Data Sheet

Cisco Catalyst 2960-S and 2960 Series Switches

with LAN Lite Software

The Cisco

Catalyst

2960-S and 2960 Series Switches are the leading Layer 2 edge

switches, providing improved operational excellence, highly secure business

operations, improved sustainability, and an enhanced workspace experience. They

are fixed-configuration access switches designed for entry-level enterprise,

midmarket, and branch office networks. Figure 1 shows the Cisco Catalyst 2960-S

Series Switch model and Figure 2 shows the Cisco Catalyst 2960 Series Switch

model with LAN Lite software.

The Cisco Catalyst 2960-S Series Switches with LAN Lite Software have the following capabilities:

●

24 and 48 ports of Gigabit Ethernet (GbE) 10/100/1000 desktop connectivity

●

1 GbE Small Form-Factor Pluggable (SFP) uplinks

●

USB storage interface for file backup, distribution, and simplified operations

●

Enhanced troubleshooting for problem solving, including link connectivity and cable diagnostics

●

Single IP address management for up to 16 switches

●

A wide range of software features to provide ease of operation, secure business operations, sustainability

and borderless networking experience

●

Limited lifetime hardware warranty, including next-business-day replacement with 90-day service and

support

The Cisco Catalyst 2960 Series Switches with LAN Lite Software have the following capabilities:

●

Fast Ethernet connectivity with Power over Ethernet (PoE) of up to 15.4W per port

●

GbE for data connectivity

●

Enhanced troubleshooting for problem solving, including link connectivity and cable diagnostics

●

Single IP address management for up to 16 switches

●

A wide range of software features to provide ease of operation, highly secure business operations,

sustainability, and a borderless networking experience

●

Limited lifetime hardware warranty

Figure 1. Cisco Catalyst 2960-S and 2960 Series Switches with LAN Lite Software

Figure 2. Cisco Catalyst 2960-S Series Switches with LAN Lite Software

Switch Configurations

Table 1 shows the configuration information for the Cisco Catalyst 2960-S and 2960 Series Switches with LAN Lite

Software.

Table 1. Configurations of Cisco Catalyst 2960-S and 2960 Series Switches with LAN Lite Software

Switch Model

Description

Uplinks

Catalyst 2960-S Switches with 1 Gigabit Uplinks and 10/100/1000 Ethernet Connectivity

Cisco Catalyst 2960S-48TS-S

48 Ethernet 10/100/1000

2 1 GbE ports

Cisco Catalyst 2960S-24TS-S

24 Ethernet 10/100/1000

2 1 GbE SFP ports

Catalyst 2960 Switches with 1 Gigabit Uplinks and 10/100 Ethernet Connectivity

Cisco Catalyst 2960-48PST-S

48 Ethernet 10/100 PoE ports (370W capacity)

2 fixed 10/100/1000 ports and 2 SFP ports

Cisco Catalyst 2960-24PC-S

24 Ethernet 10/100 PoE ports (370W capacity)

2 dual-purpose ports (10/100/1000 or SFP)

Cisco Catalyst 2960-24LC-S

24 Ethernet 10/100 and 8 10/100 PoE ports (123W

capacity)

2 dual-purpose ports (10/100/1000 or SFP)

Cisco Catalyst 2960-48TC-S

48 Ethernet 10/100

2 dual-purpose ports (10/100/1000 or SFP)

Cisco Catalyst 2960-48TT-S

48 Ethernet 10/100

2 fixed 10/100/1000 ports

Cisco Catalyst 2960-24TC-S

24 Ethernet 10/100

2 dual-purpose ports (10/100/1000 or SFP)

Cisco Catalyst 2960-24-S

24 Ethernet 10/100

None

Compact Switches

Cisco Catalyst 2960-8TC-S

8 Ethernet 10/100 compact size with no fan

1 dual-purpose port (10/100/1000 or SFP)

Cisco Catalyst 2960-S and 2960 Series Switches Enable Cisco Borderless Network

The Cisco Borderless Network Architecture delivers the new workspace experience, connecting anyone,

anywhere, using any device, to any resource securely, reliably, and transparently. The Cisco Borderless Networks

architecture addresses primary IT and business challenges to help create a truly borderless experience by bringing

interactions closer to the employee and customer.

Borderless experience is only possible with intelligent network elements designed and architected to meet the

needs of a global workspace. Cisco Network Access is a primary component of this architecture, enabling various

borderless network services such as mobility, security, EnergyWise, and ease of operations for increased

productivity and operational efficiency.

Cisco Network Access for Borderless solution focuses on the following primary areas:

●

Sustainability

●

Ease of operations

●

Borderless security

●

Borderless experience

Sustainability

Cisco Catalyst switching solutions enable greener practices through measurable power efficiency, integrated

services, and continuous innovations such as Cisco EnergyWise, an enterprisewide solution that monitors and

conserves energy with customized policies. Together, Cisco EnergyWise technology and Cisco Catalyst switches

reduce greenhouse gas (GhG) emissions and increase energy cost savings and sustainable business behavior.

