CHA PT ER
1
Introducing the Content Router 4430
This chapter provides a basic functional overview of the Content Router 4430 and
describes the Content Router 4430 hardware, major components, and front and
back panel indicators and controls.
This chapter contains the following sections:
• Introduction, page 1-1
• System Hardware Features, page 1-2
• Specifications, page 1-9
• Regulatory Compliance, page 1-10
• Class A Warning Statements, page 1-10
Introduction
78-12541-01
Cisco Content Routers are the content routing elements of a larger,
Cisco Content Delivery Network (CDN) solution, which includes content
switching, content distribution and delivery, content services, and content
management, as well as content routing. The Content Router 4430 (CR-4430) is
deployed at strategic locations within your network and operates in conjunction
with Content Engines to redirect DNS requests to optimal Content Engines based
on network proximity; presence of requested content; current Content Engine
status, including load and availability; and current network conditions,
including load.
Cisco Content Router 4430 Hardware Installation Guide
1-1
System Hardware Features
System Hardware Features
The Content Router 4430 is configured for AC-input power. The default
factory configuration comes with one power supply installed. The
Content Router 4430 has one internal 18-gigabyte (GB) Ultra2 LVD SCSI
hard drive. For network connections, the Content Router 4430 has two
10/100BASE-T Ethernet/Fast Ethernet ports with RJ-45 receptacles.
Port Ethernet 0 supports autodetect speed mode and full-duplex
operation. The second port (Ethernet 1) is currently not supported.
Table 1-1 lists the storage and memory specifications for the
Content Router 4430.
Table 1-1 Storage and Memory Specifications
Specification Description
Internal hard disk storage 1 18-GB Ultra2 LVD SCSI
hard drive
Memory 16-MB Flash memory
Chapter 1 Introducing the Content Router 4430
1-2
1-GB SDRAM
Figure 1-1 shows the Content Router 4430 front panel. Figure 1-2 shows the rear
panel with one AC power supply.
Cisco Content Router 4430 Hardware Installation Guide
78-12541-01
Chapter 1 Introducing the Content Router 4430
LINK
CONS ETHERNET 0
ETHERNET 1
100Mbps
LINK
100Mbps
0
1
2
3
Figure 1-1 Content Router 4430—Front Panel
Power indicator
System indicator
Status LEDs
LINK
100Mbps
LINK
0
1
100Mbps
2
3
CONS
ETHERNET 0
ETHERNET 1
SLOT 0
SCSI LVD ONLY
SLOT 1
SLOT 0
SLOT 1
System Hardware Features
Link LED
100Mbps LED
43905
78-12541-01
Ethernet ports
Console port
Slot 1
Slot 0
Slot 1 LED
Slot 0 LED
SCSI LVD only port
Cisco Content Router 4430 Hardware Installation Guide
1-3
System Hardware Features
Figure 1-2 Content Router 4430—Back Panel
Power switch
Power receptacle
Chapter 1 Introducing the Content Router 4430
33192
Ports, Receptacles, and LEDs
Table 1-2 describes the front and back panel ports and receptacles. (See the front
panel in Figure 1-1 and the back panel in Figure 1-2.)
Table 1-2 Ports and Receptacles
Item Description
Front Panel
CONS port This serial port connects to a console.
ETHERNET 0 port The Ethernet cable connects to this port.
ETHERNET 1 port This port is currently not supported.
SCSI LVD only port This port is not supported on the CR-4430.
Cisco Content Router 4430 Hardware Installation Guide
1-4
78-12541-01
