Candy GO DC 67 User Manual
Instruction Book
GO DC 67
Condenser Tumble Dryer
®
English
Dansk
Deutsch
Norsk
Suomi
Svenska
40005040Eng.qxd 09/05/2007 11:04 Page 1
English . . . . . . . . . . . . . . . . . 2
Dansk . . . . . . . . . . . . . . . . . 20
Deutsch . . . . . . . . . . . . . . . . 38
Norsk. . . . . . . . . . . . . . . . . . 56
Suomi . . . . . . . . . . . . . . . . . 74
Svenska . . . . . . . . . . . . . . . . 92
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Delivery information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Unpacking the Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety reminders. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
The Laundry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Environmental Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
GIAS Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Electrical requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Adjusting the feet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Ventilation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Preparing the load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Clothes preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Sorting the load. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Drying advice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Do not tumble dry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Energy saving. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Drying guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Door and Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Opening the door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Filter care indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Water container. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
To remove the container . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Condenser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
To remove the condenser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Selecting the Programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Cancelling and resetting the programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Start Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Cleaning and Routine Maintenance. . . . . . . . . . . . . . . . . . . . 17
Cleaning the dryer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Customer Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Spares. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
GIAS Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2
40005040Eng.qxd 09/05/2007 11:04 Page 2
Introduction
Please read and follow these instructions
carefully and operate the machine accordingly.
This booklet provides important guidelines for
safe use, installation, maintenance and some
useful advice for best results when using your
machine.
Keep all documentation in a safe place for future
reference or for any future owners
Delivery information
Please check that the following items are
delivered with the appliance:
● Instruction manual
● Guarantee card
● Energy label
Remove the machine from its packaging close to
the final location of the machine.
1. Cut carefully around the base of the
packaging and up one corner.
2. Remove the polythene sleeve and lift the
dryer off the polystyrene base.
3
Check that no
damage has
occurred to the
machine during
transit. If it has,
call for service by
GIAS.
Failure to comply
with the above
can compromise
the safety of the
appliance. You
may be charged
for a service call
if a problem with
your machine is
caused by
misuse.
Unpacking the product
Dispose of the packaging safely. Make
sure it is out of the reach of children,
it is a potential source of danger.
40005040Eng.qxd 09/05/2007 11:04 Page 3
Safety reminders
Installation
● Check that the product has no visible signs of damage before use. If damaged do
not use and please call GIAS Service.
● Do not use adapters, multiple connectors and/or extensions.
● Never install the dryer against curtains and be sure to prevent items from falling
or collecting behind the dryer.
● The appliance must not be installed behind a lockable door, a sliding door or a
door with a hinge on the opposite side to that of the tumble dryer.
Use
● This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
● Children should be supervised to ensure that they do not play with the appliance.
● WARNING Misuse of a tumble dryer may create a fire hazard.
● This machine is solely for domestic use, i.e. to dry household textiles and garments.
● This machine should only be used for its intended purpose as described in this
manual. Ensure that the instructions for installation and use are fully understood
before operating the appliance.
● Do not touch the appliance when hands or feet are damp or wet.
● Do not lean on the door when loading the machine or use the door to lift or
move the machine.
● Do not allow children to play with the machine or its controls.
● WARNING Do not use the product if the fluff filter is not in position or is
damaged; fluff could be ignited.
● WARNING Where the hot surface symbol is located the temperature rise
during operation of the tumble dryer may be in excess of 60 degrees C.
● Remove the plug from the electricity supply. Always remove the plug before
cleaning the appliance.
● Do not continue to use this machine if it appears to be faulty.
● Lint and fluff must not be allowed to collect on the floor around the outside of
the machine.
● The drum inside may be very hot. Always allow the dryer to complete the cool
down period before removing the laundry.
The Laundry
● Do not dry unwashed items in the tumble dryer.
● WARNING Do not tumble dry fabrics treated with dry cleaning fluids.
● WARNING Foam rubber materials can, under certain circumstances, when heated
become ignited by spontaneous combustion. Items such as foam rubber (latex
foam), shower caps, waterproof textiles, rubber backed articles and clothes or
pillows fitted with foam rubber pads MUST NOT be dried in the tumble dryer.
● Always refer to the laundry care labels for directions on suitability for drying.
4
40005040Eng.qxd 09/05/2007 11:04 Page 4
● Clothes should be spin dried or thoroughly wrung before they are put into the
tumble dryer. Clothes that are dripping wet should NOT be put into the dryer.
● Lighters and matches must not be left in pockets and NEVER use flammable
liquids near the machine.
● Glass fibre curtains should NEVER be put in this machine. Skin irritation may
occur if other garments are contaminated with the glass fibres.
● Items that have been soiled with substances such as cooking oil, acetone, alcohol,
petrol, kerosene, spot removers, turpentine, waxes and wax removers should be
washed in hot water with an extra amount of detergent before being dried in
the tumble dryer.
● Fabric softeners, or similar products, should be used as specified by the fabric
softener instructions.
Environmental Issues
● All packaging materials used are environmentally-friendly and recyclable. Please
help dispose of the packaging via environmentally-friendly means. Your local
council will be able to give you details of current means of disposal.
