Catler RC 4010 User Manual

Instruction Booklet

uctio

ooklet

EF

U

F

0

Instr

n B

MULTI CH

MULTI CHEF

MULTI CHEF

M

LTI CHE

RC 4010

RC 401

MULTI CHEF

CONTENTS

2 Congratulations

3 Catler recommends safety  rst

7 Know your Multi Chef RC 4010

8 Operating your Multi Chef RC 4010

8 How to make risotto

9 How to make rice

11 How to slow cook

13 Rice cooking tables

14 Rice variations

15 Steaming foods

19 Care and cleaning

20 Troubleshooting

21 Recipes

CONTENTS

1

Congratulations

on the purchase of your new Multi Chef RC 4010.

2

CONGRATULATIONS

CATLER RECOMMENDS SAFETY FIRST

At Catler we are very safety conscious. We design and manufacture consumer products with
the safety of you, our valued customer, foremost in mind. In addition we ask that you exercise
adegree of care when using any electrical appliance and adhere to the following precautions.

IMPORTANT SAFEGUARDS
READ ALL INSTRUCTIONS BEFORE USE AND SAVE FOR FUTURE REFERENCE

• Remove and safely discard any packaging
material and promotional labels before
using the appliance for the  rst time.

• To eliminate achoking hazard for young
children, remove and safely discard the
protective cover  tted to the power plug
of this multi cooker.

• Do not place the multi cooker near
the edge of abench or table during
operation. Ensure that the surface is
level, clean and free of water and other
substances.

• Position the lid so that the steam vent is
directed away from you. Lift and remove
the lid carefully to avoid scalding from
escaping steam.

• Always ensure the multi cooker is
properly assembled before use. Follow
the instructions provided in this book.

• Always operate the multi cooker on
astable and heat resistant surface.

• Use the removable cooking bowl
supplied with the multi cooker. Do not
use any other bowl inside the multi
cooker housing.

• Do not use adamaged or dented
removable cooking bowl. If damaged or
dented, replace bowl before using.

• Do not operate the multi cooker on asink
drain board.

• Do not place anything on top of the lid
when assembled, when in use and when
stored.

• Do not touch hot surfaces. Use the handle
for lifting and carrying the multi cooker.

• Do not use chemicals, steel wool, metal
scouring pad or abrasive cleaners to
clean the outside of the multi cooker
housing or cooking bowl as these can
damaged the housing or the coating of
the cooking bowl.

• Keep the multi cooker clean. Follow the
cleaning instructions provided in this
book.

• Never plug in or switch on the multi
cooker without having the removable
cooking bowl placed inside the multi
cooker housing.

• Do not place food or liquid in the multi
cooker housing. Only the removable
cooking bowl is designed to contain food
or liquid.

• Never operate the multi cooker without
food and liquid in the removable cooking
bowl.

• Do not touch hot surfaces, use oven
mitts to remove the lid and or removable
cooking bowl. Lift and remove the lid
carefully and away from yourself to avoid
scalding from escaping steam.

• Do not allow water from the lid to drip
into the multi cooker housing, only into
the removable cooking bowl.

• Do not leave the multi cooker
unattended when in use.

• Extreme caution must be used when
the multi cooker contains hot food and
liquids. Do not move the appliance
during cooking.

CATLER RECOMMENDS SAFETY FIRST

3

• The temperature of accessible surfaces
will be high when the multi cooker is
operating and for some time after use

• Do not place anything, other than the
lid, on top of the multi cooker when
assembled, when in use and when stored.

• Always insert the connector end of the
power cord into the appliance inlet
before inserting power plug into the
power outlet and switching on appliance.

Ensure the appliance inlet is completely

dry before inserting the connector end of
the power cord.

• To prevent scratching the non-stick
surface of the removable cooking bowl,
always use wooded or plastic utensils.

• Always position steam vent on lid away
from yourself to avoid scalding from
escaping steam.

• Ensure the removable cooking bowl is
correctly positioned in the multi cooker
base before you commence cooking.

• The appliance connector must be
removed before the multi cooker is
cleaned and that the appliance inlet must
be dried before the multi cooker is used
again.

• To prevent damage to the multi cooker
do not use alkaline cleaning agents
when cleaning, use asoft cloth and mild
detergent.

• Always have the glass lid placed
correctly into position on the appliance
throughout operation of the appliance
unless states in the recipe to have it
removed.

• The glass lid has been specially treated to
make it stronger, more durable and safer
than ordinary glass, however it is not
unbreakable. If struck extremely hard, it
may break or weaken, and could at alater
time shatter into many small pieces
without apparent cause.

