Cisco RV130, RV130W User Manual

ADMINISTRATION

GUIDE

Cisco RV130 Multifunction VPN Router Cisco RV130W Wireless Multifunction VPN Router

Revised July 2015

Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this URL: www.cisco.com/go/trademarks. Third-party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company. (1110R)

Contents

Chapter 1: Getting Started 5

Connecting to Your Wireless Network 7

Chapter 2: Viewing Device Status 8

Viewing the Dashboard 8 Viewing the System Summary 9 Viewing Active TCP/IP Services 11 Viewing Wireless Statistics 11 Viewing Captive Portal Status 11 Viewing Site-to-Site IPsec VPN Connection Status 11 Viewing the IPsec VPN Server Status 12 Viewing PPTP Server 12 Viewing Logs 12 Viewing Connected Devices 13 Viewing Port Statistics 14 Viewing the Mobile Network Status 14

Chapter 3: Configuring Networking 16

Configuring Wired WAN Connections 16

Configuring a Mobile Network 25

Configuring Global Mobile Network Settings 25 Configuring Mobile Network Settings Manually 26 Bandwidth Cap Setting 27 E-mail Setting

Setting Failover and Recovery 28

Configuring LAN Settings 29

Changing the Device Management IP Address 29 Configuring DHCP Server 30

Configuring VLANs 32 Configuring Static DHCP 33 Viewing DHCP Leased Clients 34

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 1

Configuring a DMZ Host 34 Configuring RSTP 35 Port Management 36 Configuring Link Aggregation 37

Contents

Cloning the MAC Address 38 Configuring Routing 39 Viewing the Routing Table 41 Configuring Dynamic DNS 42 Configuring the IP Mode 43 Configuring IPv6 44

Configuring the IPV6 WAN Connection 44 Configuring IPv6 LAN Connections 48 Configuring IPv6 Static Routing 50 Configuring Routing (RIPng) 51 Configuring Tunneling 52 Viewing IPv6 Tunnel Status 53 Configuring Router Advertisement 53 Configuring Advertisement Prefixes 55

Chapter 4: Configuring Wireless Networks 57

Wireless Security 57 Wireless Networks on Your Device 59 Configuring Basic Wireless Settings 60

Editing Wireless Network Settings 61 Configuring the Security Mode 62 Configuring MAC Filtering 66 Configuring Time of Day Access 67

Configuring Advanced Wireless Settings 67 Detecting Rogue Access Points 70 Configuring WDS 73 Configuring WPS 75

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 2

Contents

Configuring Captive Portal 75 Configuring Device Mode 78

Chapter 5: Configuring the Firewall 80

Firewall Features 80 Configuring Basic Firewall Settings 81

Configuring Remote Management 84 Configuring Universal Plug and Play 85

Managing Firewall Schedules 85 Configuring Services Management 86 Configuring Access Rules 87

Adding Access Rules 88

Creating an Internet Access Policy 90

Adding or Editing an Internet Access Policy 90

Configuring One-to-One Network Address Translation (NAT) 92 Configuring Port Forwarding 92

Configuring Single Port Forwarding 93 Configuring Port Range Forwarding 94 Configuring Port Range Triggering 94

Chapter 6: Configuring VPN 97

VPN Tunnel Types 97 Configuring Basic Site-to-Site IPsec VPN 97

Viewing Default Values 98

Configuring Site-to-Site IPsec VPN Advanced Parameters 99

Managing IKE Policies 99 Managing VPN Policies 100

Configuring IPsec VPN Server 103

Configuring the IPsec VPN Server 103 Configuring IPsec VPN User Accounts 104

Configuring PPTP 105

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 3

Configuring the PPTP Server 105 Creating and Managing PPTP Users 105

Contents

Configuring VPN Passthrough 106 SSL Certificate 106 VPN Setup Wizard 108

Chapter 7: Configuring Quality of Service (QoS) 109

Configuring Bandwidth Management 109 Configuring QoS Port-Based Settings 112 Configuring CoS Settings 113 Configuring DSCP Settings 113

Chapter 8: Managing Your Device 115

Setting Device Properties 115 Setting Password Complexity 115 Configuring User Accounts 116

Importing User Accounts 117

Setting the Session Timeout Value 119 Configuring Simple Network Management (SNMP) 119 Using Diagnostic Tools 122

Network Tools 122 Configuring Port Mirroring 123

Configuring Log and E-mail Settings 124

Configuring Log Settings 124 Configuring Log E-Mailing 126

Configuring Bonjour 128 Configuring Date and Time Settings 128 Backing Up and Restoring the System 129 Upgrading Firmware or Changing the Language 132 Restarting the Device 134 Restoring the Factory Defaults 134

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 4

Getting Started

The Getting Started page displays the most common configuration tasks on your device. Click the links on the Web page to go to the relevant configuration page.

This page appears every time you start Devic e Manager. To change this behavior, check Don’t show on start up.

Initial Settings

Change Default Administrator Password

Launch Setup Wizard Launches the Setup Wizard. Follow the on-screen

Configure WAN Settings Opens the Internet Setup page to change

Configure LAN Settings Opens the LAN Configuration page to modify LAN

Configure Wireless Settings

Displays the Users page where you can change the administrator password and set up a guest account. See Configuring User Accounts.

instructions.

parameters. For example, the device host name. See Configuring Wired WAN Connections.

parameters. For example, the management IP address. See Configuring LA N Settings.

Open the Basic Settings page to manage the radio. See Configuring Wireless Networks.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 5

Getting Started

Quick Access

Upgrade Router Firmware

Add VPN Clients Opens the PPTP Server page to set up and

Configure Remote Management Access

Device Status

System Summary Displays the System Summary page that shows

Wireless Status Displays the Wireless Statistics page that shows

Opens the Firmware/Language Upgrade page to update the device firmware or language pack. See

Upgrading Firmware or Changing the Language.

manage VPN tunnels. See Configuring PPTP. Opens the Basi c Se tt in g s page to enable the basic

features of the device. See Configuring Basic

Firewall Settings.

the state of the firmware, IPv4 and IPv6 configuration status, and the status of the wireless and the firewall on the device. See Viewing the

System Summary.

the state of the radio. See Viewing Wireless

Statistics.

VPN Status Displays the IPsec VPN Server page that lists the

VPN managed by this device. See Viewing Site-

to-Site IPsec VPN Connection Status.

Other Resources

Support Click to open the Cisco support page. Forums Click to visit Cisco online support forums.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 6

Getting Started

Connecting to Your Wireless Network

To connect a client device (such as a computer) to your wireless network, configure the wireless connection on the client device with the wireless security information that you configured for the router by using the Setup Wizard.

The following steps are provided as an example; you may need to configure your device differently. For specific instructions, consult the documentation for your client device.

STEP 1 Open the wireless connection settings window or program for your device.

Your computer might have special software installed to manage wireless connections, or you might find the wireless connections under the Control Panel in the Network Connections or Network and Internet window. (The location depends on your operating system.)

STEP 2 Enter the network name (SSID) that you chose for your network in the Setup

Wizard.

STEP 3 Choose the type of encryption and enter the security key that you specified in the

Setup Wizard. If you did not enable security (not recommended), leave the wireless encryption

fields that were configured with the security type and passphrase blank.

STEP 4 Verify your wireless connection and save your settings.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 7

Viewing Device Status

To ensure that data and statistics are frequently updated on Status pages, choose a refresh rate from the Refresh Rate drop-down list.

Viewing the Dashboard

Choose Status > Dashboard to view a snapshot of the configuration of your device. The Dashboard page displays information about your device’s firmware version, CPU and memory utilization, error-logging settings, LAN, WAN, wireless, site-to-site IPsec VPN, and PP TP VPN server settings.

To modify the information display ed, click the details link to go t o the configuration page for the section. For more information about managing the settings displayed on the Dashboard page, see:

• Configuring Log Settings

• Configuring Basic Site-to-Site IPsec VPN

• Configuring LAN Settings

• Configuring Wired WAN Connections

• Configuring Basic Wireless Settings

From the Refresh Rate drop-down list, choose the rate at which the latest statistics and parameter values are refreshed on the dashboard.

The Dashboard page also displays an interactive view of your device’s back panel when you click Show Panel View. Mouse-over each port to view port connection information.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 8

Viewing Device Status

Viewing the System Summary

Choose Status > System Summary to view details of your device properties, network settings across IP address modes, firewall, wireless and VPN settings. Click Refresh to see the latest information.

Click the underlined link to go to the related configuration window. For example, to modify the LAN IP address, click LAN IP. The LAN Configuration window is displayed.

The System Summary page displays information in the following sections:

System Information

• Firmware Version—Current software version that the device is running.

• Firmware MD5 Checksum—The message-digest algorithm used to verify

the integrity of files.

• Locale—The language installed on the router.

• Language Version—The version of the installed language pack. The

language pack version should be compatible with the currently installed firmware. In some cases, an older language pack may be used with a newer firmware image. The router checks the language pack version to see if it is compatible with the current firmware version.

• Language MD5 Checksum—The MD5 checksum of the language pack.

• CPU Model—Chipset of CPU currently used.

• Serial Number—Serial number of the device.

• System Up Time—Length of time that the system has been running.

• Current Time—Time of day.

• PID VID—Product ID and version ID of the device.

IPv4 Configuration

• LAN IP—LAN IP address of the device.

• WAN IP—WAN IP address of the device. To release the current IP address

and obtain a new one, click Release or Renew.

• Gateway—IP addr ess of the gateway to which the device is connected (for

example, the cable modem).

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 9

Viewing Device Status

Viewing the System Summary

• Mode—Displays Gateway if NAT is enabled, or Router.

• DNS 1—Primary DNS server IP address of the WAN port.

• DNS 2—Secondary DNS server IP address of the WA N port.

• DDNS—Indicates whether the Dynamic DNS is enabled or disabled.

IPv6 Configuration

• LAN IP—LAN IP address of the device.

• WAN IP—WAN IP address of the device.

• Gateway—IP addr ess of the gateway to which the device is connected (for

example, the cable modem).

• Prefix Delegation—Prefix returned from the device at the ISP, which is

provided to IPv6 addresses on the device.

• DNS 1—IP address of the primary DNS server.

• DNS 2—IP address of the secondary DNS server.

Wireless Summary

Displays the public name and security settings for your wireless networks configured on the Wireless > Basic Settings page. For more information, see

Configuring B asic Wireless Settings.

Firewall Setting Status

Displays DoS, WAN request and remote management settings configured on the Firewall > Basic Settings page. For more information, see Configuring Basic

Firewall Settings.

VPN Setting Status

Displays available IPsec and PPTP VPN connections, and the connected users for each VPN type.

• IPsec Connections Available—Number of available IPse c VPN

connections.

• PPTP VPN Connections Available—Number of available PPTP VPN

connections.

• Connected IPsec Users—Number of connected IPsec VPN users.

• Connected PPTP VPN Users—Number of connected PPTP VPN users.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 10

Viewing Device Status

Viewing Active TCP/IP Services

For more information on configuring VPN server connections and user accounts, see Configuring Basic Site-to-Site IPsec VPN and Configuring PPTP.

Viewing Active TCP/IP Services

Choose Status > Active TCP/IP Services to view IPv4 and IPv6 TCP/IP connections that are active on your device. The Active Service List section for IPv4 and IPv6 displays the protocols and the services that are active on the device.

Viewing Wireless Statistics

Choose Status > Wireless Statistics to view wireless statistical data for the device radio. In the Refresh Rate field, choose the rate at which you want the latest statistics to be displayed.

To show the bytes in kilobytes (KB) and the numerical data in rounded-up values, check the Show Simplified S tatistic Data check box and click Save. By default, byte data is displayed in bytes and other numerical data is displayed in long form.

To reset the wireless statistics counters, click Clear Count. The counters are reset when the device is rebooted.

Viewing Captive Portal Status

Choose Status > Captive Portal to view information about the connected Captive Portal users. For more information about configuring Captive Portals on your device, see Configuring Captive Portal.

Viewing Site-to-Site IPsec VPN Connection Status

Choose Status > Site-to-Site IPsec VPN to view the connection status of active site-to-site IPsec VPN policies on the device. For information on configuring VPN policies, see Configuring Basic Site-to-Site IPsec VPN.

To change the rate at which latest and real-time connection status is displayed, choose a refresh rate from the Refresh Rate drop-down list.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 11

Viewing Device Status

Viewing the IPsec VPN Server Status

By default, byte data is displayed in bytes and other numerical data is displayed in long form. To show the bytes in kilobytes (KB) and the numerical data in roundedup form, check the Show Simplified Statistic Data box and click Save.

To terminate an active VPN connection, click Disconnect.

Viewing the IPsec VPN Server Status

Choose Status > IPsec VPN Server to view a list of your IPsec VPN connections and the duration of the connection. For more information about configuring IPsec VPN connections, see Configuring IPsec VPN Server.

Viewing PPTP Server

Choose Status > PPTP Server to view a list of your PPTP VPN connections, the duration of the connection, and the actions you can perfom on this connection. For more information about configuring PPTP VPN connections, see Configuring

PPTP.

Viewing Logs

Choose Status > View Logs. Click Refresh Logs, to display latest log entries. To filter logs or specify the severity of logs to display, check the boxes next to the

log type and click Go. Note that all log types above a selected log type are automatically included and you cannot deselect them. For example, checking the Error check box automatically includes emergency, alert, and critical logs in addition to error logs.

The event severity levels are list ed from the highest severity to the lowest severity , as follows:

• Emergency—Messages about events such as a system crash.

• Alert—Messages about conditions that require immediate correcti ve action.

• Critical—Messages for when the system is in a critical condition.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 12

Viewing Device Status

Viewing Connected Devices

• Error—Messages about conditions that are not critical but require corrective

action.

• Warning—System warnings.

• Notification—Messages about normal but significant conditions that may

require attention.

• Inf ormational—Messages about device information.

• Debugging—Detailed information about an event.

To delete all entries in the log window, click Clear Logs. To save all log messages from the device to the local hard drive, click Save Logs. To specify the number of entries to show per page, choose a number from the

drop-down menu. To move between log pages, use the page navigation buttons .

Viewing Connected Devices

The Connected Devices page displays information about the active client devices connected to your router. To view connected devices, choose Status > Connected Devices.

To specify the types of interfaces to display, select a value from the Filter dropdown menu:

• All—All devices connected to the router.

• Wireless—All devices connected through the wireless interface.

• Wired—All devices connected through the Ethernet ports on the router.

• WDS—All Wireless Distribution System (WDS) devices connected to the

router .

IPv4 ARP Table displays information from other routers that have responded to the device’s Address Resolution Protocol (ARP) request. If a device does not respond to the request, it is removed from the list.