● To ensure safety when disposing of an old tumble dryer disconnect the mains
plug from the socket, cut the mains power cable and destroy this together with
the plug. To prevent children shutting themselves in the machine break the door
hinges or the door lock.
GIAS Service
●
To ensure the continued safe and efficient operation of this appliance we
recommend that any servicing or repairs are only carried out by an authorised
GIAS service engineer.
European directive 2002/96/EC
This appliance is marked according to the European directive 2002/96/EC on Waste
Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment
and human health, which could otherwise be caused by
inappropriate waste handling of this product.
The symbol on the product indicates that this product may not
be treated as household waste. Instead it shall be handed over
to the applicable collection point for the recycling of electrical
and electronic equipment.
Disposal must be carried out in accordance with local
environmental regulations for waste disposal.
For more detailed information about treatment, recovery and
recycling of this product, please contact your local city office,
your household waste disposal service or the shop where you
purchased the product.
5
If the appliance is not running properly or breaks down,
switch it off and disconnect the plug from the socket.
Consult GIAS Service for possible repair.
40005040Eng.qxd 09/05/2007 11:05 Page 5
Electrical requirements
Tumble dryers are supplied to operate at a
voltage of 230V, 50 Hz single phase. Check that
the supply circuit is rated to at least 16A.
Electricity can be extremely dangerous.
This appliance must be earthed.
The socket outlet and the plug on the appliance
must be of the same type.
Do not use multiple adapters and/or extension
leads.
The plug should be accessible for disconnection
after the appliance has been installed.
The wires in the mains lead are coloured in
accordance with the following codes:
Blue NEUTRAL
Brown LIVE
Green and Yellow EARTH
CE Appliance complies with European Directive
89/336/EEC, 73/23/EEC and subsequent amendments.
Adjusting the feet
Once the machine is in place the feet should be
adjusted to ensure that the machine is level.
6
You may be
charged for a
service call if a
problem with
your machine is
caused by
incorrect
installation.
If the mains cord
on this
appliance is
damaged, it
must be
replaced by a
special cord
which is ONLY
obtainable from
the spares
service. It must
be installed by a
competent
person.
Installation
Do not plug the machine in and
switch it on at the mains until the
installation is completed.
For your safety, this dryer must be
correctly installed.
If there is any doubt about
installation, call GIAS Service for
advice.
40005040Eng.qxd 09/05/2007 11:05 Page 6
Adequate ventilation must be provided in the
room where the tumble dryer is located to
prevent gases from appliances burning other
fuels, including open fires, being drawn into the
room during operation of the tumble dryer.
● Exhaust air must not be discharged into a
flue which is used for exhausting fumes
from appliances burning gas or other fuels.
● Check regularly that the air flowing through
the dryer is not restricted.
● Check the fluff filter after use, and clean, if
necessary.
● The inlet and outlets should be kept free
from obstructions. To ensure adequate
ventilation the space between the bottom
of the machine and the floor must not be
obstructed. There should be a gap of at
least 12mm between the machine and any
obstructions.
● Prevent items from falling or collecting
behind the dryer as these may obstruct the
air inlet and outlet.
● NEVER install the dryer up against curtains.
7
Ventilation
AIR OUTLETS
AIR OUTLETS IN THE BASE
AIR INLET VENTS
40005040Eng.qxd 09/05/2007 11:05 Page 7
Before using the tumble dryer for the first time:
● Please read this instruction book thoroughly.
● Remove all items packed inside drum.
● Wipe the inside of the drum and door with
a damp cloth to remove any dust which may
have settled in transit.
Clothes preparation
Make sure that the laundry you are going to dry
is suitable for drying in a tumble dryer, as shown
by the care symbols on each item.
Check that all fastenings are closed and that
pockets are empty. Turn the articles inside out.
Place clothes loosely in the drum to make sure
that they don't get tangled.
Maximum drying weight
● Cottons Max. 7 kg
● Synthetics Max. 3.5 kg
8
Preparing the load
Do not overload
the drum, large
items when wet
can exceed the
maximum
admissible
clothes load
(for example:
sleeping bags,
duvets).
40005040Eng.qxd 09/05/2007 11:05 Page 8
Sort the load as follows:
● By care symbols
These can be found on the collar or inside
seam:
Suitable for tumble drying.
Tumble drying at high temperature.
Tumble drying at low temperature only.
Do not tumble dry.
If the item does not have a care label it
must be assumed that it is not suitable
for tumble drying.
● By amount and thickness
Whenever the load is bigger than the dryer
capacity, separate clothes according to
thickness (e.g. towels from thin underwear).
● By type of fabric
Cottons/linen: Towels, cotton jersey, bed and
table linen.
Synthetics: Blouses, shirts, overalls, etc.
made of polyester or polyamid, as well as
for cotton/synthetic mixes.
● By drying level
Sort into: iron dry, cupboard dry, etc. For
delicate articles press the button to
select low drying temperature.
