BT 400 Plus User Manual

Paragon 400 Plus ~ 3rd Edition ~ 5th August ’03 ~ 5290
User Guide
BT PARAGON 400 PLUS
DIGITAL TELEPHONE ANSWERING MACHINE
This product is intended for connection to analogue public switched telephone networks and private switchboards in the United Kingdom.
Paragon 400 Plus ~ 3rd Edition ~ 5th August ’03 ~ 5290
Please open this page for a further ‘at a glance’ guide to your BT Paragon 400 Plus.
Paragon 400 Plus ~ 3rd Edition ~ 5th August ’03 ~ 5290
At a glance
Display
Inductive coupler
Vol
Adjusts the volume of the
loudspeaker when playing
back messages and memos.
Del
Deletes messages.
Answer On/Off
Switches the answering
machine on and off.
Play
Plays back messages.
Monitor
Allows you to dial and
hear if a call has been
answered without lifting
the handset.
Memo
Leave yourself or another
user a reminder message
instead of a written note.
 
Lets you skip for war ds and backwards through your messages.
Used to select set-up options. Allows you to change the
display contrast.
Menu
Lets you select the function you want from the range of options.
Handset park
Use when telephone is wall mounted to rest the handset temporarily during a call.
Secrecy
Allows you to talk to
someone close by without the
person on the other end of the
telephone line being able to
hear the conversation.
Quickdial buttons
Store and dial 10 numbers at the touch of a button.
Shift
Lets you store and dial a further 10 numbers by pressing just two buttons.
Redial/Pause
Redial the last 5 numbers called.
Also lets you enter a pause when
storing numbers in the memor y.
Recall
For use when
connected to a switchboard
or BT Calling Features.
Microphone
For recording memos and your outgoing message.
Mailboxes 2 and 3
Directory label
Dial/OK
Confirms the setting you want.
Also dials out.
1
Memo
Vol
Answer on off
Secrecy
Recall
Redial
BT Paragon 400 Plus
MESSAGES
0 I 7 I I I 022 9 3 02
Dial/OK
D
A
B
E
C
1
G
H
I
4
Q
P
R
S
7
23
J
5
T
8
F
K
N
M
L
O
6
W
U
X
V
Y
Z
9
0
Shift
Monitor
Menu
Del
Play
2
3
NO.




Mic
3
Paragon 400 Plus ~ 3rd Edition ~ 5th August ’03 ~ 5290
In this guide
At a glance 1 Introduction 4
For your records 4 Unpacking your Paragon 400 Plus 4
Setting up 5
Safety 5 Plan the location of your Paragon 400 Plus 5
Using the telephone 10
Making and ending calls 10 Using the quickdial memory 11 Two way recording 12
Using the answering machine 13
Selecting the answering machine mode 13 Using the Mailboxes 13 To use the pre-recorded outgoing
message and announcement 14 Message and Ring indicator 16 To use Caller return (Auto 1471) 17 Using VIP 18 Using Remote access 19
Optional settings 21 Help 23 General information 24
Help and advice 23 Guarantee 24 Technical information 24
Wall-mounting template 26 Index 27
4
Paragon 400 Plus ~ 3rd Edition ~ 5th August ’03 ~ 5290
Introduction
Your Paragon 400 Plus has been designed for ease of use and made to the high standards set by BT.
Unpacking your Paragon 400 Plus
If anything is missing, please contact your place of purchase immediately.
●
Paragon 400 Plus telephone answering machine.
●
Handset and cord.
●
Plug mounted, 13 amp mains
adaptor.
●
Line cord.
●
Wall mounting plugs and screws.
●
Plinth for desk mounting
●
Remote access card. Spare memory label.
You can expect your Paragon 400 Plus to give you many years of trouble-free service.
Please read the instr uctions carefully befor e use and keep this User Guide for future reference.
For your records
For guarantee purposes, proof of purchase is required, so please keep your receipt.
Enter your Remote access PIN here
See page19 for more information about your PIN.
Date of purchase:
Place of purchase:
Serial number (on the underside of the telephone base):
Purchase price:
Remote access menu
Press to:
H
ear m
ain m
essag
e.
Play m
essages.
Repeat m
essage and play
previous m
essage.
D
elete the m
essage being
played or delete all m
essages
at th
e end o
f playback.
Skip to next m
essag
e.
P
lay outgoing
m
essage.
Record outgoing m
essage.
A
nsw
er on/off.
1
2
A
B
C
4
G
H
I
5
J
K
L
6
M
N
O
8
T
U
V
9
W
X
Y
Z
0
Operating your Paragon 400
from another telephone
To play back messages:
•Ring your answering machine as normal.
•Press during the outgoing message. You hear two beeps.
•Use the keypad to enter your security PIN. Wait to hear the confirmation beep after each digit.
•After the last digit, the prompt says: “You
have X messages”and begins to play them.
•You can now control your answering
machine by pressing the appropriate button
on the keypad.
(P
lease see ov
er)
INTRODUCTION
BT Paragon 400 Plus
Menu
Memo
MESSAGES
Del
Vol
0 I 7 I I I 02293 02
Answer
Play
on off
Dial/OK
NO.
D
A
B
E
C
F

