BT 500 Kit, 500 User Manual

User Guide

Broadband Extender 500 Kit

Follow the steps in this guide to set up your kit.

If you need some help, see the Frequently Asked Questions at bt.com/producthelp or call 0808 100 6116*.

* Calls made from within the UK mainland network are free. Mobile and International call costs may vary.

1 Plug one extender near your router

2 Plug one extender near your device

3 Connect your device

Check box content:

Broadband Extender

Data

Ethernet

Power

Broadband Extender

Data

Ethernet

Power

2 x Broadband Extender 500 2 x Ethernet cables

Find out more

• If you need more detailed instructions, Frequently Asked Questions are
available at bt.com/producthelp

• If you cannot find the answer to your problem in the Frequently Asked Questions,

then please call our free Helpline on 0808 100 6116*. Our dedicated advisors
are more likely to be able to help you than the retailer where you made
your purchase.

1 Plug one extender near

your router

1 Plug one end of the ethernet cable into a spare ethernet socket on your router/hub.

2 Plug the other end into either of the extenders.

IMPORTANT: to work properly, extenders must be plugged directly into the wall

socket and not into extension leads.

3 Plug the extender directly into a wall power socket. Make sure the socket’s switched on.

1

2

3

2 Plug one extender near

your device

1 Plug the other extender directly into a wall power socket near the device you want

to connect. Make sure the socket’s switched on.

2 Wait for connection to complete. Give it a couple of minutes. If everything’s okay,

the Power and Data indicators on both extenders will light up.

See Connection help overleaf if the Data indicator doesn’t light up on the extenders.

È

1 2
