Casio CASSIOPEIA E-105 User Manual

E-100/E-105

Getting Started with

the CASSIOPEIA

(Hardware Manual)

User documentation consists of two manuals: Palm-size PC User’s Guide and this booklet. Be sure to read this manual first.

Be sure to read the Safety Precautions contained in this manual to ensure proper operation of this product.

Keep this manual in a safe place for future reference.

• Microsoft, Windows, and Windows NT are either registered trademarks or trademarks of

Microsoft Corporation in the United States and/or other countries.

• Pentium is a registered trademark of Intel Corporation.

• CompactFlash is a registered trademark of SanDisk Corporation.

• All other product and company names mentioned herein may be the trademarks of their

respective owners.

• Data can be uploaded from this unit to a personal computer for storage on a hard disk,

floppy diskette, or other storage medium. Be sure to make multiple copies of all important data to protect against its accidental loss.

• CASIO COMPUTER CO., LTD. assumes no responsibility for any damage or loss

resulting from the use of this manual.

• CASIO COMPUTER CO., LTD. assumes no responsibility for any loss or claims by

third parties which may arise through the use of this product.

• CASIO COMPUTER CO., LTD. assumes no responsibility for any damage or loss

caused by deletion of data as a result of malfunction, repairs, or battery replacement. Be sure to back up all important data on other media to protect against its loss.

• The contents of this manual are subject to change without notice.

• No part of this manual may be reproduced in any form without the express written

consent of the manufacturer.

Safety Precautions

Congratulations upon your selection of the CASSIOPEIA. Be sure to read the following Safety Precautions before trying to use it for the first time.

Note

All mentions of “the unit” in the following precautions refer to the CASSIOPEIA.

Markings and Symbols

The following are the meanings of the markings and symbols used in these Safety Precautions.

Danger

Warning

Caution

• A diagonal line indicates something you should not do. The symbol shown

here indicates you should not try to take the unit apart.

• A black circle indicates something you should do. The symbol shown here

indicates you should unplug the unit from the wall outlet.

Health Precautions

• Long continuous use of the unit when you are tired is not good for your

health, and should be avoided.

• Be sure to allow for adequate rest when using the unit for

long periods. As a general rule, you should allow for 10 to 15 minutes of rest per hour.

This symbol indicates information that, if ignored or applied incorrectly, creates the dang er of death or serious personal injury.

This symbol indicates information that, if ignored or applied incorrectly, creates the possibility of death or serious personal injury.

This symbol indicates information that, if ignored or applied incorrectly, creates the possibility of personal injury or property damage.

W arning

Caution

Precautions During Use

Abnormal Conditions

• Continued use of the unit while it is emitting smoke or strange odor creates

the danger of fire and electrical shock. Immediately turn off power, unplug the AC adapter from the wall outlet, remove ba tteries, and contact your original dealer or an authorized CASIO service provider to request servicing.

Water and Foreign Matter

• Should any foreign matter (metal, water or other liquid) ever get into the

unit, immediately turn off power, unplug the AC adapter from the wall outlet, remove batteries, and contact your original dealer or an authorized CASIO service provider to request servicing.

Dropping and Damage

• Should the unit ever fall or otherwise become damaged, unplug the AC

adapter from the power outlet, remove batteries, and contact your original dealer or an authorized CASIO service provider. Continued use creates the danger of fire and electrical shock.

Disassembly

• Never try to take the unit apart or modify it in any way. Doing so creates the

danger of fire and electrical shock.

Magnetic Force

• If you are fitted with a pacemaker, keep the unit away from your chest area.

In particular, do not carry the unit in your breast pocket. Magnetic force generated by the speaker built into the unit could possibly affect operation of a pacemaker. Should you ever suspect a problem, immediately move away from the unit and contact your physician.

Warning

Memory Protection

• Be sure to keep separate copies of all important data by saving it on a

Location

• Do not locate the unit in an area subjected to large amounts of humidity or

• Keep the unit away from food preparation area, stoves, and anywhere else it

Caution

computer hard disk or other medium. Note that all data stored in unit memory is deleted whenever batteries go dead. Memory contents can also become lost or corrupted due to malfunction and repair of the unit.

dust. Doing so can create the danger of fire and electrical shock.

might be exposed to oil smoke or steam. Such conditions can create the danger of fire and electrical shock.

Avoid unstable surfaces.

