Thank you for purchasing this Clarion product.
English
∗ Please read this owner’s manual in its entirety before operating this equipment.
∗ After reading this manual, be sure to keep it in a handy place (e.g., glove compartment).
∗ Check the contents of the enclosed warranty card and keep it carefully with this manual.
∗ This manual includes the operating procedures of the CD changer and TV tuner connected via the
CeNET cable. The CD changer and TV tuner have their own manuals, but no explanations for operating them are described.
Contents
1. FEATURES...................................................................................................................................... 2
2. PRECAUTIONS .............................................................................................................................. 3
Sloping Console .............................................................................................................................. 4
Handling Compact Discs ................................................................................................................. 4
3. CONTROLS .................................................................................................................................... 5
4. NOMENCLATURE .......................................................................................................................... 6
Names of the Buttons and their Functions ...................................................................................... 6
Major Button Operations When External Equipment is Connected to This Unit .............................. 7
Display Items ................................................................................................................................... 8
LCD Screen ..................................................................................................................................... 8
5. DCP ................................................................................................................................................. 9
6. REMOTE CONTROL ..................................................................................................................... 10
Inserting the Battery ...................................................................................................................... 10
Functions of the Remote Control Unit Buttons ............................................................................... 11
7. OPERATIONS ............................................................................................................................... 12
Basic Operations ........................................................................................................................... 12
Radio Operations ........................................................................................................................... 14
CD/MP3/WMA Operations ............................................................................................................. 16
MUSIC CATCHER Operations ...................................................................................................... 20
Common Operations ..................................................................................................................... 21
8. OPERATIONS OF ACCESSORIES .............................................................................................. 26
CD Changer Operations ................................................................................................................ 26
TV Operations ............................................................................................................................... 28
9. IN CASE OF DIFFICULTY ............................................................................................................ 30
10. ERROR DISPLAYS ....................................................................................................................... 32
11. SPECIFICATIONS ......................................................................................................................... 33
1. FEATURES
• Full-Dot, High-Contrast Positive Display With Eye-Catching Graphics
• 728 Variable Colors (Display/Function Keys)
• MP3 and WMA Playback With ID3-TAG and WMA-TAG Display Capability
• High-Powered Internal MOSFET Amplifier (53 Watts x 4 Channels)
• Music Catcher for One-Touch CD Recording (Up to 80 Songs)
• Shock-Proof Memory for Skip-Free CD Playback
• 6-Channel RCA Output for Easy System Expansion
• Auxiliary Input for External Device Connection
• 2-Band Parametric EQ and ADF Compressed Audio Enhancer
• Aluminum Motorized Detachable Faceplate
2 DXZ755MC
2. PRECAUTIONS
Bottom View of Source Unit
Ball-point pen
Roughness
English
1. When the inside of the car is very cold and the
player is used soon after switching on the
heater moisture may form on the disc or the
optical parts of the player and proper playback
may not be possible. If moisture forms on the
disc, wipe it off with a soft cloth. If moisture
forms on the optical parts of the player, do not
use the player for about one hour. The condensation will disappear naturally allowing normal operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to consult the dealer or an experienced radio/TV technician for help.
2. Driving on extremely bumpy roads which cause
severe vibration may cause the CD to skip.
3. This unit uses a precision mechanism. Even in
the event that trouble arises, never open the
case, disassemble the unit, or lubricate the rotating parts.
CAUTION
USE OF CONTROLS, ADJUSTMENTS, OR PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN, MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
THE COMPACT DISC PLAYER and MINI DISC
PLAYER SHOULD NOT BE ADJUSTED OR REPAIRED BY ANYONE EXCEPT PROPERLY
QUALIFIED SERVICE PERSONNEL.
CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE MANUFACTURER FOR COMPLIANCE COULD VOID THE
USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
INFORMATION FOR USERS:.
CHANGES OR MODIFICATIONS TO THIS
PRODUCT NOT APPROVED BY THE MANUFACTURER WILL VOID THE WARRANTY AND
WILL VIOLATE FCC APPROVAL.
DXZ755MC 38 DXZ755MC
Ball-point pen
Roughness
This unit uses sloping console to make largescreen displays possible.
When you use the sloping console, be sure to
close it.
CAUTION
BE CAREFUL NOT TO GET YOUR FINGERS
CAUGHT WHEN OPENING AND CLOSING
THE SLOPING CONSOLE.
1. For safety’s sake, always close the SLOPING CONSOLE before leaving this unit unused for a prolonged period or switching
OFF the ignition key.
If you switch OFF the ignition key with the
SLOPING CONSOLE tilted, the SLOPING
CONSOLE does not close.
Handling Compact Discs
Use only compact discs bearing the or
mark.
Do not play heart-shaped, octagonal, or other
specially shaped compact discs.
Some CDs recorded in CD-R/CD-RW mode
may not be usable.
Handling
• Compared to ordinary music CDs, CD-R and CD-RW
discs are both easily affected by high temperature and
humidity and some of CD-R and CD-RW discs may
not be played. Therefore, do not leave them for a long
time in the car.
• New discs may have
some roughness around
the edges. If such discs
are used, the player may
not work or the sound
may skip. Use a ballpoint pen or the like to
remove any roughness
from the edge of the
disc.
• Never stick labels on the surface of the compact disc
or mark the surface with a pencil or pen.
• Never play a compact disc with any cellophane tape or
other glue on it or with peeling off marks. If you try to
play such a compact disc, you may not be able to get it
back out of the CD player or it may damage the CD
player.
Be sure to unfold and read the next page. / Veuillez déplier et vous référer à la page suivante.
Cerciórese de desplegar y de leer la página siguiente.
English
2. Before the SLOPING CONSOLE closes,
there may be a braking sound from the
safety mechanism. This is normal.
3. If you move the SLOPING CONSOLE by
hand, this may create play. To correct this
play, with the power on for the unit, press the
[Q] button to close the SLOPING CONSOLE.
4. After a disc is ejected, the SLOPING CONSOLE automatically returns to the tilted or
closed state. If there is any obstruction when
the SLOPING CONSOLE tries to close, the
safety mechanism is triggered and the
SLOPING CONSOLE returns to the open
state. If this happens, remove the obstruction, then press the [Q] button.
5. To avoid scratching the compact disc, keep
the 12 or 8 cm CD level when inserting or removing them.
• Do not use compact discs that have large
scratches, are misshapen, cracked, etc. Use of
such discs may cause misoperation or damage.
•To remove a compact disc from its storage case, press
down on the center of the case and lift the disc out,
holding it carefully by the edges.
• Do not use commercially available CD protection
sheets or discs equipped with stabilizers, etc. These
may damage the disc or cause breakdown of the internal mechanism.
Storage
• Do not expose compact discs to direct sunlight or any
heat source.
• Do not expose compact discs to excess humidity or
dust.
• Do not expose compact discs to direct heat from heat-
ers.
Cleaning
•To remove fingermarks and dust, use a soft cloth and
wipe in a straight line from the center of the compact
disc to the circumference.
• Do not use any solvents, such as commercially avail-
able cleaners, anti-static spray, or thinner to clean
compact discs.
• After using special compact disc cleaner, let the com-
pact disc dry off well before playing it.
DXZ755MC 4
English
3.CONTROLS / LES COMMANDES / CONTROLES
Source unit / Appareil pilote / Unidad fuente
Français
Español
[
PS/AS],
[
RELEASE
[
ROTARY
[a] / [d]
[
ADJ
]
]
]
[
[ ]
A-M
[
SRC]
IR-Receiver / Récepteur IR /
Receptor IR
]
[
SCN]
[
RPT]
[
RDM]
[
P.LIST], [ERASE]
[
DIRECT
]
With the SLOPING CONSOLE opened / Ouvrez la CONSOLE RABATTABLE /
Apertura de la CONSOLA INCLINABLE
[DN]
[UP]
[
BND
[
ISR
[Q]
[
REC
[
COLOR
]
]
[
DISP]
[
TITLE]
[
ADF]
]
]
[
CD SLOT
Note: Be sure to unfold this page and refer to the front diagrams as you read each chapter.
Remarque: Veuillez déplier cette page et vous référer aux schémas quand vous lisez chaque chapitre.
Nota: Cuando lea los capítulos, despliegue esta página y consulte los diagramas.
]
English
4. NOMENCLATURE
Notes:
• Be sure to read this chapter referring to the front diagrams of chapter “3. CONTROLS” on page 5 (unfold).
• MC is the abbreviation of MUSIC CATCHER.
• ADF is the abbreviation of Anti Distortion Filter.
Names of the Buttons and their Functions
[RELEASE] button
•
Deeply push in the button to unlock the DCP.
[PS/AS], [ ] button
•
Plays or pauses a CD while in the CD/MP3/WMA,
MC mode.
•
Performs preset scan in the radio mode. Press and
hold for 2 seconds or longer to perform auto store.
•
Confirms various settings.
IR-Receiver
•
Receiver for remote control unit. (Operating range:
30° in all directions)
[ISR] button (Instant station recall)
•
Recalls ISR radio station in memory.
•
Press and hold for 2 seconds or longer: Stores current station into ISR memory (radio mode only).
[Q] button
•
Press to open the SLOPING CONSOLE and insert a
CD into the CD SLOT.
•
Press to eject a CD loaded in the unit.
[DISP] button
•
Switches the display indication (main display, sub display, title display).
•
Press and hold for 1 second or longer to switch to the
display adjust mode.
[TITLE] button
•
Switches the titles.
•
Press and hold for 1 second or longer to input or
scroll the title.
[ADF] button
•
Selects one of the 4 types of sound characteristics
preset in memory.
