Brother QL-600, QL-710W, QL-720NW Software Developer's Manual Raster Command Reference

Software Developer's Manual

Raster Command Reference QL-600/QL-710W/QL-720NW

Version 1.02

Microsoft and Windows are registered trademarks of Microsoft Corporation in the United States and other countries.

Each owner whose software title is mentioned in this document has a Software License Agreement specific to its proprietary programs. Any trade names and product names of companies appearing on Brother products, related documents and any other materials are all trademarks or registered trademarks of those respective companies.

IMPORTANT - PLEASE READ CAREFULLY

Note

This documentation (“Documentation”) provides information that will assist you in controlling your Printer QL-XXX (where “XXX” is the model name). You may use the Documentation only if you first agree to the following conditions. If you do not agree to the following conditions, you may not use the Documentation.

Condition of Use

You may use and reproduce the Documentation to the extent necessary for your own use of your Printer Model (“Purpose”). Unless expressly permitted in the Documentation, you may not; (i) copy or reproduce the Documentation for any purpose other than the Purpose,

(ii) modify, translate or adapt the Documentation, and/or redistribute it to any third party, (iii) rent or lease the Documentation to any third party, or, (iv) remove or alter any copyright notices or proprietary rights legends included within the Documentation.

No Warranty

a. Any updates, upgrades or alteration of the Documentation or Printer Model will be performed at the sole

discretion of Brother. Brother may not respond to any request or inquiry about the Documentation.

b. THIS DOCUMENTATION IS PROVIDED TO YOU "AS IS" WITHOUT WARRANTY OF ANY KIND,

WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE. BROTHER DOES NOT REPRESENT OR WARRANT THAT THIS DOCUMENTATION IS FREE FROM ERRORS OR DEFECTS.

c. IN NO EVENT SHALL BROTHER BE LIABLE FOR ANY DIRECT, INDIRECT, PUNITIVE, INCIDENTAL,

SPECIAL OR CONSEQUENTIAL DAMAGES OR ANY DAMAGES WHATSOEVER, ARISING OUT OF THE USE, INABILITY TO USE, OR THE RESULTS OF USE OF THE DOCUMENTATION OR ANY SOFTWARE PROGRAM OR APPLICATION YOU DEVELOPED IN ACCORDANCE WITH THE DOCUMENTATION.

Updates

Version

Date

Contents changed

1.01

03/21/2013

Initial version for QL-710W/ QL-720NW

1.02

01/29/2019

QL-600 added

Raster Command Reference

- i -

Contents

Introduction ······························································································ 1 About Raster Commands ············································································ 2

1. Printing Using Raster Commands ····························································· 3

2. Print Data ······························································································ 5

2.1 Print data overview ····················································································· 5

2.2 Sample (analyzing the print data of the test page) ·············································· 7

2.2.1 Preparation ...................................................................................................... 7

2.2.2 Checking the print data .................................................................................... 7

2.2.3 Explanation of print data for the test page ....................................................... 10

2.3 Page data details ······················································································ 12

2.3.1 Resolution ..................................................................................................... 12

2.3.2 Page size ...................................................................................................... 12

2.3.3 Feed amount ................................................................................................. 15

2.3.4 Maximum and minimum lengths ..................................................................... 16

2.3.5 Raster line ..................................................................................................... 17

3. Print Command List ··············································································· 20

4. Printing Command Details ······································································ 21

NULL Invalidate .............................................................................................. 21

ESC i S Status information request ..................................................................... 21

ESC @ Initialize................................................................................................. 27

ESC i d Specify margin amount (feed amount) .................................................... 27

ESC i a Switch dynamic command mode ............................................................ 28

g Raster graphics transfer ........................................................................ 28

ESC i B Specify baud rate .................................................................................. 29

Z Zero raster graphics .............................................................................. 29

FF Print command ...................................................................................... 29

Control-Z Print command with feeding ................................................................... 29

ESC i z Print information command .................................................................... 30

M Select compression mode ...................................................................... 31

ESC i A Specify the page number in “cut each * labels” ....................................... 32

ESC i M Various mode ........................................................................................ 33

ESC i K Expanded mode .................................................................................... 33

5. Flow Charts ·························································································· 34

5.1 Normal flow for USB connection ··································································· 34

5.2 Error flow for USB connection (when feeding at the end of the page) ······················ 35

5.3 Error flow for USB connection (with a concurrent printing error such as end of tape)··· 36

5.4 Cooling flow for USB connection ··································································· 37

5.5 Flow for setting serial connection baud rate (QL-710W / QL-720NW Only) ··············· 38

5.6 Normal flow for serial connection (QL-710W / QL-720NW Only) ···························· 39

5.7 Error flow for serial connection (QL-710W / QL-720NW Only) ······························· 40

5.8 Cleaning flow for serial connection (QL-710W / QL-720NW Only) ·························· 41

5.9 Normal Flow for Network (Standard TCP/IP port) Connection (QL-710W / QL-720NW Only) ·········································································································· 42

Appendix A: USB Specifications ································································· 43 Appendix B: Introducing the Brother Developer Center ·································· 44

Raster Command Reference

- 1 Introduction

Introduction

This material provides the necessary information for directly controlling the Brother printer QL-XXX (where “XXX” is the model name). This information is provided assuming that the user has full understanding of the operating system being used and basic mastery of USB and networks in a developer's environment. Details concerning the USB interface are not described in this material. If a USB interface is being used, refer to “Appendix A: USB Specifications” to prepare the interface.

Read the model names that appear in the screens in this manual as the name of your printer.

Raster Command Reference

- 2 -

About Raster Commands

Using raster commands a QL-XXX printer (where “XXX” is the model name) can be used to print without using our printer driver. This operation is useful in the following situations. ⚫ When printing from an operating system other than Windows

(Example: When printing from a Linux computer or mobile terminal) ⚫ When adding print functions to an existing system In addition, printing can be performed with advanced settings.

