• Meets U.S. EPA Tier 4 Final and EU Stage V emission standards.
• Net power advertised is the power available at the ywheel
when engine is equipped with fan, air cleaner, CEM exhaust
gas aftertreatment, alternator, and cooling fan running at
intermediatespeed.
• Rated speed 2,200 rpm.
3
Transmission
Forward/Reverse
1st Gear10 km/h6.2 mph
2nd Gear35 km/h21.7 mph
Creeper Speed
1st Gear5.5 km/h3.4 mph
2nd Gear15 km/h9.3 mph
Drawbar Pull104 kN23,380 lbf
Maximum Gradeability at
(19000kg/41,850 lb)
65%
Service Refill Capacities
Fuel Tank (total capacity)290 L76.6 gal
Diesel Exhaust Fluid Tank20 L5.3 gal
Cooling System35 L9.2 gal
Engine Oil13 L3.4 gal
Hydraulic Tank120 L31.7 gal
Hydraulic System (including tank)280 L74 gal
Rear Axle Housing (differential)14 L3.7 gal
Front Steering Axle (differential)10.5 L2.8 gal
Final Drive (each)2.5 L0.7 gal
Powershift Transmission2.5 L0.7 gal
Swing Mechanism
Maximum Swing Speed9.4 rpm
Maximum Swing Torque44 kN·m32,560 lbf-ft
Undercarriage
Ground Clearance360 mm14.2 in
Maximum Steering Angle35°
Oscillation Axle Angle± 8.5°
Minimum Turning Radius
Outside of Tire6600 mm21.6 ft
Outside of Tire (plastic fender)7900 mm25.9 ft
End of Variable Adjustable Boom7100 mm23.3 ft
Operating Weights*
Minimum19 000 kg41,890 lb
Maximum21 050 kg46,410 lb
Typical Congurations
Variable Adjustable Boom**
Rear Blade Only19 250 kg42,440 lb
Blade and Outriggers20 250 kg44,640 lb
Front and Rear Outriggers20 450 kg45,080 lb
** Operating weight includes full fuel tank, operator, bucket 700 kg
(1,540 lb) and dual pneumatic tires. Weight varies depending on
conguration.
** Typical congurations include 2.5 m (8'2") stick, bucket and
220kg (485 lb) quick coupler.
2
M319 Wheeled Excavator Specifications
Major Component Weights
Booms (including VA and stick
cylinder, pins and standard
hydrauliclines)
5.2 m (17'1") Variable
AdjustableBoom
Sticks (including cylinder, bucket
linkage, pins and standard
hydrauliclines)
2.2 m (7'3") Stick*790 kg1,740 lb
2.5 m (8'2") Stick810 kg1,790 lb
2.9 m (9'6") Stick860 kg1,900 lb
Counterweight
5000 kg (11,020 lb) Counterweight5000 kg11,020 lb
Undercarriage (including axles,
standard tires and steps)
Rear Blade4950 kg10,910 lb
Front Blade/Rear Outrigger6000 kg13,230 lb
Rear Outrigger/Front Blade6000 kg13,230 lb
Rear Outrigger/Front Outrigger6200 kg13,670 lb
Buckets
CW Bucket GD 1200 mm (47"),
3
(1.19 yd3)
0.91m
Pin-On Bucket GD 1200 mm (47"),
3
(1.19 yd3)
0.91 m
Quick Couplers
CW30 Dedicated Quick Coupler220 kg490 lb
Pin Grabber Quick Coupler300 kg660 lb
*Europe only.