4

CATLER RECOMMENDS SAFETY FIRST

DO NOT USE THIS APPLIANCE WITH PROGRAMMER, TIMER OR ANY
OTHER APPLIANCE THAT IS ENABLE TO SWITCH ON THE APPLIANCE
AUTOMATICALLY.

USE ONLY THE ACCESSORIES SUPPLIED OR INTENDED TO BE USED
WITHTHIS APPLIANCE.

IMPORTANT SAFEGUARDS FOR ALL
ELECTRICAL APPLIANCES

• Fully unwind the power cord before use.

• Connect only to 230V or 240V power
outlet.

• Do not let the power cord hang over
the edge of abench or table, touch hot
surfaces or become knotted.

• To protect against electric shock, do not
immerse the power cord, power plug or
appliance in water or any other liquid or
allow moisture to come in contact with
the part, unless it is recommended in the
cleaning instructions.

• The appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning use
of the appliance by aperson responsible
for their safety.

• Children should be supervised to ensure
that they do not play with the appliance.

• It is recommended to regularly inspect
the appliance. To avoid ahazard, do not
use the appliance if power cord, power
plug or appliance becomes damaged
in any way. Return the entire appliance
to the nearest authorized Catler service
centre for examination and/or repair.

• Any maintenance other than cleaning
should be performed at an authorised
Catler Service Centre.

• This appliance is for household use only.
Do not use this appliance for anything

other than its intended use. Do not use
in moving vehicles or boats. Do not use
outdoors. Misuse may cause injury.

• The installation of aresidual current
device (safety switch) is recommended
to provide additional safety protection
when using electrical appliances. It is
advisable that asafety switch with arated
residual operating current not exceeding
30mA be installed in the electrical
circuit supplying the appliance. See your
electrician for professional advice.

• Always turn the appliance to the OFF
position, switch o at the power outlet
and unplug at the power outlet when the
appliance is not in use.

• Before cleaning, always turn the
appliance to the OFF position, switch o
at the power outlet, unplug at the power
outlet and remove the power cord, if
detachable, from the appliance and allow
all parts to cool.

• Do not place this appliance on or near
aheat source, such as hot plate, oven or
heaters.

• Position the appliance at aminimum
distance of 20cm away from walls,
curtains and other heat or steam
sensitive materials and provide adequate
space above and on all sides for air
circulation.

FULLY UNWIND THE CORD BEFORE USE.
DO NOT OPERATE THE APPLIANCE ON AN INCLINED SURFACE.
DO NOT MOVE THE APPLIANCE WHILE IT IS SWITCHED ON.
THE POWER PLUG WHEN PLUGGED MUST REMAIN ACCESSIBLE FOR EASY
REMOVING.
ENSURE THE APPLIANCE IS FULLY COOLED BEFORE CLEANING AND STORING.

SAVE THESE INSTRUCTIONS

CATLER RECOMMENDS SAFETY FIRST

5

BEFORE STARTING TO COOK, CLEAN THE BOTTOM OF THE INNER POT
AND THE SURFACE OF THE HEATING PLATE.

TO ENSURE THE POT IS SITTING FLAT ON THE HEATING PLATE, TURN THE
POT CLOCKWISE AND ANTI CLOCKWISE INSIDE THE RICE COOKER.

THE POT MUST BE PROPERLY POSITIONED INSIDE THE RICE COOKER OR
THE UNIT WILL NOT WORK AND MAY BECOME DAMAGED.

6

CATLER RECOMMENDS SAFETY FIRST

WARNING
FOR HOUSEHOLD USE ONLY.
DO NOT IMMERSE IN WATER.

FULLY UNWIND THE CORD BEFORE USE.
SAFE THESE INSTRUCTIONS.

KNOW YOUR MULTI CHEF RC 4010

A. Tempered domed glass lid

With steam vent. Dishwasher safe.
B. Removable non-stick cooking bowl
Prevents risotto and rice from sticking.

C. Cool-touch handles
D. Removable power cord (not shown)

For convenient serving at the table and

storage.

E. RISOTTO setting
F. SAUTÉ|SEAR setting
G. RICE|STEAM setting

Large 10 scoop capacity cooks up to

20scoops of cooked rice.

H. LOW SLOW COOK setting
Gently simmers food for an extended

period of time.

I. HIGH SLOW COOK setting

Simmers food quicker for when time is

aconstraint.

J. KEEP WARM

Automatically switches on after each

setting (except sauté).

K. START|CANCEL button
L. Stainless steel steaming tray

Ideal for vegetables, seafood and poultry.

