Brother Laser Printer
PARTS REFERENCE LIST
MODEL:
HL-5240/5240L/5250DN/5251DN/
5250DNT/5270DN/5280DW
Read this list thoroughly before maintenance work.
Keep this list in a convenient place for quick and easy reference at all times.
September 2005
PL-PRN083
NOTE FOR USING THIS PARTS REFERENCE LIST
1. In the case of ordering parts, it is necessary to mention the following items:
(1) Code
(2) Q'ty
(3) Description
(4) Symbol (PCB No. etc.)
<Example>
REF.NO. CODE Q’TY DESCRIPTION SYMBOL REMARK
Revision No.: marked on the main printed circuit board (Main PCB)
(1)
(2)
(3)
(4)
B48K056
2. Design-changed parts:
If any of the parts is changed, one of the following symbols is indicated in the REMARK column.
CHG (chg): The part is changed for a new one.
ADD (add): The part is newly added.
DEL (del): The part is deleted.
Symbol in capital letters indicates the latest parts change information in the page.
3. The original parts reference list is based on the information available in September 2005.
4. Parts are subject to change in design without prior notice.
Circuit board No.
COUNTRIES AND AREAS
AP: Asia Pacific
ARG: Argentina
ARL: Australia
BEL: Belgium
BRZ: Brazil
CAN: Canada
CHI: Chile
CHN: China
EEU: EEU GENERAL
(Bulgaria/Czech/Hungary/Poland/Romania/Slov
akia)
EUR: Europe
FRA: France
GER: Germany
HOL (NL): Holland (Netherlands)
LANGUAGES
IBERIA: Spain/Portugal
IND: India
ISR: Israel
ITA: Italy
KOR: Korea
NZ: New Zealand
PAN-NOR: PAN-NORDIC
(Norway/Finland/Denmark/Sweden)
RUS: Russia
SAF: South Africa
SGP/GULF: Singapore/Gulf
SWI: Switzerland
UK: U.K.
US: U.S.A
BUL: Bulgarian
CHN: Chinese
CZE: Czech
DEN (DAN): Danish
DUT: Dutch
ENG: English
FIN: Finnish
FRE: French
GER: German
HUN: Hungarian
ITA: Italian
NOR: Norwegian
KOR: Korean
POL: Polish
POR: Portuguese
ROM: Romanian
RUS: Russian
SVK: Slovak
SPA: Spanish
SWE: Swedish
CONTENTS
1. FRAME L&DRIVE UNIT.......................................................................1
2. FRAME R UNIT .................................................................................... 3
3. FRAME UNIT........................................................................................5
4. LASER UNIT ........................................................................................7
5. PAPER FEEDER..................................................................................9
6. DX....................................................................................................... 11
7. PAPER TRAY..................................................................................... 13
8. FUSER UNIT ...................................................................................... 15
