Candy GO DC57F User Manual
Instruction Book
GO DC57F
Condenser Tumble Dryer
®
English
Español
Português
Deutsch
40006166Eng.qxd 03/09/2009 11:13 Page 1
English . . . . . . . . . . . . . . . . . 2
Español . . . . . . . . . . . . . . . . 22
Português . . . . . . . . . . . . . . 42
Deutsch . . . . . . . . . . . . . . . . 62
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Delivery information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Unpacking the Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety reminders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
The Laundry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Environmental Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
GIAS Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Electrical requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Adjusting the feet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Ventilation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Preparing the load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Clothes preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Sorting the load. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Drying advice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Do not tumble dry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Energy saving. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Drying guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Selecting the Programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Door and Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Opening the door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Filter care indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Water container . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
To remove the container . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Condenser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
To remove the condenser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Cancelling and resetting the programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Start Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Cleaning and Routine Maintenance. . . . . . . . . . . . . . . . . . . . 18
Cleaning the dryer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Customer Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Spares. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
GIAS Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2
40006166Eng.qxd 03/09/2009 11:13 Page 2
Introduction
Please read and follow these instructions
carefully and operate the machine accordingly.
This booklet provides important guidelines for
safe use, installation, maintenance and some
useful advice for best results when using your
machine.
Keep all documentation in a safe place for future
reference or for any future owners
Delivery information
Please check that the following items are
delivered with the appliance:
● Instruction manual
● Guarantee card
● Energy label
Remove the machine from its packaging close to
the final location of the machine.
1. Cut carefully around the base of the
packaging and up one corner.
2. Remove the polythene sleeve and lift the
dryer off the polystyrene base.
3
Check that no
damage has
occurred to the
machine during
transit. If it has,
call for service by
GIAS.
Failure to comply
with the above
can compromise
the safety of the
appliance. You
may be charged
for a service call
if a problem with
your machine is
caused by
misuse.
Unpacking the product
Dispose of the packaging safely. Make
sure it is out of the reach of children,
it is a potential source of danger.
40006166Eng.qxd 03/09/2009 11:13 Page 3
Safety reminders
Installation
● Check that the product has no visible signs of damage before use. If damaged do
not use and please call GIAS Service.
● Do not use adapters, multiple connectors and/or extensions.
● Never install the dryer against curtains and be sure to prevent items from falling
or collecting behind the dryer.
● The appliance must not be installed behind a lockable door, a sliding door or a
door with a hinge on the opposite side to that of the tumble dryer.
Use
● This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
● Children should be supervised to ensure that they do not play with the appliance.
● WARNING Misuse of a tumble dryer may create a fire hazard.
● This machine is solely for domestic use, i.e. to dry household textiles and garments.
● This machine should only be used for its intended purpose as described in this
manual. Ensure that the instructions for installation and use are fully understood
before operating the appliance.
● Do not touch the appliance when hands or feet are damp or wet.
● Do not lean on the door when loading the machine or use the door to lift or
move the machine.
● Do not allow children to play with the machine or its controls.
● WARNING Do not use the product if the fluff filter is not in position or is
damaged; fluff could be ignited.
● WARNING Where the hot surface symbol is located the temperature rise
during operation of the tumble dryer may be in excess of 60 degrees C.
● Remove the plug from the electricity supply. Always remove the plug before
cleaning the appliance.
● Do not continue to use this machine if it appears to be faulty.
● Lint and fluff must not be allowed to collect on the floor around the outside of
the machine.
● The drum inside may be very hot. Always allow the dryer to complete the cool
down period before removing the laundry.
The Laundry
● Do not dry unwashed items in the tumble dryer.
● WARNING Do not tumble dry fabrics treated with dry cleaning fluids.
● WARNING Foam rubber materials can, under certain circumstances, when heated
become ignited by spontaneous combustion. Items such as foam rubber (latex
foam), shower caps, waterproof textiles, rubber backed articles and clothes or
pillows fitted with foam rubber pads MUST NOT be dried in the tumble dryer.
● Always refer to the laundry care labels for directions on suitability for drying.
