Page 1
Computerized Embroidery and Sewing Machine
Operation Manual
Product Code 885-V35/V37
GETTING READY
SEWING BASICS
UTILITY STITCHES
EMBROIDERY
APPENDIX
Please visit us at http://solutions.brother.com
where you can get product support and answers to
frequently asked questions (FAQs).
Page 2
Page 3
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Introduction
Thank you for purchasing this embroidery and sewing machine. Before using this machine, carefully read the
"Important Safety Instructions", and then study this manual for the correct operation of the various functions.
In addition, after you have finished reading this manual, store it where it can quickly be accessed for future
reference.
Important Safety Instructions
Please read these safety instructions before attempting to use the machine.
This machine is intended for household use.
DANGER - To reduce the risk of electric shock
1Always unplug the machine from the electrical outlet immediately after using, when cleaning,
when making any user servicing adjustments mentioned in this manual, or if you are leaving the
machine unattended.
WARNING - To reduce the risk of burns, fire, electric shock, or injury to persons.
2Always unplug the machine from the electrical outlet when removing covers, lubricating, or
when making any adjustments mentioned in the instruction manual.
• To unplug the machine, switch the machine to the symbol “O” position to turn it off, then grasp
the plug and pull it out of the electrical outlet. Do not pull on the cord.
• Plug the machine directly into the electrical outlet. Do not use an extension cord.
• Always unplug your machine if the power is cut.
3 Never operate this machine if it has a damaged cord or plug, if it is not working properly, if it has
been dropped or damaged, or water is spilled on the unit. Return the machine to the nearest
authorized dealer or service center for examination, repair, electrical or mechanical adjustment.
• While the machine is stored or in use if you notice anything unusual, such as an odor, heat,
discoloration or deformation, stop using the machine immediately and unplug the power cord.
• When transporting the sewing machine, be sure to carry it by its handle. Lifting the sewing
machine by any other part may damage the machine or result in the machine falling, which could
cause injuries.
• When lifting the sewing machine, be careful not to make any sudden or careless movements,
otherwise you may injure your back or knees.
4 Always keep your work area clear:
• Never operate the machine with any air openings blocked. Keep ventilation openings of the
sewing machine and foot control free from the build up of lint, dust, and loose cloth.
• Do not store objects on the foot controller.
• Do not use extension cords. Plug the machine directly into the electrical outlet.
1
Page 4
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
• Never drop or insert any object into any opening.
• Do not operate where aerosol (spray) products are being used or where oxygen is being
administered.
• Do not use the machine near a heat source, such as a stove or iron; otherwise, the machine,
power cord or garment being sewn may ignite, resulting in fire or an electric shock.
• Do not place this sewing machine on an unstable surface, such as an unsteady or slanted table,
otherwise the sewing machine may fall, resulting in injuries.
5 Special care is required when sewing:
• Always pay close attention to the needle. Do not use bent or damaged needles.
• Keep fingers away from all moving parts. Special care is required around the machine needle.
• Switch the sewing machine to the symbol “O” position to turn it off when making any adjustments
in the needle area.
• Do not use a damaged or incorrect needle plate, as it could cause the needle to break.
• Do not push or pull the fabric when sewing, and follow careful instruction when freehand
stitching so that you do not deflect the needle and cause it to break.
6 This machine is not a toy:
• Your close attention is necessary when the machine is used by or near children.
• The plastic bag that this sewing machine was supplied in should be kept out of the reach of
children or disposed of. Never allow children to play with the bag due to the danger of
suffocation.
• Do not use outdoors.
7 For a longer service life:
• When storing this machine, avoid direct sunlight and high humidity locations. Do not use or store
the machine near a space heater, iron, halogen lamp, or other hot objects.
• Use only neutral soaps or detergents to clean the case. Benzene, thinner, and scouring powders
can damage the case and machine, and should never be used.
• Always consult the operation manual when replacing or installing any assemblies, the presser feet,
needle, or other parts to assure correct installation.
8 For repair or adjustment:
• If the light unit is damaged, it must be replaced by an authorized dealer.
• In the event a malfunction occurs or adjustment is required, first follow the troubleshooting table
in the back of the operation manual to inspect and adjust the machine yourself. If the problem
persists, please consult your local authorized Brother dealer.
Use this machine only for its intended use as described in the manual.
Use accessories recommended by the manufacturer as contained in this manual.
Use only the interface cable (USB cable) included with this machine.
Save these instructions.
The contents of this manual and specifications of this product are subject to change without notice.
For additional product information and updates, visit our web site at www.brother.com
2
Page 5
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
FOR USERS IN THE UK, EIRE, MALTA AND CYPRUS ONLY
IMPORTANT
• In the event of replacing the plug fuse, use a fuse approved by ASTA to BS 1362, i.e. carrying
the mark, rating as marked on plug.
• Always replace the fuse cover. Never use plugs with the fuse cover omitted.
• If the available electrical outlet is not suitable for the plug supplied with this equipment, you should
contact your authorized dealer to obtain the correct lead.
FOR USERS IN AUSTRALIA AND NEW ZEALAND
This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their safety. Children should
be supervised to ensure that they do not play with the appliance.
3
Page 6
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Federal Communications Commission (FCC)
Declaration of Conformity (For USA Only)
Responsible Party: Brother International Corporation
100 Somerset Corporate Boulevard
Bridgewater, NJ 08807-0911 USA
TEL : (908) 704-1700
declares that the product
Product Name: Brother Sewing Machine
Model Number : NV900D
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
• The included interface cable should be used in order to ensure compliance with the limits for a
Class B digital device.
• Changes or modifications not expressly approved by Brother Industries, Ltd. could void the user's
authority to operate the equipment.
4
Page 7
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Contents
Introduction ........................................................................................................................ 1
Important Safety Instructions .............................................................................................. 1
Machine Features ................................................................................................................ 8
Accessories.......................................................................................................................... 9
Included accessories ......................................................................................................................................... 9
Optional accessories ....................................................................................................................................... 10
Names of Machine Parts and Their Functions ................................................................... 11
Front view....................................................................................................................................................... 11
Needle and presser foot section ...................................................................................................................... 12
Right-side/rear view ........................................................................................................................................ 12
Operation buttons ........................................................................................................................................... 13
Operation panel.............................................................................................................................................. 14
GETTING READY 15
Turning the Machine On/Off............................................................................................. 16
Power supply precautions ............................................................................................................................... 16
Turning on the machine .................................................................................................................................. 17
Turning off the machine .................................................................................................................................. 17
LCD (Liquid Crystal Display) Operation ............................................................................ 18
Viewing the LCD............................................................................................................................................. 18
Changing the machine settings........................................................................................................................ 18
Checking machine operating procedures ........................................................................................................ 21
Winding/Installing the Bobbin........................................................................................... 22
Bobbin precautions ......................................................................................................................................... 22
Winding the bobbin ........................................................................................................................................ 22
Installing the bobbin ....................................................................................................................................... 27
Upper Threading ............................................................................................................... 31
About the spool of thread................................................................................................................................ 31
Threading the upper thread ............................................................................................................................. 32
Using the twin needle ..................................................................................................................................... 36
Replacing the Needle ........................................................................................................ 39
Needle precautions ......................................................................................................................................... 39
Selecting the needle depending on the thread and fabric types ...................................................................... 39
Checking the needle ....................................................................................................................................... 40
Replacing the needle....................................................................................................................................... 41
Replacing the Presser Foot ................................................................................................ 43
Presser foot precautions .................................................................................................................................. 43
Replacing the presser foot ............................................................................................................................... 43
Removing and attaching the presser foot holder .............................................................................................. 45
Sewing Cylindrical Pieces and Large Pieces....................................................................... 46
Free-arm sewing.............................................................................................................................................. 46
Using extension table...................................................................................................................................... 46
SEWING BASICS 49
Sewing............................................................................................................................... 50
General sewing procedure .............................................................................................................................. 50
Stitch types...................................................................................................................................................... 51
Selecting stitching ........................................................................................................................................... 51
Positioning the fabric ...................................................................................................................................... 54
Starting to sew................................................................................................................................................. 55
Securing the stitching ...................................................................................................................................... 57
Cutting the thread ........................................................................................................................................... 59
Setting the Stitch ............................................................................................................... 61
Adjusting the stitch width................................................................................................................................ 61
Adjusting the stitch length ............................................................................................................................... 62
Adjusting the thread tension............................................................................................................................ 62
5
Page 8
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Useful Functions................................................................................................................ 64
Automatic sewing reverse/reinforcement stitches ............................................................................................ 64
Automatically cutting the thread ..................................................................................................................... 65
Mirroring stitches ............................................................................................................................................ 66
Saving stitch settings ....................................................................................................................................... 67
Useful Sewing Tips ............................................................................................................ 68
Trial sewing .................................................................................................................................................... 68
Changing the sewing direction ........................................................................................................................ 68
Sewing curves ................................................................................................................................................. 68
Sewing thick fabrics ........................................................................................................................................ 68
Sewing hook-and-loop fastener ....................................................................................................................... 69
Sewing thin fabrics.......................................................................................................................................... 69
Sewing stretch fabrics...................................................................................................................................... 70
Sewing an even seam allowance..................................................................................................................... 70
UTILITY STITCHES 71
Stitch Setting Chart ........................................................................................................... 72
Utility stitches ................................................................................................................................................. 72
Other stitches.................................................................................................................................................. 76
Overcasting Stitches .......................................................................................................... 78
Sewing overcasting stitches using overcasting foot "G" .................................................................................... 78
Sewing overcasting stitches using zigzag foot "J" ............................................................................................. 79
Sewing overcasting stitches using the optional side cutter ............................................................................... 80
Basic Stitching ................................................................................................................... 82
Basting ............................................................................................................................................................ 82
Basic stitching ................................................................................................................................................. 82
Blind Hem Stitching .......................................................................................................... 84
Buttonhole Stitching/Button Sewing.................................................................................. 87
Buttonhole sewing .......................................................................................................................................... 88
Button sewing ................................................................................................................................................. 92
Zipper Insertion................................................................................................................. 94
Inserting a centered zipper .............................................................................................................................. 94
Inserting a side zipper ..................................................................................................................................... 96
Sewing Stretch Fabrics and Elastic Tape ............................................................................ 99
Stretch stitching............................................................................................................................................... 99
Elastic attaching ............................................................................................................................................ 100
Appliqué, Patchwork and Quilt Stitching ........................................................................ 101
Appliqué stitching ......................................................................................................................................... 102
Patchwork (crazy quilt) stitching ................................................................................................................... 103
Piecing.......................................................................................................................................................... 103
Quilting ........................................................................................................................................................ 104
Free-motion quilting...................................................................................................................................... 106
Satin stitching using the sewing speed controller........................................................................................... 107
Reinforcement Stitching .................................................................................................. 108
Triple stretch stitching ................................................................................................................................... 108
Bar tack stitching........................................................................................................................................... 108
Darning......................................................................................................................................................... 111
Eyelet Stitching................................................................................................................ 113
Decorative Stitching ........................................................................................................ 114
Fagoting ........................................................................................................................................................ 115
Scallop stitching............................................................................................................................................ 116
Smocking ...................................................................................................................................................... 117
Shell tuck stitching ........................................................................................................................................ 118
Joining .......................................................................................................................................................... 119
Heirloom stitching ........................................................................................................................................ 119
Sewing the Various Built-in Decorative Patterns ............................................................. 122
Sewing beautiful patterns .............................................................................................................................. 122
Sewing patterns............................................................................................................................................. 122
Changing the stitch density ........................................................................................................................... 123
Changing the pattern size.............................................................................................................................. 123
Changing the length for satin stitches ............................................................................................................ 124
6
Page 9
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Adjusting the character spacing..................................................................................................................... 124
Realigning the pattern ................................................................................................................................... 125
Combining patterns....................................................................................................................................... 126
Saving patterns.............................................................................................................................................. 129
Designing a Pattern (My Custom Stitch).......................................................................... 131
Drawing a sketch of the pattern..................................................................................................................... 131
Entering the pattern data ............................................................................................................................... 132
Editing the pattern data ................................................................................................................................. 133
Examples of designs ...................................................................................................................................... 134
EMBROIDERY 135
Embroidering Neatly ....................................................................................................... 136
What to prepare ............................................................................................................................................ 136
Embroidery step by step ................................................................................................................................ 137
Attaching the Embroidery Foot....................................................................................... 138
Attaching the embroidery foot...................................................................................................................... 138
Removing the embroidery foot ..................................................................................................................... 140
Attaching the Embroidery Unit........................................................................................ 141
Embroidery unit precautions ......................................................................................................................... 141
Attaching the embroidery unit....................................................................................................................... 141
Removing the embroidery unit ...................................................................................................................... 143
Preparing the Fabric ........................................................................................................ 144
Attaching a stabilizer material to the fabric ................................................................................................... 144
Setting the fabric in the embroidery frame..................................................................................................... 145
Attaching the Embroidery Frame..................................................................................... 148
Attaching the embroidery frame .................................................................................................................... 148
Removing the embroidery frame ................................................................................................................... 149
Selecting Embroidery Patterns......................................................................................... 150
Copyright information ................................................................................................................................... 150
Embroidery pattern types............................................................................................................................... 150
LCD (liquid crystal display) operation ........................................................................................................... 151
Selecting alphanumeric characters ................................................................................................................ 154
Selecting an embroidery pattern.................................................................................................................... 155
Selecting a frame pattern............................................................................................................................... 155
Using an embroidery card............................................................................................................................. 156
Embroidering................................................................................................................... 157
Embroidering a pattern.................................................................................................................................. 157
Appliquéing ................................................................................................................................................. 159
Editing and Saving Patterns ............................................................................................. 161
Adjusting the layout and the size................................................................................................................... 161
Adjusting the thread tension.......................................................................................................................... 163
Connecting character patterns....................................................................................................................... 164
Resewing ...................................................................................................................................................... 165
Thread runs out partway through a design..................................................................................................... 166
Stopping while embroidering ........................................................................................................................ 166
Using the Memory Function ............................................................................................ 168
Embroidery data precautions......................................................................................................................... 168
Saving patterns.............................................................................................................................................. 169
Retrieving embroidery patterns from the computer........................................................................................ 170
APPENDIX 173
Care and Maintenance .................................................................................................... 174
Cleaning the machine surface ....................................................................................................................... 174
Cleaning the race .......................................................................................................................................... 174
Troubleshooting .............................................................................................................. 176
Error messages .............................................................................................................................................. 181
Adjusting the LCD......................................................................................................................................... 185
Operation beep............................................................................................................................................. 185
Upgrading Your Machine's Software ............................................................................... 186
Index ............................................................................................................................... 187
7
Page 10
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Machine Features
a Automatic thread cutting
The thread can be cut automatically after sewing (page 59, 65).
b Fast bobbin winding system
With the fast and simple bobbin winder, you can wind bobbins with one press of a button (page 22).
c Built-in stitches
You can select from the built-in stitches available, including utility stitches and decorative stitches (page 72).
d USB port
Various embroidery patterns on the website or saved in your PC become available by using the USB cable (page 170).
e Accessory case
You can store the accessory case inside the arm of the machine as shown in the figure.
ripper, etc. can be stored in this case.
f Bobbin clip
You can use the bobbin clip to prevent the end of the thread wound onto the bobbin from loosening. Bobbin clips can be
stored inside of the accessory case cover.
g Bright light
The convenient LED lamp makes it easy to work on dark fabrics.
h Seven-point feed dogs
Ensure smooth, even feeding of multiple fabric layers and a variety of fabric weights (page 12).
i Quick-set bobbin
You can start sewing without pulling up the bobbin thread (page 27).
j Easy-to-use needle threader
You can thread the needle easily by one press of a lever (page 32).
k Lighting Start/Stop button
When the green light is on, the machine is ready to sew. A red or orange light indicates an error or that the machine is
warming up (page 13).
l Embroidery
You can embroider built-in embroidery patterns, alphanumeric characters, framed decorations, and designs from optional
embroidery cards (page 135).
m Extension table (Cover of the embroidery unit)
You can use the cover of the embroidery unit as the extension table when you sew a large material (page 46).
Presser foot, bobbins, a seam
8
Page 11
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Accessories
After opening the box, check that the following accessories are included. If any item is missing or
damaged, contact your dealer.
Included accessories
Note
z Foot controller: Model T
This foot controller can be used on the machine with product code 885-V35/V37.The product code is
mentioned on the machine rating plate.
z The securing screw on the side of the presser foot holder is available through your authorized dealer.
(Part code: 132730-122)
*
12.3.4.5.6.7.8.9.
10.
1
11. 12. 13. 14. 15. 16. 17. 18.
20. 21. 22. 23.
24.
25. 26. 27.
19
.
28. 29. 30. 31. 32. 33. 34.