IPv6 NDP Table displays all IPv6 Neighbor Discovery Protocol (NDP) devices connected to the device’s local link.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 13

Viewing Device Status

Viewing Port Statistics

The Port Statistics page displays detailed port activity. To view port statistics, choose Status > Port Statistics. To refresh the page at regular intervals, choose a refresh rate from the Refresh

Rate drop-down list. To show the bytes in kilobytes (KB) and the numerical data in rounded-up form,

check the Show Simplified Statistic Data box and click Save. By default, byte data is displayed in bytes and other numerical data is displayed in long form.

To reset the port statistics counters, click Clear Count. The Port Statistics page displays this information:

Interface Name of the network interface. Packet Number of received/sent packets. Byte Number of received/sent bytes of information per second. Error Number of received/sent packet errors. Dropped Number of received/sent packets that were dropped. Multicast Number of multicast packets sent over this radio. Collisions Number of signal collisions that occurred on this port. A

collision occurs when the port tries to send data at the same time as a port on another router or computer that is connected to this port.

Viewing the Mobile Network Status

The mobile network statistics about the mobile 3G/4G network and communication device (dongle) configured on the device.

To view the mobile network status, choose Status > Mobile Network. The following information is displayed:

• Connection—Device connected to the guest network.

• Internet IP Address—IP address assigned to the USB device.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 14

Viewing Device Status

Viewing the Mobile Network Sta tus

• Subnet Mask—Subnet mask of the USB device.

• Default Ga teway—IP address of the default gateway.

• Connection Up Time—The length of time that link has been up.

• Current Session Usage—Volume of data being received (Rx) and

• Monthly Usage—Monthly data download and bandwidth usage.

• Manufacturer—Card manufacturer name.

• Car d Model—Card model number.

• Card Firmware—Card firmware version.

• SIM Status—Subscriber identification module (SIM) status.

transmitted (Tx) on the mobile link.

• IMS—The unique identification associated with the GSM, UMTS, or LTE

network mobile phone users.

• Carrier—Mobile network carrier.

• Service Type—Type of service accessed.

• Signal Strength—Strength of the wireless mobile network signal.

• Card Status—Status of the data card.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 15

Configuring Networking

Configuring Wired WAN Connections

Configuring WAN properties for an IPv4 network differs depending on which type of Internet connection you have.

Configuring DHCP (Automatic Configuration)

If your Internet Service Provider (ISP) uses Dynamic Host Control Protocol (DHCP) to assign you an IPaddress, you receive an IP address that is dynamically generated each time you log in.

To configure DHCP WAN settings:

STEP 1 Choose Networking > WAN. STEP 2 From the Internet Connection Type drop-down list, choose Automatic

Configuration - DHCP.

STEP 3 From the DNS Server Source drop-down list, choose one of the following ways to

set the DNS server address:

• If y ou alr eady have DNS server addresses from your ISP, choose Use these

DNS Servers, and enter the primary and secondary addresses.

• If you do not have DNS server addresses from your ISP, choose Get

Dynamically from ISP.

• To use the DNS servers provided by OpenDNS (208.67.222.222,

208.67.220.220) to resolve your web addresses, choose Use OpenDNS.

STEP 4 Click Save.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 16

Configuring Networking

STEP 1 Choose Networking > WAN. STEP 2 From the Internet Connection Type drop-down menu, choose Static IP. STEP 3 Enter this information:

Configuring Static IP

If your ISP assigned you a permanent IP address, perform the following steps to configure your WAN settings:

Internet IP Address IP address of the WA N port. Subnet mask Subnet mask of the WAN port. DNS Server Source The DNS server address. If you already have DNS

server addresses from your ISP, choose Use these DNS Servers, and enter the primary and secondary addresses in the Static DNS 1 and Static DNS 2 fields.

To use the DNS servers provided by OpenDNS (208.67.222.222, 208.67.220.220) to resolve your web addresses, choose Use OpenDNS.

Default Gateway IP address of the default gateway.

STEP 4 Click Save.

Configuring PPPoE

To configure the Point-to-Point Protocol over Ethernet (PPPoE) settings:

STEP 1 Choose Networking > WAN. STEP 2 From the Internet Connection Type drop-down menu, choose PPPoE. STEP 3 Select a PPPoE profile or click Configure Profile to create a new profile. STEP 4 On the PPPoE Profiles page, enter the following information (you might nee d to

contact your ISP to obtain your PPPoE login information):

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 17

Configuring Networking

Profile Name A unique name for the PPPoE profile.

Username The username assigned by the ISP. Password The password assigned by the ISP. DNS Server Source The DNS server address. If you already have DNS

server addresses from your ISP, choose Use these DNS Servers, and enter the primary and secondary addresses in the Static DNS 1 and Static DNS 2 fields.

To get DNS server addresses from your ISP, choose Get Dynamically from ISP.

To use the DNS servers provided by OpenDNS (208.67.222.222, 208.67.220.220) to resolve your web addresses, choose Use OpenDNS.

Connect on Demand Select this option if your ISP charges based on the

amount of time that you are connected. When you select this option, the Internet connection is on only when traffic is present. If the connection is idle— that is, no traffic is flowing—the conne ction is closed. If you click Connect on Demand, enter the number of minutes after which the connection shuts off in the Max Idle Time field.

Keep Alive When you select this option, the Internet

connection is always on. In the Redial Period field, enter the number of seconds after which the device attempts to reconnect if it is disconnected.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 18

Configuring Networking

Authentication Type Auto-negotiation—The server sends a

configuration request specifying the security algorithm set on it. The devic e then sends back authentication credentials with the security type sent by the server.

PAP—Password Authentication Protocol (PAP) used by Point-to-Point Protocol to connect to the ISP.

CHAP—Challenge Handshake Authentication Protocol (CHAP) requires that both the client and server know the plaintext of the secret to use ISP services.

MS-CHAP or MS-CHAPv2—The Microsoft version of CHAP used to access ISP services.

STEP 5 Click Save.

Configuring PPTP

To configure the PPTP settings:

STEP 1 Choose Networking > WAN. STEP 2 From the Internet Connection Type drop-down menu, choose PPTP. STEP 3 Enter this information:

Internet IP Address IP address of the WA N port. Subnet mask Subnet mask of the WAN port. Default Gateway IP address of the default gateway. PPTP Server IP address of the Point-To-Point Tunneling Protocol

server.

Username The username assigned to you by the ISP. Password The password assigned to you by the ISP.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 19

Configuring Networking

Connect on Demand Select this option if your ISP charges based on the

Keep Alive When you select this option, the Internet

connection is always on. In the Redial period field, enter the number of seconds after which the device attempts to reconnect, if it is disconnected.

Authentication Type Choose the authentication typ e:

Auto-negotiation—The server sends a

configuration request specifying the security algorithm set on it. The devic e then sends back authentication credentials with the security type sent earlier by the server.

PAP—The device uses the Password Authentication Protocol (PAP) to connect to the ISP.

CHAP—The device uses the Challenge Handshake Authentication Protocol (CHAP) when connecting with the ISP.

MS-CHAP or MS-CHAPv2—The device uses Microsoft Challenge Handshake Authentication Protocol when connecting with the ISP.

Service Name Enter a name for the new PPTP service. MPPE Encryption Check the Enable check box to enable Microsoft

Point-to-Point Encryption for the PPTP connection.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 20

Configuring Networking

STEP 4 Click Save.

DNS Server Source The DNS server address. If you already have DNS

server addresses from your ISP, choose Use these DNS Servers, and enter the primary and secondary addresses in the Static DNS 1 and Static DNS 2 fields.

To get DNS server addresses from your ISP, choose Get Dynamically from ISP.

To use the DNS servers provided by OpenDNS (208.67.222.222, 208.67.220.220) to resolve your web addresses, choose Use OpenDNS.

Configuring L2TP

To configure L2TP settings:

STEP 1 Choose Networking > WAN. STEP 2 From the Internet Connection Type drop-down menu, choose L2TP. STEP 3 Enter this information:

Internet IP Address The IP address of the WAN port. Subnet mask The subnet mask of the WAN port. Default Gateway The IP address of the default gateway. L2TP Server The IP address of the L2TP server. Version The L2TP version that you want to use. If you select

version 3, enter the vendor ID, and the virtual circuit ID.

Cookie Length The size of the cookie in the L2TP v3 data packet,

which identifies the L2TP session.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 21

Configuring Networking

Vendor I D The vendor ID contained in the AVP encoding

format for L2TP. To use the IETF-adopted attribute values in the A VP,

select Standard. To implement Cisco’s L2TP extensions and private

attribute values, select Cisco.

Virtual Circuit ID The identifier for the Layer 2 circuit over which

L2TP data packets are carried. This information is required if you selected Cisco as the Vendor ID for L2TP v3.

Username Enter your username assigned to you by the ISP. Password Enter your password assigned to you by the ISP. Connect on Demand Select this option if your ISP charges based on the

Keep Alive When you select this option, the Internet

connection is always on. In the redial period field, enter the number of seconds after which the device attempts to reconnect if it is disconnected.

Authentication Type Auto-negotiation—The server sends a

configuration request specifying the security algorithm set on it. The devic e then sends back authentication credentials with the security type sent by the server.

PAP—Password Authentication Protocol (PAP) is used to connect to the ISP.

CHAP—Challenge Handshake Authentication Protocol (CHAP) is used to connect to the ISP.

MS-CHAP or MS-CHAPv2—Microsoft Challenge Handshake Authentication Protocol is used to connect to the ISP.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 22

Configuring Networking

Service Name Enter a name for the new L2TP service. MPPE Encryption Check Enable to enable Microsoft Point-to-Point

Encryption for the L2TP connection.

DNS Server Source The DNS server address. If you already have DNS

server addresses from your ISP, choose Use these DNS Servers, and enter the primary and secondary addresses in the Static DNS 1 and Static DNS 2 fields.

To get DNS server addresses from your ISP, choose Get Dynamically from ISP.

To use the DNS servers provided by OpenDNS (208.67.222.222, 208.67.220.220) to resolve your web addresses, choose Use OpenDNS.

STEP 4 Click Save.

Configuring Optional Network Settings

To configure optional settings:

STEP 1 In the Optional Settings section, configure the f ollowing settings:

MTU Maximum transmission unit (MTU) is the size of the

largest packet that can be sent over the network. Unless a change is required by your ISP, we

recommend that you choose Auto. The default MTU size is 1500 bytes.

If your ISP requires a custom MTU setting, choose

Manual and enter the MTU size.

Size The custom MTU size. The standard MTU value for

Ethernet networks is usually 1500 bytes. For PPPoE connections, the value is 1492 bytes.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 23

Configuring Networking

Untagged VLAN Check the box to enable VLAN tagging. When

enabled (the default), all traffic is tagged with a VLAN ID.

By default, all traffic on the device uses VLAN 1, the default untagged VLAN. All traffic is untagged until you disable the untagged VLAN, change the untagged traffic VLAN ID, or change the VLAN ID.

Untagged VLAN ID A number between 1 and 4094 for the untagged

VLAN ID. The default is 1. Traffic on the VLAN that you specify in this field is not tagged with a VLAN ID when forwarded to the network.

VLAN 1 is the default untagged VLAN.

AP Management VLAN The VLAN associated with the IP address you use

to access the device when it is configured as an access point.

STEP 2 Click Save.

If you create additional VLANs, for security reasons, choose a value that corresponds with the VLAN configured on other switches in the network. You may need to change the management VLAN to limit access to Device Manager.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 24

Configuring Networking

Configuring a Mobile Network

Choose Networking > WAN > Mobile Network to configure to configure the device to connect to a Mobile Broadband USB modem that is connected to its USB interface.

Configuring Global Mobile Network Settings

To configure global settings for supported USB devices:

STEP 1 Connect the USB modem. If the modem is supported, it is automatically detected

and appears on the Mobile Network page.

STEP 2 Select Auto or Manual connection mode. Ethernet Connection Recovery works

only if the Connect Mode is set to Auto.

• To enable your modem to establish a connection automatically, select Auto

mode. If you select Auto, set a Connect on Demand time or select Keep Alive. Connect on Demand terminates the Internet connection after it is inactive for the period of time specified in the Max Idle Time field.

If your Internet connection is terminated due to inactivity, the modem automatically reestablishes a connection when a user attempts to acces s the Internet. In the Max Idle Time field, enter the number of minutes of idle time that can elapse before the Int ernet connection terminat es. Select Keep Alive to keep the connection active at all times.

• To connect or disconnect your modem connection manually, select Manual

mode.

The device displays the current modem connection status that includes initializing, connecting, disconnecting, or disconnected.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 25

Configuring Networking

Configuring a Mobile Network

STEP 3 Verify that the Card Status field shows your mobile card is Connected.

STEP 1 Enter information in the following fields:

Configuring Mobile Network Settings Manually

To change mobile netw ork parameters in the Mobile Network Setup area, click the Manual radio button. The device automatically detects supported modems and lists the appropriate configuration parameters. To override global parameters, select Manual.

Field Description

Access point Name (APN)

Dial Number Dial number provided by your mobile network service

Username Password

SIM Check SIM card check enable or disable. SIM PIN PIN code associated with your SIM card. This field is

Server Name Name of the server for the Internet connection (if

Authentication Authentication used by your service provider. The value

Internet network that the mobile device is connecting to. Enter the access point name provided by your mobile network service provider. If you do not know the name of the access p o int, contact your service provider.

provider for the Internet connection. User name and password provided by your mobile

network service provider.

only displayed for GSM SIM cards. You can modify the SIM PIN in either Auto or Manual

mode.

provided by your service provider).

can be changed by choosing the authentication type from the drop-down list. The default is Auto. If you do not know which type of authentication to use, select Auto.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 26

Configuring Networking

Configuring a Mobile Network

STEP 2 Click Save to save your settings

Field Description

Server Type The most commonly available type of mobile data

service connection based on your area service signal. If your location supports only one mobile data service, you can limit your pref err ed option, reducing connection setup times. The first selection always searches for HSPDA/3G/UMTS service and switches automatically to GPRS when it is available.

LTE Service L ong-term E volution (LTE) Service setting. Auto chooses

a signal based on the area service signal. 4G only searches for only 4G signals. 3G only searches for only 3G signals.

Bandwidth Cap Setting

The device monitors the data activity across the mobile network link and when it reaches a given threshold, sends a notification.

To enable or disable Bandwidth Cap Tracking and set the limits:

STEP 1 Click Enabled or Disabled. STEP 2 Select the Monthly Renewal Date fr om the dr op-down list to indicate which day of

the month the bandwidth cap is reset .

STEP 3 In the Monthly Bandwidth Cap field, enter the maximum amount of data in

megabytes that is allowed to pass before the device takes an action, such as sending an email to an administrator.

E-mail Setting

When the bandwidth data limit is reached, an email message can be sent to the administrator. To set up the target email address, see Configuring Log E-Mailing.

When enabled by checking the box, email is sent when:

• Mobile network usage has exc eeded a given percentage.

• The device fails over to the backup pathway and recovers.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 27

Configuring Networking

Configuring a Mobile Network

STEP 1 Choose Networking > WAN > Failover & Recovery, to display the Failover &

STEP 2 Select Enable Failover to 3G WAN to enable the mobile network link and set it to

• At every interval specified while a mobile network link is active.

