English

BLT573

Clarion BLT573

This manual is published by Clarion, without any warranty. Improvements any changes to this manual necessitated by typographical errors, inaccuracies of current information or improvements to programs and/or equipment, may be made by Clarion at any time and without notice. Such changes will, however, be incorporated into new editions of this manual.

English

BLT573

1. WHAT IS INCLUDED IN THIS PACKAGE?

A complete BLT573 package consists of the following items:

CeNET extension cable

(

2.5m

)

Velcro hook (x2)

CeNET

Bluetooth

Interface Adapter

Mini jack extension cable (2.5m,

from head unit to CeNET

Bluetooth

Interface Adapter)

CeNET is an abbreviation of Clarion Entertainment Networks, an original bus system developed by Clarion, which enables high-speed data transfer and high quality sound transmission.

Screws and plate nuts (2 sets

)

Velcro loop (x2)

English

BLT573

The Clarion BLT573 is a CeNET

Bluetooth

interface adapter that allows you to utilize your car’s built-in audio system for wireless mobile phone handsfree communication. The car stereo with BLT573 installed will be able to retrieve phonebook contacts, received call, dialled call, missed call, incoming and outgoing calls.

BLT573 is specially designed to work with MAX973HD main unit (Update until May2007). For MAX973HD and mobile phone operations, please refer to the relevant owner’s manual. No any other car stereo can be connected.

Product Features Overview

The BLT573 has some of the following great features to give user an ultimate experience of handsfree communication via

Bluetooth

wireless technology.

Bluetooth

Pairing

Multiple mobile phones support

Make and Receive Calls

Caller ID display support

Acoustic Echo Cancellation and Noise Reduction

Automatic Answering

Incoming Call Refusal

Automatic connection

Phonebook downloading

Call transfer

(

Private mode

)

∗

Call waiting

∗

2. INTRODUCTION

Received/Dialled/Missed Call history support

Note: ∗Dependent on mobile phone

English

BLT573

3. CONNECTION

Please consult your nearest Clarion dealer before attempting to connect BLT573 to your main unit. Improper connection might damage your main unit, BLT573, or your vehicle wiring.

Please refer to the wiring instructions for your main unit or contact your Clarion Dealer.

Notes:

The C-Bus conversion adaptor (RCB-138) is not compatible with current system.

Please use the microphone included in MAX973HD. Connect the BLT573 and the main unit with the included

microphone extension cable.

There is a cover on the left CeNet connector. Please do not peel the cover off when not in use as it is only for

connecting to other CeNet device. Use the right CeNet connector for connecting to main unit.

Connect the BLT573 to the MAX973HD.

English

BLT573

4. INSTALLATION

There are no moving parts in BLT573. However, caution must be taken to ensure minimum damage to the unit. Do not press, puncture or drop the unit at anytime. Install the unit where there is no direct sunlight, away from vents or high moisture areas and away from other vehicle electronic components. Mount BLT573 away from moving parts in the vehicle.

Using Screws

There are screws mounting holes in BLT573. Before drilling, make sure there are no hidden wires and parts that might be damaged.

Improper wiring might damage BLT573 and MAX973HD.

CAUTION

Using Velcro or Double-Sided Tape

St ick Velcr o or Doubl e-si ded tap e to the BLT573.

Note:

In case of usi ng Velc ro or double -s id ed tap e,

make sure the unit will not fall down as this might damage the electronic component inside.

Floor

Velcro or 2-sided tapes

English

BLT573

Hands-Free Proﬁle (HFP

)

This is commonly used to allow car hands-free kits to communicate with mobile phones in the car. The

Bluetooth

car kits allow users with

Bluetooth

equipped cell phones to make use of some of the phone’s features, such as transfer calls.

5. INTRODUCTION TO BLUETOOTH

TECHNOLOGY

What is Bluetooth

wireless

technology?

Bl u etoot h

wirel e ss techn o logy is a ra dio technology that connects devices, such as mobile phones and headsets, without wires or cords over a short distance of approximately 10 meters (

Approx. 33 feet). Get more information at www.

bluetooth.com.