9
40005040Eng.qxd 09/05/2007 11:05 Page 9
Do not tumble dry:
Woollens, silk, delicate fabrics, nylon stockings,
delicate embroidery, fabrics with metallic
decorations, garments with PVC or leather
trimmings, training shoes, bulky items such as
sleeping bags, etc.
Energy saving
Only put into the tumble dryer laundry which has
been thoroughly wrung or spin-dried. The drier
the laundry the shorter the drying time thus
saving electricity.
ALWAYS
● Try to dry the maximum weight of laundry,
this will save time and electricity.
● Check that the filter is clean before every
drying cycle.
NEVER
● Exceed the maximum weight, this will waste
time and electricity.
● Put dripping wet items into the tumble
dryer, this may damage the appliance.
Drying guide
The table shows approximate drying times,
depending on the type of fabric and dampness of
the clothes.
10
Drying advice
IMPORTANT: Do
not dry articles
which have been
treated with a
dry cleaning fluid
or rubber clothes
(danger of fire or
explosion).
During the last
15 minutes the
load is always
tumbled in cool
air.
Fabric
COTTON
SYNTHETICS
ACRYLIC
HEAT SETTING
HIGH
LOW
LOW
HEAVY LOAD
140-165 min
–
–
MEDIUM LOAD
70-80 min
70-80 min
50-65 min
LIGHT LOAD
50-65 min
40-55 min
30-40 min
40005040Eng.qxd 09/05/2007 11:05 Page 10
11
Controls and indicators
ACRYLICS/
SYNTHETICS
BUTTON
ON/OFF
BUTTON
FILTER CARE
INDICATOR
EMPTY
WATER
INDICATOR
PROGRAMME
SELECTOR
START
BUTTON
START
DELAY
BUTTON
COUNTDOWN DISPLAY
40005040Eng.qxd 09/05/2007 11:05 Page 11
Control panel and indicator lights
Programme Selector – Select the required programme
On/Off button and indicator – Press to switch on, the indicator will light
Start – Press Start to commence the selected drying programme. Press for 5 seconds to
cancel/reset the programme
Acrylics/Synthetics button – Press to reduce the heat level for delicate items, the
indicator above the button will light up. To change the heat setting the programme
must be reset
Low Heat – Indicator light ON High Heat – Indicator light OFF
Empty Water indicator – lights when the water container is full
Filter Care indicator – lights when the filter needs cleaning
Start Delay button – Allows the user to delay the start of the drying cycle (see
details of operation page 16)
Display
START – When the dryer is switched On the START indicator will flash, when the
programme starts the START indicator will light up
60' – Indicator lights when there is less than 60 minutes left until completion of the
programme
15' - Indicator lights when there is less than 15 minutes left until completion of the
programme. At this stage of the drying cycle the machine enters the Cool Down phase
STOP - Indicator lights when the programme is finished
6h - 6 hour start delay (light flashes when in operation)
9h - 9 hour start delay (light flashes when in operation)
Opening the door
Pull on handle to open the door.
To restart the dryer, close the door and press
Start.
Filter
IMPORTANT: To maintain the efficiency of the
dryer check that the fluff filter is clean before
each drying cycle.
1. Pull the filter upwards.
2. Open filter as shown.
3. Gently remove lint using a soft brush or
your fingertips.
4. Snap the filter together and push back into
place.
Filter Care Indicator
lights when the filter needs cleaning.
If the laundry is not drying check that the filter is
not clogged.
12
Door and Filter
WARNING!
When the tumble dryer is in use the
drum and door may be VERY HOT.
Never stop a tumble dryer before
the end of the drying cycle unless
all items are quickly removed and
spread out so that the heat is
dissipated.
40005040Eng.qxd 09/05/2007 11:06 Page 12
The water removed from the laundry during the
drying cycle is collected in a container at the
bottom of the dryer.
When the container is full the indicator on
the control panel will light, and the container
MUST be emptied. However, we recommend that
the container is emptied after each drying cycle.
NOTE: Very little water will collect during the
first few cycles of a new machine as an internal
reservoir is filled first.
To remove the container
1. Gently pull the bottom of the kickplate so
that it unclips from the dryer. The top
section can then be unhinged allowing the
kickplate to be completely removed.
2. Pull firmly on the handgrip and slide the
water container out of the dryer.
Support the container with both hands. When
full, the water container will weigh about 4kg.
3. Open the lid located on the top of the
container and empty the water.
4. Refit the lid and slide the water container
back into position. PUSH FIRMLY INTO
PLACE.
5. Refit the kickplate by engaging the hinges
at the top and 'snapping' the lower clips
into place.
13
Water Container
40005040Eng.qxd 09/05/2007 11:06 Page 13
Important: Always switch off and remove the plug from the electricity supply
before cleaning the condenser.
To maintain the efficiency of the dryer regularly check that the condenser is clean.
To remove the condenser
1. Remove the kickplate (see page 13).
2. Turn the two locking levers anti-clockwise and pull out the condenser.
3. Pull out the condenser unit.
4. Gently remove any dust or fluff with a cloth,
then wash the unit by holding it under a
running tap turning it so that water flows
between the plates, to remove any dust or
fluff.