Set t ing Failover and Recovery

While both Ethernet and mobile network links are available, only one connection can be used to establish a W AN link, at a time. When one W AN connection fails, the device attempts to establish a connection on another interface. This feature is called Failover. When the primary WAN connection is restored, it reverts to the original path and ends the backup connection. This feature is called Recovery.

Recovery window.

failover from the Ethernet link. When the Ethernet W AN link is not active, the device attempts to enable the mobile network link on the USB interface. (If failover is not enabled, the mobile network link is always disabled.)

STEP 3 Select Enable Recovery back to Ethernet WAN to enable the link to return to the

Ethernet link, dropping the mobile network link. The Connect Mode accessed through WAN > Mobile Network must be set to Auto to use Ethernet WAN connection recovery.

STEP 4 In the Failover Check Interval field, enter the fr equency (in seconds) with which the

device must attempt to detect the physical connection or presence of traffic on the mobile network link. If the link is idle, the device attempts to ping a destination at this interval. If there is no reply t o the ping pack et, the device assumes the link is down and retries the Ethernet WAN interface.

STEP 5 In the Recovery Check Interval field, enter the frequency (in seconds) with which

the device must attempt to detect the physical connection or presence of traffic on the Ethernet WAN link. If the link is idle, the device attempts to ping a destination at the interval. If there is a reply to the ping pa cket, the device assumes the link is up and attempts to disable the mobile network link and enable the Ethernet WAN link.

STEP 6 Click Switch back to Ethernet immediately when Ethernet is available or click

Switch back to Ethernet in a specific time range and enter the start and end time for the range.

STEP 7 In the Connection Validation Site field, choose the site from which to perform

failover validation. Use the next hop gateway (by default the device pings the default gateway) or choose a custom site and enter the site IPv4 or IPv6 address.

STEP 8 Click Save to save your settings.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 28

Configuring Networking

Configuring LAN Settings

The WAN Inter face table shows the status of the Ethernet WAN and mobile network link to the Internet. Click the Status hyper link to view the port detail.

Configuring LAN Settings

The default DHCP and TCP/IP settings work for most applications. If you want another PC on your network to be the DHCP server, or if you want to manually configure the network settings of all of your devices, disable DHCP.

Also, instead of using a DNS server that maps Internet domain names (for example, www.cisco.com) to IP addresses, you can use a Windows Internet Naming Service (WINS) ser ver. A WINS server is the equivalent of a DNS server, but uses the NetBIOS protocol to resolve hostnames. The device includes the IP address of the WINS server in the DHCP configuration the device sends to DHCP clients.

If your device is connected to a modem or to another device that has a configured network on the same subnet (192.168.1.x), it automatically changes the LAN subnet to a random subnet based on 10.x.x.x, so there is no conflict with the subnet on the WAN side of the router.

Changing the Device Management IP Address

The local device management IP address of the devic e is static and defaults to

192.168.1.1. To change the local device management IP address:

STEP 1 Choose Networking > LAN > LAN Configuration. STEP 2 In the IPv4 section, enter this information:

VLAN The VLAN number. Local IP Address Local LAN IP address of the device. Make sure this

IP address is not in use by another device.

Subnet mask Subnet mask for the local IP address. The default

subnet mask is 255.255.255.0.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 29

Configuring Networking

Configuring LAN Settings

STEP 3 Click Save.

After changing the IP address of your device, your PC is no longer able to display Device Manager.

To display

• If DHCP is configured on the device, release and renew your PC IP address.

• Manually assign an IP address to your PC. The address must be on the same

Open a new browser window and enter the new IP address of the device to reconnect.

Device Manager, do one of the following:

subnetwork as the device. For example, if you change the device IPaddress to 10.0.0 .1 , assign your PC an IP address in the range of 10.0.0.2 t o 10.0.0 .255.

Configuring DHCP Server

By default, the device functions as a DHCP server to the hosts on the wireless LAN (WLAN) or wired LAN. It assigns IP addresses, and provides DNS server addresses.

With DHCP enabled, the device assigns IP addresses to other network devices on the LAN from a pool of IPv4 addresses. The device tests each address before it is assigned to avoid duplicate addresses on the LAN.

The default IP address pool is 192.168.1.100 to 192.168.1.149. To set a static IP address on a network device, use an IP address outside the po ol. For example, assuming that the DHCP pool is set to the default parameters, static IP addresses from 192.168.1.2 to 192.168.1.99 in the IP address pool can be used to prevent conflicts with the DHCP IP address pool.

To configure DHCP settings:

STEP 1 Choose Networking > LAN > LAN Configuration. STEP 2 (Optional) Select a VLAN to edit from the drop-down list. STEP 3 In the DHCP Server field, select one of the following options:

Enable Allows the device to act as the DHCP server in the network.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 30

Configuring Networking

Configuring LAN Settings

Disable Disables DHCP on the device when you want to manually

configure the IP addresses of all of your network devices.

DHCP Relay Relays the IPaddresses assigned by another DHCP server to

the network devices .

If you enabled the device DHCP server, enter this information:

Starting IP Addre ss The first address in the IP address pool. Any DHCP

client joining the LAN is assigne d an IP address in this range.

Maximum Number of DHCP Users

IP Address Range (Read-only) The range of IP addresses available to

Client Lease time Duration (in hours) that IP addresses are leased to

Static DNS 1 IP address of the primary DNS server. Static DNS 2 IP address of the secondary DNS server. Static DNS 3 IP address of the tertiary DNS server. WINS IP address of the primary WINS server.

STEP 4 If you selected DHCP Relay , ent er the addr ess of the relay gat ewa y in the Remote

DHCP Server field. The relay gateway transmits DHCP messages to network

device, including those on other subnetworks.

STEP 5 Click Save.

The maximum number of DHCP clients.

the DHCP clients.

clients.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 31

Configuring Networking

Configuring LAN Settings

STEP 1 Choose Networking > LAN > VLAN Membership. STEP 2 Click Add Row. STEP 3 Enter the following information:

Configuring VLANs

A virtual LAN (VLAN) is a group of endpoints in a network that are associated by function or other shared characteristics. Unlike LANs that are typically geographically based, VLANs can group endpoints without regard to the physical location of the equipment or users.

The device has a default VLAN (VLAN 1) that cannot be deleted. You can create up to four other VLANs on the device.

To create a VLAN:

VLAN ID Numerical VLAN ID to assign to endpoints in the VLAN

membership. The number you enter must be between 3 to 4094. VLAN ID 1 is reserved for the default VLAN, and is used for untagged frames received on the interface.

Description A description that identifies the VLAN. Port 1

Port 2 Port 3 Port 4

You can associate VLANS on the device to the LAN ports on the device. By default, all LAN ports belong to VLAN1. You can edit these ports to associate them with other VLANS. Choose the outgoing frame type for each port:

Untagged—The interface is an untagged member of the VLAN. Frames of the VLAN are sent untagged to the port VLAN.

Tagged—The port is a tagged member of the VLAN. Frames of the VLAN are sent tagged to the port VLAN.

Excluded—The port is currently not a member of the VLAN. This is the default for all the ports when the VLAN is first created.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 32

Configuring Networking

Configuring LAN Settings

STEP 4 Click Save.

STEP 1 Choose Networking > LAN > Static DHCP. STEP 2 From the VLAN drop-down menu, choose a VLAN number.

To edit the settings of a VLAN, select the VLAN and click Edit. To delete a select ed VLAN, click Delete. Click Save to apply changes.

Configuring Static DHCP

You can configure your router to assign a specific IP address to a client device with a specific MAC address.

To configure static DHCP:

STEP 3 Click Add Row. STEP 4 Enter the following information:

Description Description of the client. IP Address IP address you want assigned to the client device. The IP

address assigned should be outside the pool of the DHCP addresses.

Static DHCP assignment means the DHCP server assigns the same IP address to a defined MAC address every time the client device is connected to the network.

The DHCP server assigns the reserved IP address when the client device using the corresponding MAC address requests an IP address.

MAC Address MAC address of the client device.

The format for a MAC address is XX:XX:XX:XX:XX:XX where X is a number from 0 to 9 (inclusive) or a letter between A and F (inclusive).

To edit the settings of a static DHCP client, select the client and click Edit. To delete a selected DHCP client, click Delete. Click Save to apply the changes.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 33

Configuring Networking

Configuring LAN Settings

STEP 1 In the row of the connected device, check Add to Static DHCP. STEP 2 Click Save.

Viewing DHCP Leased Clients

You can view a list of endpoints on the network (identified by hostname, IP address, or MAC address) and see the IP addresses assigned to them by the DHCP server. The VLAN of the endpoints is also displayed.

To view the DHCP clients, choose Networking > LAN > DHCP Leased Client. For every VLAN defined on the device, a table displays a list of the clients

associated with the VLAN. To as sign a static IP address to one of the connected devices:

The DHCP server on the device always assigns the IP address shown when the device requests an IP address.

Configuring a DMZ Host

Your device supports demilitarized zones (DMZ). A DMZ is a subnetwork that is open to the public but behind the firewall. A DMZ allows you to redirect packets going to your WAN port IP address to a particular IP address in your LAN.

We recommended that you place hosts that must be exposed to the W AN ( such as web or e-mail servers) in the DMZ network. You can configure firewall rules to allow access to specific services and ports in the DMZ from both the LAN or W AN. In the event of an attack on any of the DMZ nodes, the LAN is not necessarily vulnerable.

You must configure a fixed (static) IP address for the endpoint that you designate as the DMZ host. You should assign the DMZ host an IP address in the same subnet as the device LAN IP address, but it cannot be identical to the IP address given to the LAN interface of this gateway.

To configure DMZ:

STEP 1 Choose Networking > LAN > DMZ Host. STEP 2 Check Enable to enable DMZ on the network.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 34

Configuring Networking

Configuring LAN Settings

STEP 3 From the VLAN drop-down menu, choose the ID of the VLAN where DMZ is

STEP 4 In the Host IP Address field, enter the IP address of the DMZ host. The DMZ host

STEP 5 Click Save.

enabled.

is the endpoint that receives the redirected packets.

Configuring RSTP

Rapid Spanning Tree Protocol (RSTP) is a network protocol that prevents loops in the network and dynamically reconfigures which physical links should forward frames. To configure Rapid Spanning Tree Protocol (RTSP):

STEP 1 Choose Networking > LAN > RSTP. STEP 2 Enter the following information:

System Priority Choose the system priority from the drop-down

menu. You can choose from a system priority from 0 to 61440 in increments of 4096. Valid values are 0, 4096, 8192, 12288, 16384, 20480, 24576, 28672, 32768, 40960, 45056, 49152, 53248, 57344, and 61440.

The lower the system priority, the more likely the device is to become the root in the spanning tree. The default is 327688.

Hello Time The hello time is the ti me period that the r oot of the

spanning tree waits before sending hello messages. Enter a number from 1 to 10 . The default is 2.

Max Age The max age is the time period that the router waits

to receive a hello message. If the max age is reached, the router tries to change the spanning tree. Enter a number from 6 to 40. The default is 20.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 35

Configuring Networking

Configuring LAN Settings

STEP 3 In the Setting Table, configure the following settings:

Forward Delay The forward delay is the interval after which an

interface changes from the blocking to forwarding state. Enter a number from 4 to 30. The default is

15.

Force Version Select the default protocol version to use. Select

Normal (use RSTP) or Compatible (compatible with old STP). The default is Normal.

Protocol Enable Check to enable RSTP on the associated port.

RSTP is disabled by default.

Edge Check to specify that the associated port is an

edge port (end station). Uncheck to specify that the associated por t is a link (bridge) to another STP device. Edge port is enabled by default.

Path Cost Enter the RSTP path cost for the designated ports.

Use 0 for the default value (the device automatically determines the path value). You can also enter a number from 2 to 200000000.

STEP 4 Click Save.

Port Management

You can configure the speed and flow control settings of the device LAN por ts. To configure port speeds and flow control:

STEP 1 Choose Networking > Port Management . STEP 2 Configure this information:

Port The port number.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 36

Configuring Networking

Configuring LAN Settings

Link The port speed. If no device is connected to the

port, this field displays Down.

Mode Choose from the drop-down menu one of the

following port speeds:

• Auto Negotiation—The device and the

connect ed device choose a common speed.

• 10Mbps Half—10 Mbps in both directions,

but only one direction at a time.

• 10Mbps Full—10 Mbps in both directions

simultaneously.

• 100Mbps Half—100 Mbps in both

directions, but only one direction at a time.

Jumbo Frame Check to enable jumbo frames on the device and

Flow Control Check to enable flow control for this port.

STEP 3 Click Save.

• 100Mbps Full—100 Mbps in both

directions simultaneously.

send frames within the LAN containing up to 9,000 bytes of data per frame. A standard Ethernet frame contains 1,500 bytes of data.

Flow control is the process of managing the rate of data transmission between two nodes to prevent a fast sender from outrunning a slow receiver. It provides a mechanism for the receiver to control the transmission speed, so that the receiving node is not overwhelmed with data from the transmitting node.

Configuring Link Aggregation

Use the Link Aggregation page to group multiple Ethernet links into a single logical channel. Link aggregation groups improve the cost effectiveness of your device by increasing cumulative bandwidth without requiring hardware upgrades, and facilitates easy rerouting in case of a single port or cable failure.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 37

Configuring Networking

Cloning the MAC Address

To assign ports to link aggregation group:

STEP 1 Choose Networking > LAN > Link Aggregation. The Port Status section displays

the mode associated with each port on the device and the status.

STEP 2 In the Link Aggregation Setting Table section, check the check box for each port to

include it in the group.

STEP 3 Click Save.

Cloning the MAC Address

Sometimes, you might need to set the MAC address of the device W A N port to be the same MAC address as your PC or some other MAC address. This is called MAC address cloning.

For example, some ISPs register your computer card MAC address when the service is first installed. When you place a router behind the cable modem or DSL modem, the MAC address from the device WAN port is not recognized by the ISP.

In this case, to configure your device to be recognized by the ISP, you can clone the MAC address of the WAN port to be the same as your computer MAC address.

To configure a MAC address clone:

STEP 1 Choose Networking > MAC Address Clone. STEP 2 In the MAC Address Clone field, check Enable. STEP 3 To set the MAC address of the device WAN port, do one of the following:

• To set the MAC address of the WA N port to your PC MAC address, click

Clone My PC’s MAC.

• To specify a different MAC address, enter it in the MAC Address field.

STEP 4 Click Save.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 38

Configuring Networking

Configuring Routing

Use the Routing page to configure the operating mode and other routing options for your d evice.

Configuring the Operating Mode

To configure the operating mode:

STEP 1 Choose Networking > Routing. STEP 2 In the Operating Mode field, select one of the following options:

Gateway To set the device to act as a gateway.

