Clarion MS1001 User Manual

ongratulations on your purchase of the Ungo Security System.
This Ungo Security System was designed in the heart of

C

California’s high-tech “Silicon Valley” by Ungo Security
Corporation, a subsidiary of Clarion Corporation. Since its founding in
1975, Ungo has been recognized as a pioneer and long time industry
leader in vehicle security.

Please read this manual thoroughly to familiarize yourself with your
system’s components and operation. Discuss any questions you might
have with your installing dealer.

Record the serial number of your Ungo system and keep all dealer
records and receipts. Be sure to discuss the installation with the dealer
so that you understand the specifics of the installation in your vehicle.
Also, do not forget to complete and mail the Product Warranty
Registration Card within 60 days of purchase and insure that the
installing dealer has stamped and signed the appropriate section in
order to properly register your warranty.

Table of Contents

1. About Your System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 1

2. Remote Transmitters

Remote Transmitter Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 2

Two Car Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 3

Adding a New Transmitter into the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 4

Deleting Transmitters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 4

Battery Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 5

3. Basic Operation

Remote Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 6

Remote Disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 7

Tamper Alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 7

Silent Arming / Disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 7

Arming Mode Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 8

Passive Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 8

Panic Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 8

Emergency Override . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 9

Automatic System Rearming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 9

Full Time System Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 9

4. Other Features

Valet Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 10

Ignition Controlled Door Locking / Unlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 10

Dome Light Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 10

Auxiliary Function Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 11

Remote Car Starter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 12

Garage Door Receiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 12

Additional Remote Transmitters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 12

5. Reference Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 13

6. Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 14

7. Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 15

Note: Certain features described in this manual may require additional parts and/or labor. Also, many features of

the Ungo MS3001 / MS3200 security systems have selectable options that must be activated or programmed
during the system’s installation. These items will be identified in the following sections. Your Authorized
Ungo Dealer will be happy to discuss these features with you and help you design your system to meet your
needs.

About Your Ungo Security System

Ungo Security Systems are state-of-the-art vehicle protection systems equipped with features
designed to:

Deter

❐

❐

❐

❐

❐

Each Ungo MS1001 System comes with:

• Main Unit - the “brain” of the system.

• 2 - Three Button Remote Transmitters

• Siren - Water resistant, high output siren that sounds when system is triggered.

• Shock Sensor - Ungo Security’s patented sensor that detects both shock and motion.

• Status LED - red illuminated indicator that provides system status information.

• Emergency Override / Valet Switch - used to override the system in case the Remote

Options and Convenience Features*

The advanced design of the Ungo system incorporates a number of optional inputs and outputs
allowing you to create a customized security / convenience system by easily accommodating
many optional convenience and security features such as:

❐ Remote Door Locking
❐ Starter Disable
❐ Horn Honk
❐ Illuminated Entry / Exit
❐ Remote Window Control
❐ Remote Car Start
❐ Extended Range Antenna
❐ Power Trunk / Hatch Release

potential intrusions to the vehicle by continually flashing the system LED status
indicator while the system is Armed, giving a visual indication to any passer-by that the
system is equipped with a security system.

Detect

intrusions to the vehicle, including impacts to the vehicle’s body and glass, and

opening of the doors, trunk and hood.

Alert

those in the vicinity of the vehicle by sounding the system’s siren and flashing,

parking lights, and honking the horn.

Inform

the owner when the system has been triggered and specifically which zone was
violated. The system will also inform the user of any bad switches or sensors that may
be causing the system to function improperly.

Protect

dome light illumination, and ignition controlled door locking.

Transmitters become lost or stolen. Also used to temporarily disable the system when the
vehicle is being serviced or turned over to a parking attendant.

both you and the contents of your vehicle with features such as panic mode,

❐ Glass Breakage Sensor
❐ Radar Sensor
❐ Garage Door Receiver
❐ Auxiliary Lighting Control
❐ Stereo System Valet
❐ Remote Head Lamp Control
❐ Back-up Battery Siren

*May require additional parts and/or labor, see store for details.

MS1001 Owner’s Manual - Page 1

Remote Transmitters

Remote Transmitter Layout

Button 1

LED

Button 2

Each MS1001 system comes with 2 multifunction Remote Transmitters used to control nearly all
of the system’s features.

Each time a transmitter button is pressed, the LED will flash to indicate that a transmission is
taking place.

Button 1 Arms and Disarms the system. This Button also locks and unlocks the doors when the
system is in Valet Mode.

Button 2 controls the system’s Auxiliary Function 1, which is normally used for activating a car’s
electric trunk release.

silently

When Button 1 and 2 are pressed together, the system will Arm or Disarm

(without chirp

confirmation).

As an option, your installer can set system to
pressing Buttons 1 and 2 together will Arm or Disarm the system

always

arm without chirp confirmation. If this is done, then

with

chirp confirmation.

It is also possible to set individual Remote Transmitters to arm and disarm the system using
either of the Transmitters function Buttons, which is useful when a Transmitter is used to control
two systems. See

Adding a Remote Transmitter into the System.

Page 2 - MS1001 Owner’s Manual

The following diagram illustrates how the Remote Transmitter controls the functions of the
system:

BUTTON 1
BUTTON 2

ARM / DISARM
F1

Two Car Operation

If you want to control two Ungo Security systems by a single Remote Transmitter, the unused
function of the Remote Transmitter can be set up by your dealer to operate another Ungo
Security system, giving you the convenience of operating multiple vehicles from a single Remote
Transmitter.

When set for two car operation, the Remote Transmitters will function as in the example below:
For more information about Two Car operation, see your Authorized Ungo Dealer.

BUTTON 1
BUTTON 2

(A) = Car 1
(B) = Car 2

ARM / DISARM (A)
ARM / DISARM (B)

MS1001 Owner’s Manual - Page 3
