Clarion MS2105 User Manual

CONTENTS
1. Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. Ungo-Net Interface Introduction . . . . . . . . . . . . . . . . . . . . . . 4
3. Remote Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.1 Remote Transmitter Layout . . . . . . . . . . . . . . . . . . . . 5
3.2 Battery Replacement . . . . . . . . . . . . . . . . . . . . . . . . . 5
4. Security System Operation . . . . . . . . . . . . . . . . . . . . . . . . . 6
4.1 Arming Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4.2 Remote Sensor Bypass . . . . . . . . . . . . . . . . . . . . . . . 6
4.3 Passive Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
4.4 Disarming Operation . . . . . . . . . . . . . . . . . . . . . . . . . .6
4.5 Tamper Alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.6 Silent Arming / Disarming . . . . . . . . . . . . . . . . . . . . . . 7
4.7 Driver’s Door Priority Unlock . . . . . . . . . . . . . . . . . . . 7
4.8 Auto Rearm Feature . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.9 Ignition Controlled Door Locks . . . . . . . . . . . . . . . . . . 7
4.10 Remote Panic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.11 Emergency Override . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.12 Valet Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.13 Optional Trunk Release . . . . . . . . . . . . . . . . . . . . . . . 9
4.14 Optional Trunk Disarm Feature . . . . . . . . . . . . . . . . . 9
4.15 Programming Remote Transmitters . . . . . . . . . . . . . . 9
5. Remote Start Operation . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5.1 Remote Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5.2 Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5.3 Stop and Go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6. LCD 2-way Transmitter (MS2107) . . . . . . . . . . . . . . . . . . 11
7. User Selectable Programming Options . . . . . . . . . . . . . . . 12
5.1 Programmable Options . . . . . . . . . . . . . . . . . . . . . . . 12
5.2 Entering User Programming . . . . . . . . . . . . . . . . . . . 13
5.3 Default Reset For User Programming . . . . . . . . . . . . 13
8. Reference Charts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
6.1 Transmitter Operation . . . . . . . . . . . . . . . . . . . . . . . 14
6.2 Status Indicator (LED) Functions . . . . . . . . . . . . . . . .14
6.3 Siren Chirp Status . . . . . . . . . . . . . . . . . . . . . . . . . . .14
9. Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
10. Installation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2
1. FEATURES
The Ungo MS2105 and MS2107 are state-of-the-art combination vehicle security and remote controlled car starter systems. These systems offer features designed to deter and detect potential intrusions to your vehicle, and send an alert signal when a zone is violated.
These systems will inform the user of any bad switches or sensors that may be causing the system to function improperly, and when triggered the violated zone will be identified. Your Ungo system protects both you and the contents of your vehicle with features such as panic mode, dome light illumination, and ignition controlled door locking.
In addition to security features, the MS2105 and MS2107 will safely start your car by remote control, without your key in the ignition. If your vehicle is powered by a diesel engine, the ignition will turn on for several seconds prior to starting the engine, in order for the glow plugs to warm up.
Once the engine is remote started, your preset accessories (heater/air conditioner) will be turned on to provide you with the maximum comfort when you enter the vehicle. After activation, the vehicle will run for approximately 15 minutes (or 25 minutes if selected by your installer at the time of installation) before automatically shutting off.
The MS2107 adds the convenience and security of 2-way operation with LCD display confirmation. The LCD display provides real-time information about the status of your vehicle including arm/disarm confirmation, triggered sensor identification, engine running indication, and more. For a complete description of the LCD transmitter functions, please see the 2-way transmitter supplement included with the MS2107.
Standard Features
• Two 5-Button VariCode31-way Remote Transmitters (
or
• One 5-Button VariCode31-way Remote Transmitter and One 2-way LCD Transmitter (
• Status Indicator (LED)
• Multi-Tone 120dB Siren
• Dual Stage Shock Sensor
• Built-in Starter Disable
• Coded Emergency Override
• Ungo-Net Interface
• Flashing Parking Lights
Note:
Some features may require additional parts and labor, and may not be appropriate for certain
vehicles. Consult your authorized Ungo dealer for assistance.