5. Refit the condenser ensuring it is in the
correct way (as indicated by the arrow) and
pushed firmly into place. Lock the two levers
by turning them clockwise.
6. Refit the kickplate.
The Sensor Dry machine gives many options
for drying the laundry to suit all
circumstances.
Note: The sensor may not detect a small load
of small articles. For small loads and separate
items or pre-dried fabrics with low moisture
content, use the timed programmes. Set the
14
Condenser
Selecting the
Programme
40005040Eng.qxd 09/05/2007 11:06 Page 14
programme between 30 and 75 minutes depending on the load size and
dryness required, and select high or low heat depending upon the fabric type.
If the sensor does not detect the item the dryer will only operate for 10
minutes before going into cooldown.
If the load is too large or too wet to tumble dry the dryer will automatically
go into cooldown after 185 minutes.
The table below lists the programmes and the function of each programme.
15
Programme
Bone Dry
Extra Dry
Cupboard Dry
Iron Dry
Wool
Fast Iron
120'
75'
60'
45'
30'
AIR
Description
Select the degree of dryness that you require.
This ranges from Bone Dry for bath towels and
bathrobes, through Cupboard Dry for items that will be
put away without ironing, to the programme that
leaves the laundry suitable for ironing.
A gentle programme specially created to get woollens
softer after air-drying.
This delicate warm air cycle, lasting 12 minutes, can
also be used to get woollens 'refreshed' after being
stored in the wardrobe.
The Fast Iron programme provides a conditioning and
anticrease function. The dryer will heat the load for
9 minutes followed by a 3 minute cool down period
and is especially good for garments which may have
been left for some time prior to ironing, in a linen
basket for example. Garments may also become
stiffened when dried outside on a washing line or
inside on radiators. The Fast Iron process relaxes the
creases in the fabric making ironing quicker and easier.
120 minutes of drying
75 minutes of drying
60 minutes of drying
45 minutes of drying
30 minutes of drying
Tumbling of laundry in cool air for 30 minutes
40005040Eng.qxd 09/05/2007 11:06 Page 15
1. Open the door and load the drum with laundry. Ensure that garments do
not hinder closure of the door.
2. Gently close the door pushing it slowly until you hear the door 'click'
shut.
3. Press the button to switch on the dryer. The indicator will light up
and the START indicator will flash.
4. Turn the Programme Selector dial to select the required drying program
(see Programme Guide).
5. If drying synthetics, acrylics or delicate items, press the button to
reduce the heat level.
The light above the push button will light up when the machine is in low
heat setting. To deselect this status when the drying cycle has started it is
necessary to reset the machine.
6. Press the Start button. The dryer will start automatically and the START
indicator will be continuously lit.
7. The display will show the drying progress in terms of time
remaining.
8. If the door is opened during the programme to check the laundry, it is
necessary to press Start to recommence drying after the door has been
closed.
9. When the 15' indicator is lit the machine will enter the cool down phase,
the clothes will be tumbled in cool air allowing the load to cool down.
10. When the programme is complete the STOP indicator will light.
Cancelling and resetting the
programme
To cancel a programme press the Start button for 5 seconds. The machine will
indicate that it has been reset by the START indicator flashing. It is possible to
change the programme within the first 10 minutes without using the cancel
and reset function.
Start Delay
The Delay Start Function allows the user to delay the start of the drying
cycle by 6 or 9 hours.
When the function is first selected the display will show a delay of 6 hours, a
subsequent press of the button will increase the delay to 9 hours.
16
Operation
40005040Eng.qxd 09/05/2007 11:06 Page 16
To commence the programme press Start and the
appliance will complete the drying cycle at the
end of this time. The 6 or 9 hour indicator light
will flash to indicate that the start delay is in
progress.
Cleaning the dryer
● Clean the filter and empty the water
container after every drying cycle.
● Regularly clean the condenser.
● After each period of use, wipe the inside of
the drum and leave the door open for a
while to allow circulation of air to dry it.
● Wipe the outside of the machine and the
door with a soft cloth.
● DO NOT use abrasive pads or cleaning
agents.
● To prevent the door sticking or the build up
of fluff periodically clean the inner door and
gasket with a damp cloth.
Technical specifications
Drum capacity 115 litres
Maximum load 7 kg
Height 85cm
Width 60cm
Depth 60cm
Energy Label Band C
17
IMPORTANT
Always switch
off and remove
the plug from
the electricity
supply before
cleaning this
appliance.
For electrical data
refer to the
rating label on
the front of the
dryer cabinet
(with the door
open).
Cleaning and Routine
Maintenance
WARNING!
The drum, door
and load may be
very hot.
40005040Eng.qxd 09/05/2007 11:06 Page 17
What might be the cause of...
Defects you can remedy yourself
Before calling GIAS Service for technical advice please run through the
following checklist. A charge will be made if the machine is found to be
working or has been installed incorrectly or used incorrectly. If the problem
persists after completing the recommended checks, please call GIAS Service,
they may be able to assist you over the telephone.