[REC] button
•
Press during CD playback, and the track currently being played back is recorded onto MC. (TRACK REC)
•
Press and hold for 2 seconds or longer during CD playback, and all tracks are recorded onto MC. (DISC REC)
[COLOR] button
•
Press to select display color.
[BND] button
•
Switches the band.
•
Press and hold for 1 second or longer to switch seek
or manual tuning.
•
Returns to a first track while in the CD/MP3/WMA, MC
mode.
•
Press and hold for 1 second or longer to switch the
track type to play in the CD/MP3/WMA mode.
6 DXZ755MC
[UP], [DN] buttons
•
Selects the folder. (MP3/WMA disc, MC mode only)
[DIRECT] buttons
•
Stores a station into memory or recalls it directly
while in the radio mode.
[P.LIST], [ERASE] button
•
Press and hold for 1 second or longer to turn on or off
the play list mode. (MP3/WMA disc only)
•
Erases a track or folder in the MC mode.
•
Press and hold for 2 seconds or longer to switch to
the ALL ERASE mode.
[RDM] button
•
Performs random play while in the CD/MP3/WMA,
MC mode.
•
Press and hold for 1 second or longer to perform folder
random play while in the MP3/WMA disc, MC mode.
[RPT] button
•
Repeats play while in the CD/MP3/WMA, MC mode.
•
Press and hold for 1 second or longer to perform folder
repeat play while in the MP3/WMA disc, MC mode.
[SCN] button
•
Performs scan play for 10 seconds of each track
while in the CD/MP3/WMA, MC mode.
•
Press and hold for 1 second or longer to perform folder
scan play while in the MP3/WMA disc, MC mode.
[SRC] button
•
Press to turn on the power.
•
Press and hold for 1 second or longer to turn off the
power.
•
Switches the operation mode among the radio mode, etc.
[A-M] button
•
Switches to the audio mode (SUB-WOOF VOL, ADF,
BASS, TREBLE, BALANCE, FADER).
•
Press and hold for 1 second or longer to turn on or off
the MAGNA BASS EXTEND.
[ADJ] button
•
Switches to the adjust mode.
[a]/[d] lever
•
Selects a station while in the radio mode or selects a
track when listening to the CD/MP3/WMA, MC mode.
•
This lever is used to make various settings.
•
Move for 1 second or longer to switch the fast-forward/fast-rewind.
[ROTARY] knob
•
Tu rn to adjust the volume.
•
Performs various settings.
[CD SLOT]
•
CD insertion slot.
Major Button Operations When External Equipment is Connected to This Unit
English
● When the CD/DVD changer is
connected
∗
For details, see the section “CD Changer Operations”. For the DVD changer, refer to the Owner’s
Manual provided with the DVD changer.
[ ] button
• Plays or pauses a CD or DVD.
[DISP] button
• Switches the display indication (main display, sub dis-
play, title display).
[TITLE] button
• Switches the titles.
• Press and hold for 1 second or longer to input or scroll
the title.
[BND] button
• Advances to next disc.
[UP], [DN] buttons
• Selects the disc.
[RDM] button
•
Performs random play.
•
Press and hold for 1 second or longer to perform
disc random play.
[RPT] button
•Performs repeat play.
• Press and hold for 1 second or longer to perform
disc repeat play.
[SCN] button
• Performs scan play for 10 seconds of each track.
• Press and hold for 1 second or longer to perform disc
scan play.
[a]/[d] lever
• Repeats or advances a track when listening to a disc.
• Move for 1 second or longer to switch the fast-for-
ward/fast-rewind.
● When the TV is connected
∗
For details, see the section “TV Operations”.
[PS/AS] button
• Performs preset scan. Press and hold for 2 seconds
or longer to perform auto store.
[BND] button
• Switches the band.
• Press and hold for 1 second or longer to switch seek
or manual tuning.
[DIRECT] buttons
• Stores a station into memory or recalls it directly.
[ADJ] button
• Press and hold for 1 second or longer to switch the
TV picture mode or VTR (external) picture mode.
[a]/[d] lever
• Selects a station.
● When the Sirius Satellite
Radio is connected
∗
For details, refer to the Owner’s Manual provided
with the Sirius Satellite Radio.
[PS/AS] button
• Performs category scan. Press and hold for 1 second
or longer to perform preset scan.
[DIRECT] buttons
• Stores a station into memory or recalls it directly.
[ISR] button
• Press and hold for 1 second or longer to select a cat-
egory.
[a]/[d] lever
• Selects a station.
What is Sirius Satellite Radio?
Sirius is radio the way it was meant to be: Up to 100
new channels of digital quality programming delivered
to listeners coast to coast via satellite. That means 50
channels of completely commercial-free music. Plus up
to 50 more channels of news, sports, and entertainment
from names like CNBC, Discovery, SCI-FI Channel,
A&E, House of Blues, E!, NPR, Speedvision and ESPN.
Sirius is live, dynamic entertainment, completely focused on listeners. Every minute of every day of every
week will be different. All 50 commercial-free music
channels are created in-house and hosted by DJs who
know and love the music. Do you like Reggae? How
about Classic Rock or New Rock? Sirius has an array of
choices spanning a vast range of musical tastes including the hits of the 50’s, 60’s, 70’s, & 80’s as well as
Jazz, Country, Blues, Pop, Rap, R&B, Bluegrass, Alternative, Classical, Heavy Metal, Dance and many others...
From its state-of-the-art, digital broadcasting facility in
Rockefeller Center, New York City, Sirius will deliver the
broadest, deepest mix of radio entertainment from coast
to coast.
Sirius will bring you music and entertainment programming that is simply not available on traditional radio in
any market across the country. It’s radio like you’ve
never heard before.
So Get Sirius and Listen Up! For more information, visit
siriusradio.com.
DXZ755MC 75 DXZ755MC
Bottom View of Source Unit
Ball-point pen
Roughness
Display Items Sloping Console
English
Main display
Source indication
Spectrum analyzer display,
Source icon
• You can select from 5 display patterns in the “SPE/ANA PTN” setting.
Sub icon
: Trick play indication
Performance information,
Operation contents indication
: Disc icon
: Play list icon
: Folder icon
: Track icon
Function indication
Sub display
Level bar display
Title display
Spectrum analyzer display
• You can select from 4 display
patterns in the “SPE/ANA PTN”
setting.
Operation status indication,
Title indication
Clock, Mute indication
Level bar display
• You cannot change the combination of the upper and
lower title to your preference.
The user title is displayed only in the upper title, and the
lower title does not appear.
• The title display does not appear in the radio, TV, AUX or
DVD changer mode.
LCD Screen
In extreme cold, the screen movement may slow down and the screen may darken, but this is normal.
The screen will recover when it returns to normal temperature.
Operation status indication,
Title indication
5. DCP
English
The control panel can be detached to deter
theft. When detaching the control panel, store it
in the DCP (DETACHABLE CONTROL PANEL)
case to prevent scratches.
We recommend taking the DCP with you when
leaving the car.
Removing the DCP
1. With the SLOPING CONSOLE closed, turn
off the power.
2. Press the [RELEASE] button deeply to open
the DCP.
[
RELEASE] button
3. Pull the DCP toward you and remove it.
DCP
CAUTION
•Always close the SLOPING CONSOLE be-
fore removing the DCP.
• If you remove the DCP with the SLOPING
CONSOLE open, the sloping console
closes immediately. Be careful not to get
your fingers caught.
Attaching the DCP
1. Insert the DCP so that the A section on the
right side of the DCP catches on the hook B
on the unit.
2. Press the left side C of the DCP carefully to
fit it in place.
CAUTION
• The DCP can easily be damaged by
shocks. After removing it, be careful not to
drop it or subject it to strong shocks.
• If the [RELEASE] button is pressed and the
DCP is not locked into place, it may fall out
from vibration of the car. This can break
the DCP, so after removing it, either install
it on the unit or put it in its DCP case.
• The connector connecting the unit and the
DCP is an extremely important part. Be
careful not to damage it by pressing on it
with fingernails, screwdrivers, etc.
Note:
• If the DCP is dirty, wipe off the dirt with a soft, dry
cloth only.
DXZ755MC 9
English
6. REMOTE CONTROL
Remote control unit
[
]
SRC
[
], [ ]
[
]
MUTE
[
]
ISR
[
]
SCN
Receiver for remote control unit
Operating range: 30˚ in all directions
Signal transmitter
[
]
BND
[
]
[a], [d]
[
]
DISP
[
]
RDM
[
]
RPT
Inserting the Battery
1 Turn over the remote control unit and slide the cover
in the direction indicated by the arrow in the
illustration.
2 Insert the battery (CR2025) into the insertion guides,
with the printed side (+) facing upwards.
3 Press the battery in the direction indicated by the
arrow so that it slides into the compartment.
4 Replace the cover and slide in until it clicks into place.
Notes:
Misuse may result in rupture of the battery, producing
leakage of fluid and resulting in personal injury or
damage to surrounding materials. Always follow these
safety precautions:
• Use only the designated battery .
• When replacing the battery, insert properly, with +/polarities oriented correctly.
• Do not subject battery to heat, or dispose of in fire or
water. Do not attempt to disassemble the battery.
• Dispose of used batteries properly.
10 DXZ755MC
1
Insertion guide
R
2
C
0
2
5
Functions of the Remote Control Unit Buttons
English
Mode
Button
[SRC]
[BND]
[ ] , [ ]
[ ] , [ ]
[ ]
[MUTE]
[ISR]
[DISP]
[SCN]
Radio/SIRIUS
Switches among radio, SIRIUS tuner, CD/MP3/WMA, MC, CD changer, DVD changer, TV
and AUX.
Switches reception
band.
Increases and decreases volume (in all modes).