2200 kg4,850 lb
610 kg1,340 lb
650 kg1,430 lb
Hydraulic System
Maximum Pressure – ImplementCircuit
Normal35 000 kPa5,076 psi
Heavy Lift37 000 kPa5,366 psi
Travel Circuit35 000 kPa5,076 psi
Maximum Pressure – Auxiliary Circuit
High Pressure35 000 kPa5,076 psi
Medium Pressure17 000 kPa2,466 psi
Swing Mechanism35 000 kPa5,076 psi
Maximum Flow
Implements254 L/min67 gal/min
Travel Circuit210 L/min56 gal/min
Auxiliary Circuit
High Pressure250 L/min66.0 gal/min
Medium Pressure55 L/min14.5 gal/min
Swing Mechanism98 L/min25.9 gal/min
Cylinders
Boom Cylinder (VA) – Bore120 mm0'5"
Boom Cylinder (VA) – Stroke954 mm3'2"
VAB Cylinder – Bore140 mm0'6"
VAB Cylinder – Stroke743 mm2'5"
Stick Cylinder – Bore120 mm0'5"
Stick Cylinder – Stroke1147 mm3'9"
Bucket Cylinder – Bore100 mm0'4"
Bucket Cylinder – Stroke1055 mm3'6"
Tires
Standard10.00-20 (dual pneumatic)
Optional11.00-20 (dual pneumatic)
315/70R22.5 (dual pneumatic without spacer)
445/70/R19.5 TL XF (single pneumatic)
3
M319 Wheeled Excavator Specifications
Dozer Blade
Blade TypeParallel
Width2540 mm8'4"
Width (wide axles)2750 mm9'0"
Blade Roll-Over Height570 mm1'10"
Blade Total Height610 mm2'0"
Maximum Lowering Depth
FromGround
Maximum Raising Height
AboveGround
130 mm0'5"
495 mm1'7"
Emissions and Safety
Engine EmissionsTier 4 Final and
EUStageV
Vibration Levels
2
2
<8.2 ft/s
<1.6 ft/s
Maximum Hand/Arm
(ISO 5349-2001)
Maximum Whole Body
(ISO/TR 25398:2006)
Seat Transmissibility Factor
(ISO 7096:2000-spectral class EM5)
<2.5 m/s
<0.5 m/s
<0.7
Standards
BrakesISO 3450:2011
Cab (ROPS)ISO 12117-2:2008
FOPS (Falling Object
ProtectiveStructure)
Cab/Sound LevelsMeets appropriate
ISO 10262:1998
standards as listed below
Sound Performance
Operator Sound
2000/14/EC70 dB(A)
Spectator Sound
2000/14/EC98 dB(A)
• Operator Sound – The operator sound level is measured according
2
2
to the procedures specied in 2000/14/EC, for a cab offered by
Caterpillar, when properly installed and maintained and tested
with the door and windows closed.
• Exterior Sound – The labeled spectator sound power level is
measured according to the test procedures and conditions specied
in 2000/14/EC.
• Hearing protection may be needed when operating with an open
operator station and cab (when not properly maintained for doors/
windows open) for extended periods or in noisy environment(s).
Air Conditioning System
The air conditioning system on this machine contains the
uorinated greenhouse gas refrigerant R134a (Global Warming
Potential = 1430). The system contains 1.0 kg of refrigerant, which
has a CO2 equivalent of 1.43 metric tonnes.
4
7
11
12
M319 Wheeled Excavator Specifications
Dimensions
All Dimensions are approximate. Values are with 10.00-20 Dual Pneumatic Tires.
2
4
1
6
5
3
Boom OptionVariable Adjustable Boom
Stick Options2.2 m (7'3")2.5 m (8'2")2.9 m (9'6")
Shipping Height with Falling Object Guard (highest point between boom andcab)3360 mm (11'0") 3360 mm (11'0") 3380 mm (11'1")
1
Shipping Length8160 mm (26'9") 8110 mm (26'7") 8080 mm (26'6")
2
Support Point3860 mm (12'8") 3520 mm (11'7") 3340 mm (10'11")
3
Tail Swing Radius1900 mm (6'3")1900 mm (6'3")1900 mm (6'3")
4
Counterweight Clearance1300 mm (4'3")1300 mm (4'3")1300 mm (4'3")
5
Cab Height
6
No Falling Object Guard3200 mm (10'6") 3200 mm (10'6") 3200 mm (10'6")
With Falling Object Guard3360 mm (11'0") 3360 mm (11'0") 3360 mm (11'0")
Overall Machine Width
Width with Outriggers on Ground3820 mm (12'6") 3820 mm (12'6") 3820 mm (12'6")
7
Width with Outriggers Up2540 mm (8'4")2540 mm (8'4")2540 mm (8'4")
8
Width with Blade2540 mm (8'4")2540 mm (8'4")2540 mm (8'4")
9
Width with Blade (wide axles)2750 mm (9'0")2750 mm (9'0")2750 mm (9'0")
Width with Outriggers Fully Down3650 mm (12'0") 3650 mm (12'0") 3650 mm (12'0")
10
Enclosure Height (doors)2500 mm (8'2")2500 mm (8'2")2500 mm (8'2")
Upperframe Width2540 mm (8'4")2540 mm (8'4")2540 mm (8'4")
11
Roading Position
Steering Wheel to Linkage in Roading Position3260 mm (10'8") 3250 mm (10'8")—
12
Height in Roading Position3970 mm (13'0") 3990 mm (13'1")—
13
5.2 m (17'1")
13
8, 9
10
5
M319 Wheeled Excavator Specifications
22
14
14
Undercarriage Dimensions
All Dimensions are approximate.
