Basic User's Guide

DCP-J562DW

Online User's Guide

This Basic User's Guide contains basic instructions and information for your Brother machine.

For more advanced instructions and information, see the Online User's Guide at solutions.brother.com/manuals

If you need to call Customer Service

Please complete this information for future reference:

Model Number:

DCP-J562DW

Serial Number: 1

Date of Purchase:

Place of Purchase:

1The serial number is on the back of the machine. Retain this User’s Guide with your sales receipt as a permanent record of your purchase, in the event of theft, fire or warranty service.

Register your product online at

http://www.brother.com/html/registration

© 2015 Brother Industries, Ltd. All rights reserved.

You Can Use the Following Features

Mobile Connect

Use Brother iPrint&Scan to check the machine status and access various functions from mobile devices.

By installing Brother iPrint&Scan on your mobile device and connecting to the machine, you can use the following convenient features:

Print

You can print photos, documents, and web pages from your mobile device. You can also print files from various web services.

Scan

You can scan photos and documents and save them to your mobile device.

Copy

You can use your mobile device to edit scanned images (crop and rotate images), and then print them using the machine.

Check the Machine Status

You can check the remaining ink levels and other information, and view error solutions.

For more information, see the

Mobile Print/Scan Guide for Brother iPrint & Scan:

solutions.brother.com/manuals

Web Connect / Brother Apps

Scan and upload images and files to popular web services directly from your machine. Capture and convert information directly from your machine without your computer.

For more information, see the

Web Connect Guide: solutions.brother.com/manuals

Printing Scanning

i

User's Guides and Where to Find Them

Which Guide?

What's in It?

Where Is It?

Product Safety Guide

Read this Guide first. Please read the Safety

Printed / In the box



Instructions before you set up your machine.





See this Guide for trademarks and legal





limitations.









Quick Setup Guide

Follow the instructions for setting up your

Printed / In the box



machine, and installing the drivers and





software for the operating system and





connection type you are using.









Basic User's Guide

Learn the basic PC-Print, Scan, Copy and

Printed / In the box



PhotoCapture Center operations and basic





machine maintenance. See troubleshooting





tips.









Online User's Guide

This guide includes the additional contents of

HTML and PDF file /



the Basic User’s Guide.

Brother Solutions



In addition to information about the PC-Print,

Center 1



Scan, Copy, PhotoCapture Center and





Brother ControlCenter operations, useful





information is included about using the





machine on a network.









Web Connect Guide

This Guide provides useful information about

PDF file / Brother



accessing Internet services from the Brother

Solutions Center 1



machine, as well as downloading images,





printing data and uploading files directly to





Internet services.









AirPrint Guide

This Guide provides information for using

PDF file / Brother



AirPrint to print from OS X v10.8.5 or later

Solutions Center 1



and your iPhone, iPod touch, iPad, or other





iOS device to your Brother machine without





installing a printer driver.









Google Cloud Print Guide

This Guide provides details about how to use

PDF file / Brother



Google Cloud Printservices for printing

Solutions Center 1



over the Internet.









Mobile Print/Scan Guide

This Guide provides useful information about

PDF file / Brother

for Brother iPrint&Scan

printing from your mobile device and

Solutions Center 1



scanning from your Brother machine to your





mobile device when connected to a Wi-Fi®





network.









1Visit solutions.brother.com/manuals.

ii

Basic Operations and Where to Find Instructions

The contents of the Basic User's Guide are also included in the Online User's Guide with more details.

Features

Contents

Guide

Setup

Load paper

Basic User's Guide









Connect the machine to your computer

Quick Setup Guide









Connect the machine to your mobile

Quick Setup Guide



device









Copy

Copy a document

Basic User's Guide









Various types of copies (2-sided copies,

Online User's Guide



and so on)









Print

Print from your computer (Windows®/

Basic User's Guide



Macintosh)











Print from your mobile device (Brother

Mobile Print/Scan Guide



iPrint&Scan)











Print using the AirPrint function

AirPrint Guide









Print using the Google Cloud Print

Google Cloud Print Guide



function











Print data downloaded from a cloud

Web Connect Guide



service









Scan

Scan from the machine

Basic User's Guide









Scan from your computer

Basic User's Guide









Scan from your mobile device (Brother

Mobile Print/Scan Guide



iPrint&Scan)











Save scanned data to a cloud service

Web Connect Guide








Print a photo

Basic User's Guide







Additional

Error messages

Basic User's Guide

information





Troubleshooting

Basic User's Guide











Specifications

Online User's Guide







iii

The Online User's Guide Helps You Get the Most Out of Your Machine

We hope that you find this guide helpful. To learn more about your machine's features, please take a look at our Online User's Guide. It offers:

Quicker navigation!

Search box

Navigation index in a separate panel

Comprehensive!

Every topic in one guide

Simplified Layout!

Provides step-by-step instructions

Feature summary at the top of the page

1

2

3

4

1.Search Box

2.Navigation

3.Summary

4.Step-by-Step

To View Online User's Guides

To view the Online User's Guide and other available guides, visit solutions.brother.com/manuals.

For Windows® users only: you can also access your machine's guides by using Brother Utilities. The Brother Utilities tool is included in the standard installation and, once installed, you can find it

either as a shortcut on your desktop, or from the Windows® Start menu.

iv

Questions or Problems? Please take a look at our FAQs, solutions, and videos online.

Go to your model's FAQs & Troubleshooting page on the Brother Solutions Center at http://support.brother.com

Provides several ways to search!

Displays related questions for more information

Receives regular updates based on customer feedback

Since the Brother Solutions Center is updated regularly, this screenshot is subject to change without notice.

v

Definitions of Notes

We use the following symbols and conventions throughout this User's Guide:

IMPORTANT

IMPORTANT indicates a potentially hazardous situation which, if not avoided, may result in damage to property or loss of product functionality.

NOTE

NOTE specifies the operating environment, conditions for installation, or special conditions of use.

Tips icons provide helpful hints and supplementary information.

Bold

Bold style identifies buttons on the machine's control panel or computer screen.

Italics

Italicised style emphasises an important point or refers you to a related topic.

[Courier New]

Courier New font identifies messages shown on the machine's LCD.

• Most of the illustrations in this User's Guide show the DCP-J562DW.

vi

For the Latest Driver Updates

Go to your model's Downloads page on the Brother Solutions Center at http://support.brother.com to download drivers.

To keep your machine’s performance up-to-date, check there for the latest firmware upgrades.

Compilation and Publication Notice

This manual has been compiled and published to provide the latest product safety information at the time of publication. The information contained in this manual may be subject to change.

For the latest manual, visit us at solutions.brother.com/manuals.

vii

Table of Contents

Basic User's Guide

1

2

General Information ............................................................................................

1

Control Panel Overview.............................................................................................

1

Touchscreen LCD Overview ......................................................................................

3

Cloud Service Notifications..............................................................................