Drying time is too long/clothes are not dry enough…
● Have you selected the correct drying time/programme?
● Were the clothes too wet? Were the clothes thoroughly wrung or spin-
dried?
● Does the filter need cleaning?
● Does the condenser need cleaning?
● Is the dryer overloaded?
● Are the inlets, outlets and base of the dryer free from obstructions?
● Has the option been selected from a previous cycle?
The dryer does not operate…
● Is there a working electricity supply to the dryer? Check using another
appliance such as a table lamp.
● Is the plug properly connected to the mains supply?
● Is there a power failure?
● Has the fuse blown?
● Is the door fully closed?
● Is the dryer switched on, both at the mains supply and at the machine?
● Has the drying time or the programme been selected?
● Has the machine been switched on again after opening the door?
● Has the dryer stopped operating because the water tray is full and needs
emptying?
The dryer is noisy…
● Switch off the dryer and contact GIAS Service for advice.
The Filter Care Indicator is on…
● Does the filter need cleaning?
● Does the condenser need cleaning?
Empty Water Indicator is on…
● Does the water container need emptying?
18
Troubleshooting
40005040Eng.qxd 09/05/2007 11:06 Page 18
Should there still be a problem with your dryer
after completing all the recommended checks,
please call GIAS Service for advice. They may be
able to assist you over the telephone or arrange
for a suitable appointment for an engineer to call
under the terms of your guarantee. However, a
charge may be made if any of the following
applies to your machine:
● Is found to be in working order.
● Has not been installed in accordance with
the installation instructions.
● Has been used incorrectly.
Spares
Always use genuine spares, available direct from
GIAS Service.
GIAS Service
For service and repairs call your local GIAS
Service engineer.
The manufacturer declines all responsibility in the
event of any printing mistakes in this booklet.
The manufacturer also reserves the right to make
appropriate modifications to its products without
changing the essential characteristics.
19
Customer Service
40005040Eng.qxd 09/05/2007 11:06 Page 19
20
Introduktion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Leveringsoplysninger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Udpakning af produktet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Sikkerhedspåmindelser. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Anvendelse. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Vasketøjet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Miljøhensyn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
GIAS Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Elektriske krav . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Justering af fødder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Ventilation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Forberedelse af ilægning af tøj. . . . . . . . . . . . . . . . . . . . . . . . . 26
Klargøring af tøj . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Sortering af vasketøj . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Gode råd om tørring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Må ikke tørres i tørretumbler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Energibesparelse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Tørrevejledning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Knapper og indikatorer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Låge og filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Åbning af lågen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Filterplejeindikator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Vandbeholder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Sådan aftages beholderen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Kondensator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Sådan udtages kondensatoren . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Valg af program. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Betjening. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Annullering og genindstilling af program. . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Forsinket start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Rengøring og løbende vedligeholdelse. . . . . . . . . . . . . . . . 35
Rengøring af tørretumbleren . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Tekniske specifikationer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Fejlfinding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Reservedele . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
GIAS Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
40005040Dan.qxd 09/05/2007 11:39 Page 20
Læs venligst denne instruktionsbog grundigt
igennem og følg anvisningerne. Denne
instruktionsbog giver dig nogle vigtige
retningslinjer angående sikker anvendelse,
installation, vedligehold samt gode råd om
hvordan, du opnår de bedste resultater med din
maskine.
Opbevar alle papirer et sikkert sted, så du har
dem når du skal bruge dem igen, eller hvis du
sælger maskinen.
Leveringsoplysninger
Kontrollér at følgende ting fulgte med maskinen:
● Instruktionsbog
● Garantibevis
● Energietiket
Tag maskinen ud af emballagen, så tæt som
muligt på der, hvor den skal stå.
1. Skær forsigtigt rundt om den underste kant
af emballagen og op langs et af hjørnerne.
2. Tag polythenbeklædningen af og løft
tørretumbleren af polystyrenfoden.
21
Introduktion
Kontrollér at
maskinen ikke er
beskadiget, når
du modtager
den. Hvis den er,
skal du ringe til
GIAS.
Følges
ovenstående ikke
kan maskinen
tage skade. Du
kan komme til at
betale for
reparation, hvis
der opstår
problemer med
din maskine, og
dette skyldes
misbrug.
Udpakning af produktet
Bortskaf emballagen på sikker vis.
Opbevares utilgængeligt for børn.
40005040Dan.qxd 09/05/2007 11:39 Page 21
22
Sikkerhedspåmindelser
Installation
● Kontroller at produktet ikke viser tegn på beskadigelse – før det tages i brug. Er
det beskadiget må det ikke bruges og GIAS Service skal kontaktes.
● Der må ikke anvendes adaptere, flere stikdåser og/eller forlængerledninger.
● Tørretumbleren må aldrig installeres opad gardiner, og genstande skal forhindres
i at falde ned bag ved eller samles bag tørretumbleren.
● Maskinen må ikke installeres bag en dør, der kan låses, bag en skydedør eller bag
en dør, hvor hængslet sidder i modsatte side af tørretumblerens hængsel.