1
23
Secrecy

G
K
J
H
N
M
L
O
I
4
6
5

Recall
Q
P
W
T
U
X
R
V
Y
S
Z
8
9
7

Redial

0
Shift
Monitor
2
3
ic M
Plan the location of your Paragon 400 Plus
Situate your Paragon 400 Plus close enough to both the phone and mains power sockets so that the cables will reach.
Your Paragon 400 Plus should be kept free of dust, moisture, high temperature, vibration and should not be exposed to direct sunlight. Do not stand it on carpets or other sur faces which generate fibres or place it in locations which prevent the free flow of air over its surfaces.
5
Paragon 400 Plus ~ 3rd Edition ~ 5th August ’03 ~ 5290
Setting up
Follow these steps to set up your Paragon 400 Plus ready for use.
Warning
The apparatus is designed to be operated in a normal office or domestic environment where
the relative humidity does not exceed 75%.
It should not be used in bathrooms or near water.
SETTING UP
• Use only the power adaptor supplied.
• There is a slight chance that your phone could be damaged by an electrical storm. We recommend that you unplug your Paragon 400 Plus from the mains power and telephone line socket during storms.
• The Paragon 400 Plus will produce a cer tain amount of heat during operation. Whilst this is entirely safe we would advise against placing the product on antique, veneered or wooden sur faces as damage may occur.
• Do not use your Paragon 400 Plus in damp, humid conditions such as bathrooms.
• Do not expose the equipment to fire or water.
• Simply clean your Paragon 400 Plus with a damp cloth (not wet) or an anti-static wipe. Never use a dr y cloth as this may cause a static shock.
Safety
6
Paragon 400 Plus ~ 3rd Edition ~ 5th August ’03 ~ 5290
SETTING UP
9V DC
HANDSET
2 Connect handset cord to base
3 Connect the telephone line cord
If you do not have a modern phone socket, call 0800 800 150 and ask for a BT engineer to come and fit the correct socket. This is a chargeable service.
9V DC
LINE
Although optional we r ecommend fitting an alkaline battery which will provide up to 25 hours back-up and ensure your messages are saved in the event of a mains power failure.
Ensure the Paragon 400 Plus is disconnected from the telephone line.
To fit the battery.
1 Lift the cover. 2 Insert one LR61 battery (not supplied).
The batter y compartment must be fully closed for the batter y to work.
Battery low warning
The display indicates when the battery power is
low. If no battery is inserted, it remains lit.
1 Insert back-up battery
2
1
7
Paragon 400 Plus ~ 3rd Edition ~ 5th August ’03 ~ 5290
SETTING UP
5
Plug the mains adaptor cord into the back of the telephone
9V DC
LINE
The Paragon 400 Plus automatically goes through a star t up pr ocess during which the display shows INITIALISING and the monitor light flashes.
On completion the unit display will show the time and number of messages.
6
Plug the mains adaptor into the wall socket and switch on
4 Check Dial Mode setting (default TB)
Use the dialling mode switch on the underside of your Paragon 400 Plus.
Your Paragon 400 Plus should be pre-set to TB which gives you Tone dialling. This ensures the phone will work with all modern digital exchanges.
If you do not get a dialling tone, tr y setting the dialling mode to P.
If you are connecting to a switchboard, check with your switchboard operator or communications manager which dialling mode you need. Your Paragon 400 Plus is approved for all compatible switchboards.
P T
TB
HANDSET
MODE
Note
For most switchboards the switch should be
set to T.