(Recommended)

Router (For advanced users only) To set the devic e to act

STEP 3 Click Save.

Configuring Dynamic Routing

Routing Information Protocol (RIP) is an Interior Gateway Protocol (IGP) that is commonly used in internal networks. It allows the router to exchange its routing information automatically with other routers, and allows it to dynamica lly adjust its routing tables and adapt to changes in the network.

Keep this default setting if the device is hosting your network connection to the Internet and is performing routing functions.

as a router. Select this option if the device is on a network with

other routers. Enabling the Router mode disables NAT (Network

Address Translation) on the device.

Dynamic Routing (RIP) enables the device to automatically adjus t to physical changes in the network layout and exchange routing tables with the other routers.

The router determines the network packets’ route based on the fewest number of hops between the source and the destination.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 39

Configuring Networking

Configuring Routing

NOTE RIP is disabled by default on the device.

STEP 1 Choose Networking > Routing. STEP 2 Configure the following settings:

To configure dynamic routing:

RIP Check Enable to enable RIP. This allows the device

to use RIP to route traffic.

RIP Send Packet Version Select the RIP Send Packet Version (RIPv1 or

RIPv2).

The version of RIP used to send routing updates to other routers on the network depends on the configuration settings of the other routers. RIPv2 is backward compatible with RIPv1.

RIP Recv Packet Version Choose the RIP Receive Packet Version.

STEP 3 Click Save.

Configuring Inter VLAN Routing

To allow an end station in one VLAN to communicate with an end station in another VLAN, check the Inter VLAN Routing Enable check box.

Configuring Static Routing

You can configure static routes to direct packets to the destination network. A static route is a predetermined pathway that a packet must travel to reach a specific host or network.

Some ISPs require static routes to build your routing table instead of using dynamic routing protocols. Static routes do not require CPU resources to exchange routing information with a peer router.

You can also use static routes to reach peer routers that do not support dynamic routing protocols. Static routes can be used together with dynamic routes. The device supports up to 30 static routes.

Be careful not to introduce routing loops in your network.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 40

Configuring Networking

Viewing the Routing Table

STEP 1 Choose Networking > Routing. STEP 2 From the Route Entries drop-down menu, choose a route entry.

STEP 3 Configure the following settings for the selected route entry:

To configure static routing:

To delete the route entry, click Delete This Entry.

Enter Route Name Enter the name of the route. Destination LAN IP Enter the IP address of the destination LAN. Subnet Mask Enter the subnet mask of the destination network. Gateway Enter the IP address of the gateway used for this

Interface Select the interface to which packets for this route

STEP 4 Click Save.

Viewing the Routing Table

The routing table contains information about the topology of the network immediately around it.

route.

are sent:

• LAN & Wireless—Click this button to dir ect pack ets to the LAN and wireless network.

• Internet (WAN)—Click this button to direct packets to the Internet (WAN).

To view the routing information on your network, choose Networking > Routing Table and choose one of the following:

• Show IPv4 Routing Table—The routing table is displayed with the fields

configured in the Networking > Routing page.

• Show IPv6 Routing Table—The routing table is displayed with the fields

configured in the Networking > IPv6 page.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 41

Configuring Networking

Configuring Dynamic DNS

Dynamic DNS (DDNS) is an Internet service that allows routers with varying public IP addresses to be located using Internet domain names. To use DDNS, you must set up an account with a DDNS provider such as DynDNS.com, TZ O.com,

3322.org, or noip.com. The router notifies dynamic DNS servers of changes in the WAN IP address, so

that any public services on your network can be accessed by using the domain name.

To configure DDNS:

STEP 1 Choose Networking > Dynamic DNS. STEP 2 The DDNS Service Table section lists the DDNS s e rvices that you can enable on

the device.

STEP 3 Check the check box for the service you want to enable and click Edit. STEP 4 Check the Enable check box for the service. STEP 5 Configure this information:

Username/E-mail Address

Password Password of the DDNS account. Host / Domain Name Hostname of the DDNS server or the name of the

Internet IP Address (Read-only) Internet IP address of your device. Status (Read-only) Indicates that the DDNS update has

STEP 6 Click Te st Configuration, to test the DDNS configuration.

The username of the DDNS account or the e-mail address that you used to create the DDNS account.

domain that is used to access the network

completed successfully or the a ccount update information sent to the DDNS server failed.

STEP 7 Click Save.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 42

Configuring Networking

Configuring the IP Mode

Wide area network configuration properties are configurable for both IPv4 and IPv6 networks. You can enter information about your Internet connection type and other parameters in these pages.

To select an IP mode:

STEP 1 Choose Networking > IP Mode. STEP 2 From the IP Mode drop-down menu, choose one of the following options:

LAN:IPv4, WAN:IPv4 To use IPv4 on the LAN and WAN ports.

LAN:IPv6, WAN:IPv4 To use IPv6 on the LAN ports and IPv4 on the WAN

ports.

LAN:IPv6, WAN:IPv6 To use IP v6 on the LAN and WAN ports. LAN:IPv4+IPv6,

WAN:IPv4 LAN:IPv4+IPV6,

WAN:IPv4+IPv6 LAN:IPv4, WAN:IPv6 To use IPv4 on the LAN and IPv6 on the WAN ports.

STEP 3 (Optional) If you are using 6to4 tunneling, which allows IPv6 packets to be

transmitted over an IPv4 network, do the following: a. Click Show Static 6to4 DNS Entry. b. In the Domain and IP fields, enter up to five domain-to-IP mappings. The 6to4 tunneling featur e is typically used when a site or end user wants to

connect to the IPv6 Internet using the existing IPv4 network.

STEP 4 Click Save.

To use IPv4 and IPv6 on the LAN ports and IPv4 on the WAN ports.

To use IPv4 and IPv6 on both the LAN and WAN ports.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 43

Configuring Networking

Configuring IPv6

Internet Protocol version 6 (IPv6) is a version of the Internet Protocol (IP) intended to succeed Internet Protocol version 4 (IPv4). Configuring WAN proper ties for an IPv6 network depends on the type of internet connection that you have.

Configuring the IPV6 WAN Connection

You can configure your device to be a DHCPv6 client of the ISP for this WAN or to use a static IPv6 address provided by the ISP.

To configure IPv6 WAN settings on your device, you must first set the IP mode to one of the following modes:

• LAN:IPv6, WAN:IPv6

• LAN:IPv4+IPv6, WAN:IPv4

• LAN:IPv4+IPv6, WAN:IPv4+IPv6

See Configuring the IP Mode for instructions on how to set the IP mode.

Configuring SLAAC

To self-assign an address based on the IPv6 prefix, configure the device to use use Stateless Address Auto-Configuration (SLAAC) for IPv6 client address assignment.

To use SLA AC:

STEP 1 Choose Networking > IPv6 > IPv6 WAN Configuration. STEP 2 In the WAN Connection Type field, select SLAAC. For stateless DHCP, it is not

necessary to have a DHCPv6 server available at the ISP. Instead, an ICMPv6 discover message originating from your device is used for auto-configuration.

STEP 3 Click Save.

Configuring DHCPv6

If your ISP provides you with a dynamically assigned address, configure the device to be a DHCPv6 client.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 44

Configuring Networking

Configuring IPv6

STEP 1 Choose Networking > IPv6 > IPv6 WAN Configuration. STEP 2 In the WAN Connection Type field, select Automatic Configuration-DHCPv6.

STEP 3 To automate assigning prefixes to your device (the DHCP client), select the Prefix

STEP 4 Click Save.

To configure the device to be a DHCPv6 client:

The gateway connects to the ISP's DHCPv6 server for a leased address.

Delegation Enable radio button.

Configuring a Static IPv6 WAN Address

If your ISP assigns you a fixed address to access the WAN, configure the device to use a static IPv6 address.

To configure a static IPv6 WAN address:

STEP 1 Choose Networking > IPv6 > IPv6 WAN Configuration. STEP 2 From the WAN Connection Type menu, select Static IPv6. STEP 3 Enter this information:

IPv6 Address IPv6 address of the WAN port. IPv 6 Pre f ix Length Length of the IPv6 prefix (typically defined by the

ISP). The IPv6 network (subnet) is identified by the initial bits of the address called the prefix. All hosts in the subnetwork have the identical prefix.

For example, in the IPv6 address 2001:0DB8:AC10:FE01::, the prefix is 2001.

Default IPv6 Gateway IPv6 address of the default gateway. This is

typically the IP address of the server at the ISP.

Static DNS 1 IP address of the primary IPv6 DNS server. Static DNS 2 IP address of the secondary IPv6 DNS ser ver.

STEP 4 Click Save.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 45

Configuring Networking

Configuring IPv6

STEP 1 Choose Networking > IPv6 > IPv6 WAN Configuration. STEP 2 In the WAN Connection Type field, choose PPPoE IPv6. STEP 3 Enter the fo llowing inf ormation (it might be necessary to contact your ISP to obtain

Configuring PPPoE IPv6 Settings

You can run IPv4 PPPoE, IPv6 PPPoE, or both. If you run both, your IPv6 WAN PPPoE settings must match your IPv4 WAN PPPoE settings. If they do not match, a message is displayed asking if you want to set the IPv6 protocol to match the IPv4 protocol. See Configuring PPPoE.

To configure the PPPoE IPv6 settings:

your PPPoE login information):

Username Username assigned to you by the ISP. Password Password assigned to you by the ISP. Connect on Demand If your ISP charges based on the amount of time

that you are connected, select the radio button. When selected, the Internet connection is active only when traffic is present. If the conne ction is idle—that is, no traffic is flowing—the connection is closed. In the Max Idle Time field, enter the number of minutes that must elapse with no traffic detected on the link before the link is shut down.

Keep Alive Keeps the WAN link up by sending a keep-alive

message through the port. In the redial period field, enter the number of seconds after which the device attempts to reconnect if it is disconnected.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 46

Configuring Networking

Configuring IPv6

Authentication Type Authentication types:

Auto-negotiation—A server sends a configuration

request specifying the security algorithm set on the server. The device replies with its authentication credentials, including the security type sent by the server.

PAP—Use the Password Authentication Protocol (PAP) to connect to the ISP.

CHAP—Use Challenge Handshake Authentication Protocol (CHAP) to connect with the ISP.

MS-CHAP or MS-CHAPv2—Use Microsoft Challenge Handshake Authentication Protocol to connect to the ISP.

Service Name Name that your ISP might require to log onto the

PPPoE server.

MTU Maximum transmission unit is the size of the largest

packet that can be sent over the network. Unless a change is required by your ISP, we

recommend that you choose Auto. The standard MTU value for Ethernet networks is 1500 bytes. For PPPoE connections, the value is 1492 bytes. If your ISP requires a custom MTU setting, choose

Manual.

Size MTU size. If your ISP requires a custom MTU

setting, enter the MTU size.

Address Mode Dynamic or static address mode. If you choose

static, enter the IPv6 address in the next field.

IPv 6 Pre f ix Length IPv6 prefix length. Default IPv6 Gateway IP address of the default IPv6 gateway. Static DNS 1 IP address of the primary DNS server. Static DNS 2 IP address of the secondary DNS server.

STEP 4 Click Save.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 47

Configuring Networking

Configuring IPv6

Configuring IPv6 LAN Connections

In the IPv6 mode, the LAN DHCP server is enabled by default (similar to the IPv4 mode). The DHCPv6 server assigns IPv6 addresses from configured address pools that use the IPv6 prefix length assigned to the LAN.

To configure IPv6 LAN settings on your device, you must first set the IP mode to one of the following modes:

• LAN:IPv6, WAN:IPv4

• LAN:IPv6, WAN:IPv6

• LAN:IPv4+IPv6, WAN:IPv4

• LAN:IPv4+IPv6, WAN:IPv4+IPv6

See Configuring the IP Mode for more information on how to set the IP mode. To configure IPv6 LAN settings:

STEP 1 Choose Networking > IPv6 > IPv6 LAN Configuration. STEP 2 Enter the following information to configure the IPv6 LAN address:

IPv6 Address Enter the IPv6 address of the device.

The default IPv6 address for the ga teway is f ec0::1 (or FEC0:0000:0000:0000:0000:0000:0000:0001). Y o u can change this 128-bit IPv6 address based on your network requirements.

IPv 6 Pre f ix Length Enter the IPv6 prefix length.

The IPv6 network (subnet) is identified by the initial bits of the address called the prefix. By default, the prefix is 64 bits long.

All hosts in the network have the identical initial bits for their IPv6 address; you set the number of common initial bits in the network addresses in this field.

STEP 3 Click Save or continue to configure IPv6 DHCP LAN sett ings. STEP 4 Enter the following information to configure the DHCPv6 settings:

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 48

Configuring Networking

Configuring IPv6

DHCP Status Check to enable the DHCPv6 server.

When enabled, the device assigns an IP address within a specified range and provides additional information to any LAN endpoint that requests DHCP addresses.

Domain Name (Optional) Domain name of the DHCPv6 server. Serv er Pre ferenc e Server preference level of this DHCP server. DHCP

advertise messages with the highest server preference value to a LAN host are preferred over other DHCP server advertise messages.

The default is 255.

Static DNS 1 IPv6 address of the primary DNS server on the ISP

IPv6 network.

Static DNS 2 IPv6 address of the secondary DNS server on the

ISP IPv6 network.

Client Lease Time Client lease time duration (in seconds) for which

IPv6 addresses are leased to endpoints on the LAN.

STEP 5 Choose Networking > IPv6 > IPv6 LAN Configuration. STEP 6 In the IPv 6 Address Pools Table, click Add Row. STEP 7 Enter this information:

Start Address Starting IPv6 address of the pool. End Address Ending IPv6 address of the pool. IPv 6 Pre f ix Length Prefix length that determines the number of

common initial bits in the network addresse s.

STEP 8 Click Save.

To edit the settings of a pool, select the pool and click Edit. To delete a selected pool, click Delete. Click Save to apply changes.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 49

Configuring Networking

Configuring IPv6

STEP 1 Choose Networking > IPv6 > IPv6 Static Routing.

Configuring IPv6 Static Routing

You can configure static routes to direct packets to the destination network. A static route is a predetermined pathway that a packet must travel to reach a specific host or network.

Some ISPs require static routes to build a routing table instead of using dynamic routing protocols. Static routes do not require CPU resources to exchange routing information with a peer router.

You can also use static routes to reach peer routers that do not support dynamic routing protocols. Static routes can be used together with dynamic routes. Be careful not to introduce routing loops in your network.

To create a static route:

STEP 2 In the list of static routes, click Add Row. STEP 3 Enter this information:

Name Route name. Destination IPv6 address of the destination host or network for

this route.

Prefix Length Number of prefix bits in the IPv6 address that define

the destination subnet.

Gateway IPv6 address of the gateway through which the

destination host or network can be reached.

Interface Interface for the route: LAN, WAN, or 6to4. Metric Priority of the route. Choose a value between 2 and 15.

If multiple routes to the same destination exist, the route with the lowest metric is used.

