QUICKSPECS
Overview
1 DA-10022-00A-010 — 01.31.2000
Compaq Deskpro EN Series
Minitower
1. V900 Color Monitor (optional)
2. Mouse
3. Enhanced Keyboard
4. Dual-State Power Button
5. Expansion Slots
6. Expansion Card Cage with Lift Levers
7. Smart Cover Lock
8. 200-Watt Power Supply
9. SMART III Ultra ATA 66 Hard Drive
10. 1.44-MB Diskette Drive
11. Expansion Bays
12. CD-ROM Drive
WHAT
'
S NEW
• Sound Blaster PCI 128 Audio
Sound Card wit h internal
Premier•Sound
• 8X/4X/32X CD-RW Drive
• SuperDisk (LS-120) 2X Hi gh
Capacity Floppy Drive
• Easy Access Keyboard
AT A GLANCE
• 100- or 133-MHz Front Side Bus
models
• Intel Pentium
®
III processor (133
MHz) 733-, 667- or 600E-MHz
• Intel Pentium III processors
(100 MHz) 500, 5 50, 600, 650 or
700 MHz
• Compaq Premier•Sound™
• Compaq Intelligent Manageability
• Dual Installation Windows 95/98
(End user must make a one-time
selection betwe en Win do ws 95
and Windows 98. If end user
desires the rejected product(s)
after selection is made, the end
user must acquire and pay for
rejected product se par at ely .) ,
Windows 95, Windows 98, or
Windows NT 4.0 pre-installed
(model dependent)
• Protected by Compaq Serv ices,
including a thr ee-year, Limited
Warranty
- Terms and conditions
vary by country. Certain
restricti ons and exclusions apply.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Standard Features
2 DA-10022-00A-010 — 01.31.2000
Compaq Deskpro EN Series
Minitower
Processor
Choice of Intel Pentium III Processor
Upgradability
Allows for upgrade of processor, memory, graphics and hard drive
Network Controller
Intel PRO/100+ Management Adapter
Note: Deskpro EN Series Minitower models with Intel Pentium III 500-MHz processor transition to the Intel
PRO/100+ Management Adapter effective May 17, 1999.
Expansion Slots
PCI 5
PCI/ISA 2
AGP 1
Note: Availability will depend on configuration.
PCI 4
ISA 1
PCI/ISA 1
AGP 1
Note: Availability will depend on configuration.
Note: 820 chipset includes one PCI/ISA slot
Expansion Bays
Internal 1
External 4
Note: Availability will depend on configuration.
Storage
Diskette Drive 1.44 MB
CD-ROM Drive One of the following:
40X Max CD-ROM Drive
32X Max CD-ROM Drive
Hard Drives One of the following:
13.5-GB 7200 rpm SMART III Ultra ATA 66
10.0-GB 7200 rpm SMART III Ultra ATA 66
Interfaces
Parallel 1
Serial 2
Pointing Device (mouse) 1
RJ-45 1
USB 2
SCSI 0
Keyboard 1
Video 1
Audio 4
Graphics – One of the following:
Matrox Millennium G400-SG AGP Graphics Controller with 16-MB SGRAM standard, not upgradable, providing
maximum resolution of 2048 x 1536 x 16.7M colors at 65 Hz
ATI RAGE PRO TURBO AGP 2X Graphics Controller card with 8-MB SDRAM standard not upgradable,
providing maximum resolution of 1280 x 1024 x 16.7M colors at 85 Hz
Integrated Intel 3D Graphics featuring Intel Dynamic Video Memory (DVM) technology with 8-MB video memory
equivalent performance, providing maximum resolution of 1280 x 1024 with 16.7M colors 85 Hz
Audio – One of the following:
Compaq Premier•Sound using ESS 1869 16-bit Full-Duplex audio, input/output jacks, internal speaker
MODELS
Deskpro EN Series Minitower
Available in multiple
configurations
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Standard Features
3 DA-10022-00A-010 — 01.31.2000
Compaq Deskpro EN Series
Minitower
AC97 with Compaq Premier•Sound (integrated), input/output jacks, internal speakers
Intelligent Manageability
Compaq Intelligent Manageability, a key component of PC Lifecycle Solutions, is the broad set of manageability
features found on all Compaq Deskpro desktops, Armada portables, Professional Workstation, and Proliant
server products. These best-of class features on PC clients comply with industry standards, such as DMI and
Wired for Management, while pioneering new ground in client manageability. Compaq introduced the industry’s
first line of manageable clients in 1995 and has been driving the industry ever since. With Compaq’s lifecycle
management philosophy, enterprises have all of the pieces for end-to-end management and proven tools for
hassle-free management of PCs and significantly lower Total Cost of Ownership.
Intelligent Manageability offers solutions in the areas of Initial Configuration and Deployment, Asset Tracking
and Security, Software Updating and Management, and Fault Notification and Recovery. For more information,
visit our website: www.compaq.com/im.
