Canon OCE VARIOPRINT 5000 BROCHURE

Gain productivity

Océ

VP 5000
STACKER

High Capacity Output Stacker for Océ VarioPrint 5000

To derive maximum benefit from the speed of Océ cutsheet printing
systems – up to 158 A4 sheets per minute – you need to make the right
provisions for stacking and finishing your output.

The Océ VP 5000 STACKER is an add-on
stacking module for Océ VarioPrint® 5000
cutsheet printing systems. As single or
tandem High Capacity Stacker it stacks up
to 10,000 pages of output, so prints have to
be removed from the printer half as often
as before. The extra capacity means greater
speed and convenience in handling.

The prints are stacked on a trolley, making
it easy to move the output to the inserter,
perfect binder or other finishing equipment.

While a full trolley is being unloaded, a
second can be receiving a fresh stack of
prints. Each trolley acts as a mobile store­house, and you can increase this capacity
with as many trolleys as you need.

Of course, the Océ VP 5000 STACKER
gives you the same security for prints that
you’ve come to expect from Océ printing
systems: no sheet is ever lost or stacked in
duplicate. Which makes the stacker the
perfect partner for prints that need extra
careful processing.

February 2007 1/2

System data

Functions

• Stacks up to

5,000 sheets of 80 g/m¤ (22 lbs)

• Takes paper with formats up to A3+.

• Prints are stacked on a trolley.

• Job separation through stack offsetting

• Up to two High Capacity Stackers can
be connected in tandem to one printing
system.

Compatibility

Connects to printing systems

• Océ VarioPrint 5115

• Océ VarioPrint 5160

Connection of post-processing
equipment

•

Post-Processing Interface Type 1+ or UP3I

• Bypass mode for routing sheets to
post-processing equipment.

Electrical

Europe USA

• Voltage 230 V ±10% 120 V ±10%

• Frequency 50 Hz 60 Hz

Environmental

• Temperature 5ºC–35ºC

• Rel. humidity 10%–85%

Physical (incl. adapter to printing system)

• Height 47.2" (1,200 mm)

• Width 28.5" (725 mm)

• Length 42.9" (1,090 mm)

Weight

Approx. 200 kg (440 lbs)

Options

• One or more trolleys with a
stacking capacity of 5,000 sheets each

(75 g/m¤/20 lbs paper).

• Elevator (to easily feed stacked sheets
into offline finishing devices)

Océ

VP 5000
STACKER

Printing for
Professionals

For information and services, visit us at www.oce.com

© 2007 Océ. Illustrations and specifications do not necessarily apply to products and services offered in each local market.

Technical specifications are subject to change without prior notice. All other trademarks are the property of their respective owners.

February 2007 2/2
