About the Cisco Unified Videoconferencing 3515 MCU
The Cisco Unified Videoconferencing 3515 MCU enables multimedia, multiparty collaboration in
applications such as group conferencing, distance learning, training and video telephony. The
Cisco Unified Videoconferencing 3515 MCU supports multimedia, multiparty communications in the
board room, at the desktop, in the home, or on the road over wireless.
The Cisco Unified Videoconferencing 3515 MCU provides core IP-centric functionality, a wide range
of layouts, powerful audio and video transcoding, an open API for customer application development,
support of web-initiated data collaboration, and software upgradeable technology. Services are
pre-configured so that they suit most conferencing requirements. However, when necessary,
administrators can create customized services to suit their networks and user needs.
About Cisco Unified Videoconferencing 3515 MCU Users
The Cisco Unified Videoconferencing 3515 MCU provides an intuitive web interface with a single point
of entry for configuring, controlling and monitoring the
unit and conference sessions. Access to the interfaces is password-protected for four types of
users—Administrators, Moderators, Operators and conference users.
Administrators
Administrators use the Administrator interface for configuring, controlling and managing the
Cisco Unified Videoconferencing 3515 MCU, conference services and supporting devices and
applications.
Installation and Upgrade Guide for Cisco Unified Videoconferencing 3515 MCU Release 5.6
OL-17012-01
Cisco Unified Videoconferencing 3515 MCU
1-1
Main Features
Moderators and Operators
Moderators and Operators can use the Conference Control interface for controlling audio, video and data
connections, for selecting advanced conference view image positioning and multiple layouts, and for
creating new conferences and sub-conferences.
Moderators can use the Conference Control interface to view conference details and manage a specific
conference.
Operators have a global view of all current conferences, and can act as Moderators for all current
conferences.
Conference Users
Conference users participate in actual video or audio conferences.
Main Features
Chapter 1 Functionality
Table 1-1 lists the main features provided by the Cisco Unified Videoconferencing 3515 MCU for
effective audio and videoconferencing and a satisfying user experience.
Ta b l e 1-1 Summary of Cisco Unified Videoconferencing 3515 MCU Features
Feature Description
Superior video quality Video and audio processing is carried out per user rather than per
conference. Each user connects using unique, optimized audio and
video settings to enjoy the best audio and video quality supported
by his/her endpoint and network.
Seamless interoperability The Cisco Unified Videoconferencing 3515 MCU is built on the
strong foundation of the Cisco H.323 and SIP software, ensuring
full compliance and unmatched interoperability with IP and ISDN
networks.
The MCU enables H.323, SIP and SCCP devices to participate in
the same conference session.
When used with the Cisco Unified
Intuitive web-based management
and control
Videoconferencing
V.35 devices to participate in the same conference session.
Both the Cisco Unified Videoconferencing 3515 MCU system and
actual conference sessions are managed, configured, and
dynamically modified through an intuitive, web-based interface
that offers easy, high-level conference control and administrative
flexibility for an enhanced user experience.
3500 Gateway, the MCU also enables ISDN and
1-2
Installation and Upgrade Guide for Cisco Unified Videoconferencing 3515 MCU Release 5.6
OL-17012-01
Chapter 1 Functionality
Main Features
Table 1-1 Summary of Cisco Unified Videoconferencing 3515 MCU Features (continued)
Feature Description
Supported protocols • H.323 version 4
• SIP RFC 3261 for the Session Initiation Protocol
• SCCP
• H.243 for conference control
• RFC 2833 for in-band DTMF with SIP
• H.281 for far end camera control (FECC)
• H.235 for IP-based media encryption
• H.239 for standard simultaneous transmission of live video and
presentation sharing feeds.
• SDP (RFC 3264, 2327)
• T.120
• H.320 (when using a gateway)
Note The Cisco Unified Videoconferencing 3515 MCU supports
calls from H.323 and SIP endpoints in the same conference.
Call signalling is handled on all ports regardless of the
protocol type.
Audio transcoding codecs • G.711 A/µ Law
• G.722
• G.722.1
• G.723.1
• G.728
• G.729 A and B
Unmatched video quality The Cisco Unified Videoconferencing 3515 MCU delivers
exceptionally high quality video and audio processing, using the
latest industry standards and leveraging upon advanced
software-upgradeable DSP chips. The Cisco QualiVision feature
provides highly improved, standard-based video quality for
networks with packet loss, assuring best video quality at all times.
