Cisco Systems 3032, 3130 User Manual

Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Getting Started Guide
Also covered in this guide are switch management options and troubleshooting help for the switch.
For details on the number, types, and the location of the module bays and for additional information on the entire modular server system, see the documentation for the Dell PowerEdge Systems at www.support.dell.com.
For additional installation and configuration information about the switch, see the Cisco Catalyst Blade Switch 3000 Series for Dell documentation on Cisco.com. For system requirements, important notes, limitations, open and resolved caveats, and last-minute documentation updates about the switch, see the release notes, also on Cisco.com.
When you use the online publications, refer to the documents that match the Cisco IOS software version that is running on the switch.
Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Getting Started Guide
OL-14317-01
1

Contents

Note Before proceeding, read the release notes for the server chassis. The release notes
Contents
Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Getting Started Guide
For translations of the warnings that appear in this publication, see the Regulatory Compliance and Safety Information for the Cisco Catalyst Blade Switch 3000 Series for Dell that accompanies this guide.
are available on the Dell support website at www.support.dell.com.
• Taking Out What You Need, page 3
• Switch Description, page 3
• Dell Modular Server Chassis Architecture, page 6
• Installation Warning Statements, page 7
• Installing the Switch in the Server Chassis, page 8
• Configuring the Switch, page 12
• Managing the Switch, page 20
• Planning and Creating a Switch Stack (Only 3130G-S and 3130X-S
Switches), page 22
• Connecting to the Switch Ports, page 26
• In Case of Difficulty, page 28
• Obtaining Documentation, Obtaining Support, and Security Guidelines,
page 30
• Hardware Warranty Terms, page 31
Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Getting Started Guide
2
OL-14317-01
Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Getting Started Guide

Taking Out What You Need

Taking Out What You Need
These items ship with your switch:
A
17X
STK
B
Documentation
CD
Documentation
Product
Follow these steps:
1. Unpack and remove the switch and the accessory kit from the shipping box.
2. Return the packing material to the shipping container, and save it for
future use.
19X
X2-1
18X
21
22
20X
X2-2
23
24
S
Y
S
S
T
C
M
S
T
M
M
B
WS-CBS3130X-S
T
K
R
MODE
R
CONSOLE
250289
Note If you order the switches with the server chassis, the switches are already
installed, and no unpacking is required. The unpacking procedure applies only if you order a switch.

Switch Description

These are the available switch models:
Model Description
CBS3032G 1-Gigabit Ethernet nonstacking-capable switch
CBS3130G-S 1-Gigabit Ethernet stacking-capable switch
CBS3130X-S 10-Gigabit Ethernet stacking-capable switch
Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Getting Started Guide
OL-14317-01
3
Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Getting Started Guide
Switch Description
The switch runs the universal software image that has the Cisco IOS code for multiple feature sets. To enable a specific feature set, you must use the software activation feature to install the software license for that feature set. For more information, see the Cisco Software Activation Document for Dell, the release notes, and the software configuration guide on Cisco.com.
Figure 1 shows the Cisco Catalyst Blade Switch 3130 for Dell as an example.
The other switch models have similar components.
Figure 1 Switch Front Panel
1
1
17X
STK
2
18X
2
19X
X2-1
21
X2-2
22
20X
3
4
5
23
24
6
7
8
9
S
Y
S
T
S
T
C
K
M
S
T
R
M
M
B
R
WS-CBS3130X-S
11
MODE
CONSOLE
12
10
13
1 Switch 8 Release latch
2 StackWise Plus ports A and B (supported
9 Cisco status LEDs
only on the 3130G-S and 3130X-S switches)
3 Gigabit Ethernet uplink ports 17 to 20 10 System Status/ID LED
4 LEDs for ports 21 and 22 11 Mode button
5 10-Gigabit Ethernet slot 1
12 Console port
or Gigabit Ethernet ports 21 and 22
6 LEDs for ports 23 and 24 13 Power LED
7 10-Gigabit Ethernet slot 2
or Gigabit Ethernet ports 23 and 24
250198
For more information about the LEDs and their meanings, see the switch hardware installation guide on Cisco.com.
Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Getting Started Guide
4
OL-14317-01
Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Getting Started Guide
Switch Description
Table 1 describes the switch ports.
Table 1 Cisco Catalyst Blade Switch 3130 for Dell and 3032 for Dell Port Descriptions
Port Description
Ports 1 to 16 Internal Gigabit Ethernet 1000BASE-X downlink ports that connect the switch
to the server chassis blades.
Ports 17 to 20 External 10/100/1000BASE-T copper Gigabit Ethernet uplink ports that support
auto-MDIX, and autonegotiation.
Ports 21 to 24 10-Gigabit Ethernet module slots for use with the Cisco TwinGig Converter
Modules and Cisco X2 transceiver modules.
Internal 100BASE-T Ethernet port
Console port Switch management serial port that uses an RJ-45 connector.
StackWise Plus ports
The internal 100BASE-T Ethernet port (Fa0) is used only for switch management traffic, not for data traffic. It is connected to the Dell management console through the server chassis backplane connector. Traffic to and from this port is isolated from the switch ports.
Stacking cable ports (supported only on the 3130G-S and 3130X-S switches).
Each port has an associated LED. The System Status/ID LED is controlled by the Dell Remote Access Controller/Modular Chassis (DRAC/MC) management board.
For a list of supported modules, see the release notes on Cisco.com. For detailed instructions on installing, removing, and connecting to SFP modules, see the documentation that came with the SFP module.
Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Getting Started Guide
OL-14317-01
5
Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Getting Started Guide