Moves preset
channels up and
down.
No function.
Turns mute on and off.
Recalls ISR radio station in memory.
When pressed and held for 2 seconds or longer: Stores current station into ISR memory (radio
mode only).
Switches among main display, sub display and title display.
When pressed and held for 1 second or longer: Switches the titles (except in the radio, DVD
changer, TV mode).
Preset scan.
When pressed and
held for 2 seconds or
longer:
Auto store.
CD/MP3/WMA/
M.CATCHER
Returns to the first
track.
Moves tracks up and down.
When pressed and held for 1 second or longer:
Fast-forward/fast-rewind.
Switches between playback and pause.
Scan play.
When pressed and
held for 1 second or
longer:
Folder scan play
(MP3/WMA disc, MC
mode).
CD changer
DVD changer
Moves the next disc
in increasing order.
Scan play.
When pressed and
held for 1 second or
longer:
Disc scan play.
TV
Switches reception
band.
Moves preset
channels up and
down.
No function.
Preset scan.
When pressed and
held for 2 seconds or
longer:
Auto store.
[RPT]
[RDM]
∗ Some of the corresponding buttons on the main unit and remote control unit have different functions.
No function.
No function.
Repeat play.
When pressed and
held for 1 second or
longer:
Folder repeat play
(MP3/WMA disc, MC
mode).
Random play.
When pressed and
held for 1 second or
longer:
Folder random play
(MP3/WMA disc, MC
mode).
Repeat play.
When pressed and
held for 1 second or
longer:
Disc repeat play.
Random play.
When pressed and
held for 1 second or
longer:
Disc random play.
No function.
Switches between TV
and VTR.
DXZ755MC 11
English
7. OPERATIONS
Basic Operations
Note:Be sure to read this chapter referring to the front diagrams of
chapter “3. CONTROLS” on page 5 (unfold).
CAUTION
Be sure to lower the volume before switching off the unit power or the ignition key. The
unit remembers its last volume setting. If
you switch the power off with the volume up,
when you switch the power back on, the
sudden loud volume may hurt your hearing
and damage the unit.
Turning on/off the power
Note:
• Be careful about using this unit for a long time
without running the engine. If you drain the car’s
battery too far, you may not be able to start the
engine and this can reduce the service life of the
battery.
1. Press the [SRC] button.
2. The illumination and display on the unit light
up. The unit automatically remembers its last
operation mode and will automatically switch
to display that mode.
3. Press and hold the [SRC] button for 1 second
or longer to turn off the power for the unit.
Note:
• System check
During the initial power up of this unit, it will go
through a system check procedure. This procedure verifies any devices connected through
CeNET. Any additional CeNET devices plugged
into the unit after the initial power up will initiate
the system check procedure. When the power is
turned on, “SYSTEM CHECK” appears in the display if the wire connections were modified. The
system check starts automatically within the unit.
Selecting a mode
1. Press the [SRC] button to change the opera-
tion mode.
2. Each time you press the [SRC] button, the op-
eration mode changes in the following order:
Radio mode ➜ SIRIUS mode ➜ CD/MP3/
WMA mode ➜ M.CATCHER mode ➜ CD
changer mode ➜ DVD changer mode ➜
TV mode ➜ AUX mode ➜ Radio mode...
∗ External equipment not connected through
CeNET will not be displayed.
Adjusting the volume
1. Press the front part of the [ROTARY] knob.
The knob will pop up.
2. Turn the [ROTARY] knob to adjust the vol-
ume.
∗ The volume level is from 0 (minimum) to 33
(maximum).
Switching the display
● When the power is turned on
1. Each time you press the [DISP] button, the
display switches in the following order:
Main display ➜ Sub display ➜ Title display ➜ Main display ...
∗ Once selected, the preferred display becomes
the display default. When a function adjustment such as volume is made, the screen will
momentarily switch to that function’s display,
then revert back to the preferred display several seconds after the adjustment.
∗ When you have entered a title in a CD/MP3/
WMA, it appears in the display. If you have not
entered a title, “NO TITLE” appears in the display. For information on how to enter a title,
refer to the subsection “Entering titles” in the
section “Common Operations”.
● When the power is turned off
1. Each time you press the [DISP] button, the
display switches in the following order:
Clock display ➜ Display off ➜ Clock display...
Setting MAGNA BASS EXTEND
The MAGNA BASS EXTEND does not adjust
the low frequencies like the normal sound adjustment function, but emphasizes the deep
bass frequencies to provide you with a dynamic
sound.
∗ The factory default setting is “OFF”.
1. Press and hold the [A-M] button for 1 second
or longer to turn on the MAGNA BASS EXTEND effect. “M-BASS EX ON” appears on
the display.
2. Press and hold the [A-M] button for 1 second
or longer to turn off the MAGNA BASS
EXTEND effect. “M-BASS EX OFF” appears
on the display.
12 DXZ755MC
Note:
• When “ADF 1”, “ADF 2”, “ADF 3” or “ADF USER”
is selected for ADF (Anti Distortion Filter), setting
of MAGNA BASS EX cannot be performed.
Setting the Anti Distortion Filter
The adopted “Liveliness Enhancement Filter” and
“Sound Tone Compensation” functions allow well-
modulated realistic playback without affecting the
characteristics of the original sound tone.
This unit is provided with 4 types of sound tone effects stored in memory. Select the one you prefer.
∗ The factory default setting is “ADF OFF”.
Each time you press the [ADF] button, the tone
effect changes in the following order:
“ADF 1” ➜ “ADF 2” ➜ “ADF 3” ➜ “ADF
USER” ➜ “ADF OFF” ➜ “ADF 1” ...
• ADF 1 : suitable for the genuine speakers
• ADF 2 : suitable for separate speakers
• ADF 3 : suitable for coaxial speakers
• ADF USER: this setting can be adjusted by
the user to his or her individual
preference.
• ADF OFF : no sound effect
Notes:
• The volume changes each time the ADF (Anti Distortion Filter) setting is switched. Turn down the
volume and the sub-woofer volume before performing a switching operation.
• Sufficient effects cannot be obtained with some
speaker systems. In such cases, adjust the volume.
Adjusting the tone
Press the [A-M] button and select the item to
adjust. Each time you press the [A-M] button,
the item changes as following order:
● When “ADF 1, 2, 3” is set
“SUB-WOOF VOL” ➜ “BALANCE” ➜
“FADER” ➜ Last function mode...
● When “ADF USER” is set
“SUB-WOOF VOL” ➜ “ADF GAIN” ➜
“BALANCE” ➜ “FADER” ➜
Last function mode...
● When “ADF OFF” is set
“SUB-WOOF VOL” ➜ “BASS GAIN” ➜
“TREBLE GAIN” ➜ "BALANCE” ➜
“FADER” ➜ Last function mode...
Notes:
• As subwoofer is effective, “SUB-WOOF VOL” can
be selected.
• The display automatically returns to the previous
mode.
Basic Operations
Adjusting the subwoofer
∗ The factory default setting is “0”
∗ This function can be adjusted only when the
subwoofer output is set to “ON”. For details on how
to set the subwoofer, refer to the subsection “Set-
ting the subwoofer” in the section “Common Operations”.
1. Press the [A-M] button to select “SUB-
WOOF VOL”.
2. Turn the [ROTARY] knob to select from –6 to
+6.
3. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the ADF effects (Gain, Filter)
This adjustment can only be performed when the
ADF (Anti Distortion Filter) is set to “ADF USER”.
1. Press the [A-M] button and select “ADF GAIN”.
2. Turn the [ROTARY] knob to adjust the gain.
∗ The factory default setting is "1". (Adjustment
range: 1 to 4)
∗ “ADF GAIN” adjusts the filter effect.
3. Move the [a]/[d] lever to select “ADF FIL-
TER”.
Turn the [ROTARY] knob to select the filter.
∗ The factory default setting is “MID”. (Adjust-
ment LOW/MID/HIGH)
• LOW : attenuates high frequencies.
• MID : attenuates low and high frequencies evenly.
• HIGH : attenuates low frequencies.
4. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the bass (Gain,
Frequency, Q-curve)
This adjustment can only be performed when the
ADF (Anti Distortion Filter) is set to “ADF OFF”.
1. Press the [A-M] button and select “BASS
GAIN”.
2. Turn the [ROTARY] knob to adjust the bass.
∗ The factory default setting is “0”. (Adjustment
range: –6 to +8)
3. Move the [a]/[d] lever to select “BASS
FREQ”.
Turn the [ROTARY] knob to select the frequency.
∗ The factory default setting is “50”. (Adjustment
50/80/120 Hz)
English
DXZ755MC 13
Basic Operations
English
4. Move the [a]/[d] lever to select “BASS
Turn the [ROTARY] knob to select the Q-
curve.
∗ The factory default setting is “1”. (Adjustment
1/1.25/1.5/2)
5. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the treble (Gain,
Frequency)
This adjustment can only be performed when
the ADF (Anti Distortion Filter) is set to “ADF
OFF”.
1. Press the [A-M] button and select “TREBLE
GAIN”.
2. Turn the [ROTARY] knob to adjust the treble.
∗ The factory default setting is “0”. (Adjustment
range: –6 to +6)
3. Move the [a]/[d] lever to select
“TREBLE FREQ”.
Turn the [ROTARY] knob to select the fre-
quency.
∗ The factory default setting is “12k”. (Adjust-
ment 8 kHz/12 kHz)
4. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the balance
1. Press the [A-M] button and select “BAL-
ANCE”.
2. Turn the [ROTARY] knob to adjust the bal-
ance of the left and right speakers.
∗ The factory default setting is “0”. (Adjustment
range: L13 to R13)
3. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the fader
1. Press the [A-M] button and select “FADER”.
2. Turn the [ROTARY] knob to adjust the bal-
ance of the front and rear speakers.
