U.S. Power Cord

(Made in Mexico)

(Made in Mexico)
TCO model without power cord (Digital Classic)

104741-001

154486-001

201431-001

201430-001

120207-001

210189-xxx
187895-xxx
325900-xxx
168636-xxx
152991-xxx

DA-10635 North America — Version 13 — December 18, 2000 7

QuickSpecs

Options

Compaq ProLiant DL580

External Tape Drives External 20/40-GB DAT DDS-4 Tape Drive

(Note: Only External Tape Drives
are supported by the ProLiant
DL580.)

20/40-GB DAT 8 Cassette Autoloader External
External 40/80-GB DLT Drive
External 20/40-GB DLT Drive (Opal)
External AIT 50-GB Tape Drive
External AIT 35-GB, LVD
External AIT 35-GB Tape Drive
DDS-4 Media (10 pack)
20/40-GB DAT 8 Cassette Magazine with Media
12-GB DDS-3 DAT Cassette (10 Pack)
DAT Cleaning Cassette
AIT 35-GB Data Cassette (five pack)
AIT 50-GB Data Cassette (five pack)
DLT IV Drive Cartridge (single)
DLT IV Drive Cartridge (seven pack)
DLT Cleaning Cartridge

Note: Please see the Compaq 20/40-GB DAT Drive, Compaq 20/40-GB DAT DDS-4 8 Cassette Autoloader,

Compaq 40/80-GB DLT Drive, Compaq 20/40-GB DLT Drive, Compaq AIT 50-GB Tape Drive, Compaq AIT
35-GB LVD, or the Compaq AIT 35-GB Tape Drive QuickSpecs for a listing of the latest O/S Support details
at:

http://www.compaq.com/products/quickspecs/North_America/10233_na.html

Please note that all Web sites are available in English only.

157770-001

166505-001
146197-B21
340744-B22

157767-001

216885-001

388507-001

152842-001
171532-B21
295515-B21

242781-001
402371-B21

152841-001
295194-B21
295192-B21

199704-001

External Storage - Rack Compaq StorageWorks Enclosure Model 4214R (rack-mountable)

Compaq StorageWorks Enclosure Model 4254R (rack-mountable)
Compaq StorageWorks Enclosure Model 4314R (rack-mountable)
Compaq StorageWorks Enclosure Model 4354R (rack-mountable)

Note: The Compaq StorageWorks Enclosure 4200/4300 Family support the Wide Ultra2/Ultra3 1″

Hot Plug Hard Drives.

Rack-Mountable SCSI Storage Expander II
Rack-Mountable ProLiant Storage System Model UE
Rack-Mountable ProLiant Storage System Model U2

Note: The Compaq ProLiant Storage System Models UE and U2 support the Wide-Ultra SCSI-3 Drives.

ProLiant Storage System /U Redundant Power Supply
StorageWorks Enclosure 4200 Redundant Power Supply Option
StorageWorks Enclosure 4200 Ultra2 Dual Bus I/O Module Option
StorageWorks Enclosure 4200 Ultra3 Single Bus I/O Module Option
StorageWorks Enclosure 4200 Ultra3 Dual Bus I/O Module Option
StorageWorks Enclosure Tower to Rack Conversion Kit

StorageWorks DLT Departmental
Library

TL895 (96 slot) library unit, 2 drive
TL895 (96 slot) library unit, 3 drive
TL895 (96 slot) library unit, 4 drive
TL895 (96 slot) library unit, 5 drive
TL895 (96 slot) library unit, 6 drive
TL895 (96 slot) library unit, 7 drive
TL891DLX DLT Library, 1 drive, Rack, LVD
TL891DLX DLT Library, 2 drive, Rack, LVD
TL891 DLT library unit, 1 drive Rack, FWD
TL891 DLT library unit, 2 drive Rack, FWD

103381-001
138151-001
190209-001
190211-001

332607-001
348700-001

304100-B22

224206-001
119826-B21
119829-B21
190212-B21
190213-B21
150213-B21

349350-B22
349350-B23
349350-B24
349350-B25
349350-B26
349350-B27
157305-B21
157305-B22
120876-B21
120876-B22

DA-10635 North America — Version 13 — December 18, 2000 8

QuickSpecs

Options

Compaq ProLiant DL580

StorageWorks DLT Departmental
Library (continued)

Add-On 35/70-GB Drive for TL891
40/80 DLT Add-On Drive for TL891DLX
40/80 DLT Add-On Drive for TL8x1, HVD
DLT7000 drive upgrade kit

Note: Available for TL895 DLT Library only.

MiniLibrary Data Unit

Note: Available for TL891 DLT Libraries only.

MiniLibrary Expansion Unit

Note: Available for TL891 DLT Libraries only.

MiniLibrary Expansion Unit, LVD

(Available for TL891DLX DLT Libraries only.)

StorageWorks Dual Channel Ultra-Wide Differential Library Host Bus Adapter

Note: The StorageWorks Dual Channel Ultra-Wide Differential Library Host Bus
Adapter is required to support FWD-based tape libraries.

DLT IV Data Cartridges (single pack)
DLT IV Data Cartridges (7 pack)
DLT Cleaning Cartridge
MiniLibrary Pass-Through Mechanism Kit

Note: Available for TL891 DLT Libraries only.

10 Slot Magazine

Note: Available for TL891 DLT Libraries only.

MiniLibrary Table Top to Rack Mount Conversion Kit, Metric/RETMA racks

Note: Available for TL891 DLT Libraries only.

MiniLibrary Table Top to Rack Mount Conversion Kit, Compaq racks

Note: Available for TL891 DLT Libraries only.
Note: Please see the TL891, TL891 DLX, or the TL895 Automated DLT Tape Library Solution QuickSpecs for

additional information, including Upgrade Kits, Accessories, ProLiant Connectivity Kits, Host Bus Adapters,
SCSI Cable Kits, and Localization Kits and additional options needed for a complete solution at:

http://www.compaq.com/products/quickspecs/North_America/10233_na.html

Please note that all Web sites are in English only.

120878-B21
157303-B21
157304-B21
349351-B21

128670-B21

120877-B21

157301-B21

157299-B21

295194-B21
295192-B21

199704-001
120880-B21

120881-B21

120882-B21

120883-B21

Automated AIT Tape Library
Solution

Tape Array Solution TA1000 AIT Tape Array, Rackmount

SSL2020 AIT Mini-Library 1 drive, 20-slot Rackmount
SSL2020 AIT Mini-Library 2 drive, 20-slot Rackmount

SSL2020 AIT Library Pass Thru with Transport
SSL2020 AIT Library Pass Thru Extender
AIT 50GB Drive Add-On LVD Drive for SSL2020 AIT Library
19-slot Magazine for SSL2020 AIT Library
AIT 50-GB Data Cassette (5 pack)
AIT Cleaning Cassette
Tabletop to Rackmount Upgrade Kit for SSL2020 AIT Library, Compaq Rack
Tabletop to Rackmount Upgrade Kit for SSL2020 AIT Library, RETMA racks

Note: Please see the AIT Automated DLT Tape Library Solution QuickSpecs for additional information including

Upgrade Kits, Accessories, and SC SI Cable Kits and additional options needed for a complete solution at:

http://www.compaq.com/products/quickspecs/North_America/10233_na.html

Please note that all Web sites are in English only.