Anvendelse
● Maskinen er ikke beregnet til at blive benyttet af personer (herunder også børn)
med mindskede fysiske, sensoriske eller mentale evner, eller af personer, der
mangler erfaring og viden, medmindre den person, der er ansvarlig for deres
sikkerhed har observeret dem eller har instrueret dem i, hvordan maskinen
benyttes.
● Børn skal være under opsyn af en voksen for at sikre, at de ikke leger med
maskinen.
● ADVARSEL Misbrug af tørretumbleren kan medføre brandfare.
● Maskinen er kun til husholdningsbrug, dvs. til at tørring af tekstilvarer og tøj i en
husholdning.
● Denne maskine må kun anvendes til det tilsigtede formål som beskrevet i denne
håndbog. Husk at alle instruktioner vedr. installation og anvendelse skal både
læses og forstås før maskinen tages i brug.
● Undgå at røre ved maskinen med fugtige eller våde hænder og fødder.
● Man må ikke læne sig op af lågen, når der lægges tøj i maskinen, eller bruge
lågen til at løfte eller flytte maskinen.
● Børn må ikke lege med maskinen og dens knapper.
● ADVARSEL Produktet må ikke bruges hvis fnugfilteret sidder forkert eller er
beskadiget; fnug kan antændes.
● ADVARSEL Der hvor symbolet for varm overflade er placeret , kan
temperaturen, under tumbling, overstige 60 grader C.
● Tag stikket ud at kontakten. Tag altid stikket ud før apparatet rengøres.
● Maskinen må ikke anvendes, hvis den virker defekt.
● Bomuldsfibre og fnug må ikke ophobes på gulvet omkring maskinen.
● Tromlens inderside kan være meget varm. Lad altid tørretumbleren fuldføre
afkølingsperioden før tøjet tages ud.
Vasketøjet
● Unlad at tørre uvaskede ting i tørretumbleren.
● ADVARSEL Man må ikke tørretumble tørt stof behandlet med kemiske
rensevæsker.
● ADVARSEL Skumgummimateriale kan, under visse omstændigheder, selvantænde,
hvis det bliver for varmt. Skumgummi (latex skum), badehætter, vandafvisende
tekstiler, materialer med gummibehandlet bagside og tøj eller puder med
40005040Dan.qxd 09/05/2007 11:39 Page 22
23
skumgummi fyld MÅ IKKE tørres i tørretumbleren.
● Kontroller altid vaskemærkerne, om tøjet tåler tørretumbling.
● Tøjet skal centrifugeres eller vrides omhyggeligt, før det lægges i tørretumbleren.
Tøj, der er drivvådt, må IKKE lægges i tørretumbleren.
● Lightere og tændstikker må ikke efterlades i lommer, og der må ALDRIG
anvendes brandfarlige væsker i nærheden af maskinen.
● Glasfibergardiner MÅ IKKE lægges i maskinen. Der kan opstå hudirritation, hvis
andre beklædningsgenstande kontamineres med glasfibre.
● Tøj, der er blevet snavset af stoffer som madolie, acetone, alkohol, benzin,
petroleum, pletfjerner, terpentin, voksprodukter og voksfjerner, bør vaskes i
varmt vand tilsat ekstra meget vaskemiddel, før det tørres i tørretumbleren.
● Skyllemidler eller lignede produkter skal anvendes i overensstemmelse med
skyllemidlets brugervejledning.
Miljøhensyn
● Den anvendte emballage er miljøvenlig og genanvendelig. Bortskaf emballagen
med tanke for miljøet. Hent vejledning til bortskaffelse af emballagen hos din
lokale kommune.
● For at sikre sikker bortskaffelse af en gammel tørretumbler, skal du tage stikket
ud af væggen, skære ledningen og stik af og smide dem ud. Bræk hængslerne af
lågen eller ødelæg låsen, så det undgås at børn kommer til at lukke sig selv inde
i maskinen.
GIAS Service
●
For at sikre apparatets fortsatte sikre og effektive drift anbefaler vi, at eventuel
service eller reparation kun udføres af en autoriseret GIAS servicetekniker.
Europæisk direktiv 2002/96/EC
Denne maskine er markeret i overensstemmelse med det europæiske direktiv
2002/96/EC vedrørende elektrisk affald og elektronisk udstyr
(WEEE).
Ved at sikre, at dette produkt bortskaffes korrekt, bidrager du
til at forhindre eventuelle skadelige konsekvenser for miljøet og
helbredet, som ellers kan forårsages af uhensigtsmæssig
bortskaffelse af dette produkt.
Symbolet på produktet angiver, at dette produkt ikke må
bortskaffes som husholdningsaffald. I stedet bør det overdrages
til en genbrugsstation med henblik på genanvendelse af
elektrisk og elektronisk udstyr.
Bortskaffelse bør ske i henhold til de lokale miljømæssige regler.
Du kan få yderligere oplysninger om håndtering, genskabelse og
genanvendelse af dette produkt ved at kontakte dit lokale
rådhus, genbrugsstationen eller den forhandler, du købte
produktet af.