*
1 75/11 2 needles, 90/14 2 needles , 90/14 2 needles: Ball point needle (gold colored)
No. Part Name
1 Buttonhole foot "A" XC2691-023 18 Spool cap (small) 130013-124
2 Overcasting foot "G" XC3098-031 19 Extra spool pin XE2241-001
3 Monogramming foot "N" XD0810-031 20 Spool net XA5523-020
4 Zipper foot "I" X59370-021 21 Foot controller
5 Zigzag foot "J" (on machine) XC3021-031 22 Scissors XC1807-121
6 Blind stitch foot "R" XC4051-031 23 Disc-shaped screwdriver XC1074-051
7 Button fitting foot "M" XE2137-001 24 Embroidery foot "Q" XD0474-051
8 Seam ripper X54243-051 25
Bobbin (4)
9
Bobbin clip (4) XE3060-001 27 Accessory case XE3062-003
10 Needle set X58358-021 28 Hard case XE3862-001
11 Twin needle X59296-121 29 USB cable XD0745-051
12 Cleaning brush X59476-021 30 Operation manual XE3848-001
13 Eyelet punch 135793-001 31 Quick reference guide XE3849-001
14 Screwdriver XC4237-021 32 Grid sheet set
15 Touch pen XE3069-001 33 Language setting sheet XE4199-001
16 Spool cap (large) 130012-024 34 Felt with stabilizer 182986-024
Spool cap (medium) (on
17
machine)
Part Code
U.S.A. / Canada
SA156
XE1372-001
Others
SFB:
XA5539151
No. Part Name
Embroidery set (medium)
H 10 cm X W 10 cm
(H 4 inches X W 4 inches)
Embroidery bobbin thread
26
(white)
U.S.A. / Canada
Part Code
XD0501-021(EU area)
XC8816-021(other areas)
SA432
SAEBT
SA527
EF62:
XA6628-102
EBT-CEN:
X81164-001
GS4: XC4549051
Others
9
Page 12
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Optional accessories
The following are available as optional accessories.
1. 2. 3.
4. 5.
6. 7. 8.
9.
No. Part Name
Embroidery bobbin
1
thread (black)
2 Embroidery card
Embroidery set (small)
×
3
H 2 cm
(H 1 inch × W 2-1/2 inches)
Embroidery set (large)
H 17 cm × W 10 cm
4
(H 6-7/10 inches × W 4
inches)
Water soluble stabilizer SA520
5
Stabilizer material for
embroidery
6 Walking foot SA140
7 Open toe quilting foot SA187
8 Side cutter "S" SA177
9 Quilting guide SA132
W 6 cm
Part Code
U.S.A. / Canada
SAEBT999
SA431
SA434
SA519
Memo
z To obtain optional accessories or parts, contact your sales representative, the nearest authorized service
center or visit the website at [http://www.brother.com/].
z
All specifications are correct at the time of printing. The part codes are subject to change without notice.
z Visit your nearest authorized dealer for a complete listing of optional accessories available for your
machine.
Others
EBT-CEBN:
XC5520-001
EF61:
XA6630-102
EF71:
XC2026-102
BM5:
XE0615-001
BM3:
X81175-101
F033N:
XC2214-002
F061:
XE1097-001
F054:
XC3879-002
F016N:
XC2215-002
10
Page 13
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Names of Machine Parts and Their Functions
The names of the various parts of the sewing machine and their functions are described below. Before using the
sewing machine, carefully read these descriptions to learn the names of the machine parts.
Front view
a Thread guide cover (page 24, 33)
Pass the thread under this thread guide cover when
winding the bobbin thread and threading the machine.
b Thread guide (page 24, 33)
Pass the thread under this thread guide when winding
the bobbin thread and threading the machine.
c Spool pin (page 23, 32)
Place a spool of thread on the spool pin.
d Bobbin winder (page 22)
Use the bobbin winder when winding the bobbin.
e LCD (liquid crystal display) (touch panel) (page 18)
Setting for the selected stitch or pattern and error
messages appear in the LCD.
f Operation panel (page 14)
Use the keys on this panel to select stitches or
embroidery patterns, or check how to use the sewing
machine, etc.
g Embroidery unit connector slot (page 141)
Plug in the connector for the embroidery unit.
h Presser foot lever (page 54)
Raise and lower the presser foot lever to raise and lower
the presser foot .
i Operation buttons (page 13)
Use these buttons to operate the machine.
j Flat bed attachment (page 46)
Remove the flat bed attachment when sewing
cylindrical pieces such as sleeve cuffs.
k Thread cutter (page 60)
Pass the threads through the thread cutter to cut them.
l Needle threader lever (page 35)
Use the needle threader lever to thread the needle.
m Thread tension dial (page 62, 163)
Adjust the upper thread tension with this dial.
n Thread take-up lever (page 34)
o Bobbin-winding thread guide and pretension disc
(page 24)
Pass the thread under this thread guide and around the
pretension disc when winding the bobbin thread.
11
Page 14
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Needle and presser foot
section
a Buttonhole lever (page 90)
Lower the buttonhole lever when sewing buttonholes
and bar tacks.
b Thread guide disk (page 34)
Pass the thread through the thread guide disk when
using the needle threader to thread the needle.
c Needle bar thread guide (page 34)
Pass the upper thread through the needle bar thread
guide.
d Needle plate (page 70)
The needle plate is marked with guides for sewing
straight seams.
e Needle plate cover (page 174)
Remove the needle plate cover to clean the bobbin case
and race.
f Bobbin cover/bobbin case (page 28)
Remove the bobbin cover, and then insert the bobbin
into the bobbin case.
g Feed dogs (page 92)
The feed dogs feed the fabric in the sewing direction.
h Presser foot (page 43, 54)
The presser foot applies pressure consistently on the
fabric as the sewing takes place. Attach the appropriate
presser foot for the selected stitching.
i Presser foot holder (page 45)
The presser foot is installed onto the presser foot holder.
Right-side/rear view
a Handle
Carry the sewing machine by its handle when
transporting the machine.
b Handwheel (page 54)
Turn the handwheel toward you (counterclockwise) to
raise and lower the needle to sew one stitch.
c Embroidery card slot (page 156)
Insert the embroidery card.
d USB port (page 170)
Connect the one end of the USB cable to this port and
the other to the computer.
e Air vent
The air vent allows the air surrounding the motor to be
exchanged. Do not cover the air vent while the sewing
machine is being used.
f Main power switch (page 17)
Use the main power switch to turn the sewing machine
on and off.
g Foot controller jack (page 56)
Insert the plug on the end of the foot controller cable
into the foot controller jack.
h Power supply jack (page 17)
Insert the plug on the power supply cord into the power
supply jack.
i Drop feed lever (page 92)
Use the drop feed lever to lower the feed dogs.
12
Memo
z Refer to pages 11 through 14 while you are
learning to use your machine.
Page 15
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Operation buttons
The operation buttons help you to easily perform various basic sewing machine operations.
a Start/stop button
Press the start/stop button to start or stop sewing. The
machine sews at a slow speed at the beginning of
sewing while the button is pressed. When sewing is
stopped, the needle is lowered in the fabric. For details,
refer to "Starting to sew" (page 55).
The button changes color according to the machine’s
operation mode.
Green: The machine is ready to sew or is
Red: The machine can not sew.
Orange: The machine is winding the bobbin
sewing.
thread, or the bobbin winder shaft is
moved to the right side.
Memo
z When the foot controller is plugged in,
(Start/stop button) cannot be used to
start sewing.
b Needle position button
Press the needle position button to raise or lower the
needle. Be sure to raise the needle before threading the
needle. Use this button to change the sewing direction
or for detailed sewing in small areas. Pressing the
button twice sews one stitch.
c Reverse/reinforcement stitch button
Press the reverse/reinforcement stitch button to sew
reverse stitches or reinforcement stitches. Reverse
stitches are sewn by keeping the button pressed down to
sew in the opposite direction. Reinforcement stitches
are sewn by sewing 3 to 5 stitches on top of each other.
For details, refer to "Securing the stitching" (page 57).
CAUTION
● Do not press the thread cutter button
after the threads have already been cut,
otherwise the needle may break, the
threads may become tangled or damage
to the machine may occur.
Note
z Do not press the thread cutter button if there
is no fabric under the presser foot or while
the machine is sewing, otherwise damage to
the machine may occur.
z When cutting nylon thread or other special
threads, use the thread cutter on the side of
the machine. For details, refer to "Using the
thread cutter" (page 60).
e Sewing speed controller
Slide the sewing speed controller to adjust the sewing
speed.
d Thread cutter button
Press the thread cutter button after sewing is stopped to
cut both the upper thread and the bobbin threads. For
details, refer to "Cutting the thread" (page 59).
13
Page 16
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Operation panel
The front operation panel has an LCD (liquid crystal display) and operation keys.
a LCD (liquid crystal display) (touch panel)
Setting for the selected stitch or pattern and error
messages appear in the LCD.
Touch the keys displayed on the LCD with your finger
or the touch pen to perform operations.
For details, refer to "LCD (Liquid Crystal Display)
Operation" (page 18).
b Back key
Press to return to the previous screen.
c Previous page key
Displays the previous page when there are items that
are not displayed on the LCD.
d Next page key
Displays the next page when there are items that are not
displayed on the LCD.
e Memory key
Press to save character embroidery, combined stitch
patterns, My Custom Stitch patterns, etc. in the sewing
machine’s memory.
f Utility stitch key
Press this key to select a utility stitch or decorative stitch
or to design a stitch pattern using the My Custom Stitch
function.
g Embroidery key
Press this key to sew embroidery.
h Settings key
Press to set the needle stop position, the buzzer sound,
and more.
i Sewing machine help key
Press to get help on using the sewing machine. Displays
simple explanations of setting upper thread / bobbin
winding / setting bobbin thread / needle replacement /
embroidery unit attachment / embroidery frame
attachment / embroidery foot attachment / presser foot
replacement.
14
Page 17
1 GETTING READY
The various preparations required before starting to sew are described in this chapter.
Turning the Machine On/Off ..................................................................................16
LCD (Liquid Crystal Display) Operation..................................................................18
Winding/Installing the Bobbin.................................................................................22
Upper Threading .....................................................................................................31
Replacing the Needle ..............................................................................................39
Replacing the Presser Foot ......................................................................................43
Sewing Cylindrical Pieces and Large Pieces............................................................. 46
Page 18
GETTING READY — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Turning the Machine On/Off
This section explains how to turn the sewing machine on and off.
Power supply precautions
Be sure to observe the following precautions concerning the power supply.
WARNING
● Use only regular household electricity for the power source. Using other power sources may
result in fire, electric shock, or damage to the machine.
● Make sure that the plugs on the power cord are firmly inserted into the electrical outlet and
the power supply jack on the machine.
● Do not insert the plug on the power cord into an electrical outlet that is in poor condition.
● Turn off the main power and remove the plug in the following circumstances:
• When you are away from the machine
• After using the machine
• When the power fails during use
• When the machine does not operate correctly due to a bad connection or a disconnection
• During electrical storms
CAUTION
● Use only the power cord included with this machine.
● Do not use extension cords or multi-plug adapters with many other appliances plugged in to
them. Fire or electric shock may result.
● Do not touch the plug with wet hands. Electric shock may result.
● When unplugging the machine, always turn off the main power first. Always grasp the plug to
remove it from the outlet. Pulling on the cord may damage the cord, or lead to fire or electric
shock.
● Do not allow the power cord to be cut, damaged, modified, forcefully bent, pulled, twisted,
or bundled. Do not place heavy objects on the cord. Do not subject the cord to heat. These
things may damage the cord and cause fire or electric shock. If the cord or plug is damaged,
take the machine to your authorized dealer for repairs before continuing use.
● Unplug the power cord if the machine is not to be used for a long period of time. Otherwise a
fire may result.
16
Page 19
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Turning on the machine
Prepare the included power cord.
Make sure that the sewing machine is turned
a
off (the main power switch is set to " "), and
then plug the power supply cord into the
power supply jack on the right side of the
machine.
Insert the plug of the power supply cord into a
b
household electrical outlet.
1
a Power supply jack
Press the right side of the main power switch
c
on the right side of the machine to turn the
machine on (set it to "|").
X The light, LCD and (Start/stop button)
light up when the machine is turned on.
Memo
z When the machine is turned on, the needle
and the feed dogs will make sound when
they move; this is not a malfunction.
Turning off the machine
When you have finished using the sewing machine,
turn it off. In addition, before transporting the sewing
machine to another location, be sure to turn it off.
Make sure that the machine is not sewing.
a
Press the left side of the main power switch on
b
the right side of the machine to turn the
machine off (set it to " ").
X The light, LCD and (Start/stop button) go
off when the machine is turned off.
Unplug the power supply cord from the
c
electrical outlet.
Grasp the plug when unplugging the power
supply cord.
Unplug the power cord from the power supply
d
jack.
Note
z If a power outage occurs while the sewing
machine is being operated, turn off the
sewing machine and unplug the power
supply cord. When restarting the sewing
machine, follow the necessary procedure to
correctly operate the machine.
(For U.S.A. only)
z This appliance has a polarized plug (one
blade wider than the other). To reduce the
risk of electrical shock, this plug is intended
to fit in a polarized outlet only one way. If
the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit, contact
a qualified electrician to install the proper
outlet. Do not modify the plug in any way.
1
Turning the Machine On/Off 17
Page 20
GETTING READY — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
LCD (Liquid Crystal Display) Operation
Selected stitch, pattern settings and messages are displayed on the LCD (liquid crystal display) on the front
of the sewing machine. Change the screen on the LCD using the keys on the right side of the LCD, and
make operations by directly touching the icons with your finger or a
"Operation panel" (page 14).
Viewing the LCD
When the power is turned on, the LCD comes on. When you touch the LCD screen according to the message
displayed on the screen with your finger or a touch pen, the following utility stitch selection screen is displayed.
touch pen. For details, refer to
1
2
3
4
5
a Selected stitch
b Presser foot to be used
c Stitches
d Stitch settings and twin needle sewing
e Stitch width
f Stitch length
g Number of the selected stitch
h Number of stitches contained
i Horizontal mirror image
j Automatic thread cutting
k Automatic reverse/reinforcement
l Single/twin needle sewing and needle stop
position
l
k
0
9
8
7
6
Memo
z Press (Utility stitch key) to display the screen for selecting the stitch type. The details are
explained in "Stitch types" (page 51).
z A different screen is displayed when the embroidery unit is attached. The details are explained in
"Selecting an embroidery pattern" (page 155).
z Refer to "Error messages" (page 181) for messages displayed on the LCD.
z Depending on the model of sewing machine, an animation may be displayed when the power is turned
on. When an animation is displayed, the screen above will be displayed if you touch the LCD with
your finger.
Changing the machine settings
Various sewing machine operations and sewing settings can be changed.
The stitch or machine attributes that can be set are listed below. For details on operation, refer to page 20.
Attribute Icon Details Settings
Needle position
Stitch width
control
Vertical pattern
adjustment
18
Specifies where the needle is positioned when
the sewing machine is stopped.
Allows the stitch width to be adjusted with the
sewing speed controller (page 107).
Adjusts the up and down position of the pattern
(page 125 ).
Down Up
-9 to +9
Page 21
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Attribute Icon Details Settings
Character
spacing
Thread color
display
Display unit
Buzzer
Opening screen
Initial needle
position
Adjusts the space between characters when
sewing alphanumeric characters. (page 124)
Changes the thread color display on the
embroidery screen (page 151).
(When "Thread No.#123" is selected)
Selects the measurement units that are
displayed (only for embroidering) (page 152).
Specifies whether or not a beep is sounded with
each operation (page 185).
Sets whether or not to display the opening
screen when the power is turned on.
(There are models where this cannot be
changed.)
Selects whether "
3
Straight stitch (middle)" that is
"
automatically selected when the machine is
turned on.
1
Straight stitch (left)" or
0 to 10
Thread color/Time to
embroider/Needle count/
Thread number (#123)
Embroidery/Country/Madeira
poly/Madeira rayon/Sulky/
Robison Anton
mm/INCH
1
English/German/French/
Language
LCD brightness Adjust the brightness of the LCD (page 185).
Stitch counter
Product number NO.:
Program version Version: Displays the program version. -
Allows the language used in the screens to be
changed.
Displays the service count and the total number
of embroidery stitches. The service count is a
reminder to take your machine in for regular
servicing. (Contact your authorized dealer for
details.)
The "NO." is the number for the embroidery and
sewing machine.
Italian/Dutch/Spanish/
Japanese/Danish/Norwegian/
Finnish/Swedish/Portuguese/
Russian/Korean/Thai/others
Lighter Darker
Memo
z The item shown in reverse highlighting are the settings at the time of purchase.
-
-
LCD (Liquid Crystal Display) Operation 19
Page 22
GETTING READY — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Turn on the sewing machine.
The highlighted display is the initi al setting.
a
X The LCD comes on.
Example: Changing the needle stop position
Press (Settings key) on the display
b
panel.
X The setting screen appears.
Press the item to be set.
c
Switch the screen using (Previous page
key) and (Next page key).
• The following screens show their default
settings.
When settings are complete, press
d
(Back key).
X The initial stitch screen appears again.
Memo
z "NO." is the individual number for the
sewing machine.
z "VERSION" is the program version which is
installed in the sewing machine.
z Settings that are changed are saved even if
the power is turned off.
20
Page 23
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Press (Next page key) to switch to the
d
Checking machine operating
procedures
Simple explanations can be referred on the LCD
display for the following items.
Displays simple explanations of setting upper thread /
bobbin winding / setting bobbin thread / needle
replacement / embroidery unit attachment /
embroidery frame attachment / embroidery foot
attachment / presser foot replacement on the LCD.
Turn on the sewing machine.
a
X The LCD comes on.
Press (Sewing machine help key) on
b
the display panel.
next page.
If you press (Previous page key), you
return to the previous page.
Press (Back key) to return to the item
selection screen.
Example: Upper threading
1
X The sewing machine help screen appears.
Press the item to be displayed.
c
a Upper threading
b Bobbin winding
c Bobbin installation
d Needle replacement
e Presser foot replacement
f Embroidery foot attachment
g Embroidery frame attachment
h Embroidery unit attachment
X The first screen describing the procedure for
the selected topic appears.
a
h
bc
g
f
d
e
After you finish viewing, press (Back
e
key) two times.