What is Bluetooth

wireless

proﬁles?

Bluetooth

wireless profiles are the different

ways that

Bluetooth

devices communicate with

other devices.

Bluetooth

phones support either

the headset proﬁle (HSP

)

, the hands-free proﬁle

(

HFP) or both. In order to support a certain proﬁle, a phone manufacturer must implement certain mandatory features within the phone’s software. The followings are the currently supported proﬁles for BLT573.

Headset Proﬁle (HSP

)

This is the most commonly used proﬁle, providing minimal controls including the ability to ring, answer a call, hangs up and adjusts the volume.

What is pairing?

Bluetooth

devices will not work if the devices

have not been paired.

With a mob ile pho ne featur ing

Bluetoo th

technology, you must ‘

pair’ the BLT573 with the

phone before you use it for the ﬁrst time.

‘Pairing’ creates a unique wireless link between the phone with

Bluetooth

wireless technology and your BLT573 eliminating the need to repeat the pairing process during future use.

What is passkey?

Passkey or PIN is a code that you enter on your mobile phone to pair it with the

Bluetooth

receiver

unit. This makes your phone and the

Bluetooth

receiver unit recognize each other and automatically work together

Th e

Bl u etoo t h

wirel ess func tion in you r pho n e has t o be t u rned on to es t ablis h automatic connection.

Object Push Proﬁle (OPP

)

A basic proﬁle for sending “objects”, such as contacts and virtual business cards. It is called push because the transfers are always instigated by the sender (Client), not the receiver (Server).

English

BLT573

Indicators

There are some indicators in the main unit that correspondence with BLT573.

Please refer to your main unit owner’s manual for further details and indicators support.

Bluetooth® indication

This indicator shows the status of the

Bluetooth

device.

6. MAIN FEATURES

Network Signal Strength Indication

This indicator will display the network signal coverage of the connected mobile phone. The actual range will depend on the main unit and mobile phone.

Battery state indication

This indicator can display the battery level of the connected mobile phone. The actual range will depend on the main unit and mobile phone.

The indication on the main unit may not always be the same with the indication on the phone as there might be some delay between the two devices.

Option Menu

There will be some options available in the main unit (MAX973HD

)

when BLT573 is connected. In order to display these options, please refer to the car stereo owner’s manual for these operations.

Items available in option menu

(

Display name may

vary depends on MAX973HD):

Pairing

This option is used to perform

Bluetooth

pairing with the mobile phone. Up to a maximum of 5 devices can be paired.

There are 2 pairing methods:

Search Mode

User can search the

Bluetooth

mobile phone via BLT573. The general steps for performing the operation will be the followings.

1. Activate

Bluetooth

on your mobile phone. Please check your mobile phone owner’s manual for further details.

2. Set the BLT573 in “

SEARCH” mode.

Sear c h f o r your mobi l e p h o n e from the search result list. A maximum of 30

Bluetooth

device scan be fou nd in “SEARCH” mode.

Bluetooth

address will be used if device name

is not found.

Status Indicator

Bluetooth

device

searching, pairing.

Connection, telephone call

Others

Blink rapidly

Off

Disconnection

Blink slowly

Please do not turn off ACC (car ignition) when performing this pairing mode.

CAUTION

English

BLT573

4. When attempting to connect to the mobile phone, the mobile phone will prompt for a passkey, enter the request PIN code. The timeout for inputing PIN code is 1 minute.

5. Connection will be automatically started upon su cces s ful p airi n g if the r e is no other connected device.

Notes:

A ctu al op erat i o ns w i l l de pen d on e a ch ca r st ere o. Plea se re fer your car st er eo ow ner ’s manual for further details.

Default PIN code is “1234”.

Wait Mode

Alternatively, user can search the BLT573 via the mobile phone.

1. Activate

Bluetooth

on your mobile phone. Please check your mobile phone owner’s manual for further details.

2. Set the BLT573 in “WAIT” mode

(

Discoverable).