Undercarriage
Overall Undercarriage Length4440 mm (14'7") 5050 mm (16'7") 5050 mm (16'7") 4955 mm (16'3")
14
Wheel Base2700 mm (8'10") 2700 mm (8'10") 2700 mm (8'10") 2700 mm (8'10")
15
Swing Bearing Center to Rear Axle1250 mm (4'1")1250 mm (4'1")1250 mm (4'1")1250 mm (4'1")
16
Swing Bearing Center to Front Axle1450 mm (4'9")1450 mm (4'9")1450 mm (4'9")1450 mm (4'9")
17
Rear Axle to Rear Outrigger (mid)——875 mm (2'10")875 mm (2'10")
18
Front Axle to Front Outrigger (mid)—875 mm (2'10")—875 mm (2'10")
19
Rear Axle to Parallel Blade (end)1200 mm (3'11") 1200 mm (3'11")——
20
Front Axle to Parallel Blade (end)——1245 mm (4'1")—
Maximum Outrigger Depth—120 mm (0'5")120 mm (0'5")120 mm (0'5")
21
Blade Width (standard axles)2540 mm (8'4")2540 mm (8'4")2540 mm (8'4")—
22
Blade Width (wide axles)2750 mm (9'0")2750 mm (9'0")2750 mm (9'0")—
Maximum Blade Depth Below Ground130 mm (0'5")130 mm (0'5")130 mm (0'5")—
Ground Clearance
Lowest Step Clearance420 mm (1'5")420 mm (1'5")420 mm (1'5")420 mm (1'5")
Outrigger Clearance325 mm (1'1")325 mm (1'1")325 mm (1'1")325 mm (1'1")
23
Blade Clearance495 mm (1'7")495 mm (1'7")495 mm (1'7")495 mm (1'7")
24
Axle Clearance360 mm (1'2")360 mm (1'2")360 mm (1'2")360 mm (1'2")
25
* Maximum tire clearance
with outriggerfullydown
Rear Blade
Rear Blade/
FrontOutrigger
Rear Outrigger/
Front Blade
Rear Outrigger/
Front Outrigger
21
Undercarriage with dozer onlyUndercarriage with 2 sets of outriggersUndercarriage with 1 set of outriggers and dozer
23
1215
1214
20
25
15
24
1819
19
15
1617
20
6
M319 Wheeled Excavator Specifications
Meters
05101520253035Feet
Feet
2.5 m (8'2")
2.9 m (9'6")
2.2 m (7'3")
Working Ranges
All Dimensions are approximate. Values are with 10.00-20 Dual Pneumatic Tires.
12
11
35
10
30
9
8
25
7
20
6
1
5
15
10
5
0
5
10
15
20
2
4
3
2
1
0
1
2
4
3
3
4
5
6
7
8
7
6
9
5
01234567891011–1
Meters
Boom OptionVariable Adjustable Boom
5.2 m (17'1")
Stick Options2.2 m (7'3")2.5 m (8'2")2.9 m (9'6")
Maximum Cutting Height10 520 mm (34'6")10 740 mm (35'3")11 110 mm (36'5")
1
Maximum Loading Height7580 mm (24'10")7790 mm (25'7")8160 mm (26'9")
2
Maximum Digging Depth5460 mm (17'11")5750 mm (18'10")6140 mm (20'2")
3
Maximum Vertical Wall Digging Depth4230 mm (13'11")4450 mm (14'7")4830 mm (15'10")
4
Maximum Depth Cut for 2440 mm (8'0") Level Bottom5350 mm (17'7")5640 mm (18'6")6050 mm (19'10")
5
Maximum Reach9140 mm (30'0")9390 mm (30'10")9610 mm (31'6")
6
Maximum Reach at Ground Line8960 mm (29'5")9210 mm (30'3")9610 mm (31'6")
7
Minimum Loading Height3780 mm (12'5")3430 mm (11'3")3100 mm (10'2")
8
Minimum Front Swing Radius2150 mm (7'1")2180 mm (7'2")2400 mm (7'10")
Bucket Tip Radius (Pin-On)1378 mm (4'6")1378 mm (4'6")1378 mm (4'6")
Bucket Tip Radius (QC)1484 mm (4'10")1484 mm (4'10")1484 mm (4'10")
Range values are with dual pneumatic tires (10.00-20).