X The initial stitch screen appears again.
Memo
z For details on each topic, refer to the
corresponding page in this Operation
Manual.
LCD (Liquid Crystal Display) Operation 21
Page 24
GETTING READY — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Winding/Installing the Bobbin
This section describes how to wind the thread onto the bobbin, and then insert the bobbin thread.
Bobbin precautions
Be sure to observe the following precautions concerning the bobbin.
CAUTION
● Only use the Bobbin (part code: SA156, SFB (XA5539-151)) designed specifically for this
sewing machine. Use of any other bobbin may result in injuries or damage to the machine.
● The included bobbin was designed specifically for this sewing machine. If bobbins from other
models are used, the machine will not operate correctly. Use only the included bobbin or
bobbins of the same type (part code: SA156, SFB (XA5539-151)).
Actual size
11.5 mm
(7/16 inch)
This model
Other model
Winding the bobbin
Wind the thread around the bobbin to prepare the bobbin thread.
a
a Bobbin-winding thread guide
b Bobbin winder shaft
c Bobbin
b
c
22
Page 25
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Turn on the sewing machine.
a
Place the bobbin on the bobbin winder shaft so
b
that the spring on the shaft fits into the notch
in the bobbin.
Press down on the bobbin until it snaps into
place.
a
b
a Notch
b Bobbin winder shaft spring
Slide the bobbin winder in the direction of the
c
arrow until it snaps into place.
Place the spool of thread for the bobbin onto
e
the spool pin.
Slide the spool onto the pin so that the spool is
horizontal and the thread unwinds to the front
at the bottom.
Memo
z For embroidering, use the embroidery
bobbin thread.
Note
z If the spool is not positioned so that the
thread unwinds correctly, the thread may
become tangled around the spool pin.
Slide the spool cap onto the spool pin and
f
return the spool pin to its original position.
Slide the spool cap as far as possible to the right
as shown, with the rounded side on the left.
1
X (Start/stop button) lights up in orange.
Pick up the spool pin and remove the spool
d
cap that is inserted onto the spool pin.
a
a Spool cap
b Spool pin
b
CAUTION
● If the spool or the spool cap is not
positioned correctly, the thread may
become tangled around the spool pin or
the machine may be damaged.
● Three spool cap sizes are available,
allowing you to choose a spool cap that
best fits the size of spool being used. If the
spool cap is too small for the spool being
used, the thread may catch on the slit in
the spool or the machine may be
damaged.
●
Winding/Installing the Bobbin 23
Page 26
GETTING READY — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Pass the thread behind the thread guide cover
Note
z When sewing with fine, cross-wound thread,
use the small spool cap, and leave a small
space between the cap and the spool.
h
and to the front.
While holding the thread near the spool with
your right hand, pull the thread with your left
hand as shown below.
c
b
a
a Spool cap (small)
b Spool (cross-wound thread)
c Space
z When using thread that winds off quickly,
such as transparent nylon thread or metallic
thread, place the spool net over the spool
before placing the spool of thread onto the
spool pin. If the spool net is too long, fold it
to fit the size of the spool.
When the spool net is used, the upper thread
tension may become tighter. Before sewing,
refer to "Adjusting the thread tension" (page
62).
a
b
a
a Thread guide cover
Pull the thread to the right, pass it under the
i
hook of the bobbin-winding thread guide, and
then wind the thread counterclockwise under
the pretension disc, pulling it in as far as
possible.
c
d
a Spool net
b Spool
c Spool cap
d Spool pin
Pull the thread from the spool and pass the
g
thread under the hook of thread guide.
a
a Thread guide
24
a
a Bobbin-winding thread guide
Make sure that the thread passes under the
pretension disk.
b
c
b Hook
c Pretension disk
d Pull it in as far as possible.
d
Page 27
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Wind the end of the thread clockwise around
j
the bobbin five or six times.
While using your left hand to hold the thread
that was passed through the bobbin-winding
thread guide, use your right hand to wind the
end of the thread.
Wind five or six times.
CAUTION
● Be sure to pull the thread tightly and
wind it clockwise. If the thread is
wound counterclockwise, the thread
may wind around the bobbin winder
shaft.
Pass the end of the thread through the guide
k
slit in the bobbin winder seat, and then pull
the thread to the right to cut it.
Slide the sewing speed controller to the right.
l
a
a Speed controller
Press (Start/stop button) once.
m
When the foot controller is plugged in, press
down on the foot controller.
a
a Start/stop button
X The bobbin starts winding and "Winding
bobbin thread..." is displayed on the LCD
screen.
1
a
a Guide slit in bobbin winder seat
(with built-in cutter)
CAUTION
● Be sure to cut the thread as described. If
the bobbin is wound without cutting the
thread using the cutter built into the slit
in the bobbin winder seat, the thread may
become tangled in the bobbin or the
needle may bend or break when the
bobbin thread starts to run out.
Memo
z Make sure that the thread is correctly set
before starting the bobbin winding.
Otherwise the thread may become tangled
and fail to wind the thread.
Note
z Do not get away from the machine while
winding the bobbin. Make sure the bobbin
thread is being wound correctly. If the
bobbin thread is wound incorrectly, press
(Start/stop button) or operate the foot
controller immediately to stop the bobbin
winding.
When the bobbin winding stops or becomes
n
slow, press (Start/stop button) once to
stop the machine.
When the foot controller is plugged in, remove
your foot from the foot controller.
X The bobbin winding will stop.
CAUTION
● When the bobbin winding stops or
becomes slow, stop the machine.
Otherwise, the sewing machine may be
damaged.
Winding/Installing the Bobbin 25
Page 28
GETTING READY — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Cut the thread with scissors, slide the bobbin
o
winder shaft to the left, and then remove the
bobbin from the shaft.
Memo
z If the bobbin winder shaft is set to the right
side, the needle will not move. (Sewing is
impossible.)
Slide the sewing speed controller back to its
p
original position.
■ When the thread became tangled under the
bobbin winder seat.
If the bobbin winding starts when the thread is not
passed under the pretension disk of the bobbinwinding thread guide correctly, the thread may
become tangled under the bobbin winder seat.
In such a case, wind off the thread according to the
following procedure.
b
a
a Thread
b Bobbin winder seat
CAUTION
● Do not remove the bobbin winder seat
even if the thread become tangled under
the bobbin winder seat. It may result in
injuries.
● Do not remove the screw of the bobbin
winder presser, otherwise the machine
may be damaged; you cannot wind off the
thread by removing the screw.
Memo
z When the sewing machine is started or the
handwheel is turned after winding the
bobbin, the machine will make a clicking
sound; this is not a malfunction.
a Screw of the bobbin winder presser
If the thread become tangled under the bobbin
a
winder seat, press (Start/stop button) once
to stop the bobbin winding.
When the foot controller is plugged in, remove
your foot from the foot controller.
a
a Start/stop button
a
26
Page 29
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Cut the thread with scissors beside the bobbin-
b
winding thread guide.
a
Installing the bobbin
Install the bobbin wound with thread.
CAUTION
● Use a bobbin that has been correctly
wound with thread, otherwise the needle
may break or the thread tension will be
incorrect.
a Bobbin-winding thread guide
Slide the bobbin winder shaft to the left, and
c
then remove the bobbin from the shaft.
● The included bobbin was designed
specifically for this sewing machine. If
bobbins from other models are used, the
machine will not operate correctly. Use
only the included bobbin or bobbins of
the same type (part code: SA156, SFB
(XA5539-151)).
1
Hold the thread end with your left hand, and
d
wind off the thread clockwise near the bobbin
with your right hand as shown below.
Wind the bobbin again.
e
Note
z Make sure that the thread passes under the
pretension disk of the bobbin-winding
thread guide correctly (page 24).
Actual size
11.5 mm
(7/16 inch)
This model
Other model
Memo
z The order that the bobbin thread should be
passed through the bobbin case is indicated
by marks that surround the bobbin case.
Winding/Installing the Bobbin 27
Page 30
GETTING READY — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Press (Needle position button) once or
a
twice to raise the needle, and then raise the
presser foot lever.
a
b
a Needle position button
b Presser foot lever
Turn off the sewing machine.
b
Slide the bobbin cover latch to the right.
c
a
b
Insert the bobbin into the bobbin case with
f
your right hand.
• Be sure to insert the bobbin correctly.
CAUTION
● Be sure to insert the bobbin and depress it
to the bottom with your finger.
Otherwise, the thread may break or the
thread tension will be incorrect.
● Be sure to thread the machine as
indicated. Otherwise, the thread may
break or the thread tension will be
incorrect.
Lightly hold down the bobbin with your right
g
hand, and then guide the thread as shown with
your left hand.
a Bobbin cover
b Latch
X The bobbin cover opens.
Remove the bobbin cover.
d
Hold the bobbin with your right hand and hold
e
the end of the thread with your left hand.
• Be careful not to drop the bobbin.
28
Pass the thread through the slot as shown, and
h
then pull the thread out toward the front.
a
a Cutter
X The cutter cuts the thread.
Page 31
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
■ When pulling up the bobbin thread may be
Note
z If the thread is not correctly inserted through
the tension-adjusting spring of the bobbin
case, it may cause incorrect thread tension
(page 62).
a
a Tension-adjusting spring
necessary
When making gathers or before free-motion quilting,
first pull up the bobbin thread as described below.
Thread the upper thread.
a
• Refer to "Upper Threading" (page 31).
Insert the bobbin into the bobbin case.
b
• Refer to steps
bobbin" (page 28).
Pass the bobbin thread through the slot.
c
c through f of "Installing the
1
Reattach the bobbin cover.
i
Insert the tab in the lower-left corner of the
bobbin cover, and then lightly press down on
the right side.
a
1
a Tab
b Lower-left corner
X The bobbin threading is finished. You can
begin sewing without pulling up the bobbin
thread.
Next, thread the upper thread. Continue with
the procedure in "Upper Threading" (page 31).
b
Memo
z When making gathers or before free-motion
quilting, pull up the bobbin thread by
following the procedure in "When pulling up
the bobbin thread may be necessary".
2
Note
z Do not cut the thread with the cutter.
z Remove the bobbin cover.
While lightly holding the upper thread with
d
your left hand, press (Needle position
button) once or twice to raise the needle.
a
a Needle position button
X The bobbin thread is looped around the
upper thread and can be pulled up.
Winding/Installing the Bobbin 29
Page 32
GETTING READY — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Carefully pull the upper thread upward to pull
e
out the end of the bobbin thread.
Pull out about 10-15 cm (4-5 inches) of the
f
bobbin thread under the presser foot toward
the rear of the machine.
Reattach the bobbin cover.
g
Insert the tab in the lower-left corner of the
bobbin cover, and then lightly press down on
the right side.
a
b
1
a Tab
b Lower-left corner
2
30
Page 33
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Upper Threading
This section describes how to position the spool for the upper thread, and then thread the needle.
a
a Mark on handwheel
About the spool of thread
CAUTION
● When threading the upper thread,
carefully follow the instructions. If the
upper threading is not correct, the thread
may become tangled or the needle may
bend or break.
● The needle threader can be used with a
75/11 through 100/16 home sewing
machine needle. When using special
thread such as transparent nylon thread
or metallic thread, the needle threader
cannot be used.
● Thread with a thickness of 130/120 or
thicker cannot be used with the needle
threader.
● The needle threader cannot be used with
the wing needle or the twin needle.
● If the needle threader cannot be used,
refer to "Threading the needle manually
(without using the needle threader)" (page
36).
● Never use a thread weight of 20 or lower.
● Use the needle and the thread in the
correct combination. For details on the
correct combination of needles and
threads, refer to "Selecting the needle
depending on the thread and fabric types"
(page 39).
Information about the spools of thread is described
below.
CAUTION
● If the spool or the spool cap is not
positioned correctly, the thread may
become tangled around the spool pin or
the needle may break.
● Three spool cap sizes are available,
allowing you to choose a spool cap that
best fits the size of spool being used. If the
spool cap is too small for the spool being
used, the thread may catch on the slit in
the spool or the needle may break.
1
Upper Threading 31
Page 34
GETTING READY — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Press (Needle position button) once or
c
Threading the upper thread
twice to raise the needle.
Set the spool of thread on the spool pin, and then
thread the machine.
CAUTION
● When threading the upper thread,
carefully follow the instructions. If the
upper threading is not correct, the thread
may become tangled or the needle may
bend or break.
Turn on the machine.
a
Raise the presser foot lever.
b
a
a Presser foot lever
X The presser foot is raised.
a
a Needle position button
Note
z The needle is correctly raised when the mark
on the handwheel is at the top, as shown
below. Check the handwheel and, if this
mark is not at this position, press
(Needle position button) until it is.
a
a Mark on handwheel
Pick up the spool pin and remove the spool
d
cap that is inserted onto the spool pin.
Memo
z If the presser foot is not raised, the sewing
machine cannot be threaded.
32
b
a Spool pin
b Spool cap
a
Place the spool of thread onto the spool pin.
e
Slide the spool onto the pin so that the spool is
horizontal and the thread unwinds to the front
at the bottom.
Page 35
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Slide the spool cap onto the spool pin and
f
return the spool pin to its original position.
Slide the spool cap as far as possible to the right
as shown, with the rounded side on the left.
CAUTION
● If the spool or the spool cap is not
positioned correctly, the thread may
become tangled around the spool pin or
the needle may break.
Pull the thread from the spool and pass the
g
thread under the hook of the thread guide.
Pass the thread behind the thread guide cover
h
and to the front.
While holding the thread near the spool with
your right hand, pull the thread with your left
hand as shown below.
a
b
c
a Thread guide cover
b Thread guide spring
c Thread
d When the presser foot lever is lowered
1
d
a Thread guide
a
i
Note
z When passing the thread behind the thread
guide cover, be sure to use both hands. If
you do not hold the thread with your right
hand, the thread will be loose and you will
not be able to secure the thread in the thread
spring guide. It may cause incorrect thread
tension.
z Make sure that the presser foot lever is raised
before passing the thread behind the thread
guide cover. If the presser foot lever is
lowered, the thread guide spring is shut and
you cannot hang the thread on the thread
guide spring correctly.
Pass the thread through the guides in the order
shown below.
3
1
4
2
Upper Threading 33
Page 36
GETTING READY — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Make sure that the thread is passed into the
j
thread take-up lever as shown below.
a
a Thread take-up lever
Memo
z If the needle is not raised, you cannot pass
the thread into the thread take-up lever. Be
sure to press the needle position button to
raise the needle before passing the thread
into the thread take-up lever.
Pass the thread behind the needle bar thread
k
guide.
The thread can easily be passed behind the
needle bar thread guide by holding the thread
in your left hand, then feeding the thread with
your right hand, as shown.
Pull the end of the thread, which has been
m
passed through the needle bar thread guide, to
the left, then pass the thread through the notch
of the thread guide (1), and then firmly pull
the thread from the front and insert it into the
slit of the thread guide disk marked "7" all the
way (2).
Make sure that the thread passes the notch of
the thread guide.
b
a Notch of the thread guide
b Thread guide disk
a
a
a Needle bar thread guide
Lower the presser foot lever to lower the
l
presser foot.
Cut the thread with the cutter on the left side
n
of the machine.
a
a Thread cutter
a Presser foot lever
34
a
Page 37
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Lower the needle threader lever on the left
o
side of the machine as much as possible to
make the hook turn.
a
a Needle threader lever
a Needle
b Hook
Note
z If the needle threader lever is not lowered as
much as possible, the hook will not turn
fully as shown below and the thread will not
pass through the eye of the needle.
In such a case, start from
m again.
Ta
Tb
Raise the needle threader lever slowly.
p
a Needle threader lever
Ta
Raise the presser foot lever, and carefully pull
q
the loop of the thread through the eye of the
needle to pull out the end of the thread.
CAUTION
● Do not touch a button. Do not touch the
start/stop button, needle position button
or reverse/reinforcement stitch button. If
one of the buttons is accidentally pressed,
the machine will begin sewing and your
finger may be pricked with the needle or
the needle may break.
● When pulling out the thread, do not pull
it with extreme force, otherwise the
needle may bend or break.
1
z If the needle is not raised, the needle
threader cannot thread the needle. Be sure
to press (Needle position button) to raise
the needle before using the needle threader.
For details, refer to step
upper thread" (page 32).
z
c of "Threading the
Pass the end of the thread through the presser
r
foot, and then pull out about 5 cm (2 inches)
of thread toward the rear of the machine.
a
a 5cm (2 inches)
X The upper threading is finished.
Upper Threading 35
Page 38
GETTING READY — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
■ Threading the needle manually (without using
the needle threader)
When using specialty thread, such as transparent
nylon thread or metallic thread, a wing needle or a
twin needle which cannot be used with the needle
threader, thread the needle as described below.
Thread the machine to the needle bar thread
a
guide according to steps
"Threading the upper thread" (page 32).
Lower the presser foot lever.
b
a Presser foot lever
Pass the thread through the eye of the needle
c
from front to back.
a through k on
a
Using the twin needle
With the twin needle, you can sew two parallel lines
of the same stitch with two different threads. Both
upper threads should have the same thickness and
quality. Be sure to use the twin needle and the extra
spool pin.
For details on the stitches that can be sewn with the
twin needle, refer to "Stitch Setting Chart" (page 72).
a
b
a Twin needle
b Extra spool pin
CAUTION
● The twin needle (part code: X59296-121)
is recommended. Use of any other needle
may bend the needle or damage the
machine.
● Never use bent needles. Bent needles can
easily break, possibly resulting in injuries.