∗ The factory default setting is “0”. (Adjustment
range: F12 to R12)
3. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Q”.
Radio Operations
FM reception
For enhanced FM performance the
tuner includes signal actuated stereo control,
Enhanced Multi AGC, Impulse noise reduction
circuits and Multipath noise reduction circuits.
Listening to the radio
1. Press the [SRC] button and select the radio
mode. The frequency appears in the display.
2. Press the [BND] button and select the radio
band. Each time the button is pressed, the
radio reception band changes in the following order:
FM1 ➜ FM2 ➜ FM3 ➜ AM ➜ FM1...
3. Move the [a]/[d] lever to tune in the de-
sired station.
Tuning
There are 3 types of tuning modes available, seek,
manual and preset tuning.
Seek tuning
1. Press the [BND] button and select the de-
sired band (FM or AM).
∗ If “MANU” is lit in the display, press and hold
the [BND] button for 1 second or longer.
“MANU” in the display goes off and seek tuning is now available.
2. Move the [a]/[d] lever to automatically
seek a station.
When the lever is moved up, the station is
sought in the direction of higher frequencies;
if the lever is moved down, the station is
sought in the direction of lower frequencies.
Manual tuning
There are 2 ways available: Quick tuning and
step tuning.
When you are in the step tuning mode, the frequency changes one step at a time. In the quick
tuning mode, you can quickly tune the desired
frequency.
1. Press the [BND] button and select the de-
sired band (FM or AM).
∗ If “MANU” is not lit in the display, press and
hold the [BND] button for 1 second or longer.
“MANU” is lit in the display and manual tuning
is now available.
®
14 DXZ755MC
2. Tune into a station.
● Quick tuning:
Move the [a]/[d] lever for 1 second or
longer to tune in a station.
● Step tuning:
Move the [a]/[d] lever to manually tune in
a station.
Recalling a preset station
A total of 24 preset positions (6-FM1, 6-FM2, 6FM3, 6-AM) exists to store individual radio stations in memory. Pressing the corresponding
[DIRECT] button recalls the stored radio frequency automatically.
1. Press the [BND] button and select the de-
sired band (FM or AM).
2. Press the corresponding [DIRECT] button to
recall the stored station.
∗ Press and hold one of the [DIRECT] buttons
for 2 seconds or longer to store that station
into preset memory.
Manual memory
1. Select the desired station with seek tuning,
manual tuning or preset tuning.
2. Press and hold one of the [DIRECT] buttons
for 2 seconds or longer to store the current
station into preset memory.
Auto store
Auto store is a function for storing up to 6 stations that are automatically tuned in sequentially. If 6 receivable stations cannot be received,
a previously stored station remains
unoverwritten at the memory position.
1. Press the [BND] button and select the de-
sired band (FM or AM).
2. Press and hold the [PS/AS] button for 2 sec-
onds or longer. The stations with good reception are stored automatically to the preset
channels.
Radio Operations
Preset scan
Preset scan receives the stations stored in preset memory in order. This function is useful
when searching for a desired station in memory.
1. Press the [PS/AS] button.
2. When a desired station is tuned in, press the
[PS/AS] button again to continue receiving
that station.
Note:
• Be careful not to press and hold the [PS/AS] but-
ton for 2 seconds or longer, otherwise the auto
store function is engaged and the unit starts storing stations.
Instant station recall (ISR)
Instant station recall is a special radio preset
that instantly accesses a favorite radio station at
a touch of a button. The ISR function even operates with the unit in other modes.
● ISR memory
1. Select the station that you wish to store in ISR
memory.
2. Press and hold the [ISR] button for 2 seconds
or longer.
● Recalling a station with ISR
In any mode, press the [ISR] button to turn on
the radio function and tune the selected radio
station. “ISR” appears in the display. Press the
[ISR] button again to return to the previous
mode.
English
DXZ755MC 15
CD/MP3/WMA Operations
English
MP3/WMA
What is MP3?
MP3 is an audio compression method and classified into audio layer 3 of MPEG standards.
This audio compression method has penetrated
into PC users and become a standard format.
This MP3 features the original audio data compression to about 10 percent of its initial size
with a high sound quality. This means about 10
music CDs can be recorded on a CD-R disc or
CD-RW disc to allow a long listening time without having to change CDs.
What is WMA?
WMA is the abbreviation of Windows Media Audio, an audio file format developed by Microsoft
Corporation.
Notes:
• If you play a file with DRM (Digital Rights Management) for WMA remaining ON, no audio is
output. (The DRM indicator blinks.)
• Windows Media™, and the Windows® logo are
trademarks, or registered trademarks of Microsoft
Corporation in the United States and/or other
countries.
● To disable DRM (Digital Rights Manage-
ment):
1. When using Windows Media Player 8, click
on TOOLS ➜ OPTIONS ➜ COPY MUSIC
tab, then under COPY SETTINGS, unclick
the check box for PROTECT CONTENT.
Then, reconstruct files.
2. When using Windows Media Player 9, click
on TOOL ➜ OPTIONS ➜ MUSIC RECORD
tab, then under Recording settings, unclick
the Check box for RECORD PROTECTED
MUSIC. Then, reconstruct files.
Personally constructed WMA files are used
at your own responsibility.
Precautions when creating MP3/WMA disc
● Usable sampling rates and bit rates:
1. MP3: Sampling rate 11.025 kHz-48 kHz,
Bit rate: 8 kbps-320 kbps / VBR
2. WMA: Bit rate 48 kbps-192 kbps
● File extensions
1. Always add a file extension “.MP3” or
“.WMA” to MP3 or WMA file by using single
byte letters. If you add a file extension other
than specified or forget to add the file extension, the file cannot be played.
2. Files without MP3/WMA data will not play.
The indication “––:––” appears in the play
time display if you attempt to play files without MP3/WMA data.
● Logical format (File system)
1. When writing MP3/WMA file on a CD-R disc
or CD-RW disc, please select “ISO9660
level 1, 2 or JOLIET or Romeo” as the writing software format. Normal play may not be
possible if the disc is recorded on another
format.
2. The folder name and file name can be displayed as the title during MP3/WMA play but
the title must be within 128 single byte alphabetical letters and numerals (including an extension).
3. Do not affix a name to a file inside a folder
having the same name.
● Folder structure
1. A disc with a folder having more than 8 hierarchical levels will be impossible.
● Number of files or folders
1. Up to 255 files can be recognized per folder.
Up to 500 files can be played.
2. Tracks are played in the order that they were
recorded onto a disc. (Tracks might not always be played in the order displayed on the
PC.)
3. Some noise may occur depending on the type
of encoder software used while recording.
Multisession function
When a disc contains both normal CD type tracks
and MP3/WMA type tracks mixedly, you can select which type of the recorded tracks to play.
● Default value is “CD”.
Each time you press and hold the [BND] button
for 1 second or longer, the mixed mode is
switched between CD type and MP3/WMA type.
1. Types of recording that can be played are as
follows.
Disc
Mixed with CD and
MP3/WMA type tracks
CD type track only
MP3/WMA type track only
2. After making these settings, remove the disc
Setting
and then reinsert it.
Set to CD
Play CD
Play CD Play CD
Play MP3/WMA
Set to MP3/WMA
Play MP3/WMA
Play MP3/WMA
16 DXZ755MC
3. When a mixed mode CD is loaded and CD is
set, the track to be played first is MP3/WMA
file data and no sound is heard.
Note:
• When playing a CCCD (Copy Control CD), set the
setting to CD type. When this is set to MP3/WWA
type, the CD cannot be played normally in some
cases.
Disc-In-Play function
As long as the ignition key is turned to the ON or
ACC position, this function allows you to turn the
power to the unit and start playing the disc automatically when the disc is inserted even if the
power is not turned on.
CD/MP3/WMA Operations
CAUTION
• Be careful not to catch your hand or fingers while closing the SLOPING CONSOLE.
• Do not try to put your hand or fingers in
the disc insertion slot. Also never insert
foreign objects into the slot.
• Do not insert discs where adhesive comes
out from cellophane tape or a rental CD label, or discs with marks where cellophane
tape or rental CD labels were removed. It
may be impossible to extract these discs
from the unit and they may cause the unit
to break down.
English
Loading a CD
1. Press the [Q] button. The SLOPING
CONSOLE opens.
2. Insert a CD into the center of the CD SLOT
with the label side facing up. The CD plays
automatically after loading.
Notes:
•Never insert foreign objects into the CD SLOT.
• If the CD does not insert easily, there may be an-
other CD in the mechanism or the unit may require service.
• Discs not bearing the or mark and
CD-ROMs cannot be played by this unit.
• Some CDs recorded in CD-R/CD-RW mode may
not be usable.
Loading 8 cm compact discs
∗ No adapter is required to play an 8 cm CD.
∗ Insert the 8 cm CD into the center of the insertion
slot.
Backup Eject function
Pressing the [Q] button ejects the disc even if
the power to the unit is not turned on.
1. Press the [Q] button. Remove the disc after
it is ejected.
Note:
• Always close the sloping console after opening it
or ejecting the CD.
Listening to a disc already loaded
in the unit
Press the [SRC] button to select the CD/MP3/
WMA mode.
When the unit enters the CD/MP3/WMA mode,
play starts automatically.
If there is no disc loaded, the indication “
DISC”
appears in the display.
NO
Pausing play
1. Press the [ ] button to pause play.
“PAUSE” appears in the display.
2. To resume CD play, press the [ ] button
again.
Displaying CD titles
This unit can display title data for CD-text/MP3/
WMA disc and user titles input with this unit.