The Cisco Unified Videoconferencing 3515 MCU achieves the best
video quality by supporting the following video capabilities:
• High definition and standard definition participants in the same
conference.
• H.261, H.263 and H.264 in the same conference
• A choice of 26 Continuous Presence layouts
• Up to 4 Mbps on each stream (capacity affected)
• QCIF, CIF and 4CIF in the same conference without affecting
capacity
• 720p (capacity affected)
OL-17012-01
• VGA, SVGA, XGA (supported for presentation channel only)
Installation and Upgrade Guide for Cisco Unified Videoconferencing 3515 MCU Release 5.6
1-3
Port Capacities
Chapter 1 Functionality
Table 1-1 Summary of Cisco Unified Videoconferencing 3515 MCU Features (continued)
Feature Description
T.120 Data Collaboration
support
Data collaboration is defined by the T.120 standard. Data
collaboration using T.120 over the video conference connection
enhances the conference by providing the tools for conference
participants to share data instantaneously.
Security and privacy • Administrator and operator password protection for accessing
the Cisco
Unified Videoconferencing 3515 MCU web
interfaces.
• Optional PIN protection for joining a conference and web
access.
• Additional PIN protection for conference Moderator Control.
• The Cisco Unified Videoconferencing 3515 MCU uses
H.235-based encryption to achieve secure communication with
endpoints that support this standard.
In-conference control using
DTMF or H.243
During a conference, participants can use their endpoint remote
control or keypad to perform actions such as mute, volume control,
changing video layouts and inviting participants. Users interact
with the Cisco
Unified Videoconferencing 3515 MCU via DTMF
signaling or the onscreen GUI of H.243-compliant endpoints.
Optional no self-see The administrator can configure the Cisco Unified
Videoconferencing
3515 MCU service to remove the self-view for
each conference participant. This feature enables more effective use
of the video screen.
IVR messages The Cisco Unified Videoconferencing 3515 MCU includes
IVR video messages The IVR mechanism displays video messages that help users dial
Port Capacities
The Cisco Unified Videoconferencing 3515 MCU12 and Cisco Unified
Videoconferencing
The Cisco Unified Videoconferencing 3515 MCU supports Continuous Presence High Definition (CP
HD) services. CP HD services support split-screen (continuous presence) up to 4
resolutions of 1280 x 720 pixels (720p).
Note No self-see display is not available for high definition
participants, even if the no self-see option is enabled.
pre-recorded greetings to conference participants and
announcements as each new participant joins the conference. Using
the Cisco Audio Message Utility, IVR messages can be recorded to
provide custom greetings and announcements.
directly to the MCU IP address for creating or joining conferences
without the need to register to an H.323 gatekeeper or SIP registrar.
3515 MCU24 are delivered with a predetermined number of ports.
Mbps and offer
1-4
Installation and Upgrade Guide for Cisco Unified Videoconferencing 3515 MCU Release 5.6
OL-17012-01
Chapter 1 Functionality
The Cisco Unified Videoconferencing 3515 MCU supports switched High Definition (HD) video
service types. The switched HD service enables Voice Activated single-screen displays at up to 4
and offers resolutions of 1280 x 720 pixels (720p) and 1920 x 1080 pixels (1080p). Switched HD service
types also enable you to set a minimum downspeeding bandwidth rate that is common to all endpoints
participating in a conference.
Cisco Unified Videoconferencing 3515 MCU12 Port Capacity
Cisco Unified Videoconferencing 3515 MCU12 supports a fixed number of ports:
• 72 ports of fully transcoded audio.
• 24 ports of fully processed desktop video (up to 384 Kbps).
• 12 ports of fully processed high rate video of up to 4CIF and up to 2 Mbps (6 ports when using
encryption above 768 Kbps or when using a bit rate above 2 Mbps).
• 4 ports of high definition continuous presence video.
–
Fully transcoded high rate video.
–
Any Continuous Presence layout.
–
All ports are fully video processed.
Port Capacities
Mbps,
–
Any mixture of H.261/H.263/H.264.
–
Mixed QCIF/CIF/4CIF/720p conferences (4CIF is provided with H.263 at 15fps).
–
Unlimited number of conferences of which one can be a high definition conference at any given
time.
