Candy CVS 1745BK, CVS 1745BWDK, CVS 1745SK, CVS 1745SWDK, CVS 1745WK Instruction manual
...
Freezer - Fridge / User ManualEN
CVS 5166WK
Thank you for purchasing this product.
Before using your refrigerator, please carefully read this instruction manual in order
to maximize its performance. Store all documentation for subsequent use or for other
owners. This product is intended solely for household use or similar applications such as:
- the kitchen area for personnel in shops, ofces and other working environments
- on farms, by clientele of hotels, motels and other environments of a residential type
- at bed and breakfasts (B & B)
- for catering services and similar applications not for retail sale.
This appliance must be used only for purposes of storage of food, any other use is
considered dangerous and the manufacturer will not be responsible for any omissions.
Also, it is recommended that you take note of the warranty conditions.
Icon Type Meaning
WARNING Serious injury or death risk
RISK OF ELECTRIC SHOCK Dangerous voltage risk
SYMBOL ISO 7010 W021 Warning; Risk of re / ammable materials
CAUTION Injury or property damage risk
IMPORTANT Operating the system correctly
EN - 2
CONTENTS
1 SAFETY INSTRUCTIONS ................................................................................. 4
1.1 General Safety Warnings ...............................................................................................4
1.2 Safety Information ..........................................................................................................6
1.3 Installation warnings .......................................................................................................9
1.4 Electrical information (For UK type plug) ......................................................................10
1.5 During Usage................................................................................................................10
2 DESCRIPTION OF THE APPLIANCE ............................................................. 12
3 USING THE APPLIANCE ................................................................................12
3.1 Information on Less Frost Technology ..........................................................................12
3.2 Thermostat Setting .......................................................................................................12
3.3 Temperature Settings Warnings ...................................................................................13
3.4 Accessories ..................................................................................................................14
3.4.1 Ice Tray ......................................................................................................................14
3.4.2 The Plastic Scraper ...................................................................................................14
3.4.3 The Bottle Holder .......................................................................................................14
3.4.4 Adjustable Door Shelf ...............................................................................................14
4 FOOD STORAGE ............................................................................................ 15
4.1 Refrigerator Compartment ............................................................................................15
4.2 Freezer Compartment ..................................................................................................15
5 CLEANING AND MAINTENANCE ..................................................................18
5.1 Defrosting .....................................................................................................................18
5.2 Replacing the Light Bulb...............................................................................................20
6 SHIPMENT AND REPOSITIONING .................................................................21
6.1 Transportation and Changing Positioning.....................................................................21
6.2 Repositioning the Door .................................................................................................21
7 BEFORE CALLING AFTER-SALES SERVICE ............................................... 21
8 ENERGY SAVING ............................................................................................ 22
EN - 3
1 SAFETY INSTRUCTIONS
1.1 General Safety Warnings
Read this user manual carefully.
WARNING: Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear of
obstruction.
WARNING: Do not use mechanical devices or
other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
WARNING: Do not use electrical appliances inside
the food storage compartments of the appliance,
unless they are of the type recommended by the
manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: When positioning the appliance,
ensure the supply cord is not trapped or
damaged.
WARNING: Do not locate multiple portable socketoutlets or portable power supplies at the rear of the
appliance.
WARNING: In order to avoid any hazards resulting
from the instability of the appliance, it must be xed in
accordance with the following instructions:
If your appliance uses R600a as a refrigerant (this
information will be provided on the label of the cooler)
you should take care during transportation and
installation to prevent the cooler elements from being
EN - 4
damaged. R600a is an environmentally friendly and
natural gas, but it is explosive. In the event of a leak
due to damage of the cooler elements, move your
fridge away from open ames or heat sources and
ventilate the room where the appliance is located for a
few minutes.
• While carrying and positioning the fridge, do not
damage the cooler gas circuit.
• Do not store explosive substances such as aerosol
cans with a ammable propellant in this appliance.
• This appliance is intended to be used in household
and domestic applications such as:
– staff kitchen areas in shops, ofces and other
working environments.
– farm houses and by clients in hotels, motels and
other residential type environments.
– bed and breakfast type environments;
– catering and similar non-retail applications.
• If the socket does not match the refrigerator plug,
it must be replaced by the manufacturer, a service
agent or similarly qualied persons in order to avoid
a hazard.
• A specially grounded plug has been connected
to the power cable of your refrigerator. This plug
should be used with a specially grounded socket
of 13 amperes. If there is no such socket in your
house, please have one installed by an authorised
electrician.