Sustainability features in the Cisco Catalyst 2960-S and 2960 Series Switches include the following features sets:

●

Cisco EnergyWise technology

●

Efficient switch operation

●

Intelligent power management

Cisco EnergyWise Technology

Cisco EnergyWise is an innovative architecture, added to fixed configuration switches, promoting companywide

sustainability by reducing energy consumption across an entire corporate infrastructure and affecting more than 50

percent of global greenhouse gas emissions created by worldwide building infrastructure, a much greater effect

than the 2 percent generated by the IT industry. Cisco EnergyWise enables companies to measure the power

consumption of network infrastructure and network-attached devices and manage power consumption with specific

policies, reducing power consumption to realize increased cost savings, potentially affecting any powered device.

EnergyWise encompasses a highly intelligent network-based approach to communicate messages that measure

and control energy between network devices and endpoints. The network discovers Cisco EnergyWise-

manageable devices, monitors their power consumption, and takes action based on business rules to reduce

power consumption. EnergyWise uses a unique domain-naming system to query and summarize information from

large sets of devices, making it simpler than traditional network management capabilities. Cisco EnergyWise’s

management interfaces allow facilities and network management applications to communicate with endpoints and

each other using the network as a unifying fabric. The management interface uses standard Simple Network

Management Protocol (SNMP) or TCP to integrate Cisco and third-party management systems.

Efficient Switch Operation

Cisco Catalyst 2960-S and 2960 Series Switches, designed and engineered by Cisco, provide optimum power

saving, low power operations for industry best-in-class power management, and power consumption capabilities.

The Catalyst 2960-S ports are capable of reduced power modes so that ports not in use can move into a lower

power utilization state.

Intelligent Power over Ethernet Management

The Cisco Catalyst 2960 Series PoE models support the latest PoE devices including Cisco IP phones and Cisco

Aironet WLAN access points providing up to 15.4W of power per port, as well as any IEEE 802.3af-compliant end

device.

●

Per port power consumption command allows customers to specify maximum power setting on an

individual port.

●

Cisco Discovery Protocol Version 2 allows switches to negotiate a more granular power setting when

connecting to a Cisco powered device such as IP phones or access points than what is provided by IEEE

classification.

●

PoE MIB provides proactive visibility into power usage and allows customers to set different power-level

thresholds.

●

IEEE 802.3af and Cisco prestandard PoE support comes with automatic discovery to detect a Cisco

prestandard or IEEE 802.3af endpoint and provide the necessary power without any user configuration.

Per-port PoE power sensing measures the actual power being drawn, enabling more intelligent control of

powered devices.

Table 2 lists the PoE capacity of the Cisco Catalyst 2960 Series Switches.

Table 2. Switch PoE Power Capacity

Switch Model

Maximum Number of PoE Ports*

Available PoE Power

Cisco Catalyst 2960-48PST-S

24 ports up to 15.4W

48 ports up to 7.7W

370W

Cisco Catalyst 2960-24PC-S

24 ports up to 15.4W

370W

Cisco Catalyst 2960-24LC-S

8 ports up to 15.4W

123W

*Intelligent power allows flexible power allocation across all ports.

Ease of Operations

The Cisco Catalyst 2960-S and 2960 Series Switches help reduce the operating costs through:

●

Cisco Catalyst Smart Operations

●

Easy to use deployment and control features

●

Advanced, intelligent network management tools

Cisco Catalyst Smart Operations

Cisco Catalyst Smart Operations is a comprehensive set of capabilities that simplify LAN deployment,

configuration, and troubleshooting. Cisco Catalyst Smart Operations enable zero-touch installation and

replacement of switches, fast upgrade, as well as ease of troubleshooting with reduced operational cost.

Cisco Catalyst Smart Operations is a set of features that includes Smart Install, Auto Smartports, Smart

Configuration, and Smart Troubleshooting to enhance operational excellence:

●

Cisco Smart Install is a transparent plug-and-play technology to configure the Cisco IOS Software image

and switch configuration without user intervention. Smart Install utilizes dynamic IP address allocation and

the assistance of other switches to facilitate installation providing transparent network plug and play.

●

Cisco Auto Smartports provide automatic configuration as devices connect to the switch port, allowing

auto detection and plug and play of the device onto the network.

Easy to Use Deployment and Control Features

●

Auto-negotiation on all ports automatically selects half- or full-duplex transmission mode to optimize

bandwidth.

●

Dynamic Trunking Protocol (DTP) facilitates dynamic trunk configuration across all switch ports.