Operating System – One of the following:
Windows NT 4.0
Windows 98
Windows 95
Windows 95/98
(End user must make a one-time selection between Windows 95 and Windows 98. If end user desires the
rejected product(s) after selection is made, the end user must acquire and pay for rejected product
separately.)
Software
Insight Personal Edition
Computer Setup Utility
Microsoft Internet Explorer
Safety and Comfort Guide
Diagnostics for Windows
Intelligent Manageability Agent
Security
Setup password
Memory Change Alert
Ownership Tag
QuickLock/QuickBlank
Power-On Password
Removable Media Boot Control
Removable Media Write Control
Serial Port Control
Parallel Port Control
USB Port Control
Network Server Mode
Smart Cover Lock
Smart Cover Sensor
Power Supply
200 Watts
Service and Support
On-site Warranty: This Three-year limited warranty delivers three years of on-site, next business-day service for
parts and labor and includes free telephone support 7 x 24. Global coverage ensures that any product
purchased in one country and transferred to another non-restricted country will remain fully covered under the
original warranty.
Note: Terms and conditions vary by country. Certain restrictions and exclusions apply.
Note: On-site service may be provided pursuant to a service contract between Compaq and an authorized
Compaq third-party provider, and is not available in certain countries. Global warranty response times are
based on commercially reasonable best effort and may vary by country.
Note: Technical telephone support applies only to Compaq-configured Compaq and third-party Compaq-
qualified hardware and software. Toll-free calling and 7x24 support may not be available in some
countries.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Standard Features
4 DA-10022-00A-010 — 01.31.2000
Compaq Deskpro EN Series
Minitower
Models
P733/820/13.5/128/C/4 Front Side Bus 133-MHz Optical Drive 40X Max CD-ROM Drive
164024-xx2 Processor Intel Pentium III 733-MHz Hard Drive 13.5-GB Ultra ATA 66
Cache Memory 256-KB integrated L2 Graphics
Matrox Millennium G400-SG AGP
Controller
Memory Audio AC97 with Compaq Premier•Sound
Standard 128 MB Software Windows NT 4.0
Maximum 512 MB
P700/10+/128/C/4 Front Side Bus 100-MHz Optical Drive 40X Max CD-ROM Drive
165583-xx3 Processor Intel Pentium III 700-MHz Hard Drive 10.0-GB Ultra ATA 66
Cache Memory 256-KB integrated L2 Graphics ATI RAGE PRO TURBO AGP 2X
Controller
Memory Audio Compaq Premier•Sound
Standard 128 MB Software Windows NT 4.0
Maximum 768 MB
P667/820/13.5/128/C/4 Front Side Bus 133-MHz Optical Drive 40X Max CD-ROM Drive
141536-xx2 Processor Intel Pentium III 667 MHz Hard Drive 13.5-GB Ultra ATA 66
Cache Memory 256-KB integrated L2 Graphics Matrox Millennium G400-SG AGP
Controller
Memory Audio AC97 with Compaq Premier•Sound
Standard 128 MB Software Windows NT 4.0
Maximum 512 MB
P667/820/13.5/128/C/9 Front Side Bus 133-MHz Optical Drive 40X Max CD-ROM Drive
141536-xx3 Processor Intel Pentium III 667 MHz Hard Drive 13.5-GB Ultra ATA 66
Cache Memory 256-KB integrated L2 Graphics Matrox Millennium G400-SG AGP
Controller
Memory Audio AC97 with Compaq Premier•Sound
Standard 128 MB Software Windows 95/98
Maximum 512 MB
P650/10+/128/C/4
Front Side Bus 100-MHz Optical Drive 40X Max CD-ROM Drive
159707-002 Processor Intel Pentium III 650 MHz Hard Drive 10.0-GB Ultra ATA 66
Cache Memory 256-KB integrated L2 Graphics ATI RAGE PRO TURBO AGP 2X
Controller
Memory Audio Compaq Premier•Sound
Standard 128 MB Software Windows NT 4.0
Maximum 768 MB
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Standard Features
5 DA-10022-00A-010 — 01.31.2000
Compaq Deskpro EN Series
Minitower
P600E/820/13.5/128/C/4