M. Rice scoop and serving spoon

KNOW YOUR MULTI CHEF RC 4010

7

OPERATING YOUR MULTI CHEF RC 4010

BEFORE FIRST USE

Before  rst use, remove all packaging material and promotional labels and wash the non-stick
removable cooking bowl, stainless steel steaming tray and glass lid in hot soapy water, rinse
and dry thoroughly.

HOW TO MAKE RISOTTO

SAUTÉ|SEAR setting

1. Ensure exterior of the removable cooking
bowl is clean before placing it in the
housing (this will ensure proper contact
with the inner cooking surface).

2. Plug power cord into a230V or 240V
power outlet. The START|CANCEL button
and RISOTTO button surround will
illuminate in white.

3. Press the SAUTÉ|SEAR button, the button
surround will illuminate in white.

Press the START|CANCEL button to

activate the setting, the button surround
will illuminate red.

4. Cover with lid and allow to pre-heat
for approximately 2-3 minutes (do not
preheat for longer than 5 minutes).

5. Add oil/butter and allow to heat/melt for
approximately 1 minute.

6. If using chicken or seafood in the recipe,
sear in small batches, cover with lid and
stir occasionally until food is cooked.

Remove from cooking bowl.

7. Add extra oil/butter to cooking bowl if
necessary or if recipe states. Allow to heat
for approximately 1 minute.

8. Add ingredients such as onions and
garlic. Sauté, cover with lid if necessary
and stir occasionally for about 4 to
5 minutes or until cooked to desired
brownness.

9. Stir in Arborio or carnaroli rice and
mix well. Sauté for approximately 2-3
minutes, stirring occasionally.

10. Pour in wine (if using) and cook
uncovered until rice has absorbed all
liquid and alcohol has evaporated,
stirring frequently.

11. Press the START|CANCEL button to stop
the SAUTÉ|SEAR setting.

12. Refer to step 1 in the RISOTTO setting
section below.

RISOTTO Setting

1. Follow steps 1-11 in the SAUTÉ|SEAR
setting section above.

2. Add stock or water and stir well. Cover
with lid and press the RISOTTO button,
then press the START|CANCEL button to
activate the setting. The START|CANCEL
button surround will illuminate red and
cooking will commence.

3. Allow to cook until the ready beeps
sound and the multi cooker automatically
switches to the KEEP WARM setting. This
will take approximately 20-30 minutes
depending on the recipe.

4. Remove lid and stir well using the serving
spoon provided. At this stage remaining
ingredients can be added i.e., butter,
parmesan cheese, herbs, salt and pepper.

5. The multi cooker will remain on the
KEEP WARM setting for 30 minutes
before switching OFF. However, risotto
is best served as soon as possible after
completion of cooking.

8

OPERATING YOUR MULTI CHEF RC 4010

There may be occasions when the multi cooker
switches to the KEEP WARM setting or switches
o before cooking is complete.
If this occurs, simply press the desired cooking
button, then press the START|CANCEL button.
The START|CANCEL button surround will
illuminate red and the selected setting will
be activated. This is asafety mechanism to
prevent overheating due to certain cooking
conditions.

NOTE

Allow the risotto to rest in the KEEP WARM
setting for 5 or 10 minutes to  nish cooking.

TIP

For optimum risotto results, we recommend
you stir once after 15-20 minutes in the
RISOTTO setting.

TIP

HOW TO MAKE RICE

RICE|STEAM setting

1. Use the multi cooker rice scoop provided
to measure the required quantity of rice
(refer to cooking tables - page 18).

Always measure level scoops, not heaped

(Fig 1).

(1 Australian standard metric measuring cup
is equal to 200g of uncooked rice) If your multi
cooker rice scoop is lost or misplaced, use
another cup but maintain the same cooking
ratios and ensure you do not exceed the 10
scoop maximum line in the removable cooking
bowl:
White Rice = 1 scoop rice + 1 scoop water (using
the multi cooker rice scoop)
Brown Rice = 1 scoop rice + 1½ scoops water
(using the multi cooker rice scoop)

NOTE

2. Place measured rice into aseparate bowl
and wash with cold water to remove
any excess starch. The rice is ready for
cooking when water runs clear from the
rice. Drain well.

3. Ensure the exterior of the removable
cooking bowl is clean before placing it
in the housing (this will ensure proper
contact with the inner cooking surface)
(Fig 2).

Fig. 1

The multi cooker rice scoop is not astandard
metric measuring cup.
1 multi cooker rice scoop is equal to 150g of
uncooked rice and 180ml of water.

Fig. 2

4. Add the washed rice to the removable
cooking bowl, ensuring rice is spread
evenly across the bottom of the bowl and
not heaped to one side (Fig 3).

OPERATING YOUR MULTI CHEF RC 4010

9