Range values are calculated with a GD bucket (CW) and CW quick coupler with a tip radius of 1484 mm (4'10").
Force values are calculated with heavy lift on, a GD bucket (pin-on) and a tip radius of 1378 mm (4'6").
7
M319 Wheeled Excavator Specifications
Lift Capacities – Variable Adjustable Boom 2.2 m Stick
All values are in kg, work tool: none, bucket cylinder and bucket linkage installed, counterweight: 5000 kg, heavy lift function on.
Load at maximum reach (sticknose/bucket pin)Load over frontLoad over rearLoad over sideLoad point height
3000 mm4500 mm6000 mm7500 mm
Undercarriage configuration
Free on Wheels *9450 *9450 *9450
Front Empty – Rear Dozer – Stabilized *9450 *9450 *9450
Front Dozer – Rear Stabilizer – Stabilized *9450 *9450 *9450
9000 mm
Front Stabilizer – Rear Stabilizer – Stabilized *9450 *9450 *9450
Free on Wheels – Wide Axles *9450 *9450 *9450
Oscillating axle needs to be locked. Weight of all lifting accessories must be subtracted from the lifting capacities. All lift capacities calculated and rated per ISO 10567:2007. Rated loads do not exceed 87% of hydraulic lift
capacity or 75% of tipping load. Heavy Lift Function ON. Lifting capacities are based on the machine standing on a firm uniform supporting surface. The load point is the center line of the bucket pivot mounting pin on the
stick. Lift capacity is calculated with VA cylinder completely extracted. The use of a work tool attachment point to handle/lift objects, could affect the machine lift performance.
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
Oscillating axle needs to be locked. Weight of all lifting accessories must be subtracted from the lifting capacities. All lift capacities calculated and rated per ISO 10567:2007. Rated loads do not exceed 87% of hydraulic lift
capacity or 75% of tipping load. Heavy Lift Function ON. Lifting capacities are based on the machine standing on a firm uniform supporting surface. The load point is the center line of the bucket pivot mounting pin on the
stick. Lift capacity is calculated with VA cylinder completely extracted. The use of a work tool attachment point to handle/lift objects, could affect the machine lift performance.
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
Free on Wheels *585049003700
Front Empty – Rear Dozer – Stabilized *5850 *58504200
Front Dozer – Rear Stabilizer – Stabilized *5850 *5850 *5850
–3000 mm
Front Stabilizer – Rear Stabilizer – Stabilized *5850 *5850 *5850
Free on Wheels – Wide Axles *585049004150
* Limited by hydraulic rather than tipping load.
Oscillating axle needs to be locked. Weight of all lifting accessories must be subtracted from the lifting capacities. All lift capacities calculated and rated per ISO 10567:2007. Rated loads do not exceed 87% of hydraulic lift
capacity or 75% of tipping load. Heavy Lift Function ON. Lifting capacities are based on the machine standing on a firm uniform supporting surface. The load point is the center line of the bucket pivot mounting pin on the
stick. Lift capacity is calculated with VA cylinder completely extracted. The use of a work tool attachment point to handle/lift objects, could affect the machine lift performance.
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
Free on Wheels *12,500 10,500 8,000
Front Empty – Rear Dozer – Stabilized *12,500 *12,500 9,100
Front Dozer – Rear Stabilizer – Stabilized *12,500 *12,500 *12,500
–10 ft
Front Stabilizer – Rear Stabilizer – Stabilized *12,500 *12,500 *12,500
Free on Wheels – Wide Axles *12,500 10,600 8,900
* Limited by hydraulic rather than tipping load.
Oscillating axle needs to be locked. Weight of all lifting accessories must be subtracted from the lifting capacities. All lift capacities calculated and rated per ISO 10567:2007. Rated loads do not exceed 87% of hydraulic lift
capacity or 75% of tipping load. Heavy Lift Function ON. Lifting capacities are based on the machine standing on a firm uniform supporting surface. The load point is the center line of the bucket pivot mounting pin on the
stick. Lift capacity is calculated with VA cylinder completely extracted. The use of a work tool attachment point to handle/lift objects, could affect the machine lift performance.
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