Front Side Bus 133-MHz Optical Drive 40X Max CD-ROM Drive
155221-xx3 Processor Intel Pentium III 600-MHz Hard Drive 13.5-GB Ultra ATA 66
Cache Memory 256-KB integrated L2 Graphics Matrox Millennium G400-SG AGP
Controller
Memory Audio AC97 with Compaq Premier•Sound
Standard 128 MB Software Windows NT 4.0
Maximum 512 MB
P600E/820/13.5/128/C/9 Front Side Bus 133-MHz Optical Drive 40X Max CD-ROM Drive
155221-xx2
Processor Intel Pentium III 600-MHz Hard Drive 13.5-GB Ultra ATA 66
Cache Memory 256-KB integrated L2 Graphics Matrox Millennium G400-SG AGP
Controller
Memory Audio AC97 with Compaq Premier•Sound
Standard 128 MB Software Windows 95/98
Maximum 512 MB
P600/10+/128/C/4 Front Side Bus 100-MHz Optical Drive 32X Max CD-ROM Drive
154883-xx2 Processor Intel Pentium III 600-MHz Hard Drive 10.0-GB Ultra ATA 66
Cache Memory 512-KB ECC L2 Graphics
ATI RAGE PRO TURBO AGP 2X
Controller
Memory Audio Compaq Premier•Sound
Standard 128 MB Software Windows NT 4.0
Maximum 768 MB
P600/10+/128/C/5 Front Side Bus 100-MHz Optical Drive 32X Max CD-ROM Drive
166001-002 Processor Intel Pentium III 600-MHz Hard Drive 10.0-GB Ultra ATA 66
Cache Memory 512-KB ECC L2 Graphics ATI RAGE PRO TURBO AGP 2X
Controller
Memory Audio Compaq Premier•Sound
Standard 128 MB Software Windows 95
Maximum 768 MB
P550/10+/128/C/5 Front Side Bus 100-MHz Optical Drive 32X Max CD-ROM Drive
122786-xx2 Processor Intel Pentium III 550 MHz Hard Drive 10.0-GB Ultra ATA 66
Cache Memory 512-KB ECC L2 Graphics ATI RAGE PRO TURBO AGP 2X
Controller
Memory Audio Compaq Premier•Sound
Standard 128 MB Software Windows 95
Maximum 768 MB
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Standard Features
6 DA-10022-00A-010 — 01.31.2000
Compaq Deskpro EN Series
Minitower
P550/10+/128/C/4
Front Side Bus 100-MHz Optical Drive 32X Max CD-ROM Drive
122786-xx3 Processor Intel Pentium III 550-MHz Hard Drive 10.0-GB Ultra ATA 66
Cache Memory 512-KB ECC L2 Graphics ATI RAGE PRO TURBO AGP 2X
Controller
Memory Audio Compaq Premier•Sound
Standard 128 MB Software Windows NT 4.0
Maximum 768 MB
P500/10+/128/C/5 Front Side Bus 100-MHz Optical Drive 32X Max CD-ROM Drive
386185-xx2
Processor Intel Pentium III 500-MHz Hard Drive 10.0-GB Ultra ATA 66
Cache Memory 512-KB ECC L2 Graphics ATI RAGE PRO TURBO AGP 2X
Controller
Memory Audio Compaq Premier•Sound
Standard 128 MB Software Windows 95
Maximum 768 MB
P500/10+/128/C/4 Front Side Bus 100-MHz Optical Drive 32X Max CD-ROM Drive
386185-xx3 Processor Intel Pentium III 500-MHz Hard Drive 10.0-GB Ultra ATA 66
Cache Memory 512-KB ECC L2 Graphics
ATI RAGE PRO TURBO AGP 2X
Controller
Memory Audio Compaq Premier•Sound
Standard 128 MB Software Windows NT 4.0
Maximum 768 MB
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Options
7 DA-10022-00A-010 — 01.31.2000
Compaq Deskpro EN Series
Minitower
Memory
RDRAM
128-MB Memory Kit (1 x 128-MB RDRAM 45ns RIMM)
103989-B21
64- MB Memory Kit (1 x 64-MB RDRAM 45ns RIMM)
103988-B21
Bulk
128-MB Memory Kit (bulk) (1 x 128-MB RDRAM 45ns RIMM)
117671-B21
64- MB Memory Kit (bulk) (1 x 64-MB RDRAM 45ns RIMM)
117670-B21
RDRAM ECC
128-MB Memory Kit (1 x 128-MB RDRAM 45ns ECC RIMM)
103994-B21
64- MB Memory Kit (1 x 64-MB RDRAM 45ns ECC RIMM)
103993-B21
Bulk
128-MB Memory Kit (bulk) (1 x 128-MB RDRAM 45ns ECC RIMM)
117676-B21
64-MB Memory Kit (bulk) (1 x 64-MB RDRAM 45ns ECC RIMM)
117675-B21
66-MHz SDRAM DIMMs
SDRAM
128-MB Memory Kit (1 x 128-MB SDRAM DIMM, 66 MHz)
270812-B21
64-MB Memory Kit (1 x 64-MB SDRAM DIMM, 66 MHz)
242805-B21
32-MB Memory Kit (1 x 32-MB SDRAM DIMM, 66 MHz)
242804-B21
SDRAM ECC
128-MB Memory Kit (1 x 128-MB SDRAM ECC DIMM, 66 MHz)
270843-B21
64-MB Memory Kit (1 x 64-MB SDRAM ECC DIMM, 66 MHz)
