Owner’s manual
APX2180
APX4360
DPX2250
DPX1800
DPX11500
English
APX AND DPX AMPLIFIERS
APX/DPX Amplifiers 1
APX-DPXOwnersManual.pmd 2006-03-14, 21:461
English
Thank you for purchasing this Clarion product.
• Please read this owner’s manual in its entirety before operating this equipment.
• After reading this manual, keep it handy, such as in your glove compartment.
• Save your sales receipt. The warranty at the end of this manual and your sales
receipt are essential for warranty service.
FCC Approval
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to consult the dealer or an experienced
radio/TV technician for help.
2 APX/DPX Amplifiers
APX-DPXOwnersManual.pmd 2006-03-14, 21:462
Contents
1. FEATURES ............................................................................................................. 4
2. PRECAUTIONS ...................................................................................................... 5
Installation .............................................................................................................. 5
3. CONTROLS ............................................................................................................ 6
4. OPERATIONS ......................................................................................................... 8
Setting input voltage .............................................................................................. 8
Setting the operating level ..................................................................................... 8
Improving bass sound ............................................................................................ 8
Matching subwoofer output to mid-range speakers .............................................. 9
Connecting directly to a head unit ......................................................................... 9
Care and maintenance .......................................................................................... 9
5. INSTALLATION AND WIRING .............................................................................. 10
What is included in the box .................................................................................. 10
Mounting precautions .......................................................................................... 10
Wiring precautions ............................................................................................... 11
Power and speaker connections .......................................................................... 13
Applications .......................................................................................................... 15
DPX1800 and DPX11500 stackable configurations ........................................... 19
Setting the gain .................................................................................................... 19
Adjusting the crossover ........................................................................................ 20
Setting the bass boost .......................................................................................... 20
Final system checks ............................................................................................. 20
6. TROUBLESHOOTING .......................................................................................... 2 1
Indicator lights ...................................................................................................... 21
No audio ............................................................................................................... 21
Amplifier shuts down after playing for a period of time ........................................ 22
Distorted audio ..................................................................................................... 22
Amplifier fuse keeps blowing ............................................................................... 22
Whining noise when engine on ........................................................................... 22
Ticking noise when engine on ............................................................................. 23
7. GLOSSARY .......................................................................................................... 23
8. SPECIFICATIONS ................................................................................................ 24
APX Amplifiers ..................................................................................................... 24
DPX Amplifiers ..................................................................................................... 25
9. LIMITED WARRANTY INFORMATION ................................................................. 26
English
APX/DPX Amplifiers 3
APX-DPXOwnersManual.pmd 2006-03-14, 21:463
English
1. FEATURES
The Clarion APX2180, APX4360, DPX2250, DPX1800 and DPX11500 amplifiers fit a
variety of system configurations and provide these features:
• IVS - Input Voltage Selector with three sensitivity ranges on the gain control for the
ability to connect to almost any source
• PFS - Precise Frequency Selector, a detented crossover frequency adjustment
• Ground loop isolation for RCA inputs
• Full frequency response with low distortion and exceptional signal-to-noise
performance
• Advanced circuitry design provides bridgeable outputs for use in a variety of
applications
• Independent electronic crossovers to aid in audio system design
The DPX1800 and DPX11500 each have 24dB per octave slope and full adjustment range from 30Hz to 250Hz.
The APX2180, APX4360, and DPX2250 each have 12dB per octave slope and full
adjustment range from 50Hz to 550Hz.
• Bass boost circuit on APX series amps to reinforce low frequency signals
• Remote turn-on with “soft start” muting to prevent turn-on “thump”
• Protection circuits for overheating and speaker shorts
• APX2180, APX4360 and DPX2250 are 2-Ohm load capable of driving a variety of
speaker systems
• DPX1800 and DPX11500 are 1-Ohm load capable to drive a variety of subwoofers
• Gold-plated input/output connectors and on-board automotive-type fuses
• Aluminum heat sink for efficient heat dissipation
• Low profile, compact footprint to accommodate space limitations
• SLI - Speaker Level Inputs on amps for integration with factory sound systems
• SSF - Adjustable subsonic filter on the DPX1800 and DPX11500 can be turned
down to 10Hz
• Automatic load-sensing circuit (full power into 1 or 2 Ohms) on the DPX1800 and
DPX11500
4 APX/DPX Amplifiers
APX-DPXOwnersManual.pmd 2006-03-14, 21:464
2. PRECAUTIONS
• Do not operate this product in ways other than those described in this manual.
• Do not disassemble or modify this product.
• Do not pour liquid or poke foreign objects into the unit. Water and humidity will
damage internal circuitry.
