Code 3 Par 36 for Dodge Charger User Manual
INSTALLATION &
OPERATION
MANUAL
2011 DODGE CHARGER
PAR 36 LED LIGHT
Code 3 Par 36 LED light heads are sold separately:
Please call Code 3 customer service for LED congura-
tions and pricing available.
(Installation on STD PPV supplied without fog
lights from the factory. )
2011 DODGE CHARGER PAR 36 LED LIGHT
Table of Contents:
Page No: Description:
1. Preparation for installation
2. (a) Installation on vehicle supplied without fog lights from factory
2. (b) Installation on vehicle supplied with fog lights from factory
3. Wiring connections and Installation notes
4. Warranty Information
Preparation for Installation:
1. Access to the rear of the front facia is required in order to complete hardware installation
and make wiring connections. Two methods of gaining access are available:
A. Remove Front facia from vehicle for total
front end access.
B. Remove lower facia splash guard from under
the engine compartment for access to rear of
facia while mounted on vehicle.
IMPORTANT:
Read all instructions and warnings before installing and using.
INSTALLER:
This manual must be delivered to the end user of this equipment.
1
(a) Installation on vehicles supplied without fog lights from the factory:
g 1
1. remove cover by pressing lock tab up and
pushing cover forward
2. Once tab is released from behind, pull cover off
of front of vehicle to expose area
3. mount Par 36 light head onto mounting
bracket/close-off plate using (4) screws and
lock washers supplied with light head.
NOTE: light head should be set inside relief
of formed plate. Driver and Passenger side
brackets are supplied.
4. Remove J-Nuts from facia if they are present
from the factory. Install J-Nuts provided in
mounting kit with extrusion facing rearward.
g 2
(b) Installation on vehicles supplied with fog lights from the factory:
g 3
1. Remove fog light assembly from front
facia (3) screws from back of facia.
g 4
2. Remove (3) J-Nuts from front facia at each fog
light opening. Discard and replace with larger JNuts provided in mounting kit. (install J-Nuts with
extrusion facing forward).
3. mount Par 36 light head onto mounting bracket/
close-off plate using (4) screws and lock washers
supplied with light head.
4. Mounting plate and light head must be mounted
from the back side of the facia. The same mounting
plate is used on both Driver and Passenger sides.
2