Note When using a High Definition Switched Video service type, only a single screen layout is available.
High definition participants must have H.264 only and receive 720p in order to view the conference in
high definition, otherwise the endpoint is considered as a standard definition endpoint.
Cisco Unified Videoconferencing 3515 MCU24 Port Capacity
Cisco Unified Videoconferencing 3515 MCU24 supports a fixed number of ports:
• 72 ports of fully transcoded audio.
• 48 ports of fully processed standard rate video (up to 384 Kbps).
• 24 ports of fully processed high rate video of up to 4CIF (12 ports when using encryption above 768
Kbps or when using a bit rate above 2
• 16 ports of fully processed High Definition Continuous Presence video (8 ports when using
encryption above 768 Kbps or 12 ports when using a bit rate above 2
Mbps).
Mbps).
OL-17012-01
–
Fully transcoded high rate video.
–
Any Continuous Presence layout.
–
All ports are fully video processed.
–
Any mixture of H.261/H.263/H.264.
–
Mixed QCIF/CIF/4CIF/720p conferences (4CIF is provided with H.263 at 15fps).
Installation and Upgrade Guide for Cisco Unified Videoconferencing 3515 MCU Release 5.6
1-5
Chapter 1 Functionality
About Cisco Unified Videoconferencing 3515 MCU Architecture
–
Unlimited number of conferences of which one can be high definition conferences at any given
time.
Note When using a High Definition Switched Video service type, only a single screen layout is available.
High definition participants must have H.264 only and receive 720p in order to view the conference in
high definition, otherwise the endpoint is considered as a standard definition endpoint.
About Cisco Unified Videoconferencing 3515 MCU Architecture
The Cisco Unified Videoconferencing 3515 MCU enables both voice-only and video conference calls
for H.323, SIP, H.320, SCCP and regular PSTN network telephones. H.323 and SIP devices can connect
to a conference directly through the
as voice telephones and video conferencing terminals (H.320) can connect to a conference via a gateway,
such as the
Cisco Unified Videoconferencing 3500 Gateway.
Cisco Unified Videoconferencing 3515 MCU. Other devices such
Figure 1-1 Supported Devices and Protocols
IP - H323 and SCCP MCU, Gateway ISDN - H323.
IP
3G - H324.MSIP
204600
The Cisco Unified Videoconferencing 3515 MCU supports devices that can send and receive video
streams, as well as those that cannot send but only receive video streams. This means that terminals
without a video camera or video capturing capabilities can participate in a conference as voice-only
participants while benefiting from seeing the other participants.
1-6
Installation and Upgrade Guide for Cisco Unified Videoconferencing 3515 MCU Release 5.6
OL-17012-01
Chapter 1 Functionality
200844
MCU
Site 1 Site 2
Headquarters
MCU
MCU
About Cisco Unified Videoconferencing 3515 MCU Topologies
About Cisco Unified Videoconferencing 3515 MCU Topologies
The Cisco Unified Videoconferencing 3515 MCU can work in a centralized or cascaded topology. This
section describes these two options.
Centralized Topology
In a centralized topology, the Cisco Unified Videoconferencing 3515 MCU performs media processing
for all connected terminals. The
conferences simultaneously.
Figure 1-2 Centralized Topology
Cisco Unified Videoconferencing 3515 MCU can handle multiple
Cascaded Conferences
The Cisco Unified Videoconferencing 3515 MCU allows you to combine two or more conferences
resulting in a larger conference with many more participants. This is called cascading. Cascading creates
a distributed environment that helps reduce the drain on network resources. In addition, the processing
resources required by the
participating MCUs. Costly telephone or ISDN line usage can be further reduced with the mediation of
a gateway.
OL-17012-01
Cascading occurs when one conference with “x” number of participants invites another conference with
“y” number of participants. The two conferences effectively become one large conference. The
bandwidth required across a cascaded conference link is only that of one audio/video stream between
the two conferences. This is significantly less than the accumulated bandwidth of all the participants.
Each separate
control of its individual conference resources and participants.
Cisco Unified Videoconferencing 3515 MCU unit participating in a conference retains
Cisco Unified Videoconferencing 3515 MCU are distributed between
Installation and Upgrade Guide for Cisco Unified Videoconferencing 3515 MCU Release 5.6
1-7
About Cisco Unified Videoconferencing 3515 MCU Topologies
200845
MCU
Site 1 Site 2
Headquarters
MCU MCU
The cascaded conference in Figure 1-3 minimizes the use of network bandwidth while distributing
processing among the participating the Cisco Unified Videoconferencing 3515 MCU units.