CAUTION
● Do not touch the start/stop button,
needle position button or reverse/
reinforcement stitch button. If one of the
buttons is accidentally pressed, the
machine will begin sewing and your
finger may be pricked with the needle or
the needle may break.
Raise the presser foot lever, pass the end of the
d
thread through the opening in the presser foot,
and pull out about 5 cm of thread toward the
rear of the machine.
Install the twin needle.
a
•
For details on installing a needle, refer to
"Replacing the needle" (page 41).
Thread the upper thread for the left needle
b
eye.
For details, refer to steps
"Threading the upper thread" (page 32).
Manually thread the left needle with the upper
c
thread.
Pass the thread through the eye of the needle
from the front.
a through k of
CAUTION
● The needle threader cannot be used with
the twin needle. If the needle threader is
used with the twin needle, the sewing
machine may be damaged.
36
Page 39
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Insert the extra spool pin into the end of the
d
bobbin winder shaft, and install the thread
spool on it. Then, thread the upper thread.
a Bobbin winder shaft
b Extra spool pin
c Thread spool
Memo
z When setting the thread spool, set it so that
the thread winds off from the front of the
spool.
Thread the upper thread for the right side in
e
the same way that the upper thread for the left
side was threaded.
Without passing the thread through the needle
f
bar thread guide, manually thread the right
needle.
Pass the thread through the eye of the needle
from the front.
CAUTION
● The needle threader cannot be used with
the twin needle. If the needle threader is
used with the twin needle, the sewing
machine may be damaged.
Attach zigzag foot "J".
g
For details on changing the presser foot, refer to
"Replacing the Presser Foot" (page 43).
CAUTION
● When using the twin needle, be sure to
attach zigzag foot "J". If bunched stitches
occur, use presser foot "N" or use a
lightweight tear-away stabilizer.
1
• For details, refer to steps
"Threading the upper thread" (page 32).
g through j of
Turn on the sewing machine and select a
h
stitch.
• For stitch selection see "Selecting stitching"
(page 51).
• See "Stitch Setting Chart" (page 72) for
stitches that use a twin needle.
CAUTION
● When using the twin needle, be sure to
select an appropriate stitch, otherwise the
needle may break or the machine may be
damaged.
Upper Threading 37
Page 40
GETTING READY — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Press .
i
X The screen for setting the twin needle
appears.
Press .
j
X displays in reverse highlight.
The twin needle can now be used.
Memo
z If is pressed again, it returns to .
Press (Back key).
k
X The initial screen appears again, and
appears.
Start sewing.
l
• For details on starting to sew, refer to
"Starting to sew" (page 55).
X Two lines of stitching are sewn parallel to
each other.
Note
z When changing the sewing direction, press
(Needle position button) to raise the
needle from the fabric, and then raise the
presser foot lever and turn the fabric.
CAUTION
● Do not try turning the fabric with twin
needle in the down position, otherwise
the needle may break or the machine may
be damaged.
CAUTION
● When using the twin needle, be sure to
select the twin needle setting, otherwise
the needle may break or the machine may
be damaged.
38
Page 41
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Replacing the Needle
This section describes how to replace the needle.
Needle precautions
CAUTION
z Only use home sewing machine needles. Use of any other needle may bend the needle or
damage the machine.
z Never use bent needles. Bent needles can easily break, possibly resulting in injuries.
Selecting the needle depending on the thread and fabric types
The sewing machine needle that should be used depends on the fabric and thread thickness. Refer to the
following table when choosing the thread and needle appropriate for the fabric that you wish to sew.
Fabric Type/Application
Medium weight
fabrics
Thin fabrics
Type Size
Broadcloth Cotton thread
Taffeta Synthetic thread
Flannel, Gabardine Silk thread 50
Lawn Cotton thread
Georgette Synthetic thread
Challis, Satin Silk thread 50
Thread
Size of Needle
60–90
75/11–90/14
60–90
65/9–75/11
1
Denim Cotton thread
Thick fabrics
Stretch fabrics
Easily frayed fabrics
For top-stitching
Corduroy Synthetic thread
Tweed Silk thread
Jersey
Thread for knits 50–60
Tricot
Cotton thread
Silk thread 50
Synthetic thread
Silk thread
Note
z Never use a thread of weight 20 or lower. It may cause malfunctions.
30 100/16
50
90/14–100/16
50–60
Ball point needle
(gold colored)
75/11–90/14
50–90
65/9–90/14Synthetic thread
50 90/14–100/16
Replacing the Needle 39
Page 42
GETTING READY — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Memo
z The lower the thread number is, the thicker
the thread, and the higher the needle
number, the thicker the needle.
z A 75/11 needle is already installed when the
sewing machine is purchased.
■ Ball point needle (gold colored)
To avoid skipped stitches use ball point needles
with stretch fabrics.
■ Transparent nylon thread
Use a 90/14 to 100/16 needle, regardless of the
fabric or thread.
■ Embroidery needles
Use a 75/11 home sewing machine needle. When
embroidering on thick fabrics such as denim, use a
90/14 or 100/16 home sewing machine needle.
CAUTION
z The appropriate fabric, thread and needle
combinations are shown in the table
(page 39). If the combination of the
fabric, thread and needle is not correct,
particularly when sewing thick fabrics
(such as denim) with thin needles (such as
65/9 to 75/11), the needle may bend or
break. In addition, the stitching may be
uneven or puckered or there may be
skipped stitches.
Checking the needle
Sewing with a bent needle is extremely dangerous
since the needle may break while the machine is
being operated.
Before using the needle, place the flat side of the
needle on a flat surface and check that the distance
between the needle and the flat surface is even.
a
b
a Flat side
b Needle type marking
CAUTION
z If the distance between the needle and
the flat surface is not even, the needle is
bent. Do not use a bent needle.
40
a
a
a Flat surface
Page 43
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Lower the presser foot lever.
Replacing the needle
Use the screwdriver and a needle that has been
determined to be straight according to the
instructions in "Checking the needle" (page 40).
Press (Needle position button) once or
a
twice to raise the needle.
d
1
a
a Needle position button
Turn off the sewing machine.
b
CAUTION
z Before replacing the needle, be sure to
turn off the sewing machine. Otherwise,
injuries may occur if one of the operation
buttons is accidentally pressed and the
machine starts sewing.
a
a Presser foot lever
Hold the needle with your left hand, and then
e
use a screwdriver to turn the needle clamp
screw toward you (counterclockwise) to
remove the needle.
a
b
a Screwdriver
b Needle clamp screw
• Do not apply a strong force when loosening
or tightening the needle clamp screw,
otherwise certain parts of the sewing
machine may be damaged.
Place fabric or paper under the presser foot
c
and cover the holes on the needle plate.
Note
z Before replacing the needle, place fabric or
paper under the presser foot to prevent the
needle from falling into the holes in the
needle plate.
With the flat side of the needle toward the rear
f
of the machine, insert the needle until it
touches the needle stopper.
a
a Needle stopper
Replacing the Needle 41
Page 44
GETTING READY — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
While holding the needle with your left hand,
g
use the screwdriver to tighten the needle
clamp screw.
Install the twin needle in the same way.
CAUTION
z Be sure to insert the needle until it
touches the needle stopper and securely
tighten the needle clamp screw with the
screwdriver. Otherwise, the needle may
break or damage may result.
42
Page 45
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Replacing the Presser Foot
This section describes how to replace the presser foot.
Presser foot precautions
Be sure to observe the following precautions concerning the presser foot.
CAUTION
● Use the presser foot appropriate for the type of stitch that you wish to sew, otherwise the
needle may hit the presser foot, causing the needle to bend or break.
● Only use presser feet designed specifically for this sewing machine. Use of any other presser
foot may result in injuries or damage to the machine.
Replacing the presser foot
CAUTION
Replace the presser foot as described below.
Memo
z For details on attaching the embroidery foot
"Q", refer to "Attaching the Embroidery Foot"
(page 138).
z Zigzag foot "J" is already installed when the
sewing machine is purchased.
Press (Needle position button) once or
a
twice to raise the needle.
a
z Before replacing the presser foot, be sure
to turn off the sewing machine.
Otherwise, injuries may occur if one of
the operation buttons is accidentally
pressed and the machine starts sewing.
Raise the presser foot lever.
c
1
a Needle position button
Turn off the sewing machine.
b
a
a Presser foot lever
X The presser foot is raised.
Press the black button at the back of the
d
presser foot holder.
a
b
a Black button
b Presser foot holder
X The presser foot holder releases the presser
foot.
Replacing the Presser Foot 43
Page 46
GETTING READY — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Place a different presser foot below the holder
e
so that the presser foot pin is aligned with the
notch in the holder.
Position the presser foot so the letter indicating
the presser foot type (A, G, I, J, M, N or R) is
positioned to be read.
Note
z When a stitch is selected, the icon for the
presser foot that should be used appears in
the screen. Check that the correct presser
foot is attached before starting to sew. If the
wrong presser foot is installed, turn off the
a
sewing machine, attach the correct presser
foot, and then select the desired stitch again.
b
a Presser foot holder
b Notch
c Pin
c
Slowly lower the presser foot lever so that the
f
presser foot pin snaps into the notch in the
presser foot holder.
a
b
c
d
Buttonhole foot "A"
Overcasting foot "G"
Zigzag foot "J"
Button fitting foot "M"
Monogramming foot "N"
Blind stitch foot "R"
Side cutter "S" (option)
z For details on the presser foot that should be
used with the selected stitch, refer to "Stitch
Setting Chart" (page 72).
a Presser foot lever
b Presser foot holder
c Notch
d Pin
X The presser foot is attached.
Raise the presser foot lever to check that the
g
presser foot is securely attached.
44
Page 47
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
■ Attaching the presser foot holder
Removing and attaching the
presser foot holder
Remove the presser foot holder when cleaning the
sewing machine or when installing a presser foot that
does not use the presser foot holder, such as the
embroidery foot, optional free-motion open toe
quilting foot "O" and optional walking foot. Use the
screwdriver to remove the presser foot holder.
Raise the presser foot lever.
a
X The presser foot is raised.
Align the presser foot holder with the lower-
b
left side of the presser bar.
1
CAUTION
z Before attaching/removing the presser
foot, be sure to turn off the sewing
machine. Otherwise, injuries may occur if
one of the operation buttons is
accidentally pressed and the machine
starts sewing.
Remove the presser foot.
a
• For details, refer to "Replacing the presser
foot" (page 43).
Use the screwdriver to loosen the presser foot
b
holder screw.
c
a
b
a Screwdriver
b Presser foot holder
c Presser foot holder screw
d Presser bar
X The presser foot is removed from the presser
bar.
d
a
b
a Presser bar
b Presser foot holder
Hold the presser foot holder in place with your
c
right hand, and then tighten the screw using
the screwdriver in your left hand.
a
b
a Screwdriver
b Presser foot holder
CAUTION
z Do not hit the needle with your finger or
the presser foot when attaching/removing
it. The needle may break or cause injury.
z Be sure to tighten the screw with the
included screwdriver. If the screw is
loose, the needle may hit the presser foot
and break or bend.
Replacing the Presser Foot 45
Page 48
GETTING READY — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Sewing Cylindrical Pieces and Large Pieces
Free-arm sewing and using an extension table make sewing cylindrical pieces or large pieces easy.
Free-arm sewing
Removing the flat bed attachment allows for free-arm
sewing, making it easier to sew cylindrical pieces
such as sleeve cuffs and pant legs.
Remove the flat bed attachment.
a
a
a Flat bed attachment
X With the flat bed attachment removed, free-
arm sewing is possible.
Slide the part that you wish to sew onto the
b
arm, and then sew from the top.
a
Using extension table
The cover of the embroidery unit can be used as the
extension table. This is useful for sewing large pieces.
a
a Cover of embroidery unit (extension table)
CAUTION
● Do not move the sewing machine with
the extension table attached.
● Do not use the extension table in any
other way than how it is intended.
a Arm
When you have finished free-arm sewing,
c
reconnect the flat bed attachment.
46
Remove the flat bed attachment.
a
a Flat bed attachment
a
Page 49
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Raise up the two legs on the reverse side of the
b
extension table until they click.
Attach the extension table to the sewing
c
machine arm.
Keep the extension table horizontal and push it
in slowly until it stops.
Memo
● If the extension table is not stable or its
height is improper, adjust its height by
turning the rubber ends of legs.
Turn back the extension table, and then store
e
the two legs in their original positions.
Memo
● When you do not use the extension table,
use it as the cover of the embroidery unit.
1
When you have finished sewing, remove the
d
extension table by pulling it to the left. Then
reinstall the flat bed attachment to its original
position.
Sewing Cylindrical Pieces and Large Pieces 47
Page 50
GETTING READY — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
48
Page 51
2 SEWING BASICS
The necessary preparations for sewing are described in this chapter.
Sewing.....................................................................................................................50
Setting the Stitch .....................................................................................................61
Useful Functions......................................................................................................64
Useful Sewing Tips ..................................................................................................68
Page 52
SEWING BASICS — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Sewing
Basic sewing operations are described below.
Before operating the sewing machine, read the following precautions.
CAUTION
While the machine is in operation, pay special attention to the needle location. In addition,
z
keep your hands away from all moving parts such as the needle and handwheel, otherwise
injuries may occur.
z Do not pull or push the fabric too hard while sewing, otherwise injuries may occur or the
needle may break.
z Never use bent needles. Bent needles can easily break, possibly resulting in injuries.
z Make sure that the needle does not strike basting pins, otherwise the needle may break or
bend.
General sewing procedure
Follow the basic procedures below to sew.
Attach the presser foot that is appropriate for the type of stitch that you
wish to sew. Be sure to turn off the main power before replacing the
1 Attach the presser foot.
2 Turn on the machine.
3 Select the stitch.
presser foot.
For details on replacing the presser foot, refer to "Replacing the presser
foot" (page 43).
↓
Turn on the sewing machine. For details on turning on the machine,
refer to "Turning on the machine" (page 17).
↓
Select the stitch appropriate for the area to be sewn.
For details on selecting a stitch, refer to "Selecting stitching" (page 51).
4 Position the fabric.
5 Start sewing.
6 Cut the thread.
50
↓
Place the area to be sewn under the presser foot. Be sure that the fabric
pieces are sewn in the correct order and that the right and wrong sides of
the fabric are aligned correctly. For details on positioning the fabric,
refer to "Positioning the fabric" (page 54).
↓
Start sewing.
For details on starting to sew, refer to "Starting to sew" (page 55).
↓
Cut the thread at the end of sewing. Automatic thread cutting is also
possible. For details on cutting the thread, refer to "Cutting the thread"
(page 59).
Page 53
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
k Patterns saved in the machine's memory
Stitch types
A stitch can be selected from the following types
available.
For details on the various stitches, refer to "Stitch
Setting Chart" (page 72).
Selecting stitching
Stitches are selected using LCD operations. Turn the
power on, the utility stitch selecting screen appears
and the straight stitch (left needle position) is
selected.
You can retrieve a saved pattern. (For details,
refer to "Saving patterns" (page 129).)
a Utility stitches
You can select from 67 utility stitches, including
straight line stitching, overcasting, button holes
and basic decorative stitches. If this is selected,
the utility stitch selection appears right after the
power is turned on.
b My Custom Stitch
You can design original stitches. (For details, refer
to "Designing a Pattern (My Custom Stitch)" (page
131).)
c Character stitches-Gothic font
(Can be combined)
There are 55 characters, including letters,
symbols and numbers, in the Gothic font.
d Character stitches-Script font
(Can be combined)
There are 55 characters, including letters,
symbols and numbers, in the Script font.
e Character stitches-Outline style
(Can be combined)
There are 55 characters, including letters,
symbols and numbers, in the outline style.
f Decorative stitches
(Can be combined)
You can select from 30 decorative stitches,
including leaves, flowers and hearts. You can
sew combinations of multiple decorative stitches.
g Satin stitches
(Can be combined)
You can select from 16 satin stitches. You can
sew combinations of multiple decorative stitches.
h Combined utility stitches
(Can be combined)
You can sew with combinations from 39 utility
stitches.
i Decorative satin stitches
(Can be combined)
There are 9 decorative satin stitches.
j Cross stitches
(Can be combined)
You can select from 7 cross stitches. You can sew
combinations of multiple decorative stitches.
Determine the stitch to be used, and select the
a
recommended presser foot.
• Refer to "Stitch Setting Chart" (page 72).
Attach the presser foot.
b
The machine comes with zigzag foot "J"
attached.
• For details, refer to "Replacing the presser
foot" (page 43).
CAUTION
z Use the presser foot appropriate for
selected stitch. If the wrong presser foot is
used, the needle may hit the presser foot
and bend or break.
Turn on the sewing machine.
c
• When an animation is displayed on the
screen, touch the LCD with your finger.
X The straight stitch (left needle position) is
shown selected on the screen.
Press (Utility stitch key) on the
d
operation panel.
2
Sewing 51
Page 54
SEWING BASICS — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
cd
e
g
i
Select the stitch type.
e
When selecting a decorative stitch
X The screen containing the various stitches in
the selected stitch type appears.
• To select a different stitch type, press
(Back key).
Select a stitch.
f
(Previous page key) displays the previous
page, and (Next page key) displays the
next page.
If necessary, specify the settings for automatic
g
reverse/reinforcement stitching and adjust the
stitch length, etc.
• For details on sewing with each of the utility
stitches, refer to Chapter3, "UTILITY
STITCHES" which begins from page 72.