EN - 5
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning use of the appliance in
a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children
without supervision.
• If the supply cord is damaged, it must be replaced
by the manufacturer, an authorised service agent or
similar qualied persons, in order to avoid a hazard.
• This appliance is not intended for use at altitudes
exceeding 2000 m.
1.2 Safety Information
The refrigerator contains a refrigerant gas (R600a:
isobutane) and insulating gas (cyclopentane), with
high compatibility with the environment, that are,
however, in ammable.
We recommend that you follow the following
regulations so as to avoid situations dangerous to you:
• Before performing any operation, unplug the power
cord from the power socket.
• The refrigeration system positioned behind and
inside the Wine Coolers contains refrigerant.
Therefore, avoid damaging the tubes.
• If in the refrigeration system a leak is noted, do not
touch the wall outlet and do not use open ames.
EN - 6
Open the window and let air into the room. Then call
a service centre to ask for repair.
• Do not scrape with a knife or sharp object to remove
frost or ice that occurs. With these, the refrigerant
circuit can be damaged, the spill from which can
cause a re or damage your eyes.
• Do not install the appliance in humid, oily or dusty
places, nor expose it to direct sunlight and to water.
• Do not install the appliance near heaters or
inammable materials.
• Do not use extension cords or adapters.
• Do not excessively pull or fold the power cord or
touch the plug with wet hands.
• Do not damage the plug and/or the power cord; this
could cause electrical shocks or res.
• It is recommended to keep the plug clean, any
excessive dust residues on the plug can be the
cause re.
• Do not use mechanical devices or other equipment
to hasten the defrosting process.
• Absolutely avoid the use of open ame or electrical
equipment, such as heaters, steam cleaners,
candles, oil lamps and the like in order to speed up
the defrosting phase.
• Do not use or store inammable sprays, such as
spray paint, near the Wine Coolers. It could cause an
explosion or re.
EN - 7
• Do not use electrical appliances inside the food
storage compartments, unless they are of the type
recommended by the manufacturer.
• Do not place or store inammable and highly volatile
materials such as ether, petrol, LPG, propane gas,
aerosol spray cans, adhesives, pure alcohol, etc.
These materials may cause an explosion.
• Do not store medicine or research materials in the
Wine Coolers. When the material that requires a
strict control of storage temperatures is to be stored,
it is possible that it will deteriorate or an uncontrolled
reaction may occur that can cause risks.
• Maintain the ventilation openings in the appliance
enclosure or in the built-in structure, free of
obstruction.
• Do not place objects and/or containers lled with
water on the top of the appliance.
• Do not perform repairs on this Wine Coolers. All
interventions must be performed solely by qualied
personnel.
• This appliance can be used by children aged from
8 years and above and by persons with reduced
physical, sensory or mental capabilities or with a lack
of experience and knowledge; provided that they
have been given adequate supervision or instruction
concerning how to use the appliance in a safe way
and understand the hazards involved.
EN - 8
• Children should not play with the appliance. Cleaning
and user maintenance should not be made by
children without supervision.
1.3 Installation warnings
Before using your fridge freezer for the rst
time, please pay attention to the following
points:
• The operating voltage for your fridge
freezer is 220-240 V at 50Hz.
• The plug must be accessible after
installation.
• Your fridge freezer may have an odour
when it is operated for the rst time.
This is normal and the odour will fade
when your fridge freezer starts to cool.
• Before connecting your fridge freezer,
ensure that the information on the
data plate (voltage and connected
load) matches that of the mains
electricity supply. If in doubt, consult a
qualied electrician.
• Insert the plug into a socket with an
efcient ground connection. If the
socket has no ground contact or the
plug does not match, we recommend
you consult a qualied electrician for
assistance.
• The appliance must be connected
with a properly installed fused socket.
The power supply (AC) and voltage at
the operating point must match with
the details on the name plate of the
appliance (the name plate is located
on the inside left of the appliance).
• We do not accept responsibility for
any damages that occur due to
ungrounded usage.
• Place your fridge freezer where it will
not be exposed to direct sunlight.
• Your fridge freezer must never be
used outdoors or exposed to rain.
• Your appliance must be at least 50
cm away from stoves, gas ovens and
heater cores, and at least 5 cm away
from electrical ovens.
• If your fridge freezer is placed next
to a deep freezer, there must be at
least 2 cm between them to prevent
humidity forming on the outer surface.