4
40006166Eng.qxd 03/09/2009 11:13 Page 4
● Clothes should be spin dried or thoroughly wrung before they are put into the
tumble dryer. Clothes that are dripping wet should NOT be put into the dryer.
● Lighters and matches must not be left in pockets and NEVER use flammable
liquids near the machine.
● Glass fibre curtains should NEVER be put in this machine. Skin irritation may
occur if other garments are contaminated with the glass fibres.
● Items that have been soiled with substances such as cooking oil, acetone, alcohol,
petrol, kerosene, spot removers, turpentine, waxes and wax removers should be
washed in hot water with an extra amount of detergent before being dried in
the tumble dryer.
● Fabric softeners, or similar products, should be used as specified by the fabric
softener instructions.
Environmental Issues
● All packaging materials used are environmentally-friendly and recyclable. Please
help dispose of the packaging via environmentally-friendly means. Your local
council will be able to give you details of current means of disposal.
● To ensure safety when disposing of an old tumble dryer disconnect the mains
plug from the socket, cut the mains power cable and destroy this together with
the plug. To prevent children shutting themselves in the machine break the door
hinges or the door lock.
GIAS Service
●
To ensure the continued safe and efficient operation of this appliance we
recommend that any servicing or repairs are only carried out by an authorised
GIAS service engineer.
European directive 2002/96/EC
This appliance is marked according to the European directive 2002/96/EC on Waste
Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment
and human health, which could otherwise be caused by
inappropriate waste handling of this product.
The symbol on the product indicates that this product may not
be treated as household waste. Instead it shall be handed over
to the applicable collection point for the recycling of electrical
and electronic equipment.
Disposal must be carried out in accordance with local
environmental regulations for waste disposal.
For more detailed information about treatment, recovery and
recycling of this product, please contact your local city office,
your household waste disposal service or the shop where you
purchased the product.
5
If the appliance is not running properly or breaks down,
switch it off and disconnect the plug from the socket.
Consult GIAS Service for possible repair.
40006166Eng.qxd 03/09/2009 11:13 Page 5
Electrical requirements
Tumble dryers are supplied to operate at a
voltage of 230V, 50 Hz single phase. Check that
the supply circuit is rated to at least 10A.
Electricity can be extremely dangerous.
This appliance must be earthed.
The socket outlet and the plug on the appliance
must be of the same type.
Do not use multiple adapters and/or extension
leads.
The plug should be accessible for disconnection
after the appliance has been installed.
The wires in the mains lead are coloured in
accordance with the following codes:
Blue NEUTRAL
Brown LIVE
Green and Yellow EARTH
CE Appliance complies with European Directive
89/336/EEC, 73/23/EEC and subsequent amendments.
Adjusting the feet
Once the machine is in place the feet should be
adjusted to ensure that the machine is level.
6
You may be
charged for a
service call if a
problem with
your machine is
caused by
incorrect
installation.
If the mains cord
on this
appliance is
damaged, it
must be
replaced by a
special cord
which is ONLY
obtainable from
the spares
service. It must
be installed by a
competent
person.
Installation
Do not plug the machine in and
switch it on at the mains until the
installation is completed.
For your safety, this dryer must be
correctly installed.
If there is any doubt about
installation, call GIAS Service for
advice.
40006166Eng.qxd 03/09/2009 11:13 Page 6
Adequate ventilation must be provided in the
room where the tumble dryer is located to
prevent gases from appliances burning other
fuels, including open fires, being drawn into the
room during operation of the tumble dryer.
● Exhaust air must not be discharged into a
flue which is used for exhausting fumes
from appliances burning gas or other fuels.
● Check regularly that the air flowing through
the dryer is not restricted.
● Check the fluff filter after use, and clean, if
necessary.
● The inlet and outlets should be kept free
from obstructions. To ensure adequate
ventilation the space between the bottom
of the machine and the floor must not be
obstructed. There should be a gap of at
least 12mm between the machine and any
obstructions.
● Prevent items from falling or collecting
behind the dryer as these may obstruct the
air inlet and outlet.
● NEVER install the dryer up against curtains.