5

Access Brother Utilities (Windows®) .........................................................................

5

Uninstall the Brother Software and Drivers (Windows®) .................................

6

Paper Handling ....................................................................................................

7

3

4

5

Load Paper ................................................................................................................

7

Load paper in the paper tray............................................................................

7

Load Photo Paper............................................................................................

8

Load Paper in the Manual Feed Slot ...............................................................

9

Change the Check Paper Size Setting ..........................................................

12

Change the Paper Size and Paper Type .................................................................

12

Recommended Print Media .....................................................................................

13

Handle and Use Print Media....................................................................................

13

Print ....................................................................................................................

14

Print from Your Computer ........................................................................................

14

Print a Document (Macintosh) .......................................................................

14

Print a Document (Windows®) .......................................................................

14

Print on Both Sides of the Paper Automatically (Automatic 2-sided



Printing) (Windows®) .....................................................................................

14

Print More Than One Page on a Single Sheet of Paper (N in 1)



(Windows®)....................................................................................................

15

Print Photos from ControlCenter4 (Windows®) .............................................

15

Copy ...................................................................................................................

17

Copy a Document ...................................................................................................

17

Copy Settings ..........................................................................................................

18

Copy Options .................................................................................................

18

Scan....................................................................................................................

20

Scan from Your Computer (Windows®) ...................................................................

20

Scan Using ControlCenter4 Home Mode (Windows®) ..................................

20

Scan Using the Scan Button on Your Brother Machine...........................................

21

Scan Using the Scan Button on the Machine ................................................

21

viii

6 PhotoCapture Center ........................................................................................

22

Print Photos Directly from Media .............................................................................

22

Preview and Print Photos and Movie Files from Media .................................

22

PhotoCapture Center print settings overview ................................................

22

A Routine Maintenance ........................................................................................

23

Clean the Scanner...................................................................................................

23

Check the Print Quality............................................................................................

23

Check the Print Alignment from Your Brother Machine ...........................................

24

B Troubleshooting ................................................................................................

26

Identify the Problem.................................................................................................

26

Error and Maintenance Messages...........................................................................

28

Troubleshooting for Wireless LAN setup .................................................................

33

Wireless LAN Report Error Codes.................................................................

33

Print or Scan Problems............................................................................................

35

Troubleshooting for Other Print Problems .....................................................

37

Printer Jam or Paper Jam........................................................................................

38

Paper is Jammed Inside and in the Front of the Machine (Jam A Inside/



Front) .............................................................................................................

38

Paper is Jammed in the Front of the Machine (Jam B Front) ........................

40

Paper is Jammed in the Back of the Machine (Jam C Rear).........................

42

C

D

Appendix ............................................................................................................

44

Enter Text on Your Brother Machine........................................................................

44

Information for compliance with Commission Regulation 801/2013........................

44

Supply Specifications ..............................................................................................

45

Index ...................................................................................................................

46

ix

1General Information

Control Panel Overview

1

2

3

Information General 1

1.2.7"(67.5 mm) Touchscreen Liquid Crystal Display (LCD)

Access menus and options by pressing them on this Touchscreen. Adjust the angle of the Touchscreen LCD and Touchpanel by lifting it.

2. Touchpanel

(Back)

Press to go back to the previous menu.

(Home)

Press to return to the Home screen.

While the machine is in Sleep Mode, the Home icon blinks.

1

(Cancel)

Press to cancel an operation (available when illuminated in red).

3. Power On/Off

Press to turn the machine on.

Press and hold down to turn the machine off. The Touchscreen will display [Shutting Down] and will stay on for a few seconds before turning itself off.

If you turn the machine off using , it will still clean the print head periodically to maintain

print quality. To prolong print head life, provide better ink efficiency, and maintain print quality, keep your machine connected to a power source at all times.

2

Touchscreen LCD

Overview

There are two Home screens that you can access by pressing d or c.

From the Home screens, you can access WiFi setup, Shortcuts, Ink levels and Setup screens.

Home Screen 1

1 2

3

4

5

6

This screen shows the machine’s status when the machine is idle. This Home screen is also called the Ready Mode screen. When displayed, this indicates that your machine is Ready for the next command.

Home Screen 1 provides access to [Copy], [Scan] and [Photo] operations.

Home Screen 2

1 2

3

4

5

6

Home Screen 2 provides access to additional features, such as [Web] and [Apps] operations.

1. Quiet Mode

This icon appears when the [Quiet Mode] setting is set to [On].

The Quiet Mode setting can reduce printing noise. When Quiet Mode is turned on, the print speed becomes slower.

2. Wireless Status

Each icon in the following table shows the wireless network status.

Your machine has not been connected to the wireless access point.

Press this button to configure wireless settings. For more information, see the Quick Setup Guide.

Wireless network is connected.

A three-level indicator in each of the Home screens displays the current wireless signal strength.

The wireless access point cannot be detected.

The wireless setting is disabled.

You can configure wireless settings by pressing the Wireless Status button.

3. [Shortcuts]

Create Shortcuts for frequently-used operations such as making a copy, scanning and using Web Connect.

Information General 1

3

There are three Shortcuts screens. You can program four shortcuts on each screen.

To display the other Shortcuts screens, press d or c.

4. [Ink]

Displays the available ink volume. Press to access the [Ink] menu.

When an ink cartridge is near the end of its life or having a problem, an error icon is displayed on the ink colour.

5. [Settings]

Press to access the [Settings] menu.

6.Modes:

[Copy]

Press to access Copy mode.

[Scan]

Press to access Scan mode.

[Photo]

Press to access Photo mode.

[Web]

Press to connect the Brother machine to an Internet service.

For more information, see the Web Connect Guide: solutions.brother.com/ manuals

[Apps]

Press to connect the Brother machine to the Brother Apps service.

For more information, see the Web Connect Guide: solutions.brother.com/ manuals

7. Warning icon

7

The warning icon appears when there

is an error or maintenance message; press [Detail] to view it, and then press

to return to Ready mode.

IMPORTANT

DO NOT press the LCD with a sharp object such as a pen or stylus. It may damage the machine.

• This product adopts the font of ARPHIC TECHNOLOGY CO.,LTD.

DO NOT touch the LCD immediately after plugging in the power cord or turning on the machine. Doing this may cause an error.

4

Cloud Service Notifications

If you use Brother Web Connect and [New Function Notice] is set to [On], notifications about cloud services will appear on the Home screen.

Check for new notifications by pressing

[Detail].

Access Brother Utilities (Windows®)

Brother Utilities is an application launcher that offers convenient access to all Brother applications installed on your computer.

1Do one of the following:

(Windows® XP, Windows Vista® and Windows® 7)

Click (Start) > All Programs > Brother > Brother Utilities.

(Windows® 8)

Tap or click (Brother Utilities) either on the Start screen or the desktop.

(Windows® 8.1)

Move your mouse to the lower left corner of the Start screen and click

(if you are using a touch-based device, swipe up from the bottom of the Start screen to bring up the Apps screen).