3. Search for new

Bluetooth

device on the mobile

phone. The BLT573 default name is ‘BLT570

’. Default name may change according to the car stereo. Please refer to the car stereo owner’s manual.

4. When attempting to connect to the BLT573, the mobile phone will prompt for a passkey, enter the request PIN code.

5. Connection will be automatically started upon su c cessf u l pa iring if t here is n o ot her connected device.

Notes:

BLT 57 3 c a n o nl y b e f o un d b y a no t h er

Bluetooth

device in “WAIT” mode

(

Discoverable

mode).

The pairing informati on is kept in memory even

after the car ignition is off.

Pairing special device

This is used for pairing special

Bluetooth

device which cannot carry out pairing in usual pairing mode.

Please use this pairing mode if your

Bluetooth

device is listed in the menu.

1. During “

SELECT” option, choose one of the 5

devices from the list to establish a connection.

2. Connected device will be able to use all the functionalities provided.

Deleting device

This is a setting for user to delete any one of the paired device from the list.

1. During “DELETE” option, choose one of the 5 devices from the list to be deleted.

2. Confirm the paired device deleti on when prompt.

Notes:

Dele t ed pai red de v ice wi ll not au t oma tic all y

rearrange in the paired device list.

Wh en a dev i c e is delet e d fr o m the li st ,

it is necessary to del et e the BLT573 from the mo bi le phone as wel l an d vice vers a. Fai ling to do so will result pairing difﬁculties between the two devices in the future.

Microphone gain

Ch angi ng thi s optio n will affec t the ech o cancellation and noise reduction.

Please refer your car stereo owner’s manual for more information.

Ring volume

This option is used to change the ringing volume when there is an incoming call. The volume control is done by the mobile phone itself. However, if the mobile phone cannot support the ringing sound, the phone volume can be controlled through the volume setting in car stereo. Please refer your car stereo owner’s manual for more information.

Note:

Communication volume will depend on main unit.

Selecting device

This is a setting for user to select any one of the paired mobile phones to be connected to the BLT573.

English

BLT573

Automatic answering

This is a setting to determine whether any incoming call will be automatically or manually answered. The adjustment can be set to ON or OFF.

ON : An y inco ming call is auto matic ally

answered in 8 seconds

OFF : User needs to manually answer the call.

∗

Default setting is ON.

Notes:

Us er ca n sti l l manu a l ly an s wer the c all i n

less than 8 se conds even Automatic Answeri ng is turned on.

The time is counted from incoming call to answering

call.

Ringing sound period may be around 4 to 8 seconds

when the main unit is switching from other modes to Telephone mode during an incoming call.

Incoming call refusal

This function allows all incoming calls to be refused. The adjustment can be set to ON or OFF.

ON : All incoming calls are automatically

refused.

OFF : Incoming call notiﬁcation enabled.

∗

Default setting is OFF.

Note:

When this adjustment is set to ON, there are a

few things to note:

- Automatic answering will be disabled even if it is set

to ON.

- If automatic answering is set in the mobile phone,

it will be disconnected directly.

- Out-going call can still be made.

Automatic connection

This function allows BLT573 to be connected automatically with previously connected device. Connection can be established at any source mode.

The adjustment can be set to ON or OFF.

ON : Automatic connection is enabled

OFF : Automatic connection is disabled

∗

Default setting is ON.

Notes:

Automatic connection will be temporary disable

during pairing.

When the car ignition is turned on, any telephone

sp eak in g will be aut oma ti cal ly in ter rup te d to the car stereo and allowing user to continue the conversation through car stereo.

If mob i l e de v ice i s ma nua l l y di s con nec t e d,

automatic connection will not work.

PIN code

This PIN code is used during pairing mode. A maximum of 16 digits can be changed through the car stereo. However, this number can only be changed by some car stereo, please refer to car stereo owner’s manual for details.

∗

Default PIN code is “1234”.

Note:

PI N code may var y de pen ds o n ca r st ere o.

Please refer your car stereo owner’s manual for actual PIN code.