7
Ventilation
AIR OUTLETS
AIR OUTLETS IN THE BASE
AIR INLET VENTS
40006166Eng.qxd 03/09/2009 11:13 Page 7
Before using the tumble dryer for the first time:
● Please read this instruction book thoroughly.
● Remove all items packed inside drum.
● Wipe the inside of the drum and door with
a damp cloth to remove any dust which may
have settled in transit.
Clothes preparation
Make sure that the laundry you are going to dry
is suitable for drying in a tumble dryer, as shown
by the care symbols on each item.
Check that all fastenings are closed and that
pockets are empty. Turn the articles inside out.
Place clothes loosely in the drum to make sure
that they don't get tangled.
Maximum drying weight
● Cottons Max. 7 kg
● Synthetics Max. 3.5 kg
8
Preparing the load
Do not overload
the drum, large
items when wet
can exceed the
maximum
admissible
clothes load
(for example:
sleeping bags,
duvets).
40006166Eng.qxd 03/09/2009 11:13 Page 8
Sort the load as follows:
● By care symbols
These can be found on the collar or inside
seam:
Suitable for tumble drying.
Tumble drying at high temperature.
Tumble drying at low temperature only.
Do not tumble dry.
If the item does not have a care label it
must be assumed that it is not suitable
for tumble drying.
● By amount and thickness
Whenever the load is bigger than the dryer
capacity, separate clothes according to
thickness (e.g. towels from thin underwear).
● By type of fabric
Cottons/linen: Towels, cotton jersey, bed and
table linen.
Synthetics: Blouses, shirts, overalls, etc.
made of polyester or polyamid, as well as
for cotton/synthetic mixes.
● By drying level
Sort into: iron dry, cupboard dry, etc. For
delicate articles press the button to
select low drying temperature.
9
40006166Eng.qxd 03/09/2009 11:13 Page 9
Do not tumble dry:
Woollens, silk, delicate fabrics, nylon stockings,
delicate embroidery, fabrics with metallic
decorations, garments with PVC or leather
trimmings, training shoes, bulky items such as
sleeping bags, etc.
Energy saving
Only put into the tumble dryer laundry which has
been thoroughly wrung or spin-dried. The drier
the laundry the shorter the drying time thus
saving electricity.
ALWAYS
● Try to dry the maximum weight of laundry,
this will save time and electricity.
● Check that the filter is clean before every
drying cycle.
NEVER
● Exceed the maximum weight, this will waste
time and electricity.
● Put dripping wet items into the tumble
dryer, this may damage the appliance.
10
Drying advice
IMPORTANT: Do
not dry articles
which have been
treated with a
dry cleaning fluid
or rubber clothes
(danger of fire or
explosion).
During the last
15 minutes the
load is always
tumbled in cool
air.
40006166Eng.qxd 03/09/2009 11:13 Page 10
Control panel and indicator lights
Programme Selector – Select the required programme
Delay Start button – Allows the user to delay the start of the drying cycle
(see details of Operation on page 17)
Start/Pause button – Press to commence the selected drying programme
Delicates button – Press to reduce the heat level for delicate items, the
indicator above the button will light up. To change the heat setting the
programme must be reset
Low Heat – Indicator light ON
High Heat – Indicator light OFF
Empty Water indicator – lights when the water container is full
Filter Care indicator – lights when the filter needs cleaning
Progress display
DRY – When the programme is selected the DRY indicator will flash, when the
programme starts the DRY indicator will light up.
– Indicator lights when there is a short time left until completion of the
programme. At this stage of the drying cycle the machine enters the Cool
Down phase.
The length of the Cool Down phase varies between 10 and 15 minutes
depending on the programme.
END - Indicator lights when the programme is finished.
11
Controls and indicators
DELICATES
BUTTON
FILTER CARE
INDICATOR
PROGRAMME
SELECTOR
START/PAUSE
BUTTON
DELAY START
BUTTON
PROGRESS
DISPLAY
EMPTY WATER
INDICATOR
40006166Eng.qxd 03/09/2009 11:13 Page 11
12
Selecting a Programme
The Candy Sensor Dry machine gives many options for drying the laundry to
suit all circumstances.