Active Check to make the route active. When you add a route

in an inactive state, it is listed in the routing table, but is not used by the device.

Entering an inactive route is useful if the route is not available when you add the route. When the network becomes available, you can enable the route.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 50

Configuring Networking

Configuring IPv6

STEP 4 Click Save.

To edit the settings of a route, select the route and click Edit. To delete a selected route, click Delete. Click Save to apply changes.

Configuring Routing (RIPng)

RIP Next Generation (RIPng) is a routing protocol based on the distance vector (D-V) algorithm. RIPng uses UDP packets to exchange routing information through port 521.

RIPng uses a hop count to measure the distance to a destination. The hop count is referred to as metric, or cost. The hop count from a router to a directly connected network is 0. The hop count between two directly connected routers is 1. When the hop count is greater than or equal to 16, the destination network or host is unreachable.

By default, the routing update is sent every 30 seconds. If the router receives no routing updates from a neighbor after 180 seconds, the routes learned from the neighbor are considered as unreachable. After another 240 seconds, if no routing update is received, the router removes these routes from the routing table.

On your device, RIPng is disabled by default. To configure RIPng:

STEP 1 Choose Networking > IPv6 > Routing (RIPng). STEP 2 Check Enable. STEP 3 Click Save.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 51

Configuring Networking

Configuring IPv6

STEP 1 Select Networking > IPv6 > Tunneling. STEP 2 In the 6 to 4 Tunneling field, check Enable. STEP 3 Choose the type of tunneling:

Configuring Tunneling

IPv6-to-IPv4 tunneling (6-to-4 tunneling) allows IPv6 packets to be transmitted over an IPv4 network. IPv4 to IPv6 tunneling (4-t o-6 tunneling) allows IPv4 packets to be transmitted over an IPv6 network.

6 to 4 Tunneling

6-to-4 tunneling is typically used when a site or end user wants to connect to the IPv6 Internet using the existing IPv4 network.

To configure 6-to-4 tunneling:

• 6to4

• 6RD (Rapid Deployment)

• ISATAP (Intra-Site Automatic Tunnel Addressing Protocol) - Choose Auto or

Manual.

STEP 4 For 6RD Tunneling, cho ose Auto or Manual. If you choose Manual, enter the

following information:

• IPv6 Prefix

• IPv6 Prefix Length

• Border Relay

• IPv4 Mask Length

STEP 5 For ISATAP Tunneling, choose Auto or Manual. If you choose Manual, enter the

following information:

• IPv6 Prefix

• IPv6 Prefix Length

STEP 6 Click Save.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 52

Configuring Networking

Configuring IPv6

STEP 1 Select Networking > IPv6 > Tunneling. STEP 2 In the 4 to 6 Tunneling field, check the Enable box. STEP 3 Enter the local WAN IPv6 address on the device. STEP 4 Enter the remote IPv6 address, or the IP address of the remote endpoint. STEP 5 Click Save.

4 to 6 Tunneling

To configure 4-to-6 tunneling:

Viewing IPv6 Tunnel Status

To view IPv6 tunnel status:

STEP 1 Choose Networking > IPv6 > IPv6 Tunnels Status. STEP 2 Click Refresh to display the most up-to-date information.

This page displays information about the automatic tunnel set up through the dedicated WAN interface. The table shows the name of tunnel and the IPv6 address that is created on the device.

Configuring Router Advertisement

The Router Advertisement Daemon (RADVD) on the device listens for router solicitations in the IPv6 LAN and responds with router advertisements as required. This is stateless IPv6 auto-configuration, and the device distributes IPv6 prefixes to all nodes on the network.

To configure the RADVD:

STEP 1 Choose Networking > IPv6 > Router Advertisement. STEP 2 Enter this information:

RADVD Status Check Enable to enable RADVD.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 53

Configuring Networking

Configuring IPv6

Advertise Mode Select one of the following modes:

Unsolicited Multicast—Send Router

Advertisements (RAs) to all interfaces belonging to the multicast group.

Unicast only—Restrict advertisements to well-known IPv6 addresse s only (RAs are sent to the interface belonging to the known address only).

Advertise Interval Advertise interval (4–1800) for the Unsolicited

Multicast. The default is 30. The advertise interval

is a random value between the Minimum Router Advertisement Interval (MinRtrAdvInterval) and Maximum Router Advertisement Interval (MaxRtrAdvInterval).

MinRtrAdvInterval = 0.33 * MaxRtrAdvInterval

RA Flags Check Managed to use the administered/stateful

protocol for address auto configuration. Check Other to use the administered/stateful

protocol of other, non-address information auto configuration.

Router Preference Choose low, medium, or high from the drop-down

menu. The default is medium. The router preference provides a preference

metric for default routers. The low, medium, and high values are signaled in unused bits in RA messages. This extension is backward compatible, both for routers (setting the router preference value) and hosts (interpreting the router preference value). These values are ignored by hosts that do not implement router preference. This feature is useful if there are other RADVD-enabled devices on the LAN.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 54

Configuring Networking

Configuring IPv6

STEP 3 Click Save.

MTU MTU size (0 or 1280 to 1500). The default is 1500

bytes. The maximum transmission unit (MTU) is the size of

the largest packet that can be sent over the network. The MTU is used in RAs to ensure all nodes on the network use the same MTU value when the LAN MTU is not well-known.

Router Life Time Router lifetime value or the time in seconds that the

advertisement messages exists on the route. The default is 3600 seconds.

Configuring Advertisement Prefixes

To configure the RADVD available prefixes:

STEP 1 Choose Networking > IPv6 > Advertisement Prefixes. STEP 2 Click Add Row. STEP 3 Enter this information:

IPv 6 Pre fix Type Choose one of the following types:

6to4—Allows IPv6 packets to be transmitted over

an IPv4 network. It is used when an end user wants to connect to the IPv6 Internet using their existing IPv4 connection

Global/Local—A locally unique IPv6 address that you can use in private IPv6 networks or a globally unique IPv6 Internet address.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 55

Configuring Networking

Configuring IPv6

SLA ID If you choose 6to4 as the IPv6 prefix type, enter

the Site-Level Aggregation Identifier (SLA ID). The SLA ID in the 6to4 address prefix is set to the

interface ID of the interface on which the advertisements are sent.

IPv6 Prefix If you choose Global/Local as the IPv6 prefix type,

enter the IPv6 prefix. The IPv6 prefix specifies the IPv6 network address.

IPv 6 Pre f ix Length If you choose Global/Local as the IPv6 prefix type,

enter the prefix length. The prefix length variable is a decimal value that indicates the number of contiguous, higher-order bits of the address that make up the network portion of the address.

Prefix Lifetime Prefix lifetime, or the length of time over which the

STEP 4 Click Save.

requesting router is allowed to use the prefix.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 56

Configuring Wireless Networks

• Detecting Rogue Access Points, page 70

• Configuring Captive Portal, page75

• Config uring Device Mode, page 78

Wireless Security

Wireless networks are convenient and easy to install. Because wireless networking operates by sending information over radio waves, it can be more vulnerable to intruders than a traditional wired network .

Wireless Security Tips

You cannot physically prevent someone from connecting to your wireless network, but you can take the following steps to keep your network secure:

• Change the default wireless network name or SSID.

Wireless devices have a def a ult wireless network name or SSID. This is the name of your wireless network, and can be up to 32 characters in length.

To protect your network, change the default wireless network name to a unique name to distinguish your wireless network from other wireless networks that may exist around you.

When choosing names, do not use p e rsonal information because this information may be available for anyone to see when browsing for wireless networks.

• Change the default password.

For wireless products such as access points, routers, and gateways, you are asked for a password when you want to change their settings. These devices have a default password. The default password is often cisco.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 57

Configuring Wireless Networks

Wireless Security

• Enable MAC address filtering.

• Enable encryption.

Hackers know these default values and may try to use them to access your wireless device and change your network settings. To prevent unauthorized access, customize the device password so that it is difficult to guess.

Cisco routers and gateways give you the ability to enable MAC address filtering. The MAC address is a unique series of numbers and letters assigned to every networking device.

With MAC address filtering enabled, wireless network access is provided solely for wireless devices with specific MAC addresses. For example, you can specify the MAC address of each computer in your network so that only those computers can access your wireless network.

Encryption protects data transmitted over a wireless network. Wi-Fi Protect ed Access (WP A/WP A2) and Wir ed Equivalency Privacy (WEP) offer different levels of security for wireless communication. Currently, devices that are Wi-Fi certified are required to support WPA2, but are not required to support WEP.

A network encrypted with WPA/WPA2 is more secure than a network encrypted with WEP, because WPA/WPA2 uses dynamic key encryption.

To protect the information as it passes over the airwaves, enable the highest level of encryption supported by your network equipment.

WEP is an older encryption standard and may be the only option available on some older devices that do not support WPA.

• Keep wireless routers, access points, or gateways away fr om exterior walls

and windows.

• Turn wireless routers, access points, or gateways off when they are not

being used (at night, during vacations).

• Use strong passphrases that are at least eight characters in length.

Combine letters and numbers to avoid using standard words that can be found in the dictionary.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 58

Configuring Wireless Networks

Wireless Networks on Your Device

General Network Security Guidelines

Wireless network security is useless if the underlying network is not secure. We recommend that you take the following precautions:

• Password-protect all computers on the network and individually password-

protect sensitive files.

• Change passwords on a regular basis.

• Install anti-virus software and personal firewall software.

• Disable file sharing (peer-to-peer) to prevent applications from using file

sharing without your consent.

Wireless Networks on Your Device

Your device provides four virtual wireless networks, or four SSIDs (Service Set Identifier): ciscosb1, ciscosb2, ciscosb3, and ciscosb4. These are the default names or SSIDs of these networks, but you can change these names to more meaningful names. This table des cribes the default settings of these networks:

SSID Name ciscosb1 ciscosb2 ciscosb3 ciscosb4

Enabled Yes No No No SSID

Broadcast Security

Mode MAC Filter Disabled Disabled Disabled Disabled VLAN 1111 Wireless

Isolation with SSID

Enabled Disabled Disabled Disabled

Disabled

Disabled Disabled Disabled Disabled

Disabled Disabled Disabled

WMM Enabled Enabled Enabled Enabled

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 59

Configuring Wireless Networks

Configuring Basic Wireless Settings

SSID Name ciscosb1 ciscosb2 ciscosb3 ciscosb4

WPS Hardware Button

1. When using the Setup Wizard, select Best Security or Better Security to protect the device from unauthorized access.

Enabled Disabled Disabled Disabled

Configuring Basic Wireless Settings

Choose Wireless > Basic Settings to configure basic wireless settings. To configure basic wireless set tings:

STEP 1 Choose Wireless > Basic Settings. STEP 2 In the Radio field, check the Enable box to turn on the wirele ss radio. By default

there is only one wireless network enabled, ciscosb1.

STEP 3 In the Wireless Network Mode field, choose one of these options from the

drop-down menu:

B/G/N-Mixed If y ou ha v e W ir el ess-N, Wir e less-B, and W ir eless-G

devices in your network. This is the default setting (recommended).

B Only Choose this option if you have only Wireless-B

devices in your network.

G Only Choose this option if you have only Wireless-G

devices in your network.

N Only Choose this option if you have only Wireless-N

devices in your network.

B/G-Mixed Choose this option if you have Wireless-B and

Wireless-G devices in your network.

G/N-Mixed Choose this option if you have Wireless-G and

Wireless-N devices in your network.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 60

Configuring Wireless Networks

Configuring Basic Wireless Settings

STEP 4 If you chose B/G/N-Mixed, N-Only, or G/N Mixed, in the Wireles s Band Selection

field, select the wireless bandwidth on your network (20MHz or 20/40MHz). If you chose N-Only , you must use WPA2 security on your network. See Configuring

the Security Mode.

STEP 5 In the Wireless Channel field, choose the wireless channel from the drop-down

menu.

STEP 6 In the AP Management VLAN field, choose VLAN 1 if you are using the default

settings. If you create additional VLANs, choose a value that corresponds with the VLAN

configured on other switches in the network. This is done for security purposes. You might need to change the management VLAN to limit access to Device Manager.

STEP 7 (Optional) In the U-APSD (WMM Power Save) field, check Enable to enable the

Unscheduled Automatic Power Save Delivery (U-APSD) feature, also r eferr ed to as WMM Power Save, which allows the radio to conserve power.

U-APSD is a power-saving scheme optimized for real-time applications, such as VoIP, transferring full-duplex data over WLAN. By classifying outgoing IP traffic as voice data, these types of applications can increase battery life by approximately 25% and minimize transmit delays.

STEP 8 (Optional) Configure the settings of the four wireless networks (see Editing

Wireless Network Settings).

STEP 9 Click Save.

Editing Wireless Network Settings

The Wireless Table on the Basic Settings page lists the settings of the four wireless networks supported on the device.

To configure wireless network settings:

STEP 1 Check the box for the networks that you want to configure. STEP 2 Click Edit. STEP 3 Configure the following settings:

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 61

Configuring Wireless Networks

Configuring Basic Wireless Settings

Enable SSID Click On to enable the network. SSID Name Ent er the name of the network. SSID Broadcast Check this box to enable SSID broadcast. If

Security Mode See Configuring the Security Mode. MAC Filter See Configuring MAC Filtering. VLAN Choose the VLAN associated with the network. Wireless Isolation with SSID Check this box to enable wireless isolation

SSID broadcast is enabled, the wireless router advertises its availability to wireless-equipp ed devices in the range of the router.

within the SSID.

WMM (Wi-Fi Multimedia) Check this box to enable WMM. Max Associated Clients The maximum number of clients that can

WPS Check this box to map the device WPS button

Portal Profile See Configuring Captive Portal.

STEP 4 Click Save.

Configuring the Security Mode

You can configure one of the following security modes for wireless networks:

Configuring WEP

The WEP security mode offers weak security with a basic encryption method that is not as secure as WPA. WEP may be required if your network devices do not support WPA.

connect to th e selected w ire less network. Enter a number between 1 and 64.

on the front panel to this network.

NOTE If you do not have to use WEP, we recommend that you use WPA2. If you are using

the Wireless-N only mode, you must use WPA2.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 62

Configuring Wireless Networks

Configuring Basic Wireless Settings

To configure the WEP security mode:

STEP 1 Choose Wireless > Basic Settings. In the Wireless Table, check the box for the

network you want to configure.

STEP 2 Click Edit Security Mode. The Security Settings page appears. STEP 3 In the Select SSID field, choose the SSID for which to configure the security

settings.

STEP 4 From the Security Mode menu, choose WEP. STEP 5 In the Authentication Type field, choose one of the following options:

• Open System—This is the default option.

• Shared Key—Select this option if your network administrator recommends

this setting. If you are unsure, select the default option.

In both cases, the wireless client must provide the correct shared key (password) to access the wireless network.

STEP 6 In the Encryption field, choose the encryption type:

• 10/64-bit(10 hex digits)—Provides a 40-bit key.