Bluetooth® address

This will hold the unique

Bluetooth

address of the

BLT573. The address is 12 ﬁgures.

Version

This will display the software version of the BLT573.

English

BLT573

Handsfree Operations

There will be some options available in the main unit when BLT573 is connected. In order to display these options, it will depend on each car stereo model. Please refer to the car stereo owner’s manual for these operations.

Items available in option menu

(

Display name may

vary depends on car stereo):

Downloading phonebook

Phonebook in the mobile phone can be downloaded into the BLT573 when the phone is paired and connected. The mobile phone must support automatic phonebook synchronization in order to perform this automatic phonebook download. Otherwise, user can manually transfer the contacts to the BLT573.

BLT573 is able to hold 500 contacts per mobile phone. There are 5 categories of telephone numbers can be stored on each contact

(

General,

Home, Ofﬁce, Mobile and other

)

and up to 5 mobile phones can be supported in BLT573. Depending on the number of contacts, some amount of time may be required until all the contacts have been downloaded.

The phonebook will be updated automatically everytime it connects

(

only if the phone supports

automatic phonebook synchronization).

Notes:

On ly c ont a cts t hat sto r ed i n th e ph o ne w i ll

be downloaded. Please refer to Clarion dealer for downloading of each mobile phone contacts.

When the memor y is full, any further download

will be imp os sible. Use r wil l need to del et e a paired device or contacts to free more space.

Phon ebook of not connect ed

Bluetooth

device

will not be read.

Phoneboo k wil l be delet ed auto matical ly when

th e corr esp ond enc e pa ir e d d ev i ce ha s be en deleted from the list.

Char ac ter disp la y wil l dep en d on ca r ste reo ;

some c a r st er e o s c an s up p o r t J ap a n e s e , Chinese and other UTF-8 characters.

Received/Dialled/Missed Call History

Any Received/Dialled/Missed call history made will be stored in the BLT573 depends on the type of phone. The BLT573 can hold up to 60 previously call numbers (or according to the phone speciﬁcation) for each category respectively.

Note:

Some phones support downloading of previously

Received/Dialled/Missed Call History.

Call Function

The Clarion car stereo must set to telephone interrupt mode to be able to work with the BLT573, please refer to the owner’s manual of each model for details.

Incoming Call

Whenever your car stereo is operating, the BLT573 is in standby mode awaiting the next call, when an incoming call arrives the car stereo is mute automatically and the ring tone is reproduced through your car’s speaker.

Main unit will temporarily switch to Telephone mode.

Name and telephone will only be displayed in the main unit if the contact is stored in the BLT573 phonebook.

∗

Display will be vary depends on main unit.

Notes:

When an incoming call occurs during Power OFF

but car ignition ON, some car stereos will be able to temporary Power ON and switch to Telephone Mode. After the conversation, system will return to pow er OFF status . Pl ea se refer to the car stereo owner’s manual.

Display will return to previous mode after call is

ended or rejected.

Always avoid us ing the phone when it is in low

battery level as some mobile phones may cause noises to the speakers.

English

BLT573

Answering a call

User can answer an incoming call directly from the car stereo. Please refer to your car stereo owner’s manual for the button operation. Alternatively, you may also answer the call by using your phone’s answer keypad. In this case, you can transfer the call to the car stereo by following the instruction in the section “Transferring a call”.

∗

Car stere o will be aut omatically set as defau lt

sp eak e r o ut p ut eve ryt ime wh en a ns w eri ng a call.

To reject a call

This function allows you to reject an incoming call via the car stereo. Alternatively, you may also reject the call by using your phone’s keypad.

Note:

This will depend on the type of phone.

Ending a call

Use either one of the following methods to end a call:

1. To end a call from the car stereo, please refer to your car stereo owner’s manual.

2. End a call from the phone’s keypad.

Call waiting

When there is an incoming call during a call conversation, it is possible that the call can be answered via car stereo. Please refer your car stereo owner’s manual for further details on this operation.

Note:

T h is f unc t ion wi l l de pen d on mob ile pho n e,

main unit and service provider.