270842-B21
32-MB Memory Kit (1 x 32-MB SDRAM ECC DIMM, 66 MHz)
270841-B21
100-MHz SDRAM DIMMs
SDRAM
256-MB Memory Kit (1 x 256-MB SDRAM DIMM, 100 MHz)
102306-B21
128-MB Memory Kit (1 x 128-MB SDRAM DIMM, 100 MHz)
166614-B21
64-MB Memory Kit (1 x 64-MB SDRAM DIMM, 100 MHz)
166613-B21
32-MB Memory Kit (1 x 32-MB SDRAM DIMM, 100 MHz)
166612-B21
Bulk
128-MB Memory Kit (bulk) (1 x 128-MB SDRAM DIMM, 100 MHz)
294454-B21
64-MB Memory Kit (bulk) (1 x 64-MB SDRAM DIMM, 100 MHz)
294218-B21
32-MB Memory Kit (bulk) (1 x 32-MB SDRAM DIMM, 100 MHz)
294216-B21
SDRAM ECC
256-MB Memory Kit (1 x 256-MB SDRAM ECC, 100 MHz)
102307-B21
128-MB Memory Kit (1 x 128-MB SDRAM ECC, 100 MHz)
166618-B21
64-MB Memory Kit (1 x 64-MB SDRAM ECC, 100 MHz)
166617-B21
32-MB Memory Kit (1 x 32-MB SDRAM ECC, 100 MHz)
166616-B21
Bulk
128-MB Memory Kit (bulk) (1 x 128-MB SDRAM ECC, 100 MHz)
294455-B21
64-MB Memory Kit (bulk) (1 x 64-MB SDRAM ECC, 100 MHz)
294219-B21
32-MB Memory Kit (bulk) (1 x 32-MB SDRAM ECC, 100 MHz)
294217-B21
Note: RDRAM can only support a total of 32 devices. Each memory module contains a different number of
devices.
Note: Bulk memory skus are priced individually but must be ordered in lots of 50. Only orders of 50 are accepted.
Note: There is no exchange or return program available for replacing standard memory.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Options
8 DA-10022-00A-010 — 01.31.2000
Compaq Deskpro EN Series
Minitower
Monitors
TFT8000 Flat Panel
307906-001
TFT5000 Flat Panel
325700-001
P1610 Color
305708-001
P110 Color
325600-001
P75 Color
307806-001
V1000 Color
351757-001
V900 Color
303500-001
V700 Color
325800-001
V500 Color
325900-001
S900 Color
360562-001
S700 Color
360512-001
Graphics
4-MB SGRAM 100-MHz SODIMM (to support the ATI RAGE PRO TURBO AGP 2X)
294227-B21
Matrox Millennium G200-SG AGP Graphics Controller (with 8-MB SGRAM)
294308-B21
Matrox Millennium G200-SD PCI Graphics Controller (with 8-MB SDRAM)
124806-B21
Matrox Millennium G400-SG AGP Graphics Controller (with 16-MB SGRAM)
158358-B21
Matrox Millennium G200 DVI/DFP Daughter Card
124807-B21
Matrox Millennium G400 DVI Daughter Card
388557-xx1
8-MB 143-MHz R.92 SGRAM Video Memory Module (to support the Matrox Millennium G200 AGP
graphic solution)
294417-B21
Removable Storage
SuperDisk (LS-120) 2X High-Capacity Floppy Drive Kit
388117-B21
ZIP 100 High-Capacity Floppy Drive Kit
294402-xx1
ZIP 100 Media 3-Pack Kit
127591-xx1
ZIP 250 High-Capacity Floppy Drive Kit
294416-xx1
TR5 10/20 GB IDE Tape Drive Kit
294243-B21
TR5 10/20 GB IDE Media 3-Pack
125782-B21
Optical Drives
10X/40X DVD-ROM Drive
294414-xx1
8X/4X/32X CD-RW Drive Kit
294407-B21
32X Max CD-ROM Drive Kit
294240-xx1
40X Max CD-ROM Drive Kit
388116-xx1
PCI Dxr3 DVD Decoder Card
294422-B21
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Options
9 DA-10022-00A-010 — 01.31.2000
Compaq Deskpro EN Series
Minitower
Hard Drives
Ultra ATA 66 Hard Drives with Drive Protection System (DPS)
27.0-GB 7200 rpm SMART III Ultra ATA 66 Hard Drive with DPS
161610-B21
20.0-GB 7200 rpm SMART III Ultra ATA 66 Hard Drive with DPS
124724-xx1
13.5-GB 7200 rpm SMART III Ultra ATA 66 Hard Drive with DPS
124723-xx1
10.0-GB 7200 rpm SMART III Ultra ATA 66 Hard Drive with DPS
127452-xx1
6.4-GB 5400 rpm SMART III Ultra ATA 66 Hard Drive with DPS
124721-xx1
SCSI Hard Drives
36.0-GB 10,000 rpm Ultra3 SCSI Hard Drive
161498-B21
18.2-GB 10,000 rpm Ultra3 SCSI Hard Drive
159764-B21
18.2-GB 7200 rpm Ultra3 SCSI Hard Drive
147503-B21
9.1 GB 10,000 rpm Wide Ultra3 SCSI Hard Drive
159763-B21
9.1-GB
7200 rpm Wide Ultra2 SCSI Hard Drive
120204-B21
Note: SCSI hard drives require a SCSI controller.