• 26/128-bit(26 hex digits)—Provides a a 104-bit key, which offers stronger

encryption, making the key more difficult to decipher. We recommend 128bit encryption.

STEP 7 (Optional) In the Passphrase field, enter an alphanumeric phrase (longer than eight

characters for optimal security) and click Generate Key to generate four unique WEP keys in the WEP Key fields.

If you want to provide your own key, enter it directly in the Key 1 field (recommended). The length of the key should be 5 ASCII characters (or 10 hexadecimal characters) for 64-bit WEP and 13 ASCII characters (or 26 hexadecimal characters) for 128-bit WEP. Valid hexadecimal characters are 0 to 9 and A to F.

STEP 8 In the TX Key field, choose which key to use as the shared key that devices must

use to access the wireless network.

STEP 9 Click Save to save your settings . STEP 10 Click Back to go back to the Basic Settings pag e .

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 63

Configuring Wireless Networks

Configuring Basic Wireless Settings

Configuring WPA-Personal, WPA2-Personal, and WPA2-Personal Mixed

The WPA Personal, WPA2 Personal, and the WPA2 Personal Mixed security modes offer strong security to replace WEP.

• WPA-Personal—WPA is part of the wireless security standard (802.11i)

• WPA2-Personal—(Recommended) WPA2 is the implementation of the

• WPA2-Personal Mixed—Allows both WPA and WPA2 clients to connect

standardized by the Wi-Fi Alliance and was intended as an intermediate measure to take the place of WEP while the 802.11i standard was being prepared. WPA-Personal supports Temporal Key Integrity Protocol (TKIP) and Advanced Encryption Standard (AES) encryption.

security standard specified in the final 802.11i standard. WPA2 supports AES encryption and this option uses Preshared Key (PSK) for authentication.

simultaneously using PSK authentication.

The personal authentication is the PSK that is an alphanumeric passphrase shared with the wireless peer.

To configure the WPA Personal security mode:

STEP 1 In the Wireless Table (Wireless > Basic Settings), check the box for the network

you want to configure.

STEP 2 Click Edit Security Mode. The Security Settings page appears. STEP 3 In the Select SSID field, choose the SSID for which to configure the security

settings.

STEP 4 From the Security Mode menu, choose one of the three WPA Personal options. STEP 5 (WPA-Personal only) In the Encryption field, choose one of the following options:

• TKIP/AES—Choose TKIP/AES to ensure compatibility with older wireless

devices that may not support AES.

• AES—This option is more secure.

STEP 6 In the Security Key field, enter an alphanumeric phrase (8–63 ASCII characters or

64 hexadecimal digits). The password strength meter shows how secure the key is: below minimum, weak, strong, very strong, or secure. We recommend using a security key that registers on the strength meter as secure.

STEP 7 To show the security key as you are entering it, check the Unmask Password box.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 64

Configuring Wireless Networks

Configuring Basic Wireless Settings

STEP 8 In the Key Renewal field, enter the duration of time (600–7200 seconds) between

key renewals. The default value is 3600.

STEP 9 Click Save to save your settings . Click Back to go back to the Basic Settings

page.

Configuring WPA-Enterprise, WPA2-Enterprise, and WPA2-Enterprise Mixed

The WPA Enterprise, WPA2 Enterprise, and the WPA2 Enterprise Mixed security modes allow you to use RADUIS server authentication.

• WPA-Enterprise—Allows you to use WPA with RADIUS server

• WPA2-Enterprise—Allows you to use WPA2 with RADIUS server

authentication.

• WPA2-Enterprise Mixed—Allows both WPA and WPA2 clients to connect

simultaneously using R AD I US authentication.

To configure the WPA Enterprise security mode:

STEP 1 In the Wireless Table (Wireless > Basic Settings), check the box for the network

you want to configure.

STEP 2 Click Edit Security Mode. STEP 3 In the Select SSID field, choose the SSID for which to configure the security

settings.

STEP 4 From the Security Mode menu, choose one of the three WPA Enterprise options. STEP 5 (WPA-Enterprise only) In the Encryption field, choose one of the following options:

• TKIP/AES—Choose TKIP/AES to ensure compatibility with older wireless

devices that may not support AES.

• AES—This option is more secure.

STEP 6 In the RADIUS Server field, enter the IP address of the RADIUS server. STEP 7 In the RADIUS Port field, enter the port used to access the RADIUS server. STEP 8 In the Shared Key field, enter an alphanumeric phrase. STEP 9 In the Key Renewal field, enter the duration of time (600–7200 seconds) between

key renewals. The default value is 3600.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 65

Configuring Wireless Networks

Configuring Basic Wireless Settings

STEP 10 Click Save to save your settings. STEP 11 Click Back to go back to the Basic Settings pag e .

Configuring MAC Filtering

You can use MAC Filtering to permit or deny access to the wireless network based on the MAC (hardware) address of the requesting device. For example, you can enter the MAC addresses of a set of computers and only allow those computers to access the network. You can configure MAC Filtering for each network or SSID.

To configure MAC filtering:

STEP 1 In the Wireless Table (Wireless > Basic Settings), check the box for the network

you want to configure.

STEP 2 Click Edit MAC Filtering. The Wireless MAC Filter page appears. STEP 3 In the Edit MAC Filtering field, check the Enable box to enable MAC Filtering for

this SSID.

STEP 4 In the Connection Control field, choose the type of access to the wireless

network:

• Prevent—Select this option to prevent devices with the MAC addresses

listed in the MAC Address T able fr om accessing the wireless network. This option is selected by default.

• Permit—Select this option to allow devices with the MAC addresses listed

in the MAC Address Table to access the wireless network.

STEP 5 To show computers and other devices on the wireless network, click Show Client

List.

STEP 6 In the Save to MAC Address Filter List filed, check the box to add the device to

the list of devices to be added to the MAC Address Table.

STEP 7 Click Add to MAC to add the selected devices in the Client List Table to the MAC

Address Table.

STEP 8 Click Save to save your settings . STEP 9 Click Back to go back to the Basic Settings page.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 66

Configuring Wireless Networks

Configuring Advanced Wireless Settings

Configuring Time of Day Access

To further protect your network, you can restrict access to it by specifying when users can access the network.

To configure Time of Day Access:

STEP 1 In the Wireless Table (Wireless > Basic Settings), check the box for the network

you want to configure.

STEP 2 Click Time of Day Access. The Time of Day Access page appears. STEP 3 In the Active Time field, check Enable to enable Time of Day Access. STEP 4 In the Start Time and Stop Time fields, specify the time during the day, when

access to the network is allowed.

STEP 5 Click Save.

Configuring Advanced Wireless Settings

Advanced wireless settings should be adjusted only by an expert administrator; incorrect settings can reduce wireless performance.

To configure advanced wireless settings:

STEP 1 Choose Wireless > Advanced Settings. The Advanced Settings page appears. STEP 2 Configure these settings:

Frame Burst Enable this option to provide your wireless networks

with greater performance, depending on the manufacturer of your wireless products. If you are not sure how to use this option, keep the default (enabled).

WMM No Acknowledgement

Enabling WMM No Acknowledgement can result in mor e efficient throughput, but higher error rates in a noisy Radio Frequency (RF) environment. By default, this setting is disabled .

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 67

Configuring Wireless Networks

Configuring Advanced Wireless Settings

Basic Rate The Basic Rate setting is not the rate of transmission but

a series of rates at which the Services Ready Platform can transmit. The device advertises its basic rate to the other wireless devices in your network, so they know which rates will be used. The Services Ready Platform will also advertise that it will automatically select the best rate for transmission.

The default setting is Default, when the device can transmit at all standard wireless rates (1 Mbps, 2 Mbps,

5.5 Mbps, 11 Mbps, 18 Mbps, 24 Mbps, 36 Mbps, 48 Mbps, and 54 Mbps). In addition to B and G speeds, the device supports N speeds. Other options are 1-2 Mbps, for use with older wireless technology, and All, when the device can transmit at all wireless rates.

The Basic Rate is not the actual rate of data transmission. If you want to specify the device rate of data transmission, configure the Transmission Rate setting.

Transmission Rate The rate of data transmission should be set depending

on the speed of your wireless network. You can select from a range of transmission speeds, or you can select Auto to have the device automatically use the fastest possible data rate and enable the Auto-Fallback fe ature. Auto-Fallback will negotiate the best possible connection speed between the device and a wireless client. The default is Auto.

N Transmission Rate

The rate of data transmission should be set depending on the speed of your Wireless-N networking. You can select from a range of transmission speeds, or you can select Auto to have the device automatically use the fastest possible data rate and enable the Auto-Fallback featur e. Auto-Fallback will negotiate the best possible connection speed between the device and a wireless client. The default is Auto.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 68

Configuring Wireless Networks

Configuring Advanced Wireless Settings

CTS Protection Mode

Beacon Interval The Beacon Interval value indicates the frequency

DTIM Interval This value, between 1 and 255, indicates the interval of

The device automatically uses CTS (Clear-To-Send) Protection Mode when your Wireless-N and Wireless-G devices are experiencing severe problems and are not able to transmit to the device in an environment with heavy 802.11b traffic.

This function boosts the device’s ability to catch all Wireless-N and Wireless-G transmissions but will severely decrease performance. The default is Auto.

interval of the beacon. A beacon is a packet broadcast by the device to synchronize the wireless network.

Enter a value between 40 and 3,500 milliseconds. The default value is 100.

the Delivery Traffic Indication Message (DTIM). A DTIM field is a countdown field informing clients of the next window for listening to broadcast and multicast messages.

Fragmentation Threshold

When the device has buffered broadcast or multicast messages for associated clients, it sends the next DTIM with a DTIM Interval value. Its clients hear the beacons and awaken to receive the broadcast and multicast messages. The default value is 1.

This value specifies the maximum size for a packet before data is fragmented into multiple packets. If you experience a high packet error rate, you may slightly increase the Fragmentation Threshold.

Setting the Fragmentation Threshold too low may result in poor network performance. Only minor reduction of the default value is recommended. In most cases, it should remain at its default value of 2346.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 69

Configuring Wireless Networks

Detecting Rogue Access Points

RTS Threshold If you encounter inconsistent data flow, enter only minor

STEP 3 Click Save.

reductions. The default value of 2347 is recommended. If a network packet is smaller than the preset Request to

Send (RTS) threshold size, the RTS/Clear to Send (CTS) mechanism will not be enabled. The Services Ready Platform sends RTS frames to a particular receiving station and negotiates the sending of a data frame.

After receiving an RTS, the wireless station responds with a CTS frame to acknowledge the right to begin transmission.

Detecting Rogue Access Points

A rogue access point is an access point (AP) that has been installed on a secure network without authorization from a system administrator. Rogue APs pose a security threat because anyone with access to the premises can install a wireless AP that can allow unauthorized parties to access the network.

Use the Rogue AP Detection page to enable your device to display information about all APs detected by the device in the vicinity of the network. If the access point listed as a rogue is actually a legitimate access point, you can add it to the Authorized AP Table. Select a refresh rate to ensure that the Rogue AP Detection page always displays the latest information.

To enable Rogue AP detection:

STEP 1 Choose Wireless > Rogue AP. STEP 2 Click the Rogue AP Detection On radio button. STEP 3 Click Save.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 70

Configuring Wireless Networks

Detecting Rogue Access Points

To authorize detected access points:

STEP 1 In Rogue AP Detected Table, check the box for the access point that you want to

authorize.

STEP 2 Click Authorize.

To add an access point to the Authorized AP table:

STEP 1 Click Add Row. STEP 2 Enter the MAC address of the access point that you want to authorize. STEP 3 Enter the SSID or the name that identifies the wireless network. STEP 4 Choose the security mode associated with the ac cess point.

STEP 5 Choose TKIP (Temporal Key Integrity Protocol) or CCMP (Counter Cipher Mode

Protocol) as the encryption algorithm associated with the access point.

STEP 6 Choose RADIUS server or PSK (Pre-Shared Key) to authenticate th e access point. STEP 7 Select the wireless network mode that the access point uses. STEP 8 Choose the radio frequency that the access point uses. STEP 9 Click Save.

Importing Authorized AP Lists

You can import a list of authorized access points using a CSV file. Use the following values as a reference when you create the CSV file.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 71

Configuring Wireless Networks

Detecting Rogue Access Points

Field Values

Security • 0 — Open

Network Mode • 0 — B Only

• 1 — WEP

• 2 — WPA-Personal

• 3 — WPA-Enterprise

• 4 — WPA2-Personal

• 5 — WPA2-Enterprise

• 1 — G Only

• 2 — N Only

• 3 — BG-Mixed

• 4 — GN-Mixed

• 5 — BGN-Mixed

Channel • 0 — Auto

• 1 — 2.412

• 2 — 2.417

• 3 — 2.422

• 4 — 2.427

• 5 — 2.432

• 6 — 2.437

• 7 — 2.442

• 8 — 2.447

• 9 — 2.452

• 10 — 2.457

• 11 — 2.462

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 72

Configuring Wireless Networks

Configuring WDS

Field Values

Encryption • 2 — TKIP

Authentication • 2 — PS K

Ensure that the content in the CSV file is arranged as shown in the following example:

• 4 — CCMP

• 1 — RADIUS

BSSID Security Encryption Authentication Wireless

Network

00:1C:10:CE:44:48 4 2 2 3 1 Auth_Guest

To import a list of authorized APs:

STEP 1 Click Merge to add the list of access points that you want to import, to the access

points displayed in Authorized AP Table. Click Replace to replace the APs in the table with the APs in the list that you want to import.

STEP 2 Click Browse to locate the file that you want to import. STEP 3 Click Save.

Channel SSID

Configuring WDS

A Wireless Distribution System (WDS) is a system that enables the wireless interconnection of access points in a network. It allows a wireless network to be expanded using multiple access points without the need for a wired backbone to link them.

To establish a WDS link, the device and other remote WDS peers must be configured in the same wireless network mode, wireless channel, wireless b and selection, and encryption t y pes (None or WEP).

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 73

Configuring Wireless Networks

Configuring WDS

You can configure WDS in Bridge mode where one AP acts as the common link between multiple APs or in Repeater mode where one AP connects two APs without a wired connection to the LAN, by repeating signals using the wireless connection.

WDS is suppor ted on one SSID only. To configure WDS in Bridge mode:

STEP 1 Choose Wireless > WDS. STEP 2 To enable WDS, check the Enable. STEP 3 Select the WDS Bridge radio button. STEP 4 In the Remote Wireless Bridge’s MAC Address section, enter the MAC addresses

of up to four access points to use as bridges in the MAC 1, MAC 2, MAC 3,and MAC 4 fields.

STEP 5 Click Save.

To configure WDS in Repeater mode:

STEP 1 Choose Wireless > WDS. STEP 2 Check the WDS check box . STEP 3 Choose the repeater mode. If you select Allow wireless signal to be repeated by

a repeater, enter the MAC addresses of up to three access points to use as repeaters in the MAC 1, MAC 2, and MAC 3 fields.