1. Each time you press the [TITLE] button, the
title changes in the following order:
● CD-TEXT disc
User title (disc) ➜ CD-text title (disc) ➜
Artist name ➜ CD-text title (track) ➜ User
title (disc)...
● MP3/WMA disc
Folder ➜ Track ➜ Album ➜ Artist ➜ Title
➜ Folder...
● M.CATCHER
Folder Track
DXZ755MC 17
CD/MP3/WMA Operations
English
Notes:
• If the CD playing is not a CD-text CD or no user
title has been input, “NO TITLE” appears in the
display.
• If MP3/WMA disc is not input TAG, “NO TITLE”
appears in the display.
•For MP3, supports ID3 Tags V2.3 / 2.2 / 1.1 / 1.0.
•Tag displays give priority to V2.3 / 2.2.
• In the case of album Tags for WMA, the information written into the extension header is displayed.
• Only ASCII characters can be displayed in Tags.
Selecting a track
● Track-up
1. Move the [a]/[d] lever up to move ahead
to the beginning of the next track.
2. Each time you move the lever up, the track
advances ahead to the beginning of the next
track.
● Track-down
1. Move the [a]/[d] lever down to move back
to the beginning of the current track.
2. Move the lever down twice to move to the
beginning of the previous track.
Fast-forward/fast-rewind
● Fast-forward
Move the [a]/[d] lever up for 1 second or
longer.
● Fast-rewind
Move the [a]/[d] lever down for 1 second or
longer.
∗ For MP3/WMA discs, it takes some time until the
start of searching and between tracks. In addition,
the playing time may have a margin of error.
Top function
The top function resets the CD player to the first
track of the disc. Press the [BND] button to play
the first track (track No. 1) on the disc.
∗ In case of MP3/WMA, the first track of a folder be-
ing played will be returned.
Scan play
This function allows you to locate and play the
first 10 seconds of all the tracks recorded on a
disc.
1. Press the [SCN] button to perform scan play.
∗ Scan play starts from the next track after the
track currently being played.
2. To cancel scan play, press the [SCN] button
again.
Folder scan play
This function allows you to locate and play the
first 10 seconds of the first track of all the folders on an MP3/WMA disc.
1. Press and hold the [SCN] button for 1 sec-
ond or longer to perform folder scan play.
∗ Folder scan play starts from the next track af-
ter the track currently being played.
2. To cancel folder scan play, press the [SCN]
button again.
Repeat play
This function allows you to play the current track
repeatedly.
1. Press the [RPT] button to perform repeat play.
2. To cancel repeat play, press the [RPT] button
again.
Folder select
This function allows you to select a folder containing MP3/WMA files and start playing from
the first track in the folder.
1. Press the [DN] button to move to the previ-
ous folder.
Press the [UP] button to move to the next
folder.
∗ Press the [UP] button while in the final folder
to shift to the first folder.
∗ Folder without an MP3/WMA file is not select-
able.
18 DXZ755MC
Folder repeat play
This function allows you to play a track currently
being played in the MP3/WMA folder repeatedly.
1. Press and hold the [RPT] button for 1 second
or longer to perform folder repeat play.
2. To cancel folder repeat play, press the [RPT]
button again.
Random play
This function allows you to play all tracks recorded on a disc in a random order.
1. Press the [RDM] button to perform random
play.
2. To cancel random play, press the [RDM] but-
ton again.
Folder random play
This function allows you to play all the tracks of
all the folders recorded on an MP3/WMA disc in
a random order.
1. Press and hold the [RDM] button for 1 sec-
ond or longer to perform folder random play.
2. To cancel folder random play, press the
[RDM] button again.
Play list mode
This function allows you to play tracks, up to latest 5 time stamps, by reading the play list information written on the disc.
1. Press and hold the [P.LIST] button for 1 sec-
ond or longer to turn on or off the play list
mode.
∗ Play list play is possible only when there is a
file whose extension is “.M3U” on the CD-R/
RW.
∗ Up to 5 play lists can be recognized, and up to
255 files can be recognized per play list.
2. Press the [DN] button to move to the previ-
ous play list.
Press the [UP] button to move to the next
play list.
Notes:
• The SCN/RPT/RDM functions cannot be used
while in the play list mode.
• The title changes from folder name to play list
name.
CD/MP3/WMA Operations
Notes:
• When writing to a CD-R/RW, etc., be sure to use
alphanumeric/ASCII characters.
• Up to 5 layers can be recognized as a list. For
written play lists, latest 5 lists are recognized in
the order in which they are written.
• When writing to a CD-R/RW, etc., turn off the Disc
At Once function.
• When adding a play list, it is recommended to
write it in the “Root” folder.
MUSIC CATCHER
In the M.CATCHER mode, the files recorded in
the built-in flash memory are played back. Operations for listening to a recording made using
MUSIC CATCHER are the same as “CD/MP3/
WMA Operations”. For operations for recoding
using MUSIC CATCHER, refer to the section
“MUSIC CATCHER Operations”.
English
Making a play list
1. Write desired tracks to a CD-R/RW, etc. Be
sure to use alphanumeric/ASCII characters
for all file names.
2. Make a play list by using a multimedia
player, etc. and save the data. The file format
must be M3U.
3. Again, write this play list to the CD-R/RW,
etc.
DXZ755MC 19
MUSIC CATCHER Operations
English
Setting a recording mode
MUSIC CATCHER can be switched between 2
recording modes:
• HQ (High Quality) MODE: about 265 minutes
• LP (Long Play) MODE: about 353 minutes
∗ The factory default setting is “HQ”.
1. Press the [ADJ] button to switch to the adjust
mode.
2. Move the [a]/[d] lever to select “MC-REC
MODE”.
3. Turn the [ROTARY] knob to select “HQ” or
“LP”.
4. Press the [ADJ] button to return to the previ-
ous mode.
Notes on recording using MUSIC
CATCHER:
• Recording operations are to be performed in
the CD/MP3/WMA mode.
• Recordable media are CD-DAs only.
• Discs (CD-R/CD-RW) created by copying on a
music recorder cannot be recorded.
• MP3/WMA discs cannot be recorded.
• Some CDs may show a subtractive time indi-
cation in the area between tracks when they
are played back. A between-tracks area is not
recorded in such a CD.
• In recording using MUSIC CATCHER, some
amount of silent time is created between the
tracks.
• If the disc contains some tracks that have been
already recorded, the other tracks are recorded.
• Folder and track names are added automati-
cally during recording.
• If the disc is not recordable, “NO REC DISC”
appears on the display.
• If the disc contains some tracks previously re-
corded, “INCLUDED” appears on the display.
• If there is no empty folder available, “FOLDER
FULL” appears on the display.
• When the memory capacity is used up,
“MEMORY FULL” appears on the display and
recording is canceled.
• Recording cannot be performed during SCN,
RPT, and RDM. In such cases, “BUSY” appears on the display.
• The [ ], [BND], and [SCN/RPT/RDM] but-
tons and the [a]/[d] lever are invalid during
recording. When these buttons are pressed,
“INVALID” appears on the display.
20 DXZ755MC
Recording operation (REC function)
Recording using MUSIC CATCHER is performed
in the CD/MP3/WMA mode and the following 2
recording modes are available: “TRACK REC” to
record only one track currently being played back
and “DISC REC” to record all tracks on the CD.
● TRACK REC
1. Press the [SRC] button to select the CD/
MP3/WMA mode.
2. Play back a track to be recorded, and press
the [REC] button to start recording. “TRACK
REC” appears on the display for 2 seconds
then the “REC” indicator lights on the display.
∗ When recording is complete, the “REC” indi-
cator goes off and “REC DONE” appears on
the display for 2 seconds.
● DISC REC
1. Press the [SRC] button to select the CD/
MP3/WMA mode.
2. Play back a CD to be recorded, and press
and hold the [REC] button for 2 seconds or
longer to start recording. “DISC REC” appears on the display for 2 seconds then the
“REC” indicator lights on the display.
∗ When recording is complete, the “REC” indi-
cator goes off and “REC DONE” appears on
the display for 2 seconds.
Canceling recording
1. Press the [REC] button to cancel the record-
ing process.
The display shows “CANCELED” for 2 seconds and then the playback of the CD continues.
Notes:
• Recording also can be canceled by pressing the
[SRC], [Q] or [ISR] button.
• When recording is canceled, the track that has
been recorded incompletely is deleted.
Erasing operation (ERASE function)
MUSIC CATCHER has 3 different modes for
erasing files from memory.
“TRACK ERASE”:erase only one track.
“FOLDER ERASE”:erase the whole folder.
“ALL ERASE”:erase all the contents of
the flash memory.
1. Press the [SRC] button to select the
M.CATCHER mode.
MUSIC CATCHER Operations
2. Each time you press the [ERASE] button, the
display switches in the following order:
TRACK ERASE ➜ FOLDER ERASE ➜
Normal mode
Notes:
• When a selected track or folder is erased, the approximate recordable time is shown (the recordable time shown varies according to the set recording mode).
• Do not turn off the power to the unit or switch the
operation mode during erasing recordings.
● TRACK ERASE
1. Press the [SRC] button to select the
M.CATCHER mode.
2. Play back a track to be erased, and press
the [ERASE] button to select “TRACK
ERASE”.
3. Press and hold the [ ] button for 2 sec-
onds or longer. The display shows “ERAS-
ING” as the track currently being played back
is erased.
● FOLDER ERASE
1. Press the [SRC] button to select the
M.CATCHER mode.
2. Play back any track of the folder to be
erased, and press the [ERASE] button to select “FOLDER ERASE”.
3. Press and hold the [ ] button for 2 sec-
onds or longer. The display shows “ERAS-
ING” as the folder currently being played
back is erased.