Dell Modular Server Chassis Architecture

Dell Modular Server Chassis Architecture
The six chassis I/O module bays are on the rear panel (see Figure 2).
Figure 2 Dell Modular Server Chassis Rear Panel
2
1
!
3
4
5
!
STK
B
A
18X
17X
6
!
7
8
9
10
!
!
20X
19X
22
21 X2-1
!
!
24
23 X2-2
W
S
-
C
B
S
313
0X
-S
!
M
M
S
S
M
S
T
Y
B
T
C
S
R
R
K
T
M
O
D
E
C
O
N
S
O
L
E
!
!
!
!
!
!
!
!
!
11
!
!
12
!
250199
Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Getting Started Guide
6
OL-14317-01
Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Getting Started Guide

Installation Warning Statements

1 Dell server chassis 7 I/O module C2
2 Primary CMC
1
module
8 I/O module B2
3 Switch installed in I/O module A1 9 I/O module A2
4 I/O module B1 10 Secondary CMC module
2
5 I/O module C1 11 Fan modules
6 Optional iKVM
1. CMC: Chassis Management Controller.
2. This module is optional.
3. iKVM: integrated keyboard video mouse.
3
module
12 Power supplies
For more information about the components of the information panel, see the Dell documentation at www.support.dell.com.
Installation Warning Statements
This section includes the basic installation warning statements. Translations of these warning statements appear in the Regulatory Compliance and Safety Information for the Cisco Catalyst Blade Switch 3000 Series for Dell document that shipped with the switch.
Warning
Warning
Warning
Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Getting Started Guide
OL-14317-01
To prevent the switch from overheating, do not operate it in an area that exceeds the maximum recommended ambient temperature of 113°F (45°C). To prevent airflow restriction, allow at least 3 inches (7.6 cm) of clearance around the ventilation openings.
Class 1 laser product.
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 17B
Statement 1008
Statement 1030
7
Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Getting Started Guide

Installing the Switch in the Server Chassis

Warning
Warning
Warning
Ultimate disposal of this product should be handled according to all national laws and regulations.
For connections outside the building where the equipment is installed, the following ports must be connected through an approved network termination unit with integral circuit protection: 10/100/1000 Ethernet.
Installation of the equipment must comply with local and national electrical codes.
Statement 1074
Statement 1040
Statement 1044
Installing the Switch in the Server Chassis
Before you install the switch in the server chassis, consider these points:
• Review and become familiar with the safety and handling guidelines
specified in the Product Information Guide.
• Review the Regulatory Compliance and Safety Information for the Cisco
Catalyst Blade Switch 3000 Series for Dell that ships with this product.
• If you plan to create a switch stack, review the “Planning and Creating a
Switch Stack (Only 3130G-S and 3130X-S Switches)” section on page 22
before you install the switch and run the initial configuration setup program.
• To help ensure proper cooling and system reliability, keep these points
in mind:
–
Each chassis I/O module bay must contain either a module or an input/output module (IOM) blank.
–
When you remove a hot-swap module, you must replace it with an identical module or an IOM blank within 1 minute of removal.
Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Getting Started Guide
8
OL-14317-01
Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Getting Started Guide
Installing the Switch in the Server Chassis
–
You can install the switch into any of the module slots. If you install a switch in the B or C module slot, the Ethernet mezzanine card must be installed in the blade server.
–
The dust covers should always remain in place unless a module is installed in the slot.
Caution To prevent electrostatic-discharge (ESD) damage when you install the switch,
follow your normal board and component handling procedures.
Note When you install a switch, you do not need to power down the server chassis.
The initial configuration assumes that the switch was never configured, that it is in the same state as when it was received, and that it is not configured with a default username and password.
Follow these steps to install the switch into the server chassis:
Step 1 Obtain and make note of this information from your network administrator before
you begin the switch installation:
• Switch IP address
• Subnet mask (IP netmask)
• Default gateway (router)
• Enable secret password (encrypted)
• Enable password (not encrypted)
• Telnet password
• SNMP community strings (optional)
Step 2 Select a chassis I/O module bay in which to install the switch. Follow the
prerequisites listed in the “Dell Modular Server Chassis Architecture” section on
page 6.
Step 3 Remove the IOM blank from the selected bay, and store it for future use.
Step 4 If you have not already done so, touch the static-protective package that contains
the switch to an unpainted metal part of the server chassis for at least 2 seconds.
Step 5 Remove the switch from its static-protective package.
Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Getting Started Guide
OL-14317-01
9
Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Getting Started Guide
Installing the Switch in the Server Chassis
Step 6 Ensure that the release latch on the switch is in the open position or perpendicular
to the module (see Figure 3):
Figure 3 Release Latch in Open Position
STK
B
A
18X
17X
20X
19X
22
21 X2-1
24
23
X2-2
10
WS-CBS
3130X-S
M
M
S
S
M
S
T
Y
B
T
C
S
R
R
K
T
M
O
D
E
C
O
N
S
O
LE
250200
Step 7
Slide the switch into the appropriate bay until it stops.
Step 8 Push the release latch on the front of the switch to the closed position.
Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Getting Started Guide
OL-14317-01
Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Getting Started Guide
Installing the Switch in the Server Chassis
Figure 4 shows the switch being inserted into the server chassis.
Figure 4 Inserting the Switch into the Server Chassis
2
!
!
STK
B
A
1
3
18X
17X
20X
19X
22
21 X2-1
24
23 X2-2
WS-C
BS3130X-S
M
M
S
S
M
S
T
Y
B
T
C
S
R
R
K
T
M
O
D
E
C
O
N
S
O
LE
!
!
!
!
!
!
!
!
!
!
!
!
!
!
1 Switch 3 Release latch
2 Server chassis
Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Getting Started Guide
OL-14317-01
!
250201
11