9. COVERS&LABELS............................................................................ 17
10. MAIN PCB..........................................................................................20
11. LVPS................................................................................................... 22
12. HVPS..................................................................................................24
13. AC CORDS.........................................................................................26
14. ACCESSORIES.................................................................................. 28
15. PACKING MATERIALS...................................................................... 31
16. PERIODICAL MAINTENANCE PARTS .............................................33
1. FRAME L&DRIVE UNIT
(
)
g
)
g
g
L
Y
Y
Y
R
g
)
g
T
6
0
A
REF No. CODE Q'TYDESCRIPTION REMARKS
1 LU1343001 1 MAIN FRAME L UNIT
1 LU1344001 1 MAIN FRAME L UNIT 40 (HL-5240/5240L
1-1 LU7214001 1 DEVELOP JOINT ch
1-2 LM5047001 1 MAIN MOTOR ASSY A
1-3 LM5048001 1 FUSER GEAR 39 H/R DRIVE
1-4 LM5058001 1 REGISTER SOLENOID ASS
1-5 LM5062001 1 MP SOLENOID ASS
1-6 LM5067001 1 T1 SOLENOID ASS
1-7 LJ9935001 1 TONER SENSOR PCB ASSY AL
1-8 UL9037001 1 PT SENSOR HOLDE
1-9 LV0690001 1 RELAY FRONT PCB ASSY AL ch
1-10 LJ9940001 1 INTERLOCK SW ASSY AL
1-11 LJ9942001 1 RELAY REAR PCB ASSY AL (HL-5250DN/5250DNT/5251DN/
5270DN/5280DW)
1-11 LM9168001 1 RELAY REAR PCB 2 ASSY AL (HL-5240/5240L
1-12 LM5085001 1 NEW TONER ACTUATOR
1-13 LM5086001 1 NEW TONER ACTUATOR SPRING
1-14 LJ7403001 1 RUBBER FOO
1-15 LJ9945001 1 CONNECTOR 54702-1219
1-16 LM5011001 1 EJECTOR SOLENOID (HL-5250DN/5250DNT/5251DN/5270DN/
5280DW)
1-17 087320616 4 TAPTITE CUP S M3x
1-18 085311016 3 TAPTITE BIND B M3x1
1-19 085311016 1 TAPTITE BIND B M3x10 (HL-5250DN/5250DNT/5251DN/5270DN/
5280DW)
1-20
1-21
1-22
LM5043001 1 DEV GEAR 37R JOINT DRIVE add
LM5080001 1 DRIVE RELEASE LINK add
LM5079001 1 DRIVE RELEASE CAM add
2 LM5104001 1 GEAR 17 MP ROLLER DRIVE add
3 LM5103001 1 GEAR 20 T1 ROLLER DRIVE add
4 LM5102001 1 GEAR 17 FEED ROLLER DRIVE add
5 LM5051001 1 DX GEAR 15 TRAY DRIVE (EXCEPT HL-5240/5240L)
HL-5250DN/5250DNT/5251DN/5270DN/5280DW
ch
ch
ch
DD
84UZ91/92/93/94/95 HL-5240/5250DN/5270DN/5280DW/5250DNT
- 1 -
1. FRAME L&DRIVE UNIT
1
1-4
1-3
1-19
1-16
1-11
1-9
1-18
1-7
1-8
1-12
1-21
1-13
1-10
1-20
1-17
1-1
1-2
1-17
1-22
1-15
1-17
1-17
1-6
1-18
2
3
1-18
1-14
1-5
- 2 -
5
4
2. FRAME R UNIT
T
REF No. CODE Q'TYDESCRIPTION REMARKS
1 LM9022001 1 TONER LED PCB ASSY AL
2 LM4267001 1 LED HOLDER
3 LJ7403001 1 RUBBER FOO
84UZ91/92/93/94/95 HL-5240/5250DN/5270DN/5280DW/5250DNT
- 3 -
2. FRAME R UNIT
2
1
3
- 4 -
3. FRAME UNIT
Y
g
V
T
(
)
A
REF No. CODE Q'TYDESCRIPTION REMARKS