The table on the next page lists the programmes and the function of each
programme.
Note: The sensor may not detect a small load of small articles. For small loads
and separate items or pre-dried fabrics with low moisture content, use the
timed programmes. Set the programme between 30 and 75 minutes
depending on the load size and dryness required, and select high or low heat
depending upon the fabric type.
If the sensor does not detect the item the dryer will only operate for 10
minutes before going into cooldown.
If the load is too large or too wet to tumble dry the dryer will automatically
go into cooldown after approximately 3 hours.
40006166Eng.qxd 03/09/2009 11:13 Page 12
13
Programme
Bone Dry
Extra Dry
Cupboard Dry
Iron Dry
Wool Finish
Relax
40’ Rapid
150'
120'
90'
75'
60'
45'
30'
Refresh
Description
Select the degree of dryness that you require.
This ranges from for bath towels and bathrobes,
through for items that will be put away without
ironing, to the programme that leaves the laundry
suitable for ironing.
A gentle programme specially created to get woollens
softer after air-drying.
This delicate warm air cycle, lasting 12 minutes, can
also be used to get woollens 'refreshed' after being
stored in the wardrobe.
The Relax programme provides a conditioning and
anticrease function. The dryer will heat the load for 9
minutes followed by a 3 minute cool down period and
is especially good for garments which may have been
left for some time prior to ironing, in a linen basket for
example. Garments may also become stiffened when
dried outside on a washing line or inside on radiators.
This programme relaxes the creases in the fabric
making ironing quicker and easier.
The 40’ Rapid programme allows a drying cycle to be
completed quickly. This is an ideal programme for
having dry, refreshed and ready-to-wear clothes in less
than 40'. This special programme constantly monitors
the dryness and temperature in the drum thanks to the
sensor using, using the exact time and energy you
need! The machine finishes the cycle when the
cupboard dry level is reached. The stated cycle length
could vary according to fabric types, load size and
residual moisture in the garments.
The maximum load is 2kg and the programme is
suitable for all types of fabric where tumble drying is
appropriate.
150 minutes of drying
120 minutes of drying
90 minutes of drying
75 minutes of drying
60 minutes of drying
45 minutes of drying
30 minutes of drying
Tumbling the laundry in cool air for 20 minutes
40006166Eng.qxd 03/09/2009 11:14 Page 13
Opening the door
Pull on handle to open the door.
To restart the dryer, close the door and press .
Filter
IMPORTANT: To maintain the efficiency of the
dryer check that the fluff filter is clean before
each drying cycle.
1. Pull the filter upwards.
2. Open filter as shown.
3. Gently remove lint using a soft brush or
your fingertips.
4. Snap the filter together and push back into
place.
Filter Care Indicator
lights when the filter needs cleaning.
If the laundry is not drying check that the filter is
not clogged.
14
Door and Filter
WARNING!
When the tumble dryer is in use the
drum and door may be VERY HOT.
Never stop a tumble dryer before
the end of the drying cycle unless
all items are quickly removed and
spread out so that the heat is
dissipated.
DO NOT USE WATER TO CLEAN THE
FILTER
40006166Eng.qxd 03/09/2009 11:14 Page 14
The water removed from the laundry during the
drying cycle is collected in a container at the
bottom of the dryer.
When the container is full the indicator on
the control panel will light, and the container
MUST be emptied. However, we recommend that
the container is emptied after each drying cycle.
NOTE: Very little water will collect during the
first few cycles of a new machine as an internal
reservoir is filled first.
To remove the container
1. Gently pull the bottom of the kickplate so
that it unclips from the dryer. The top
section can then be unhinged allowing the
kickplate to be completely removed.
2. Pull firmly on the handgrip and slide the
water container out of the dryer.
Support the container with both hands. When
full, the water container will weigh about 4kg.
3. Open the lid located on the top of the
container and empty the water.
4. Refit the lid and slide the water container
back into position. PUSH FIRMLY INTO
PLACE.
5. Refit the kickplate by engaging the hinges
at the top and 'snapping' the lower clips
into place.
15
Water Container
40006166Eng.qxd 03/09/2009 11:14 Page 15
Important: Always switch off and remove the
plug from the electricity supply before
cleaning the condenser.