Hvis maskinen ikke kører ordentligt eller går i stykker, så
sluk for den og tag stikket ud af stikkontakten. Kontakt
GIAS Service mht. eventuel reparation.
40005040Dan.qxd 09/05/2007 11:40 Page 23
24
Elektriske krav
Tørretumblere kan køre på 230V, 50 Hz enfaset.
Kontrollér at strømkredsen er klassificeret til
mindst 16A.
Elektricitet kan være meget farligt.
Dette apparat skal være jordforbundet.
Stikkontakten og maskinens stik skal passe
sammen.
Der må ikke anvendes flere adaptere og/eller
forlængerledninger.
Stikket skal være tilgængeligt til afbrydelse efter,
at apparatet er blevet installeret.
Ledningerne i netledningen er farvede i
overensstemmelse med følgende koder:
Blå NUL
Brun STRØMFØRENDE
Grøn og gul JORDFORBINDELSE
Dette apparat opfylder kravene i EU direktiverne
89/336/EØF, 73/23/EØF og efterfølgende ændringer.
Justering af fødder
Når maskinen er på plads, skal fødderne justeres,
så maskinen står vandret.
Du kan komme
til at betale for
reparation, hvis
der opstår
problemer med
din maskine, der
skyldes ukorrekt
installation.
Hvis
hovedledningen
til denne
maskine er
beskadiget, skal
den udskiftes
med en særlig
ledning, som
KUN fås hos
reservedels-
forhandleren.
Den skal
installeres af en
kvalificeret
person.
Installation
Du må ikke sætte stikket i og tænde
for maskinen, før installationen er
fuldført.
Af hensyn til din egen sikkerhed
skal denne tørretumbler være
installeret korrekt.
Hvis der er nogen tvivl om
installation, skal du ringe til GIAS
Service for rådgivning.
40005040Dan.qxd 09/05/2007 11:40 Page 24
Der skal være tilstrækkelig ventilation i det rum,
hvor tørretumbleren placeres, så det undgås at
gasser fra andre apparater, eller åben ild, trækkes
ind i rummet under tørretumbling.
● Udsugningsluft må ikke afledes i en
trækkanal, der er beregnet til aftræk af
røggasser fra apparater, der kører på gas eller
anden brændsel.
● Kontrollér regelmæssigt at luften, der
strømmer gennem tørretumbleren, ikke
hæmmes.
● Kontrollér fnugfiltret efter brug og rengør
det om nødvendigt.
● Indløb og udløb skal holdes fri for
tilstopninger. For at sikre tilstrækkelig
ventilation må mellemrummet mellem
maskinens bund og gulvet ikke tilstoppes. Der
skal være mindst 12 mm fri luft mellem
maskinen og ting, der kan blokere.
● Genstande skal forhindres i at falde ned og
samles mellem tørretumblerens sider og
bagside, da disse kan tilstoppe luftindsugning
og -udsugning.
● Tørretumbleren må ALDRIG installeres op mod
gardiner.
25
Ventilation
LUFTUDSUGNINGSKANALER
LUFTUDSUGNINGSKANALER I BUNDEN
LUFTINDSUGNINGSKANALER
40005040Dan.qxd 09/05/2007 11:40 Page 25
Før tørretumbleren anvendes første gang:
● Læs venligst denne instruktionsbog
grundigt.
● Fjern alle genstande som er lagt ind i
tromlen.
● Aftør tromlens inderside og låge med en
fugtig klud for at fjerne eventuelt støv, som
har sat sig under transporten.
Klargøring af tøj
Du skal sikre, at det vasketøj, du skal til at tørre,
egner sig til tørring i en tørretumbler, som vist på
vaskemærker på hver genstand.
Kontroller at alle lukninger er lukkede, og at
lommerne er tomme. Vend vrangen ud på
genstandene. Læg tøjet løst i tromlen for at sikre,
at det ikke filtrer sig sammen.
Maksimal tørrevægt
● Bomuld, maks. 7 kg
● Syntetiske stoffer, maks. 3,5 kg
26
Forberedelse af ilægning
af tøj
Tromlen må ikke
overfyldes,
større, våde ting,
kan overstige
den maksimalt
tilladte vægt
(f.eks.: soveposer
og dyner).
40005040Dan.qxd 09/05/2007 11:40 Page 26
Sorter tøjet, der skal
lægges i, som følger:
● Efter vaskemærker
De findes i kraven eller på en indvendig søm:
Egnet til tørring i tumbler.
Tørring i tumbler ved høj temperatur.
Kun tørring i tumbler ved lav temperatur.
Må ikke tørres i tørretumbler.
Hvis der ikke findes noget vaskemærke,
må det betragtes som uegnet til
tørretumbling.
● Efter antal og tykkelse
Når det tøj, der skal lægges i, overstiger
tørretumblerens kapacitet, skal tøjet adskilles i
overensstemmelse med tykkelse (f.eks.
håndklæder fra tyndt undertøj).
● Efter stoftype
Bomuld/linned: Håndklæder, bomuldsjersey,
sengelinned og duge.