When the Apps screen appears, tap or click (Brother Utilities).

2 Select your machine.

Information General 1

5

3 Choose the operation you want to use.

Uninstall the Brother Software and Drivers

(Windows®)

1 Launch (Brother Utilities).

2Click the drop-down list, and then select your model name (if not already selected). Click Tools in the left navigation bar, and then click Uninstall.

Follow the instructions in the dialog box to uninstall the software and drivers.

6

2Paper Handling

Load Paper

Load paper in the paper tray

If the [Check Paper] setting is set to [On] and you pull the paper tray out of the machine, a message appears on the LCD asking if you want to change the paper type and paper size. Change the Paper Size and Paper Type settings if needed, following the on-screen instructions.

Load only one size and type of paper in the paper tray at a time.

When you load a different paper size in the tray, you must change the Paper Size setting in the machine or the paper size setting on your computer.

1Pull the paper tray completely out of the machine.

2 Open the output paper tray cover (1).

1

3

Gently press and slide the paper width

guides (1) and then the paper length

guide (2) to fit the paper size.

1

2

4 Fan the stack of paper well.

5Gently load paper in the paper tray with the printing surface face down.

Make sure the paper is flat in the tray and the paper length guide (1) touches the edges of the paper.

Handling Paper 2

7

1

IMPORTANT

Be careful not to push the paper in too far; it may lift at the back of the tray and cause paper feed problems.

Loading more than 20 sheets of Photo 2L (13 x 18 cm) paper may cause paper jams.

To add paper before the tray is empty, remove the paper from the tray and combine it with the paper you are adding. Always fan the stack of paper well to prevent the machine from feeding multiple pages.

6Gently adjust the paper width guides (1) to fit the paper.

Make sure the paper guides touch the edges of the paper.

1

7Close the output paper tray cover. Slowly push the paper tray completely into the machine.

8While holding the paper tray in the machine, pull out the paper support (1) until it locks into place, and then unfold the paper support flap (2).

2

1

Load Photo Paper

Use the photo paper tray which is located on the top of the output paper tray cover, to print on Photo (10 x 15 cm) or Photo L (89 x 127 mm) size paper.

1Press the blue photo paper tray release button (1) and slide the output paper tray cover forward until it locks into the photo printing position (2).

1

2

8

2Load up to 20 sheets of photo paper in the photo paper tray with the printing surface face down.

3Gently adjust the paper width guides to fit the paper. Make sure the paper width guides (1) touch the edges of the paper and the paper is flat in the tray.

1

IMPORTANT

When you have finished printing photos, return the photo paper tray to the Normal printing position. If you do not, you will get a [No Paper Fed] error when you use cut sheet paper.

Photo Paper Tray in the Normal printing position

Photo Paper Tray in the Photo printing position

Related Information

Print Photos from ControlCenter4 (Windows®) on page 15

Load Paper in the Manual

Feed Slot

Load special print media in this slot one sheet at a time.

IMPORTANT

DO NOT load more than one sheet of paper in the manual feed slot at any one time. Doing this may cause a paper jam.

DO NOT load paper in the manual feed slot when you are printing from the paper tray. Doing this may cause a paper jam.

Handling Paper 2

9

1 Open the manual feed slot cover.

2 Lift up the paper support.

3Slide the manual feed slot paper guides to fit the width of the paper you are using.

4Load only one sheet of paper in the manual feed slot with the printing surface face up.

5Using both hands, gently adjust the manual feed slot paper guides to fit the paper.

10

6Using both hands, push one sheet of paper into the manual feed slot until the front edge touches the paper feed rollers. Let go of the paper when you hear the machine pull it. The LCD displays [Manual Feed Slot ready.]. Read the instruction displayed on the LCD, and then press

[OK].

7While holding the paper tray in the machine, pull out the paper support (1) until it locks into place, and then unfold the paper support flap (2).

2

1

• If the document does not fit on one sheet, the Touchscreen will prompt you to load another sheet of paper. Place another sheet of paper in the manual feed slot, and then press [OK] on the Touchscreen.

When you are using envelopes, load the envelopes with the printing surface face up and the flap on the left as shown in the illustration.

Handling Paper 2

When loading an envelope, or a sheet of thick paper, push the envelope into the manual feed slot until you feel the paper feed rollers grab it.

Related Information

Error and Maintenance Messages on page 28

11

Change the Check Paper

Size Setting

If the Check Paper setting is set to [On] and you pull the paper tray out of the machine, the LCD displays a message asking if you want to change the Paper Size and Paper Type settings.

The default setting is [On].

1Press [Settings] > [All

Settings] > [General Setup] > [Check Paper].

2 Press [On] or [Off].

3 Press .

Related Information

Error and Maintenance Messages on page 28

Change the Paper Size

and Paper Type

Set the Paper Size and Paper Type settings for the paper tray.

To get the best print quality, set the machine for the type of paper you are using.

When you change the size of the paper you load in the tray, you must change the Paper Size setting on the LCD at the same time.

1 Press [Settings] > [Paper Type].

2Press a or b to display the [Plain

Paper], [Inkjet Paper], [Brother BP71] or [Other Glossy] option, and then press the option you want.

3 Press [Paper Size].

4Press a or b to display the paper size options, and then press the option you want.

5 Press .

The machine ejects paper with the printed surface face up onto the paper tray at the front of the machine. When you use glossy paper, remove each sheet at once to prevent smudging or paper jams.

Related Information

Error and Maintenance Messages on page 28

12

Recommended Print

Media

For the best print quality, we recommend using the Brother paper listed in the table.

If Brother paper is not available in your country, we recommend testing various paper types before purchasing large quantities.

Brother paper

Paper Type

Item

A4 Plain

BP60PA





A4 Glossy Photo

BP71GA4





A4 Inkjet (Matte)

BP60MA





10 x 15 cm Glossy




BP71GP





Handle and Use Print

Media

Store paper in its original packaging and keep it sealed. Keep the paper flat and away from moisture, direct sunlight and heat.

Avoid touching the shiny (coated) side of photo paper.

IMPORTANT

DO NOT use the following kinds of paper:

Damaged, curled, wrinkled, or irregularly shaped

1

1

1.2 mm or greater curl may cause jams to occur.

Extremely shiny or highly textured

Paper that cannot be arranged uniformly when stacked

Paper made with a short grain

Paper capacity of the output paper tray cover

Up to 50 sheets of A4 80 g/m² paper.

Photo paper must be picked up from the output paper tray cover one page at a time to avoid smudging.

Handling Paper 2

13

3Print

Print from Your Computer

Print a Document (Macintosh)

For printing instructions, see the Online User's Guide: Print from Your Computer (Macintosh).

Print a Document (Windows®)

1Select the print command in your application.

2Select Brother DCP-XXXX (where XXXX is the name of your model).