• If the unit becomes wet, turn off all power and ask your authorized Clarion dealer
to clean or service the unit.
Failure to observe these precautions may damage your car or the amplifier, and may
void the warranty.
WARNING
Exposure to continuous sound levels of 85dB or higher may
result in hearing loss. Although Clarion products are capable
of producing high sound pressure levels, please use your
product at reasonable levels.
While operating your vehicle, please observe all local sound
ordinances for your safety.
Installation
Installation of mobile audio and video components requires experience with a variety
of mechanical and electrical procedures. Although this manual provides general
installation and operation instructions, it does not show the exact installation methods
for your particular vehicle.
If you do not have the required knowledge and experience to successfully complete
the installation, consult an authorized Clarion dealer about professional installation
options.
English
APX/DPX Amplifiers 5
APX-DPXOwnersManual.pmd 2006-03-14, 21:465
English
3. CONTROLS
2
41 6
7
APX2180 signal connections and audio adjustments
1
APX4360 signal connections and audio adjustments
1. RCA input jacks 6. BBC (Basic Boost Control)
2. IVS (Input Voltage Selector) 7. SLI (Speaker Level Input) connector
3. PFS (Precise Frequency Selector) 8. Crossover frequency multiplier
4. Gain control 9. Crossover function switch
5. Output mode switch
4 5
3
3
8
6
2
37 89 9
5
9
6 APX/DPX Amplifiers
APX-DPXOwnersManual.pmd 2006-03-14, 21:466
1 26 4 3 910
5
DPX2250 signal connections and audio adjustments
English
11 8 7 3 14 12
2
4
6
1
5
13
DPX1800 and DPX11500 signal connections and audio adjustments
1. RCA input jacks 8. RLC (Remote Level Control) port
2. IVS (Input Voltage Selector) 9. Output mode switch
3. PFS (precise Frequency Selector) 10. Crossover function switch
4. BBS (Bass Boost Control 11. Subsonic filter frequency selector
5. SLI (Speaker Level Inputs) 12. Slave RCA jack
6. Gain control 13. RCA output jack
7. PCS (Polarity Control Switch) 14. Master/Slave selector
APX/DPX Amplifiers 7
APX-DPXOwnersManual.pmd 2006-03-14, 21:467
English
4. OPERATIONS
Selecting input voltage
APX and DPX amplifiers accommodate a wide range of signal input voltages (0.2V to
8V). This wide range is split up into three ranges, which are accessible through
switches located in the “Gain” area of the amplifier.
• 0.2V-0.6V selects an input sensitivity range between 200mV and 600mV.
• 0.6-2V selects an input sensitivity range between 600mV and 2V.
• 2V-8V selects an input sensitivity range between 2V and 8V.
The gain rotary control operates within these voltage windows.
Note:
Most decks, even 4V and 5V units do not operate at full output voltage.
This requires the switch to be set in the 0.6-2V range.
Setting the operating level
The gain switches allow you to set the nominal operating level of the amplifier from
0.2 to 8V for RCA inputs or 500mV to 5V for speaker level inputs. This wide adjust-
ment range accommodates virtually any source unit brand.
Once you set the correct range using the IVS, you must adjust the gain to match the
amplifiers sensitivity to that of the source unit. The gain control is not a volume control.
It exists only to allow an amplifier to be used with different models and brands of head
units.
Improving bass sound
The amplifiers feature a narrow-frequency band bass boost circuit (known as “highQ”). Acting much like an equalizer, the bass boost control lets you tune low-frequency
audio response to compensate for a less than ideal subwoofer enclosure design. The
added boost produces rich, full bass tones that are normally difficult to reproduce in
the car audio environment.
• The APX2180, APX4360, and DPX2250 have a switchable gain that is fixed at
45Hz. If you don’t want to boost the bass frequencies, set this control to “OFF.”
• The DPX1800 and DPX11500 have a variable-frequency bass boost control from
30Hz to 125Hz. They do not have a bass boost on/off switch, but a level control that
goes from 0dB to 15dB.
CAUTION
This control can dramatically increase the power output level
and could cause speaker damage if you over use it.
8 APX/DPX Amplifiers
APX-DPXOwnersManual.pmd 2006-03-14, 21:468
Matching subwoofer output to mid-range speakers
The DPX1800 and DPX11500 feature a polarity control switch for reversing the
polarity of the output signal. This can be useful when matching the acoustic output of
your subwoofers to the output of your mid-range speakers.
Connecting directly to a head unit
The amps provide connections directly to a head unit without a pre-amp output, such
as a factory-installed head unit.
