Catler SB 4010 User Manual
Instruction manual
CONTROL GRIP
CONTROL GRIP
CONTROL
GRIP
CONTENTS
2 Congratulations
3 Catler recommends safety rst
6 Know your Control Grip SB 4010
8 Operating your Control Grip SB 4010
15 Care and Cleaning
R2 Recipes
CONTENTS
1
Congratulations
on the purchase of your new Catler Control Grip SB 4010.
2
2
CATLER RECOMMENDS SAFETY FIRST
CONGRATULATIONS
CATLER RECOMMENDS SAFETY FIRST
We at Catler are very safety conscious. We design and manufacture consumer products with
the safety of you, our valued customer foremost in mind. In addition we ask that you exercise
a degree of care when using any electrical appliance and adhere to the following precautions:
IMPORTANT SAFEGUARD FOR YOUR CONTROL GRIP SB 4010
•
Carefully read all instructions before
operation and save for future reference.
•
Remove and safely discard any packaging
material and promotional labels before
using the appliance for the rst time.
•
To eliminate a choking hazard for young
children, remove and safely discard the
protective cover tted to the power plug
of the appliance.
•
Use this appliance ONLY for the purposes
that it has been intended for and how it is
described in this manual. This appliance
has been designed exclusively for
household use and contructed to process
of normal amount of food in household.
•
Do not place the appliance near the edge
of a bench or table during operation. Use
the appliance only on level surface, free of
water.
•
Ensure that the surface is clean, level, and
free of water.
•
Do not place the appliance on or near a
hot gas burner, electric element or where
it could touch a heated oven.
•
Do not operate the appliance on a sink
drain board.
•
This appliance is not intended to be
operated by means of an external timer or
separate remote control system.
•
Do not use sprays near the appliance.
•
Before you connect the appliance into
the power outlet make sure the voltage
on the rating label corresponds to the
voltage in your power outlet.
•
Always make sure the appliance is
completely and properly assembled
before operating, mainly the blending leg.
Follow the instructions in the manual.
•
Ensure the appliance is turned o and
the power is switche d o at the power
outlet before attempting to assemble or
disassemble.
•
Do not run the appliance unless it is
correctly and properly assembled. Do not
run an empty appliance. Incorrect using of
the appliance can negatively in uence its
life.
•
Handle the appliance and the accessories
with care – remember the blades are very
sharp and should be kept out of reach of
children.
•
Never use the appliance to process food
on a hot stove or gas burner. Always
remove the saucepan from the heat
source and ensure the power cord and
the appliance are also kept away from any
heat source.
•
Use the appliance as decribed in this
manual.
•
Use the whisk attachment only for
the recipes which require the whisk
attachment usage. Do not use the whisk
attachment any other purposes than it is
intended for.
•
Do not process hot or boiling liquids in
the chopper / mixing bowl. Allow liquids
to cool before placing into the bowl.
•
Insert only food for mixing into the
chopper / mixing bowl.
•
Allow the hot food to cool down to the
temperature of 60°C at least.
•
Do not operate the appliance
continuously for more than 1 minute.
After 1 minute, turn o the appliance and
allow the motor to rest for 1 minute at
least.
CATLER RECOMMENDS SAFETY FIRST
3
•
When processing dry, thick or heavy
mixtures, interrupt the process after 30
seconds. Stir the ingredients and allow the
motor to rest for 1 minute at least.
•
Recipes in the manual are considered as
common food amount in household.
•
If food becomes lodged around the
processing blade, turn o the appliance
by releasing the main switch and
disconnect the power cord from the
power outlet. Use a spatula, or plastic
knife, to dislodge the food. In no cases
use your ngers to dislodge the food. The
blades are very sharp.
•
Do not insert your hand into the mixing
bowl if the appliance is in process.
•
Do not remove the appliance from the
mixing mixture during operation. Turn
o the appliance at rst, disconnect the
power cord from the power outlet and
wait until the blades stop turning. Then
you can revome the appliance from the
mixing mixture.
•
Do not leave the appliance unattended
when in use.
•
Do not use the appliance with wet hands.
•
Always ensure the appliance has been
turn o before attempting to move the
appliance, when the appliance is not in
use and before cleaning and storing. Then
you can unplug the appliance from the
power outlet.
•
If you do not use the appliance for a
long time or you attempt to leave it
unattended, unplug the appliance from
the power outlet.