To maintain the efficiency of the dryer regularly
check that the condenser is clean.
To remove the
condenser
1. Remove the kickplate (see page 15).
2. Turn the two locking levers anti-clockwise
and pull out the condenser.
3. Pull out the condenser unit.
4. Gently remove any dust or fluff with a
cloth, then wash the unit by holding it
under a running tap turning it so that
water flows between the plates, to
remove any dust or fluff.
5. Refit the condenser ensuring it is in the
correct way (as indicated by the arrow)
and pushed firmly into place. Lock the
two levers by turning them clockwise.
6. Refit the kickplate.
16
Condenser
40006166Eng.qxd 03/09/2009 11:14 Page 16
17
Operation
1. Open the door and load the drum with
laundry. Ensure that garments do not hinder
closure of the door.
2. Gently close the door pushing it slowly until
you hear the door 'click' shut.
3. Turn the Programme Selector dial to select
the required drying programme (see
Programme Guide).
4. If drying synthetics, acrylics or delicate items,
press the button to reduce the heat
level.
The light next to the push button will light
up when the machine is in low heat setting.
To deselect in the first few minutes of the
programme, press the button, after this
time reset the machine to change the
setting.
5. Press the button. The dryer will start
automatically and the DRY indicator will be
continuously lit.
6. If the door is opened during the programme
to check the laundry, it is necessary to press
to recommence drying after the door
has been closed.
7. When the cycle is nearing completion the
machine will enter the cool down phase, the
clothes will be tumbled in cool air allowing
the load to cool down.
8. When the programme is complete the END
indicator will light.
9. Following the completion of the cycle the
drum will rotate intermittently to minimize
creasing. This will continue until the machine
is switched OFF or the door is opened.
WARNING!
The drum, door
and load may be
very hot.
40006166Eng.qxd 03/09/2009 11:14 Page 17
18
Cancelling and resetting the
programme
To cancel a programme press the button for 3 seconds. The DRY light will
flash to indicate that it has been reset.
Start Delay
The Delay Start Function allows the user to delay the start of the drying
cycle by 3, 6 or 9 hours.
When the function is first selected the display will show a delay of 3 hours,
subsequent presses of the button will increase the delay to 6 or 9 hours.
To commence the programme press and the appliance will complete the
drying cycle at the end of this time. The 3, 6 or 9 hour indicator light will flash
to indicate that the start delay is in progress.
Cleaning the dryer
● Clean the filter and empty the water
container after every drying cycle.
● Regularly clean the condenser.
● After each period of use, wipe the inside of
the drum and leave the door open for a
while to allow circulation of air to dry it.
● Wipe the outside of the machine and the
door with a soft cloth.
● DO NOT use abrasive pads or cleaning
agents.
● To prevent the door sticking or the build up
of fluff periodically clean the inner door and
gasket with a damp cloth.
Technical specifications
Drum capacity 115 litres
Maximum load 7 kg
Height 85cm
Width 60cm
Depth 60cm
Energy Label Band B
IMPORTANT
Always switch
off and remove
the plug from
the electricity
supply before
cleaning this
appliance.
For electrical data
refer to the
rating label on
the front of the
dryer cabinet
(with the door
open).
Cleaning and Routine
Maintenance
40006166Eng.qxd 03/09/2009 11:14 Page 18
19
What might be the cause of...
Defects you can remedy yourself
Before calling GIAS Service for technical advice please run through the
following checklist. A charge will be made if the machine is found to be
working or has been installed incorrectly or used incorrectly. If the problem
persists after completing the recommended checks, please call GIAS Service,
they may be able to assist you over the telephone.
Drying time is too long/clothes are not dry enough…
● Have you selected the correct drying time/programme?
● Were the clothes too wet? Were the clothes thoroughly wrung or spin-
dried?
● Does the filter need cleaning?
● Does the condenser need cleaning?
● Is the dryer overloaded?
● Are the inlets, outlets and base of the dryer free from obstructions?
● Has the option been selected from a previous cycle?