In this material, “raster” refers to binary bitmap data (collection of dots). Refer to this material to print by sending initialization commands and control codes together with raster data to the QL-XXX printer (hereafter, referred to as “printer”). This manual describes the procedure for adding these codes and sending the data.

Raster Command Reference

- 3 -

1. Printing Using Raster Commands

The printing procedure is described below. For detailed flow charts, refer to “5. Flow Charts”. For details on each command, refer to “4. Printing Command Details”.

(2) Receive the status

(Confirm the printer status.)

(1) Open the port

(5) Receive the status

(Confirm that printing is completed.)

(6) Close the port

Port

(4) Print

At your side

(3) Send the print data

Your printer

Computer, mobile terminal, etc.

Raster Command Reference

- 4 -

1. Printing Using Raster Commands

(1) Open the USB/serial/network port

Open the USB/serial/network port in the operating environment. The procedure for opening the USB/serial/network port is not described in this material.

(2) Confirm the printer status sent from the printer

The “status information request” command is sent to the printer, the status information received from the printer is analyzed, and then the status of the printer is determined.

For details on the “status information request” command and on the definitions of “status”, refer to “Status information request” in “4. Printing Command Details”.

(3) Send the print data

If the status analysis confirms that media compatible with the print data is loaded into the printer and that no error has occurred, the print data is sent. The structure of the print data is explained in the next section, “2. Print Data”.

Note: No command can be sent to the printer after the print data is transmitted and until the completion of printing is confirmed. Even the “status information request” command cannot be sent during printing.

(4) Print the data

(5) Confirm that printing is completed

When printing is completed, the status is received from the printer. If this status is analyzed to confirm that printing is completed, printing one page is considered finished. If the print job has multiple pages, (2) through (4) are repeated.

(6) Close the USB/serial/network port

After all printing is finished, close the USB/serial/network port.

Note: In order to print at high speed when a USB port is used to send uncompressed raster data, the Brother QL-XXX starts printing when it starts to receive print data, instead of waiting for a print command (concurrent printing). For the processing flow, for example when managing errors, refer to “5. Flow Charts”.

Raster Command Reference

- 5 -

2. Print Data

2.1 Print data overview

The print data is constructed of the following: (1) initialization commands, (2) control codes, (3) raster data, and (4) print commands. If the print job consists of multiple pages, (2) through (4) are repeated.

(1) Initialization commands

Specified only once at the beginning of the job.

Sequence

Command Name

Description/Example

1

Invalidate

Sends a 200-byte invalidate command, and then resets the printer to the receiving state.

2

Initialize

Initializes for printing. 1Bh, 40h (Fixed)

(2) Control codes

Added at the beginning of each page and sent for each page.

Sequence

Command Name

Description/Example

1

Switch dynamic command mode

Switches to raster mode. 1Bh, 69h, 61h, 01h

2

Print information command

Sets the print information for the printer. For 102-mm-wide continuous length tape: 1Bh, 69h, 7Ah, 86h, 0Ah, 66h, 00h, 09h, 07h, 00h, 00h, 00h, 00h

3

Various mode

To select “Auto Cut” 1Bh, 69h, 4Dh, 40h

4

Specify the page number in “cut each * labels”

When an auto cut setting is effective, specify the number of sheets for auto cut. For each sheets, 1Bh, 69h, 41h, 01h

5

Expanded mode

To select “Cut at End” flag 1Bh, 69h, 4Bh, 08h

6

Specify margin amount

Specifies the amount of the margins. For 3 mm margins: 1Bh, 69h, 64h, 23h, 00h

7

Select compression mode

(QL-710W / QL-720NW Only) Selects the compression mode for raster graphics. To send the data compressed to TIFF format: 4Dh, 02h

Raster Command Reference

- 6 -

2. Print Data

(3) Raster data

Repeated for each page in the print job.

Sequence

Command Name

Description/Example

-

Raster graphics transfer

Sends image data as commands.

-

Zero raster graphics

Sends image data for 1 blank line as a compression command. (Valid only when TIFF is selected as the compression mode) 5Ah (Fixed)

(4) Print commands

Specified at the end of the page.

Sequence

Command Name

Description/Example

-

Print command

Specifies at the end of a page that is not the last page. 0Ch

-

Print command with feeding

Specifies at the end of the last page. 1Ah (Fixed)

Last

Switch dynamic command mode

(QL-600 Only) Resets the command mode of the printer to default mode. 1Bh, 69h, 61h, FFh

Raster Command Reference

- 7 -

2. Print Data

2.2 Sample (analyzing the print data of the test page)

Based on print data created by the printer driver, descriptions of the commands introduced in the previous chapter are provided here. As an example, we will check the print data created when the [Print Test Page] button in the printer Properties dialog box is clicked to print the test page. Since the print data differs depending on the print settings of the printer, refer to this procedure and try creating print data with various print settings. Furthermore, this procedure is for the Windows® 7 operating environment. A similar procedure can be performed if you are using a different operating system.

Test page

Printer Properties

2.2.1 Preparation

Install the two listed below.

・ Printer driver of the Brother QL-XXX ・ Binary file editor

The data that we will analyze in this sample is a binary file. Therefore, use a binary file editor to display and check the contents of the binary file.

2.2.2 Checking the print data

The procedure for checking the print data is provided below.

Step 1: Change the port of the printer to “FILE:”. Step 2: Print the desired item (in this case, the test page), and then specify the file name. Step 3: Open the created file in the binary file editor to check it.

Raster Command Reference

- 8 -

2. Print Data

Step 1: Change the port of the printer to “FILE:”.

Open the Printers and Faxes folder, and then right-click the printer to display the Properties dialog box. In the Properties dialog box, click the [Ports] tab, select the “FILE:” check box, and then click the [Apply] button.

[Ports] tab of the printer Properties dialog box

Step 2: Print the item (in this case, the test page), and then specify the file name.

For this sample, print the test page with the default print settings, which were specified immediately after the printer driver was installed.