1 LU0951001 1 FILTER T7 ASS
2 LM5114001 1 FAN MOTOR 60 UNIT L
3 LM5116001 1 FAN MOTOR 60 UNI
4 LG6846001 1 PCB T60H929.00 ASSY 02, HL-5280DW US (for
Brazil)/GER/UK/SWI/GENERAL/PAN-NORDIC
4 LG7359001 1 WIRELESS PCB
5 LM6655001 1
IR DUCT ASSY AL add
HL-5280DW
ch
chg
CHG
84UZ91/92/93/94/95 HL-5240/5250DN/5270DN/5280DW/5250DNT
- 5 -
3. FRAME UNIT
1
5
3
2
4
- 6 -
4. LASER UNIT
(SP)
6
REF No. CODE Q'TYDESCRIPTION REMARKS
1 LM5750001 1 LASER UNIT AL
2 LJ0908001 1 LASER CAUTION LABEL B (EXCEPT CHN)
2 UL7931001 1 LASER CAUTION LABEL (CHN)
3 087320616 6 TAPTAITE CUP S M3x
84UZ91/92/93/94/95 HL-5240/5250DN/5270DN/5280DW/5250DNT
- 7 -
4. LASER UNIT
2
1
3
3
3
3
3
3
- 8 -
5. PAPER FEEDER
Y
Y
T
R
Y
Y
P
g
A
g
g
Y
Y
)
)
(
)
(
)
R
(
)
8
0
A
REF No. CODE Q'TYDESCRIPTION REMARKS
1 LM9001001 1 PE EG SENSOR ASS
2 LU7935001 1 PE ACTUATOR ASS
3 LM5132001 1 EDGE ACTUATOR
4 LM5133001 1 EDGE ACTUATOR SPRING
5 LM5140001 1 ROLLER HOLDER ASSY
6 LM5150001 1 REGIST ACTUATOR FRON
7 LM5151001 1 REGIST ACTUATOR REA
8 LM5152001 2 REGIST ACTUATOR SPRING
9 LJ9999001 1 MP PE SENSOR ASS
10 LM5165001 1 MP ROLLLER HOLDER ASS
11 LM5171001 1 PE ACTUATOR M
12 LU0027001 1 PE ACTUATOR MP B 2 ch
13 LM6490001 1 MP SEPARATION SPRING
14 LM6752001 1 SEPARATION PAD ASSY MP 2 ch
15 LJ8657001 1 BINDER 2.3X7.9
16 LM5196001 1 TRAY MP ASS
17 LM5201001 1 MP TRAY COVER ASS
18 LM5205001 1 PROCESS COVER ASSY AL (HL-5240/5250DN EXCEPT
CHN/IND, HL-5250DNT/5270DN/5280DW)
18 LM5205002 1 PROCESS COVER ASSY AL (HL-5240L
18 LM5962001 1 PROCESS COVER ASSY AL CHN (CHN
18 LM6964001 1 PROCESS COVER ASSY AL IND
18 LM7031001 1 PROCESS COVER ASSY
18-1 LM5124001 1 PROCESS COVER STOPPE
18-2 LM5208001 1 SUPPORT FLAP AL (HL-5240/5250DN/5250DNT/5251DN/
5270DN/5280DW)
18-2 LM5208002 1 SUPPORT FLAP AL
19 085310816 2 TAPTITE BIND B M3x
20 087411016 1 TAPTITE CUP B M4X1
21 LM6584001 7
NTISTATIC FILM SWI (SWI) add
HL-5251DN
HL-5240L
IND
CHG
ch
add
add
add
84UZ91/92/93/94/95 HL-5240/5250DN/5270DN/5280DW/5250DNT
- 9 -
5. PAPER FEEDER
18-2
18
18-1
20
21
21
21
21
21
21
21
14
13
16
17
9
10
19
12
15
11
1
19
7
4
8
8
6
3
5
2
- 10 -
6. DX
(
)
)
REF No. CODE Q'TYDESCRIPTION REMARKS
1 LM5209001 1 DX FEED ASSY LTR AL
HL-5250DN/5270DN/5280DW/5250DNT US/CAN/PHL/ARG/CHI
1 LU7503001 1 DX FEED ASSY A4 AL (HL-5250DN/5251DN/5270DN/5280DW
EXCEPT US/CAN/PHL/ARG/CHI
CHG
84UZ91/92/93/94/95 HL-5240/5250DN/5270DN/5280DW/5250DNT
- 11 -
6. DX
1
- 12 -
7. PAPER TRAY
R
Y
REF No. CODE Q'TYDESCRIPTION REMARKS
1 LU0691001 1 PAPER TRAY UNIT US 2 CHG
1 LM5739001 1 PAPER TRAY UNIT EU
1 LM6568001 1 PAPER TRAY UNIT A4 S add
1 LU0698001 1 PAPER TRAY UNIT UNIV IND 2 CHG
1 LU0629001 1 PAPER TRAY UNIT 5240L
1-1 LM5237001 1 SEPARATION PAD ASS
1-2 LM5239001 1 SEPARATION PAD SPRING
1-3 LM5245001 1 GEAR 15