AIT 50-GB Data Cassette (5 pack)
AIT Cleaning Cassette
DLT Tape Array III Model 40/80-4
DLT Tape Array III Model 0

175196-B21
175196-B22
175312-B21
175312-B22
175197-B21
175198-B21

152841-001
402374-B21
175199-B21
175199-B22

175005-001

152841-001
402374-B21

161140-001

168047-001

DA-10635 North America — Version 13 — December 18, 2000 9

QuickSpecs

Options

Compaq ProLiant DL580

Tape Array Solution (continued) DLT Tape Array II Model 35/70-4 no software

DLT IV Data Cartridges (single pack)
DLT IV Data Cartridges (7 pack)
DLT Cleaning Cartridge
DLT Library Tabletop Conversion Kit
Tape Array Cable Kit

Note: Available for the DLT Tape Array and DLT Tape Array II only.

DLT Tape Array III Model 0, LVD Cable Kit

Note: Available for the DLT Tape Array III Model.
Note: Please see the Compaq TA1000 AIT Tape Array, Compaq DLT Tape Array III, or the Compaq DLT Tape

Array II QuickSpecs for additional information including Tape Drives, Cartridges, Controllers, and SCSI
Cables and additional options needed for a complete solution at:

http://www.compaq.com/products/quickspecs/North_America/10233_na.html

Please note that all Web sites are in English only.

StorageWorks Enterprise Tape
Library

ESL9326DX Enterprise Library 6 40/80 Drive
ESL9326DX Enterprise Library 8 40/80 Drive
ESL9326DX Enterprise Library 10 40/80 Drive
ESL9326DX Enterprise Library 12 40/80 Drive
ESL9326DX Enterprise Library 14 40/80 Drive
ESL9326DX Enterprise Library 16 40/80 Drive
ESL9326D, 0 Drive Unit
ESL9236D Enterprise Library 6 35/70 Drive
ESL9236D Enterprise Library 8 35/70 Drive
ESL9236D Enterprise Library 10 35/70 Drive
ESL9236D Enterprise Library 12 35/70 Drive
ESL9236D Enterprise Library 14 35/70 Drive
ESL9236D Enterprise Library 16 35/70 Drive
ESL9198DLX Enterprise Library LVD, 0 Devices
ESL9198DLX Enterprise Library 2 40/80 Drive
ESL9198DLX Enterprise Library 4 40/80 Drive
ESL9198DLX Enterprise Library 8 40/80 Drive
ESL9000 Add-On 40/80-GB DLT Drive
ESL9000 Add-On LVD 40/80-GB DLT Drive in Hot Plug Canister
Library Ready 35/80GB DLT Hot-Swap Drive for ESL9326D
LVD Extender Kit
ESL 9000 Pass Through Kit for Multi User Connectivity
StorageWorks Dual Channel Ultra-Wide Differential Library Host Bus Adapter

Note: The StorageWorks Dual Channel Ultra-Wide Differential Library Host Bus
Adapter is required to support the ESL9236D Library.

DLT IV Data Cartridges (single pack)
DLT IV Data Cartridges (7 pack)
DLT Cleaning Cartridge

Note: Please see the Compaq StorageWorks Enterprise Backup Solution QuickSpecs for additional information

including Tape Drives, Cartridges, Controllers, and SCSI Cables and additional options needed for a
complete solution at:

http://www.compaq.com/products/quickspecs/North_America/10233_na.html

Please note that all Web sites are in English only.

295165-001
295194-B21
295192-B21

199704-001
350384-B21

242427-001
168048-B21

161265-B23
161265-B24
161265-B25
161265-B26
161265-B27
161265-B28
146205-B21
146205-B23
146205-B24
146205-B25
146205-B26
146205-B27
146205-B28
194993-B21
194993-B22
194993-B24
194993-B28
161267-B21
221248-B21
146209-B21
221249-B21
161268-B21
157299-B21

295194-B21
295192-B21

199704-001

DA-10635 North America — Version 13 — December 18, 2000 10

QuickSpecs

Options

Compaq ProLiant DL580

StorageWorks RAID Array 4100

StorageWorks Raid Array 4100 (rack)
Fibre Channel Storage Hub 12
Fibre Channel Storage Hub 7
Compaq Storage Hub 7 Universal Rack Mount Kit
Fibre Channel Storage Hub – 12 Port with 41U/42U Bracket
Compaq Storage Hub 12 Management Option
StorageWorks Raid Array 4000 Redundant Array Controller
StorageWorks Fibre Channel Arbitrated Loop Switch 8
StorageWorks Fibre Channel Ar bitrated Loop 3-Port Expansion Module
64-bit/66MHz Fibre Channel Host Adapter
Fibre Channel Host Adapter Redundancy Kit
GBIC-SW Connector Kit (two each)
GBIC-LW Connector Kit (two each)
Fibre Channel Connection Kit, 3 SW GBICS, 2 Cables
Fibre Channel Connection Kit, 2 SW GBICS, 2 Cables
Fibre Channel short-wave GBIC
Fibre Channel long-wave GBIC
2m Multi-Mode Fibre Channel Cable
5m Multi-Mode Fibre Channel Cable
15m Multi-Mode Fibre Channel Cable
30m Multi-Mode Fibre Channel Cable
50m Multi-Mode Fibre Channel Cable
Raid Array 4000 Redundant Power Supply
Raid Array 4100 Rack to Tower Conversion Kit
Fibre Channel Array Controller 64-MB Cache Upgrade Kit
Raid Array 4100 Rack to Tower Conversion Kit
Fibre Channel Troubleshooting Kit

146013-001

295573-001

234453-001
136127-B21
295573-B22
159262-B21
223187-B21
177862-B21
177863-B21
120186-B21
174681-B21
234459-B21
340412-B21
380579-B21
380596-B21
380561-B21
127508-B21
234457-B21
234457-B22
234457-B23
234457-B24
234457-B25

224206-001
154253-B21
262398-B21
154253-B21
234468-B21

StorageWorks RAID Array 8000

Departmental Pedestal Models

RA8000 FC Single Controller (Opal)
RA8000 FC Dual Controller (Opal)
Expansion Cabinet 24-slot (Opal)

Rack Mountable Models

RA8000 FC Single Controller
RA8000 FC Dual Controller
Expansion Cabinet 24-slot

Note: Please see the Compaq StorageWorks Fibre Channel RAID Array 8000, ESA12000 QuickSpecs for FC

Hubs, FC switches, platform software, host adapters, disks and options for complete solutions at:

http://www.compaq.com/products/quickspecs/North_America/10418_na.html

Please note that all Web sites are available in English only.