• Do not cover the body or top of fridge
freezer with lace. This will affect the
performance of your fridge freezer.
• Clearance of at least 150 mm is
required at the top of your appliance.
Do not place anything on top of your
appliance.
• Do not place heavy items on the
appliance.
• Clean the appliance thoroughly before
use (see Cleaning and Maintenance).
• Before using your fridge freezer,
wipe all parts with a solution of warm
water and a teaspoon of sodium
bicarbonate. Then, rinse with clean
water and dry. Return all parts to the
fridge freezer after cleaning.
• Use the adjustable front legs to make
sure your appliance is level and
stable. You can adjust the legs by
turning them in either direction. This
must be done before placing food in
the appliance.
• Install the two plastic distance guides
(the parts on the black
vanes -condenser- at
the rear) by turning it
90° (as shown in the
gure) to prevent the
condenser from
touching the wall.
• The distance between the appliance
and back wall must be a minimum of
75 mm.
EN - 9
1.4 Electrical information (For UK type
plug)
Warning! This appliance must be
earthed.
The mains lead of this appliance has been
tted with a specially earthed plug.
Important: Do not use the
appliance without the fuse cover in position.
Should the fuse need to be replaced, it
must be replaced with a 13A fuse, ASTA
approved to BS1362.
The plug must be used with a specially
easrthed socket of 13 amperes. If there is
no such socket in your house, please have
one installed by an authorised electrician.
The mains lead of this appliance has been
tted with a BS 1363A 13A fused plug. To
change a fuse in this type of plug, follow
the steps below:
1 Remove the fuse cover and fuse.
2 Fit replacement 13A fuse, ASTA approved
to BS 1362 type, into the fuse cover.
3 Replace fuse cover.
1.5 During Usage
• Do not connect your fridge freezer to
the mains electricity supply using an
extension lead.
• Do not use damaged, torn or old
plugs.
• Do not pull, bend or damage the cord.
• Do not use plug adapter.
• This appliance is designed for use by
adults. Do not allow children to play
with the appliance or hang off the
door.
• Never touch the power cord/plug with
wet hands. This may cause a short
circuit or electric shock.
• Do not place glass bottles or cans in
the ice-making compartment as they
will burst when the contents freeze.
• Do not place explosive or ammable
material in your fridge. Place drinks
with high alcohol content vertically
in the fridge compartment and make
sure their tops are tightly closed.
• When removing ice from the ice-
making compartment, do not touch it.
Ice may cause frost burns and/or cuts.
• Do not touch frozen goods with wet
hands. Do not eat ice-cream or
ice cubes immediately after they
are removed from the ice-making
compartment.
• Do not re-freeze thawed frozen food.
This may cause health issues such as
food poisoning.
Old and Out-of-order Fridges
• If your old fridge or freezer has a
lock, break or remove the lock before
discarding it, because children may
get trapped inside it and may cause
an accident.
• Old fridges and freezers contain
isolation material and refrigerant with
CFC. Therefore, take care not to harm
environment when you are discarding
your old fridges.
CE Declaration of conformity
By placing the mark on this product,
we are conrming compliance to all
relevant European safety, health and
environmental requirements which are
applicable in legislation for this product.
SCRAPPING OLD APPLIANCES
This appliance is marked according to
the European directive 2012/19/EU on
EN - 10
Waste Electrical and Electronic Equipment
(WEEE).
WEEE contains both polluting substances
(which can cause negative consequences
for the environment) and basic components
(which can be re-used). It is important
to have WEEE subjected to specic
treatments, in order to remove and dispose
properly all pollutants, and recover and
recycle all materials.
Individuals can play an important role in
ensuring that WEEE does not become an
environmental issue; it is essential to follow
some basic rules:
- WEEE should not be treated as
household waste;
- WEEE should be handed over to the
relevant collection points managed
by the municipality or by registered
companies. In many countries, for
large WEEE, home collection could be
present.
In many countries, when you buy a new
appliance, the old one may be returned
to the retailer who has to collect it free of
charge on a one-to-one basis, as long as
the equipment is of equivalent type and
has the same functions as the supplied
equipment.
Packaging and the Environment
Packaging materials protect your machine
from damage that may occur during
transportation. The packaging materials
are environmentally friendly as they are
recyclable. The use of recycled material
reduces raw material consumption and
therefore decreases waste production.
Notes:
• Please read the instruction manual
carefully before installing and
using your appliance. We are not
responsible for the damage occurred
due to misuse.