1-4 LM5246001 1 GEAR 21-16
1-5 LM5247001 1 LIFT GEAR 46
84UZ91/92/93/94/95 HL-5240/5250DN/5270DN/5280DW/5250DNT
- 13 -
7. PAPER TRAY
1
1-1
1-5
1-2
1-4
1-3
- 14 -
8. FUSER UNIT
(SP)
(SP) (
)
(SP) (
)
(SP) (
)
)
REF No. CODE Q'TYDESCRIPTION SYMBOL REMARKS
1 LU1390001 1 FUSER UNIT 115V
1 LU1399001 1 FUSER UNIT 230V
1 LU1397001 1 FUSER UNIT 230V
1 LU1395001 1 FUSER UNIT 230V
1
LU0112001 1 FUSER UNIT 230V SNG (SP
1-1 LM5408001 4 PRESSURE SPRING add
1-2 LM5513001 4 EJECT PINCH ROLLER M add
AP/CHN/ARG/CHI
EUR/SAF
IND
CHG
CHG
CHG
CHG
del
84UZ91/92/93/94/95 HL-5240/5250DN/5270DN/5280DW/5250DNT
- 15 -
8. FUSER UNIT
1
1-2
1-2
1-1
1-2
1-1
1-1
1-2
1-1
- 16 -
9. COVERS&LABELS
)
)
(
)
)
(
2
)
g
)
(
)
A
2
)
A
REF No. CODE Q'TYDESCRIPTION REMARKS
TOP COVER ASSY AL PSL
(HL-5240 GER/UK/ARL/SWI/SPA/POR/ITA/ISR/CHN/
PHL/SAF/ARG/CHI/SGP/GULF/KOR/IND/RUS/PAN-NORDIC/
BEL/FRA/NL/EEU GENERAL/MOF BEL/CONSIP ITA,
HL-5250DN GER/UK/ARL/SWI/SPA/POR/ITA/ISR/
CHN/PHL/SAF/ARG/CHI/SGP/GULF/KOR/IND/RUS/
PAN-NORDIC/BEL/FRA/NL/EEU GENERAL/ HY GER/
CONSIP ITA,
HL-5251DN CONSIP ITA
1 LM5262001 1 TOP COVER ASSY AL
(HL-5240 US/CAN,
HL-5250DN US/CAN,
HL-5250DNT US
1 LU0126002 1 TOP COVER ASSY AL PSL
1 LU0231001 1 TOP COVER ASSY AL MOF BEL PSL (HL-5240 MOF BEL
1-1 LM5269001 1 INNER CHUTE AL (HL-5240/5250DN/5250DNT/5251DN/
5270DN/5280DW)
1-1 LM5269005 1 INNER CHUTE AL
1-2 LM5083001 1 SW KEY A
1-3 LM5084001 1 SW KEY B
1-4 LJ9933001 1 PANEL PCB ASSY AL
1-5 085411216 6 TAPTITE BIND B M4x1
1-6 LU0160001 1 CHG
2 LU0125001 1 TOP COVER 2 ASSY 5270 PSL ch
2 LU0232001 1 TOP COVER 2 ASSY 5280 PSL (GER/UK/SWI/GENERAL/
2 LM5769001 1 TOP COVER 2 ASSY 5280
2-1 LM5269001 1 INNER CHUTE AL
2-2
2-3
2-4
2-5
2-6
2-7 LM9041001
2-8 LM5535001
2-8 LM5768001
2-9 LM9043001
2-10 LE7130001
2-11 085411216
2-12 LM5882001 1 SET KEY FILM
2-13 LU0160001 1 PAPER STACK LEVER ASSY AL (GER/UK/SWI/GENERAL/
2-14
LM5530001 1 SW KEY A
LM5531001 1 SW KEY B
LM5532001
LM5635001
LM5534001
LG6059001 1 LCD
3 LM5778001
PAPER STACK LEVER ASSY AL
(HL-5240 GER/UK/ARL/SWI/SPA/POR/ITA/ISR/CHN/
PHL/SAF/ARG/CHI/SGP/GULF/KOR/IND/RUS/PAN-NORDIC/
BEL/FRA/NL/EEU GENERAL/MOF BEL/CONSIP ITA,
HL-5250DN GER/UK/ARL/SWI/SPA/POR/ITA/ISR/
CHN/PHL/SAF/ARG/CHI/SGP/GULF/KOR/IND/RUS/
PAN-NORDIC/BEL/FRA/NL/EEU GENERAL/ HY GER/
CONSIP ITA,
HL-5251DN CONSIP ITA
PAN-NORDIC
1 SW KEY C
1 SET KEY PRINTED ASSY
1 KEY TOP
1 LCD PANEL PCB ASSY AL
1 PANEL PLATE PRINTED ASSY 5270
1 PANEL PLATE PRINTED ASSY 5280
1 BACK LIGHT PCB ASSY AL
1 BACK LIGHT FILM
7 TAPTITE BIND B M4x1
PAN-NORDIC
SIDE COVER R ASSY AL (HL-5240/5250DN/5250DNT/
1
5251DN/5270DN/5280DW)
HL-5240L)
HL-5240L
US/CAN
CHG1 LU0126001 1
ADD
del
CHG
DD
CHG
add
3 LM5778005 1 SIDE COVER R ASSY AL (HL-5240L)
4 LM5780001