400553-B22
400552-B22
380570-B22

400554-B21
400700-B21
380568-B21

DA-10635 North America — Version 13 — December 18, 2000 11

QuickSpecs

Options

Compaq ProLiant DL580

StorageWorks Enterprise Storage
Array 12000

StorageWorks Modular Array
6000

StorageWorks Modular Array
8000/Enterprise Modular Array
12000

ESA Building Blocks

High-capacity/General Business – Dual Controllers 48 slots, 60 Hz (Opal)
High bandwidth Quad controllers 48 slots, 60 Hz (Opal)

Single expansion Dual controllers 24 slots, 25U extra cabinet space, 60 Hz (Opal)
Expansion enclosure 48 slots, 60 Hz (Opal)

Note: Please see the Compaq StorageWorks Fibre Channel RAID Array 8000, ESA12000 QuickSpecs for FC

Hubs, FC switches, platform software, host adapters, disks and options for complete solutions at:

http://www.compaq.com/products/quickspecs/North_America/10418_na.html

Please note that all Web sites are available in English only.

MA6000 D14
MA6000 S14

Note: Please see the Compaq StorageWorks MA6000 QuickSpecs for FC Hubs, FC switches, platform software,

host adapters, disks and options for complete solutions at:

http://www.compaq.com/products/quickspecs/North_America/10418_na.html

Please note that all Web sites are available in English only.

EMA12000 D14 60 Hz
EMA12000 S14 60 Hz
MA8000 60 Hz
EMA12000 Blue 60 Hz

Note: Options include controller, solution kits, ACS. MA8000/EMA12000 includes controller shelf, drive shelves

and cabinet. Packaging upgrade to RA8000/ESA12000.

Note: Please see the Compaq StorageWorks MA8000/EMA12000 QuickSpecs for FC Hubs, FC switches, platform

software, host adapters, disks and options for complete solutions at:

http://www.compaq.com/products/quickspecs/North_America/10418_na.html

Please note that all Web sites are available in English only.

400557-002

400555-002

400559-002

380640-002

187738-B21
187739-B21

175990-B21
175991-B21
175992-B21
175993-B21

StorageWorks Options

Uninterruptible Power Systems –
Rack

Fibre Channel Tape Controller – II
Fibre Channel Storage Switch 16
Fibre Channel Storage Switch 8
Fibre Channel SAN Switch/8 with Fabric Operating Software
Fibre Channel SAN Switch/16 with Fabric Operating Software
F200 Clustering Kit

Rack-Mountable UPS R1500 (100 to 127 VAC)
Compaq UPS R3000 XR (120V)
Compaq UPS R3000 XR (208V)
Rack-Mountable UPS R6000 (208V)
R6000 Extended Runtime Module

Note: Available for the UPS R6000 Models only.

Extended Runtime Module, R3000 XR

Note: Available for the UPS R3000 XR Models only.

Six-Port Card

Note: Available for the new UPS “XR” Models only.

SNMP/Serial Port Card

Note: Available for the new UPS “XR” Models only.

SNMP-EN Adapter

152975-001
380578-B21
380591-B21
158222-B21
158223-B21
380357-B21

242704-001

192186-001

192186-002

347207-001
347224-B21

192188-B21
192185-B21
192189-B21
347225-B21

DA-10635 North America — Version 13 — December 18, 2000 12

QuickSpecs

Options

Compaq ProLiant DL580

Uninterruptible Power Systems –
Rack (continued)

Compaq Rack 9000 Series (Opal)

Rack Options for Compaq Rack
9000 Series

High to Low Voltage Transformer (250VA)

Multi-Server UPS Card
Scalable UPS Card

Compaq Rack Builder for configuration assistance at

www.compaq.com/products/storageworks/rack_accessories/rackbuilderpro2.html.

Compaq Rack 9142 (42U) – Pallet
Compaq Rack 9142 (42U) – Shock Pallet
Compaq Rack 9142 (42U) – Cr ated
Compaq Rack 9136 (36U) – Pallet
Compaq Rack 9136 (36U) – Shock Pallet
Compaq Rack 9136 (36U) – Cr ated
Compaq Rack 9122 (22U) – Pallet
Compaq Rack 9122 (22U) – Shock Pallet
Compaq Rack 9122 (22U) – Cr ated

Note: -B22 part numbers are used to ship configured racks (by custom systems, VARs and Channels)

-B23 part numbers are used for air shipments

Baying/Coupling Kit
Rack 9142 Side Panel
Rack 9136 Side Panel
Ballast Option Kit
Stabilizer Option Kit
Rack Rail Adapter Kit (25″ depth)
Fan (110 VAC) Roof Mount
Fan (220 VAC) Roof Mount
9142 Extension Kit
Grounding Rack Option Kit
Cable Management D-Rings Kit
Rack Blanking Panels (1U)
Rack Blanking Panels (2U)
Rack Blanking Panels (3U)
Rack Blanking Panels (4U)
Rack Blanking Panels (5U)
9136 Extension Kit
9142 Short Rear Door
9136 Short Rear Door

388643-B21

123508-B21
123509-B21

120663-B21
120663-B22
120663-B23
120664-B21
120664-B22
120664-B23
120665-B21
120665-B22
120665-B23

120669-B21
120670-B21
120671-B21
120672-B21
120673-B21
120675-B21
120677-B21
120678-B21
120679-B21
120682-B21
168233-B21
189453-B21
189453-B22
189453-B23
189453-B24
189453-B25
218216-B21
218217-B21
218218-B21

Rack Options for Compaq Rack
7000 Series

DA-10635 North America — Version 13 — December 18, 2000 13

Rack Sidewall Kit (42U only)
Coupling Kit (42U only)
Stabilizing Feet (42U only)
High Air Flow Rack Door Insert for 7122
High Air Flow Rack Door Insert for 7142
High Air Flow Rack Door Insert for 7142 (six pack)
Compaq Rack Extension Kit for 7142