• Never place the unit on an unstable surface, on a high shelf, or in any other

unstable location. Doing so can create the danger of the unit falling and causing personal injury.

Magnetic Force

• Keep the unit away from ATM cards, credit cards, and any other magnetic

card during transport and storage. Magnetic force generated by its speaker can render magnetic cards unusable.

• Keep the unit away from televisions and other radio wave receivers.

Magnetic force generated by its speaker can cause interference with radio wave reception.

Rechargeable Battery Pack

• Never try to take apart the battery pack or modify it in any way. The battery

pack has built-in safety and protection mechanisms that ensure safe operation. Damaging these mechanisms creates the danger of fire, smoke emission, and explosion.

• Never allo w the positive (+) and negativ e (–) terminals of the battery pack to

become connected by metal. Never transport or store the battery pack together with a necklace, hairpins or other metal objects. Doing so can short the battery pack, which creates the danger of fire, overheating, and explosion.

• Never use or leave the battery pack next to open flame, near a stove, or any other area exposed to temperatures of 80°C/170°F or greater. Doing so creates the danger of fire and explosion.

• Never charge the battery pack near a stove, under direct sunlight, in an automobile parked in the sun, or any other area subject to high temperatures. High temperature can cause the battery pack’s safety mechanism to operate making it impossible to achieve a full charge. Heat can also cause an abnormal chemical reaction, which creates the danger of fire and explosion.

• Never pierce the battery pack with nails, hit it with a hammer, step on it, or throw it. Doing so can cause internal shorting, which creates the danger of fire and explosion.

• Never use a battery pack whose exterior is e xtremely damaged or deformed. Use of such a battery pack creates the danger of fire, overheating, and explosion.

•

Never use the battery pack with any device other than this product. Doing so can cause abnormal current that damages the battery pack and creates the danger of fire.

• Keep a battery pack that is emitting a strange odor or leaking fluid away from open flame. Fluid leaking from the battery pack is highly flammable. It creates the danger of fire and explosion.

Caution

Danger

Batteries

Warning

• Never expose the battery pack to direct flame, do not throw it into fire, fresh water, or seawater. Doing so can damage the built in safety and protection mechanisms, and cause battery fluid to ignite, creating the danger of fire and explosion.

• Should fluid from the battery pack ever accidentally get into your eyes, do not rub them. Rinse your eyes with tap water and then consult your physician immediately.

• If the battery pack does not achieve full charge after the normal charge time, stop charging. Continued charging creates the danger of fire, overheating, and explosion.

Warning

• Never try to charge backup battery, take it apart, or allow it to become shorted. Do not apply solder to battery or expose it to heat, and never throw battery into fire or water.

• While the lithium battery is removed from the unit, take care to keep it in a place where there is no danger of it being accidentally swallowed. Be especially careful around young children.

• Keep batteries out of the reach of young children. If a battery is accidentally swallowed, consult a physician immediately.

• Should fluid from the battery accidentally get into your eyes, do not rub them. Rinse your eyes with water and then consult your physician immediately.

Caution

Misuse of batteries can cause them to leak, which damages and corrodes the area around the battery and creates the danger of fire and personal injury. Be sure to observe the following precautions.

• When loading batteries, make sure their positive (+) and negative (–) poles are facing correctly.

• Remove battery from the unit if you do not plan to use it for a long time.

• Use only battery types that are specified for this unit.

AC Adapter

• Never use a voltage that is different from that for which the AC adapter is

• Never modify the power cord or excessively bend, twist, or pull it. Doing so

• Do not allow the power cord to become damaged. Do not place heavy

• Never touch the AC adapter while your hands are wet. Doing so creates the

• Should the power cord ever become seriously damaged (internal wiring

• Use only the AC adapter specified for this unit. Use of another type of AC

W arning

rated. Also, do not plug the unit into a power outlet that is shared by other devices. Doing so creates the danger of fire and electrical shock.

creates the danger of fire and electrical shock.

objects on the power cord or expose it to heat. A damaged power cord creates the danger of fire and electrical shock.

danger of electrical shock.

exposed or shorted), contact your original dealer or an authorized CASIO service provider to request servicing. Continued use of a seriously damaged power cord creates the danger of fire and electrical shock.

adapter can damage the battery pack and create the danger of fire and personal injury.

Caution

• Unplug the AC adapter from the wall outlet whenever leaving the unit unattended for long periods.

• Be sure to unplug the AC adapter from the wall outlet before attempting to move the unit to another location.