4 LM5779001
4 LU0282001
4 LU0634001
5 LM5273001
5 LM5273005
84UZ91/92/93/94/95 HL-5240/5250DN/5270DN/5280DW/5250DNT
1 SIDE COVER L ASSY AL (HL-5240/5250DN/5250DNT/5251DN)
1 SIDE COVER L 2 ASSY AL (HL-5270DN/5280DW)
1 SIDE COVER L ASSY AL MOF (HL-5240 MOF BEL) add
1 SIDE COVER L ASSY 5240L (HL-5240L)
ACCESS COVER AL (HL-5240/5250DN/5250DNT/5251DN/
1
5270DN/5280DW)
1
CCESS COVER AL (HL-5240L)
- 17 -
9. COVERS&LABELS
)
2
REF No. CODE Q'TYDESCRIPTION REMARKS
6 LM5274001
6 LM5274005 1 REAR COVER AL (HL-5240L)
7 LU0278001
7 LU0277001
8 LM5424001
8 LM5424005
9 LM5771001
9 LM5771002
10 LM5521001
10 LU0524001
10 LM5284001
10 LM5537001
10 LM5604001
10 LU0059001
11 LM5542001
11 LM5834001
11 LM5835001
11 LM5836001
11 LU0060001
12 LM5758001
13 085411216
REAR COVER AL (HL-5240/5250DN/5250DNT/5251DN/
1
5270DN/5280DW)
1 OUTER CHUTE ASSY2 EL20 (EXCEPT US/CAN
chg
1 OUTER CHUTE ASSY2 EL25 (US/CAN) add
1 DX COVER (HL-5240) chg
1 DX COVER (HL-5240L)
BROTHER EMBLEM AL (HL-5240/5250DN/5250DNT/
1
5251DN/5270DN/5280DW)
1 BROTHER EMBLEM AL (HL-5240L)
1 MODEL PLATE 5240
1 MODEL PLATE 5240L
1 MODEL PLATE 5250
1 MODEL PLATE 5270
1 MODEL PLATE 5280
1 MODEL PLATE 5251 add
1 PROCESS UNIT OP LABEL AL US
1 PROCESS UNIT OP LABEL AL EUR
1 PROCESS UNIT OP LABEL AL AP
1 PROCESS UNIT OP LABEL AL CHN
1 PROCESS UNIT OP LABEL AL ITA (HL-5251DN) add
1 RELEASE LABEL
6 TAPTITE BIND B M4x1
84UZ91/92/93/94/95 HL-5240/5250DN/5270DN/5280DW/5250DNT
- 18 -
9. COVERS&LABELS
10
10
2
2-8
2-10
2-14
2-9
2-6
2-5
2-12
2-7
2-4
2-3
2-2
2-13
2-1
13
1
1-6
1313
1-3
1-4
1-2
13
1-1
12
2-11
6
13
5
4
2-11
7
8
13
1-5
1-5
3
13
11
- 19 -
13
9
10. MAIN PCB
R
REF No. CODE Q'TYDESCRIPTION SYMBOL REMARKS
1 LM9076001 1 MAIN PCB ASSY 5240
1 LV0119001 1 MAIN PCB ASSY 5240L
1 LM9077001 1 MAIN PCB ASSY 5250
1 LM9110001 1 MAIN PCB ASSY 5270
1 LM9064001 1 MAIN PCB ASSY 5280DW US
1 LM9138001 1 MAIN PCB ASSY 5280DW EU
1 LM9169001 1 MAIN PCB ASSY 5240 CHN add
1 LM9170001 1 MAIN PCB ASSY 5250 CHN add
1 LM9429001 1 MAIN PCB ASSY 5240 IND
1 LM9430001 1 MAIN PCB ASSY 5250 IND
1 LV0048001 1 MAIN PCB ASSY 5250 KO
add
add
add
84UZ91/92/93/94/95 HL-5240/5250DN/5270DN/5280DW/5250DNT
- 20 -
10. MAIN PCB
1
- 21 -
11. LVPS
A
(
)
g
REF No. CODE Q'TYDESCRIPTION REMARKS
1 LJ9979001 1 PS PCB UNIT AL 115V
1 LJ9983001 1 PS PCB UNIT AL 230V FOR
RL/ISR/PHI/SAF/ARG/CHI/SGP/GULF/KOR
1 LV0739001 1 PS PCB UNIT AL 230V FOR GER/UK/SWI/IBERIA/ITA/
PAN-NOR/BEL/FRA/HOL/EEU/GENERAL
1 LM9088001 1 PS PCB UNIT AL CHN
CHN/IND/RUS
ADD
ch
84UZ91/92/93/94/95 HL-5240/5250DN/5270DN/5280DW/5250DNT
- 22 -
11. LVPS
1
- 23 -
12. HVPS
REF No. CODE Q'TY DESCRIPTION REMARKS
1 LJ9978001 1 HIGH-VOLTAGE PS PCB ASSY AL
84UZ91/92/93/94/95 HL-5240/5250DN/5270DN/5280DW/5250DNT
- 24 -
12. HVPS
1