165652-001

165664-001

189907-001
157847-B21
327281-B21
327281-B22
154392-B21

QuickSpecs

Options

Compaq ProLiant DL580

Rack Options for Compaq Rack
7000 and 9000 Series

Sliding Shelf Kit
Monitor Utility Shelf
Rack Blanking Panel Kit for Rack 7000 series (Beach Gray)
Rack Blanking Panel Kit for Rack 9000 series(Opal)
Compaq Networking Cable Management Kit
Compaq Networking Recessed Rail Management Kit
Compaq Power Distribution Unit-24A Low Voltage PDU
Compaq Power Distribution Unit-16A High Voltage PDU (cord attached)
Compaq Power Distribution Unit-16A High Voltage, 16A (detachable cord)
Compaq Power Distribution Unit-24A High Voltage
Compaq Dual Input Power Distribution Unit-24A High Voltage
Compaq High Voltage PDU Right Angled Cable Kit (IEC13-IEC14)

Note: The 10-Amp AC cord which ships standard with the Compaq ProLiant DL580 utilizes a right angle plug on

the server side (the side that plugs into the server) to avoid interference with the Cable Management Arm.
Compaq High Voltage PDUs ship standard with 15-Amp AC cords that incorporate straight plugs on the
server side. The optional Compaq High Voltage PDU Right Angled Cable Kit (142257-004) provides a right
angle version of the 15-Amp AC cord. When deploying Compaq High Voltage PDUs with the Compaq
ProLiant DL580, you may choose to simplify cable management at the rear of the server chassis by

installing this option kit.

Server Console Switch 1 x 2 port (100 to 230 VAC)
Server Console Switch 1 x 4 port (100 to 230 VAC)
Server Console Switch 1 x 8 port (100 to 230 VAC)
Server Console Switch 2 x 8 port (100 to 230 VAC)
Server Console Switch 2 x 8 port (48 VDC)
CPU to Server Console Cable, 12′
CPU to Server Console Cable, 20′
CPU to Server Console Cable, 40′
CPU to Server Console Cable, 3′
CPU to Server Console Cable, 6′
CPU to Server Console Cable (Plenum Rated) 20′
CPU to Server Console Cable (Plenum Rated) 40′
Switch Box Connector Kit (115 V)
Switch Box Connector Kit (230 V)
Keyboard with Hot Keys and Trackball
Rack Internal Trackball Keyboard (Opal)
1U Rack Keyboard Drawer
Keyboard/Monitor/Mouse extension cables

332564-B21
303606-B21

169940-001
169940-B21
292407-B21
292406-B21

295363-001

295363-002
295363-B21

295363-003

191186-001

142257-004

120206-001

400336-001

400337-001

400338-001
400542-B21
110936-B21
110936-B22
110936-B23
110936-B24
110936-B25
149363-B21
149364-B21

144007-001

144007-002

158649-001

185152-406
338056-B21

169989-001

Rack Options for Third Party
Cabinet Racks

CarePaqs

DA-10635 North America — Version 13 — December 18, 2000 14

Depth Adjustable Fixed Rails

Hardware Services 4-Hour On-site Service

4-Hour On-site Service, 5-Day x 9-Hour Coverage, 3 Years (2-5-2 Part Number for
U.S.)

4-Hour On-site Service, 5-Day x 9-Hour Coverage, 3 Years (2-5-2 Part Number for
Canada)

4-Hour On-site Service, 5-Day x 9-Hour Coverage, 3 Years (6-3 Part Number for
U.S.)

4-Hour On-site Service, 5-Day x 9-Hour Coverage, 3 Years (6-3 Part Number for
Canada)

4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years (2-5-2 Part Number
for U.S.)

332558-B21

FM-MI4HR-36

FP-MI4HR-36

401783-002

401783-122

FM-MI724-36

QuickSpecs

Options

Compaq ProLiant DL580

CarePaqs (continued) 4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years (2-5-2 Part Number

for Canada)
4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years (6-3 Part Number for

U.S.)
4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years (6-3 Part Number for

Canada)

Installation & Start-up Services

Hardware Installation (2-5-2 Part Number for U.S.)
Hardware Installation (2-5-2 Part Number for Canada)
Hardware Installation (6-3 Part Number for U.S.)
Hardware Installation (6-3 Part Number for Canada)
O/S & Hardware Installation (2-5-2 Part Number for U.S.)

(Hardware installation plus two days O/S start-up activity (installation,
configuration, network access & orientation))

O/S & Hardware Installation (6-3 Part Number for U.S.)
(Hardware installation plus two days O/S start-up activity (installation,
configuration, network access & orientation))

Business Solutions Priority Service Plan – Priority Level

5 x 9 4-hour H/W, 5 x 9 2-hour O/S (NT & NetWare), Three Years (2-5-2 Part
Number for U.S.)

5 x 9 4-hour H/W, 5 x 9 2-hour O/S (NT & NetWare), Three Years (2-5-2 Part
Number for Canada)

5 x 9 4-hour H/W, 5 x 9 2-hour O/S (NT & NetWare), Three Years (6-3 Part
Number for U.S.)

FP-MI724-36

401782-002

401782-122

FM-MIINS-IN

FP-MIINS-IN

401793-002

401793-122

FP-CXHSI-03

160557-002

FP-CX103-36

FP-CZ103-36

155325-002

5 x 9 4-hour H/W, 5 x 9 2-hour O/S (NT & NetWare), Three Years (6-3 Part
Number for Canada)

Business Solutions Priority Service Plan – Priority 24 Level

7 x 24 4-hour H/W, 7 x 24 2-hour O/S (NT & NetWare), Three years (2-5-2 Part
Number for U.S.)

7 x 24 4-hour H/W, 7 x 24 2-hour O/S (NT & NetWare), Three years (6-3 Part
Number for U.S.)

Business Solutions Priority Service Plan – Priority Plus Level

7 x 24 4-hour H/W, 7 x 24 1-hour O/S (NT & NetWare), SPS account review,
Three Years
(2-5-2 Part Number for U.S.)

7 x 24 4-hour H/W, 7 x 24 1-hour O/S (NT & NetWare), SPS account review,
Three Years
(2-5-2 Part Number for Canada)

7 x 24 4-hour H/W, 7 x 24 1-hour O/S (NT & NetWare), SPS account review,
Three Years
(6-3 Part Number for U.S.)

7 x 24 4-hour H/W, 7 x 24 1-hour O/S (NT & NetWare), SPS account review,
Three Years
(6-3 Part Number for Canada)

155325-122

FP-CX203-36

155329-002

FP-CX303-36

FP-CZ303-36

155333-002

155333-122

DA-10635 North America — Version 13 — December 18, 2000 15

QuickSpecs

r

r

r

Options

Compaq ProLiant DL580

CarePaqs (continued)

Business Solutions Priority Service Plan – Priority Premier Level

7 x 24 2-hour H/W, 7 x 24 1-hour O/S (NT & NetWare), SPS Account Review,
Proactive Management Review, named S/w rep, Three Years (2-5-2 Part Number
for U.S.)