• Be sure to grasp the AC adapter when unplugging it from a wall outlet. Pulling on the power cord can damage it, and create the danger of fire and electrical shock.

• Keep the power cord away from stoves and other sources of heat. Heat can melt the insulation of the power cord and create the danger of fire and electrical shock.

Operating Precautions

The CASSIOPEIA is a precision digital instrument. Incorrect operation and rough handling can cause data storage problems and other malfunction. Be sure to read the following precautions to ensure proper operation.

• Charge the battery pack as soon as possible when they start to become weak.

Continued use while power is low can lead to loss of memory data.

• Do not leave dead batteries in the CASSIOPEIA for long periods. Doing so can result

in battery leakage, which can damage the CASSIOPEIA and cause malfunction.

• Use the CASSIOPEIA under the conditions listed below.

• Temperature: 0°C to 40°C (32°F to 104°F)

• No condensation

Conditions other than those above can cause malfunction.

• Avoid using the CASSIOPEIA in areas subjected to the following conditions.

• Static electricity

• Extreme heat or cold

• High humidity

• Sudden temperature changes

• Large amounts of dust

• If you drop the CASSIOPEIA and damage it, immediately turn off power and contact

your original dealer or an authorized CASIO service provider. Never continue using a damaged unit.

• Never place heavy objects on top of the CASSIOPEIA.

• Never try to take the CASSIOPEIA apart. Doing so can cause malfunction.

• Never insert foreign objects into connectors, slots, or other openings.

• Take care to avoid spilling water or drinks on the CASSIOPEIA.

• Use only the stylus that comes with the CASSIOPEIA to press the RESET button.

• Never use a pen, pencil, or other sharp writing implement. Doing so can scratch the

touch screen and cause malfunction.

• Never use thinner, benzene, cosmetics, or other volatile agents to clean the exterior of

the CASSIOPEIA. Use only a dry soft cloth or a soft cloth moistened with a weak solution of water and mild neutral detergent.

• Setting the display brightness too high or use of an optionally available

CompactFlash card results in battery life shorter than that indicated in the specifications of this manual.

• Be sure to use the soft case to protect the display panel of your CASSIOPEIA while

carrying it.

Important!

• The TFT color LCD is a product of the latest color LCD manufacturing technology.

However, virtually all TFT color LCDs have a very small number of pixels (about

0.01% of the total number of pixels) that do not turn on or always remain turned on. This is normal and does not indicate malfunction.

• Playing back movies, digital camera images, and audio files consumes large amounts

of power and may cause the CASSIOPEIA to become warm to the touch. This is normal and does not indicate malfunction.

Safety Precautions............................................................................................1

Markings and Symbols...........................................................................................1

Health Precautions..................................................................................................1

Precautions During Use..........................................................................................2

Rechargeable Battery Pack.....................................................................................3

Batteries..................................................................................................................4

AC Adapter.............................................................................................................5

Operating Precautions......................................................................................6

Terms and Symbols used in this manual..........................................................9

Getting Ready..................................................................................................10

Initial Setup..........................................................................................................10

Where to go for information.................................................................................11

Operations.......................................................................................................12

General Guide.......................................................................................................12

Using the Stylus....................................................................................................14

Recalibrating the Touch Screen............................................................................14

Adjusting Display Contrast..................................................................................15

Adjusting Display Brightness...............................................................................15

Adjusting Auto Dimming Settings.......................................................................15

Using the Cradle...................................................................................................16

To remove the CASSIOPEIA from the cradle...............................................17

Connecting the Cradle to a Computer............................................................18

Required System Configuration...........................................................................19

Using the AC Adapter...........................................................................................20

Infrared Communications.....................................................................................21

Using a CompactFlash Card.................................................................................22

Removing the Card Slot Cover......................................................................23

Replacing the Card Slot Cover.......................................................................23

About Modem Cards (U.S. and Canada Only).....................................................23

Software Applications...........................................................................................24

User Maintenance...........................................................................................25

Batteries................................................................................................................25

Replacing the Main Battery............................................................................26

Replacing the Backup Battery........................................................................27

Charging the Battery Pack..............................................................................29

Resetting the Unit.................................................................................................30

Performing a Reset.........................................................................................30

Memory Error Message..................................................................................31

Full Reset (Memory Initialize).............................................................................32

Performing a Full Reset..................................................................................32

Errors Following a Full Reset........................................................................33

Troubleshooting..............................................................................................34

Appendix..........................................................................................................38

Button Operations.................................................................................................38

[Action] control + Cursor Key Combinations................................................38

Specifications........................................................................................................39

Regulatory Information........................................................................................40

Terms and Symbols used in this manual

•The term “unit” in this manual refers to the CASSIOPEIA.

