BT BT-4 User Manual
01
* CONTENTS*
01. CONTENTS
02.SAFETY RULES / FOREWORD
03. WARRANTY
04. BARREL INSTALLATION / AIR CYLINDER INSTALLATION /
VELOCITY ADJUSTMET / LOADER INSTALLATION / LOADING PAINTBALLS
05. STORAGE / UNLOADING / REMOVING AIR SUPPLY / CLEANING /
DISSASSEMBLY & FIELD STRIPPPING
06. DISASSEMBLY & FIELD STRIPPPING CONT’D
07. REASSEMBLY / STORAGE & TRANSPORTATION
08. S.W.A.T. / BANSHEE / IRONHORSE
09. PARTS LIST
10. DIAGRAM
02
BT Paintball Designs, Inc.
Model BT-4
TM
No part of this document may be copied or reproduced without the prior written
consent of BT Paintball Designs, Inc.
Congratulations on your selection of the BT-4
TM
paintball marker. The BT-4
TM
is
made to provide you with many years of reliable performance. BT Paintball
Designs, Inc. is honored that you have chosen the BT-4
TM
as your marker of
choice and hope you enjoy using this high quality product.
BT-4
TM
Specifications
Model.................................................................................................................BT-4
Caliber................................................................................................................. .68
Action....................................................................................................Semi-Automatic
Powered.............................................................CO2 or Compressed Air (HP Output)
Cycle Rate.............................................................................................................13BPS
Main Body Material............................................................................................Aluminum
Accuracy Range.......................................................................................................150+ft
The BT-4
TM
comes with a removable barrel system. This feature allows the user
to select a barrel that is most suitable for the playing conditions. Standard bar-
rels are mirror-honed with a step-bore, porting and a stock length of 8 inches.
Rules of Safe Marker Handling
1. Treat every marker as if it were loaded.
2. Never look down the barrel of a paintball marker.
3. Keep your finger off the trigger until ready to shoot.
4. Never point the marker at anything you don’t wish to shoot.
5. Keep the marker on “safe” until ready to shoot.
6. Keep the barrel blocking device in/ on the marker’s muzzle when not shooting.
7. Always remove paintballs and propellant source before disassembly.
8. After removing propellant source, point marker in safe direction and discharge
until marker is degassed.
9. Store the marker unloaded and degassed in a secure place.
10. Follow warnings listed on propellant source for handling and storage.
11. Do not shoot at fragile objects such as windows.
12. Every person within range must wear eye, face and ear protection designed
specifically to stop paintballs and meeting ASTM standard F1776.
13. Always measure your marker’s velocity before playing paintball and never
shoot at velocities in excess of 91.44 meters (300 feet-per-second).
* READ OWNERS MANUAL BEFORE USING.*
BATTLE TESTED
03
B
BT PAINTBALL DESIGNS, INC.
LIMITED WARRANTY
BT PAINTBALL DESIGNS, INC. warrants the replacement of any original part due to defect in material and/or workmanship of this mar
ker. This
warranty will be in effect for twelve (12) months for parts and twelve (12) months for labor following the original date of pur
chase for the original
purchaser. Such warranty service will be provided only if the warranty registration card included with this manual is filled i
n completely and on file
at BT PAINTBALL DESIGNS, INC. All other service will be duly charged for and returned via UPS C.O.D.
BT PAINTBALL DESIGNS, INC. will replace without charge any original part that is determined by BT PAINTBALL DESIGNS, INC. to be def
ec-
tive under the terms of this warranty. However, shipping charges are not covered hereunder. Failure due to an accident, abuse
, neglect, modi-
fication, normal wear, operator error, maintenance by other than an authorized BT PAINTBALL DESIGNS, INC. dealer, or use of parts
inconsistent with the use originally intended for the marker as sold, is not covered by this warranty.
There are no other warranties or guarantees, expressed or implied, made by BT PAINTBALL DESIGNS, INC. on this marker. The sole a
nd exclu-
sive liability of BT PAINTBALL DESIGNS, INC. and/or its authorized dealers, affiliates, or agents pursuant to this warranty will
be for repair or
replacement of the defective part; incidental or consequential damages are expressly excluded hereunder.
BT PAINTBALL DESIGNS, INC., its authorized dealers, affiliates, or agents, will not be liable under this warranty, nor under any
state or federal
law, or the common law or otherwise for any damage or failure, including personal injury, resulting from such use and/or altera
tion. This warran-
ty gives you specific legal rights, and you may also have other rights that may vary from state to state.
BATTLE TESTED
For warranty parts, service or information contact:
BT PAINTBALL DESIGNS, INC.
3217 EAST WASHINGTON BLVD.
FORT WAYNE, INDIANA 46803
260-424-9100