7 x 24 2-hour H/W, 7 x 24 1-hour O/S (NT & NetWare), SPS Account Review,
Proactive Management Review, named S/w rep, Three Years (2-5-2 Part Number
for Canada)

7 x 24 2-hour H/W, 7 x 24 1-hour O/S (NT & NetWare), SPS Account Review,
Proactive Management Review, named S/w rep, Three Years (6-3 Part Number fo
U.S.)

7 x 24 2-hour H/W, 7 x 24 1-hour O/S (NT & NetWare), SPS Account Review,
Proactive Management Review, named S/w rep, Three Years (6-3 Part Number for
Canada)

Business Solutions Priority Service Plan – Priority Executive Premier Level

7 x 24 2-hour H/W, 7 x 24 30-minute O/S (NT & NetWare), SPS Account Review,
Proactive Management Review, named S/w rep, Three Years (2-5-2 Part Number
for U.S.)

7 x 24 2-hour H/W, 7 x 24 30-minute O/S (NT & NetWare), SPS Account Review,
Proactive Management Review, named S/w rep, Three Years (2-5-2 Part Number
for Canada)

7 x 24 2-hour H/W, 7 x 24 30-minute O/S (NT & NetWare), SPS Account Review,
Proactive Management Review, named S/w rep, Three Years (6-3 Part Number fo
U.S.)

7 x 24 2-hour H/W, 7 x 24 30-minute O/S (NT & NetWare), SPS Account Review,
Proactive Management Review, named S/w rep, Three Years (6-3 Part Number fo
Canada)

Note: For more information, customer/resellers can contact www.Compaq.com/services. Please note this web site

is available in English only.

155341-122

FP-CX503-36

FP-CZ503-36

155337-002

155337-122

FP-CX703-36

FP-CZ703-36

155341-002

DA-10635 North America — Version 13 — December 18, 2000 16

QuickSpecs

Compaq ProLiant DL580

Memory

Compaq ProLiant DL580

STANDARD MEMORY

512-MB PC100-MHz Advanced ECC SDRAM DIMM installed (4 x 128-MB SDRAM DIMM)

STANDARD MEMORY PLUS OPTIONAL MEMORY

Up to 12,800-MB memory is available with the optional installation of PC100-MHz Advanced ECC SDRAM DIMM memory kits.

STANDARD MEMORY REPLACED WITH OPTIONAL MEMORY

Up to 16,384-MB of memory is available with the removal of the standard 512-MB of memory and the optional installation of PC100-MHz
Advanced ECC SDRAM DIMM memory kits.

Note: Memory must be added in banks of four DIMMS. This chart does not represent all possible memory configurations.

Memory Slot

Standard 512MB 128 MB 128 MB 128 MB 128 MB Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty

Optional 12,800 MB 128 MB 128 MB 128 MB 128 MB 1024 MB 1024 MB 1024 MB 1024 MB 1024 MB 1024 MB 1024 MB 1024 MB 1024 MB 1024 MB 1024 MB 1024 MB

Maximum 16,384 MB 1024 MB 1024 MB 1024 MB 1024 MB 1024 MB 1024 MB 1024 MB 1024 MB 1024 MB 1024 MB 1024 MB 1024 MB 1024 MB 1024 MB 1024 MB 1024 MB

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16

Following are memory options available from Compaq:

• 4096-MB PC100-MHz Advanced ECC SDRAM Memory Option Kit (4 x 1024 MB) 189083-B21

• 2048-MB PC100-MHz Advanced ECC SDRAM Memory Option Kit (4 x 512 MB) 189082-B21

• 1024-MB PC100-MHz Advanced ECC SDRAM Memory Option Kit (4 x 256 MB) 189081-B21

• 512-MB PC100-MHz Advanced ECC SDRAM Memory Option Kit (4 x 128 MB) 189080-B21

DA-10635 North America — Version 13 — December 18, 2000 17

QuickSpecs

Storage

Compaq ProLiant DL580

A

B 3.5 inch Diske tte Drive
C High Speed IDE CD-ROM

0-3

Hot Plug Power Supplies

Wide Ultra2/Ultra3 Drive Cage (4 x 1″)

DRIVE SUPPORT

Quantity
Supported

Removable Media

1.44-MB Diskette Drive Up to 1 C Integrated
IDE CD-ROM Drive Up to 1 B Integrated IDE

Hard Drives

Wide Ultra3 Hot Pluggable Drives

Note: Wide Ultra3 SCSI drives require the purchase and installation of Wide Ultra3 Controllers or Adapters to run at Wide Ultra3

speeds.

1-inch

36.4-GB 10,000 rpm

18.2-GB 10,000 rpm

9.1-GB 10,000 rpm

18.2-GB 15,000 rpm

9.1-GB 15,000 rpm

Wide Ultra2 Hot Pluggable Drives

1-inch

18.2-GB

9.1-GB

Up to 4 0-3 Integrated Smart Array Controller

Up to 4 0-3 Integrated Smart Array Controller

Position
Supported Controller

Smart Array 431 Controller
Smart Array 3200 Controller
Smart Array 4200 Controller
Smart Array 5300 Controller
64-bit/66-MHz Single Channel Wide Ultra3 SCSI Adapter
64-bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter

Smart Array 431 Controller
Smart Array 3200 Controller
Smart Array 4200 Controller

Smart Array 5300 Controller
64-bit/66-MHz Single Channel Wide Ultra3 SCSI Adapter
64-bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter

External Storage

StorageWorks Enclosure
4200/4300 Family

(supports Ultra2/Ultra3 drives
only)

ProLiant Storage System
Models UE
ProLiant Storage System
Models U2

(supports Wide-Ultra SCSI-3
drives only)

SCSI Storage Expander II Up to 10

StorageWorks RAID Array
4100 Kit

DA-10635 North America — Version 13 — December 18, 2000 18

Up to 10

(2 per channel
SCSI
controller)

Up to 10

(2 per channel
SCSI
controller)

(2 per channel
SCSI
controller)

Up to 11 External Fibre Channel Host Adapter

External Integrated Smart Array Controller

External

External

Smart Array 431 Controller
Smart Array 3200 Controller
Smart Array 4200 Controller
Smart Array 5300 Controller
64-bit/66-MHz Single Channel Wide Ultra3 SCSI Adapter
64-bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter

Smart Array 3200 Controller
Smart Array 4200 Controller
Smart Array 5300 Controller
64-bit/66-MHz Single Channel Wide Ultra3 SCSI Adapter
64-bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter

Smart Array 3200 Controller
Smart Array 5300 Controller

64-bit/66-MHz Single Channel Wide Ultra3 SCSI Adapter
64-bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter

QuickSpecs

Compaq ProLiant DL580

Storage

DRIVE SUPPORT (continued)

Maximum Internal Hot Plug Storage Cap a ci t y – (S C S I At tac h ed)

Internal
External 4.368 TB (10 ProLiant Storage Systems, each with 12 x 36.4-GB 1″ hard drives)
Total 4.513 TB