● ALL ERASE
1. Press the [SRC] button to select the
M.CATCHER mode.
2. Press the [ERASE] button for 2 seconds or
longer to select “ALL ERASE”.
3. Press and hold the [ ] button for 2 sec-
onds or longer. The display shows “ERAS-
ING” as ALL ERASE is executed.
Remaining capacity of the memory
By pressing the [REC] button while in the
M.CATCHER mode, the remaining capacity of
the flash memory can be displayed for 4 seconds as an approximate recordable time in “MM
(minute): SS (second)”.
The display shows “AVIL. 123:45”.
Note:
• The recordable time shown varies according to
the set recording mode
Common Operations
Display Adjust Mode
Setting the clock
1. Press and hold the [DISP] button for 1 second
or longer to switch to the display adjust mode.
2. Move the [a]/[d] lever to select “CLOCK”.
3. Press the [ ] button.
4. Move the lever to select the hour or the
minute.
5. Turn the [ROTARY] knob to set the correct
time.
∗ The clock is displayed in 12-hour format.
6. Press the [ ] button to store the time into
memory.
7. Press the [DISP] button to return to the previ-
ous mode.
Note:
•You cannot set the clock when it is displayed with
only the ignition on. If you drain or remove the car’s
battery or take out this unit, the clock is reset.
While setting the clock, if another button or operation is selected, the clock set mode is canceled.
Switching the patterns of the
spectrum analyzer display
∗ The factory default setting is “SRC ICON”.
1. Press and hold the [DISP] button for 1 second
or longer to switch to the display adjust mode.
2. Move the [a]/[d] lever to select “SPE/ANA
PTN”.
3. Turn the [ROTARY] knob to select the set-
ting. Each time you turn the [ROTARY] knob,
the setting changes in the following order:
1 ➜ 2 ➜ 3 ➜ 4 ➜ SRC ICON
∗ “SRC ICON” cannot be selected in the sub
display.
4. Press the [DISP] button to return to the previ-
ous mode.
Setting the sensitivity of the
spectrum analyzer display
∗ The factory default setting is “MID”.
1. Press and hold the [DISP] button for 1 second
or longer to switch to the display adjust mode.
2. Move the [a]/[d] lever to select “S/A
SENS”.
3. Turn the [ROTARY] knob to select from
“LOW”, “MID” or “HIGH”.
4. Press the [DISP] button to return to the previ-
ous mode.
English
DXZ755MC 21
Common Operations
English
Setting the speed of the spectrum
analyzer display
∗ The factory default setting is “HIGH”.
1. Press and hold the [DISP] button for 1 second
or longer to switch to the display adjust mode.
2. Move the [a]/[d] lever to select “S/A
SPEED”.
3. Turn the [ROTARY] knob to select from
“LOW”, “MID” or “HIGH”.
4. Press the [DISP] button to return to the previ-
ous mode.
Turning the screen saver function
on or off
This unit features various screen saver patterns
that are exhibited across the display. If the
screen savers are not desired, they can be
turned off.
If the button operation is performed with the
screen saver function on, the operation display
corresponding to the button operation is shown
for about 30 seconds and the display returns to
the screen saver display.
∗ The factory default setting is “RANDOM”.
1. Press and hold the [DISP] button for 1 second
or longer to switch to the display adjust mode.
2. Move the [a]/[d] lever to select “SCREEN
SVR”.
3. Press the [ ] button.
4. Turn the [ROTARY] knob to select the set-
ting. Each time you turn the [ROTARY] knob,
the setting changes in the following order:
OFF ➜ SS1 ➜ SS2 ➜ SS3 ➜ MESSAGE ➜
RANDOM
5. Press the [DISP] button to return to the previ-
ous mode.
Entering MESSAGE INFORMATION
When “MESSAGE” is selected for the screen
saver setting, you can change the contents of
the message.
∗ Up to 30 characters can be entered.
∗ The factory default setting is “Welcome to
Clarion”.
1. Press and hold the [DISP] button for 1 second
or longer to switch to the display adjust mode.
2. Move the [a]/[d] lever to select
“MSG INPUT”.
3. Press the [ ] button.
4. Move the lever to move the cursor.
5. Press the [BND] button to select a character.
Each time you press the [BND] button, the
character changes in the following orders:
Capital letters ➜ Small letters ➜ Numbers
and Symbols ➜ Umlaut ➜ Capital letters…
6. Turn the [ROTARY] knob to select the de-
sired character.
7. Repeat steps 4 to 6 to enter up to 30 characters for message.
8. Press and hold the [ ] button for 2 seconds
or longer to store the message in memory and
return to the display adjust mode.
∗ Press and hold the [BND] button for 1 second
or longer to delete the message. Then press
and hold the [ ] button for 2 seconds or
longer to return the message to the default
setting.
9. Press the [DISP] button to return to the previ-
ous mode.
Setting the method for title scroll
Set how to scroll in CD-TEXT, MP3/WMA TITLE.
∗ The factory default setting is “ON”.
1. Press and hold the [DISP] button for 1 second
or longer to switch to the display adjust mode.
2. Move the [a]/[d] lever to select “AUTO
SCROLL”.
3. Turn the [ROTARY] knob to select “ON” or
“OFF”.
● ON:
Scrolls automatically.
● OFF:
Scrolls just 1 time when the title was
changed or you press and hold the [TITLE]
button for 1 second or longer.
4. Press the [DISP] button to return to the previ-
ous mode.
Setting the speed of title scroll
∗ The factory default setting is “SPEED3”. (Speed:1
to 6)
1. Press and hold the [DISP] button for 1 second
or longer to switch to the display adjust mode.
2. Move the [a]/[d] lever to select “SCRL
SPEED”.
3. Turn the [ROTARY] knob to select the setting.
4. Press the [DISP] button to return to the previ-
ous mode.
22 DXZ755MC
Dimmer control
You can set the dimmer control.
∗ The factory default setting is “3”. (Setting level: OFF,
1 to 5)
1. Press and hold the [DISP] button for 1 second
or longer to switch to the display adjust mode.
2. Move the [a]/[d] lever to select
“DIMMER LV”.
3. Turn the [ROTARY] knob to select the set-
ting.
4. Press the [DISP] button to return to the previ-
ous mode.
Adjusting the display contrast
You can adjust the display contrast to match the
angle of installation of the unit.
∗ The factory default setting is “8”. (Adjustment level:
1 to 16)
1. Press and hold the [DISP] button for 1 second
or longer to switch to the display adjust mode.
2. Move the [a]/[d] lever to select
“CONTRAST”.
3. Turn the [ROTARY] knob to adjust the con-
trast.
4. Press the [DISP] button to return to the previ-
ous mode.
Adjust Mode
Anti-theft indicator
The red Anti-theft indicator is a function for
detering theft. When the DCP is removed from
the unit, this indicator blinks.
∗ The factory default setting is “OFF”.
1. Press the [ADJ] button to switch to the adjust
mode.
2. Move the [a]/[d] lever to select “BLINK
LED”.
3. Turn the [ROTARY] knob to select “ON” or
“OFF”.
4. Press the [ADJ] button to return to the previ-
ous mode.
Common Operations
Setting the subwoofer
∗ The factory default setting is “ON”.
1. Press the [ADJ] button to switch to the adjust
mode.
2. Move the [a]/[d] lever to select “SUB-W”.
3. Turn the [ROTARY] knob to select “ON” or
“OFF”.
4. Press the [ADJ] button to return to the previ-
ous mode.
Setting the low pass filter
∗ The factory default setting is “THROUGH”.
1. Press the [ADJ] button to switch to the adjust
mode.
2. Move the [a]/[d] lever to select
“SUB-W LPF”.
3. Turn the [ROTARY] knob to select the set-
ting. Each time you turn the [ROTARY] knob,
the setting changes in the following order:
THROUGH ➜ 50Hz ➜ 80Hz ➜ 120Hz
4. Press the [ADJ] button to return to the previ-
ous mode.
Setting the amplifier bypass circuit
∗ The factory default setting is “OFF”.
1. Press the [ADJ] button to switch to the adjust
mode.
2. Move the [a]/[d] lever to select “AMP
CANCEL”.
3. Turn the [ROTARY] knob to select “ON” or
“OFF”.
● ON:
Uses with connected AMP.
● OFF:
Uses with inside AMP.
4. Press the [ADJ] button to return to the previ-
ous mode.
English
DXZ755MC 23
Common Operations
English
Displaying the Sirius ID No.
∗ This function only applies when a Sirius receiver is
connected.
∗ The factory default setting is the upper 6 digits.
1. Press the [ADJ] button to switch to the adjust
mode.
2. Move the [a]/[d] lever to select “SID
DISP”.
3. Turn the [ROTARY] knob to switch between
the display for the upper 6 digits and lower 6
digits.
4. Press the [ADJ] button to return to the previ-
ous mode.
Adjusting the auxiliary input
sensitivity
Adjust the auxiliary sensitivity when the audio
from an external device is difficult to hear even
after adjusting the volume.
∗ The factory default setting is “MID”.
1. Press the [ADJ] button to switch to the adjust
mode.
2. Move the [a]/[d] lever to select
“AUX SENS”.
3. Turn the [ROTARY] knob to select from
“LOW”, “MID” or “HIGH”.
4. Press the [ADJ] button to return to the previ-
ous mode.
Performing a system check
This function verifies the devices hooked up
through CeNET.
1. Press the [ADJ] button to switch to the adjust
mode.
2. Move the [a]/[d] lever to select “SYSTEM
CHECK”.
3. Press and hold the [ ] button for 1 second or longer to start the system check.
The digital connection configuration is automatically checked.