Default settings immediately after installation of the printer driver

Raster Command Reference

- 9 -

2. Print Data

When the test page is printed with the printer, a dialog box appears so that the file name can be specified. (Refer to the illustration below.) After a file name is typed in and the [OK] button is clicked, the printer driver creates the print data and saves it in a file with the specified name.

Dialog box for specifying the file name

Step 3: Open the print data in the binary file editor.

Open the saved file in the binary file editor. The rows of numbers that appear are the print data. (Refer to the illustration below.) The print data is constructed of the following: (1) initialization commands, (2) control codes, (3) raster data and (4) print commands, which were described in “2.1 Print data overview”. For details on the print

data, refer to “2.2.3 Explanation of print data for the test page”.

(1) Initialization commands

(2) Control codes

(4) Print commands

(3) Raster data

Print data

Raster Command Reference

- 10 -

2. Print Data

2.2.3 Explanation of print data for the test page

The print data for the test page outputted in the previous section is described below. The following illustration shows the print data created in section “2.2.1 Preparation” opened in the binary file editor.

1

5 7 11

* For QL-600, switch dynamic command mode (1B 69 61 FF) after position 12.

Print data

Raster Command Reference

- 11 -

2. Print Data

Descriptions for the numbers in the print data on the previous page are provided in the following table.

For details on each command, refer to “4. Printing Command Details”.

No.

Command Name

Description

１

Invalidate

A 200-byte invalidate command is sent.

2

Initialize

The “initialize” command is sent.

3

Switch dynamic command mode

The printer is switched to raster mode. Send this command before sending raster data to the printer.

4

Job ID setting commands

(QL-710W / QL-720NW Only) Internal specification commands Since this is a command for outputting with the commercial version driver, it is unnecessary for the user to send this command.

5

Print information command

Media size information for the print data is sent. This is the command for “1.1" × 3.5" (29 mm × 90 mm)” die-cut labels.

6

Various mode

(1Bh+69h+4Dh+00H)

This is the command for specifying settings such as cut options. Here, “auto cut” is specified.

7

Specify the page number in “cut each * labels”

The number of pages printed before automatically cutting is specified.

8

Expanded mode

This is the command for specifying expanded functions. Here, “cut at end” is specified.

9

Specify margin amount

Since a margin amount cannot be specified with die-cut labels, this command is sent with a margin amount of 0.

10

Select compression mode

(QL-710W / QL-720NW Only) TIFF compression mode is selected.

11

Raster data

Raster data continues.

12

Print command with feeding

Since one page will be printed, this is sent at the end of the first page.

13

Switch dynamic command mode

(QL-600 Only) This command resets to default mode that is switched by No.3. Send this command after [Print command with feeding] is sent.

Raster Command Reference

- 12 -

2. Print Data

2.3 Page data details

2.3.1 Resolution

Resolution

Height-to-Width Proportion

300 dpi high, 300 dpi wide

1:1

600 dpi high, 300 dpi wide

2:1

2.3.2 Page size

(a) Continuous length tape

Feeding direction

6

5

Landscape

3

1 4 2

Print area

6

5

3

1 4 2

Portrait

Feeding direction

Print area

Number 1 Width 2 Length 3 Print area width (maximum printing width) 4 Print area length 5 Width offset 6 Length offset

Raster Command Reference

- 13 -

2. Print Data

ID

Tape Size

Designation

1 2 3 4 5

6

257

12 mm

0.47"

12.0 mm 142 dots

→2.3.4

9.0 mm 106 dots

→2.3.4

1.5 mm 18 dots

→2.3.3

258

29 mm

1.1"

29.0 mm 342 dots

→2.3.4

25.9 mm 306 dots

→2.3.4

1.5 mm 18 dots

→2.3.3

264

38mm

38 mm

1.4"

38.0 mm 449 dots

→2.3.4

35.0 mm 413 dots

→2.3.4

1.5 mm 18 dots

→2.3.3

262

50 mm

1.9"

50.0 mm 590 dots

→2.3.4

46.9 mm 554 dots

→2.3.4

1.5 mm 18 dots

→2.3.3

261

54 mm

2.1"

53.8 mm 636 dots

→2.3.4

50.0 mm 590 dots

→2.3.4

1.9 mm 23 dots

→2.3.3

259

62 mm

2.4"

62.0 mm 732 dots

→2.3.4

58.9 mm 696 dots

→2.3.4

1.5 mm 18 dots

→2.3.3

Raster Command Reference

- 14 -

2. Print Data

(b) Die-cut labels

Print area

1

6

2

5

3

4

1

2

6

5

3

4

Print area

789

10

Number 1 Width 2 Length 3 Print area width (maximum printing width) 4 Print area length 5 Width offset 6 Length offset 7 Width offset of masked area 8 Length offset of masked area 9 Width of masked area 10 Length of masked area

Raster Command Reference

- 15 -

2. Print Data

ID

Label Size

1 2 3 4 5

6

269

17 mm x 54 mm

0.66" x 2.1"

17.0 mm 201 dots

53.9 mm 636 dots

14.0 mm 165 dots

47.9 mm 566 dots

1.5 mm 18 dots

3.0 mm 35 dots

270

17 mm x 87 mm

0.66" × 3.4"

17.0 mm 201 dots

86.9 mm 1026 dots

14.0 mm 165 dots

80.9 mm 956 dots

1.5 mm 18 dots

3.0 mm 35 dots

370

23 mm x 23 mm

0.9" x 0.9"

23.0 mm 272 dots

20.0 mm 236 dots

17.1 mm 202 dots

1.5 mm 18 dots

3.0 mm 35 dots

358

29 mm × 42 mm

1.1" x 1.6"

29.0 mm 342 dots

41.9 mm 495 dots

25.9 mm 306 dots

36.0 mm 425 dots

1.5 mm 18 dots

3.0 mm 35 dots

271

29 mm x 90 mm

1.1" x 3.5"

29.0 mm 342 dots

89.8 mm 1061 dots

25.9 mm 306 dots

83.9 mm 991 dots

1.5 mm 18 dots

3.0 mm 35 dots

272

38 mm x 90 mm

1.4" x 3.5"