•The symbol “Important

that can result in problems if not performed correctly. Be sure to read such information carefully.

” indicates important information about a procedure

Getting Ready

Initial Setup

After you first unpack your CASSIOPEIA, perform the following initial setup procedure before using it for the first time.

1.Load the main battery (rechargeable battery pack) (page 25).

Important

Be sure to use the AC Adapter to charge the battery pack before doing anything else. Your CASSIOPEIA will not operate correctly if you load the backup battery before charging the battery pack.

2.Use the AC Adapter to charge the battery pack.

3.Load the backup battery.

4.Let the CASSIOPEIA rest for about five seconds, and then press the [Power] button.

5.The initial startup screen should appear first, followed shortly by a touch screen calibration screen.

6.Follow the instructions that appear on the screen to set up your CASSIOPEIA.

• You can later change the settings you make with this procedure if you want. See the separate Palm-size PC User’s Guide for more information.

• The desktop appears after settings are complete.

• See “Where to go for information...” on page 11 of this manual for information about

where you should go to find out about the versatile features and functions of your CASSIOPEIA.

• Be sure to press the [Power] button to turn off power after you are finished using your CASSIOPEIA.

Important

• If the touch panel does not respond when you tap it or if nothing appears on the display, try performing a full reset (page 32). If this does not restore proper operation, remove the main battery and the backup battery and wait for about five minutes. Reload the main battery first and then the backup battery, and perform the above procedure again from step 4.

• Make sure the positive and negative poles of batteries are facing correctly when you load them into the unit.

• If the message “A problem with memory contents has been found...” appears on the display, perform a full reset (page 32).

Where to go for information...

Your CASSIOPEIA comes with two manuals: this Hardware Manual and a separate Palm-size PC User’s Guide. Be sure to read the contents of this Hardware Manual first.

What should I do after reading this Hardware Manual?

Read the Palm-size PC User’s Guide next to find out about the powerful software features and functions available on the CASSIOPEIA.

What should I do if I run into problems?

Check the troubleshooting guides on page 34 of this Hardware Manual and in the Palm-size PC User’s Guide.

Where can I find out about the bundled software?

Your CASSIOPEIA comes with a collection of standard Palm-size PC programs from Microsoft, plus a collection of original programs from CASIO.

■ Microsoft Programs

See the Palm-size PC User’s Guide for details on Calendar, Contacts, Tasks, Inbox, and Note Taker from Microsoft.

■ CASIO Programs

See the Palm-size User’s Guide for details on Menu launcher program and Card Backup Tool.

How can I connect my CASSIOPEIA to a desktop computer?

See page 16 of this Hardware Manual for details about how to connect and the type of computer you can connect to. See the separate Palm-size PC User’s Guide for information about actually exchanging data between your CASSIOPEIA and a computer.

How can I install the software on the CASSIOPEIA Applications CD-ROM that comes with the E-105?

See the documentation contained on the CD-ROM. Note that you need a Windows computer to view the contents of the CD-ROM.

Important

The optionally available modem card mentioned in this and the other manuals is intended for use in the U.S. and Canada only.

Operations

General Guide

Charge indicator (Green)

Indicates battery pack is charging.

Stereo headphone jack

For connection of a commercially available earphone/headphone (ø3.5mm)

Power button

Turns power on and off.

Exit button

Same as a computer’s ESC key

Action control

See “About the [Action] Control” on the next page.

Voice recorder button (Program button)

Hold down to activate Voice Recorder for instant recording of a voice memo.

Infrared port

Card slot

Microphone

Stylus

Indicator lamp (Red)

Alerts you to alarms and warning.

Touch screen

Perform operations and input data by tapping and writing directly on the screen.

• Menu

(Launcher)

• Contacts

• Calendar

Speaker

Cursor button

Moves the cursor around the screen.

Program buttons

Press to launch the assigned program. The programs shown here are the initial default settings.

AC adapter terminal

+ 30 hidden pages

Casio CASSIOPEIA E-105 User Manual

Safety Precautions

Operating Precautions

Contents

Getting Ready

Operations