Controllers/Cables/Adapters
Wide Ultra SCSI Controller Kit
294311-xx1
Wide Ultra2 SCSI Controller Kit
124720-B21
Ultra3 Single Channel SCSI Controller Kit
157810-B21
Ultra3 Dual Channel SCSI Controller Kit
144387-B21
Multimedia
32X Max Premier•Sound Multimedia Kit
294296-001
40X Max Premier•Sound Multimedia Kit
388551-001
Compaq Microphone Kit
103589-B21
Premier•Sound Audio Card Kit
387471-xx1
Sound Blaster Audio PCI 128 PS Kit
388550-xx1
Compaq Premier•Sound PS115 Speakers
133566-xxx
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Options
10 DA-10022-00A-010 — 01.31.2000
Compaq Deskpro EN Series
Minitower
Communications
Intel PRO/100+ Management Adapter Kit
127453-B21
Compaq USB ISDN Adapter
321750-B31
Compaq Microcom 610 Internal ISDN Adapter
333056-B21
Compaq NC3121 Fast Ethernet NIC PCI 10/100 WOL
323551-B21
Compaq NC4621 Token Ring NIC PCI 4/16 WOL
379956-B21
Compaq 10 T PCI Intel UTP Controller
317356-B21
Compaq 10/100 TX PCI Intel UTP Controller
317600-B21
Compaq 16/4 TR ISA IBM UTP/STP Controller
301207-B21
Compaq Microcom 705 Corporate Communicator
294700-001
Compaq 56K ISA Fax Modem
294900-002
Compaq 56K PCI Fax Modem
321500-001
Compaq 56K USB Fax Modem
322050-001
Compaq Microcom 510 56K External Fax Modem
316906-002
Compaq Microcom 415 56K External Fax Modem w/ Speakerphone
321108-002
Note: Designed only to allow faster downloads from K56flex compliant sources. Maximum
achievable download transmission rates currently do not reach 56 Kbps and will vary with line
conditions. Modem only works with Windows 9.x and Windows NT.
Input/Output Devices
Compaq I/O Expansion Board
294293-xx1
Easy Access Keyboard
122660-xx6
Compaq Enhanced Smart Card Keyboard
115504-xx6
Compaq Smart Card Keyboard
115506-xx6
Compaq 2-Button Mouse
143315-xx3
Compaq Scroll Mouse
170299-B21
Compaq Fingerprint Identification Reader
294307-xx1
Compaq Smart Card Reader
113771-B21
Compaq Enhanced Smart Card Reader
113784-B21
Support Software CD
Annual Subscription
183426-xxx
Single CD-ROM (current month)
272505-001
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Memory
11 DA-10022-00A-010 — 01.31.2000
Compaq Deskpro EN Series
Minitower
BX chipset (128-MB)
STANDARD MEMORY
128-MB DIMM Memory Installed
Standard Slot
123
128 MB
Empty Empty
STANDARD MEMORY PLUS
OPTIONAL MEMORY
Support for up to 640 MB of DIMM memory is available with the installation of optional
SDRAM Memory Kits.
Up to Slot
123
640 MB
STANDARD MEMORY REPLACED
WITH OPTIONAL MEMORY
Support for up to 768 MB of DIMM memory is available with the removal of the standard 128MB DIMM and the installation of optional SDRAM Memory Kits.
Up to Slot
123
768 MB
Note: It is not necessary to add memory in like pairs or kits. Memory upgrades are accomplished by
adding single or multiple DIMMs of the same or varied sizes. This chart does not represent all
possible memory configurations.
Following are memory options available from Compaq for the Deskpro EN Series Minitower:
100-MHz SDRAM DIMMs:
• 256-MB Memory Kit (1 x 256-MB SDRAM DIMM, 100 MHz) 102306-B21
• 128-MB Memory Kit (1 x 128-MB SDRAM DIMM, 100 MHz) 166614-B21
• 64-MB Memory Kit (1 x 64-MB SDRAM DIMM, 100 MHz) 166613-B21
• 32-MB Memory Kit (1 x 32-MB SDRAM DIMM, 100 MHz) 166612-B21
• 256-MB Memory Kit (1 x 256-MB SDRAM DIMM ECC, 100 MHz) 102307-B21
• 128-MB Memory Kit (1 x 128-MB SDRAM DIMM ECC, 100 MHz) 166618-B21
• 64-MB Memory Kit (1 x 64-MB SDRAM DIMM ECC, 100 MHz) 166617-B21
• 32-MB Memory Kit (1 x 32-MB SDRAM DIMM ECC, 100 MHz) 166616-B21
• 128-MB Memory Kit (bulk) (1 x 128-MB SDRAM DIMM, 100 MHz) 294454-B21
• 64-MB Memory Kit (bulk) (1 x 64-MB SDRAM DIMM, 100 MHz) 294218-B21
• 32-MB Memory Kit (bulk) (1 x 32-MB SDRAM DIMM, 100 MHz)
294216-B21
• 128-MB Memory Kit (bulk) (1 x 128-MB SDRAM ECC DIMM, 100 MHz) 294455-B21
• 64-MB Memory Kit (bulk) (1 x 64-MB SDRAM ECC DIMM, 100 MHz) 294219-B21
• 32-MB Memory Kit (bulk (1 x 32-MB DSRAM ECC DIMM, 100 MHz) 294217-B21
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Memory
12 DA-10022-00A-010 — 01.31.2000
Compaq Deskpro EN Series
Minitower
820 chipset (128-MB)
STANDARD MEMORY
128-MB RIMM Memory Installed
Standard Slot
12
128 MB
8 devices 0 devices
STANDARD MEMORY PLUS
OPTIONAL MEMORY
Support for up to 384 MB of RDRAM RIMM memory is available with the installation of
optional RDRAM Memory Kits.