Making a call

There are 2 ways to make outgoing call.

Direct Number Call

Outgoing call can be made by entering telephone numbers directly via the car stereo.

Telephone number uses 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, *, #, and +.

Call from Phonebook

Us er can se arc h the con tac t name in the phonebook and make call.

Alternatively, user can call from mobile phone.

Notes:

If no phone is connected, car stereo will not be

able to make outgoing call.

If call is made directly from the keypad of mobile

phone, telephone numbers and name may be displayed in the main unit. This will depend on mobile phone.

Redial

When the phone is connected, redial can be performed as it remembers the last dialed number. Each phone has its own redial number. If there’s no redial number, operation will not be performed.

Transferring a call (Private Mode

)

This function allows user to transfer a call from car stereo to mobile phone.

During a call, press the relevant button on the car stereo to transfer the call to the mobile phone. A call can be transferred back to car stereo by performing transfer call function in the phone. Please refer your car stereo and mobile phone owner’s manual for further operation.

Note:

This function is dependent on the type of phone.

Some phones are not supported.

English

BLT573

7. COMPATIBLE MODELS

BLT573 is exclusively made for MAX973HD.

Supported phones with Bluetooth

wireless technology

M a k e s ur e y ou r m ob il e p ho ne s u pp or ts

Bluetooth

ve rsio n 1.1, 1.2 and th e foll owi ng

Bl ueto oth

proﬁle:

- HFP/HSP v1.0 (Handsfree for mobile phone

)

For phonebook downloading, make sure your phone supports these proﬁles.

- OPP v1.0

(

Object Push Proﬁle

)

For automatic phonebook download, make sure your phone supports automatic phonebook synchronization feature.

Please check your phone’s specification for supported proﬁles or consult your Clarion dealer for phone compatibility.

Note:

Compat ib ility and con necti vi ty with all mob ile

phones with

Bluetooth

wi reless technology are

not guaranteed.

English

BLT573

8. TROUBLESHOOTING

Problem

Counter Measure

Unable to download phonebook.

Cause

Phone is not connected with

BLT573.

Connect the phone with BLT573. Please refer to your car stereo and mobile phone owner’s manual for pairing.

Phone does not have the relevant

Bluetooth

proﬁle.

Use a phone with required

Blue-

tooth

proﬁle supported or consult

your Clarion dealer.

Internal memory full. Delete unused paired device to free

more space.

Unable to pair with the phone.

Bluetooth

is not activated on the

phone.

Activate

Bluetooth

on the phone.

Call is not interrupted to the car stereo.

Telephone interrupt mode is off.

Set the telephone interrupt function to ON.

Cannot automatic connect the phone.

The BLT573 may be connected

to another mobile phone or your

phone may be connected to

another

Bluetooth

device, such as

headset.

Disconnect the other

Bluetooth

device and reconnect again.

If your mobile phone is able to select proﬁle, please select the handsfree proﬁle.

If your mobile phone is unable to select proﬁle, please delete the pairing information on both mobile phone and main unit and pair again.

Maximum 5 paired devices have

reached.

Delete one of the paired devices and redo the pairing.

Bluetooth

is not activated on the

phone.

Activate

Bluetooth

on the phone.

Automatic connection setting is

OFF.

Please turn on automatic connection.

No automatic answering during incoming call.

The automatic answering setting

is OFF.

Turn on the automatic answering setting.

Cannot operate the handsfree function properly.

No response from mobile phone. Turn off and on the mobile phone.

The caller side is unable to hear any sound.

Microphone may be disconnected. Please check the microphone con-

nection.

It is difﬁcult for the caller to hear.

Mircophone gain/sensitivity setting

is not suitable for current enviro-

ment.

Please adjust the setting accordingly.

The BLT573 is automatically con-

nected to previously connected

mobile phone.

Set the auto connection option to OFF and re-connect the mobile phone.

Cannot connect to the car handsfree.