3 Click Print.

4 Complete your print operation.

For more information, see the Online User's Guide: Print from Your Computer

(Windows®).

Print on Both Sides of the Paper Automatically (Automatic 2-sided Printing)

(Windows®)

Make sure the back cover is closed.

If paper is curled, straighten it and put it back in the paper tray.

Use regular paper or thin paper. DO NOT use bond paper.

If the paper is thin, it may wrinkle.

1Select the print command in your application.

2Select Brother DCP-XXXX (where XXXX is the name of your model), and then click the printing properties or preferences button.

The printer driver window appears.

14

3In the Orientation field, select either the

Portrait or Landscape option to set the orientation of your printout.

If your application software contains a similar layout feature, we recommend using the one in the application.

4Click the 2-sided / Booklet drop-down list, and then select 2-sided.

5 Click the 2-sided Settings button.

6Select one of the options from the

2 sided Type menu.

7Select the Binding Offset check box if you want to specify the offset for binding in inches or millimetres.

8Click OK to return to the printer driver window.

9 Change other printer settings if needed.

The Borderless feature is not available when using this option.

10 Click OK again, and then complete your print operation.

Print More Than One Page on a Single Sheet of Paper

(N in 1) (Windows®)

1Select the print command in your application.

2Select Brother DCP-XXXX (where XXXX is the name of your model), and then click the printing properties or preferences button.

The printer driver window appears.

3In the Orientation field, select either the

Portrait or Landscape option to set the orientation of your printout.

If your application software contains a similar layout feature, we recommend using the one in the application.

4Click the Multiple Page drop-down list, and then select the 2 in 1, 4 in 1, 9 in 1, or 16 in 1 option.

5Click the Page Order drop-down list, and then select your page order.

6Click the Border Line drop-down list, and then select your border line type.

7 Change other printer settings if needed.

8Click OK, and then complete your print operation.

Print Photos from ControlCenter4 (Windows®)

You can print and edit photos using various ControlCenter features.

In the following steps, the ControlCenter Home mode is used as an example.

1Make sure you have loaded the correct media in the paper tray.

2Click the (ControlCenter4) icon in the task tray, and then click Open.

Print 3

15

3

4

5

Click the Photo tab.

Select the folder that contains the image you want to print.

Select images you want to print by clicking the image in the image viewer and selecting the check box under the image.

6

7

8

9

Specify the number of copies you want to print (1-99) by clicking .

Click Print.

The print settings window appears.

Configure the settings for the Paper Size, Media Type, and Layout options.

Click the Start Printing button.

Related Information

• Load Photo Paper on page 8

16

4Copy

Copy a Document

1Make sure you have loaded the correct size paper in the paper tray.

2Place the document face down on the scanner glass.

3Press [Copy].

The Touchscreen displays:

4 Change the copy settings, if needed.

• When you load paper other than A4 size Plain Paper, you must change the

[Paper Size] and [Paper Type] settings by pressing the [Options] button.

(No. of Copies )

Press to display the keyboard on the Touchscreen, and then enter the number of copies using the Touchscreen keyboard. Press [OK].

You can also use [-] or [+].

[Options]

Press to change the copy settings for the next copy only.

When finished, press [OK].

After you have finished choosing new options, you can save them by pressing the [Save as

Shortcut] button.

5Press [Mono Start] or [Colour Start].

To stop copying, press .

Copy 4

17

Copy Settings

Copy Options

To change copy settings, press the [Options] button.

Option

Description



Quality

Select the Copy resolution for your type of document.



• When you select the Normal option, Plain Paper is the only



Paper Type option.



Paper Type

Select a paper type.





If you are copying on special paper, set the machine for the type of



paper you are using to get the best print quality.







Paper Size

Select a paper size.





If you are copying on paper other than A4 size, you must change the



Paper Size setting.









Enlarge/Reduce

100%

-



Enlarge

Select an enlargement ratio for the





next copy.



Reduce

Select a reduction ratio for the next





copy.



Fit to Page

Adjusts the copy size to fit on the





paper size you have set.



Custom(25-400%)

Enter an enlargement or reduction





ratio.

Density

Increase the density to make the text darker.



Decrease the density to make the text lighter.





Stack/Sort

Select to stack or sort multiple copies.



Stack







Sort







B



B

B

B



B







AB B A





A A





A













A



Page Layout

Make N in 1, 2 in 1 ID, or Poster copies.







4 in1







Poster





18

Option

Description





2-sided Copy Select to copy on both sides of the paper.

1-sided→2-sided

2-sided→2-sided



1

1



2

2

Advanced Remove Background Colour

Settings Removes the document's background colour in copies. The white background becomes more apparent. This saves some ink and may make certain copies easier to read.

Set New Default Saves the copy settings that you use most often by setting them as the default settings.

Factory Reset Restores any changed copy settings to the factory settings.

Save as Shortcut Add the current settings as a shortcut.

Copy 4

19

5Scan

Scan from Your Computer (Windows®)

There are several ways you can use your computer to scan photos and documents on your Brother machine. Use the software applications provided by Brother, or use your favourite scanning application.

Scan Using ControlCenter4

Home Mode (Windows®)

Select Home Mode as the mode setting for ControlCenter4.

1 Load your document.

2Click the (ControlCenter4) icon in the task tray, and then click Open.

3 Click the Scan tab.

4

Select the Document Type.

5

needed.Change the document's Scan Size, if

6Click (Scan).

The machine starts scanning, and the scanned image appears in the image viewer.

7 Crop the scanned image, if needed.

8Do one of the following:

Click (Save) to save scanned data.

Click (Print) to print scanned data.

Click (Open with an Application) to open scanned data in another application.

Click (Send E-mail) to attach scanned data to an email.

20

Scan Using the Scan Button on Your Brother Machine

Scan Using the Scan Button on the Machine

Use the Scan button on the machine to make temporary changes to the scan settings. To make permanent changes, use Brother's ControlCenter software.

1Place the document face down on the scanner glass.

2 Press [Scan] > [to File].

3If the machine is connected over the network, press a or b to display the computer where you want to send data, and then press the computer name.

If the LCD prompts you to enter a PIN, use the LCD to enter the four-digit PIN for the computer, and then press [OK].

4Do one of the following:

To change the settings, press [Options], and then go to the next step.

Press [Start] to start scanning without changing additional settings.

The machine starts scanning. Follow the LCD instructions to complete the scanning job.

5Press the [Scan Settings] option, and then press [Set at Device].

To use the [Scan Settings] option, a computer with the ControlCenter software installed must be connected to the machine.

6Select the scan settings you want to change, and then press [OK].

[Scan Type]

Select the scan type for your document.

[Resolution]

Select the scan resolution for your document.

[File Type]

Select the file format for your document.

[Scan Size]

Select the scan size for your document.

[Remove Background Colour]

Change the amount of background colour that is removed.

7Press [Start].

The machine starts scanning. Follow the LCD instructions to complete the scanning job.