Up to Slot
12
256 MBmv
8 devices 8 devices
384 MB
8 devices 16 devices
STANDARD MEMORY REPLACED
WITH
OPTIONAL MEMORY
Support for up to 512 MB of RDRAM RIMM memory is available with the removal of the
standard 512-MB RIMM and the installation of optional RDRAM Memory Kits.
Up to Slot
12
512 MB
16 devices 16 devices
Note: It is not necessary to add memory in like pairs or kits. Memory upgrades are accomplished by
adding single or multiple RIMMs of the same or varied sizes. This chart does not represent all
possible memory configurations. RDRAM can only support a total of 32 devices. Each memory
module contains a different number of devices.
Note: The number of devices in the memory modules will decrease in the year 2000 allowing maximum
memory to increase.
Following are memory options available from Compaq for the Deskpro EN Series Minitower
(Only RDRAM):
• 128-MB Memory Kit RDRAM 45ns RIMM 103989-B21
• 64-MB Memory Kit RDRAM 45ns RIMM 103988-B21
• 128-MB Memory Kit RDRAM 45ns ECC RIMM 103994-B21
• 64-MB Memory Kit RDRAM 45ns ECC RIMM 103993-B21
• 128-MB Memory Kit (bulk) RDRAM 45ns RIMM 117671-B21
• 64-MB Memory Kit (bulk) RDRAM 45ns RIMM 117670-B21
• 128-MB Memory Kit (bulk) RDRAM 45ns ECC RIMM 117676-B21
• 64-MB Memory Kit (bulk) RDRAM 45ns ECC RIMM 117675-B21
• Continuity Module (CRIMM) 164173-B21
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Storage
13 DA-10022-00A-010 — 01.31.2000
Compaq Deskpro EN Series
Minitower
DRIVE SUPPORT
Quantity
Supported
Position
Supported
Controller
Removable Media
1.44-MB Diskett e Drive 1 1 Floppy
SuperDisk (LS-120) 2X High- Capacity Floppy Drive 3 1,2,3 IDE
ZIP 250 High-Capacity Floppy Drive 2 2,3 IDE
ZIP 100 High-Capacity Floppy Drive 2 2.3 IDE
TR5 10/20 GB IDE Tape Drive 1 2,3 I DE
40X Max CD-ROM Drive 2 2,3 IDE
32X Max
CD-ROM Drive 2 2,3 IDE
8/4/32X CD-RW Dri ve 22,3IDE
Hard Drive s
27.0-GB 7200 rpm SMART III Ultra ATA 66 Hard Drive Up to 3 2,3,5 Ultra ATA 66(embedded)
20.0-GB 7200 rpm SMART III Ultra ATA 66 Hard Drive Up to 3 2,3,5 Ultra ATA (embedded)
13.5-GB 7200 rpm SMART III Ultra ATA 66 Hard Drive Up to 3 2,3,5 Ultra ATA 66(embedded)
10.0-GB 7200 rpm SMART III Ultra ATA 66 Hard Drive Up to 3 2,3,5 Ultra ATA 66(embedded)
10.0-GB 5400 rpm SMART III Ultra ATA 66 Hard Drive Up to 3 2,3,5 Ultra ATA (embedded)
6.4-GB 5400 rpm SMART III Ultra ATA Hard Drive Up to 3 2,3,5 Ultra ATA (embedded)
36.0-GB 10,00 0 rpm Ultra3 SCSI Hard Drive Up to 3 1,2,3 SCSI
18.2-GB 10,00 0 rpm Ultra3 SCSI Hard Drive Up to 3 1,2,3 SCSI
18.2-GB 7200 rpm Ultra3 SC SI Hard Driv e Up to 3 1,2,3 SCSI
9.1-GB 10,000 rpm Wide-Ultra3 SCSI Hard Drive Up to 3 1,2,3 SCSI
9.1-GB 7200 rpm Wide-Ultra2 SCSI Hard Drive Up to 3 1,2,3 SCSI
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Technical Specifications
14 DA-10022-00A-010 — 01.31.2000
Compaq Deskpro EN Series
Minitower
System Unit Dimensions (HxWxD) 20.25 x 8.38 x 18.6 in/51.44 x 21.29 x 47.24 cm
Weight (approximate) 40 lbs/18.1 kg
Power Supply
Operating Voltage Range 90 to 132 VAC/180 to 264 VAC
Rated Voltage Range 100 to 120 VAC/220 to 240 VAC
Rated Line Frequency 47 to 63 Hz
Rated Input Current 5.5A
Maximum Rated Power 200W
Temperature
Ambient Air Temperature 50° to 95°F/10° to 35°C
Maximum Rate of Change 50°F or 10°C/hour
Storage –22° to 140°F/–30° to 60°C