English

BLT573

9. SPECIFICATIONS

Compliance

Proﬁles

Wireless Range

Data rate

Antenna

Compression/decompression

Operating temperature

Storage temperature

Dimensions

Weight

Signal-to-Noise Ratio

Voltage source

Max Current

Built in intenal ﬂash memory

Bluetooth

1.1 & 1.2

Phone Management: HFP1.0, HSP 1.0 Phone Book: PBAP1.0, OPP1.0 Server/Client (Vcard2.1

)

Class 2: Up to 10m (line of sight

)

1 Mbps (Max 723.2kbps

)

Embedded BT Antenna on PCB Module

SBC (sub-band coding

)

-20˚C ~ +70˚C

-40˚C ~ +85˚C

136.4mm (Depth) x 102.7mm (width) x 30mm (Height

)

0.15kg

more than 45dB

12V DC ~ 15.6V DC

less than 3A

2Mb

Car stereo has no response

Disconnect BLT573 and reconnect again.

Disconnect your mobile phone and reconnect again.

Power OFF and ON again the car stereo.

Handsfree proﬁle is not selected.

Name of contacts information is broken or missing.

Noises come out from the speaker during making outgoing call or conversation.

Please set the data encoding setting of mobile phone to “no encoding”

Recharge your mobile phone battery.

Encoded data from mobile phone

cannot be recognized properly.

Mobile phone battery level is low.

No sound from caller or having some problems during conversation.

Please delete the pairing information on both mobile phone and main unit and pair again.

Mobile phone has some connection

problems with BLT573.

English

BLT573

10. ADDITIONAL INFORMATION

Safe and efﬁcient use

Note: Read this information before using your BLT573.

Changes or modifications to this product not expressly approved by Clarion may void the user’s authority to operate the equipment.

Please check for any exceptions, due to national requirements or limitations, in usage of equipment with

Bluetooth

wirelesss technology before using

this product.

Product care

Do not expose your product to liquid or moisture

or to humidity.

Do not expose your product to extreme high or

low temperatures.

Do not expose your product to lit candles,

cigarettes, or cigars, or to open ﬂames etc.

Do not drop, throw or try to bend the product

as rough treatment could damage it.

Do not use any other accessories than Clarion

originals intended for use with this product. Use of non-original accessories may result in loss of performance, damage to the product, fire, electric shock or injury. The warranty does not cover product failures which have been caused by use of non-original accessories.

Do not attempt to disassemble your product. The

product does not contain consumer serviceable or replaceable components. Only Clarion service partners should perform service.

Do not keep the product in an area prone to

dust and dirt. Only use a soft damp cloth to clean your product.

If you will not be using the product for a while,

store it in a place that is dry, free from damp, dust and extreme temperatures.

To reduce risk of electric shock, unplug the unit

from any power source before attempting to clean it.

Installation

Please note that only authorised personnel should install the BLT573. Please check with your car dealer for recommendations on professional installat ion engineers. Check with your car manufacturer’s representative to be sure that all equipment for the BLT573, including additional accessories, is placed in a safe location. If your car is equipped with an air bag, check that the handsfree equipment does not interfere with its function.

Radio frequency exposure

Your BLT573 is a radio transmitter and receiver. When in operation, it communicates with a mobile device featuring

Bluetooth

wireless technology by receiving and transmitting radio frequency (RF)

electromagnetic ﬁelds

(

Microwaves

)

in the frequency range 2400 to 2500 MHz. The output power of the radio transmitter is low, 0.001 watt.

The BLT573 is designed to operate in compliance with the RF exposure guidelines and limits set by national authorities and international health agencies when used with any compatible mobile phone with

Bluetooth

wireless technology.

Driving

Check the laws and regulations on the use of mobile phones and handsfree equipment in the areas where you drive.

Always give full attention to driving and pull off the road and park before making or answering a call if driving conditions so require.

RF energy may affect some electronic systems in motor vehicles such as car stereo, safety equipment etc. Check with your vehicle manufacturer’s representative to be sure that your mobile phone or BLT573 will not affect the electronic systems in your vehicle.