Note
z When a stitch is selected, the icon for the
presser foot that should be used appears on
the screen. Check that the correct presser
foot is attached before starting to sew. If the
wrong presser foot is installed, turn off the
sewing machine, attach the correct presser
foot, and then select the desired stitch again.
Memo
z For details on setting automatic reverse/
reinforcement stitching etc., refer to "Useful
Functions" (page 64).
z For details on adjusting the stitch width,
stitch length and thread tension, refer to
"Setting the Stitch" (page 61).
■ Selecting utility stitches
Memo
z When touching the screen with your finger
is difficult, use the included touch pen.
h
a
f
b
a Selects decorative stitch
b Sets width and length
c Selects single stitch sewing
d Selects repeat sewing
e Makes horizontal mirror image
f Deletes a selected pattern
g Used for checking combined pattern
h Activates automatic thread cutting
i Activates automatic reverse/reinforcement stitch
• To select a different stitch, press to
remove the selected pattern.
Follow steps a to c in "Selecting stitching"
a
(page 51).
Select a stitch.
b
Memo
z The utility stitch selection screen appears
when you turn on the machine.
Example: When
11
is selected:
52
Page 55
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
■ Selecting characters
Three styles of character stitches are available. The
procedure for selecting a character is the same with
all styles.
Follow steps a to d in "Selecting stitching"
a
(page 51) to display the screen where a stitch
type can be selected.
Select the character style.
b
Select the characters.
c
• If a wrong character was selected, press
to erase the character, and then select
the correct character
•
To select a different character style,
press , and then select the desired
character style.
• Press to view a sample of the selected
pattern.
Example: BUS
2
Sewing 53
Page 56
SEWING BASICS — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
While holding the end of the thread and the
d
Positioning the fabric
fabric with your left hand, turn the handwheel
toward you (counterclockwise) with your right
Be sure that the fabric pieces are sewn in the correct
order and that the right and wrong sides of the fabric
hand to lower the needle to the starting point
of the stitching.
are aligned correctly.
Turn on the machine.
a
Press (Needle position button) once or
b
twice to raise the needle.
a
j Needle position button
Place the fabric under the presser foot.
c
Memo
z If the seam allowance is positioned on the
right side, sewing in a straight line is easier
and the extra fabric does not get in the way.
Lower the presser foot lever.
e
a
a Presser foot lever
X The fabric is now positioned to be sewn.
54
Page 57
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Starting to sew
Once you are ready to start sewing, you can start the
sewing machine. Sewing can be started and stopped
using the operation button (Start/stop button) or
the foot controller. For details on the foot controller,
refer to next page.
Memo
Memo
z When the foot controller is plugged in,
(Start/stop button) cannot be used to start
sewing.
■ Using the operation button
Sewing can be started and stopped using the
operation button (Start/stop button).
z The machine will sew at a slow speed at the
beginning of sewing.
z If you press and hold the (Start/stop
button) while sewing, the machine will sew
at a slow speed. If you use this function at
the point just before the position where you
want to stop the machine, you can stop the
machine with more precision.
2
Slide the sewing speed controller to the left or
a
right to select the desired sewing speed.
Slide the sewing speed controller to the left to
sew at a slower speed, or slide the speed
controller to the right to sew at a faster speed.
a
a Sewing speed controller
Press (Start/stop button) once.
b
When the end of the stitching is reached, press
c
d
(Start/stop button) once.
X The machine stops sewing with the needle
lowered (in the fabric).
Cut the threads.
• For details, refer to "Cutting the thread" (page
59).
Note
z This machine will automatically stop when
the bobbin becomes almost empty. When
the machine stops, replace the bobbin
thread, and then press (Start/stop button)
to begin sewing again.
a
a Start/stop button
X The machine starts sewing.
Sewing 55
Page 58
SEWING BASICS — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
■ Using the foot controller
Sewing can be started and stopped using the foot
controller.
Turn off the sewing machine.
a
Note
z When connecting the foot controller, be sure
to turn off the sewing machine in order to
prevent the machine from accidentally being
started.
Insert the foot controller plug into its jack on
b
the right side of the sewing machine.
Slide the sewing speed controller to the left or
d
right to select the desired sewing speed.
Slide the sewing speed controller to the left to
sew at a slower speed, or slide the speed
controller to the right to sew at a faster speed.
a
a Sewing speed controller
X The speed set using the sewing speed
controller is the foot controller's maximum
sewing speed.
Once you are ready to start sewing, slowly
e
press down on the foot controller.
Pressing down on the foot controller increases
the sewing speed; releasing the pressure on the
foot controller decreases the sewing speed.
a Foot controller jack
Turn on the machine.
c
a
Slower
Faster
• Slowly press down on the foot controller.
Pressing it down hard starts sewing too
quickly.
X The machine starts sewing.
When the end of the stitching is reached,
f
completely release the foot controller.
X The machine stops sewing with the needle
lowered (in the fabric).
Cut the threads.
g
• For details, refer to "Cutting the thread" (page
59).
56
Page 59
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Memo
z When the foot controller is plugged in,
(Start/stop button) cannot be used to start
sewing.
z When sewing is stopped, the needle remains
lowered (in the fabric). The machine can be
set so that the needle will stay up when
sewing is stopped. For details on setting the
machine so that the needle stays up when
sewing is stopped, refer to "Changing the
machine settings" (page 18).
CAUTION
z
Do not allow thread or dust to
accumulate in the foot controller,
otherwise a fire or an electric shock may
occur.
z Do not place objects on the foot
controller, otherwise damage to the
machine or injuries may occur.
z If the machine is not to be used for a long
period of time, unplug the foot controller,
otherwise a fire or an electric shock may
occur.
Securing the stitching
When sewing with the straight stitch, for example, at
the end of an opening or where seams do not
overlap, use reverse stitching or reinforcement
stitching to secure the end of the thread.
Lower the needle into the fabric at the
a
beginning of the stitching, then lower the
presser foot.
Press (Start/stop button), or press down on
b
the foot controller.
At this time, if (Start/stop button) is held
down, the machine sews at a slow speed.
• For details, refer to "Starting to sew" (page
55).
2
a
a Start/stop button
X The machine starts sewing.
Sewing 57
Page 60
SEWING BASICS — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
After sewing 3 to 5 stitches, press
c
(Reverse/reinforcement stitch button).
Keep (Reverse/reinforcement stitch button)
held down until you reach the beginning of the
stitching.
• The machine sews at a slow speed when
(Reverse/reinforcement stitch button) is
held down.
a
a Reverse/reinforcement stitch button
X While (Reverse/reinforcement stitch
button) is held down, reverse stitches are
sewn.
After sewing back to the beginning of the
d
stitching, release (Reverse/reinforcement
stitch button).
X The machine stops sewing.
Press (Start/stop button), or press down on
e
the foot controller.
X The machine starts sewing in the normal
sewing direction.
When the end of the stitching is reached, press
f
(Reverse/reinforcement stitch button).
Keep (Reverse/reinforcement stitch button)
held down until 3 to 5 reverse stitches are
sewn.
X While (Reverse/reinforcement stitch
button) is held down, reverse stitches are
sewn.
After 3 to 5 reverse stitches have been sewn,
g
release (Reverse/reinforcement stitch
button).
X The machine stops sewing.
Press (Start/stop button), or press down on
h
the foot controller.
At this time, if (Start/stop button) is held
down, the machine sews at a slow speed.
X The machine starts sewing in the normal
sewing direction.
After sewing to the end of the stitching, the
i
sewing machine stops.
Release (Start/stop button) or foot
controller.
58
a
Press
3
Press
4
b
a Beginning of stitching
X End of stitching
Press
1
Press
2
Press
5
Press
6
Page 61
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
■ Sewing stitches
When (Reverse/reinforcement stitch button) is
pressed with stitches other than 1 , 3 and
7 stitches, reinforcement stitches are used.
Reinforcement stitches are 3 to 5 stitches sewn on
top of each other in one place.
Cutting the thread
When you have finished sewing, cut the thread.
■ Using the thread cutter button
When you wish to finish the stitching, press
a
(Thread cutter button) once.
2
a
a Reverse stitching
b Reinforcement stitching
b
Memo
z The sewing machine can be set to
automatically sew reverse or reinforcement
stitches at the beginning and end of the
stitching. For details, refer to "Automatic
sewing reverse/reinforcement stitches" (page
64).
a
a Thread cutter button
X The threads are cut and the needle is raised.
Note
z The thread cutter button cannot be used
when the presser foot lever is raised.
Raise the presser foot lever, then remove the
b
fabric.
a
a Presser foot lever
CAUTION
z Do not press (Thread cutter button)
after threads have already been cut,
otherwise the needle may break, the
threads may become tangled or damage
to the machine may occur.
z Do not press (Thread cutter button) if
there is no fabric under the presser foot
or while the machine is sewing, otherwise
damage to the machine may occur.
Memo
z The machine can be set so that the thread
will be cut automatically when sewing is
finished. For details, refer to "Automatically
cutting the thread" (page 65).
Sewing 59
Page 62
SEWING BASICS — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
■ Using the thread cutter
When sewing with nylon or metallic threads, or
other special threads, use the thread cutter on the
side of the machine to cut the threads.
When you wish to finish the stitching and the
a
sewing machine is stopped, press (Needle
position button) once to raise the needle.
a
a Needle position button
Raise the presser foot lever.
b
a
a Presser foot lever
Pull the fabric to the left side of the machine,
c
and then pass the threads through the thread
cutter to cut them.
a
a Thread cutter
60
Page 63
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Setting the Stitch
This machine is preset with the default settings for the stitch width and stitch length for each stitch. However,
you can change any of the settings by pressing in the screen, then follow the procedure described in this
section.
Note
z Settings for some stitches cannot be changed. For details, refer to "Stitch Setting Chart" (page 72).
z Stitch settings return to their defaults if they are changed, when the machine is turned off or a different
stitch is selected before the stitch setting is saved. If you want to save settings, refer to "Saving stitch
settings" (page 67).
2
Adjusting the stitch width
The stitch width (zigzag width) can be adjusted to
make the stitch wider or narrower.
Each press of makes the zigzag stitch narrower.
Each press of makes the zigzag stitch wider.
Memo
z
means the setting cannot be adjusted.
z
If the straight stitch (left needle position or triple
stretch stitch) was selected, changing the stitch
width changes the needle position. Increasing
the width moves the needle to the right;
reducing the width moves the needle to the
left. For details, refer to "Changing the needle
position" (
z Press to return the setting to its default.
z If the foot controller is connected, the
sewing speed controller can be used to
adjust the zigzag width. For details, refer to
"Satin stitching using the sewing speed
controller" (page 107).
page 83
).
CAUTION
z After adjusting the stitch width, slowly
turn the handwheel toward you
(counterclockwise) and check that the
needle does not touch the presser foot. If
the needle hits the presser foot, the
needle may bend or break.
Setting the Stitch 61
Page 64
SEWING BASICS — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Adjusting the stitch length
The stitch length can be adjusted to make the stitch
coarser or finer.
Each press of makes the stitch finer (shorter).
Each press of makes the stitch coarser (longer).
Adjusting the thread tension
You may need to change the thread tension,
depending on the fabric and thread being used.
■ Correct thread tension
The upper thread and the bobbin thread should
cross near the center of the fabric. Only the upper
thread should be visible from the right side of the
fabric, and only the bobbin thread should be
visible from the wrong side of the fabric.
a
b
c
d
a Wrong side of fabric
b Right side of fabric
c Upper thread
d Bobbin thread
■ Upper thread is too tight
If the bobbin thread is visible from the right side of
the fabric, the upper thread is too tight.
Memo
z means the setting cannot be adjusted.
z Press to return the setting to its
default.
CAUTION
If the stitches are bunched together,
z
increase the stitch length. Continuing to
sew with the stitches bunched together
may result in the needle bending or
breaking.
Note
z If the bobbin thread was incorrectly
threaded, the upper thread may be too tight.
In this case, refer to "Installing the bobbin"
(page 27) and rethread the bobbin thread.
a
b
c
d
a Wrong side of fabric
b Right side of fabric
c Upper thread
d Bobbin thread
e The bobbin thread is visible from the right side of
the fabric.
Turn the thread tension dial to the left to loosen
the upper thread.
e
62
Page 65
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Memo
z When you finish sewing, remove the bobbin
cover and then make sure that the thread is
shown as below. If the thread is not shown
as below, the thread is not inserted through
the tension-adjusting spring of the bobbin
case correctly. Reinsert the thread correctly.
For details, refer to page 29.
■ Upper thread is too loose
If the upper thread is visible from the wrong side of
the fabric, the upper thread is too loose.
Note
z If the upper thread was incorrectly threaded,
the upper thread may be too loose. In this
case, refer to "Threading the upper thread"
(page 32) and rethread the upper thread.
Memo
z If the upper thread is not threaded correctly
or the bobbin is not installed correctly, it
may not be possible to set the correct thread
tension. If the correct thread tension cannot
be achieved, rethread the upper thread and
insert the bobbin correctly.
z The level "4" on the tension dial is a guide
for working normal fabrics (medium weight).
However, the actual stitch tension you’ll
want to use will vary according to the fabric
and thread you are using, so you should
always sew a stitch sample and adjust stitch
tension before beginning on the actual piece
to be worked.
z The machine may stop sewing if tension is
set extremely low. This is not a sign that
there is anything wrong with your machine.
Simply adjust to the correct stitch tension
and begin again.
2
e
a
b
c
d
a Wrong side of fabric
b Right side of fabric
c Upper thread
d Bobbin thread
e The upper thread is visible from the wrong side of
the fabric.
Turn the thread tension dial to the right to tighten
the upper thread.
Setting the Stitch 63
Page 66
SEWING BASICS — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Useful Functions
Functions useful in improving sewing efficiency are described below.
Position the fabric under the presser foot, and
d
Automatic sewing reverse/
reinforcement stitches
The sewing machine can be set to automatically sew
reverse or reinforcement stitches at the beginning and
end of the stitching. Depending on the selected stitch,
reverse stitches or reinforcement stitches are
automatically set. For details on reverse/
reinforcement stitching, refer to "Stitch Setting Chart"
(page 72).
Turn on the machine.
a
X The LCD comes on.
Select a stitch.
b
• For details on selecting a stitch, refer to
"Selecting stitching" (page 51).
Press on the LCD.
c
then press (Start/stop button) once.
a
a Start/stop button
X Stitching starts after reverse stitching or
reinforcement stitching.
After reaching the end of the stitching, press
e
(Reverse/reinforcement stitch button) once.
Buttonholes or bar tacking require
reinforcement stitching making this operation
unnecessary.
X It turns to , and the sewing machine is
set for automatic reverse/reinforcement
stitching.
Memo
z To turn automatic reverse/reinforcement
stitching off, press .
z When the sewing machine is turned off, the
automatic reverse/reinforcement stitching
setting is cancelled.
z When the stitch such as those for sewing
buttonholes and bar tacks is selected,
reinforcement stitches are automatically
sewn.
64
a
a Reverse/reinforcement stitch button
X After reverse/reinforcement stitches are
sewn, the sewing machine stops.
Page 67
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Press the stitch selection.
Memo
z Press (Start/stop button) when you want
to stop the sewing machine in the middle of
sewing without reverse stitching or
reinforcement stitching (for example, when
you want to change the sewing direction).
The sewing machine stops without reverse
stitching or reinforcement stitching.
Press (Reverse/reinforcement stitch
button) at the end of the stitching.
b
• For details on selecting a stitch, refer to
"Selecting stitching" (page 51).
Press on the screen.
c
2
1
a
2
4
a Stop the machine and change the sewing
direction.
b Start the machine again.
b
3
Automatically cutting
the thread
The sewing machine can be set to automatically cut
the threads at the end of the stitching. This is called
"programmed thread-cutting".
If programmed thread-cutting is set, automatic
reverse/reinforcement stitching is also set.
Turn on the machine.
a
X You get , and the sewing machine is
set for programmed thread-cutting and
automatic reverse/reinforcement stitching.
Memo
z To turn programmed thread cutting off,
press .
Position the fabric under the presser foot, and
d
then press (Start/stop button) once.
X The LCD comes on.
a
a Start/stop button
X Stitching starts after reverse stitching or
reinforcement stitching.
Useful Functions 65
Page 68
SEWING BASICS — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
After reaching the end of the stitching, press
e
(Reverse/reinforcement stitch button)
once.
Buttonholes or bar tacking require
reinforcement stitching making this operation
unnecessary.
X After the reverse stitching or reinforcement
stitching has been done, the sewing machine
stops, and the thread is cut.
Mirroring stitches
You can sew the mirror image of a stitch horizontally
(left and right).
Turn on the machine.
a
X The LCD comes on.
Select a stitch.
b
• For details on selecting a stitch, refer to
"Selecting stitching" (page 51).
The thread is cut here.
Memo
z Press (Start/stop button) when you want
to stop the sewing machine in the middle of
sewing without programmed thread-cutting
(for example, when you want to change the
sewing direction). The sewing machine stops
without programmed thread cutting.
Press (Reverse/reinforcement stitch
button) at the end of the stitching.
1
a
2
c
4
a Stop the machine and change the sewing
direction.
b Start the machine again.
c The thread is cut here.
z If the power is turned off, programmed
thread-cutting will be turned off.
b
3
Press on the screen.
c
X It turns to , and the pattern displayed at
the top of the screen is mirrored.
Memo
z To cancel the mirror image setting,
press .
z Mirror image is not possible for buttonholes
and other stitches where shows.
z When the sewing machine is turned off, the
mirror image setting is cancelled.