- 25 -
13. AC CORDS
A
REF No. CODE Q'TY DESCRIPTION REMARKS
1A LJ9271001 1 AC CORD ASSY LF UL/CSA 10
1B
1B
1C
1D
1E
1F
1G
1H
1I
1J
1K
1L
LV0363001 1 AC CORD ASSY LF VDE chg
LV0392001 1 AC CORD ASSY LF KOR add
LV0946001 1 AC CORD ASSY LF SEV chg
LJ9294001 1 AC CORD ASSY LF CHILE
LV0365001 1 AC CORD LF SAA chg
LV0367001 1 AC CORD ASSY LF BS/PSB chg
LM9288001 1 AC CORD ASSY LF ISRAEL chg
LV1092001 1 AC CORD ASSY LF CHINA CHG
LJ9295001 1 AC CORD ASSY LF SOUTH AFRICA
LJ9256001 1 AC CORD ASSY LF DEMKO
LV0377001 1 AC CORD ASSY LF IRAM chg
LV0213001 1 AC CORD ASSY LF IND chg
84UZ91/92/93/94/95 HL-5240/5250DN/5270DN/5280DW/5250DNT
- 26 -
13. AC CORDS
1A
1B
1C
1D
1E
1F
1G
1H
1I
1J
1K
1L
- 27 -
14. ACCESSORIES
)
(
)
)
(
)
(
)
(
)
(
)
(
)
)
REF No. CODE Q'TY DESCRIPTION REMARKS
1 LU0015001 1 CD ASSY 40/50 S AL (HL-5240/5250DN EXCEPT
CHN/IND/RUS/EEU GENERAL, HL-5250DNT/5251DN
1 LU1154001 1 CD ASSY 5240L AL
HL-5240L EXCEPT RUS/EEU GENERAL
1
LM5594001 1 CD ASSY 70 AL del
1 LM6464001 1 CD ASSY 70/80 AL (HL-5270DN EXCEPT RUS/
EEU GENERAL, HL-5280DW)
1 LM6232001 1 CD ASSY AL CHN (CHN
1 LM5997001 1 CD ASSY 40/50AL EEU/RUS del
1 LM5903001 1 CD ASSY AL EEU/RUS
1 LM6785001 1 CD ASSY 40 KOR
1 LU0244001 1 CD ASSY AL KOR
1 LM6947001 1 CD ASSY 40/50 AL IND
2 LU0425001 1 CD-ROM ASSY VISTA EU/US chg
2 LU1155001 1 CD-ROM ASSY VISTA 5240L
2 LU0426001 1 CD-ROM ASSY VISTA CHN/ENG add
2 LU0429001 1 CD-ROM ASSY VISTA EEU/RUS add
2 LU0430001 1 CD-ROM ASSY VISTA KOR add
3 LU1160001 1 CD ASSY WIN7 (HL-5240L EXCEPT RUS/EEU GENERAL,
3 LU1162001 1 CD ASSY WIN7 (HL-5240 CHN) ADD
3 LU1161001 1 CD ASSY WIN7 (HL-5240L RUS/EEU GENERAL) ADD
4
LM5292001 1 SET GUIDE AL ENG del
4 LM6472001 1 SET GUIDE AL ENG UNIV (HL-5240/5250DN/5250DNT) chg
4
LM5668001 1 SET GUIDE AL-LCD ENG (HL-5270DN)
4 LM5678001
4
LM6475001 1 SET GUIDE AL-W ENG UNIV (HL-5280DW) chg
4 LM5628001
4
LM6473001 1 SET GUIDE AL FRE UNIV (HL-5240/5240L/5250DN) chg
4 LM5667001 1 SET GUIDE AL-LCD FRE (HL-5270DN)
4
LM5680001 1 SET GUIDE AL-W FRE del
4 LM6476001 1 SET GUIDE AL-W FRE UNIV (HL-5280DW) chg
4
LM5618001 1 SET GUIDE AL GER (HL-5240/5240L/5250DN)
4 LM5666001 1 SET GUIDE AL-LCD GER (HL-5270DN)
4
LM5679001 1 SET GUIDE AL-W GER (HL-5280DW)
4 LM5651001
4
LM6474001 1 SET GUIDE AL SPA UNIV (HL-5240/5240L/5250DN) chg
4 LM5671001 1 SET GUIDE AL-LCD SPA (HL-5270DN)
4
LM5683001 1 SET GUIDE AL-W SPA (HL-5280DW)
4 LM5652001 1 SET GUIDE AL POR (HL-5240/5240L/5250DN)
4
LM5672001 1 SET GUIDE AL-LCD POR (HL-5270DN)
4 LM5684001 1 SET GUIDE AL-W POR (HL-5280DW)
4
LM5638001 1 SET GUIDE AL SWI/ITA (HL-5240/5240L/5250DN/5251DN)
4 LM5670001 1 SET GUIDE AL-LCD ITA (HL-5270DN)
4
LM5682001 1 SET GUIDE AL-W ITA (HL-5280DW)
4 LM5657001 1 SET GUIDE AL CHN
4