Maximum Rate of Change 68°F or 20°C/hour
Humidity
Operating 20% to 80%
Non-operating 5% to 90%
Maximum Altitude
Operating 0 to 10,000 ft/0 to 3,048 m
Non-operating 0 to 30,000 ft/0 to 9,144 m
Maximum Rate of Change 1,500 feet per minute/457 meters per minute
Enhanced Keyboard Dimensions (HxWxD) 1.5 x 18 x 6.5 in/3.81 x 45.72 x 16.51 cm
Weight 3.15 lbs/1.59 kg
1.44-MB Diskette Drive Diskette Size
3.5 in
LED Indicators
Green
Read/Write Capacity per Diskette (high/low density)
1.44 MB/720 KB
Drive Height
1 in
Drive Rotation
300 rpm
Transfer Rate (high/low density)
500/250 Kb/s
Bytes/Sector
512
Sectors/Track (high/low density)
18/9
Tracks/Side (high/low density)
80/80
Seek Time
Track-to-Track (high/low density)
3/6 ms
Average (high/low density)
94/173 ms
Settling Time
15 ms
Latency Average
100 ms
Cylinders (high/low)
80/80
Read/Write Heads
2
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Technical Specifications
15 DA-10022-00A-010 — 01.31.2000
Compaq Deskpro EN Series
Minitower
13.5-GB Capacity
13,500 MB
Seek Time (typical reads, including settling)
Height
1 in/25.4 mm Single Track 1.7 ms
Width
3.5 in/88.9 mm Average 8.5 ms
Interface
Ultra ATA 66 Full-Stroke 15.0 ms
Transfer Rate
Rotational Speed 7200
66.6 MB/s
Physical Configuration
Synchronous
(Maximum)
Bytes/Sector 512
Logical Blocks 19,541,088
SMART III Ultra ATA 66
Hard Drives
Operating Temperature
41° to 131°F/5° to
10.0-GB Capacity
10,000 MB
Seek Time (typical reads, including settling)
Height
1 in/25.4 mm Single Track 1.7 ms
Width
3.5 in/88.9 mm Average 8.5 ms
Interface
Ultra ATA 66 Full-Stroke 15.0 ms
Transfer Rate
Rotational Speed 7200
66.6 MB/s
Physical Configuration
Synchronous
(Maximum)
Bytes/Sector 512
Logical Blocks 19,541,088
Operating Temperature
41° to 131°F/5° to
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Technical Specifications
16 DA-10022-00A-010 — 01.31.2000
Compaq Deskpro EN Series
Minitower
40X Max
CD-ROM Drive
Disk
Applicable Disk
Photo-CD/Multi-session, Audio CD, CD-I, CD-ROM XA. MPEG,
MPC level 2
Note: Additional hardware required for CD-ROM XA.
Capacity
650 MB
Block Size Mode 1: 2,048, bytes
Mode 2: 2,340, 2,336 bytes
(CD-DA): 2,352 bytes
(CD-XA): 2,328 bytes
Rotational Speed
Diameter
Center Hole
Thickness
Track Pitch
5200 rpm
12 cm, 8 cm
15 mm
1.2 mm
1.6 µm
Interface IDE
Access Time (typical)
Random
< 100 ms
Full-Stroke
< 150 ms
Audio Output Level
Line-Out
0.7 V @ 47K ohm
Headphone
0.6 V @ 32 ohm
Data Transfer Rate
Sustained
150 KB/s Min (audio)
Variable
2,550 to 6,000 KB/s (CD)
Cache Buffer 128 KB
Start-up Time < 7 sec (typical); < 30 sec with multi-session
Stop Time < 4 sec
Laser Parameters
Type
Semiconductor Laser ConA1As
Wave Length
780 ± 25 nm
Divergence Angle 53.5° ± 1.5°
Output Power
0.14mW @ objective lens
Operating Conditions
Temperature
41° to 113°F/5 to 45°C
Humidity
10% to 80% relative humidity
Dimensions
(H x W x D, maximum)
1.69 x 5.91 x 8.2 in/4.29 x 15.01 x 20.8 cm
Weight 2.65 lbs/1.2 kg
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Technical Specifications
17 DA-10022-00A-010 — 01.31.2000
Compaq Deskpro EN Series
Minitower
Disk
32X Max
CD-ROM Drive
Applicable Disk
Photo-CD/Multi-session, Audio CD, CD-I, CD-ROM XA, MPEG,
MPC level 2
Note: Additional hardware required for CD-ROM XA.