Figure 1-3 Cascaded Conference
Chapter 1 Functionality
Installation and Upgrade Guide for Cisco Unified Videoconferencing 3515 MCU Release 5.6
1-8
OL-17012-01
CHAP T ER
2
Setting Up Your Cisco Unified Videoconferencing 3515 MCU
• Physical Description, page 2-1
• Verifying the Package Contents, page 2-2
• Mounting the Cisco Unified Videoconferencing 3515 MCU Unit in a 19-inch Rack, page 2-3
• How to Perform the Cisco Unified Videoconferencing 3515 MCU Unit Initial Configuration,
page 2-4
• How to Perform the Video Processing Module Initial Configuration, page 2-8
• About Managing and Monitoring the Cisco Unified Videoconferencing 3515 MCU Unit, page 2-13
• Accessing the Cisco Unified Videoconferencing 3515 MCU Administrator Interface, page 2-13
• Registering the Online Help for the 3515 MCU, page 2-15
Physical Description
Each Cisco Unified Videoconferencing 3515 MCU unit internally contains two cards:
• Signaling and audio card (MCU—the upper card)
• Video processing card (EMP—the lower card)
The two cards work together to perform audio and videoconferencing, but each card requires a unique
IP address. The cards communicate with each other using IP as the backbone.
Note For correct operation, the EMP card must register with the MCU.
This section provides a physical description of the Cisco Unified Videoconferencing 3515 MCU12 and
Cisco
Unified Videoconferencing 3515 MCU24 units.
The Cisco Unified Videoconferencing 3515 MCU unit has a 10/100BaseT Ethernet port on the front
panel that uses an RJ-45 connector to connect to the network. There is an asynchronous, 9-pin serial-port
that you can use with a hyperterminal program to configure and monitor the module.
Figure 2-1 shows the front panel of the Cisco Unified Videoconferencing 3515 MCU unit. Ta b le 2-1
describes the components of the front panel.
OL-17012-01
Installation and Upgrade Guide for Cisco Unified Videoconferencing 3515 MCU Release 5.6
2-1
Verifying the Package Contents
10/100 Base T
SERIAL
RST
ACTALARM
CPU HightGK Reg
157265
10/100 Base T
SERIAL
RST
ACTALARM
CPU HightMC
PWR
Figure 2-1 Cisco Unified Videoconferencing 3515 MCU Front Panel
Ta b l e 2-1 Front Panel Components
Component Description
10/100 BaseT connector An RJ-45 connector that provides the primary Ethernet connection
Serial connector A DB-9 connector that allows you to connect a PC terminal for local
RST button Allows you to reset the Cisco Unified
GK Reg and MC LEDs Lights green when the Cisco Unified
CPU High LED Lights green when more than 50% of the Cisco Unified
ACT LED Lights green to indicate that there is at least one currently active
ALARM LED Lights green to indicate that an error has occurred and the
10/100 BaseT LEDs The top part of the 10/100 BaseT connector contains two LED
Chapter 2 Setting Up Your Cisco Unified Videoconferencing 3515 MCU
for the IP network port.
configuration.
Videoconferencing
Videoconferencing
3515 MCU unit manually.
3515 MCU is registered with a gatekeeper, or
when there is no gatekeeper registered and the auto attendant feature
is enabled.
Videoconferencing
conference on the Cisco
3515 MCU unit resources are in use.
Unified Videoconferencing 3515 MCU
unit.
Cisco
Unified Videoconferencing 3515 MCU unit requires
resetting.
indicators. The left-hand LED lights green when the local IP
network link is active. The right-hand LED lights green if the
connection speed is 100 Mbps, and is off when the connection speed
is 10
Mbps.
Verifying the Package Contents
Procedure
Step 1 Inspect the contents of the box for shipping damage.
Step 2 Report any damage or missing items to your Cisco representative.
Step 3 Verify the package contents for the Cisco Unified Videoconferencing 3515 MCU unit. See Table 2-2.
2-2
Installation and Upgrade Guide for Cisco Unified Videoconferencing 3515 MCU Release 5.6
OL-17012-01
Loading...