38.0 mm 449 dots

89.8 mm 1061 dots

35.0 mm 413 dots

83.9 mm 991 dots

1.5 mm 18 dots

3.0 mm 35 dots

367

39 mm x 48 mm

1.5" x 1.8"

39.0 mm 461 dots

47.8 mm 565 dots

36.0 mm 425 dots

41.9 mm 495 dots

1.5 mm 18 dots

3.0 mm 35 dots

374

52 mm x 29 mm 2" x 1.1"

52.0 mm 614 dots

28.9 mm 341 dots

48.9 mm 578 dots

22.9 mm 271 dots

1.5 mm 18 dots

3.0 mm 35 dots

383

60 mm x 86 mm

2.3" x 3.4"

60.0 mm 708 dots

86.8 mm 1024 dots

56.9 mm 672 dots

80.8 mm 954 dots

1.5 mm 18 dots

3.0 mm 35 dots

274

62 mm x 29 mm

2.4" x 1.1"

62.0 mm 732 dots

28.9 mm 341 dots

58.9 mm 696 dots

22.9 mm 271 dots

1.5 mm 18 dots

3.0 mm 35 dots

275

62 mm x 100 mm

2.4" x 3.9"

62.0 mm 732 dots

99.8 mm 1179 dots

58.9 mm 696 dots

93.9 mm 1109 dots

1.5 mm 18 dots

3.0 mm 35 dots

362

12 mm Dia

0.47" Dia

12.0 mm 142 dots

8.0 mm 94 dots

2.0 mm 24 dots

363

24 mm Dia

0.94" Dia

24.0 mm 284 dots

20.0 mm 236 dots

2.0 mm 24 dots

273

58 mm Dia

2.2" Dia

58.3 mm 688 dots

52.3 mm 618 dots

3.0 mm 35 dots

ID 7 8 9 10

273

19.64 mm 201 dots

53.9 mm 636 dots

14.0 mm 165 dots

47.9 mm 566 dots

*1 The number of dots in the table is for 300 dpi; it is difference in the high-resolution mode. *2 Margins of 3 mm (1.5 mm × 2) horizontally and 3 mm (1.5 mm × 2) vertically are added to a diameter of 16 mm.

2.3.3 Feed amount

The feed amount (left and right margins) is defined below.

Raster Command Reference

- 16 -

2. Print Data

Type

Minimum Margin Setting

Maximum Margin Setting

Continuous length tape

3 mm

0.12" 35 dots

127 mm 5" 1500 dots

Die-cut labels

The length offset indicated in “(b) Die-cut labels” of “2.3.2 Page size” is used. However, set “0” as the value of the “specify margin amount” command.

*1 The number of dots in the table is for 300 dpi; it is difference in the high-resolution mode.

2.3.4 Maximum and minimum lengths

The maximum and minimum lengths are defined below.

Type

Minimum Length

Maximum Length

Continuous length tape

12.7 mm 150 dots

1000 mm 11811 dots

Die-cut labels

Fixed

*1 The number of dots in the table is for 300 dpi; it is difference in the high-resolution mode.

Raster Command Reference

- 17 -

2. Print Data

2.3.5 Raster line

As shown below, the parts with data to be printed are converted with “raster graphics transfer”, and the parts with no data are converted with “zero raster graphics”. On the actual tape, margins (feed) are added specified with “various mode” at the beginning and the end.

Feeding direction

Print area

Rasterized

Feeding direction

Print area Print head

Expansion direction

RasterLine 3

RasterLine 2

RasterLine 1

Zero Raster 1

RasterLine 4

The following shows the relationship between the raster graphics parameters and the pixels.

MSB LSB

1stB

MSB LSB

2ndB

3rdB

4thB ...

Raster Command Reference

- 18 -

2. Print Data

Total number of pins: 720 pins

0 pin

First byte

Left and right margins

Last byte

Raster line

Feeding direction

Print area

Pins on print head

Number of print area pins

Number of pins for right margin

Total number of pins

Number of pins for left margin

Raster Command Reference

- 19 -

2. Print Data

Continuous length tape:

Tape Size

Number of Pins

for Left Margin

Number of Print

Area Pins

Number of Pins

for Right Margin

Number of Bytes for

Raster Graphics Transfer

12 mm

585

106

29

90

29 mm

408

306 6 90

38 mm

295

413

12

90

50 mm

154

554

12

90

54 mm

130

590 0 90

62 mm

12

696

12

90

Die-cut labels:

Label Size

Number of Pins

for Left Margin

Number of Print

Area Pins

Number of Pins

for Right Margin

Number of Bytes for

Raster Graphics Transfer

17mm x 54mm

555

165 0 90

17mm x 87mm

555

165 0 90

23mm x 23mm

442

236

42

90

29mm x 42mm

408

306 6 90

29mm x 90mm

408

306 6 90

38mm x 90mm

295

413

12

90

39mm x 48mm

289

425 6 90

52mm x 29mm

142

578 0 90

60mm x 86mm

24

672

24

90

62mm x 29mm

12

696

12

90

62mm x 100mm

12

696

12

90

12mm Dia

513

94

113

90

24mm Dia

442

236

42

90

58mm Dia

51

618

51

90

Raster Command Reference

- 20 -

3. Print Command List

ASCII Code

Binary Code

Description

NULL

00

Invalidate

ESC i S

1B 69 53

Status information request

ESC @

1B 40

Initialize

ESC i d

1B 69 64

Specify margin amount (feed amount)

ESC i a

1B 69 61

Switch dynamic command mode

g

67

Raster graphics transfer

ESC i B

1B 69 42

Specify baud rate

Z

5A

Zero raster graphics

FF

0C

Print command

Control-Z

1A

Print command with feeding

ESC i z

1B 69 7A

Print information command

M

4D

Select compression mode

ESC i A

1B 69 41

Specify the page number in “cut each * labels”

ESC i M

1B 69 4D

Various mode

ESC i K

1B 69 4B

Expanded mode

Raster Command Reference

- 21 -

4. Printing Command Details

NULL Invalidate

ASCII: NULL Hexadecimal: 00

Description

⚫ Skipped ⚫ If data transmission is to be stopped midway, send the “initialize” command after sending the “invalidate”

command for the appropriate number of bytes to return to the receiving state, where the print buffer is

cleared.