Maximum Internal Hot Plug Storage Capacity – (External StorageWorks Enclosure Attached)

Internal
External 5.096 TB (10 StorageWorks Enclosures, each with 14 x 36.4-GB hard drives)
Total 5.241 TB

Maximum Storage Capacity – (External RAID Array 4100 Attached)

Internal
External 28.828 TB (6 PCI slots x 11 Raid Array 4000, each with 12 x 36.4-GB 1″ hard drives)
Total 28.974 TB

145.6 GB (4 x 36.4-GB Wide Ultra3 SCSI 1″ Drives)

145.6 GB (4 x 36.4-GB Wide Ultra3 SCSI 1″ Drives)

145.6 GB (4 x 36.4-GB Wide Ultra3 SCSI 1″ Drives)

DA-10635 North America — Version 13 — December 18, 2000 19

QuickSpecs

Technical Specifications

Compaq ProLiant DL580

System Unit Tower

Dimensions (HxWxD) 6.94 x 19 x 28.3 in/ 17.6 x 48.3 x 71.9 cm
Chassis Footprint (HxWxD) 6.94 x 19 x 25 in/17.6 x 48.3 x 63.5 cm
Weight

No hard drives installed,
one power supply

Input Requirements

BTU Rating
SCSI Connector
Power Supply Output Power

(per power supply)

Temperature Range

Relative Humidity

(non-condensing)

Temperature

66 lbs/29.9 kg

Rated Input Voltage
Rated Input Frequency

Input Power
Rated Input Current
2291 BTU

One 68-pin connector supporting Wide Ultra2 SCSI
Rated Steady-State Power

Maximum Peak Power
Operating
Non-operating

Shipping
Operating

Non-operating

101.7°F/38.7°CMaximum Wet Bulb

90 to 120 VAC/200 to 240 VAC
50 to 60 Hz

600W @ 110 VAC/600W @ 220 VAC
7A (90 VAC), 5A (120 VAC), 3A (210 VAC)

450W/450W (lowline/highline)
480W/480W (lowline/highline)
50° to 95°F/10° to 35°C
–20° to 140°F/–29° to 60°C

–22° to 122°F/–30° to 50°C
20% to 80%

5% to 90%

1.44-MB Diskette Drive

Acoustic Noise

Diskette Size
LED Indicators (front panel)

Read/Write Capacity per
Diskette (high/low density)

Drive Supported
Drive Height
Drive Rotation
Transfer Rate (high/low)
Bytes/Sector
Sectors/Track (high/low)
Tracks/Side (high/low)
Access Times

Cylinders (high/low)
Read/Write Heads

Idle
(Fixed Disk Drives Spinning)

L

(BELS) 7.2

WAd

(dBA) 53

L

pAm

Operating
(Random Seeks to Fixed Disks)

L

(BELS)

WAd

L

(dBA)

pAm

3.5 in
Green

1.44 MB/720 KB
One

One-third
300 rpm
500/250 Kb/s
512
18/9
80/80
Track-to-Track (high/low) 3/6 ms

Average (high/low) 169/94 ms
Settling Time 15 ms
Latency Average 100 ms
80/80

Two

7.3
54

DA-10635 North America — Version 13 — December 18, 2000 20

QuickSpecs

y

y

y

y

Technical Specifications

Compaq ProLiant DL580

Hot Plug Wide Ultra3 SCSI
Hard Drives

36.4 GB 10K Capacity 36400 MB

176496-B22

18.2 GB 10K Capacity 18209.3 MB
142673-B22

Height 1 in/25.4 mm
Width
Interface Wide Ultra3 SCSI

Transfer Rate S

(Maximum)

Seek Time

(typical reads, including
settling)

Physical Configuration Logical Blocks 71,132,000
Operating Temperature 50° to 95°F/10° to 35°C

Height 1 in/25.4 mm
Width 3.5 in/88.9 mm

Interface
Transfer Rate S

(Maximum)

Seek Time

(typical reads, including
settling)

Physical Configuration Logical Blocks 35,565,080
Operating Temperature 50° to 95°F/10° to 35°C

nchronous

nchronous

3.5 in/88.9 mm

160 MB/s
Single Track 0.8 ms

Average 5.2 ms
Full-Stroke 12 ms
Rotational Speed 10,000 rpm

Wide Ultra3 SCSI
160 MB/s

Single Track 0.8 ms
Average

Full-Stroke 12 ms
Rotational Speed 10,000 rpm

5.2 ms

9.1 GB 10K Capacity 9100.0 MB
142671-B22

18.2 GB 15K Capacity 18209.3 MB
188122-B22

Height 1 in/25.4 mm
Width 3.5 in/88.9 mm

Interface
Transfer Rate S

(Maximum)

Seek Time

(typical reads, including
settling)

Physical Configuration Logical Blocks 17,773,524
Operating Temperature 50° to 95°F/10° to 35°C

Height 1 in/25.4 mm
Width 3.5 in/88.9 mm

Interface
Transfer Rate S

(Maximum)

Seek Time

(typical reads, including
settling)

Physical Configuration Logical Blocks 35,565,080
Operating Temperature 50° to 95°F/10° to 35°C

nchronous

nchronous

Wide Ultra3 SCSI
160 MB/s

Single Track 0.8 ms
Average

Full-Stroke 12 ms
Rotational Speed 10,000 rpm

Wide Ultra3 SCSI
160 MB/s

Single Track 0.8 ms
Average

Full-Stroke 12 ms
Rotational Speed 15,000 rpm

5.0 ms

5.0 ms

DA-10635 North America — Version 13 — December 18, 2000 21

QuickSpecs

y

y

y

Technical Specifications

Compaq ProLiant DL580

Hot Plug Wide Ultra3 SCSI
Hard Drives (continued)

Hot Plug Wide Ultra2 SCSI
Hard Drives

9.1 GB 15K Capacity 9100.0 MB

188120-B22

18.2 GB Capacity 18209.3 MB
388144-B22

Height 1 in/25.4 mm
Width 3.5 in/88.9 mm

Interface
Transfer Rate S

(Maximum)

Seek Time

(typical reads, including
settling)

Physical Configuration Logical Blocks 17,773,524
Operating Temperature 50° to 95°F/10° to 35°C

Height 1 in/25.4 mm
Width

Interface Wide Ultra2 SCSI
Transfer Rate S

(Maximum)

Seek Time

(typical reads, including
settling)

Physical Configuration
Operating Temperature

nchronous

nchronous

Wide Ultra3 SCSI
160 MB/s

Single Track 0.8 ms
Average

Full-Stroke 12 ms
Rotational Speed 15,000 rpm

3.5 in/88.9 mm

80 MB/s
Single Track

Average
Full-Stroke
Rotational Speed
Logical Blocks 35,565,080
50° to 95°F/10° to 35°C