• Follow all instructions on your
appliance and instruction manual, and
keep this manual in a safe place to
resolve the problems that may occur
in the future.
• This appliance is produced to be used
in homes and it can only be used in
domestic environments and for the
specied purposes. It is not suitable
for commercial or common use. Such
use will cause the guarantee of the
appliance to be cancelled and our
company will not be responsible for
the losses to be occurred.
• This appliance is produced to be
used in houses and it is only suitable
for cooling / storing foods. It is not
suitable for commercial or common
use and/or for storing substances
except for food. Our company is
not responsible for the losses to be
occurred in the contrary case.
EN - 11
2 DESCRIPTION OF THE
APPLIANCE
1
(When the thermostat is positioned on top)
A
2
3
4
5
6
7
12
11
10
9
B
8
This presentation is only for
information about the parts of the
appliance. Parts may vary according to the
appliance model.
A) Refrigerator compartment
B) Freezer compartment
1) Thermostat box
2) Refrigerator shelves
3) Crisper cover
4) Crisper
5) Freezer drawers
6) Ice box tray
7) Plastic ice scraper *
8) Freezer glass shelves *
9) Bottle shelf
10) Egg holder
11) Adjustable door shelf * / door shelf
12) Door shelf
Lamp cover
Thermostat knob
3 USING THE APPLIANCE
3.1 Information on Less Frost
Technology
Thanks to the wrap around evaporator,
Less Frost technology offers more efcient
cooling, less manual defrost requirement,
and more exible storage room.
3.2 Thermostat Setting
The thermostat automatically regulates
the temperature inside the refrigerator and
freezer compartments. Cooler temperatures
can be obtained by rotating the knob to
higher numbers, 1 to 5.
Important note: Do not try to rotate
the knob beyond position 1, it will stop
your appliance from working.
When lighting and thermostat are positioned
on top
* In some models
EN - 12
Lamp cover
Thermostat knob
When lighting and thermostat are positioned
on side
Lamp cover
Thermostat knob
Thermostat Settings
• Set the knob to a low/medium position,
up to 3, for short-term storage of food
in the appliance.
• Set the knob to a medium position, 3
or 4, for long-term storage of food in
the appliance.
• Set the knob to 5 position for freezing
the fresh food. The appliance will run
for colder temperatures.
Note that: The ambient temperature,
the temperature of freshly stored food,
and how often the door is opened all affect
the temperature in the appliance. If
required, change the temperature setting.
3.3 Temperature Settings Warnings
• The ambient temperature, temperature
of the freshly stored food and how
often the door is opened affects
the temperature in the refrigerator
compartment. If required, change the
temperature setting.
• It is not recommended that you
operate your fridge in environments
colder than 10°C in terms of its
efciency.
• When setting the thermostat, take into
consideration how often the appliance
doors are opened and closed, how
much food is stored in the refrigerator,
and the environment in which the
refrigerator is located.
• When the appliance is rst switched
on, allow it to run for 24 hours in
order to reach operating temperature.
During this time, do not open the door
and do not keep a large quantity of
food inside.
• Unplug your appliance during a
power cut to prevent damage to the
compressor. Once power is restored,
delay plugging in your appliance
for 5 to 10 minutes. This will help
prevent damage to the appliance's
components.
• Your appliance is designed to
operate in the ambient temperature
ranges stated in the standards,
according to the climate class stated
in the information label. It is not
recommended that your fridge is
operated in the environments which
are outside of the stated temperature
ranges. This will reduce the cooling
efciency of the appliance.
• Your appliance is designed to operate
in the ambient temperature (ST/N =
16°C - 38°C) intervals stated in the
standards, according to the climate
class displayed on the information
label. We do not recommend
operating your appliance out of the
stated temperature limits in terms of
cooling effectiveness.
Climate
Class
T Between 16 and 43 (°C)
ST Between 16 and 38 (°C)
N Between 16 and 32 (°C)
SN Between 10 and 32 (°C)
Ambient Temperature oC
EN - 13
3.4 Accessories
3.4.1 Ice Tray
• Fill the ice tray with water and place in
the freezer compartment.
• After the water has completely frozen,
you can twist the tray as shown below
to remove the ice cubes.
3.4.2 The Plastic Scraper
After some time, frost will build up in certain
areas of the freezer. The frost
accumulated in the freezer
should be removed regularly.
Use the plastic scraper
provided, if necessary. Do not
use sharp metal objects for this
operation. They could puncture the
refrigerator circuit and cause irreparable
damage to the unit.