•
Do not disconnect the appliance from the
power point by pulling the electric cable
– it may damage the electric cable/power
point. Disconnect the cable from the
power point by gently pulling the plug of
the electric cable.
•
The appliance is not intended for use by
young children or in rm persons unless
they have been adequately supervised by
a responsible person to ensure they can
use the appliance safely.
•
Use only supplied accessories or
recommended accessories by a
manufacturer. Otherwise it may result in
re, electric shock or injury to persons.
•
Keep the appliance clean. Follow the
cleaning instructions provided in Care and
Cleaning chapter.
4
CATLER RECOMMENDS SAFETY FIRST
CAUTION: HOUSEHOLD USE ONLY. READ INSTRUCTIONS BEFORE USE. DO
NOT IMMERSE IN ANY LIQUID.
TO PROTECT AGAINST ELECTRIC SHOCK DO NOT IMMERSE THE MOTOR
BODY, POWER CORD OR POWER PLUD IN WATER OR ANY OTHER LIQUID
OR DO NOT ALLOW MOISTURE TO COME IN CONTACT WITH THESE PARTS.
DO NOT WASH THE POWER BASE UNDER RUNNING WATER.
IMPORTANT SAFEGUARD FOR ALL
ELECTRICAL APPLIANCES
•
This appliance is for household use only.
•
Unwind the cord fully before use.
•
Do not let the cord hang over the edge of
a table or counter, touch hot surfaces or
become knotted.
•
This appliance is not intended for use by
persons (including children) with reduces
physical, sensory or mental capabilities
or lack of experience and knowledge,
unless they have been given supervision
or instruction concerning use of the
appliance by a person responsible for
their safety.
•
Children should be supervised to ensure
that they do not play with this appliance.
•
It is recommended to inspect the
appliance regularly. Do not use the
appliance if power supply cord, plug or
appliance becomes damaged in any way.
Return the entire appliance to the nearest
authorised Catler Service Centre for
examination and/or repair.
•
Any maintenance other than cleaning
should be performed at an authorised
Catler Service Centre.
•
Do not use this appliance for other than
its intended use. Do not use in moving
vehicles or boats. Do not use outdoors.
•
The installation of a residual current
device (safety switch) is recommended to
provide additional safety protection when
using electrical appliances. It is advisable
that a safety switch with a rated residual
operating current not exceeding 30mA be
installed in the electrical circuit supplying
the appliance. See your electrician for
professional advice.
•
For the security reasons, we recommend
to plug the appliance directly to its own
circuit, separate from other appliances.
It is not recommended using hub or
extension cord.
This symbol points out that the
device has double insulation
between the dangerous mains
voltage and the parts accessible to
the user. In the case of servicing use
only identical spare parts.
DO NOT OPERATE THE APPLIANCE ON AN INCLINED SURFACE. DO NOT MOVE
THE APPLIANCE WHILE IT IS SWITCHED ON.
THE POWER PLUG WHEN PLUGGED MUST REMAIN ACCESSIBLE FOR EASY
REMOVING.
THE BLADES ARE VERY SHARP. PAY YOUR OWN ATTENTION WHEN HANDLING
WITH BLADES.
CATLER RECOMMENDS SAFETY FIRST
5
KNOW YOUR CONTROL GRIP SB 4010
Speed Control Dial
Turn the dial uently anticlockwise to increase
the speed. Turn the dial uently clockwise to
reduce the speed.
Main Switch
Located in ergonomic handle; press and
hold the switch to operate the appliance.
700W Motor Unit
With ergonomic handle
Attach/Detach Buttons
6
KNOW YOUR CONTROL GRIP SB 4010
Detachable Blending Attachement with
doubled blade
Unique enlarged design of blade protective
part ensures equal and proper food
processing.
Chopper Bowl Lid with Gear
easy attachment of motor unit
Chopper Bowl
750ml measuring bowl
Chopping Doubled Blade
Double Purpose Storage Lid and Anti-Slip
Mat
intelligent opening system. Lid can be used
as an anti-slip mat at the same time.
1,2l Blending Jug
measuring jug with a funnel for easy
pouring of mixture.
Gear Box
allows easy and comfortable attaching and
operating of a whisk.
Whisk
Unique whisk design ensures proper whip
of ingredients.
KNOW YOUR CONTROL GRIP SB 4010
7