ESC i S Status information request

ASCII: ESC i S Hexadecimal: 1B 69 53

Description ⚫ When a status information request is sent to the printer, a fixed size of 32 bytes is returned as a response

from the printer. For details on these 32 bytes, refer to the following page.

Note Before sending print data to the printer, this command should be sent once. Since error information is automatically sent by the printer during printing, do not send this command while printing. For details on transmission of the status, refer to “5. Flow Charts”.

Raster Command Reference

- 22 -

4. Printing Command Details

Number

Offset

Size

Name

Value/Reference

1 0 1

Print head mark

Fixed at 80h

2 1 1

Size

Fixed at 20h

3 2 1

Reserved

Fixed at “B” (42h)

4 3 1

Series code

Fixed at “4” (34h)

5 4 1

Model code

QL-710W: Fixed at “6” (36h) QL-720NW: Fixed at “7” (37h) QL-600: Fixed at “G” (47h)

6 5 1

Reserved

Fixed at “0” (30h)

7 6 1

Reserved

Fixed at “0” (30h)

8 7 1

Reserved

Fixed at “00h”

9 8 1

Error information 1

Refer to table (1) below.

10 9 1

Error information 2

Refer to table (2) below.

11

10

1

Media width

Refer to table (3) below.

12

11

1

Media type

Refer to table (4) below.

13

12

1

Reserved

Fixed at 00h

14

13

1

Reserved

Fixed at 00h

15

14

1

Reserved

Fixed at 3Fh

16

15

1

Mode

Value specified where the “various mode” command 00h if not specified

17

16

1

Reserved

Fixed at 00h

18

17

1

Media length

Refer to table (3) below.

19

18

1

Status type

Refer to table (5) below.

20

19

1

Phase type

Refer to table (6) below.

21

20

1

Phase number (higher order bytes)

22

21

1

Phase number (lower order bytes)

23

22

1

Notification number

Refer to table (7) below.

24

23

1

Reserved

Fixed at 00h

25

24

8

Reserved

Fixed at 00h

Raster Command Reference

- 23 -

4. Printing Command Details

(1) Error information 1

Flag

Mask

Definition

Bit 0

01h

“No media” error

Bit 1

02h

“End of media” error (only for die-cut labels)

Bit 2

04h

Cutter jam

Bit 3

08h

(Not used)

Bit 4

10h

Printer in use

Bit 5

20h

Printer turned off

Bit 6

40h

High-voltage adapter (not used)

Bit 7

80h

Fan motor error (not used)

(2) Error information 2

Flag

Mask

Definition

Bit 0

01h

“Replace media” error

Bit 1

02h

“Expansion buffer full” error

Bit 2

04h

Communication error

Bit 3

08h

“Communication buffer full” error (not used)

Bit 4

10h

“Cover open” error

Bit 5

20h

Cancel key (not used)

Bit 6

40h

Media cannot be fed (also when the media end is detected)

Bit 7

80h

System error

Raster Command Reference

- 24 -

4. Printing Command Details

(3) Media width and length

The media width and length is described in millimeters. 0～255 (0 to FFh) (a) Continuous length tape * Media Width: The tape width is indicated in millimeters. * Media Length: Fixed at 00h

Media

Media Width

Media Length

12 mm

12

0

29 mm

29

0

38 mm

38

0

50 mm

50

0

54 mm

54

0

62 mm

62

0

(b) Die-cut labels * Media Width: The width of the die-cut section is indicated. * Media Length: The length of the die-cut section is indicated.

Media

Media Width

Media Length

17 mm x 54 mm

17

54

17 mm × 87 mm

17

87

23 mm × 23 mm

23

29 mm × 42 mm

29

42

29 mm × 90 mm

29

90

38 mm × 90 mm

38

90

39 mm x 48 mm

39

48

52 mm x 29 mm

52

29

60 mm x 86 mm

60

87

62 mm x 29 mm

62

29

62 mm x 100 mm

62

100

12 mm Dia

12

24 mm Dia

24

58 mm Dia

58

Raster Command Reference

- 25 -

4. Printing Command Details

(4) Media type

Media Type

Value

Description

No media

00h

Used as print information when the media type is not indicated.

Continuous length tape

4Ah

Used for both paper and film.

Die-cut labels

4Bh

Used for both paper and film.

(5) Status type

Status Type

Value

Reply to status request

00h

Printing completed

01h

Error occurred

02h

Turned off

04h

Notification

05h

Phase change

06h

(Not used)

08h to 20h

(Reserved)

21h to FFh

If an error occurred during printing, the printer returns the error status.

Raster Command Reference

- 26 -

4. Printing Command Details

(6) Phase type and phase number

If the phase number is not used, both are fixed at 00h.

Phase State

Phase Type

Receiving state

00h

Printing state

01h

Receiving state

Phase

Value (Dec.)

Higher Order Bytes

Lower Order Bytes

Waiting to receive

0

00h

Printing state

Phase

Value (Dec.)

Higher Order Bytes

Lower Order Bytes

Printing

0

00h

⚫ When the printer is turned on, it is in the receiving state. When printing begins, it changes to the “printing”

phase (phase type: printing state; phase number: printing), and the printer sends that phase status to the

computer. When printing has finished, the printer sends the “receiving state” phase status (phase type:

receiving state; phase number: waiting to receive) to the computer. Unless an error occurs during printing,

the printer sends the “printing completed” status. ⚫ With concurrent printing, printing starts even if a print command has not been sent from the computer in

order to print at high speed. At this time, care should be taken since the “printing” and “waiting to receive”

phase statuses will be sent. (Refer to “5. Flow Charts”.)