3.4.3 The Bottle Holder
Use the bottle holder to prevent bottles
from slipping or falling over.
3.4.4 Adjustable Door Shelf
Six different height adjustments can be
made to provide storage areas that you
need by adjustable door shelf.
To change the position of adjustable door
shelf ;
Hold the bottom of the shelf and pull the
buttons on the side of
the door shelf
direction of arrow.
(Fig.1)
Position door shelf
the height you need
by moving up and
down. After you get
Fig. 1
the position that you
want the door shelf,
release the buttons on
the side of the door
shelf (Fig.2) Before
releasing the door
shelf, move up down
and make sure the
Fig. 2
door shelf is xed.
Note: Before moving door shelf is
loaded, you must hold the shelf by
supporting the bottom. Otherwise, door
shelf could fall off the rails due to the
weight. So damage may occur on the door
shelf or rails.
EN - 14
Visual and text descriptions in
the accessories section may vary
according to the model of your
appliance.
4 FOOD STORAGE
4.1 Refrigerator Compartment
• To reduce humidity and avoid the
consequent formation of frost, always
store liquids in sealed containers
in the refrigerator. Frost tends to
concentrate in the coldest parts of the
evaporating liquid and, in time, your
appliance will require more frequent
defrosting.
• Never place warm food in the
refrigerator. Warm food should be
allowed to cool at room temperature
and should be arranged to ensure
adequate air circulation in the
refrigerator compartment.
• Make sure no items are in direct
contact with the rear wall of the
appliance as frost will develop and
packaging will stick to it. Do not open
the refrigerator door frequently.
• We recommend that meat and clean
sh are loosely wrapped and stored
on the glass shelf just above the
vegetable bin where the air is cooler,
as this provides the best storage
conditions.
• Store loose fruit and vegetable items
in the crisper containers.
• Store loose fruit and vegetables in the
crisper.
• Storing fruit and vegetables separately
helps prevent ethylene-sensitive
vegetables (green leaves, broccoli,
carrot, etc.) being affected by
ethylene-releaser fruits (banana,
peach, apricot, g etc.).
• Do not put wet vegetables into the
refrigerator.
• Storage time for all food products
depends on the initial quality of
the food and an uninterrupted
refrigeration cycle before refrigerator
storage.
• To avoid cross-contamination do not
store meat products with fruit and
vegetables. Water leaking from meat
may contaminate other products in the
refrigerator. You should package meat
products and clean any leakages on
the shelves.
• Do not put food in front of the air ow
passage.
• Consume packaged foods before the
recommended expiry date.
NOTE: Potatoes, onions and garlic
should not be stored in the refrigerator.
The table below is a quick guide to show
you the most efcient way to store the
major food groups in your refrigerator
compartment.
Food
Vegetables
and fruits
Meat and
sh
Fresh
cheese
Butter and
margarine
Bottled
products
e.g. milk
and
yoghurt
Eggs 1 month
Cooked
food
Maximum
storage time
1 week Vegetable bin
2 - 3 Days
3 - 4 Days
1 week
Until the
expiry date
recommended
by the
producer
All shelves
How and where to
store
Wrap in plastic foil,
bags, or in a meat
container and store
on the glass shelf
On the designated
door shelf
On the designated
door shelf
On the designated
door shelf
On the designated
egg shelf
4.2 Freezer Compartment
• The freezer is used for storing frozen
food, freezing fresh food, and making
ice cubes.
• To freeze fresh food, ensure that as
much of the surface of the food as
possible is in contact with the cooling
surface.
• Do not store fresh food next to frozen
food as it can thaw the frozen food.
• Before freezing fresh food, divide it
EN - 15
into portions that can be consumed in
one sitting.
• Consume thawed frozen food within a
short period of time after defrosting
• Never place warm food in the freezer
compartment as it will thaw the frozen
food.
• Always follow the manufacturer's
instructions on food packaging when
storing frozen food. If no information
is provided food, should not be stored
for more than 3 months from the date
of purchase.
• When purchasing frozen food, make
sure that it has been stored under
appropriate conditions and that the
packaging is not damaged.
• Frozen food should be transported in
appropriate containers and placed in
the freezer as soon as possible.
• Do not purchase frozen food if the
packaging shows signs of humidity
and abnormal swelling. It is probable
that it has been stored at an
unsuitable temperature and that the
contents have deteriorated.