Scan 5

21

6PhotoCapture Center

Print Photos Directly from Media

Preview and Print Photos and Movie Files from Media

Preview your photos on the LCD before you print them. Print images from movie files that are stored on a memory card.

1 Open the media slot cover.

2

Put the memory card in the correct slot.

3

Press [Photo] > [View Photos].

4Press d or c to display the photo you want to print, and then press it.

If you want to print all the photos, press [Print All], and then press the [Yes] button to confirm.

5Press to display the keyboard on the Touchscreen, and then enter the number of copies using the Touchscreen keyboard. Press [OK].

You can also use [-] or [+].

6 Press [OK].

7Repeat the last three steps until you have selected all the photos you want to print.

8 Press [OK].

9Read and confirm the displayed list of options.

10 To change the print settings, press

[Print Settings].

11 Press [Start].

PhotoCapture Center print settings overview

The Print Settings you change are temporary for your current printout. The machine returns to its default settings after printing is complete.

You can save the print settings you use most often by setting them as the default.

For more information, see the Online User's Guide.

22

ARoutine Maintenance

Clean the Scanner

1 Unplugsocket. the machine from the electrical

2Lift the document cover (1). Clean the scanner glass (2) and the white plastic

(3) with a soft lint-free cloth moistened with a non-flammable glass cleaner.

1

3



2

Related Information

Troubleshooting for Other Print Problems on page 37

Check the Print Quality

If faded or streaked colours and text appear or if text is missing on your printouts, the print head nozzles may be clogged. Print the Print Quality Check Sheet and look at the nozzle check pattern.

1Press [Ink] > [Improve Print Quality] > [Check Print

Quality].

You can also press [Settings] >

[Maintenance] > [Improve Print Quality] > [Check Print Quality].

2Press [Start].

The machine prints the Print Quality Check Sheet.

3Check the quality of the four colour blocks on the sheet.

4The Touchscreen asks about the print quality. Do one of the following:

If all lines are clear and visible, press

[No], and then press to finish the Print Quality check.

If lines are missing (see Poor, below), press [Yes].

OK

Poor

5The Touchscreen asks you to check the print quality of each colour. Press the number of the pattern (1–4) that most closely matches the printing result.

6Do one of the following:

If print head cleaning is needed, press [Start] to start the cleaning procedure.

If print head cleaning is not needed, the Maintenance screen reappears on the LCD. Press .

Maintenance Routine A

23

7After the cleaning procedure is finished, the Touchscreen asks if you want to print the Print Quality Check Sheet again. Press [Yes], and then press

[Start].

The machine prints the Print Quality Check Sheet again. Check the quality of the four colour blocks on the sheet again.

If you clean the print head and the print has not improved, try installing a new Genuine Brother Brand replacement ink cartridge for each problem colour. Try cleaning the print head again. If the print has not improved, contact Brother customer service or your local Brother dealer.

IMPORTANT

DO NOT touch the print head. Touching the print head may cause permanent damage and may void the print head's warranty.

When a print head nozzle is clogged, the printed sample looks like this.

After the print head nozzle is cleaned, the horizontal lines are gone.

Related Information

Troubleshooting for Other Print Problems on page 37

Check the Print Alignment from Your Brother Machine

If your printed text becomes blurred or images become faded after transporting the machine, adjust the print alignment.

1Press [Ink] > [Improve Print Quality] > [Alignment].

You can also press [Settings] >

[Maintenance] > [Improve Print Quality] > [Alignment].

2Press [Next], and then press

[Start].

The machine starts printing the Alignment Check Sheet.

(A)

3For the (A) pattern, press a or b to display the number of the test print with the fewest visible vertical stripes (1-9), and then press it (in the example above, row number 6 is the best choice). Press

[OK].

Repeat this step for the rest of the patterns.

24

When the print alignment is not adjusted correctly, text looks blurry or crooked, like this.

After the print alignment is adjusted correctly, text looks like this.

4 Press .

Related Information

Troubleshooting for Other Print Problems on page 37

Maintenance Routine A

25

BTroubleshooting

Use this section to resolve problems you may encounter when using your Brother machine.

Identify the Problem

Even if there seems to be a problem with your machine, you can correct most problems yourself. First, check the following:

The machine's power cord is connected correctly and the machine's power is on.

All of the machine's orange protective parts have been removed.

The ink cartridges are installed correctly.

The Scanner Cover and the Jam Clear Cover are fully closed.

Paper is inserted correctly in the paper tray.

The interface cables are securely connected to the machine and the computer, or the wireless connection is set up on both the machine and your computer.

(For network models) The access point (for wireless), router, or hub is turned on and its link button is blinking.

Check the LCD or the machine's status in Status Monitor on your computer.

Find the Error



Find the Solution

Using the Status Monitor

A green icon indicates the normal stand-by









condition.







A yellow icon indicates a warning.







A red icon indicates an error has occurred.







A grey icon indicates the machine is









offline.







Click the Troubleshooting button to









access Brother's troubleshooting website.

Double-click the

icon in the task tray.





(Windows®) If you check Load Status







Monitor on Startup, the Status Monitor will







launch automatically each time you start your







computer.

















26

Find the Error

Find the Solution

Using the LCD

1.

Follow the messages on the LCD.



2.

See the instructions in the following Error





and Maintenance Messages table.



3.

If you cannot resolve the error, please





refer to the Online User's Guide: Error





and Maintenance Messages or see FAQs





on the Brother Solutions Center at





http://support.brother.com







Troubleshooting B

27

Error and Maintenance Messages

The most common error and maintenance messages are shown in the table. To see more detailed information, read the Online User's Guide.

You can correct most errors and perform routine maintenance yourself. If you need more tips, go to your model's FAQs & Troubleshooting page on the Brother Solutions Center at http:// support.brother.com.

Error Message

Action

B&W 1-sided Print

One or more of the colour ink cartridges have reached the end of their

Only

lives.

Replace ink.

Replace the ink cartridges.



For more information, see the Online User's Guide: Replace the Ink



Cartridges.



The machine will stop all print operations and you will not be able to



use the machine until you change to a new ink cartridge in the



following cases:



If you unplug the machine or take out the ink cartridge.



(Windows®) If you select Slow Drying Paper in the Basic tab of





the printer driver.





(Macintosh) If you select Slow Drying Paper in the Print Settings





drop-down list of the printer driver.





Cannot Detect

Take out the new ink cartridge and reinstall it slowly and firmly until it



latches.



For more information, see the Online User's Guide: Replace the Ink



Cartridges.







Remove the used ink cartridge and install a new one.







Replace the cartridge with a Brother Original ink cartridge. If the error



message remains, contact Brother customer service or your local



Brother dealer.







Slowly turn the ink cartridge so that the ink supply port is pointing



downward, and then reinstall the cartridge.







Check the model numbers of the ink cartridges and install the correct



ink cartridges.



See Related Information: Supply Specifications at the end of this



section.