When the system check is complete, the display returns to the previous mode.
Other operations
Setting the button illumination
Press the [COLOR] button to select a color.
Each time you press the [COLOR] button, the
color changes in the following order:
COLOR SCAN ➜ Indigo Blue ➜ Surf Blue ➜
Silky White ➜ Aqua Green ➜ Fresh Green ➜
Leaf Green ➜ Warm Amber ➜ Passion Red
➜ Vivid Pink ➜ Pale Pink ➜ Dark Violet ➜
Pure Purple ➜ USER COLOR1 ➜ USER
COLOR2 ➜ USER COLOR3 ➜ COLOR
SCAN...
● Setting COLOR SCAN mode
Selecting “COLOR SCAN”, the color automatically changes.
∗ The factory default setting is “COLOR SCAN”.
∗ Every 3 seconds the color changes to another.
● Setting USER mode
∗ The factory default setting is “RED 8, GREEN 8,
BLUE 8”.
Selecting “USER COLOR 1, 2, 3”, press and
hold the [COLOR] button for 1 second or longer.
“RED 8” appears in the display.
1. Move the [a]/[d] lever to move the cursor.
2. Turn the [ROTARY] knob to select from 0 to
8.
3. Press and hold the [ ] button for 2 seconds or longer to store the color in memory
and return to the previous mode.
COLOR
Indigo Blue
Surf Blue
Silky White
Aqua Green
Fresh Green
Leaf Green
Warm Amber
Passion Red
Vivid Pink
Pale Pink
Dark Violet
Pure Purple
USER COLOR 1
USER COLOR 2
USER COLOR 3
R
G
B
0
0
8
0
4
8
8
8
7
0
8
2
0
8
0
3
8
0
8
3
0
8
0
0
8
0
3
8
2
3
3
0
8
6
0
8
8
8
8
8
8
8
8
8
8
24 DXZ755MC
Entering titles
Titles up to 10 characters long can be stored in
memory and displayed for CD, M.CATCHER,
CD changer and Radio/TV stations. The number
of titles that can be entered for each mode are
as follows.
Mode Number of titles
CD mode 50 titles
TV mode 20 titles
Radio mode 30 titles
CD changer mode Number of titles
DCZ625 connected 100 titles
CDC655Tz connected 100 titles
CDC1255z connected 50 titles
1. Press the [SRC] button to select the mode
you want to enter a title (Radio, CD,
M.CATCHER, CD changer or TV).
2. Play a track or tune in to a radio/TV station
for which you want to enter the title.
3. Do one of the following:
● In the CD or CD changer mode
Press the [TITLE] button to select “USER”.
● In the M.CATCHER mode
Press the [TITLE] button to select
“FOLDER”.
∗ In the title display, select “FOLDER” in the up-
per title.
● In the radio or TV mode
Skip this step.
4. Press and hold the [TITLE] button for 1 sec-
ond or longer to switch to the title input display.
5. Move the [a]/[d] lever to move the cursor.
6. Press the [BND] button to select a character.
Each time you press the [BND] button, the
character changes in the following order:
Capital letters ➜ Small letters ➜ Numbers
and Symbols ➜ Umlaut ➜ Capital letters…
7. Turn the [ROTARY] knob to select the de-
sired character.
8. Repeat steps 5 to 7 to enter up to 10 characters for the title.
9. Press and hold the [ ] button for 2 seconds or longer to store the title into memory
and return to the previous mode.
Common Operations
Clearing titles
1. Play a track or tune in to a radio/TV station
for which you want to delete the title.
2. Do one of the following:
● In the CD or CD changer mode
Press the [TITLE] button to select “USER”.
● In the M.CATCHER mode
Press the [TITLE] button to select
“FOLDER”.
∗ In the title display, select “FOLDER” in the up-
per title.
● In the radio or TV mode
Skip this step.
3. Press and hold the [TITLE] button for 1 sec-
ond or longer to switch to the title input display.
4. Press and hold the [BND] button for 1 sec-
ond or longer to delete the title.
5. Press and hold the [ ] button for 2 seconds or longer to store the setting and return
to the previous mode.
Cellular telephone mute
This unit requires special wiring to mute the audio signal automatically when a cellular telephone rings in the car.
∗ This function is not compatible with all cellular tele-
phones. Contact your local authorized Clarion
dealer for information on proper installation and
compatibility.
AUX function
This system has an external input jack so you
can listen to audio from an external device connected to this unit.
English
DXZ755MC 25
English
8. OPERATIONS OF ACCESSORIES
CD Changer Operations
CD changer functions
When an optional CD changer is connected
through the CeNET cable, this unit controls all
CD changer functions. This unit can control a total of 2 changers.
Press the [SRC] button and select the CD
changer mode to start play. If 2 CD changers
are connected, press the [SRC] button to select
the CD changer for play.
∗ If “NO MAGAZINE” appears in the display, insert
the magazine into the CD changer. “DISC CHECK”
appears in the display while the player loads
(checks) the magazine.
∗ If “NO DISC” appears in the display, eject the maga-
zine and insert discs into each slot. Then, reinsert
the magazine back into the CD changer.
Note:
• Some CDs recorded in CD-R/CD-RW mode may
not be usable.
CAUTION
CD-ROM discs cannot be played from every
CD changer, it’s depended on the model.
Pausing play
1. Press the [ ] button to pause play.
“PAUSE” appears in the display.
2. To resume play, press the [ ] button again.
Displaying CD titles
This unit can display title data for CD-text CDs
and user titles input with this unit.
● When connected to CDC655Tz or DCZ625
1. Each time you press the [TITLE] button, the
title changes in the following order:
User title (disc) ➜ CD-text title (disc) ➜
Artist name ➜ CD-text title (track) ➜ User
title (disc)…
Notes:
• If the CD playing is not a CD-text CD or no user
title has been input, “NO TITLE” appears in the
display.
• If a CD-text CD is not input its disc title or a track
title, “NO TITLE” appears in the display.
Procedure to scroll a title
Set “SCROLL” to “ON” or “OFF”.
(The factory default setting is “ON”. Refer to the
subsection “Setting the method for title scroll”
in the section “ Common Operations ”.)
● When set to “ON”
The title is automatically kept scrolling.
● When set to “OFF”
To scroll just 1 time when the title was changed
or you press and hold the [TITLE] button for 1
second or longer.
Selecting a CD
Press the [UP] or [DN] button to select the desired disc.
∗ If a CD is not loaded in a slot of magazine, pressing
the [UP] or [DN] button can not work.
Selecting a track
● Track-up
1. Move the [a]/[d] lever up to move ahead
to the beginning of the next track.
2. Each time you move the lever up, the track
advances ahead to the beginning of the next
track.
● Track-down
1. Move the [a]/[d] lever down to move back
to the beginning of the current track.
2. Move the lever down twice to move to the
beginning of the previous track.
Fast-forward/fast-rewind
● Fast-forward
Move the [a]/[d] lever up for 1 second or
longer.
● Fast-rewind
Move the [a]/[d] lever down for 1 second or
longer.
26 DXZ755MC
Scan play
Scan play locates and plays the first 10 seconds
of each track on a disc automatically. This function continues on the disc until it is cancelled.
∗ The scan play is useful when you want to select a
desired track.
1. Press the [SCN] button.
2. To cancel the scan play, press the [SCN] but-
ton again.
Disc scan play
Disc scan play locates and plays the first 10
seconds of the first track on each disc in the
currently selected CD changer. This function
continues automatically until it is cancelled.
∗ Disc scan play is useful when you want to select a
desired CD.
1. Press and hold the [SCN] button for 1 sec-
ond or longer.
2. To cancel disc scan play, press the [SCN]
button again.
Repeat play
Repeat play continuously plays the current
track. This function continues automatically until
it is cancelled.
1. Press the [RPT] button.
2. To cancel repeat play, press the [RPT] button
again.
CD Changer Operations
Disc random play
The disc random play selects and plays individual tracks or discs automatically in no particular order. This function continues automatically until it is cancelled.
1. Press and hold the [RDM] button for 1 sec-
ond or longer.
2. To cancel disc random play, press the [RDM]
button again.
English
Disc repeat play
After all the tracks on the current disc have
been played, disc repeat play automatically replays the current disc over from the first track.
This function continues automatically until it is
cancelled.
1. Press and hold the [RPT] button for 1 second
or longer.
2. To cancel disc repeat play, press the [RPT]
button again.
Random play
Random play selects and plays individual tracks
on the disc in no particular order. This function
continues automatically until it is cancelled.
1. Press the [RDM] button.
2. To cancel random play, press the [RDM] but-
ton again.
DXZ755MC 27
TV Operations
English
TV tuner functions
When an optional TV tuner is connected through
the CeNET cable, this unit controls all TV tuner
functions. To watch TV it requires a TV tuner
and a monitor.
Watching a TV
1. Press the [SRC] button and select the TV
mode.
2. Press the [BND] button to select the desired
TV band (TV1 or TV2). Each time the button
is pressed, the input selection toggles between TV1 and TV2.
3. Move the [a]/[d] lever to tune in the de-
sired TV station.
Watching a video
The TV tuner features a VTR input for an external A/V source, such as a DVD player or game
station.
1. Press and hold the [ADJ] button for 1 second
or longer to select VTR.
2. To return to the TV broadcast, press and
hold the [ADJ] button for 1 second or longer.
TV tuning
There are 3 types of TV tuning modes available,
seek, manual and preset tuning.
Seek tuning
1. Press the [BND] button and select the de-
sired TV band (TV1 or TV2).
∗ If “MANU” is lit in the display, press and hold
the [BND] button for 1 second or longer.
“MANU” in the display goes off and seek tuning is now available.