• The storage life of frozen food
depends on the room temperature,
the thermostat setting, how often the
door is opened, the type of food, and
the length of time required to transport
the product from the shop to your
home. Always follow the instructions
printed on the packaging and never
exceed the maximum storage life
indicated.
• The maximum amount of fresh food (in
kg) that can be frozen in 24 hours is
indicated on the appliance label.
• For optimum appliance performance
to reach maximum freezing capacity,
set the refrigerator thermostat at 4 - 5
for 24 hours before placing fresh food
into the freezer.
• After placing fresh food into the
freezer, change the setting to 4 - 5 for
24 hours is generally sufcient. After
24 hours, you can reduce the setting
if required.
• To use the maximum capacity of the
freezer compartment, use the glass
shelves for the upper and middle
section, and use the lower basket for
the bottom section.
• Use the fast freezing shelf to freeze
home cooking (and any other food
which needs to be frozen quickly)
more quickly because of the freezing
shelf’s greater freezing power. Fast
freezing shef is the bottom drawer of
the freezer compartment.
NOTE: If you attempt to open the freezer
door immediately after closing it, you
will nd that it will not open easily. This
is normal. Once equilibrium has been
reached, the door will open easily.
Important note:
• Never refreeze thawed frozen food.
• The taste of some spices found
in cooked dishes (anise, basilica,
watercress, vinegar, assorted spices,
ginger, garlic, onion, mustard, thyme,
marjoram, black pepper, etc.) changes
and they assume a strong taste when
they are stored for a long period of
time. Therefore, add small amounts
of spices to food to be frozen, or the
desired spice should be added after
the food has thawed.
• The storage time of food is dependent
on the type of oil used. Suitable oils
are margarine, calf fat, olive oil and
butter. Unsuitable oils are peanut oil
and pig fat.
• Food in liquid form should be frozen in
plastic cups and other food should be
frozen in plastic folios or bags.
The table below is a quick guide to
show you the most efcient way to
store the major food groups in your freezer
compartment.
EN - 16
Meat and sh Preparation
Steak Wrap in foil 6 - 8
Lamb meat Wrap in foil 6 - 8
Veal roast Wrap in foil 6 - 8
Veal cubes In small pieces 6 - 8
Lamb cubes In pieces 4 - 8
Minced meat In packaging without using spices 1 - 3
Giblets (pieces) In pieces 1 - 3
Bologna sausage/salami Should be kept packaged even if it has a membrane
Chicken and turkey Wrap in foil 4 - 6
Goose and duck Wrap in foil 4 - 6
Deer, rabbit, wild boar In 2.5 kg portions or as llets 6 - 8
Freshwater sh
(Salmon, Carp, Crane,
Catsh)
Lean sh (Bass, Turbot,
Flounder)
Fatty shes (Tuna,
Mackarel, Bluesh,
Anchovy)
Shellsh Clean and in a bag 4 - 6
Caviar
Snails In salty water, or in an aluminium or plastic container 3
NOTE: Thawed frozen meat should be cooked as fresh meat. If the meat is not cooked after defrosting, it
must not be re-frozen.
After cleaning the bowels and scales of the sh,
wash and dry it. If necessary, remove the tail and
head.
In its packaging, or in an aluminium or plastic
container
Maximum storage time
(months)
2
4
2 - 4
2 - 3
Vegetables and Fruits Preparation
String beans and beans Wash, cut into small pieces and boil in water 10 - 13
Beans Hull, wash and boil in water 12
Cabbage Clean and boil in water 6 - 8
Carrot Clean, cut into slices and boil in water 12
Pepper
Spinach Wash and boil in water 6 - 9
Cauliower
Eggplant Cut into pieces of 2cm after washing 10 - 12
Corn Clean and pack with its stem or as sweet corn 12
Apple and pear Peel and slice 8 - 10
Apricot and Peach Cut into two pieces and remove the stone 4 - 6
Strawberry and
Blackberry
Cut the stem, cut into two pieces, remove the core
and boil in water
Remove the leaves, cut the heart into pieces and
leave it in water with a little lemon juice for a while
Wash and hull 8 - 12
Maximum storage time
(months)
8 - 10
10 - 12
EN - 17
Cooked fruits Add 10 % of sugar to the container 12
Plum, cherry, sourberry Wash and hull the stems 8 - 12
Maximum storage time
(months)
Bread 4 - 6 2 - 3 4-5 (220-225 °C)
Biscuits 3 - 6 1 - 1,5 5-8 (190-200 °C)
Pastry 1 - 3 2 - 3 5-10 (200-225 °C)
Pie 1 - 1,5 3 - 4 5-8 (190-200 °C)
Phyllo dough 2 - 3 1 - 1,5 5-8 (190-200 °C)
Pizza 2 - 3 2 - 4 15-20 (200 °C)
Dairy products Preparation
Packet (Homogenized)
Milk
Cheese - excluding
white cheese
Butter, margarine In its packaging 6
In its own packet 2 - 3 Pure Milk – in its own packet
In slices 6 - 8
5 CLEANING AND
MAINTENANCE
Disconnect the unit from the power
Thawing time at room
temperature (hours)
Maximum storage time
(months)
Thawing time in oven
Storage conditions
Original packaging may be
used for short-term storage.