The dryer does not operate…
● Is there a working electricity supply to the dryer? Check using another
appliance such as a table lamp.
● Is the plug properly connected to the mains supply?
● Is there a power failure?
● Has the fuse blown?
● Is the door fully closed?
● Is the dryer switched on, both at the mains supply and at the machine?
● Has the drying time or the programme been selected?
● Has the machine been switched on again after opening the door?
● Has the dryer stopped operating because the water tray is full and needs
emptying?
The dryer is noisy…
● Switch off the dryer and contact GIAS Service for advice.
The Indicator is on…
● Does the filter need cleaning?
● Does the condenser need cleaning?
Indicator is on…
● Does the water container need emptying?
Troubleshooting
40006166Eng.qxd 03/09/2009 11:14 Page 19
Should there still be a problem with your dryer
after completing all the recommended checks,
please call GIAS Service for advice. They may be
able to assist you over the telephone or arrange for
a suitable appointment for an engineer to call
under the terms of your guarantee. However, a
charge may be made if any of the following applies
to your machine:
● Is found to be in working order.
● Has not been installed in accordance with
the installation instructions.
● Has been used incorrectly.
Spares
Always use genuine spares, available direct from
GIAS Service.
GIAS Service
For service and repairs call your local GIAS Service
engineer.
The manufacturer declines all responsibility in the
event of any printing mistakes in this booklet. The
manufacturer also reserves the right to make
appropriate modifications to its products without
changing the essential characteristics.
20
Customer Service
40006166Eng.qxd 03/09/2009 11:14 Page 20
21
40006166Eng.qxd 03/09/2009 11:14 Page 21
Introducción . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Información de entrega . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Desembalaje del producto . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Advertencias sobre seguridad . . . . . . . . . . . . . . . . . . . . . . . . . .24
Instalación . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Uso . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
La colada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Temas medioambientales . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Servicio técnico de GIAS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Instalación . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Requisitos eléctricos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Ajuste de las patas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Ventilación . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Preparación del material para secar . . . . . . . . . . . . . . . . . . . .28
Preparación de la ropa . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Clasificación del material para secar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Consejos para el secado . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
No secar en secadora . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Ahorro de energía . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Guía de secado . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Controles e indicadores . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Selección del programa . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Puerta y filtro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Modo de abrir la puerta . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Filtro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Control de mantenimiento del filtro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Depósito del agua . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Modo de sacar el recipiente . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Condensador . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Modo de sacar el condensador . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Operación . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Modo de cancelar y restablecer el programa . . . . . . . . . . . . . . . . . . . . . . . . .38
Inicio diferido . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Limpieza y mantenimiento de rutina . . . . . . . . . . . . . . . . . .38
Limpieza de la secadora . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Especificaciones técnicas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Resolución de problemas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Servicio de atención al cliente . . . . . . . . . . . . . . . . . . . . . . . . . .40
Servicio de recambios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Servicio técnico de GIAS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
22
40006166Spa.qxd 03/09/2009 12:04 Page 22
Introducción
Por favor lea cuidadosamente estas instrucciones y
utilice la máquina según sus indicaciones. Este folleto
presenta directrices importantes para el seguro, la
instalación y el mantenimiento seguros y algunos
consejos útiles para obtener los mejores resultados de
su secadora.
Conserve toda la documentación en un lugar seguro
para referencia futura o para los dueños futuros
Información de entrega
Por favor verifique que los siguientes artículos hayan
sido entregados con el electrodoméstico:
● Manual de instrucciones
● Tarjeta de garantía
● Etiqueta de energía
Desembale la secadora en un lugar cercano al de su
instalación definitiva.
1. Corte con cuidado la base del embalaje y levante
una de las esquinas.
2. Retire la funda de plástico y saque la secadora de
la base de poliestireno.
23
Verifique que no se
hayan producido
daños al
electrodoméstico
durante el
transporte. De
haberlos, llame al
Servicio técnico de
GIAS.
El incumplimiento
de lo anterior
puede perjudicar a
la seguridad del
electrodoméstico.
Es posible que se le
cobre una llamada
al servicio técnico
si el problema con
el electrodoméstico
es el resultado de
un uso incorrecto.