Cannot Detect Ink

Replace the cartridge with a Brother Original ink cartridge. If the error

Volume

message remains, contact Brother customer service or your local



Brother dealer.

28

Error Message

Action

Cannot Print

One or more of the ink cartridges have reached the end of their lives.

Replace ink.

Replace the ink cartridges.



For more information, see the Online User's Guide: Replace the Ink



Cartridges.



You can still scan even if the ink is low or needs to be



replaced.

Data Remaining in

Press





. The machine will cancel the job and clear it from the

Memory







memory. Try to print again.



High Temperature

After cooling the room, allow the machine to cool down to room



temperature. Try again when the machine has cooled down.

Ink Absorber Pad

The ink absorber box or flushing box must be replaced. Contact

Full

Brother customer service or your local Brother Authorised Service



Centre to have your machine serviced.



Reasons for cleaning are:



1. The machine automatically cleans itself after you remove the



power cord and plug it back in.



2. After a paper jam has been cleared, the machine automatically



cleans itself before the next received page is printed.



3. The machine automatically cleans itself after sitting idle for more



than 30 days (infrequent use).



4. The machine automatically cleans itself after ink cartridges of the



same colour have been replaced 12 times.





Ink Absorber Pad

The ink absorber box or flushing box must be replaced soon. Contact

NearFull

Brother customer service or your local Brother dealer.

Ink Low

One or more of the ink cartridges are near the end of their lives.



Order a new ink cartridge. You can continue printing until the



Touchscreen displays Cannot Print.



For more information, see the Online User's Guide: Replace the Ink



Cartridges.



You can still scan even if the ink is low or needs to be



replaced.





Jam A Inside/

Remove the jammed paper.

Front

See Related Information: Printer Jam or Paper Jam at the end of this

Repeat Jam A

section.

Inside/Front



Make sure the paper length guide is set to the correct paper size.









Do not put more than one sheet of paper in the manual feed slot at any



one time. Wait until the Touchscreen displays Where to Place the



Paper before you feed the next sheet of paper in the manual feed slot.

Troubleshooting B

29

Error Message

Action

Jam B Front

Remove the jammed paper.

Repeat Jam B

See Related Information: Printer Jam or Paper Jam at the end of this

Front

section.



Make sure the paper length guide is set to the correct paper size.





Jam C Rear

Remove the jammed paper.



See Related Information: Printer Jam or Paper Jam at the end of this



section.







Make sure the paper length guide is set to the correct paper size.







Clean the paper pick-up rollers.



For more information, see the Online User's Guide: Clean the Paper



Pick-up Rollers.





Low Temperature

After warming the room, allow the machine to warm up to room



temperature. Try again when the machine has warmed up.

Media card error

Multiple data storage devices were in the machine when it was turned



on.



Remove the memory card that you are not using.





Media Error

Remove the memory card from the media drive (slot) of the machine



and format it correctly.



Put the card firmly into the slot again to make sure it is in the correct



position. If the error remains, check the media drive (slot) of the



machine by putting in another memory card that you know is working.





Media is Full.

Your machine can only save to your memory card if it contains fewer



than 999 files. Delete unused files and try again.



Delete unused files from your memory card to make some free space,



and then try again.





No Ink Cartridge

Take out the new ink cartridge and re-install it slowly and firmly until it



latches.



For more information, see the Online User's Guide: Replace the Ink



Cartridges.





30

Error Message

Action





No Paper Fed

Do one of the following:



Refill the paper tray, and then follow the on-screen instructions.



Remove and reload the paper, and then follow the on-screen





instructions.







The photo paper tray is in the wrong position.



Return the photo paper tray to the Normal printing position when you



use cut sheet paper.







The paper was not inserted in the centre position of the manual feed



slot.







Remove the paper and reinsert it in the centre of the manual feed slot,



and then follow the on-screen instructions.



See Related Information: Load Paper in the Manual Feed Slot at the



end of this section.







The Jam Clear Cover is not closed correctly.





Out of Memory

If a copy operation is in progress:



Press



or Quit or Close and wait until the other operations









that are in

progress finish, and then try again.



Press Partial Print to copy the pages scanned so far.

Paper Size

1. Check that the paper size you chose on the machine's display

Mismatch



matches the size of the paper in the tray.





See Related Information: Change the Paper Size and Paper Type





at the end of this section.



2. Make sure you loaded the paper in a Portrait position, by setting





the paper guides at the indicators for your paper size.



3. After you have checked the paper size and the paper position,





follow the on-screen instructions.







If you are printing from your computer, make sure the paper size you



chose in the printer driver matches the size of paper in the tray.



For more information, see the Online User's Guide: Print Settings



(Windows®) or Print Options (Macintosh).

Paper Tray not

Slowly push the paper tray completely into the machine.

detected



Paper or a foreign object has prevented the paper tray from being



inserted properly.



Pull the paper tray out of the machine, and remove the jammed paper



or foreign object. If you cannot find or remove the jammed paper, see



Related Information: Printer Jam or Paper Jam at the end of this



section.









Repetitive No

Clean the paper pick-up rollers.

Paper Fed

For more information, see the Online User's Guide: Clean the Paper



Pick-up Rollers.











Troubleshooting B

31

Error Message

Action

Touchscreen Init.

The Touchscreen was pressed before the power on initialisation was

Failed

completed.



Make sure nothing is touching or resting on the Touchscreen,



especially when plugging the machine in.







Debris may be stuck between the lower part of the Touchscreen and



its frame.



Insert a piece of stiff paper between the lower part of the Touchscreen



and its frame and slide it back and forth to push out the debris.





Tray removed

This message is displayed when the setting to confirm the paper type



and size is enabled.



To not display this confirmation message, change the setting to Off.



See Related Information: Change the Check Paper Size Setting at the



end of this section.





Unable to Clean

A foreign object, such as a paper clip or a piece of ripped paper, is in

XX

the machine.

Unable to

Open the scanner cover and remove any foreign objects and paper

Initialize XX

scraps from inside the machine.

Unable to Print

If the error message continues, disconnect the machine from the

XX

power for several minutes, and then reconnect it.

Wrong Ink

The ink cartridge model number is not compatible with your machine.

Cartridge

Verify the cartridge model number will work with your machine.



See Related Information: Supply Specifications at the end of this



section.





Wrong Ink Colour

Check which ink cartridges are not matched by colour to their ink



cartridge positions and move them to their correct positions.

Related Information

Load Paper in the Manual Feed Slot on page 9

Change the Check Paper Size Setting on page 12

Change the Paper Size and Paper Type on page 12

Printer Jam or Paper Jam on page 38

Supply Specifications on page 45

32

Troubleshooting for Wireless LAN setup

Wireless LAN Report Error Codes

If the Wireless LAN Report shows that the connection failed, check the error code on the printed report and see the corresponding instructions in the table:

Error Code

Problem and Recommended Solutions





TS-01

The wireless setting is not activated, change the wireless setting to ON.