66
Page 69
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Saving stitch settings
This machine is preset with the default settings for the
stitch width (zigzag width), stitch length,
programmed thread-cutting, and automatic reverse/
reinforcement stitching for each stitch. However, if
you wish to save specific settings for a stitch so that
they can be used later, press after changing the
settings to save the new settings with the selected
stitch. This feature can be used only with utility
stitches. The settings you saved will not be cleared if
the machine is turned off.
■ To use a stitch length of 2.0 mm for the straight
stitch
Select a straight stitch.
a
Press .
b
Memo
z The default stitch length is 2.5 mm.
Set the stitch length to 2.0 mm.
c
Note
z All stitch settings (stitch width (zigzag
width), stitch length, programmed threadcutting, and automatic reverse/
reinforcement stitching, etc.) are saved, not
just the setting that was changed. When the
same stitch pattern is selected, the last
settings saved are displayed even if the
machine was turned off. If the settings are
changed again and is pressed, or if
is pressed to reset the setting to its
default, the new settings are not saved unless
is pressed another time.
Even if is pressed, the settings for
programmed thread-cutting and automatic
reverse/reinforcement stitching are saved in
the machine.
2
Press .
d
• To reset the selected stitch patterns to its
default settings, press , and then
press .
X The confirmation message is displayed.
Press .
e
X The next time that the same straight stitch is
selected, the stitch length is set to 2.0 mm.
Useful Functions 67
Page 70
SEWING BASICS — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Useful Sewing Tips
Various ways to achieve better results for your sewing projects are described below. Refer to these tips when
sewing your project.
Trial sewing
After you have set up the machine with the thread
and needle appropriate for the type of fabric being
sewn, the machine automatically sets the stitch
length and width for the stitch that is selected.
However, a trial piece of fabric should be sewn.
Depending on the type of fabric and stitching being
sewn, the desired results may vary. For trial sewing,
use a piece of fabric and thread that are the same as
those used for your project, and check the thread
tension and stitch length and width. Since the results
may vary depending on the type of stitching and the
number of layers of fabric sewn, perform the trial
sewing under the same conditions that will be used
with your project.
Changing the sewing direction
When the stitching reaches a corner, stop the
a
sewing machine.
Leave the needle lowered (in the fabric). If the
needle remained up when the machine stopped
sewing, press (Needle position button) to
lower the needle.
Sewing curves
Stop sewing, and then slightly change the sewing
direction to sew around the curve. For details on
sewing with an even seam allowance, refer to
"Sewing an even seam allowance" (page 70).
When sewing along a curve while using a zigzag
stitch, select a shorter stitch length in order to obtain
a finer stitch.
Raise the presser foot lever, and then turn the
b
fabric.
Turn the fabric using the needle as a pivot.
Lower the presser foot lever and continue
c
sewing.
68
Sewing thick fabrics
■ If the fabric does not fit under the presser foot
Raise the presser foot lever even higher to bring
the presser foot to its highest position.
Page 71
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
■ If thick seams are being sewn and the fabric does
not feed at the beginning of stitching
Zigzag foot "J" is equipped with a feature that
keeps the presser foot level.
Sewing hook-and-loop
fastener
CAUTION
z Use only the ungummed hook-and-loop
a
a Sewing direction
Raise the presser foot lever.
a
Press the black button (presser foot holding
b
pin) on the left side of zigzag foot "J". Keep the
button held in and lower the presser foot.
a
a Presser foot holding pin
X Release the button. The foot will lock in
place level with the seam, allowing the
fabric to feed.
fastener designed for sewing. If the glue
adheres to the needle or the bobbin hook
race, it may cause malfunction.
z If the hook-and-loop fastener is sewn with
a fine needle (65/9-75/11), the needle
may bend or break.
Note
z Before starting to sew, baste the fabric and
hook-and-loop together.
Make sure that the needle passes through the hookand-loop fastener by turning the handwheel and
lower the needle into the hook-and-loop fastener
before sewing. And then, sew the edge of the hookand-loop fastener at a slow speed.
If the needle does not pass through the hook-andloop fastener, replace the needle with the needle for
thick fabrics (page 39).
a
2
X Once the trouble spot has been passed, the
foot will return to its normal position.
CAUTION
z If fabric more than 6 mm (15/64 inch)
thick is sewn or if the fabric is pushed
with too much force, the needle may
bend or break.
a Edge of the hook-and-loop fastener
Sewing thin fabrics
When sewing thin fabrics, the stitching may become
misaligned or the fabric may not feed correctly.
If this occurs, place thin paper or stabilizer material
under the fabric and sew it together with the fabric.
When you have finished sewing, tear off any excess
paper.
a
a Stabilizer material or paper
Useful Sewing Tips 69
Page 72
SEWING BASICS — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
■ Aligning the fabric with a needle plate marking
Sewing stretch fabrics
First, baste the pieces of fabric together, and then sew
without stretching the fabric.
The markings on the needle plate show the
distance from the needle position of a seam sewn
with the straight stitch (left needle position). Sew
while keeping the edge of the fabric aligned with a
marking in the needle plate. The distance between
the markings in the upper scale is 1/8 inch (3 mm)
and the distance between the markings in the grid
is 5 mm (3/16 inch).
a
a Basting
Using the stretch stitches or the thread for knits gives
an attractive finish.
4591034
Sewing an even seam
allowance
To sew an even seam, start sewing so that the seam
allowance is to the right of the presser foot, and the
edge of the fabric is aligned with either the right edge
of the presser foot or a marking on the needle plate.
■ Aligning the fabric with the presser foot
Sew while keeping the right edge of the presser
foot aligned with a fixed distance from the edge of
the fabric.
1
2
a Seam
b Presser foot
c Centimeters
d Inches
e Needle plate
f 1.6 cm (5/8 inch)
5
4
3
6
a Seam
b Presser foot
Memo
z If the straight stitch (left needle position,
triple stretch stitch, basting stitch etc.) is
selected, you can change the distance
between the seam and the right edge of the
presser foot by changing the stitch width. For
details, refer to "Changing the needle
position" (page 83).
70
Page 73
3 UTILITY STITCHES
The various stitches and their applications are described in this chapter.
Stitch Setting Chart .................................................................................................72
Overcasting Stitches................................................................................................78
Basic Stitching .........................................................................................................82
Blind Hem Stitching ................................................................................................84
Buttonhole Stitching/Button Sewing........................................................................87
Zipper Insertion.......................................................................................................94
Sewing Stretch Fabrics and Elastic Tape ..................................................................99
Appliqué, Patchwork and Quilt Stitching ..............................................................101
Reinforcement Stitching ........................................................................................108
Eyelet Stitching......................................................................................................113
Decorative Stitching.............................................................................................. 114
Sewing the Various Built-in Decorative Patterns ...................................................122
Designing a Pattern (My Custom Stitch)................................................................131
Page 74
UTILITY STITCHES — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Stitch Setting Chart
Applications, stitch lengths and widths and whether the twin needle can be used are listed for utility
stitches in the following table.
Utility stitches
Stitch Name Pattern
Straight
Left
stitch
Center
Triple stretch stitch
Stretch stitch
Basting stitch
Zigzag
stitch
Center
Right
2-point
zigzag stitch
3-point
zigzag stitch
Stitch Width
Application
Presser Foot
1
2
3
4
5
6
Basic stitching, sewing gathers or
J
pintucks, etc.
Basic stitching and sewing
J
gathers or pintucks
Attaching zippers, basic
J/I
stitching, sewing gathers or
pintucks, etc.
Attaching sleeves, sewing
J
inseams, sewing stretch fabrics
and decorative stitching
Sewing stretch fabrics and
J
decorative stitching
J Temporarily securing
7
8
9
Overcasting and attaching
J
appliqués
Beginning sewing from the right
J
needle position
Overcasting on mediumweight
J
or stretch fabrics, attaching
elastic, darning, etc.
10
11
Overcasting on mediumweight
J
or stretch fabrics, attaching
elastic, darning, etc.
Overcasting on thin or
G
mediumweight fabrics
[mm (inch)]
Auto Manual Auto Manual
0.0
0.0–7.0
(0)
(0–1/4)
0.0
0.0–7.0
(0)
(0–1/4)
3.5
0.0–7.0
(1/8)
(0–1/4)
0.0
0.0–7.0
(0)
(0–1/4)
1.0
1.0–3.0
(1/16)
(1/16–1/8)
0.0
0.0–7.0
(0)
(0–1/4)
3.5
0.0–7.0
(1/8)
(0–1/4)
3.5
2.5–5.0
(1/8)
(3/32–3/16)
5.0
1.5–7.0
(3/16)
(1/16–1/4)
5.0
1.5–7.0
(3/16)
(1/16–1/4)
3.5
2.5–5.0
(1/8)
(3/32–3/16)
Stitch Length
[mm (inch)]
Reverse/
Reinforcement
Stitching
Twin Needle
2.5
(3/32)
2.5
(3/32)
2.5
(3/32)
2.5
(3/32)
2.5
(3/32)
0.2–5.0
(1/64–3/16)
0.2–5.0
(1/64–3/16)
0.2–5.0
(1/64–3/16)
1.5–4.0
(1/16–3/16)
1.0–4.0
(1/16–3/16)
Yes
Yes
Yes
Yes
Yes
Reverse No
(J)
Reinforcement Yes
(J)
Reverse No
(J)
Reinforcement No
(J)
Reinforcement No
(J)
– – No Reinforcement No
1.4
(1/16)
1.4
(1/16)
1.0
(1/16)
1.0
(1/16)
2.0
(1/16)
0.0–4.0
(0–3/16)
0.3–4.0
(1/64–3/16)
0.2–4.0
(1/64–3/16)
0.2–4.0
(1/64–3/16)
1.0–4.0
(1/16–3/16)
Yes
Yes
Yes
Yes
Reverse No
(J)
Reinforcement Yes
(J)
Reinforcement Yes
(J)
Reinforcement No
(J)
No Reinforcement No
Walking Foot
Overcasting stitch
72
12
13
14
15
16
G Overcasting on thick fabrics
Overcasting on thick fabrics and
G
decorative stitching
J Overcasting on stretch fabrics
Overcasting on thick or stretch
J
fabrics
Overcasting on stretch fabrics
J
and decorative stitching
5.0
(3/16)
5.0
(3/16)
5.0
(3/16)
5.0
(3/16)
4.0
(3/16)
2.5–5.0
(3/32–3/16)
3.5–5.0
(1/8–3/16)
0.0–7.0
(0–1/4)
0.0–7.0
(0–1/4)
0.0–7.0
(0–1/4)
2.5
(3/32)
2.5
(3/32)
2.5
(3/32)
2.5
(3/32)
4.0
(3/16)
1.0–4.0
(1/16–3/16)
1.0–4.0
(1/16–3/16)
0.5–4.0
(1/32–3/16)
0.5–4.0
(1/32–3/16)
1.0–4.0
(1/16–3/16)
No Reinforcement No
No Reinforcement No
Yes
Reinforcement No
(J)
Yes
Reinforcement No
(J)
Yes
Reinforcement No
(J)
Page 75
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Stitch Name Pattern
Blind hem stitch
Appliqué stitch
Shell tuck stitch
Piecing straight stitch
Mock hand-quilting
stitch
Zigzag stitch
(for quilting)
Appliqué stitch
(for quilting)
Quilting stitch
(for stippling)
Satin scallop stitch
Stitch Width
Application
Presser Foot
17
18
19
20
21
22
23
24
25
26
27
Blind hem stitching on
R
mediumweight fabrics
Blind hem stitching on stretch
R
fabrics
J Appliqué stitching
J Shell tuck stitching
Piecing straight stitching (with a
seam allowance of 6.5 mm (1/4
J
inch) from the right edge of the
presser foot)
Piecing straight stitching (with a
seam allowance of 6.5 mm (1/4
J
inch) from the left edge of the
presser foot)
Straight stitch quilting that looks
J
hand-sewn
Appliqué quilting, free-motion
J
quilting, satin stitching
J Attaching appliqués and binding
Quilting background stitching
J
(stippling)
N Scallop stitching
[mm (inch)]
Auto Manual Auto Manual
00 3← – →3
00 3← – →3
3.5
2.5–7.0
(1/8)
(3/32–1/4)
4.0
0.0–7.0
(3/16)
(7/32)
(1/16)
(1/16)
(3/16)
5.5
1.5
0.0
(0)
3.5
(1/8)
1.5
7.0
(1/4)
5.0
(0–1/4)
0.0–7.0
(0–1/4)
0.0–7.0
(0–1/4)
0.0–7.0
(0–1/4)
0.0–7.0
(0–1/4)
0.5–3.5
(1/32–1/8)
1.0–7.0
(1/16–1/4)
2.5–7.0
(3/32–1/4)
Stitch Length
[mm (inch)]
2.0
(1/16)
2.0
(1/16)
2.5
(3/32)
(1/16–3/16)
2.5
(3/32)
(1/64–3/16)
2.0
(1/16)
(1/64–3/16)
2.0
(1/16)
(1/64–3/16)
2.5
(3/32)
(1/16–3/16)
1.4
(1/16)
1.8
(1/16)
(1/16–3/16)
1.6
(1/16)
(1/16–3/16)
0.5
(1/32)
(1/64–1/16)
1.0–3.5
(1/16–1/8)
1.0–3.5
(1/16–1/8)
1.6–4.0
0.2–4.0
0.2–5.0
0.2–5.0
1.0–4.0
0.0–4.0
(0–3/16)
1.0–4.0
1.0–4.0
0.1–1.0
Reverse/
Reinforcement
Stitching
Twin Needle
No Reinforcement No
No Reinforcement No
Yes
Reinforcement No
(J)
Yes
Reinforcement No
(J)
No Reinforcement No
No Reinforcement Yes
No Reinforcement No
No Reinforcement Yes
No Reinforcement No
No Reinforcement No
Yes
Reinforcement No
(J)
Walking Foot
3
Joining stitch
Smocking stitch
Fagoting stitch
Elastic-attaching
stitch
28
29
Patchwork stitching and
J
decorative stitching
Patchwork stitching, decorative
stitching and sewing overcasting
J
on both pieces of fabric, such as
4.0
(3/16)
5.0
(3/16)
0.0–7.0
(0–1/4)
2.5–7.0
(3/32–1/4)
1.2
(1/16)
2.5
(3/32)
0.2–4.0
(1/64–3/16)
1.0–4.0
(1/16–3/16)
Yes
Reinforcement No
(J)
Yes
Reinforcement No
(J)
with tricot
30
31
32
33
34
Patchwork stitching and
J
decorative stitching
Smocking stitching and
J
decorative stitching
Fagoting and decorative
J
stitching
Fagoting and decorative
J
stitching
Attaching elastic to stretch
J
fabrics
5.0
(3/16)
5.0
(3/16)
5.0
(3/16)
5.0
(3/16)
4.0
(3/16)
0.0–7.0
(0–1/4)
0.0–7.0
(0–1/4)
0.0–7.0
(0–1/4)
2.5–7.0
(3/32–1/4)
0.0–7.0
(0–1/4)
1.2
(1/16)
1.6
(1/16)
2.5
(3/32)
2.5
(3/32)
1.0
(1/16)
0.2–4.0
(1/64–3/16)
1.0–4.0
(1/16–3/16)
1.0–4.0
(1/16–3/16)
1.0–4.0
(1/16–3/16)
0.2–4.0
(1/64–3/16)
Yes
Reinforcement No
(J)
Yes
Reinforcement No
(J)
Yes
Reinforcement No
(J)
Yes
Reinforcement No
(J)
Yes
Reinforcement No
(J)
Stitch Setting Chart 73
Page 76
UTILITY STITCHES — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Stitch Name Pattern
Decorative stitch
Stitch Width
Application
Presser Foot
35
36
37
J Decorative stitching
J Decorative stitching
J Decorative stitching
38
39
Decorative stitching and
N
elastic-attaching
Lace sewing, decorative
N
hemming, heirloom stitching,
etc.
40
41
42
Decorative hemming, heirloom
N
stitching, etc.
Decorative hemming on thin,
N
mediumweight and plain weave
fabrics, heirloom stitching, etc.
Decorative hemming on thin,
N
mediumweight and plain weave
fabrics, heirloom stitching, etc.
43
44
Decorative hemming on thin,
N
mediumweight and plain weave
fabrics, heirloom stitching, etc.
Decorative hemming on thin,
N
mediumweight and plain weave
fabrics, heirloom stitching, etc.
45
46
47
Decorative hemming, ribbon
N
threading, heirloom stitching,
etc.
Decorative stitching, smocking
N
stitching, heirloom stitching, etc.
Decorative stitching, smocking
N
stitching, heirloom stitching, etc.