2. Move the [a]/[d] lever to automatically
seek a station. Move the lever up to automatically tune up the frequency band to the
next available TV station; move the lever
down to automatically tune down.
Manual tuning
There are 2 ways available: Quick tuning and
step tuning.
When you are in the step tuning mode, the frequency changes one step at a time. In the quick
tuning mode, you can quickly tune the desired
frequency.
1. Press the [BND] button and select the de-
sired band (TV1 or TV2).
∗ If “MANU” is not lit in the display, press and
hold the [BND] button for 1 second or longer.
“MANU” lights in the display and manual tuning is now available.
2. Tune into a station.
● Quick tuning:
Move the [a]/[d] lever for 1 second or
longer to tune in a station.
● Step tuning:
Move the [a]/[d] lever to manually tune in
a station.
Recalling a preset station
A total of 12 TV stations can be stored (6-TV1
and 6-TV2). This allows you to select your favorite TV stations and store them in memory.
1. Press the [BND] button and select the de-
sired TV band (TV1 or TV2).
2. To recall a stored TV station, press the desired [DIRECT] button to select that station.
∗ Press and hold one of the [DIRECT] buttons
for 2 seconds or longer to store the current
station into preset memory.
Manual memory
1. Select the desired station with seek tuning,
manual tuning or preset tuning.
2. Press and hold one of [DIRECT] buttons for
2 seconds or longer to store the current station into preset memory.
28 DXZ755MC
Auto store
Auto store selects 6 TV stations automatically
and stores each one into preset memory.
If the 6 stations with good reception are available, stations previously stored in memory remain. Only stations with strong reception are
stored into memory.
1. Press the [BND] button and select the de-
sired TV band (TV1 or TV2).
2. Press and hold the [PS/AS] button for 2 sec-
onds or longer. The stations with good reception are stored automatically to the preset
channels.
Preset scan
Preset scan allows the user to view each preset
position before it automatically advances to the
next preset. This function is useful for searching
for a desired TV station in memory.
1. Press the [PS/AS] button.
2. When the desired station is found, press the
[PS/AS] button again to remain tuned to that
station.
Note:
• Do not press and hold the [PS/AS] button for 2
seconds or longer. Doing so will trigger the auto
store function and start storing stations into
memory.
TV Operations
English
Setting the TV diver
You can change the reception setting for the TV
antenna connected to the TV tuner.
∗ The factory default setting depends on the TV.
1. Press the [ADJ] button to switch to the adjust
mode.
2. Move the [a]/[d] lever to select “TV
DIVER”.
3. Turn the [ROTARY] knob to select “ON” or
“OFF”.
● ON:
Sets the diver setting to ON.
● OFF:
Sets the diver setting to OFF.
4. Press the [ADJ] button to return to the previ-
ous mode.
DXZ755MC 29
English
9. IN CASE OF DIFFICULTY
Problem
Power does not
turn on.
(No sound is
produced.)
No audio when
operating the unit
with amplifiers.
Nothing happens
when buttons are
pressed.
General
Display is not
accurate.
No audio.
No audio.
CD/MP3/WMA
Sound skips or is
noisy.
Cause
Fuse is blown.
Incorrect wiring.
Amplifier turn-on lead is
shorted to ground or
excessive current is required.
The microprocessor has
malfunctioned due to noise,
etc.
DCP or main unit connectors
are dirty.
The speaker protection
circuit is operating.
There is a disc other than a
compact disc or foreign
object already in place.
MP3/WMA files are absent
on the disc.
Files are not recognized as
an MP3/WMA file.
File system is not correct.
Disc is dirty.
Disc is heavily scratched or
warped.
Measure
Replace with a fuse of the same amperage. If the
fuse blows again, consult Clarion dealer.
Consult Clarion dealer.
Turn the unit off and check each wire for a possible
short. If the amplifier turn-on lead shorts out, cover it
with insulation such as tape.
Turn off the power, then
press the [RELEASE]
button and remove the DCP.
Press the reset button for
about 2 seconds with a thin
rod.
Wipe the dirt off with a soft cloth moistened with
cleaning alcohol.
1. Check the speaker connection.
2. Turn down sound volume. Function can also be
restored by turning the power off and on again.
3. If the sound is muted again, consult Clarion
dealer.
With the sloping console open, press and hold the
[Q] button for 3 seconds or longer.
The foreign object is forcibly ejected.
Write MP3/WMA files onto the disc properly.
Use MP3/WMA files encoded properly.
Use ISO9660 level 1, 2 or JOLIET or Romeo file system.
Clean the disc with a soft cloth.
Replace with a disc with no scratches.
Reset button
30 DXZ755MC
Problem
Sound is cut or
skipped.
Noise is
generated or
noise is mixed
with sound.
Cause Measure
MP3/WMA files are not
encoded properly.
Use MP3/WMA files encoded properly.
English
Poor sound
quality in
extremely cold
weather or
extreme humidity.
CD/MP3/WMA
Wrong filename
Play list play is
not performed.
Water droplets may form on
the internal lens when the
car is parked in a humid
place.
File system is not correct.
File name or extension is not
correct.
Let dry for about 1 hour with the power on.
Use ISO9660 level 1, 2 or JOLIET or Romeo file
system.
Use alphanumeric/ASCII characters for MP3/WMA
file name.
Use “.M3U” for the file extension of a play list.
DXZ755MC 31
English
10. ERROR DISPLAYS
If an error occurs, one of the following displays is displayed.
Take the measures described below to eliminate the problem.
ERROR 2
ERROR 3
CD/MP3/WMA
ERROR 6
ERROR 7
ERROR 8
M.CATCHER
ERROR 9
ERROR 2
ERROR 3
CD changer
ERROR 6
ERROR 2
ERROR 3
ERROR 6
DVD changer
ERROR P
CauseError Display
A DISC is caught inside the CD deck and is
not ejected.
A DISC cannot be played due to scratches,
etc.
A DISC is loaded upside-down inside the
CD deck and cannot play.
The format of the flash memory is damaged.
There is a failure with the flash memory.
An error during recording, scratch on the
disc, or error due to sound skips
A DISC inside the CD changer is not loaded
properly.
A DISC inside the CD changer cannot be
played due to scratches, etc.
A DISC inside the CD changer cannot be
played because it is loaded upside-down.
A DISC inside the DVD changer is not
loaded properly.
A DISC cannot be played due to scratches,
etc.
A DISC inside the DVD changer cannot be
played because it is loaded upside-down.
Parental level error
Measure
This is a failure of CD deck’s mechanism and
consult Clarion dealer.
Replace with a non-scratched disc.
Eject the disc then reload it properly.
Execute ALL ERASE on the flash memory,
and the problem is solved.
Turn POWER/ACC off and then turn it on
again, and the problem is solved.
If not solved, executed ALL ERASE on the
flash memory, and the problem is solved.
Turn POWER/ACC off and then turn it on
again, or eject the CD. The problem is
solved.
This is a failure of CD changer’s mechanism
and consult Clarion dealer.
Replace with a non-scratched disc.
Eject the disc then reload it properly.
This is a failure of DVD mechanism and consult Clarion dealer.
Retry or replace with a non-scratched disc.
Eject the disc then reload it properly
Set the correct Parental level.
ERROR R
Region code error
Eject the disc and replace correct region
code disc.
If an error display other than the ones described above appears, press the reset button. If the problem
persists, turn off the power and consult Clarion dealer.
32 DXZ755MC
11. SPECIFICATIONS
English
FM Tuner
Frequency Range:
87.9 MHz to 107.9 MHz
Usable Sensitivity:
9 dBf
50dB Quieting Sensitivity:
15 dBf
Alternate Channel Selectivity:
70 dB
Stereo Separation (1 kHz):
35 dB
Frequency Response (±3 dB):
30 Hz to 15 kHz
AM Tuner
Frequency Range:
530 kHz to 1710 kHz
Usable Sensitivity:
25 µV
CD Player
System:
Compact disc digital audio system
Usable Discs:
Compact disc
Frequency Response (±1 dB):
5 Hz to 20 kHz
Signal to Noise Ratio (1 kHz):
100 dB
Dynamic Range (1 kHz):
95 dB
Harmonic Distortion:
0.01%
Channel Separation (1 kHz):
85 dB
Audio
Maximum Power Output:
212 W (53 W ✕ 4 ch)
Continuous Average Power Output:
18 W ✕ 4, into 4 Ω, 20 Hz to 20 kHz, 1%THD
Bass Control Action (50 Hz/80 Hz/120 Hz):
+16 dB, -12dB
Treble Control Action (8 kHz/12 kHz):
±12 dB
Line Output Level (CD 1 kHz):
1.8 V
General
Power Supply Voltage:
14.4 V DC (10.8 to 15.6 V allowable), negative
ground
Current Consumption:
Less than 15 A, 3A
Speaker Impedance:
4 Ω (4 Ω to 8 Ω allowable)
Weight / Source unit:
3.52 lb. (1.6 kg)
Weight / Remote control unit:
1.41 oz. (40 g) (including battery)
Dimensions / Source unit:
7" (Width) ✕ 2" (Height) ✕ 6-1/8" (Depth)
[178 (W) ✕ 50 (H) ✕ 155 (D) mm]
Dimensions / Remote control unit:
1-3/4" (Width) ✕ 4-7/16" (Height) ✕ 1/2"
(Depth)
[44 (W) ✕ 113 (H) ✕ 13 (D) mm]
MC mode
HQ:
Approximately 265 minutes, 66 tracks
(4 minutes for each)
LP:
Approximately 353 minutes, 88 tracks
(4 minutes for each)
Note:
• Specifications and design are subject to change without notice for further improvement.
DXZ755MC 33
34 DXZ755MC
Loading...