5.0 ms

0.8 ms

7.0 ms
15 ms
7200 rpm

9.1 GB Capacity 9100.0 MB
123065-B22

Height 1 in/25.4 mm
Width 3.5 in/88.9 mm

Interface
Transfer Rate S

(Maximum)

Seek Time

(typical reads, including
settling)

Physical Configuration
Operating Temperature

nchronous

Wide Ultra2 SCSI
80 MB/s

Single Track
Average
Full-Stroke
Rotational Speed
Logical Blocks 17,773,524
50° to 95°F/10° to 35°C

0.8 ms

7.0 ms
15 ms
7200 rpm

DA-10635 North America — Version 13 — December 18, 2000 22

QuickSpecs

Technical Specifications

Compaq ProLiant DL580

24X Max (or higher) IDE
CD-ROM Drive Slim Line

Disk

Block Size Mode 1 2,048

Interface IDE (ATAPI)

Access Times (typical) Random 100 ms

Audio Output Level Line-Out 0.7 VRMS at 47 kOhms

Applicable Disk CD-ROM (Mode 1 and 2)

CD-DA, CD-XA (Mode 2, Form 1 and 2)
Photo CD (Single and Multi-session)
Mixed Mode (Audio and Data combined)

Capacity 540 MB (Mode 1, 12 cm)

650 MB (Mode 2, 12 cm)

Diameter
Rotational Speed
Center Hole
Thickness
Track Pitch

Mode 2 2,340, 2,336, 1,024 bytes
CD-DA 2,352 bytes
CD-XA 2,328 bytes

Full-Stroke 2000 ms

Headphone 0.6 VRMS at 32 kOhms (maximum volume)

4.7 in, 3.15 in/12 cm, 8 cm
4200 rpm maximum

0.6 in/15 mm diameter

1.2 mm

1.6 µm

Data Transfer Rate Sustained 150 KB/s (single)

Burst 2100 to 3600 KB/s

Cache Buffer 128 KB

Start-up Time (typical) < 7 seconds

Stop Time < 4 seconds

Laser Parameters Type Semiconductor Laser GaA1As

Wave Length 780 ± 25 nm
Divergence Angle 53.5° ± 1.5°
Output Power 0.14 mW

Operating Conditi ons Temperature 41° to 113°F/5° to 45°C

Humidity 10% to 80%

Dimensions (HxWxD, maximum) 1.69 x 5.75 x 8.19 in/4.29 x 15 x 20.8 cm

Weight 2.66 lbs/1.2 kg

DA-10635 North America — Version 13 — December 18, 2000 23

QuickSpecs

A

Technical Specifications

Compaq ProLiant DL580

Integrated Smart Array
Controller

Data Compatible with all Smart Array Controllers Yes
Instant Upgrades to other Smart Array Controllers Yes
Consistent Software Manageability Tools Yes
PCI Bus 32-bit, 33 MHz (integrated on server board)
PCI Peak Data Transfer Rate 133 MB/s
SCSI Protocols Supported Ultra2, Wide-Ultra
SCSI Peak Data Transfer Rate 80 MB/s

Note: For ProLiant servers having TWO internal drive bays on separate SCSI ports: SCSI Peak Data Transfer Rate

is 160 MB/s total; 80 MB/s per channel and Channels is 2.

Channels 1

Note: For ProLiant servers having TWO internal drive bays on separate SCSI ports: SCSI Peak Data Transfer Rate

is 160 MB/s total; 80 MB/s per channel and Channels is 2.

SCSI Ports (external/internal) 0/1

Note: For ProLiant servers having TWO internal drive bays on separate SCSI ports: SCSI Peak Data Transfer Rate

is 160 MB/s total; 80 MB/s per channel and Channels is 2.

Drives Supported (maximum) Maximum = total number of drives

Note: Maximum is the total number of internal drives on each specific ProLiant server.

Cache 8-MB read only
RAID Support 0, 1, 0+1, 5
Logical Drives (maximum) 32
Online Configuration Yes
Online Capacity Expansion Yes
Logical Drive Capacity Extension Yes
Online Stripe Size Migration Yes
Online RAID Level Migration Yes
Online Spare Support Yes
Automatic Data Recovery Yes
Drive Roaming Yes
Redundant Controllers No

NIC 64 PCI Dual Port 10/100

DA-10635 North America — Version 13 — December 18, 2000 24

Network Interface 10Base-T/100Base-TXCompaq NC3134 Fast Ethernet
Compatibility PCI v2.2, IEEE 802.3/802.3u compliant
Data Transfer Method 64-bit/66-MHz bus -master PCI

Network Transfer Rate 10Base-T (Half-Duplex),

Connector Dual RJ-45
I/O Address and

Interrupt
Cable Support

10Base-2
10Base-T (Full-Duplex) 20 Mb/s
100Base-TX (Half-

Duplex)
100Base-TX (Full-

Duplex)

utomatic Configuration

10Base-T100Base-TX

10 Mb/s

100 Mb/s
200 Mb/s

Categories 3, 4 or 5 UTP (2 or 4 pair); up to 328 feet (100
meters)

Category 5 UTP (2 pair); up to 328 feet (100 meters)

QuickSpecs

Technical Specifications

Compaq ProLiant DL580

Smart Array 431
Controller

Data Compatible with all Smart Array Controllers Yes
Instant Upgrades to other Smart Array Controllers Yes
Consistent Software Manageability Tools Yes
PCI Bus 64-bit, 66MHz
PCI Peak Data Transfer Rate 533 MB/s
SCSI Protocols Supported Ultra3, Ultra2, Wide-Ultra
SCSI Peak Data Transfer Rate 160 MB/s
Channels 1
SCSI Ports (external/internal) 1/1
Drives Supported (maximum) 14

Note: Drives Supported (maximum) is based on use of Compaq Stor ageWorks Enclosure 4200/4300 family (14 hard

disk drive enclosure).

Cache 16-MB cache engine
RAID Support 0, 1, 0+1 5
Logical Drives (maximum) 32
Online Configuration Yes
Online Capacity Expansion Yes
Logical Drive Capacity Extension Yes
Online Stripe Size Migration Yes
Online RAID Level Migration Yes
Online Spare Support Yes
Automatic Data Recovery Yes
Drive Roaming Yes
Redundant Controllers No

Smart Array 3200
Controller

Data Compatible with all Smart Array Controllers Yes
Instant Upgrades to other Smart Array Controllers Yes
Consistent Software Manageability Tools Yes
PCI Bus 64-bit, 33 MHz
PCI Peak Data Transfer Rate 266 MB/s
SCSI Protocols Supported Ultra2, Wide-Ultra
SCSI Peak Data Transfer Rate 320 MB/s total, 80 MB/s per channel
Channels 4
SCSI Ports (external/internal) 4/2
Drives Supported (maximum) 56

Note: Drives Supported (maximum) is based on use of Compaq Stor ageWorks Enclosure 4200/4300 family (14 hard

disk drive enclosure).