(7) Notification number

Notification

Value

Not available

00h

Cooling (started)

03h

Cooling (finished)

04h

Raster Command Reference

- 27 -

4. Printing Command Details

ESC @ Initialize

ASCII: ESC @ Hexadecimal: 1B 40

Description

⚫ Initializes mode settings. ⚫ Also used to cancel printing.

ESC i d Specify margin amount (feed amount)

ASCII: ESC i d {n1} {n2} Hexadecimal: 1B 69 64 {n1} {n2}

Description

⚫ Specifies the amount of the margins. ⚫ Margin amount (dots)=n1+n2*256 ⚫ With die-cut labels, the margin amount at the ends of the printed area is 0.

(a) Continuous length tape

Print area

Margin amount

Tape

Paper

Cut line

(b) Die-cut labels

Margin amount (only “0” is available)

Print area

Label

Paper

Cut line

Raster Command Reference

- 28 -

4. Printing Command Details

ESC i a Switch dynamic command mode

ASCII: ESC i a {n1} Hexadecimal: 1B 69 61 {n1}

Parameters

Definitions of {n}: 0: ESC/P mode (default of QL-710W / QL-720NW) (QL-710W / QL-720NW Only) 1: Raster mode (Be sure to switch to this mode.) (default of QL-600) 3: P-touch Template mode (QL-710W / QL-720NW Only) FF: Mode set as default

Description ⚫ Dynamically switches between the printer's command modes. A printer that receives this command

operates in the specified command mode until the printer is turned off. ⚫ The printer must be switched to raster mode before raster data is sent to it. Therefore, send this command

to switch the printer to raster mode.

g Raster graphics transfer

ASCII: g {s} {n} {d1} ... {dn} Hexadecimal: 67 {s} {n} {d1} ... {dn}

Parameters

{s} 00h {n} Number of bytes of raster data (d1 to dh)

However, use the following value if no compression is specified as the compression mode. n=104 {d1~dn} Raster data.

Raster Command Reference

- 29 -

4. Printing Command Details

ESC i B Specify baud rate

ASCII: ESC i B {n1} {n2} Hexadecimal: 1B 69 42 {n1} {n2}

Parameters

Setting=n1+n2*256 Setting: 96=9600 bps, 576=57600 bps, 1152=115200 bps

Description ⚫ Changes the communications baud rate for the printer. The manufacturer’s default setting is 9600 bps.

Z Zero raster graphics

ASCII: Z Hexadecimal: 5A

Description ⚫ Fills raster line with 0 data.

FF Print command

ASCII: FF Hexadecimal: 0C

Description ⚫ Used as a print command at the end of pages other than the last page when multiple pages are printed.

Control-Z Print command with feeding

ASCII: Control-Z Hexadecimal: 1A

Description ⚫ Used as a print command at the end of the last page.

Raster Command Reference

- 30 -

4. Printing Command Details

ESC i z Print information command

ASCII: ESC i z {n1} {n2} {n3} {n4} {n5} {n6} {n7} {n8} {n9} {n10} Hexadecimal: 1B 69 7A {n1} {n2} {n3} {n4} {n5} {n6} {n7} {n8} {n9} {n10}

Description

⚫ Specifies the print information. ⚫ Definitions of {n1} through {n10}

{n1}:

Valid flag; Specifies which values are valid 0x02: Media type 0x04: Media width 0x08: Media length 0x40: Priority given to print quality 0x80: Printer recovery always on

{n2}:

Media type Continuous length tape: 0Ah Die-cut labels: 0Bh

{n3}:

{n3}: Media width (mm) {n4}: Media length (mm) For the media of width 62 mm × length 100 mm, specify as n3=3Eh and n4=64h.

{n4}:

{n5-n8}:

Raster number = n8*256*256*256 + n7*256*256 + n6*256 + n5 If the media is not correctly loaded into the printer when the media type, media width and media length of valid flag {n1} are set to “ON”, an error status is returned. (Bit 0 of “(2)

Error information 2” is set to “ON”.)

{n9}:

Starting page: 0 Other pages: 1

{n10}:

Fixed at 0

Raster Command Reference

- 31 -

4. Printing Command Details

M Select compression mode

ASCII: M {n} Hexadecimal: 4D {n}

Parameters

Definitions of {n}

0

No-compression mode (Enabled)

1

Reserved (Disabled)

2

TIFF (Enabled)

Description ⚫ Selects the compression mode. Data compression is available only for data in raster graphic transfer.

[TIFF(Pack Bits)]

⚫ 1-byte units ⚫ If the same data is repeated, the number of data units and that 1 byte of data are specified.

If different data is in a series, the number of data items and all of the different data are specified.

⚫ If the same data is repeated, the number of data units is specified as the actual number minus 1,

expressed as a negative number. If different data is in a series, the number of data units is specified as the number of bytes minus 1, expressed as a positive number.

⚫ If the above process results in more than 90 bytes of compressed data, the data is treated as being all

different. As a result, the data will be 91 bytes, including the 1 byte that specifies the data length.

Example 1 raster of raster graphics transfer:

Without compression:

00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 22 22 23 BA BF A2 22 2B……

With compression:

ED 00 FF 22 05 23 BA BF A2 22 2B … a b c

a.

Since “00h” is repeated for 20 bytes, 20d -> 19d -> 13h changed into a negative number is EDh. Therefore: ED 00

b.

Since “22h” is repeated for 2 bytes, 2d -> 1d -> 1h changed into a negative number is FFh. Therefore: FF 22

c.

The following 6 bytes remain unchanged. 6d -> 5d -> 5h Therefore: 05 23 BA BF A2 22 2B

Continue for the remaining number of bytes for the uncompressed data. Even if 00h continues until the end, it cannot be omitted.

Raster Command Reference

- 32 -

4. Printing Command Details

Explanation of “TIFF compression mode” With compression, the data for the “raster graphics transfer” command is based on 90 bytes of the total number of pins (720). As shown below, with no compression, the sum of the number of offset pins and the number of pins within the print area is the byte data. However, with compression, the number of unused pins is also added to the data. In other words, with compression, this becomes 90 bytes when it is expanded by the printer, regardless of the tape width.