MS2105
MS2107
)
)
Optional Features
• Keyless Entry
• Remote Trunk/Hatch Release
• Dome Light Supervision
• Hood and Trunk Protection
• Power Window Roll Up
• Driver's Door Priority Locks
• Radar Sensor
• Remote Head Light Control
3
2. Ungo-Net Interface Introduction
The MS2105 and MS2107 are equipped with Ungo’s newest and most revolutionary technology to date, the Ungo-Net bus system. Ungo-Net is a network system that allows expansion, flexibility, and superior vehicle security through digital communication. This is established through a PC link through either a computer or PDA, similar to a USB port on a PC. Utilizing this interface, the alarm system and remote transmitters can be configured to best suit the needs of the operator. This includes arming mode selections, auxiliary functions, multiple vehicle operation, transmitter configuration, and interface modules.
For additional convenience and operation, households with multiple vehicles can utilize a single remote transmitter to operate 2 vehicles. Eliminating the cumbersome cluster of multiple remote transmitters. Also, the remote transmitters can be customized to better suit the needs of the operator. The Arm and Disarm buttons can be consolidated into the one button with the remaining buttons controlling assignable features.
Capitalizing on Ungo-Net, an optional LCD transmitter kit can be added to the security system. This transmitter features 2-way communication with audible and visual confirmation that provides vehicle status information and alerts the operator to violation attempts.
In addition, system configuration, software upgrades, and diagnostics can be performed through the Ungo-Net port. Thus allowing the Ungo dealer to maintain the utmost protection and serviceability of the security system. Ungo-Net also allows the dealer to troubleshoot false triggers and calibrate sensors quickly.
Ungo-Net Accessories
PCLINK
: Includes Ungo-Net software, serial cable, instructions, and power supply.
FMKIT
: Includes SAA217T (LCD transmitter), extended range antenna, instructions,
and transceiver module.
AUX BOX
: Includes receiver module, wiring harness, and instructions.
4
3. REMOTE TRANSMITTER
3.1 Remote Transmitter Layout
Arm/Lock
Silent Arm w/ Shift
Disarm/Unlock
Silent Disarm w/ Shift
Level Shift
Auxiliary 1
Start
Auxiliary 2 w/ Shift
The Ungo MS2105/MS2107 comes with one or two
VariCode
3
Remote Transmitters used to control the system’s features. Each time a transmitter button is pressed, the LED will flash to indicate that a transmission is taking place.
Button 1 Arms the system and locks the doors.* Button 2 Disarms the system and unlocks the doors.* If the optional Driver’s Door
Priority Unlocking feature is installed, pressing Button 2 Disarms the system and unlocks only the driver’s door. Pressing Button 2 again unlocks all doors.
Button 3 Activates the system’s auxiliary 1 output (usually used for trunk release).* Button 4 Activates the system’s remote start feature. The Level Shift Button temporarily changes the function of buttons 1-4 allowing
expanded operation and multi-car compatibility. Each time the Level Shift button is pressed, a new level of commands are accessed up to a maximum of four levels (Level Shift three times). Note: pages 3 and 4 are reserved for channel expansion modules or multi-car operation. See your Authorized Ungo Dealer for details.
* Optional feature
3.2 Battery Replacement
Your Ungo remote transmitter uses a 12 volt alkaline battery (type 23A), which will need to be replaced from time to time. Under normal conditions, the battery may last more than 6 months before it needs replacement. When your remote transmitter’s battery needs replacement, you will notice a decrease in operating range or a decrease in the brightness of the transmitter’s LED indicator.
To change the battery, remove the 2 screws at the back of the transmitter and carefully separate the top and bottom halves of the transmitter case. Insert the new battery, carefully observing proper polarity, then replace the cover.
5
