Citizen AN8160-52L Instruction manual

INSTRUCTION MANUAL

CONTENTS

1. Features

2. Displays and Buttons

3. Setting the Time

4. Setting the Date

5. Using the Chronograph

6. Zero Positioning of Chronograph Hands

7. Precautions

8. Specications

2

...........................................................................................................

.....................................................................................

.............................................................................................

..............................................................................................

.................................................................................

...................................................................................................

................................................................................................

(After Replacing the Battery)

............

3
3
4
6

8
10
12
19

1. Features

This watch is an analog quartz watch equipped with features including a 24 hour
display and chronograph function.

2. Displays and Buttons

Hour hand

Chronograph minute hand

Second hand

18

Chronograph second hand

Button (B)

Minute hand

Crown

24 hour hand

Button (A)

Date

* The illustrations shown in this manual may differ from the actual watch you

have purchased.

3

3. Setting the Time

Minute hand

Hour hand

Second hand

18

Time correction position

In the case the crown is of the screw-lock type, loosen the screw by turning the
crown to the left before operating the crown, and after having returned the crown
to the normal position following operation, turn the crown to the right while
pushing it in to securely retighten it.

4

1. Pull the crown out to the time correction position when the second hand has
reached the 0 seconds position.

2. Turn the crown to set the time.
* The 24 hour hand moves in conjunction with the hour hand. Pay attention

to AM and PM when setting the time.

3. Securely return the crown to the normal position in synchronization with a
telephone or other time service.

[Hint for Accurately Setting the Time]

After stopping the second hand at the 0 seconds position, turn the minute hand
4-5 minutes past the correct time and then turn it back to the correct time. The
time on the watch can then be set to the correct time by pushing in the crown in
synchronization with a time service tone.

5

4. Setting the Date

6

18

Date correction position

Date