English

BLT573

Electronic equipment

Most modern electronic equipment is shielded from RF energy. However, certain electronic equipment is not, therefore:

Do not use your BLT573 near medical equipment without requesting permission. If you are using any personal medical devices, e.g. a pacemaker or a hearing aid, please read in your mobile phone’s User’s Guide for further information.

Blasting areas

Turn off all your electronic devices when in a blasting area or in areas posted turn off two-way radio to avoid interfering with blasting operations. Construction crews often use remote control RF devices to set off explosives.

Potentially explosive atmospheres

Turn off your electronic device when in any area with a potentially explosive atmosphere. It is rare, but your electronic device could generate sparks. Sparks in such areas could cause an explosion or ﬁre resulting in bodily injury or even death.

Areas with a potentially explosive atmosphere are often, but not always, clearly marked.

Children

Do not allow children to play with your BLT573 since it contains small parts that could become detached and create a choking hazard.

Emergency calls

This BLT573, and t he electronic device connected to the handsfree operate using radio signals, cellular, bluetooth wireless technology and landline networks as well as user-programmed functions, which cannot guarantee connection under all conditions. Ther efore you sho uld never rel y sole ly upon any electronic device for essential communications (e.g. medical emergencies).

Remembe r, in order to make or receive calls, the BLT573 and the electronic device connected to the handsfree must be switched on and in a service area with adequate cellular signal strength. Emergency calls may not be possible on all cellular phone networks or when certain network services and/or phone features are in use. Check with your local service provider.

IMPORTANT!

If you want to dispose this product, do not mix it with general household waste. There is a separate collection system for used el ectro nic pro duc ts in accordan ce with legislation that requires proper treatment, recovery and recycling.

CAUTION!

Private households in the 25 member states of the EU, in Switzerland and Norway may return their used electronic products free of charge to designated collection facilities or to a retailer (if you purchase a similar new one). For countries not mentioned above, please contact your local authorities for the correct method of disposal. By doing so you will ensure that your disposed product under goes the necessary treatment, recovery and recycling and thus prevent potential negative effects on the environment and human health.

Declaration of Conformity

R&TTE Directive

(1999/5/EC)

We, manufacturer / supplier Clarion

(M)

Sdn Bhd

Phase 3, Free Industrial Zone, 11900, Bayan Lepas, Penang, Malaysia.

Declare under our sole responsibility that the following product:

Type of Equipment: CeNET Bluetooth Interface Adapter

Model No. : BLT573

Product code: EA-1316Y-A

To which this declaration relates, is in conformity with the following standards and/or other normative documents. :

Standards: ETSI EN 300 328 v1.6.1 (2004-11) ETSI EN 301 489-17 v1.2.1 (2002-08) ETSI EN 301 489-1 v1.6.1(2005-09) EN 60950-1: 2001 + A11

(If applicable) following the provisions of 1999/5/EC Directive And following the provisions of 2004/104/EC Directive, according to paragraph 3.2.9 of Annex I, meets the limits deﬁned in paragraph 6.5, 6.6, 6.8 and 6.9 of Annex I

Trade name : Clarion Co., Ltd Address : 50 Kamitoda, Toda-shi, Saitama 335-8511, Japan

I, the undersigned hereby declare that the equipment speciﬁed above Conforms to the above Directive and Standard(s)

Place : Clarion (M) Sdn Bhd

Date : June 20, 2007

Name/Title : T. Nakazaki/Director

TEL : +6046148403

FAX : +6046414324

Authorized representative: Clarion Europe GmbH Hessenring

19-21 64546 Mörfelden-Walldorf

Name/Title : S. Yamakawa/President

TEL : +49-6105-9770

FAX : +49-6105-977300

Clarion Co., Ltd.

Printed in Malaysia / Imprimé en Malaisie / Gedruckt in Malaysia / Stampato in Malesia / Gedrukt in Malaysia / Impreso en Malasia /

Tryckt i Malaysia / Impresso na Malásia / Trykt i Malaysia

EA-1316E

280-8517-01

Clarion BLT573 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