STEP 4 If you select Repeat wireless signal of a remote access point:

• Enter the MAC address of a wireless access point in the MAC field.

• Click Show Available Networks to display the Available Networks Table.

Click Connect to add the MAC address of the selected access point to the MAC field.

STEP 5 Click Save.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 74

Configuring Wireless Networks

Configuring WPS

Configure WPS to allow WPS-enabled devices to easily and securely connect to the wireless network . Refer to your client device documentation for additional instructions on setting up WPS on your client device.

To configure WPS:

STEP 1 Choose Wireless > WPS. The Wi-Fi Protected Setup page appears STEP 2 Select the SSID option from the drop-down menuCisco RV130W STEP 3 Configure the WPS on client devices in one of the following three ways:

• Click or press the WPS button on the client device and click the WPS icon on

this page.

• Enter the WPS PIN number of the client and click Register.

• A client device requires a PIN number from this router, use the router PIN

number indicated.

- Device PIN Status—WPA device personal identification number (PIN)

status.

- Device PIN—Identifies the PIN of a device trying to connect.

- PIN Lifetime—The lifetime of the key. If the time expires, a new key is

negotiated.

After you configure WPS, the following information appears at the bottom of the

WPS page: Wi-Fi Protected Setup Status, Network Name (SSID), and Security.

Configuring Captive Portal

Use the Captive Portal feature to provide controlled, authenticated access to the Internet and your network resources, without compromising security. A captive portal displays a special web page to authenticate clients before they can use the Internet. You can configure Captive Portal verification to allow access for both guest and authenticated network users.

Configure Captive Portal instances for each virtual wireless network on your device by associat ing it with a portal profile.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 75

Configuring Wireless Networks

Configuring Captive Portal

Creating Captive Portal Profiles

To create a captive portal profile:

STEP 1 Choose Wireless > Captive Portal > Portal Profile. In the Portal Profile Table

section, click Add Row. To modify the portal profile provided on the device, check the Default_Portal_Profile box and click Edit.

STEP 2 Enter a name for your Captive Portal profile. STEP 3 Choose if you want to use the profile to authenticate guest users or users on your

network.

STEP 4 To redirect users to a URL after authentication, enable Auto Redirect URL, and

enter a fully qualified domain name or IP address in the Redirect URL field. For example, include http:// in the URL.

STEP 5 In the Session Timeout field, specify the number of minutes that the device will

keep an authentication session open with the associated wireless client. The default timeout is 60 minutes.

STEP 6 Select a font color for the text that you want to display on the page. STEP 7 Specify the text that you want to display, such as the name of your organization,

the label text for username and password fields, and the label on the Login button.

STEP 8 Enter standard Copyright text associated with your company. STEP 9 In the Error 1 and Error 2 fields, enter the error messages that you want to display

to clients when login fails and when the maximum number of connections is exceeded.

STEP 10 To use a check box to allow users to accept terms of use before they continue,

enable Agreement. The text in the Agreement Text field will be displayed as the label for the checkbox.

STEP 11 Enter the acceptance terms t hat you want to d isplay to users in the Acceptance

Use Policy field.

STEP 12 In the Upload Files section, choose files to upload your company logo and

background files in keeping with your company’s branding guidelines. S ave your profile.

To preview this profile, choose Captive Portal > Portal Page Preview, and select the profile from the Portal Profile drop-down list.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 76

Configuring Wireless Networks

Configuring Captive Portal

Configuring Captive Portal Instances

To configure a captive portal instance for your device:

STEP 1 Choose Wireless > Basic Setti ngs. STEP 2 In the Wirel es s Table section, check the Enable box for the SSID for which you

want to configure a captive portal. Click Edit.

STEP 3 Select a portal profile for the SSID.

You can create up to f our captive portals using the SSIDs for your device. To create a new portal profile, select Create a new Portal Profile from the drop-down list. Choose Default_Portal_Profile to use the portal profile provided on your device.

STEP 4 Check the Enable box to enable the captive portal for the SSID. STEP 5 Save your captive portal instances.

Creating Captive Portal User Accounts

To create a captive portal user account :

STEP 1 Choose Wireless > Captive Portal > User Accounts. STEP 2 Click Add Row. STEP 3 Enter a username and password. Reenter the password to verify it.

We recommended that the pas s word contains no dictionary words from any language, and is a mix of letters (both uppercase and lowercase), numbers, and symbols. The password can be up to 64 characters long.

STEP 4 In the Access Time (Minutes) field, specify the duration after which the

authentication session will timeout.

STEP 5 To import usernames and passwords from a CSV file, click Import. The

Administration > Users page is displayed. In the Import Username and Password section, click Browse to locate th e file, and click Import. See Importing User

Accounts for more information.

STEP 6 Save your user accounts.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 77

Configuring Wireless Networks

Configuring Device Mode

You can configure your device to work in the following modes:

• Router—To act as a wireless router.

• AP (access point)—To provide wireless connections to clients and extend

Wi-Fi capability to an existing wired network. All LAN ports are disabled when the device works as an access point.

Ensure that you configure the AP management VLAN information on the Networking > WAN > WAN Configuration page. For more information, see

Configuring Optional Network Settings.

To configure the device mode:

STEP 1 Choose Wireless > Device Mode, and select the mode in which you want to run

your device.

STEP 2 Click Save.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 78

Configuring Wireless Networks

Configuring Device Mode

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 79

Configuring the Firewall

Firewall Features

You can secure your network by creating and applying rules that the device uses to selectively block and allow inbound and outbound Internet traffic. You then specify how and to what devices the rules apply. To do so, you must define the following:

• Services or traffic types that the router should allow or block. For example,

web browsing, VoIP, other standard services and custom services that you define.

• Direction for the traffic by specifying the source and destination of traffic;

this is done by specifying the From Zone (LAN/WAN/DMZ) and To Zone (LAN/WAN/DMZ).

• Schedules as to when the router should apply rules.

• Keywords (in a domain name or on a URL of a web page) that the router

should allow or block.

• Rules for allowing or blocking inbound and outbound Internet traffic for

specified services on specified schedules.

• MAC addresses of devices whose inbound access to your network the

router should block.

• Port triggers that signal the router to allow or block access to specified

services as defined by port number.

• Reports and alerts that you want the router to send to you.

You can, for example, establish restricted-access policies based on time-of-day, web addresses, and web address keywords. You can block Internet access by applications and services on the LAN, such as chat rooms or games. You can block specific groups of PCs on your network from being accessed by the WAN or public DMZ network.

Cisco RV130/130W Wireless Multifunction VPN Router Administration Guide 80

Configuring the Firewall

Configuring Basic Firewall Settings

Inbound (WAN to LAN/DMZ) rules restrict access to traffic entering your network, selectively allowing only specific outside users to access specific local resources. By default, all access from the insecure WAN side is blocked from accessing the secure LAN, except in response to requests from the LAN or DMZ. To allow outside devices to access services on the secure LAN, you must create a firewall rule for each service.

If you want to allow incoming traffic, you must make the router's WAN port IP address known to the public. This is called “exposing your host.” How you make your address known depends on how the WAN ports are configured; for the device, you may use the IP address if a static address is assigned to the W AN port, or if your WAN addres s is dynamic, a DDNS (Dynamic DNS) name can be used.

Outbound (LAN/DMZ to WAN) rules restrict access to traffic leaving your network, selectively allowing only specific local users to access specific outside resources. The default outbound rule is to allow access from the secure zone (LAN) to either the public DMZ or insecure WAN. To block hosts on the secure LAN from accessing services on the outside (insecure WAN), you must create a firewall rule for each service.

Configuring Basic Firewall Settings

To configure basic firewall settings:

STEP 1 Choose Firewall > Basic Settings. STEP 2 Configure the following firewall settings:

IP Address Spoofing Protection

DoS Protection Check Enable to enable Denial of Service

Block WAN Request Blocks ping requests to the device from the WAN. LAN/VPN Web Access Choose the type of web access that can be used

To protect your network against IP address spoofing, check the Enable check box.

protection.

to connect to the firewall: HTTP or HTTPS (secure HTTP).

Cisco RV130/130W Wireless Multifunction VPN Router Administration Guide 81

Configuring the Firewall

Configuring Basic Firewall Settings

Remote Management Remote Access Remote Upgrade Allowed Remote IP Address Remote Management Port

IPv4 Multicast Passthrough (IGMP Proxy)

IPv 6 Multicast Passthrough (IGMP Proxy)

SIP ALG To allow Se ssion Initiation Protocol (SIP) traffic to

UPnP Allow Users to Configure Allow Users to Disable Internet Access

See Configuring Remote Management.

Check Enable to enable multicast passthrough for IPv4.

Check Enable to enable multicast passthrough for IPv6.

traverse the firewall, check the SIP A LG check box. The device supports a maximum of 256 sessions.

See Configuring Universal Plug and Play.

Block Java Check to block Java applets. Java applets are

small programs embedded in web pages that enable dynamic functionality of the page. A malicious applet can be used to compromise or infect computers.

Enabling this setting blocks Java applets from being downloaded. Click Auto to automaticall y block Java, or click Manual and enter a specific port on which to block Java.

Cisco RV130/130W Wireless Multifunction VPN Router Administration Guide 82

Configuring the Firewall

Configuring Basic Firewall Settings

Block Cookies Check to block cookies. Cookies are used to store

Block ActiveX Check to block ActiveX content. Similar to Java

session information by websites that usually require login. However, several websites use cookies to store tracking information and browsing habits. Enabling this option filters out cookies from being created by a website.

Many websites require that cookies be accepted in order for the site to be accessed properly . Blocking cookies can cause many websites to not function properly.

Click Auto to automatically bl ock coo kies, or click Manual and enter a specific port on which to block cookies.

applets, ActiveX controls are installed on a Windows computer while running Internet Explorer. A malicious ActiveX control can be used to compromise or infect computers.

Enabling this setting blocks ActiveX applets from being downloaded.

Click Auto to automatically block ActiveX, or click Manual and enter a specific port on which to block ActiveX.

Block Proxy Check to block proxy servers. A proxy server (or

proxy) allows computers to route connections to other computers through the proxy, thus circumventing certain firewall rules.

For example, if connections to a specific IP address are blocked by a firewall rule, the requests can be routed through a proxy that is not blocked by the rule, rendering the restriction ineffective. Enabling this feature blocks proxy servers.

Click Auto to automatically block proxy s ervers, or click Manual and enter a specific port on which to block proxy servers.

Cisco RV130/130W Wireless Multifunction VPN Router Administration Guide 83

Configuring the Firewall

Configuring Basic Firewall Settings

STEP 3 Click Save.

Configuring Remote Management

You can enable remote management so that you can access the device from a remote WAN network.

To configure remote management, configure these settings on the Bas ic Setti ngs page:

Remote Management Check Enable to enable remote management.

Remote Access Choose the type of web access that can be used

to connect to the firewall: HTTP or HTTPS (secure HTTP).

Remote Upgrade To allow remote upgrades of the device, check

Enable.

Allowed Remote IP Address

Remote Management Port

CAUTION When remote management is enabled, the router is accessible to anyone who

knows its IP address. Because a malicious WAN user can reconfigure the device and misuse it, it is highly recommended that you change the administrator and an y guest passwords before continuing.

Click the Any IP Address button to allow remote management from any IP address, or enter a specific IP address in the address field.

Enter the port on which remote access is allowed. The default port is 443. When remotely accessing the router, you must enter the remote management port as part of the IP address. For example:

https://<remote-ip>:<remote-port>, or https://

168.10.1.11:443

Cisco RV130/130W Wireless Multifunction VPN Router Administration Guide 84

Configuring the Firewall

Managing Firewall Schedules

Configuring Universal Plug and Play

Universal Plug and Play (UPnP) allows automatic discovery of devices that can communicate with the device.

To configure UPnP, configure these settings on the Basic Settings page:

UPnP Check Enable to enable UPnP. Allow Users to Configure Check this box to allow UPnP port-mapping rules

to be set by users who have UPnP support enabled on their computers or other UPnP-enabled devices. If disabled, the device does not allow the application to add the forwarding rule.

Allow Users to Disable Internet Access

Managing Firewall Schedules

You can create firewall schedules to apply firewall rules on specific days or at specific times of the day.

Adding or Editing a Firewall Schedule

To create or edit a schedule:

STEP 1 Choose Firewall > Schedule Management. STEP 2 Click Add Row. STEP 3 In the Name field, enter a unique name to identify the schedule. This name is

available on the Fir ewall Rule Configuration page in the Select Schedule list. (See

Configuring Access Rules.)

Check this box to allow users to disable Internet access.

STEP 4 In the Scheduled Days section, choose if you want to apply the schedule to All

days or Specific Days. If you choose Specific Days, check the box next to the days that you want to include in the schedule.

STEP 5 In the Scheduled Time of Day section, choose the time when you want the

schedule to apply. If you choose Specific Time, enter the start and end times.

STEP 6 Click Save.

Cisco RV130/130W Wireless Multifunction VPN Router Administration Guide 85

Configuring the Firewall

Configuring Services Management

When you create a firewall rule, you can specify a service that is controlled by the rule. Common types of services are available for selection, and you can create your own custom services.

The Services Management page allows you to create custom services against which firewall rules can be defined. Once defined, the new service appears in the List of Available Custom Services table.

To create a custom service:

STEP 1 Choose Firewall > Service Management. STEP 2 Click Add Row.

STEP 3 In the Service Name field, enter the service name for identification and

management purposes.

STEP 4 In the Protocol field, choose the Layer 4 protocol that the service uses from the

drop-down menu:

• TCP

• UDP

• TCP & UDP

• ICMP

STEP 5 In the Start Port field, enter the first TCP or UDP port of the range that the service

uses.

STEP 6 In the End Port field, enter the last TCP or UDP port of the range that the service

uses.

STEP 7 Click Save.

To edit an entry, select the entry and click Edit. Make your changes, then click Save.

Cisco RV130/130W Wireless Multifunction VPN Router Administration Guide 86

Configuring the Firewall

Configuring Access Rules

Configuring the Default Outbound Policy

The Access Rules page allows you to configure the default outbound policy for the traffic that is directed from the secure network (LAN) to the non-secure network (dedicated WAN/optional).

The default inbound policy for traffic flowing from the non-secure zone to the secure zone is always blocked and cannot be changed.

NOTE Internet access policies override access rules, when both are configured on the

device. To configure the default outbound policy:

STEP 1 Choose Firewall > Access Rules. STEP 2 Choose Allow or Deny.

Note: Ensure that IPv6 support is enabled on the device to configure an IPv6

firewall. See Configuring IPv6.

STEP 3 Click Save.

Reordering Access Rules

The order in which access rules are displayed in the access rules table indicates the order in which the rules are applied. You may want to reorder the table t o have certain rules applied before other rules. For e xample, you ma y want to apply a rule allowing certain t y pes of traffic before blocking other types of traffic.