Syntetiske stof: Skjortebluser, skjorter,
overalls, osv., fremstillet af polyester eller
polyamid samt efter bomulds/syntetiske
blandinger.
● Efter tørringsniveau
Sorter tøjet i: Strygetørt, Skabstørt, osv. For
sarte genstande tryk på knappen for at
vælge lav tørretemperatur.
27
40005040Dan.qxd 09/05/2007 11:40 Page 27
28
Må ikke tørres i
tørretumbler:
Uld, silke, sarte stoffer, nylonstrømper, sart broderi,
stof med metaldekoration, beklædningsgenstande
med PVC eller læderkanter, gummisko,
pladskrævende genstande, som f.eks. soveposer,
osv.
Energibesparelse
Læg kun vasketøj i tørretumbleren som er blevet
grundigt vredet eller centrifugeret. Jo mere tørt
vasketøj er, jo kortere vil tørretiden være og
derved spare elektricitet.
ALTID
● Prøv altid at tørre vasketøj så meget vasketøj
som maskinen tillader, dette sparer både tid
og elektricitet.
● Det skal altid kontrolleres, at filtret er rent
før hver tørrecyklus.
ALDRIG
● Den maksimale vægt må aldrig overskrides,
dette vil spilde tid og elektricitet.
● Læg aldrig drivvåde genstande i
tørretumbleren, dette kan beskadige
apparatet.
Tørrevejledning
Tabellen viser omtrentlige tørretider afhængig af
stoftype og tøjets fugtighed.
Gode råd om tørring
VIGTIGT: Tør ikke
genstande som
er behandlet med
kemisk
rensevæske eller
gummitøj (fare
for brand eller
eksplosion).
I de sidste 15
minutter tørres
tøjet altid i kold
luft.
Stof
BOMU\LD
SYNTETISKE
STOFFER
AKRYL
VARMEINDSTILLING
HØJ
LAV
LAV
STOR
MÆNGDE
140-165 min
–
–
MEDIUM
MÆNGDE
70-80 min
70-80 min
50-65 min
LILLE
MÆNGDE
50-65 min
40-55 min
30-40 min
40005040Dan.qxd 09/05/2007 11:40 Page 28
29
Kontrolpanel og indikatorlys
Programvælger – Vælg det ønskede program
Tændt/slukket knap og indikator – Tryk for at tænde, indikatoren lyser
Start – Tryk Start for at fortsætte det valgte tørreprogram. Tryk i 5 sekunder for at
annullere/genindstille programmet
Akryl/Syntetiske stoffer-knap – Tryk for at reducere varmeniveau for sarte
genstande, indikatorlyset over knappen tænder. Skal varmeniveauet ændres, skal man
vælge et nyt program
Lav varme – Indikatorlys TÆNDT Høj varme – Indikatorlys SLUKKET
Tøm vand indikator – Lyser når vandbeholderen er fuld
Filterpleje-indikator – Lyser når filtret skal renses
Forsinket start-knap – Lader brugeren vælge en anden startstid (se detaljerede
Oplysninger på side 34)
Displayet
START – Når tørretumbleren tændes, blinker START-indikatoren, når programmet starter
lyser START-indikatoren
60' – indikatoren lyser når der er mindre end 60 min. tilbage af programmet
15' – indikatoren lyser når der er mindre end 15 min. tilbage af programmet. På dette
tidspunkt skifter tørretumbleren fra varm til kold luft
STOP – Indikatoren lyser, når programmet er færdigt
6h – 6 timers forsinket start (blinker når valgt)
9h – 9 timers forsinket start (blinker når valgt)
Knapper og indikatorer
AKRYL/
SYNTETISKE
STOFFER-KNAP
ON/OFF
(TÆND SLUK)-
KNAP
FILTERPLEJE-
INDIKATOR
TØM VAND
INDIKATOR
PROGRAM-
VÆLGER
START-
KNAP
START DELAY
(START
GENINDSTIL)-
KNAP
NEDTÆLLINGS-DISPLAY
40005040Dan.qxd 09/05/2007 11:41 Page 29
30
Åbning af lågen
Træk i håndtaget for at åbne lågen.
For at genstarte tørretumbleren, luk lågen og
tryk på Start.
Filter
VIGTIGT: For at bevare tørretumblerens
effektivitet skal det kontrolleres, at fnugfiltret er
rent før hver tørrecyklus.
1. Træk filtret opad.
2. Åbn filtret som vist.
3. Fjern forsigtigt bomuldsfibrene med en blød
børste eller fingerspidserne.
4. Smæk filtret sammen og skub det på plads.
Filterplejeindikator
lyser når filtret behøver rengøring.
Hvis vasketøjet ikke tørrer, skal det kontrolleres,
at filtret ikke er tilstoppet.
Låge og filter
ADVARSEL!
Når tørretumbleren er i brug kan
tromlen og lågen blive MEGET
VARME. Du må aldrig stoppe
tørretumbleren, før
tørreprogrammet er afsluttet,
medmindre tøjet tages ud og
spredes hurtigt, så det kan køles
ned.
40005040Dan.qxd 09/05/2007 11:41 Page 30
Loading...