0 pin

Last byte

First byte

Tape margin

Raster line with compression

Feeding direction

Print area

Pins on print head

Number of print area pins

Number of offset pins

Total number of pins

Number of unused pins

Raster line with no compression

ESC i A Specify the page number in “cut each * labels”

ASCII: ESC i A {n} Hexadecimal: 1B 69 41 {n}

Parameters

Definitions of {n} Page number = n1 (1 - 255) Default is 1 (cut each label).

Description When “auto cut” is specified, you can specify page number (1 - 255) in “cut each * labels”.

Raster Command Reference

- 33 -

4. Printing Command Details

ESC i M Various mode

ASCII: ESC i M {n} Hexadecimal: 1B 69 4D {n}

Parameters

Definitions of {n} The meaning of each bit in a 1-byte parameter is described below. 1 ~ 6bit: Not used 7bit: Auto cut 1: Auto cut 0:No auto cut 8bit: Not used

ESC i K Expanded mode

ASCII: ESC i K {n} Hexadecimal: 1B 69 4B {n}

Parameters

Definitions of {n} The meaning of each bit in a 1-byte parameter is described below. 1 ~ 3bit: Not used 4bit: Cut at end 1:Cut at end (default) 0:Not cut at end 5,6bit: Not used 7bit: High resolution printing

1: It prints at 600 dpi in the paper length direction 0: It prints at 300 dpi in the paper length direction.（default）

8bit: Not used

Raster Command Reference

- 34 -

5. Flow Charts

5.1 Normal flow for USB connection

Computer (host)

Printer

Status information request

Status (response to status information request)

Printing

Display ing printing

Printing of the 1st page is actually not finished, but the

“Printing completed” status and “Waiting to receive” phase are

sent.

Sending control codes

Sending raster data

Initialize

The printer is initialized.

Status

(Phase change:

“Printing”)

Sending a print command (print command with feeding (1A) for the last page or print command (0C) for other pages)

Phase change

“Printing” received.

“Printing completed”

received.

Sending raster data

Status (“Printing completed”)

Status (Phase change:

“Waiting to receive”)

Sending control code/print data

Sending raster data

Finishing process for printing page 1

Sending data for page 2

Printing 1st page

Printing 2nd page

Sending raster data

READ

The status of the printer (media, etc.) is checked and a response is sent.

If there are no problems with the printer status (media, etc.), the data is transmitted. If there is a problem, an error appears.

Displaying sending

READ

Data received.

Beginning printing without waiting for a print command

Status

(Phase change:

“Printing”)

Raster Command Reference

- 35 -

5. Flow Charts

5.2 Error flow for USB connection (when feeding at the end of the page)

Computer (host)

Status information request

Status (response to status information request)

The status of the printer (media, etc.) is checked and a response is sent.

Data received.

Beginning printing without waiting for a print command

Printing

Displaying printing

Displaying sending

Sending control codes

Sending raster data

Initialize

The printer is initialized.

Status

(Phase change:

“Printing”)

Sending a print command (print command with feeding (1A) for the last page or print command (0C) for other page)

“Printing completed” received.

Sending raster data

Status (Phase change: “Waiting to receive”)

Sending control code/raster data

Status

(“Error occurred”)

Sending raster data

Sending a print command (print command with feeding (1A) for the last page or print command (0C) for other pages)

“Error Occured” received.

Initialize

If there are no problems with the printer status (media, etc.), the data is transmitted. If there is a problem, an error appears.

Printing of the 1st page is actually not finished, but the

“Printing completed” status and “Waiting to receive” phase are

sent.

An error appears. When restarted, data is resent starting with the 1st page since “Printing” for the 2nd page is not received.

If an error occurs, all data read from the computer is cleared.

Reprinting 1st page

READ

Printer

Phase change

“Printing” received.

Status (“Printing completed”)

Finishing process for printing page 1

Sending data for page 2

Error occurred

Resending process for data of 1st page

Displaying printing

Raster Command Reference

- 36 -

5. Flow Charts

5.3 Error flow for USB connection (with a concurrent printing error such as end of tape)

Computer (host)

If there are no problems with the printer status (media, etc.), the data is transmitted. If there is a problem, an error appears.

The status of the printer (media, etc.) is checked and a response is sent.

Data received.

Beginning printing without waiting for a print command

Printing

Printing of the 1st page is actually not finished,

but the “Printing

completed” status and

“Waiting to receive”

phase are sent.

Finishing process for printing page 1

Sending data for page 2

The printer is initialized.

Sending a print command (print command with feeding (1A) for the last page or print command (0C) for other pages)

If an error occurs, all data read from the computer is cleared.

Displaying printing

Sending a print command (print command with feeding (1A) for the last page or print command (0C) for other pages)

Reprinting 2nd page

An error appears. When restarted, data is resent starting with the 2nd page since “Printing” for the 2nd page is received.

READ

Any jobs with errors remaining in the printer are cleared.

Status information request

Status (response to status information request)

Sending control codes

Sending raster data

Initialize

Status

(Phase change :

“Printing”)

Sending raster data

Status (“Printing completed”)

Status (Phase change: “Waiting to receive”)

Sending control code/raster data

Sending raster data

Status

(Phase change :

“Printing”)

Phase change

“Printing” received.

“Printing completed” received.

Phase change “Waiting to receive” received.

Initialize

Status

(“Error Occurred”)

Phase change

“Printing” received.

“Error Occured” received.

Printer

Printing 1st page

Printing 2nd page

Error occurred

Resending process for data of 2nd page

READ

Displaying sending

Displaying printing

Raster Command Reference

- 37 -

5. Flow Charts

5.4 Cooling flow for USB connection

Computer (host)

Printer

If there are no problems with the printer status (media, etc.), the data is transmitted. If there is a problem, an error appears.

The status of the printer (media, etc.) is checked and a response is sent.

Data received.