WARNING
When using the speaker (high-level) inputs, the black wire
must be grounded at the radio. Failure to do so will result in
noise and/or improper operation.
Care and maintenance
Cleaning the case
Use a soft, dry cloth to gently wipe dust and dirt from the unit.
Do not use benzene, thinner, car cleaner, or other cleaners. These substances may
damage the unit or cause the paint to peel.
Servicing the unit
In the event that trouble arises, never open the case or disassemble the unit. The
internal parts are not serviceable by the user. Opening any components will void the
warranty.
English
CAUTION!
Changes or modifications to this product not approved by the
manufacturer will void the warranty and will violate FCC approval.
APX/DPX Amplifiers 9
APX-DPXOwnersManual.pmd 2006-03-14, 21:469
English
5. INSTALLATION AND WIRING
Read these instructions and the following precautions carefully.
What is included in the box
In addition to this manual, the box contains:
• Amplifier
• High-level speaker input harness
Mounting precautions
If you lack the necessary skills, do not install the amplifier yourself. See your authorized Clarion Dealer for installation recommendations.
• This unit is exclusively for vehicles with a negative ground, 12V power supply.
• This unit requires additional mobile audio components for proper operation.
• Choose a location in the vehicle that provides adequate ventilation around the
amplifier. Although any moving air dissipates heat, cool air should run along the
length of the fins rather than across them.
CAUTION
Although Clarion amplifiers include heat sinks and protection
circuits, mounting an amplifier in a tight space without any air
movement will reduce performance and damage the unit’s internal circuitry over time.
The DPX1800 does not have a fan. Install it such that air can
flow to the bottom of the amplifier.
The DPX11500 has two fans. Mounted in the ends of the unit,
they blow through the length of the amplifier. Ensure a 3-inch
clearance between the power/speaker and the control ends for
proper ventilation.
• Mount the amplifier on a firm, flat surface away from subwoofer enclosures or to
any area that is prone to vibration. Do not install the amplifier on plastic or on any
other combustible material.
• For easy system setup, mount the amplifier so that the adjustment controls are
accessible after installation.
10 APX/DPX Amplifiers
APX-DPXOwnersManual.pmd 2006-03-14, 21:4610
• Always use great care when attaching anything to a vehicle! Check clearances on
all sides of the planned installation before drilling any holes or installing any
screws.
• Make sure the holes you plan to drill will not cut into the fuel tank, fuel lines, break
lines (under the chassis) or electrical wiring. Don’t guess. Check first.
Wiring precautions
Read all wiring precautions. If you are not sure of the connections, contact your
authorized Clarion Dealer.
• Do not open the case. There are no user-serviceable parts inside. If you require
assistance, consult your Clarion Dealer or an authorized Clarion Service Center.
Power
• Before you start, make sure the source unit’s power switch is off.
WARNING!
To prevent short circuits during installation, disconnect the
vehicle’s negative (-) battery lead before making any power
connections.
Fuses
• To protect the vehicle from fire or explosion in the event of a collision, add an
external fuse to the amp’s positive (+) power lead and connect it as close as
possible to the vehicle’s plus (+) battery terminal.
Use a fuse rated to the total current consumption of the amplifier. Fuses mounted
near the battery should be ~10 Amps bigger than fuses on the amplifier itself.
If you are using more than one amplifier, add the total current consumption for the
entire system and use the closest available fuse. For example, if you’re connecting
both an APX2180 and an APX4360, install a 100 Amp fuse at the battery.
• Power wire size can greatly affect the performance of your audio system. The
Power wire size table indicates the minimum power wire requirements for proper
operation.
English
Power wire size table
<12 feet total electrical path length 12-22 feet total electrical path length
Wire size Maximum fuse Wire size Maximum fuse
8 Awg 70 Amp 8 Awg 40 Amp
4 Awg 170 Amp 4 Awg 50 amp
2 Awg 240 Amp 2 Awg 140 Amp
0 Awg 400 Amp 0 Awg 200 Amp
APX/DPX Amplifiers 11
APX-DPXOwnersManual.pmd 2006-03-14, 21:4611
English
Cables
• Whenever possible, route power wire and signal wire on opposite sides of the
vehicle. This prevents the signal cables from picking up electrically radiated noise.
• Protect all wire from damage. Where a power wire passes through the fire wall or
near exposed metal edges, protect the wire with a rubber or plastic grommet. Use
wire loom where possible for further protection.
• Extra cable can cause signal loss and act as an antenna for noise. Use only highquality RCA cables that are no longer than necessary to make a direct connection
with the source unit and amplifiers.
• Make sure each connection is clean and secure. Insulate final connections with
electrical tape or shrink tubing.