Cache 64-MB battery backed read-write
RAID Support 0, 1, 0+1, 4, 5
Logical Drives (maximum) 32
Online Configuration Yes
Online Capacity Expansion Yes
Logical Drive Capacity Extension Yes
Online Stripe Size Migration Yes
Online RAID Level Migration Yes
Online Spare Support Yes
Automatic Data Recovery Yes
Drive Roaming Yes
Redundant Controllers No

DA-10635 North America — Version 13 — December 18, 2000 25

QuickSpecs

Technical Specifications

Compaq ProLiant DL580

Smart Array 4200
Controller

Data Compatible with all Smart Array Controllers Yes
Instant Upgrades to other Smart Array Controllers Yes
Consistent Software Manageability Tools Yes
PCI Bus 64-bit, 33 MHz
PCI Peak Data Transfer Rate 266 MB/s
SCSI Protocols Supported Ultra2, Wide-Ultra
SCSI Peak Data Transfer Rate 320 MB/s total, 80 MB/s per channel
Channels 4
SCSI Ports (external/internal) 4/2
Drives Supported (maximum) 56

Note: Drives Supported (maximum) is based on use of Compaq Stor ageWorks Enclosure 4200/4300 family (14 hard

disk drive enclosure).

Cache 64-MB battery backed read-write
RAID Support 0, 1, 0+1, 5
Logical Drives (maximum) 32
Online Configuration Yes
Online Capacity Expansion Yes
Logical Drive Capacity Extension Yes
Online Stripe Size Migration Yes
Online RAID Level Migration Yes
Online Spare Support Yes
Automatic Data Recovery Yes
Drive Roaming Yes
Redundant Controllers No

DA-10635 North America — Version 13 — December 18, 2000 26

QuickSpecs

Technical Specifications

Compaq ProLiant DL580

Smart Array 5300
Controller

Data Compatible with all Smart Array Controllers Yes
Instant Upgrades to other Smart Array Controllers Yes
Consistent Software Manageability Tools Yes
PCI Bus 64-bit, 66MHz
PCI Peak Data Transfer Rate 533 MB/s
SCSI Protocols Supported Ultra3, Ultra2, Wide-Ultra
SCSI Peak Data Transfer Rate 640 MB/s total, 160 MB/s per channel
Channels 2, 4
SCSI Ports (external/internal) 2 channel model: 2/2

4 channel model: 4/2
Drives Supported (maximum) 56

Note: Drives Supported (maximum) is based on use of Compaq Stor ageWorks Enclosure 4200 family. (14 hard disk

drive enclosure)

Cache 128, 64 or 32 MB battery backed read-write
RAID Support 0, 1, 0+1, 5, Advanced Data Guarding

Note: RAID ADG will be available as in the near future. For customers who have purchased the SA-5304/128 a

quick firmware upgrades to enable the technology will be available from www.compaq.com/smartarray. The
128-MB cache module with RAID ADG will also be available in the near future.

Note: RAID Support: Advanced Data Guarding (RAID ADG) is available with 128-MB versions of the SA-5300 only.

Logical Drives (maximum) 32
Online Configuration Yes
Online Capacity Expansion Yes
Logical Drive Capacity Extension Yes
Online Stripe Size Migration Yes
Online RAID Level Migration Yes
Online Spare Support Yes
Automatic Data Recovery Yes
Drive Roaming Yes
Redundant Controllers No

64-bit/66-MHz Dual
Channel Wide Ultra3
SCSI Adapter

Drives Supported
Storage Capacity
Data Transfer Method
Maximum SCSI Channel Transfer Rate
Maximum Transfer Rate per PCI Bus (peak) 532 MB/s per channel
SCSI Protocols

Electrical Protocol Low Voltage Differential (LVD )
SCSI Termination Active Termination
External SCSI Connectors Two 68-Pin VHDCI connectors
Internal SCSI Connectors Two 68-Pin Wide-Ultra SCSI-3 connectors

Up to 28 SCSI devices (14 per channel)

1.019 TB

64-bit/66-MHz PCI bus-master

160 MB/s per channel

Wide Ultra3 SCSI

Wide Ultra2 SCSI

Wide-Ultra SCSI-3

Fast SCSI-2

One 50-Pin Narrow Ultra connector

DA-10635 North America — Version 13 — December 18, 2000 27

QuickSpecs

Technical Specifications

Compaq ProLiant DL580

64-bit/66-MHz Single
Channel Wide Ultra3
SCSI Adapter

Compaq Rack 9142

(42U)(optional)

Compaq Rack 9136

(36U)(optional)

Drives Supported
Storage Capacity
Data Transfer Method
Maximum SCSI Channel Transfer Rate
Maximum Transfer Rate per PCI Bus (peak) 532 MB/s per channel
SCSI Protocols

Electrical Protocol Low Voltage Differential (LVD )
SCSI Termination Active Termination
External SCSI Connectors One 68-Pin Wide Ultra SCSI-3 connector
Internal SCSI Connectors

Dimensions

Height
Depth 35.8 in/909 mm 48 in/121.92 mm Opal
Width 23.7 in/603 mm 32 in/812.8 mm
Weight 253 lbs/114.84 kg 325 lbs/147.52 kg

Dimensions

Height
Depth 35.8 in/909 mm 48 in/121.92 mm Opal
Width 23.7 in/603 mm 32 in/812.8 mm
Weight 165 lbs/75 kg 234 lbs/106 kg

Total Cabinet

78.7 in/2,000 mm

Total Cabinet

68.6 in/1,742 mm

Up to 14 SCSI devices

254.8 GB

64-bit/66-MHz PCI bus-master

160 MB/s per channel

Wide Ultra3 SCSI

Wide Ultra2 SCSI

Wide-Ultra SCSI-3

Fast-Wide SCSI-2

Fast SCSI-2

Two 68-Pin Wide Ultra SCSI-3 connectors (one LVD and

one SE)

One 50-Pin Narrow Ultra connector

Shipping

83.38 in/2,168.65 mm

Shipping

75.25 in/1,911.35 mm

Color

Color

Compaq Rack 9122

(22U)(optional)

Dimensions

Height
Depth 35.8 in/909 mm 48 in/121.92 mm Opal
Width 24 in/610 mm 32 in/812.8 mm
Weight 176 lbs/79.89 kg 225 lbs/102.13 kg

Total Cabinet

43 in/1,092 mm

Shipping

52.25 in/1,327.15 mm

Color

DA-10635 North America — Version 13 — December 18, 2000 28