Keep wrapped in foil for
longer periods.
5.1 Defrosting
Defrosting the Refrigerator
Compartment
(minutes)
supply before cleaning.
Do not wash your appliance by
pouring water on it.
Do not use abrasive products,
detergents or soaps for cleaning the
appliance. After washing, rinse with clean
water and dry carefully. When you have
nished cleaning, reconnect the plug to the
mains supply with dry hands.
• Make sure that no water enters the
lamp housing and other electrical
components.
• The appliance should be cleaned
regularly using a solution of
bicarbonate of soda and lukewarm
water.
• Clean the accessories separately by
hand with soap and water. Do not
wash accessories in a dish washer.
• Clean the condenser with a brush at
least twice a year. This will help you
to save on energy costs and increase
productivity.
The power supply must be
disconnected during cleaning.
• Defrosting occurs automatically in
the refrigerator compartment during
operation. The water is collected by
the evaporation tray and evaporates
automatically.
• The evaporation tray and the water
drain hole should be cleaned
periodically with the defrost drain plug
EN - 18
to prevent the water from collecting at
the bottom of the refrigerator instead
of owing out.
• You can also clean the drain hole by
pouring half a glass of water down it.
Freezer defrosting process
• Small amounts of frost will accumulate
inside the freezer, depending on
the length of time the door may be
left open or the amount of moisture
introduced. It is essential to ensure
that no frost or ice is allowed to form
in places where it will affect the close
tting of the door seal. This might
allow air to penetrate the cabinet,
encouraging continuous running of
the compressor. Thin frost formation
is quite soft and can be removed with
a brush or plastic scraper. Do not use
metal or sharp scrapers, mechanical
devices or other means to accelerate
the defrosting process. Remove all
dislodged frost from the cabinet oor.
It is not necessary to switch off the
appliance for the removal of thin frost.
• For the removal of heavy ice deposits,
disconnect the appliance from the
mains supply, empty the contents into
cardboard boxes and wrap in thick
blankets or layers of paper to keep
cool. Defrosting will be most effective
if carried out when the freezer is
nearly empty and should be carried
out as quickly as possible to prevent
an unnecessary increase in the
temperature of the contents.
• Do not use metal or sharp scrapers,
mechanical devices or other means
to accelerate the defrosting process.
An increase in temperature of frozen
food during defrosting will shorten
the storage life. Keep contents well
wrapped and cool while defrosting is
taking place.
• Dry the inside of the compartment with
a sponge or a clean cloth.
• To accelerate the defrosting process,
place one or more bowls of warm
water in the freezer compartment.
• Examine the contents when replacing
them in the freezer and if some of
the packages have thawed out, they
should be eaten within 24hours, or be
cooked and re-frozen.
• After defrosting is complete, clean the
inside of the appliance with a solution
of warm water and a little bicarbonate
of soda, then dry thoroughly. Wash all
removable parts in the same way and
reassemble. Reconnect the appliance
to the mains supply and leave for 2 to
3 hours on setting number '5' before
introducing the food back into the
freezer.
EN - 19
5.2 Replacing the Light Bulb
Important note: Unplug the unit from
the power supply before start the
process.