[mm (inch)]
Auto Manual Auto Manual
4.0
0.0–7.0
(3/16)
(3/16)
(7/32)
(3/16)
(15/64)
(3/16)
(3/16)
(3/16)
(3/16)
(3/16)
(15/64)
(3/16)
4.0
5.5
5.0
3.5
(1/8)
6.0
5.0
5.0
5.0
5.0
5.0
6.0
5.0
(0–1/4)
0.0–7.0
(0–1/4)
0.0–7.0
(0–1/4)
1.5–7.0
(1/16–1/4)
1.5–7.0
(1/16–1/4)
1.5–7.0
(1/16–1/4)
1.5–7.0
(1/16–1/4)
1.5–7.0
(1/16–1/4)
1.5–7.0
(1/16–1/4)
1.5–7.0
(1/16–1/4)
1.5–7.0
(1/16–1/4)
1.5–7.0
(1/16–1/4)
1.5–7.0
(1/16–1/4)
Stitch Length
[mm (inch)]
3.0
(1/8)
(1/16–3/16)
2.5
(3/32)
(1/16–3/16)
1.6
(1/16)
(1/16–3/16)
1.0
(1/16)
(1/64–3/16)
2.5
(3/32)
(1/16–3/16)
3.0
(1/8)
(1/16–3/16)
3.5
(1/8)
(1/16–3/16)
4.0
(3/16)
(1/16–3/16)
2.5
(3/32)
(1/16–3/16)
2.0
(1/16)
(1/16–3/16)
3.0
(1/8)
(1/16–3/16)
1.6
(1/16)
(1/16–3/16)
1.6
(1/16)
(1/16–3/16)
2.0–4.0
1.0–4.0
1.0–4.0
0.2–4.0
1.6–4.0
1.5–4.0
1.5–4.0
1.5–4.0
1.5–4.0
1.5–4.0
1.5–4.0
1.0–4.0
1.0–4.0
Reverse/
Reinforcement
Stitching
Twin Needle
No Reinforcement No
Yes
Reinforcement No
(J)
Yes
Reinforcement No
(J)
Yes
Reinforcement No
(J)
No Reinforcement No
No Reinforcement No
No Reinforcement No
Yes
Reinforcement No
(J)
Yes
Reinforcement No
(J)
Yes
Reinforcement No
(J)
Yes
Reinforcement No
(J)
No Reinforcement No
No Reinforcement No
Walking Foot
74
Page 77
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Stitch Name Pattern
Buttonhole stitch
Darning stitch
Bar tack stitch
Button-sewing stitch
Eyelet stitch
Side cutter
*1
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
Application
Presser Foot
Horizontal buttonholes on thin
A
and mediumweight fabrics
Horizontal buttonholes on areas
A
that are subject to strain
Horizontal buttonholes on thick
A
fabrics
Secured buttonholes for fabrics
A
that have backings
Buttonholes for stretch or knit
A
fabrics
A Buttonholes for stretch fabrics
A Bound buttonholes
Keyhole buttonholes for thick or
A
furry fabrics
Keyhole buttonholes for
A
mediumweight and thick fabrics
Horizontal buttonholes for thick
A
or furry fabrics
A Darning mediumweight fabrics
A Darning thick fabrics
Reinforcing openings and areas
A
where the seam easily comes
loose
M Button sewing
Sewing eyelets, for example, on
N
belts
Sewing straight stitches while
S
cutting the fabric
Sewing zigzag stitches while cut-
S
ting the fabric
Overcasting on thin and
S
mediumweight fabrics while cutting the fabric
Overcasting on thick fabrics
S
while cutting the fabric
Overcasting on mediumweight
S
and thick fabrics while cutting
the fabric
Stitch Width
[mm (inch)]
Stitch Length
[mm (inch)]
Auto Manual Auto Manual
5.0
(3/16)
5.0
(3/16)
5.0
(3/16)
5.0
(3/16)
6.0
(15/54)
6.0
(15/54)
5.0
(3/16)
7.0
(1/4)
7.0
(1/4)
7.0
(1/4)
7.0
(1/4)
7.0
(1/4)
2.0
(1/16)
3.5
(1/8)
7.0
(1/4)
0.0
(0)
3.5
(1/8)
3.5
(1/8)
5.0
(3/16)
5.0
(3/16)
3.0–5.0
(1/8–3/16)
3.0–5.0
(1/8–3/16)
3.0–5.0
(1/8–3/16)
3.0–5.0
(1/8–3/16)
3.0–6.0
(1/8–15/64)
3.0–6.0
(1/8–15/64)
0.0–6.0
(0–15/64)
3.0–7.0
(1/8–1/4)
3.0–7.0
(1/8–1/4)
3.0–7.0
(1/8–1/4)
2.5–7.0
(3/32–1/4)
2.5–7.0
(3/32–1/4)
1.0–3.0
(1/16–1/8)
2.5–4.5
(3/32–3/16)
7.0, 6.0, 5.0
(1/4, 15/64,
3/16)
0.0–2.5
(0–3/32)
3.5–5.0
(1/8–3/16)
3.5–5.0
(1/8–3/16)
3.5–5.0
(1/8–3/16)
3.5–5.0
(1/8–3/16)
0.5
0.2–1.0
(1/32)
(1/64–1/16)
0.5
0.2–1.0
(1/32)
(1/64–1/16)
0.5
0.2–1.0
(1/32)
(1/64–1/16)
0.5
0.2–1.0
(1/32)
(1/64–1/16)
1.0
0.5–2.0
(1/16)
(1/32–1/16)
1.5
1.0–3.0
(1/16)
(1/16–1/8)
2.0
0.2–4.0
(1/16)
(1/64–3/16)
0.5
0.3–1.0
(1/32)
(1/64–1/16)
0.5
0.3–1.0
(1/32)
(1/64–1/16)
0.5
0.3–1.0
(1/32)
(1/64–1/16)
2.0
0.4–2.5
(1/16)
(1/64–3/32)
2.0
0.4–2.5
(1/16)
(1/64–3/32)
0.4
0.3–1.0
(1/64)
(1/64–1/16)
––No
7.0, 6.0, 5.0
7.0
(1/4, 15/64,
(1/4)
(3/32)
(1/16)
(1/16)
(3/32)
(3/32)
2.5
1.4
2.0
2.5
2.5
3/16)
0.2–5.0
(1/64–3/16)
0.0–4.0
(0–3/16)
1.0–4.0
(1/16–3/16)
1.0–4.0
(1/16–3/16)
1.0–4.0
(1/16–3/16)
Reverse/
Reinforcement
Stitching
Twin Needle
No
No
No
No
No
No
No
No
No
No
No
No
No
No
Automatic
reinforcement
Automatic
reinforcement
Automatic
reinforcement
Automatic
reinforcement
Automatic
reinforcement
Automatic
reinforcement
Automatic
reinforcement
Automatic
reinforcement
Automatic
reinforcement
Automatic
reinforcement
Automatic
reinforcement
Automatic
reinforcement
Automatic
reinforcement
Automatic
reinforcement
Automatic
reinforcement
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No Reinforcement No
No Reinforcement No
No Reinforcement No
No Reinforcement No
No Reinforcement No
*1: Side cutter is optional.
Walking Foot
3
Stitch Setting Chart 75
Page 78
UTILITY STITCHES — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Other stitches
Stitch Type Pattern
Adjustable
Pattern Size
Stitching Density
Length/width
Adjustable Pattern
Left/Right Flipping
1 2345678910
Presser Foot
Twin Needle
Decorative
stitches
Satin stitches
Cross-stitches
Decorative
satin stitches
Combined
utility stitches
11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29
30
*
1 2345678910
11 12 13 14 15 16
123
4**5**6**7
**
1 23456789
***
12345
6
78910
11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30
NNo - No Yes Yes
N Yes - No Yes Yes
Yes
NNo - No
(**Not
Yes
possible)
Yes
NNo -Yes
(length
Yes
only)
Yes
NNo - No
(
***length
Yes
only)
31 32 33 34 35 36 37 38 39
*Pattern for making adjustment
76
Page 79
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Stitch Type Pattern
Adjustable
Pattern Size
Stitching Density
Adjustable Pattern
Length/width
Left/Right Flipping
1 2345678910
11 12 13 14 15 16 17 18 19 20
Presser Foot
Twin Needle
Character
stitches
(Gothic font)
Character
stitches
(Script font)
21 22 23 24 25 26 27 28 29 30
31 32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49 50
51 52 53 54 55
1 2345678910
11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30
31 32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49 50
51 52 53 54 55
1 2345678910
11 12 13 14 15 16 17 18 19 20
NNo
Large,
Small
No No Yes
N No Large No No Yes
3
Character
stitches
(Outline style)
21 22 23 24 25 26 27 28 29 30
31 32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49 50
51 52 53 54 55
NNo
Large,
No No Yes
Small
Stitch Setting Chart 77
Page 80
UTILITY STITCHES — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Overcasting Stitches
Sew overcasting stitches along the edges of cut fabric to prevent them from fraying. 15 stitches are available for
overcasting. The procedure for sewing overcasting stitches is explained according to the presser foot that is
used.
Sewing overcasting stitches using overcasting foot "G"
Three stitches can be used to sew overcasting with overcasting foot "G".
Stitch Name Pattern Application
Stitch Width
[mm (inch)]
Stitch Length
[mm (inch)]
Presser
Foot
Auto Manual Auto Manual
Overcasting
stitch
11
12
13
Preventing fraying in medium
weight and thin fabrics
Preventing fraying in thick
fabrics and fabrics that fray
easily
3.5
(1/8)
5.0
(3/16)
2.5-5.0
(3/32-3/16)
3.5-5.0
(1/8-3/16)
2.0
(1/16)
2.5
(3/32)
1.0-4.0
(1/16-3/16)
CAUTION
● Be sure to turn off the main power before replacing the presser foot. Otherwise, injuries may
occur if (Start/stop button) is accidentally pressed and the machine starts sewing.
Attach overcasting foot "G".
a
G
Position the fabric with the edge of the fabric
c
against the guide of the presser foot, and then
lower the presser foot lever.
G
• For details, refer to "Replacing the presser
foot" (page 43).
Select a stitch.
b
• For details, refer to "Selecting stitching"
(page 51).
78
a
a Guide
Sew with the edge of the fabric against the
d
presser foot guide.
a
a Needle drop point
Page 81
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Sewing overcasting stitches using zigzag foot "J"
Seven stitches can be used to sew overcasting stitches with zigzag foot "J".
Stitch Name Pattern Application
Zigzag stitch
(center
needle
position)
Zigzag stitch
(right needle
position)
2-point
zigzag stitch
3-point
zigzag stitch
Overcasting
stitch
10
14
15
16
7
Preventing fraying (center
baseline/reverse stitching)
8
Preventing fraying (right
baseline/reinforcement stitching)
9
Preventing fraying in thick
fabrics and stretch fabrics
Preventing fraying in stretch
fabrics
Preventing fraying in thick
fabrics and stretch fabrics
Preventing fraying in stretch
fabrics
Stitch Width
[mm (inch)]
Stitch Length
[mm (inch)]
Auto Manual Auto Manual
3.5
(1/8)
5.0
(3/16)
4.0
(3/16)
0.0-7.0
(0-1/4)
2.5-5.0
(3/32-3/16)
1.5-7.0
(1/16-1/4)
0.0-7.0
(0-1/4)
1.4
(1/16)
1.0
(1/16)
2.5
(3/32)
4.0
(3/16)
0.0-4.0
(0-3/16)
0.3-4.0
(1/64-3/16)
0.2-4.0
(1/64-3/16)
0.5-4.0
(1/32-3/16)
1.0-4.0
(1/16-3/16)
Presser
Foot
3
J
CAUTION
● Be sure to turn off the main power before replacing the presser foot. Otherwise, injuries may
occur if (Start/stop button) is accidentally pressed and the machine starts sewing.
Attach zigzag foot "J".
a
J
• For details on replacing the presser foot, refer
to "Replacing the presser foot" (page 43).
Select a stitch.
b
• For details, refer to "Selecting stitching"
(page 51).
Sew along the edge of the fabric with the
c
needle dropping off the edge at the right.
a
a
a Needle drop point
Overcasting Stitches 79
Page 82
UTILITY STITCHES — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
a
Sewing overcasting stitches using the optional side cutter
Using the optional side cutter, seam allowances can be finished while the edge of the fabric is cut off. Five
stitches can be used to sew overcasting stitches with the side cutter.
Stitch Name Pattern Application
63
64
65
Side cutter
66
67
Sewing straight stitches while
cutting the fabric
Sewing zigzag stitches while
cutting the fabric
Preventing fraying in thin and
mediumweight fabrics while
cutting the fabric
Preventing fraying in thick
fabrics while cutting the fabric
Preventing fraying in thick
Stitch Width
[mm (inch)]
Auto Manual Auto Manual
0.0
(0)
3.5
(1/8)
5.0
(3/16)
0.0-2.5
(0-3/32)
3.5-5.0
(1/8-3/16)
Stitch Length
[mm (inch)]
2.5
(3/32)
1.4
(1/16)
2.0
(1/16)
2.5
(3/32)
Presser
Foot
0.2-5.0
(1/64-3/16)
0.0-4.0
(0-3/16)
S
1.0-4.0
(1/16-3/16)
fabrics while cutting the fabric
CAUTION
● Be sure to turn off the main power before replacing the presser foot. Otherwise, injuries may
occur if (Start/stop button) is accidentally pressed and the machine starts sewing.
Position the side cutter so that side cutter pin
c
is aligned with the notch in the presser foot
holder, and then slowly lower the presser foot
lever.
Note
z Thread the needle manually when using the
side cutter, or only attach the side cutter
a
after threading the needle using the needle
threader.
Remove the presser foot.
a
• For details on replacing the presser foot, refer
to "Replacing the presser foot" (page 43).
a Notch in presser foot holder
b Pin
X The side cutter is attached.
Hook the connecting fork of the side cutter
b
onto the needle clamp screw.
b
a Connecting fork
b Needle clamp screw
80
b
Page 83
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Raise the presser foot lever to check that the
d
side cutter is securely attached.
Pass the upper thread under the side cutter,
e
and then pull it out toward the rear of the
sewing machine.
Select a stitch.
f
• For details, refer to "Selecting stitching"
(page 51
).
Position the fabric in the side cutter.
h
The cut in the fabric should be positioned over
the guide plate of the side cutter.
a
a Guide plate
Memo
z If the fabric is not positioned correctly, the
fabric will not be cut.
Lower the presser foot lever, and then start
i
sewing.
3
Make a cut of about 2 cm (3/4 inch) long in
g
the fabric at the beginning of the stitching.
1
a 2 cm (3/4 inch)
X A seam allowance is cut while the stitching
is sewn.
Memo
z If the stitching is sewn in a straight line
63
, the seam allowance will be about 5
mm (3/16 inch).
1
a 5 mm (3/16 inch)
z The side cutter can cut as much as one layer
of 13-oz. denim.
z After using the side cutter, clean to remove
any lint or dust.
z If the side cutter can no longer cut fabric,
use a rag to apply a small amount of oil to
the cutting edge of the cutter.
Overcasting Stitches 81
Page 84
UTILITY STITCHES — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Basic Stitching
Straight stitches are used for sewing plain seams. Five stitches are available for basic stitching.
Stitch Name Pattern Application
Basting stitch
Straight stitch
(left needle
position)
Straight stitch
(center
needle
position)
Triple stretch
stitch
6
Temporarily securing
Basic stitching and sewing
1
gathers or pintucks (left baseline/
reverse stitching)
Basic stitching and sewing
2
gathers or pintucks (left baseline/
reinforcement stitching)
Basic stitching and sewing
3
gathers or pintucks (center
baseline/reverse stitching)
4
Reinforcing seams and sewing
stretch fabrics
Stitch Width
[mm (inch)]
Auto Manual Auto Manual
0.0
(0)
0.0-7.0
(0-1/4)
3.5
(1/8)
0.0
(0)
Stitch Length
[mm (inch)]
--
0.2-5.0
(1/64-3/16)
2.5
(3/32)
1.5-4.0
(1/16-3/16)
Presser
Foot
CAUTION
● Be sure to turn off the main power before replacing the presser foot. Otherwise, injuries may
occur if (Start/stop button) is accidentally pressed and the machine starts sewing.
J
Basting
Attach zigzag foot "J".
a
• For details on replacing the presser foot, refer
to "Replacing the presser foot" (page 43).
J
Select stitch 6.
b
• For details, refer to "Selecting stitching"
(page 51).
Start sewing.
c
• For details, refer to "Starting to sew" (page 55).
82
Basic stitching
Baste or pin together the fabric pieces.
a
Attach zigzag foot "J".
b
J
• For details on replacing the presser foot, refer
to "Replacing the presser foot" (page 43).
Select a stitch.
c
•
For details, refer to "Selecting stitching"
page 51
(
).
Page 85
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Lower the needle into the fabric at the
d
beginning of the stitching.
Start sewing.
e
• For details, refer to "Starting to sew" (page
55).
• For details on sewing reverse/reinforcement
stitches, refer to "Securing the stitching" (page
57).
When sewing is finished, cut the thread.
f
• For details, refer to "Cutting the thread" (page
59).
■ Changing the needle position
The needle position used as the baseline is
different for the straight stitch (left needle position)
and the straight stitch (center needle position).
a
a Straight stitch (left needle position)
b Straight stitch (center needle position)
b
When the stitch width of the straight stitch (left
needle position) is set to its standard setting (0.0
mm), the distance from the needle position to
the right side of the presser foot is 12 mm (1/2
inch). If the stitch width is changed (between 0
and 7.0 mm (1/4 inch)), the needle position will
also change. By changing the stitch width and
sewing with the right side of the presser foot
aligned with the edge of the fabric, a seam
allowance can be sewn with a fixed width.
3
0.0 2.0 5.5 7.0
a Stitch width setting
b Distance from the needle position to the right
side of the presser foot
c 12.0 mm (1/2 inch)
d 10.0 mm (3/8 inch)
e 6.5 mm (1/4 inch)
f 5.0 mm (3/16 inch)
• For details, refer to "Adjusting the stitch
width" (page 61).
Basic Stitching 83
Page 86
UTILITY STITCHES — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Blind Hem Stitching
Secure the bottoms of skirts and pants with a blind hem. Two stitches are available for blind hem stitching.