To reorder access rules:

STEP 1 Choose Firewall > Access Rules. STEP 2 Click Reorder. STEP 3 Check the box in the row of the rule that you want to move up or down and click

the up or down arrow to move the rule up or down one line, or select the desired position of the rule in the drop-down list and click Move to.

STEP 4 Click Save.

Cisco RV130/130W Wireless Multifunction VPN Router Administration Guide 87

Configuring the Firewall

Configuring Access Rules

STEP 1 Choose Firewall > Access Rules. STEP 2 Click Add Row. STEP 3 In the Connection Type field, choose the source of originating traffic:

Adding Access Rules

All configured firewall rules on the device are displayed in the Access Rules Table. This list also indicates whether the rule is enabled (active) and gives a

summary of the From/To zone as well as the services and users the rule affects. To create an access rule:

• Outbound (LAN > WAN)—Choose this option to create an outbound rule.

• Inbound (WAN > LAN)—Choose this option to create an inbound rule.

• Inbound (WAN > DMZ)—Choose this option to create an inbound rule.

STEP 4 From the Action drop-down menu, choose the action:

• Always Block—Always block the selected type of traffic.

• Always Allow—Never block the selected type of traffic.

• Block by schedule—Blocks the selected type of traffic according to a

schedule.

• Allow by schedule—Allows the selected type of traffic according to a

schedule.

STEP 5 From the Services drop-down menu, choose the service to allow or block for this

rule. Choose All Traffic to allow the rule to apply to all applications and services, or choose a single application to block:

• Domain Name System (DNS), UDP or TCP

• File Transfer Protocol (FTP)

• Hyptertext Transfer Protocol (HTTP)

• Secure Hypertext Transfer Protocol (HTTPS)

• Trivial File Transfer Protocol (TFTP)

• Internet Message Access Protocol (IMAP)

• Network News Transport Protocol (NNTP)

Cisco RV130/130W Wireless Multifunction VPN Router Administration Guide 88

Configuring the Firewall

Configuring Access Rules

• Post Office Protocol (POP3)

• Simple Network Management Protocol (SNMP)

• Simple Mail Tr ansfer Protocol (SMTP)

• Telnet

• STRMWORKS

• Terminal Access Controller Access-Control System (TACACS)

• Telnet (command)

• Telnet Secondar y

• Telnet SSL

• Voice (SIP)

STEP 6 In the Source IP field, select the users to which the firewall rule applies:

• Any—The rule applies to traffic originating on any host in the local network.

• Single Address—The rule applies to traffic originating on a single IP address

in the local network. Enter the address in the Start field.

• Address Range—The rule applies to traffic originating from an IP address

located in a range of addresses. Enter the starting IP address in the Start field, and the ending IP address in the Finish field.

STEP 7 In the Log field, specify whether the packets for this rule should be logged.

To log details for all packets that match this rule, choose Always from the dropdown menu. For example, if an outbound rule for a schedule is selected as Block Always, for every packet that tries to make an outbound connection for that service, a message with the packet's source address and destination address (and other information) is recorded in the log.

Enabling logging may generate a significant volume of log messages and is recommended for debugging purposes only.

Choose Never to disable logging. Note: When traffic is going from the LAN or DMZ to the WAN, the system requires

rewriting the source or destination IP address of incoming IP packets as they pass through the firewall.

STEP 8 Check the Rule Status Enable check box, to enable the new access rule.

Cisco RV130/130W Wireless Multifunction VPN Router Administration Guide 89

Configuring the Firewall

Creating an Internet Access Policy

STEP 9 Click Save.

Creating an Internet Access Policy

The device supports several options for blocking Internet access. You can block all Internet traffic, block Internet traffic to certain PCs or endpoints, or block access to Internet sites by specifying keywords to block. If these keywords are found in the site's name (for example, web site URL or newsgroup name), the site is blocked.

Adding or Editing an Internet Access Policy

To create a Internet access policy:

STEP 1 Choose Firewall > Internet Access Policy. STEP 2 Click Add Row. STEP 3 Check the Status Enable check box. STEP 4 Enter a policy name for identification and management purposes. STEP 5 From the Action drop-down menu, choose the type of access restriction you need:

• Always block—Always block Internet traffic. This blocks Internet traffic to

and from all endpoints. If you want to block all traffic but allow certain endpoints to receive Internet traffic, see Step 7.

• Always allow—Always allow Internet traffic. You can refine this to block

specified endpoints from Internet traffic; see Step 7. You can also allow all Internet traffic except for certain websites; see Step 8.

• Block by schedule—Blocks Internet traffic according to a schedule (for

example, if you wanted t o block Internet traffic during the weekda y business hours, but allow it after hours and on weekends).

• Allow by schedule—Allows Internet traffic according to a schedule.

If you chose Block by schedule or Allow by schedule, click Config u re Sc hed ul es to create a schedule. See Managing Firewall Schedules.

STEP 6 Choose a schedule from the drop-down menu.

Cisco RV130/130W Wireless Multifunction VPN Router Administration Guide 90

Configuring the Firewall

Creating an Internet Access Policy

STEP 7 (Optional) Apply the access policy to specific PCs to allow or block traffic coming

from specific devices: a. In the Apply Access Policy to the Following PCs table, click Add Row. b. From the Type drop-down menu, choose how to identify the PC (by MAC

address, by IP address, or by providing a range of IP addresses).

c. In the Value field, depending on what you chose in the previous step, enter the

one of the following:

• MAC address (xx:xx:xx:xx:xx:xx) of the PC to which the policy applies.

• The IP address of the PC to which the policy applies.

• The starting and ending IP addresses of the range of addresses to block (for

STEP 8 To block traffic from specific websites:

example, 192.168.1.2-192.168.1.253).

a. In the Website Domain Name & Keyword table, click Add Row. b. From the Type drop-down menu, choose how to block a website (by

specifying the domain name or by specifying a keyword that appears in the URL).

c. In the Value field, enter the URL or keyword used to block the website.

For example, t o block the example.com URL, choose URL Address from the drop-down menu and enter example.com in the Value field. To block a URL that has the keyword “example” in the URL, choose Keyword from the dropdown menu and enter example in the Value field.

STEP 9 Click Save.

Cisco RV130/130W Wireless Multifunction VPN Router Administration Guide 91

Configuring the Firewall

Configuring One-to-One Network Address Translation (NAT)

Use the One-to-one NAT page to map local IP addresses behind your firewall to global IP addresses. One-to-one NAT is a way to make systems configured with private IP addresses, which are behind a firewall, appear to have public IP addresses.

To add a One-to-One NAT rule:

STEP 1 Choose Firewall > One-to-One NAT. STEP 2 Click Add Row. STEP 3 In the Private Range Begin field, enter the starting IP address in the private (LAN) IP

address range.

STEP 4 In the Public Range Begin field, enter the starting IP address in the public (WAN) IP

address range.

STEP 5 In the Range Length, enter the number of public IP addresses that should be

mapped to private addresses.

STEP 6 In the Service field, choose the service for which the rule applies. Services for

one-to-one NAT allow you to configure the service to be accepted by the private IP (LAN) address when traffic is sent to the corresponding public IP address. Configured services on private IP addresses in the range are accepted when traffic is available on the corresponding public IP address.

STEP 7 Click Save.

Configuring Port Forwarding

Port forwarding is used to redirect traffic from the Internet from one port on the W AN t o another port on the LAN. Common services are available or you can define a custom service and associated ports to forward.

The Single Port Forwarding Rules and Port Range Forwarding Rules pages list all the available port forwarding rules for this device and allow you to configure port forwarding rules .

Cisco RV130/130W Wireless Multifunction VPN Router Administration Guide 92

Configuring the Firewall

Configuring Port Forwarding

NOTE Port forwarding is not appropriate for servers on the LAN because there is a

dependency on the LAN device making an outgoing connection before incoming ports are opened.

The gateway has a list of common applications and games with corresponding outbound and inbound ports to open. You can also specify a port forwarding rule by defining the type of traffic (TCP or UDP) and the range of incoming and outgoing ports to open when enabled.

Configuring Single Port Forwarding

To add a single po rt forwarding rule:

STEP 1 Choose Firewall > Single Port Forwarding. A preexisting list of applications is

displayed.

STEP 2 In the Application field, enter the name of the application for which to configure

port forwarding.

STEP 3 In the External Port field, enter the port number that triggers this rule when a

connection request from outgoing traffic is made.

STEP 4 In the Internal Port field, enter the port number used by the remote system to

respond to the request it receives.

STEP 5 In the Interface drop-down menu, choose Both (Ethernet & 3G), Ethernet, or 3G. STEP 6 From the Protocol drop-down menu, choose a protocol (TCP, UDP, or TCP &

UDP).

STEP 7 In the IP Address field, enter the IP address of the host on the LAN side to which

the specific IP traffic will be forwarded. For example, you can forward HTTP traffic to port 80 of the IP address of a web server on the LAN side.

STEP 8 In the Enable field, check the Enable box to enable the rule. STEP 9 Click Save.

Cisco RV130/130W Wireless Multifunction VPN Router Administration Guide 93

Configuring the Firewall

Configuring Port Forwarding

STEP 1 Choose Firewall > Po rt Range Forwarding. STEP 2 In the Application field, enter the name of the application for which to configure

STEP 3 In the External Port field, specify the port number that will trigger this rule when a

STEP 4 In the Start field, spe cify the port number that begins the range of ports to

STEP 5 In the End field, specify the port number that ends the range of ports to forward. STEP 6 In the Interface drop-down menu, choose Both (Ethernet & 3G), Ethernet, or 3G.

Configuring Port Range Forwarding

To add a po rt range forwarding rule:

port forwarding.

connection request from outgoing traffic is made.

forward.

STEP 7 From the Protocol drop-down menu, choose a protocol (TCP, UDP, or TCP &

UDP).

STEP 8 In the IP Address field, enter the IP address of the host on the LAN side to which

the specific IP traffic will be forwarded.

STEP 9 In the Enable field, check the Enable box to enable the rule. STEP 10 Click Save.

Configuring Port Range Triggering

Port triggering allows devices on the LAN or DMZ to request one or more ports to be forwarded to them. Port triggering waits for an outbound request from the LAN/ DMZ on one of the defined outgoing ports, and then opens an incoming port for that specified type of traffic.

Port triggering is a form of dynamic port forwarding while an application is transmitting data over the opened outgoing or incoming ports. Port triggering opens an incoming port for a specific type of traffic on a defined outgoing port. Port triggering is more flexible than static port forwarding (available when configuring firewall rules) because a rule does not have to reference a specific LAN IP or IP range. Ports are also not left open when not in use, which provides a level of security that port forwarding does not offer.

Cisco RV130/130W Wireless Multifunction VPN Router Administration Guide 94

Configuring the Firewall

Configuring Port Forwarding

NOTE Port triggering is not appropriate for servers on the LAN, since there is a

STEP 1 Choose Firewall > Port Range Triggering. STEP 2 In the Application field, enter the name of the application for which to configure

dependency on the LAN device making an outgoing connection before incoming ports are opened.

Some applications require that, when external devices connect to them, they receive data on a specific port or range of ports in order to function properly. The router must send all incoming data f o r that application only on the required port or range of ports. The gateway has a list of common applications and games with corresponding outbound and inbound ports to open. Yo u can also specify a port triggering rule by defining the type of traffic (TCP or UDP) and the range of incoming and outgoing ports to open when enabled.

To add a port triggering rule:

port forwarding.

STEP 3 In the Triggered Range fields, enter the port number or range of port numbers that

will trigger this rule when a connection request from outgoing traffic is made. If the outgoing connection uses only one port, enter the same port number in both fields.

STEP 4 In the Forwarded Range fields, enter the port number or range of port numbers

used by the remote system to respond to the request it receives. If the incoming connection uses only one port, then specify the same port number in both fields.

STEP 5 In the Interface drop-down menu, choose Both (Ethernet & 3G), Ethernet, or 3G. STEP 6 In the Enable field, check the Enable box to enable the rule. STEP 7 Click Save.

Cisco RV130/130W Wireless Multifunction VPN Router Administration Guide 95

Configuring the Firewall

Configuring Port Forwarding

Cisco RV130/130W Wireless Multifunction VPN Router Administration Guide 96

Configuring VPN

VPN Tunnel Types

You can configure VPN on your device to provide you a secure communication channel or a tunnel between:

• Two gateway routers

• A remote client device and a gateway router

Configuring Basic Site-to-Site IPsec VPN

Your device supports site-to-site IPsec VPN for a single gateway-to-gateway VPN tunnel. After configuring these basic VPN set tings, you can connect securely to another VPN-enabled router. For example, you can configure your device at a branch site to connect to a router that connects site-to-site VPN tunnels at the corporate site, so that the branch site has secur e access to the corporate network.

To configure basic VPN se ttings for a site-to-site IPsec connection:

STEP 1 Choose VPN > Site-to-Site IPsec VPN > Basic VPN Setup. STEP 2 In the New Connection Name field, enter a name for the VPN tunnel. STEP 3 In the Pre-Shared Key field, enter the pre-shared key, or password, that will be

exchanged between the two routers. It must be between 8 and 49 characters.

STEP 4 In the Endpoint Information fields, enter the following information:

• Remote Endpoint—Choose if the router to which your device will connect

will be identified by its IP address or by a fully qualified domain name. For example, an IP address such as 192.168.1.1 or a fully qualified domain name such as cisco.com.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 97

Configuring VPN

Configuring Basic Site-to-Site IPsec VPN

• Remote WAN (Internet) IP Address—Enter the public IP address or domain

name of the remote endpoint.

• Local WAN (Internet) IP Address—Enter the public IP address or domain

name of your device.

STEP 5 In the Secure Connection Remote Accessibility fields, enter the following

information:

• Remote LAN (Local Network) IP Address—The private network (LAN)

address of the remote endpoint. This is the IP address of the internal network at the remote site.

• Remote LAN Subnet Mask—The private network (LAN) subnet mask of the

remote endpoint.

• Local LAN (Local Network) IP Address—The private netw ork (LAN)

address of the local network. This is the IP address of the internal network on the device.

• Local LAN (Local Network) Subnet Mask—The private network (LAN)

subnet mask of the local network.

Note: The remote WAN and remote LAN IP addresses cannot exist on the same subnet. For example, a remote LAN IP address of 192.168.1.100 and a local LAN IP address of 192.168.1.115 causes a conflict when traffic is routed over the VPN. The third octet must be different so that the IP addresses are on differ ent subnets. For example, a remote LAN IP address of 192.168.1.100 and a local LAN IP address of 192.168.2.100 is acceptable.

STEP 6 Click Save.

Viewing Default Values

Click View Default Settings to view the default values used in the basic VPN settings. These values are proposed by the VPN consortiu m and assume that you are using a pre-shared k ey, or password that is known to both your device and the remote endpoint.

Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 98

Cisco RV130, RV130W User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