●

Port Aggregation Protocol (PAgP) automates the creation of Cisco Fast EtherChannel

groups or Gigabit

EtherChannel groups to link to another switch, router, or server.

●

Link Aggregation Control Protocol (LACP) allows the creation of Ethernet channeling with devices that

conform to IEEE 802.3ad. This feature is similar to Cisco EtherChannel technology and PAgP.

●

Automatic media-dependent interface crossover (MDIX) automatically adjusts transmit and receive pairs

if an incorrect cable type (crossover or straight-through) is installed.

●

Unidirectional Link Detection Protocol (UDLD) and Aggressive UDLD allow unidirectional links caused

by incorrect fiber-optic wiring or port faults to be detected and disabled on fiber-optic interfaces.

●

Dynamic Host Configuration Protocol (DHCP) autoconfiguration of multiple switches through a boot

server eases switch deployment.

●

Switching Database Manager (SDM) templates for access, routing, and VLAN deployment allow the

administrator to easily maximize memory allocation to the desired features based on deployment-specific

requirements.

●

Local Proxy Address Resolution Protocol (ARP) works in conjunction with Private VLAN Edge to

minimize broadcasts and maximize available bandwidth.

●

Internet Group Management Protocol (IGMP) Snooping for IPv4 and IPv6 MLD v1 and v2 Snooping

provide fast client joins and leaves of multicast streams and limit bandwidth-intensive video traffic to only

the requestors.

●

Per-port broadcast, multicast, and unicast storm control prevents faulty end stations from degrading

overall systems performance.

●

Voice VLAN simplifies telephony installations by keeping voice traffic on a separate VLAN for easier

administration and troubleshooting.

●

Cisco VLAN Trunking Protocol (VTP) supports dynamic VLANs and dynamic trunk configuration across

all switches.

●

Switch Port Analyzer (SPAN) allows administrators to monitor ports in a Layer 2 switch network from any

other switch in the same network.

●

For enhanced traffic management, monitoring, and analysis, the Embedded Remote Monitoring (RMON)

software agent supports four RMON groups (history, statistics, alarms, and events).

●

Trivial File Transfer Protocol (TFTP) reduces the cost of administering software upgrades by downloading

from a centralized location.

●

Network Timing Protocol (NTP) provides an accurate and consistent timestamp to all intranet switches.

●

Cisco Emergency Responder (CER) enhances emergency calling from Cisco Unified CallManager. It

helps assure that Cisco Unified CallManager sends emergency calls to the appropriate Public Safety

Answering Point (PSAP) for the caller's location.

Advanced, Intelligent Network Management Tools

The Cisco Catalyst 2960-S and 2960 Series Switches offer both a superior CLI for detailed configuration and Cisco

Network Assistant software, a PC-based tool for quick configuration based on preset templates. In addition,

CiscoWorks LAN Management Solution (LMS) supports the Cisco Catalyst 2960-S and 2960 Series Switches for

networkwide management.

Cisco Network Assistant

A PC-based network management application designed for small and medium-sized business (SMB) networks with

up to 250 users, Cisco Network Assistant offers centralized network management and configuration capabilities.

Cisco Network Assistant uses Cisco Smartports technology to simplify both initial deployment and ongoing

maintenance. This application also features an intuitive GUI where users can easily apply common services across

Cisco switches, routers, and access points, such as:

●

Configuration management

●

Troubleshooting advice

●

Inventory reports

●

Event notification

●

Network security settings

●

Password synchronization

●

Drag-and-drop Cisco IOS Software upgrades

●

Secure wireless

For detailed information about Cisco Network Assistant, visit http://www.cisco.com/go/cna.

CiscoWorks LAN Management Solution

CiscoWorks LAN Management Solution (LMS) is a comprehensive network lifecycle management solution. It

provides an extensive library of easy-to-use features to automate the initial and day-to-day management of your

Cisco network infrastructure. CiscoWorks LMS uniquely uses Cisco hardware and software platform knowledge

and operational experience into a powerful set of workflow driven configuration, monitoring, troubleshooting,

reporting, and administrative tools. Including:

●

Support for new Cisco hardware platforms the day they ship

●

Support for new technologies and services from initial deployment to day-to-day administration and

management, such as EnergyWise, Identity, Cisco Auto Smartports, Cisco Smart Install, and much more

●

Configuration management tools built from Cisco experience and Cisco Validated Design recommendations

●

Monitoring and troubleshooting capabilities that incorporates Cisco hardware best practices and diagnostics

features

●

Automation in managing hardware inventories, security vulnerabilities (PSIRTS) and platform end-of-life and

support cycles

For detailed information about CiscoWorks LMS, go to:

http://www.cisco.com/en/US/products/sw/cscowork/ps2425/index.html.

+ 11 hidden pages