LM5653001 1 SET GUIDE AL NOR (HL-5240/5240L/5250DN)
4 LM5673001 1 SET GUIDE AL-LCD NOR (HL-5270DN)
4
LM5685001 1 SET GUIDE AL-W NOR (HL-5280DW)
4 LM5662001 1 SET GUIDE AL SWE (HL-5240/5240L/5250DN)
4
LM5674001 1 SET GUIDE AL-LCD SWE (HL-5270DN)
4 LM5686001 1 SET GUIDE AL-W SWE (HL-5280DW)
4
LM5663001 1 SET GUIDE AL DAN (HL-5240/5240L/5250DN)
4 LM5675001 1 SET GUIDE AL-LCD DAN (HL-5270DN)
4
LM5687001 1 SET GUIDE AL-W DAN (HL-5280DW)
4 LM5664001 1 SET GUIDE AL FIN (HL-5240/5240L/5250DN)
4
LM5676001 1 SET GUIDE AL-LCD FIN (HL-5270DN)
4 LM5688001 1 SET GUIDE AL-W FIN (HL-5280DW)
4
LM5665001 1 SET GUIDE AL DUT (HL-5240/5240L/5250DN)
4 LM5669001 1 SET GUIDE AL-LCD DUT (HL-5270DN)
4
LM5681001 1 SET GUIDE AL-W DUT (HL-5280DW)
HL-5240L EXCEPT RUS/EEU GENERAL
HL-5250DN ISR/SGP/GULF, HL-5270DN ISR
1 SET GUIDE AL-W ENG del
1 SET GUIDE AL FRE del
1 SET GUIDE AL SPA del
RUS/EEU GENERAL
HL-5240 KOR
HL-5250DN KOR
IND
chg
ADD
chg
add
add
add
add
ADD
ADD
84UZ91/92/93/94/95 HL-5240/5250DN/5270DN/5280DW/5250DNT
- 28 -
14. ACCESSORIES
(
)
(
)
,
)
REF No. CODE Q'TY DESCRIPTION REMARKS
4 LM5893001 1 SET GUIDE AL RUS (HL-5240/5240L/5250DN) add
4
LM5896001 1 SET GUIDE AL-LCD RUS (HL-5270DN) add
4 LM5891001 1 SET GUIDE AL ENG/CZE/HUN (HL-5240/5240L/5250DN) add
4
LM5894001 1 SET GUIDE AL-LCD ENG/CZE/HUN (HL-5270DN) add
4 LM5892001 1 SET GUIDE AL POL/BUL/ROM (HL-5240/5240L/5250DN) add
4
LM5895001 1 SET GUIDE AL-LCD POL/BUL/ROM (HL-5270DN) add
4 LM6945001 1 SET GUIDE 40/50 AL IND add
5 LU0354001 1 SETUP GUIDE VISTA ENG (HL-5240/5250DN/5250DNT/5270DN) add
5 LU0370001 1 SETUP GUIDE VISTA W ENG (HL-5280DW) add
5 LU0355001 1 SETUP GUIDE VISTA GER (HL-5240/5250DN/5270DN) add
5 LU0371001 1 SETUP GUIDE VISTA W GER (HL-5280DW) add
5 LU0356001 1 SETUP GUIDE VISTA FRE (HL-5240/5250DN/5270DN) add
5 LU0372001 1 SETUP GUIDE VISTA W FRE (HL-5280DW) add
5 LU0357001 1 SETUP GUIDE VISTA DUT (HL-5240/5250DN/5270DN) add
5 LU0373001 1 SETUP GUIDE VISTA W DUT (HL-5280DW) add
5 LU0358001 1 SETUP GUIDE VISTA ITA (HL-5240/5250DN/5251DN/5270DN) add
5 LU0374001 1 SETUP GUIDE VISTA W ITA (HL-5280DW) add
5 LU0359001 1 SETUP GUIDE VISTA SPA (HL-5240/5250DN/5270DN) add
5 LU0375001 1 SETUP GUIDE VISTA W SPA (HL-5280DW) add
5 LU0360001 1 SETUP GUIDE VISTA POR (HL-5240/5250DN/5270DN) add
5 LU0376001 1 SETUP GUIDE VISTA W POR (HL-5280DW) add
5 LU0361001 1 SETUP GUIDE VISTA NOR (HL-5240/5250DN/5270DN) add
5 LU0377001 1 SETUP GUIDE VISTA W NOR (HL-5280DW) add
5 LU0362001 1 SETUP GUIDE VISTA SWE (HL-5240/5250DN/5270DN) add
5 LU0378001 1 SETUP GUIDE VISTA W SWE (HL-5280DW) add
5 LU0363001 1 SETUP GUIDE VISTA DEN (HL-5240/5250DN/5270DN) add
5 LU0379001 1 SETUP GUIDE VISTA W DEN (HL-5280DW) add
5 LU0364001 1 SETUP GUIDE VISTA FIN (HL-5240/5250DN/5270DN) add