TS-02

The wireless access point/router cannot be detected.







1. Check the following two points:







Unplug the power to your wireless access point/router, wait for 10









seconds, and then plug it back in.







If your WLAN access point/router is using MAC address filtering,









confirm that the MAC address of the Brother machine is allowed in the









filter.







2. If you manually entered the SSID and security information (SSID/







authentication method/encryption method/Network Key), the information







may be incorrect.







Reconfirm the SSID and security information and re-enter the correct







information if needed.













TS-04

The Authentication/Encryption methods used by the selected wireless access







point/router are not supported by your machine.







For infrastructure mode, change the authentication and encryption methods of







the wireless access point/router. Your machine supports the following







authentication methods:







• WPA-Personal







TKIP or AES







• WPA2-Personal



B



AES







Troubleshooting



• Open











WEP or None (without encryption)







• Shared key







WEP







If your problem is not solved, the SSID or network settings you entered may







be incorrect. Confirm the wireless network settings.







For Ad-Hoc Mode, change the authentication and encryption methods of your







computer for the wireless setting. Your machine supports Open authentication







only, with optional WEP encryption.













TS-05

The security information (SSID/Network Key) is incorrect.







Confirm the SSID and Network Key. If your router uses WEP encryption, enter







the key used as the first WEP key. Your Brother machine supports the use of







the first WEP key only.















33

Error Code

Problem and Recommended Solutions

TS-06

The wireless security information (Authentication method/Encryption method/



Network Key) is incorrect.



Confirm the wireless security information (Authentication method/Encryption



method/Network Key) listed in TS-04. If your router uses WEP encryption,



enter the key used as the first WEP key. Your Brother machine supports the



use of the first WEP key only.





TS-07

The machine cannot detect a wireless access point/router that has WPS or



AOSSenabled.



If you would like to configure your wireless settings using WPS or AOSS,



you must operate both your machine and the wireless access point/router.



Confirm that your wireless access point/router supports WPS or AOSSand



try starting again.



If you do not know how to operate your wireless access point/router using



WPS or AOSS, see the documentation provided with your wireless access



point/router, ask the manufacturer of your wireless access point/router, or ask



your network administrator.





TS-08

Two or more wireless access points that have WPS or AOSSenabled are



detected.



Confirm that only one wireless access point/router within range has the





WPS or AOSSmethod active and try again.



Try starting again after a few minutes to avoid interference from other





access points.







34

Print or Scan Problems

IMPORTANT

Using non-Brother supplies may affect the print quality, hardware performance, and machine reliability.

If you cannot print or scan a document, check the following:

1

2

3

All of the machine's protective parts have been removed.

The interface cables are securely connected to the machine and the computer.

The printer or scanner driver has been installed correctly.

4 (Scan problem only)

Confirm the machine is assigned with an available IP address. (Windows®) a. Do one of the following:

(Windows® XP, Windows Vista® and Windows® 7)



Click

(Start) > All Programs > Brother > Brother Utilities.



Click the drop-down list and select your model name (if not already selected). Click



Scan in the left navigation bar, and then click Scanners and Cameras.



(Windows® 8)





Click

(Brother Utilities), and then click the drop-down list and select your model

B

name (if not already selected). Click Scan in the left navigation bar, and then click

Troubleshooting

Properties dialog box appears.

Scanners and Cameras. b. Do one of the following:

(Windows® XP)

Right-click a scanner device, and then select Properties. The Network Scanner

(Windows Vista®, Windows® 7 and Windows® 8) Click the Properties button.

c. Click the Network Setting tab to confirm the machine's IP address.

35

Try printing with your machine. If the problem still remains, uninstall and reinstall the printer driver.

5If the problem still remains after trying all the above, try the following: For a USB interface connection

Change the USB cable for a new one.

Use a different USB port.

For a Wireless Network connection

• Confirm your machine's Wireless status on the LCD.

Your machine has not been connected to the wireless access point. Set up the wireless network connection.

The wireless connection setting is disabled. Enable the WLAN connection and set up the wireless network connection.

The wireless access point cannot be detected. Set up the wireless network connection again.

The wireless network is connected. A three-level indicator in the LCD displays the current wireless signal strength.

You can configure wireless settings by pressing each wireless status button.

If you cannot print on both sides of paper, check the following:

6 Change the paper size setting in the printer driver to A4.

36

Troubleshooting for Other Print Problems

Difficulties

Suggestions

Poor print quality

Check the print quality.



See Related Information: Check the Print Quality at the end of this



section.







Make sure the Media Type setting in the printer driver or the Paper



Type setting in the machine’s menu matches the type of paper you are



using.



For more information, see the Online User's Guide: Print Settings



(Windows®) or Print Options (Macintosh).

White horizontal lines

Check the print quality.

appear in text or

See Related Information: Check the Print Quality at the end of this

graphics.

section.







The machine prints

Check the print quality.

blank pages.

See Related Information: Check the Print Quality at the end of this





section.





Characters and lines

Check the printing alignment.

are blurred.

See Related Information: Check the Print Alignment from Your Brother





Machine at the end of this section.





Printing appears dirty

If you are using photo paper, make sure the glossy side of the photo

or ink seems to run.

paper is face down in the tray and you have set the correct paper type.



If you are printing a photo from your computer, set the Media Type in



the printer driver.





Photo paper does not

When you print on Brother Photo paper, load one extra sheet of the

feed correctly.

same photo paper in the paper tray. An extra sheet has been included



in the paper package for this purpose.





Black marks or spots

Black marks or spots on copies are typically caused by dirt or

appear in copies.

correction fluid on the scanner glass. Clean the scanner glass and



white plastic above it.



See Related Information: Clean the Scanner at the end of this section.



Check that the speck of dirt has been removed.





Related Information

Clean the Scanner on page 23

Check the Print Quality on page 23

Check the Print Alignment from Your Brother Machine on page 24

Troubleshooting B

37

Printer Jam or Paper Jam

Locate and remove the jammed paper.

Related Information

• Error and Maintenance Messages on page 28

Paper is Jammed Inside and in the Front of the Machine (Jam A Inside/Front)

If the LCD displays [Jam A Inside/ Front] or [Repeat Jam A Inside/ Front], follow these steps:

1 Unplugsocket. the machine from the electrical

2Pull the paper tray (1) completely out of the machine.

1

3Pull the two green levers inside the machine to release the jammed paper.

4Place both hands under the plastic tabs on both sides of the machine to lift the scanner cover (1) into the open position.

1

5Slowly pull the jammed paper (1) out of the machine.

1

38

Brother DCP-L562DW User Manual

6If the LCD displays [Repeat Jam A Inside/Front], move the print head (if needed) to take out any paper remaining in this area. Make sure scraps of paper are not left in the corners of the machine (1) and (2).

2 1

IMPORTANT

DO NOT touch the encoder strip, a thin strip of plastic that stretches across the width of the machine (1). Doing this may cause damage to the machine.