Beginning printing without waiting for a print command

Printing

Displaying sending

The printer is initialized.

Status

(Notification:

“Cooling (started)”)

Returned “NAK” from cooling

Repeating reading of maximum and transmission timeout times. If the transmission timeout is exceeded, reading, and displaying the cooling status if a hightemperature error is returned.

Failed

Status (Notification: “Cooling (finished)”)

Resuming printing

Continuing reading. 0 packets are returned while cooling.

0 packet

When cooling is finished, Notification: “Cooling (finished)” is returned.

READ

Any jobs with errors remaining in the printer are cleared.

Status information request

Status (response to status information request)

Sending control codes

Sending raster data

Initialize

Status

(Phase change:

“Printing”)

Sending raster data

0 packet

Sending raster data

Cooling occurred

Raster Command Reference

- 38 -

5. Flow Charts

5.5 Flow for setting serial connection baud rate (QL-710W / QL-720NW Only)

Computer (host)

Specify baud rate

“Specify baud rate completed” status (normal status)

Old baud rate

New baud rate

Printer waiting to recover from 3000 ms Sleep

Status information request

* The request/response at the new baud rate are

simply to verify that communication is possible and may be omitted.

Printer

Status (response to status information request)

Raster Command Reference

- 39 -

5. Flow Charts

5.6 Normal flow for serial connection (QL-710W / QL-720NW Only)

If there are no problems with the printer status (media, etc.), the data is transmitted. If there is a problem, an error appears.

Data received.

Printing

Displaying printing

Displaying sending

Finishing process for printing 1st page

Sending data for 2nd page

The printer is initialized.

Phase change

“Printing” received.

“Printing completed”

received.

Phase change “Waiting to receive” received.

Printing 1st page

Printing 2nd page

Status information request

Status (response to status information request)

Sending control codes

Sending raster data

Initialize

Sending raster data

Sending a print command (print command with feeding (1A)

for the last page or print command (0C) for other page)

Status

(“Printing completed”)

Status

(Phase change: “Waiting to receive”)

Sending control codes

Sending raster data

Printer

Computer (host)

The status of the printer (media, etc.) is checked and a response is sent.

Sending raster data

READ

Status

(Phase change: “Printing”)

Raster Command Reference

- 40 -

5. Flow Charts

5.7 Error flow for serial connection (QL-710W / QL-720NW Only)

Computer (host)

Status information request

Data received.

Printing Displaying printing

Displaying sending

Sending control codes

Sending raster data

Initialize

The printer is Initialized.

Sending a print command (print command with feeding (1A) for the last page or print command (0C) for other page)

Phase change “Printing” received.

Status (“Error Occurred”)

READ

Printer

If there are no problems with the printer status (media, etc.), the data is transmitted. If there is a problem, an error appears.

READ

Status (response to status information

request) or an error is displayed

Status

(Phase change: “Printing”)

Error occurred

The status of the printer (media, etc.) is checked and a response is sent.

Raster Command Reference

- 41 -

5. Flow Charts

5.8 Cleaning flow for serial connection (QL-710W / QL-720NW Only)

Status (response to status request)

Data received.

Printing

Displaying printing

Displaying sending

The printer is initialized.

Phase change “Printing” received.

Phase change “Waiting to receive” received.

Printing 1st page

Printing 2nd page

Status

(Notification: “Cooling (started)”)

Printing

Cooling

* “Cooling (standard)”

and “Cooling (finished)” may be repeated multiple times during one printing operation.

Computer (host)

Status information request

Sending control codes

Sending raster data

Initialize

Sending a print command (print command with feeding (1A) for the last page or print command (0C) for other page)

Status

(Printing completed)

Status

(Phase change: “Waiting to receive”)

Sending control codes

Status

(Phase change :“Printing”)

“Printing completed” received.

Status

(Notification: “Cooling (finished)”)

Sending raster data

Printer

Sending raster data

If there are no problems with the printer status (media, etc.), the data is transmitted. If there is a problem, an error appears.

READ

Status (response to status

information request)

READ

End process for printing 1st page

Sending data for 2nd page

Raster Command Reference

- 42 -

5. Flow Charts

5.9 Normal Flow for Network (Standard TCP/IP port) Connection (QL-710W / QL-720NW Only)

*With a network connection, print data from the operating system’s port monitor is simply sent as is.

When it prints 2 pages data

BUSY

Computer

Printer

Divide print data into particular size, and send it.

Receive data

Printing 1st page

End process for printing 1st

Sending data for 2nd page

Sending raster data

Printing 2nd page

As one page data receives in the printer buffer, start printing

As 2nd page data receives in the printer buffer, start printing.

At host side, as sending print data has completed, the print job data is erased.

The print job is treated to be completion at printer side

Printer buffer is full

Sending raster data

Raster Command Reference

- 43 Appendix A: USB Specifications

Appendix A: USB Specifications

USB specifications 1.1

Item

Description

Vendor ID

0x04F9

Product ID

QL-710W : 0x2043 QL-720NW : 0x2044 QL-600 : 0x20c0

Class

Printer Mass storage (QL-710W / QL-720NW Only)

Character string for

manufacturer

Character string descriptor: 0x01 0x0409: “Brother”

Character string for

serial number

Character string descriptor: 0x03 0x0409: “000000000001” Last twelve digits of the printer’s serial number

Device speed

Full speed

Number of interfaces

1 (No alternate interfaces)

Power supply

Self-powered

End point 1

In bulk (Sends the status from the printer to the computer.) Maximum packet size: 64 bytes

End point 2

Out bulk (Sends print commands and data from the computer to the printer.) Maximum packet size: 64 bytes

Raster Command Reference

- 44 -

Appendix B: Introducing the Brother Developer Center

Useful information for developers, such as applications, tools, SDKs as well as FAQs, are provided in the Brother Developer Center.

http://www.brother.com/product/dev/index.htm

Brother QL-600, QL-710W, QL-720NW Software Developer's Manual Raster Command Reference

Specifications and Main Features

Frequently Asked Questions

User Manual