Desembalaje del producto
Deshágase de los materiales de embalaje
de forma segura. Asegúrese de que estén
fuera del alcance de los niños, dado que
es una fuente potencial de peligro.
40006166Spa.qxd 03/09/2009 12:04 Page 23
Advertencias sobre seguridad
Instalación
●
Verifique que el producto no muestre daños visibles antes de usarlo. En caso de presentar
algún daño, no lo use y póngase en contacto con el Servicio técnico de GIAS.
●
No utilice adaptadores, conectores múltiples y/o alargaderas.
●
Nunca instale la secadora junto a cortinas, y procure que no caigan objetos ni se acumule
nada detrás de la secadora.
●
El electrodoméstico no debe instalarse detrás de una puerta con cierre, de una puerta
corredera ni de puertas cuyas bisagras se encuentren en el lado opuesto del lugar donde se
encuentra la secadora.
Uso
●
Este electrodoméstico no está diseñado para su utilización por parte de personas, incluidos
niños, con capacidades físicas, sensoriales o mentales reducidas, o sin experiencia y
conocimiento a menos que hayan sido supervisados o formados, por parte de una persona
responsable de su seguridad, en la utilización del electrodoméstico.
●
Debe asegurarse de que los niños no juegan con el electrodoméstico.
●
ADVERTENCIA El uso incorrecto de una secadora puede provocar riesgo de incendio.
●
Esta máquina está diseñada para su uso doméstico, es decir, para secar tejidos y prendas de
uso familiar.
●
Esta máquina debe usarse solamente para el propósito para el cual fue diseñada, tal y como
se describe en este manual. Asegúrese de que entiende todas las instrucciones de
instalación antes de utilizar el electrodoméstico.
●
No toque el electrodoméstico cuando tenga las manos o los pies mojados o húmedos.
●
No se apoye en la puerta al cargar la secadora ni utilice la puerta para levantar o mover la
máquina.
●
No permita a los niños jugar con la máquina ni los mandos.
●
ADVERTENCIA No use el producto si el filtro de pelusa no está en su lugar o si está dañado,
ya que la pelusa podría arder.
● ADVERTENCIA En el lugar donde aparezca el símbolo de superficie caliente , el
incremento de temperatura durante la operación de la secadora puede exceder los
60 grados centígrados.
●
Desconecte el enchufe de la red del suministro eléctrico. Siempre debe desenchufar la
máquina antes de limpiarla.
●
No siga usando esta máquina si pareciera tener algún desperfecto.
●
No hay que dejar que se acumulen lanilla y pelusas en el suelo alrededor de la máquina.
●
El tambor interior puede calentarse mucho. Antes de retirar la ropa de la máquina, siempre
deje que ésta termine de enfriarse.
La colada
●
No utilice la secadora con prendas que no haya lavado.
●
ADVERTENCIA No debe usarse para secar tejidos tratados con líquidos para limpieza en
seco.
●
ADVERTENCIA Los materiales de gomaespuma, en algunas circunstancias, pueden arder por
combustión espontánea si se calientan. Los artículos como gomaespuma (espuma de látex),
los gorros de ducha, los tejidos impermeables a base de goma, así como las almohadas o las
prendas de gomaespuma NO DEBEN secarse en la secadora.
24
40006166Spa.qxd 03/09/2009 12:04 Page 24
●
Consulte siempre las etiquetas sobre lavado de las prendas para conocer si se pueden secar
en secadora.
●
Antes de introducir ropa en la secadora, aquélla debe centrifugarse o escurrirse bien. Las
prendas que escurren agua NO deben introducirse en la secadora.
●
Deben sacarse de los bolsillos encendedores y cerillas y no se deben NUNCA usar líquidos
inflamables cerca de la máquina.
●
No se deben introducir NUNCA cortinas de fibra de vidrio en esta máquina. Puede
producirse irritación de la piel si otras prendas se contaminan con fibras de vidrio.
●
Las prendas que se hayan ensuciado con sustancias como aceite de cocina, acetona, alcohol,
gasolina, queroseno, limpiamanchas, trementina, ceras y limpiadores de ceras deben lavarse
en agua caliente con una cantidad extra de detergente antes de introducirse en la
secadora.