CAUTION
Improper connections may result in
unreliable operation and damage the
amplifier or the vehicle.
Grounding the amplifier
• A good chassis ground connection is critical
to minimize resistance and avoid noise
problems.
Use the shortest wire possible. Clean off any
paint, primer or sound deading prior to
making this connection.
To minimize resistance and avoid noise
External fuse rating table
Model Fuse rating
APX2180 30 Amp
APX4360 50 Amp
DPX2250 50 Amp
DPX1800 90 Amp
DPX11500* 200 Amp
*This amplifier has no amplifiermounted fuses. Always use a 200
Amp fuse installed at the battery.
problems, securely connect the ground wire
to the car chassis and the source unit ground. Using existing bolts is not recommended.
• The last connection you make should be the ground wire at the amplifier. As the
power supply capacitors in the amplifier are not charged, a spark may be produced when you make this connection.
Use a test light with an incandescent bulb between the ground terminal and the
power wire to charge these capacitors if this is a concern. The ground wire is the
most important connection to the amplifier. Make sure it is both electrically and
mechanically sound.
12 APX/DPX Amplifiers
APX-DPXOwnersManual.pmd 2006-03-14, 21:4612
Power and speaker connections
The rear panel contains the power and speaker ports.
3
4
6
5
87
APX2180 power and speaker connections
1
5
6
7
2
8
9 10
APX4360 power and speaker connections
1. Left front speaker output 6. Ground input
2. Right front speaker output 7. Battery 12V input
3. Left speaker output 8. Fuses
4. Right speaker output 9. Left rear speaker output
5. Remote turn-on input 10. Right rear speaker output
English
APX/DPX Amplifiers 13
APX-DPXOwnersManual.pmd 2006-03-14, 21:4613
English
3
6
7
54
DPX1800 power and speaker connections
3
4
5
7
DPX11500 power and speaker connections
1
5
2
4 7
6
DPX2250 power and speaker connections
1. Left rear speaker output 4. Remote turn-on connection
2. Right rear speaker output 5. Ground connection
3. Mono speaker output 6. Fuses
7. Battery 12V connection
14 APX/DPX Amplifiers
APX-DPXOwnersManual.pmd 2006-03-14, 21:4614
Applications
+
+
+
+
+
Mono subwoofer system (APX2180 and APX4360)
In this application, the rear channels are bridged for mono operation to drive a
subwoofer while the front channels are available to drive a set of full-range speakers.
Stereo Amp configuration (APX2180)
• Set crossover mode to LP
• Set input mode switch to L + R (Mono)
• Set crossover frequency to ~80Hz
• Fine-tune crossover frequency to suit
musical tastes and performances
• 4Ω min
--
LEFT
FRONT
REAR
2
BRIDGED (4
RIGHT
--
2
)
GND
REM
12V
FUSES
English
Stereo Amp configuration (APX4360)
• Set rear crossover mode to LP
• Set input mode switch to L + R (Mono)
• Set crossover frequency to ~80Hz
• Fine-tune crossover frequency to suit
musical tastes and performances
• 4Ω min
Note:
You may bridge the front, rear or both pairs of channels using the above
settings.
APX/DPX Amplifiers 15
APX-DPXOwnersManual.pmd 2006-03-14, 21:4615
English
Two-channel full-range or subwoofer system (APX2180)
In this application, the APX2180 is used to drive two speakers.
Subwoofers
Full-range co-axial
or
Component speakers
Subwoofers in stereo
• Set crossover mode switch to LP
• Set crossover frequency to ~80Hz
• Fine-tune as required
• 2 Ω
Full-range speakers or components in stereo
• Set crossover mode switch to OFF
Component speakers in stereo with separate subwoofer amp
• Set crossover mode switch to HP
• Set crossover frequency to ~200Hz for 4-inch speakers
~100Hz for 5.25-inch speakers
~75Hz for 6.5-inch speakers
~65Hz for 6 x 9-inch speakers
Subwoofers and component speakers at the same time
• Set crossover mode switch to OFF
• Install passive crossovers on subwoofers (inductor) and components (capacitor)
16 APX/DPX Amplifiers
APX-DPXOwnersManual.pmd 2006-03-14, 21:4616
Four-channel high-power system (APX4360)
In this application, the APX4360 is used as a four-channel amplifier to drive four
speakers in stereo with fader control.