5 LU0380001 1 SETUP GUIDE VISTA W FIN (HL-5280DW) add
5 LU0365001 1 SETUP GUIDE VISTA ENG/CEZ/HUN
HL-5240/5250DN/5270DN
5 LU0366001 1 SETUP GUIDE VISTA POL/BUL/ROM
5 LU0367001 1 SETUP GUIDE VISTA RUS (HL-5240/5250DN/5270DN) add
5 LU0368001 1 SETUP GUIDE VISTA CHN (HL-5250DN) add
6 LU7878001 1 SETUP GUIDE VI/7 ENG (HL-5240L UK,
6 LU7879001 1 SETUP GUIDE VI/7 GER (HL-5240L GER/SWI/EEU GENERAL) ADD
6 LU7880001 1 SETUP GUIDE VI/7 FRE (HL-5240L SWI/FRA/BEL/DUT) ADD
6 LU7881001 1 SETUP GUIDE VI/7 DUT (HL-5240L) ADD
6 LU7882001 1 SETUP GUIDE VI/7 SWI/ITA (HL-5240L) ADD
6 LU7883001 1 SETUP GUIDE VI/7 SPA (HL-5240L) ADD
6 LU7884001 1 SETUP GUIDE VI/7 POR (HL-5240L) ADD
6 LU7885001 1 SETUP GUIDE VI/7 NOR (HL-5240L) ADD
6 LU7886001 1 SETUP GUIDE VI/7 SWE (HL-5240L) ADD
6 LU7887001 1 SETUP GUIDE VI/7 DEN (HL-5240L) ADD
6 LU7888001 1 SETUP GUIDE VI/7 FIN (HL-5240L) ADD
6 LU7891001 1 SETUP GUIDE VI/7 ENG/CEZ/HUN (HL-5240L) ADD
6 LU7892001 1 SETUP GUIDE VI/7 POL/BUL/ROM (HL-5240L) ADD
6 LU7893001 1 SETUP GUIDE VI/7 RUS (HL-5240L) ADD
6 LU7890001 1 SETUP GUIDE VI/7 CHN (HL-5240) ADD
7 LJ9803001 1 USB CABLE 2.0 (CHN) add
8 LU1261001 1 DRUM CLEANING SHEET KIT AL ADD
HL-5240/5250DN/5270DN
HL-5250DN ISR/SGP/GULF
HL-5270DN ISR
add
add
ADD
84UZ91/92/93/94/95 HL-5240/5250DN/5270DN/5280DW/5250DNT
- 29 -
14. ACCESSORIES
2
1
3
4
5
6
7
8
- 30 -
15. PACKING MATERIALS
REF No. CODE Q'TY DESCRIPTION REMARKS
1 LM5616001 1 CARTON HL-5240 US
1 LL0943001 1 CARTON (HL-5250 US, HL-5250DN ARG/CHI, HL-5250DNT US)
1 LM5841001 1 CARTON HL-5280DW US
1 LM5639001 1 CARTON HL-5240 EU
1 LU0525001 1 CARTON HL-5240L EU
1 LM5699001 1 CARTON HL-5250DN EU
1 LM5765001 1 CARTON HL-5270DN EU
1 LM5837001 1 CARTON HL-5280DW EU
1 LM5655001 1 CARTON HL-5240 CHN
1 LM5722001 1 CARTON HL-5250DN CHN
1 LM6786001 1 CARTON HL-5240 KOR add
1 LU0245001 1 CARTON HL-5250DN KOR add
1 LM6953001 1 CARTON HL-5240 IND add
1 LM6956001 1 CARTON HL-5250DN IND add
1 LU0052001 1 CARTON HL-5251DN COSIP ITA add
2 LM5294001 1 POLYSTYRENE PAD ASSY AL 40/50 (HL-5240/5240L/
5250DN/5250DNT/5251DN)
2 LM5599001 1 POLYSTYRENE PAD ASSY AL 70/80 (HL-5270DN/5280DW)
3 LM5298001 1 OPTION CARTON AL
4 LJ5584001 1 BAG, 700X800H
5 LM5826001 1 CARTON OUTER 5250DNT US
6 LM5829001 4 PAD 5250DNT A (HL-5250DNT US)
7 LM2042001 2 PAD 5050LT B (HL-5250DNT US)
84UZ91/92/93/94/95 HL-5240/5250DN/5270DN/5280DW/5250DNT
- 31 -
15. PACKING MATERIALS
2
4
3
2
2
(HL-5250DNT)
7
1
7
5
6
6
6
6
- 32 -
16. PERIODICAL MAITENANCE PARTS
REF No. CODE Q'TYDESCRIPTION REMARKS
1 LM5852001 1 ROLLER HOLDER SP ASSY
2 LM6753001 1 MP ROLLER HOLDER SP ASSY 2 chg
84UZ91/92/93/94/95 HL-5240/5250DN/5270DN/5280DW/5250DNT
- 33 -
16. PERIODICAL MAINTENANCE PARTS
1
2
- 34 -
Loading...