●
Los suavizantes de tejidos y los productos similares pueden utilizarse siguiendo las
instrucciones del suavizante.
Temas medioambientales
●
Todos los materiales de embalaje utilizados son ecológicos y reciclables. Por favor deshágase
de los materiales de embalaje por medios ecológicos. Su ayuntamiento podrá informarle de
los medios actuales de desecho.
●
Por razones de seguridad cuando se deseche una secadora, desenchufe el cable eléctrico de
la toma general, corte el cable y destrúyalo junto con el enchufe. Para evitar que los niños
se queden encerrados en la máquina, rompa las bisagras o la cerradura de la puerta.
Servicio técnico de GIAS
●
Para que esta máquina siga funcionando de modo seguro y eficiente, recomendamos que
todo mantenimiento o reparación sea efectuado únicamente por un ingeniero de
mantenimiento autorizado de GIAS.
Directiva europea 2002/96/EC
Este electrodoméstico está marcado conforme a la directiva Europea 2002/96/CE sobre los residuos
de aparatos eléctricos y electrónicos (WEEE).
Asegurándose que este producto ha sido eliminado correctamente,
ayudará a evitar posibles consecuencias negativas en el ambiente y la
salud humana, que pudieran ser consecuencia del tratamiento
inapropiado de los residuos de este producto.
El símbolo sobre el producto indica que este aparato no puede ser
tratado como un residuo doméstico normal, en su lugar deberá ser
entregado al centro de recogidas para reciclaje de aparatos eléctricos y
electrónicos.
La eliminación debe ser efectuada de acuerdo con las reglas
medioambientales vigentes para el tratamiento de los residuos.
Para información más detallada sobre el tratamiento, recuperación y
reciclaje de este producto, por favor contacte con la oficina competente
(del departamento de ecología y medioambiente), o su servicio de
recogida a domicilio si lo hubiera o el punto de venta donde compró el
producto.
25
Si el electrodoméstico no funciona correctamente o se avería,
apáguelo y desconecte el enchufe de la toma de corriente.
Consulte al Servicio técnico de GIAS para la posible reparación.
40006166Spa.qxd 03/09/2009 12:04 Page 25
Requisitos eléctricos
Las secadoras están preparadas para funcionar con un
voltaje monofásico de 230 V, a 50 Hz. Verifique que el
circuito de suministro tenga una corriente nominal de al
menos 10 A.
La electricidad puede ser muy peligrosa.
Este electrodoméstico debe conectarse a tierra.
La toma de corriente y el enchufe del electrodoméstico
deben ser del mismo tipo.
No utilice adaptadores múltiples y/o alargaderas.
Después de instalar la máquina, el enchufe debe quedar
en una posición accesible para su desconexión.
Los conductores del cable de conexión eléctrica son de
diferentes colores, según la codificación siguiente:
Azul NEUTRO
Marrón CON CORRIENTE
Verde y amarillo CONEXIÓN A TIERRA
Este electrodoméstico CE cumple la Directiva europea
89/336/EEC, 73/23/EEC y sus enmiendas subsiguientes.
Ajuste de las patas
Una vez que la máquina esté en su sitio, las patas deben
ajustarse para asegurarse de que esté nivelada.
26
Es posible que se le
cobre una llamada
al servicio técnico
si el problema con
el electrodoméstico
es el resultado de
una instalación
incorrecta.
Si se dañara el
cable eléctrico de
este
electrodoméstico,
debe
reemplazarse con
un cable especial
que se puede
obtener
ÚNICAMENTE del
Servicio de
recambios. Una
persona
capacitada debe
encargarse de la
instalación.
Instalación
No enchufe el electrodoméstico ni lo
encienda conectado a la red eléctrica
hasta que se haya completado la
instalación.
Por su seguridad, esta secadora debe
instalarse correctamente.
En caso de alguna duda acerca de la
instalación, llame al Servicio GIAS de
Atención al Cliente para obtener
información.
40006166Spa.qxd 03/09/2009 12:04 Page 26
Loading...