+
+
--
LEFT
FRONT
REAR
+
2
BRIDGED (4 )
RIGHT
+
--
2
GND
REM
12V
FUSES
+
2 Ω2 Ω
English
Front left
Full range
Front right
Full range
Rear right
Full range
Rear left
Full range
Four speakers in stereo—full range
• Set crossover mode switch to OFF
Four speakers in stereo—filtered
If the front or rear speakers are smaller than 5.25”, you may decide to enable the
crossover. The following apply to the front or rear channels with the small speakers.
• Set crossover mode switch to HP
• Set crossover frequency to ~200Hz for 4-inch speakers
~350Hz for 3.5-inch speakers
APX/DPX Amplifiers 17
APX-DPXOwnersManual.pmd 2006-03-14, 21:4717
English
2-Ohm subwoofer system (DPX1800/DPX11500)
This application shows a DPX1800 or DPX11500 driving a pair of DVC 4Ohm
subwoofers.
DVC 4 Ohm subwoofer
DVC 4 Ohm subwoofer
DPX1800/DPX11500 speaker configurations
Although the units produce maximum power when connected to a 1 or 2 Ohm load, a
2-Ohm load is recommended.
WARNING
Do not connect a load less than 1-Ohm as permanent damage
may occur and the warranty will be nullified.
The following DPX1800 or DPX11500 configurations achieve full power.
Speaker configurations
Driver type Quantity Wiring Net load
Single-voice coil - 8 Ohm 8 Parallel 2 Ohm
Single-voice coil - 4 Ohm 4 Parallel 2 Ohm
Single-voice coil - 2 Ohm 2 Parallel 2 Ohm
Dual-voice coil - 8 Ohm 4 Parallel/Parallel 2 Ohm
Dual-voice coil - 4 Ohm 2 Parallel/Parallel 2 Ohm
Dual-voice coil - 2 Ohm 1 Parallel 2 Ohm
Other speaker configurations are possible using a combination of series and parallel
wiring. See your authorized Clarion dealer for assistance.
18 APX/DPX Amplifiers
APX-DPXOwnersManual.pmd 2006-03-14, 21:4718
DPX1800 and DPX11500 stackable configurations
In this mode, the master amp’s front-panel controls apply to all amplifiers. For example, setting the crossover frequency on the master sets it on all slaves. This works
for all front-panel controls.
Multiple amplifiers can be daisy-chained together. For example, if you had six
DPX1800s in a show car, you could control all of them from one master unit (and one
remote).
The following describes the configuration of the amplifiers:
Master • Route input from the head into the normal mode inputs.
• Set the master/slave switch to Master.
• Route a single RCA cable from the Slave Out to first slave unit.
First slave • Set the master/slave switch to Slave.
• Route a single RCA cable from the master Slave Out to the
current amplifier’s Slave In.
Additional slave(s) • Set the master/slave switch to Slave.
• Route a single RCA cable from the previous amplifier’s Slave
Out to the current amplifier’s Slave In.
Each amplifier can independently control separate speaker loads (assuming the
phase switch on all amplifiers is set the same).
Or, to power a large single load (phase switch opposite on the amplifier), you can
bridge across the amplifiers: + and + to load, - and - to each other. The master amp is
“speaker +” for in-phase operation.
Any pair of amplifiers could also be bridged, but be careful to set the phase switches
correctly.
English
Setting the gain
After completing the installation, follow these steps to set the gain control and perform
the final system checks.
1. Turn the gain control all the way down (counterclockwise).
2. Select the proper input voltage range using the IVS. See “Selecting Input Voltage”
in the “Operations” section of this manual.
3. Turn the vehicle’s ignition switch on.
4. Turn the audio system on with the volume turned all the way down.
4. Set all tone or equalization controls to flat positions and turn loudness off.
5. Play a CD and turn the volume up on the head unit until you hear distortion. This
should be most of the way up.
APX/DPX Amplifiers 19
APX-DPXOwnersManual.pmd 2006-03-14, 21:4719
English
6. Turn the volume back down slightly.
7. Slowly increase the gain control (clockwise). Stop when you hear a slight audio
distortion.
When the gain is properly set, you should achieve maximum undistorted output with
the volume turned up all the way, not half way.
If an oscilloscope is available, monitor the output of the amplifier with the scope,
watching for clipping of the waveform. Set the gain so that only minor clipping occurs.
Adjusting the crossover
The APX2180, APX4360 and DPX2250 amplifiers feature fully-adjustable crossovers.
The DPX1800 and DPX11500 do not have a way to disable the low-pass 24dB slope
crossover.
1. On the APX2180, APX4360, and DPX2250, use the X-Over mode switch to select
either LP (low pass) or HP (high pass) or OFF for full range.