When lighting and thermostat are
positioned on top
2
1
4
3
1. Press the hooks on light cover. (Fig. 1)
2. Open the light cover towards arrow when
top hooks pull out from housing. (Fig. 2)
3. Pull out the cover towards arrow remove
it. (Fig. 3)
4. Turn the light bulb counter clockwise and
remove it. (Fig. 4)
5. Change the present light bulb with a new
one of not more than 15 W. (Fig. 4)
6. Implement the steps in reverse order.
7. After waiting 5 minutes, plug the unit.
When lighting and thermostat are
positioned on side
2
1
3
4
5
1. Remove the screw on the light cover by
screw driver. (Fig.1)
2. Press the hooks on light cover. (Fig. 2)
3. Open the light cover towards arrow when
top hooks pull out from housing. (Fig. 3)
4. Pull out the cover towards arrow remove
it. (Fig. 4)
5. Turn the light bulb counter clockwise and
remove it. (Fig. 5)
6. Change the present light bulb with a new
one of not more than 15 W. (Fig. 5)
7. Implement the steps in reverse order.
8. After waiting 5 minutes, plug the unit.
Replacing LED Lighting
If your appliance has LED lighting
contact the help desk as this should
be changed by authorized personnel only.
EN - 20
6 SHIPMENT AND
REPOSITIONING
6.1 Transportation and Changing
Positioning
• The original packaging and foam
may be kept for re-transportation
(optional).
• Fasten your appliance with thick
packaging, bands or strong cords
and follow the instructions for
transportation on the packaging.
• Remove all movable parts (shelves,
accessories, vegetable bins, and
so on) or x them into the appliance
against shocks using bands when repositioning or transporting.
Always carry your appliance in the
upright position.
6.2 Repositioning the Door
• It is not possible to change the
opening direction of your appliance
door if door handles are installed on
the front surface of the appliance
door.
• It is possible to change the opening
direction of the door on models
without handles.
• If the door-opening direction of your
appliance can be changed, contact
the nearest Authorised Service Centre
to change the opening direction.
7 BEFORE CALLING AFTER-
SALES SERVICE
If your refrigerator is not working properly,
there may be a minor problem. Check the
following.
The appliance does not operate
Check if:
• There is power
• The mains is connected
• The thermostat setting is on the “•”
position
• The socket is defective. To check this,
plug another working appliance into
the same socket.
The appliance performs poorly
Check if:
• The appliance is overloaded
• The doors are closed properly
• There is any dust on the condenser
• There is enough space near the rear
and side walls.
The appliance is noisy
The cooling gas which circulates in the
refrigerator circuit may make a slight
noise (bubbling sound) even when the
compressor is not running. Do not worry,
this is normal. If you hear a different sound,
check whether:
• The appliance is level
• Anything is touching the rear of the
appliance
• Objects in the appliance are vibrating.
There is water in the lower part of the
refrigerator
Check if:
The drain hole for the water is not clogged
(use defrost drain plug to clean the drain
hole).
Recommendations
• If the appliance is switched off or
unplugged, wait at least 5 minutes
before plugging the appliance in
or restarting it in order to prevent
damage to the compressor.
• The cooling unit of your refrigerator is
located at the rear of the appliance.
Therefore, water droplets or ice may
form on the rear surface of your
fridge due to the operation of the
compressor at specied intervals. This
is normal, there is no need to perform
a defrosting operation unless there is
excessive ice.
• If you do not intend to use your fridge
for a long period of time (such as
during the summer holidays), set
the thermostat to “•” position, defrost
and clean your fridge, leaving the
EN - 21
door open to prevent the formation of
mildew and odour.
• If a problem persists after you have
followed all the above instructions,
please consult the nearest authorised
service centre.
• The appliance you have purchased
is designed for domestic use only.
It is not suitable for commercial or
common use. If the consumer uses
the appliance in a way that does not
comply with this, we emphasise that
the manufacturer and the dealer will
not be responsible for any repair and
failure within the guarantee period.
8 ENERGY SAVING
For better energy saving we suggest :
1 Installing tge appliance away from heat
sources and not exposed to direct
sunlight and in a well ventilated roo.
2 Avoid putting hot food into the
refrigerator to avoid increasing the
internal temperature and therefore
causing continuos functionaliting of the
compressor.
3 Do not excessively stuff foods so as to
ensure proper air circulation.
4 Defrost the appliance in case there is ice
to facilitate the transfer of cold.
5 In case of absence of electrical energy, it
is advisable to keep the refrigerator door
closed.
6 Open or keep the doors of the appliance
open as little as possible.
7 Avoid adjusting the setting to
temperatures too cold.
8 Remove dust present on the rear of the
appliance.
9 Energy consumption of your appliance
is declared without drawers and fully
loaded in freezer compartmant.
10 For saving energy, do not use volume
between the load limit and the door,
along the load limit line. Load limit line
is also used in energy consumption
declaration.
EN - 22
EN - 23
EN - 24
EN - 25
52263735
Loading...