Capacity
650 MB
Block Size
Mode 1: 2,048 bytes
Mode 2: 2,340, 2,336 bytes
(CD-DA): 2,352 bytes
(CD-XA): 2,328 bytes
Rotational Speed
5200 rpm
Diameter
12 cm, 8 cm
Center Hole
15 mm
Thickness
1.2 mm
Track Pitch
1.6 µm
Interface IDE
Access Time (typical)
Random
< 100 ms
Full-Stroke < 150 ms
Audio Output Level
Line-Out
0.7 V
@ 47 ohm
Headphone
0.6 V
@ 32 ohm
Data Transfer Rate
Data Transfer Rate
Sustained
150 KB/s Min (audio)
Variable
1800 to 4800 KB/s (CD)
Cache Buffer 128 KB
Start-up Time
< 7 seconds (typical); < 30 sec with multi-session
Stop Time
< 4 seconds
Laser Parameters
Type
Semiconductor Laser ConAIAs
Wave Length
780 ± 25 nm
Divergence Angle 53.5° ± 1.5°
Output Power
0.14mW @ objective lens
Operating Conditions
Temperature
41° to 113°F/5° to 45°C
Humidity
10% to 80% relative humidity
Dimensions (HxWxD) 1.69 x 5.91 x 8.2 in/4.29 x 15.01 x 20.8 cm
Weight
2.65 lbs/1.2 kg
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Technical Specifications
18 DA-10022-00A-010 — 01.31.2000
Compaq Deskpro EN Series
Minitower
Network Interface 10/100 Base TX
Intel PRO/100+
Management Adapter
Expansion Bus Architecture PCI 2.2
Network Transfer Rate
10Base-T (Half-Duplex)
10 Mb/s
10Base-T (Full-Duplex)
20 Mb/s
100Base-TX (Half-Duplex)
100 Mb/s
100Base-TX (Full-Duplex)
200 Mb/s
Connectors RJ-45
Standards Compliance
10-MB/s Ethernet
IEEE 802.3
100-MB/s Ethernet
IEEE 802.3u
I/O Address Auto configured
Remote Wakeup Yes
Temperature
Operating
32° to 131°F/0° to 55°C
Humidity (non-condensing)
Operating
85% at +131°F/+55°C
Altitude
Operating
10,000 ft/3,048 m
Communication Processor Intel 82559
OS Driver Support
MS Windows NT 3.51 and 4.0
NDIS 3.0, 4.0 Compliant
MS Windows 95, 98, 2000 Beta
NDIS 3.0, 4.0, 5.0 Compliant
Novell NetWare Server v. 3.x, 4.x and 5.0
ODI Compliant
SunSoft Solaris
Not supported
SCO UnixWare, OpenDesktop, OpenServer
Supported
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Technical Specifications
19 DA-10022-00A-010 — 01.31.2000
Compaq Deskpro EN Series
Minitower
16-MB SGRAM
Resolution (maximum) Colors Supported Refresh Rate
2048 x 1536
16.7M 65 Hz
Matrox Millennium G400SG AGP
Acceleration
3 ROP BitBLT, Line Draw, Text, Color Expansion, Basic
Video Color, Conversion and Scaling and Triangle Setup
Engine
Memory 16 MB SGRAM
8-MB SDRAM
Resolution (maximum) Colors Supported Refresh Rate
1280 x 1024
16.7M 75 Hz
ATI RAGE PRO TURBO
AGP 2X Graphics
Controller with SDRAM
Acceleration 3 ROP BitBLT, Line Draw, Text, Color Expansion, Basic
Video Color, Conversion and Scaling and Triangle Setup
Engine
Memory 8-MB SDRAM, not upgradable
8-MB SGRAM
Resolution (maximum) Colors Supported Refresh Rate
1280 x 1024
16.7M 75 Hz
ATI RAGE PRO TURBO
AGP 2X Graphics
Controller with SGRAM
Acceleration 3 ROP BitBLT, Line Draw, Text, Color Expansion, Basic
Video Color, Conversion and Scaling and Triangle Setup
Engine
Memory 4-MB SGRAM, upgradable to 8 MB SGRAM
Compaq, Deskpro, registered United States Patent and Trad emark Office.
Intel, the Intel Inside Logo, and Pentium are regis tered trademar ks of Intel Corporation.
Microsoft, MS, Windows and Windows NT are regist ered trademarks of the Microsoft Corporation.
Other product names mentioned h er ein may be trademarks and/or regis tered tradema r ks of their respec tive companies .
©2000 Compaq Computer Corporation.
Loading...