2. Using the Frequency (Hz) selection control, select the frequency.
Setting the bass boost
1. Initially set the bass boost control to the OFF position.
2. Listen to a variety of music styles (for example, rock, rap, etc.) and switch the bass
boost control on until you notice an increase in low bass response.
Note:
Using the bass boost requires the amplifier to produce a great deal of
additional power. Use bass boost sparingly.
CAUTION
If you hear a pop caused by speaker overexertion, lower the
bass boost to prevent damage to the speaker.
Final system checks
1. Start the engine and turn on the source unit.
2. After a two-second delay, slowly increase the volume control and listen to the
audio.
If you hear any noise, static, distortion or no sound at all, check the connections
and refer to Troubleshooting. Depending on your system, the volume may become
quite loud even at moderate volume control settings. Until you get an “audio feel”
for the system’s power, use care when adjusting the controls.
3. Turn the balance controls to their extreme positions and listen to the results.
Audio output should match control settings (audio from the left speaker when
balance is left).
20 APX/DPX Amplifiers
APX-DPXOwnersManual.pmd 2006-03-14, 21:4720
4. Increase the volume and verify that the amplifier reproduces the audio at full
frequencies without distortion.
If you hear distortion check the connections and verify that the gain control is set
correctly. Another cause of distortion could be underpowered or damaged speakers. Refer to Troubleshooting.
6. Troubleshooting
Indicator lights
The APX2180, APX4360, DPX1800 and DPX11500 have lights that indicate amplifier
status.
Blue top Red end- Blue end-
LED panel light panel light Meaning
on off off Amplifier running normally
on alternating between red and blue In thermal protection mode
slow blink slow out-of-sync off Over voltage;
blink reduce the input voltage
quick blink quick in-sync off Short circuit protection
blink
3 blinks, then pause 3 blinks, then pause off Repeated shorts detected;
remove the short circuit, wait
5 minutes for error condition
to clear; or clear condition by
removing the main power, for
example, by pulling the fuse.
English
No Audio
• Low or no remote turn-on voltage: check remote connections at the amplifier and
source unit.
• Blown amplifier fuse: replace with a new fast-blow fuse (same rating).
• Power wires not connected: check battery and ground wiring at the amplifier and
check the battery connections.
• Speaker leads shorted: check speaker continuity to ground; it should not show a
common ground.
• Speakers not connected or are blown: check speaker connections at the ampli-
fier and measure at speakers. Measure coil impedance at amplifier with speaker
wires disconnected.
APX/DPX Amplifiers 21
APX-DPXOwnersManual.pmd 2006-03-14, 21:4721
English
Amplifier shuts down after playing for a period of time
• Thermal protection circuits are shutting the amplifier off: Check the location for
adequate ventilation. Relocate amplifier as required. Consult an authorized
Clarion audio dealer.
Distorted audio
• Gain is not properly set properly: review the instructions for setting the gain.
• Speaker cones are damaged: inspect each speaker cone for signs of damage,
such as a frozen cone, burnt smell, separated or ripped surround or separated
spider.
Amplifier fuse keeps blowing
• Incorrect wiring or short circuit: review the installation and check all wiring
connections.
• Amplifier being driven too hard: Turn down the
volume, gain or bass boost.
• Undersized or faulty fuse installed: Replace the
amplifier fuse with the same rating fuse as the one
that shipped with the unit.
Note:
The DPX11500 ships with a 200 Amp, ANL-type
fuse; mount it external to the unit, near the battery.
Fuse rating table
Model Fuse rating
APX2180 30 Amp
APX4360 50 Amp
DPX2250 50 Amp
DPX1800 90 Amp
DPX11500 200 Amp
Whining noise when engine on
• RCA cables too close to the power wire: Separate RCA and power cables.
Ground loops are caused by a mismatch in the ground potential (voltage) between
two sources. Current flows through the shield of the RCA cable and is quickly
picked up by the amplifier. There are several ways to solve this problem:
• Re-ground the amplifier to a more electrically conductive location.
• Re-ground the head unit to a more electrically conductive location.
• Run a ground wire from the head unit to the amplifier ground.
• Upgrade or replace the ground wire on the battery and alternator.
• Run a ground cable from the negative terminal of the battery to the amplifier.
• Wire the entire audio system using a single connection point to the chassis.
• Induced noise: Relocate components away from electrical noise sources:
• Engine control computers
• ABS brake control modules.
22 APX/DPX Amplifiers
APX-DPXOwnersManual.pmd 2006-03-14, 21:4722
Ticking noise when engine on
• High voltage ignition problem: Check for problems with the ignition system and
replace components as required.
• Cracked distributor caps
• Carbon traces on plug wires
• Loose spark plugs
7. Glossary
English
Crossover
dB
two acoustic signals.