1

If the print head is in the right corner as shown in the illustration (2), you cannot move the print head. Close the scanner cover, and then reconnect the power cord. Open the scanner cover again, and then

hold down until the print head moves to the centre. Then unplug the machine

from the power source and take out the paper.

If the paper is jammed under the print head, unplug the machine from the power source, and then move the print head to take out the paper.

Hold the concave areas with the triangle marks shown in the illustration (3) to move the print head.

2

3

If ink gets on your skin or clothing, immediately wash it off with soap or detergent.

7Gently close the scanner cover using both hands.

Troubleshooting B

39

8Slowly pull the jammed paper (1) out of the machine.

1

If the LCD displays [Repeat Jam A Inside/Front], do the following:

a.Make sure you look carefully inside

(1) for any scraps of paper.

1

b.Squeeze both levers (1), and then open the Jam Clear Cover at the back of the machine.

1

c.Slowly pull the jammed paper out of the machine.

d.Close the Jam Clear Cover. Make sure the cover is closed completely.

9Put the paper tray firmly back in the machine.

10 While holding the paper tray in the machine, pull out the paper support (1) until it locks into place, and then unfold the paper support flap (2).

2

1

11 Reconnect the power cord.

Paper is Jammed in the Front of the Machine (Jam B Front)

If the LCD displays [Jam B Front] or

[Repeat Jam B Front], follow these steps:

1 Unplugsocket. the machine from the electrical

40

2Pull the paper tray (1) completely out of the machine.

1

3Pull the two green levers inside the machine to release the jammed paper.

4 Slowly pull out the jammed paper (1).

1

If the LCD displays [Repeat Jam B Front], do the following:

a.Make sure you look carefully inside

(1) for any scraps of paper.

1

b.Squeeze both levers (1), and then open the Jam Clear Cover at the back of the machine.

1

c.Slowly pull the jammed paper out of the machine.



B

d. Close the Jam Clear Cover. Make

Troubleshooting



sure the cover is closed completely.



41

5Put the paper tray firmly back in the machine.

6While holding the paper tray in the machine, pull out the paper support (1) until it locks into place, and then unfold the paper support flap (2).

2

1

7 Reconnect the power cord.

Paper is Jammed in the Back of the Machine (Jam C Rear)

If the LCD displays [Jam C Rear], follow these steps:

1 Unplugsocket. the machine from the electrical

2Pull the paper tray (1) completely out of the machine.

1

3Pull the two green levers inside the machine to release the jammed paper.

Depending on the paper size, it is easier to remove the jammed paper from the front of the machine rather than from the back of the machine.

4Squeeze both levers (1), and then open the Jam Clear Cover at the back of the machine.

1

5Slowly pull the jammed paper out of the machine.

42

6Close the Jam Clear Cover. Make sure the cover is closed completely.

7Put the paper tray firmly back in the machine.

8While holding the paper tray in the machine, pull out the paper support (1) until it locks into place, and then unfold the paper support flap (2).

2

1

9 Reconnect the power cord.

Troubleshooting B

43

CAppendix

Enter Text on Your Brother Machine

The characters that are available may differ depending on your country.

The keyboard layout may differ depending on the function you are setting.

When you need to enter text on your Brother machine, a keyboard will appear on the Touchscreen.

Press to cycle between letters, numbers and special characters.

Press to cycle between lowercase and uppercase letters.

To move the cursor to the left or right, press d or c.

Inserting spaces

To enter a space, press [Space]. Or, you can press c to move the cursor.

Making corrections

If you entered an incorrect character and want to change it, press d or c to highlight

the incorrect character. Press , and then enter the correct character.

To insert a character, press d or c to move the cursor to the correct place, and then enter the character.

Press for each character you want

to erase, or press and hold to erase all the characters.

Information for compliance with Commission Regulation 801/2013

Power consumption

DCP-J562DW

Networked Standby 1



Approx. 1.3 W

1All network ports activated and connected

How to enable/disable Wireless LAN

To turn on or off the wireless network connection, press [Settings] > [All

Settings] > [Network] > [WLAN Enable] > [On] or [Off].

44

Supply Specifications

Ink

The machine uses individual Black, Yellow, Cyan and Magenta ink



cartridges that are separate from the print head assembly.





Service Life of

The first time you install a set of ink cartridges the machine will use an

Ink Cartridge

amount of ink to fill the ink delivery tubes for high quality printouts. This



process will only happen once. After this process is complete the cartridges



provided with your machine will have a lower yield than regular capacity



cartridges (80%). With all following ink cartridges you can print the specified



number of pages.





Replacement

<Standard Yield Black> LC221BK

Supplies

<Standard Yield Yellow> LC221Y





<Standard Yield Cyan> LC221C



<Standard Yield Magenta> LC221M



Black, Yellow, Cyan and Magenta - Approximately 260 pages 1



<High Yield Black> LC223BK



<High Yield Yellow> LC223Y



<High Yield Cyan> LC223C



<High Yield Magenta> LC223M



Black, Yellow, Cyan and Magenta - Approximately 550 pages 1



For more information about replacement supplies, visit us at



http://www.brother.com/pageyield





What is

Innobella is a range of genuine supplies offered by Brother. The name

Innobella?

"Innobella" derives from the words "Innovation" and "Bella" (meaning



"Beautiful" in Italian) and is a representation of the "innovative" technology



providing you with "beautiful" and "long lasting" print results.



When you print photo images, Brother recommends Innobella glossy photo



paper (BP71 series) for high quality. Brilliant prints are made easier with



Innobella Ink and paper.





1Approx. cartridge yield is declared in accordance with ISO/IEC 24711

If you are using Windows®, double-click the Brother CreativeCenter icon on your desktop

to access our FREE website designed as a resource to help you easily create and print customised materials for business and home use with photos, text and creativity.

Mac users can access Brother CreativeCenter at this web address: http://www.brother.com/creativecenter

Related Information

• Error and Maintenance Messages on page 28

Appendix C

45

DIndex

C



Cleaning



scanner...........................................

23

Control Panel Overview.........................

1

Copy....................................................

17

settings............................................

18

D



Document



how to load................................

17, 21

E



Entering Text........................................

44

Envelope................................................

9

Error messages...................................

28

J



Jams



paper...............................................

38

M



Manual feed slot....................................

9

P



Paper



check paper setting.........................

12

how to load .......................................

7

Photo paper tray....................................

8

PhotoCapture Center...........................

22

Print.....................................................

14

alignment check..............................

24

quality check...................................

23

S



Scan.....................................................

20

Supplies...............................................

45

T



Troubleshooting



error and maintenance messages ..

28

paper jams .....................................

38

print or scan problems ....................

35

W



Wireless LAN report.............................

33

46

Visit us on the World Wide Web

http://www.brother.com

Made from 100% recycled paper (excludes cover)

UK

Version 0