Equalizer
quality of the sound.
Gain control
audio signal expressed in dB.
Hz
IVS
Octave
musical scale.
Ohm
PFS
RCA input/output
refers to the type of connector, which was first manufactured by the Radio Corporation
of America.
Slope
faster the frequency drops off.
: A device that limits the range of frequencies sent to a speaker or amplifier.
: decibel, a measurement of the relative difference in power or intensity between
: Component that boosts or cuts sound signal frequencies to improve the
: gain is the amount of amplification (voltage, current or power) of an
: Abbreviation for Hertz, a unit of frequency equal to one cycle per second.
: Input Voltage Selector
: the musical principle of dividing sound frequencies into the eight notes of the
: unit of electric resistance
: Precise Frequency Selector
: port through which sound travels in and out of the system; “RCA”
: how fast the sound gets quieter rated in dBs. The higher the dB number, the
APX/DPX Amplifiers 23
APX-DPXOwnersManual.pmd 2006-03-14, 21:4723
English
8. Specifications
Note:
The technical data and the design of the equipment may change
without prior notice for the sake of technical improvements.
APX Amplifiers
Parameter APX4360 APX2180
Maximum power output 160W x 4 160W x 2
Continuous rated power 90W x 4 90W x 2
Typical power in bridged mode 300W x 2 300W x 1
Typical power in 2-Ohm load 160W x 4 150W x 2
THD (1KHz, 10W, 40 Ohms) ≤ 0.025% ≤ 0.025%
IM distortion ≤ 0.08% ≤ 0.08%
S/N (A-weighted) ≥ 92dB ≥ 93dB
Floor noise ≤ 2mV ≤ 2mV
Channel separation ≥ 70dB ≥ 70dB
Frequency response 10Hz to 50kHz 10Hz to 50kHz
Line level input sensitivity 200mV to 8 Volts 200mV to 8 Volts
Speaker level input sensitivity 600mV to 20 Volts 600mV to 20 Volts
Input impedance 33K Ohms 33K Ohms
Allowable battery voltage 10.5 to 16.5 Volts 10.8 to 16.5 Volts
Size 16"x12"x2 7/8" 12"x12"x2 7/8"
These specifications are Amplifier Power Standard CEA-2006 Compliant.
24 APX/DPX Amplifiers
APX-DPXOwnersManual.pmd 2006-03-14, 21:4724
DPX Amplifiers
Parameter DPX11500 DPX1800 DPX2250
Maximum power output 1900W 1000W 150W x 2
Continuous rated power 430W x1 (11Hz-220Hz) 430W x1 (11Hz-220Hz) 125Wx2
Typical power in bridged mode Not bridgeable; Not bridgeable; 400W
stackable with second stackable with second
DPX11500 DPX1800
Typical power in 2-Ohm load 1500W 800W 200W x 2
Typical power in 1-Ohm load 1500W 700W N/A
S/N (A-weighted) >100dB ≥ 79dB 80dB
Floor noise 1mV 1mV 1.5mV
Channel separation Mono Mono 70dB
Frequency response (±1.0dB) 16 to 150Hz 16 to 150Hz 18 to 30 kHz
Line level input sensitivity 0.2 to 8V with IVS 0.2 to 8V with IVS 0.2 to 8V with IVS
Input impedance 22K Ohms 22K Ohms 22K Ohms
Allowable battery voltage 10 to 16 Volts 10 to 16 Volts 10 to 16 Volts
Size 21 1/4”x12”x2 7/8” 19 1/4”x12”x2 7/8” 13 1/4”x12”x2 7/8”
These specifications are Amplifier Power Standard CEA-2006 Compliant.
English
APX/DPX Amplifiers 25
APX-DPXOwnersManual.pmd 2006-03-14, 21:4725
English
9. LIMITED WARRANTY INFORMATION
For USA and Canada only
Except as noted, Clarion products purchased from an authorized Clarion Dealer are warranted against all
defects in materials and workmanship for a period of one (1) year from date of original purchase.
The following Clarion products noted below ** are warranted against all defects in materials and workmanship for
a two (2) year period from the date of original purchase when purchased from AND installed by an authorized
Clarion dealer.
** DRZ9255 DXZ865MP DXZ765MP DXZ665MP DXZ465MP DFZ675MC DPX11500 DPX1800 DPX2250
All Clarion cables, wires and other accessories if purchased from an authorized Clarion dealer are warranted
against all defects in materials and workmanship for ninety (90) days from the date of original purchase.
ALL PURCHASES OF CLARION PRODUCTS FROM NON-AUTHORIZED CLARION DEALERS ARE SUBJECT TO
FURTHER WARRANTY RESTRICTIONS AS DESCRIBED BELOW.
The conditions of this Limited Warranty and the extent of responsibility of Clarion Corporation of America
(“Clarion”) under the Limited Warranty are as follows:
1. PROOF OF DATE OF PURCHASE FROM AN AUTHORIZED CLARION DEALER WILL BE REQUIRED FOR
WARRANTY SERVICE OF THIS PRODUCT. IN THE CASE OF THE TWO (2) YEAR LIMITED WARRANTY FOR
THE CLARION PRODUCTS NOTED ABOVE, PROOF OF DATE OF PURCHASE AND PROOF OF
INSTALLATION BY AN AUTHORIZED CLARION DEALER IS REQUIRED. INFORMATION ABOUT CLARION
AUTHORIZED WARRANTY SERVICE CENTERS MAY BE OBTAINED BY CONTACTING CLARION AT THE
ADDRESS LISTED BELOW.
2. This Limited Warranty will become void if service performed by anyone other than an approved Clarion
Warranty Service Center results in damage to the products.
3. This Limited Warranty does not apply to any product which has been subject to misuse, neglect or accident,
or which has had the serial number altered, defaced or removed, or which has been connected, installed,
adjusted or repaired, other than in accordance with the instructions furnished by Clarion.
4. This Limited Warranty does not cover car static or other electrical interferences, tape head or laser pick-up
cleaning or adjustments, or labor costs for the removal or reinstallation of the unit for repair.
5. The sole responsibility of Clarion under this Limited Warranty shall be limited to the repair of the product or
replacement of the product, at the sole discretion of Clarion.
6. Product must be shipped in its original carton or equivalent carton, fully insured, with shipping charges
prepaid. Clarion will not assume any responsibility for any loss or damage incurred in shipping.
7. CLARION PRODUCTS PURCHASED FROM A SOURCE OTHER THAN AN AUTHORIZED CLARION DEALER,
INCLUDING ANY AND ALL PURCHASES VIA THE INTERNET FROM A NON INTERNET AUTHORIZED
CLARION DEALER, SHALL NOT BE COVERED BY ANY CLARION LIMITED WARRANTY TO THE EXTENT
ALLOWED BY APPLICABLE LAW. IN THE EVENT AND TO THE EXTENT APPLICABLE LAW PROHIBITS
ELIMINATION OF WARRANTIES UNDER THESE CIRCUMSTANCES, THE APPLICABLE LIMITED WARRANTY
PERIOD SHALL BE DEEMED TO BE FIFTEEN (15) DAYS FROM THE DATE OF ORIGINAL PURCHASE.
8. ALL IMPLIED WARRANTIES EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW SHALL HAVE
NO GREATER DURATION THAN THE WARRANTY PERIOD SET FORTH ABOVE. UNDER NO
CIRCUMSTANCES SHALL CLARION BE LIABLE FOR ANY LOSS OR DAMAGE, DIRECT OR
CONSEQUENTIAL, ARISING OUT OF THE USE OR INABILITY TO USE THE PRODUCT. BECAUSE SOME
STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS OR EXCLUSIONS
OR LIMITATIONS OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, THE ABOVE LIMITATIONS OR
EXCLUSIONS MAY NOT APPLY TO YOU.
9. THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER
RIGHTS WHICH VARY FROM STATE TO STATE.
10. The laws of the state of California shall govern and control this Limited Warranty, its interpretation and
enforcement.
11. Should you have any difficulties with the performance of this product during the warranty period, please call
Clarion or visit our web site for a listing of Authorized Warranty Service Centers in your area. You may also
contact Clarion Customer Service at the address listed below for any service you may need with Clarion
products.
In USA
Clarion Corporation of America
Attn: Customer Service Manager
661 W. Redondo Beach Blvd
Gardena, CA. 90247-4201
1-800-GO-CLARION (310)327-9100
www.clarion.com
In Canada
Clarion Canada, Inc.
Warranty Service Center
2239 Winston Park Drive
Oakville, Ontario L6H 5R1
(905)829-4600
www.clarioncanada.com
26 APX/DPX Amplifiers
APX-DPXOwnersManual.pmd 2006-03-14, 21:4726
English
APX/DPX Amplifiers 27
APX-DPXOwnersManual.pmd 2006-03-14, 21:4727
English
Clarion Corporation of America
All Rights Reserved. Copyright © 2006: Clarion Corp. of America
28 APX/DPX Amplifiers
APX-DPXOwnersManual.pmd 2006-03-14, 21:4728
Loading...