Stitch Name Pattern Application
Blind hem
stitch
17
18
Blind hem stitching on
mediumweight fabrics
Blind hem stitching on stretch
Stitch Width
[mm (inch)]
Auto Manual Auto Manual
00 3← – →3
Stitch Length
[mm (inch)]
2.0
(1/16)
Presser
Foot
1.0-3.5
(1/16-1/8)
fabrics
CAUTION
● Be sure to turn off the main power before replacing the presser foot. Otherwise, injuries may
occur if (Start/stop button) is accidentally pressed and the machine starts sewing.
Sew a blind hem according to the following procedure.
Memo
z When the size of cylindrical pieces is too small to slide onto the arm or the length is too short, the
fabric will not feed and desired results may not be achieved.
Reverse the skirt or pants.
a
a
Use a chalk to mark on the fabric about 5 mm
c
(3/16 inch) from the edge of the fabric, and
then baste it .
R
a Right side of fabric
b Bottom side
Fold the fabric along the desired edge of the
b
hem, and press.
1
1
S< Seen from the side>
a Wrong side of fabric
b Right side of fabric
2
2
2
84
b
S< Seen from the side>
a Wrong side of fabric
b Right side of fabric
c Edge of fabric
d Basting stitching
e 5 mm (3/16 inch)
Page 87
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Fold back the fabric inside along the basting.
d
2
4
1
1
S< Seen from the side>
a Wrong side of fabric
b Edge of fabric
c Basting
d 5 mm (3/16 inch)
Unfold the edge of fabric, and position the
e
fabric with the wrong side facing up.
1
1
3
3
Remove the flat bed attachment and make
h
free-arm sewing possible.
• For details on free-arm sewing, refer to "Freearm sewing" (page 46).
Slide the item that you wish to sew onto the
i
arm, make sure that the fabric feeds correctly,
and then start sewing.
a
a Arm
Position the fabric with the edge of the folded
j
hem against the guide of the presser foot, and
then lower the presser foot lever.
R
3
2
1
S< Seen from the side>
a Wrong side of fabric
b Basting
c Edge of fabric
1
Attach blind hem foot "R".
f
R
• For details on replacing the presser foot, refer
to "Replacing the presser foot" (page 43).
Select a stitch.
g
• For details, refer to "Selecting stitching" (page
51).
1
a Wrong side of fabric
b Fold of hem
c Guide
Adjust the stitch width until the needle slightly
k
catches the fold of the hem.
b
c
R
1
a Needle drop point
When you change the needle drop point, raise
the needle, and then change the stitch width.
a
a Stitch width
Blind Hem Stitching 85
Page 88
UTILITY STITCHES — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
■ If the needle catches too much of the hem
fold
The needle is too far to the left.
Press to decrease the stitch width so that
the needle slightly catches the fold of the hem.
1 2
a Wrong side of fabric
b Right side of fabric
■ If the needle does not catch the hem fold
The needle is too far to the right.
Press to increase the stitch width so that the
needle slightly catches the fold of the hem.
1 2
a Wrong side of fabric
b Right side of fabric
Memo
z For details, refer to "Adjusting the stitch
width" (page 61).
Sew with the fold of the hem against the
l
presser foot guide.
Remove the basting stitching and reverse the
m
fabric.
1
a Wrong side of fabric
b Right side of fabric
2
86
Page 89
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Buttonhole Stitching/Button Sewing
Buttonholes can be sewn and buttons can be sewn on. 10 stitches are available for sewing one-step buttonholes,
and one stitch is available for attaching the button.
Stitch Name Pattern Application
Buttonhole
stitch
48
49
50
51
52
53
54
55
56
57
Horizontal buttonholes on thin
and mediumweight fabrics
Horizontal buttonholes on areas
that are subject to strain
Horizontal buttonholes on thick
fabrics
Buttonholes with bar tacks on
both ends for stabilized fabrics
Buttonholes for stretch or knit
fabrics
Buttonholes for stretch fabrics
Bound buttonholes
Keyhole buttonholes for thick or
plush fabrics
Keyhole buttonholes for
mediumweight and thick fabrics
Horizontal buttonhole for thick
or plush fabrics
Stitch Width
[mm (inch)]
Stitch Length
[mm (inch)]
Auto Manual Auto Manual
5.0
(3/16)
6.0
(15/64)
5.0
(3/16)
7.0
(1/4)
3.0-5.0
(1/8-3/16)
3.0-6.0
(1/8-15/64)
0.0-6.0
(0-15/64)
3.0-7.0
(1/8-1/4)
0.5
(1/32)
1.0
(1/16)
1.5
(1/16)
2.0
(1/16)
0.5
(1/32)
0.2-1.0
(1/64-1/16)
0.5-2.0
(1/32-1/16)
1.0-3.0
(1/16-1/8)
0.2-4.0
(1/64-3/16)
0.3-1.0
(1/64-1/16)
Presser
Foot
3
A
Button-sewing
stitch
61
Button sewing
3.5
(1/8)
2.5-4.5
(3/32-3/16)
--M
Buttonhole Stitching/Button Sewing 87
Page 90
UTILITY STITCHES — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Buttonhole sewing
The maximum buttonhole length is about 28 mm (1-1/8 inches) (diameter + thickness of the button).
Buttonholes are sewn from the front of the presser foot to the back, as shown below.
1
1
1
1
a Reinforcement stitching
CAUTION
● Be sure to turn off the main power before replacing the presser foot. Otherwise, injuries may
occur if (Start/stop button) is accidentally pressed and the machine starts sewing.
The names of parts of buttonhole foot "A", which is
used for sewing buttonholes, are indicated below.
1
2
5
6
3
4
A
a Button guide plate
b Presser foot scale
c Pin
d Reference marks
e 5 mm (3/16 inch)
f Bracket
Use chalk to mark on the fabric the position
a
and length of the buttonhole.
1
a Marks on fabric
b Buttonhole sewing
2
88
Page 91
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Pull out the button guide plate of buttonhole
b
foot "A", and then insert the button that will be
put through the buttonhole.
■ If the button does not fit in the button guide
plate
Add together the diameter and thickness of the
button, and then set the button guide plate to the
calculated length. (The distance between the
markings on the presser foot scale is 5 mm (3/16
inch).)
a
b
c
Select a stitch.
d
• For details, refer to "Selecting stitching" (page
51).
Position the fabric with the front end of the
e
buttonhole mark aligned with the red marks on
the sides of the buttonhole foot, and then
lower the presser foot lever.
a
3
a Presser foot scale
b Length of buttonhole (diameter + thickness of
button)
c 5 mm (3/16 inch)
Example:
For a button with a diameter of 15 mm (9/16
inch) and a thickness of 10 mm (3/8 inch), the
button guide plate should be set to
25 mm (1inch) on the scale.
10mm
15mm
a 10 mm (3/8 inch)
b 15 mm (9/16 inch)
X The size of the buttonhole is set.
Attach buttonhole foot "A".
c
• For details on replacing the presser foot, refer
to "Replacing the presser foot" (page 43).
b
A
a Mark on fabric (front)
b Red marks on buttonhole foot
• Pass the upper thread down through the hole
in the presser foot.
Buttonhole Stitching/Button Sewing 89
Page 92
UTILITY STITCHES — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Raise the presser foot lever, remove the fabric,
Note
h
and then cut the threads.
z Do not lower the needle into fabric when
aligning the marks. Desired results may not
be achieved.
Raise the buttonhole lever to its original
i
position.
z When lowering the presser foot, do not push
in the front of the presser foot.
Insert a pin along the inside of one bar tack at
j
the end of the buttonhole stitching to prevent
the stitching from being cut.
1
a Do not reduce the gap.
Pull down the buttonhole lever as far as
f
possible.
a Buttonhole lever
a
a
The buttonhole lever is positioned behind the
bracket on the buttonhole foot.
a
a Buttonhole lever
b Bracket
Gently hold the end of the upper thread in
g
your left hand, and then start sewing.
b
a Pin
Use the seam ripper to cut towards the pin and
k
open the buttonhole.
a
a Seam ripper
For keyhole buttonholes, use the eyelet punch
to make a hole in the rounded end of the
buttonhole, and then use the seam ripper to cut
open the buttonhole.
a
X Once sewing is completed, the machine
automatically sews reinforcement stitches,
then stops.
90
a Eyelet punch
Note
z When using the eyelet punch, place thick
paper or some other protective sheet under
the fabric before punching the hole in the
fabric.
Page 93
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
■ Sewing buttonholes on stretch fabrics
CAUTION
● When opening the buttonhole with the
seam ripper, do not place your hands in
the cutting path, otherwise injuries may
When sewing buttonholes on stretch or loosely
woven fabrics, use a gimp thread.
Hook the gimp thread onto the part of
a
buttonhole foot "A" shown in the illustration.
result if the seam ripper slips.
● Do not use the seam ripper in any other
way than how it is intended.
■ Changing the density of the stitching
Adjust the stitch length.
It fits into the grooves, and then loosely tie it.
b
Memo
z For details, refer to "Adjusting the stitch
length" (page 62).
z If the fabric does not feed (for example, if it
is too thick), decrease the density of the
stitching.
3
■ Changing the stitch width
Adjust the stitch width.
Memo
z For details, refer to "Adjusting the stitch
width" (page 61).
z Before sewing buttonholes, check the stitch
length and width by sewing a trial
buttonhole on a scrap piece of fabric.
Attach buttonhole foot "A".
c
• For details on replacing the presser foot, refer
to "Replacing the presser foot" (page 43).
Select stitch
d
Adjust the stitch width to the thickness of the
e
gimp thread.
Lower the presser foot lever and the
f
buttonhole lever, and then start sewing.
When sewing is finished, gently pull the gimp
g
thread to remove any slack.
Use a handsewing needle to pull the gimp
h
thread to the wrong side of the fabric, and
then tie it.
52
or
53
.
Buttonhole Stitching/Button Sewing 91
Page 94
UTILITY STITCHES — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Adjust the stitch width so that it is the same as
e
Button sewing
the distance between the holes in the button.
Buttons can be sewn on with the sewing machine.
Buttons with two or with four holes can be attached.
Measure the distance between the holes in the
a
button to be attached.
Raise the presser foot lever, and then slide the
b
drop feed lever, located at the rear of the
machine on the base, to (to the left as seen
from the rear of the machine).
a
a Drop feed lever (as seen from the rear of the
machine)
X The feed dogs are lowered.
Place the button in the position where it will
f
be sewn, and lower the presser foot lever.
a
a Button
X The button is held in place.
Memo
z When attaching four-hole buttons, first sew
the two holes closest to you. Then, slide the
button so that the needle goes into the two
holes toward the rear of the sewing
machine, and then sew them in the same
way.
Attach button-fitting foot "M".
c
• For details on replacing the presser foot, refer
to "Replacing the presser foot" (page 43).
Select stitch 61 .
d
• For details, refer to "Selecting stitching" (page
51).
Note
z Since the end of the thread will be tied off
later, do not set the sewing machine for
programmed-thread cutting.
Turn the handwheel toward you
g
(counterclockwise) to check that the needle
correctly goes into the two holes of the button.
Adjust the stitch width to the distance between
the button holes.
CAUTION
● When sewing, be sure that the needle
does not touch the button, otherwise the
needle may bend or break.
92
Page 95
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Start sewing.
h
Set the sewing speed controller to the left (so
that the speed will be slow).
X The sewing machine automatically stops
after sewing reinforcement stitches.
Note
z Do not press (Thread cutter button).
Pull the upper thread at the end of the
i
stitching to the wrong side of the fabric, and
then tie it with the bobbin thread.
Use scissors to cut the upper thread and the
bobbin thread at the beginning of the stitching.
When you are finished attaching t he button, slide the drop feed lever to (to the right as seen from the rear of the machine ).
3
When you have finished attaching the button,
j
slide the drop feed lever to (to the right
as seen from the rear of the machine) and turn
the handwheel to raise the feed dogs.
Memo
z The drop feed lever is normally set to the
right side.
Buttonhole Stitching/Button Sewing 93
Page 96
UTILITY STITCHES — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Zipper Insertion
A zipper can be inserted.
Stitch Name Pattern Application
Straight stitch
(center
needle
position)
Attaching zippers
3
Sewing concealed seams and
pintucks
Stitch Width
[mm (inch)]
Auto Manual Auto Manual
3.5
(1/8)
0.0-7.0
(0-1/4)
Stitch Length
[mm (inch)]
2.5
(3/32)
0.2-5.0
(1/64-3/16)
Presser
Foot
I
CAUTION
● Be sure to turn off the main power before replacing the presser foot. Otherwise, injuries may
occur if (Start/stop button) is accidentally pressed and the machine starts sewing.
There are many methods for inserting zippers. The procedures for inserting a centered zipper and a side zipper
are described below.
Using a basting stitch, continue sewing to the
c
Inserting a centered zipper
Stitching is sewn on both pieces of fabric butted
against each other.
2
1
edge of the fabric.
1
3
2
4
3
a Right side of fabric
b Stitching
c End of zipper opening
Attach zigzag foot "J".
a
J
• For details on replacing the presser foot, refer
to "Replacing the presser foot" (page 43).
Sew straight stitches up to the zipper opening.
b
With the right sides of the fabric facing each
other, sew reverse stitches after reaching the
zipper opening.
• For details, refer to "Basic stitching" (page
82).
94
a Basting stitching
b Reverse stitches
c Wrong side of fabric
d End of zipper opening
Press open the seam allowance from the
d
wrong side of the fabric.
1
a Wrong side of fabric
Page 97
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Align the seam with the center of the zipper,
e
and then baste the zipper in place.
2
1
3
a Wrong side of fabric
b Basting stitching
c Zipper
Remove about 5 cm (2 inches) from the end of
f
the basting on the outside.
2
3
a Wrong side of fabric
b Zipper basting
c Outside basting
d 5 mm (2 inches)
Attach the presser foot holder to the right pin
g
of zipper foot "I".
4
1
a
Select stitch 3 .
h
• For details, refer to "Selecting stitching"
(page 51).
CAUTION
● When using zipper foot "I", be sure to
select the straight stitch (center needle
position), and slowly turn the handwheel
toward you (counterclockwise) to check
that the needle does not touch the presser
foot. If a different stitch is selected or the
needle hits the presser foot, the needle
may bend or break.
Topstitch around the zipper.
i
1
2
3
4
3
I
b
a Pin on the right side
b Needle drop point
• For details on replacing the presser foot, refer
to "Replacing the presser foot" (page 43).
a Stitching
b Right side of fabric
c Basting stitching
d End of zipper opening
CAUTION
● When sewing, be sure that the needle
does not touch the zipper, otherwise the
needle may bend or break.
Remove the basting stitching.
j
Zipper Insertion 95
Page 98
UTILITY STITCHES — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Press open the seam allowance from the
d
Inserting a side zipper
wrong side of the fabric.
Stitching is visible on only one piece of fabric. Use
this type of zipper application for side openings and
back openings.
1
2
3
a Stitching
b Right side of fabric
c End of zipper opening
The following procedure will describe how to stitch
on the left side, as shown in the illustration.
Attach zigzag foot "J".
a
J
1
a Wrong side of fabric
Press the seam allowance so that the right side
e
(the side that will not be stitched) has an extra
3 mm (1/8 inch).
1
2
a Wrong side of fabric
b 3 mm (1/8 inch)
Align the zipper teeth with the pressed edge of
f
the fabric having the extra 3 mm (1/8 inch),
and then baste or pin the zipper in place.
• For details on replacing the presser foot, refer
to "Replacing the presser foot" (page 43).
Sew straight stitches up to the zipper opening.
b
With the right sides of the fabric facing each
other, sew reverse stitches after reaching the
zipper opening.
• For details, refer to "Basic stitching" (page
82).
Using a basting stitch, continue sewing to the
c
edge of the fabric.
1
3
2
4
a Basting stitching
b Reverse stitches
c Wrong side of fabric
d End of zipper opening
2
1
a Zipper teeth
b Basting stitching
Attach the presser foot holder to the right pin
g
of zipper foot "I".
If the stitching will be sewn on the right side,
attach the presser foot holder to the left pin of
the zipper foot.
a
I
b
a Pin on the right side
b Needle drop point
• For details on replacing the presser foot, refer
to "Replacing the presser foot" (page 43).
96
Page 99
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Select stitch 3 .
h
• For details, refer to "Selecting stitching"
(page 51).
CAUTION
● When using zipper foot "I", be sure to
select the straight stitch (center needle
position), and slowly turn the handwheel
toward you (counterclockwise) to check
that the needle does not touch the presser
foot. If a different stitch is selected or the
needle hits the presser foot, the needle
may bend or break.
Sew the zipper to the piece of fabric with the
i
extra 3 mm (1/8 inch), starting from the base
of the zipper.
When you are about 5 cm (2 inches) from the
j
end of the zipper, stop the sewing machine
with the needle lowered (in the fabric), and
then raise the presser foot lever.
Open the zipper and continue sewing.
k
Close the zipper, turn over the fabric, and then
l
baste the other side of the zipper to the fabric.
1
3
CAUTION
● When sewing, be sure that the needle
does not touch the zipper, otherwise the
needle may bend or break.
a Basting stitching
Attach the presser foot holder to the left pin of
m
zipper foot "I".
If the presser foot holder was attached to the left
pin in step
g, change it to the right pin.
a
I
b
a Pin on the left side
b Needle drop point
Zipper Insertion 97
Page 100
UTILITY STITCHES — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Topstitch around the zipper.
n
Sew reverse stitches at the end of the zipper
opening and align the zipper teeth with the side
of the presser foot.
3
2
4
1
a Right side of fabric
b End of zipper opening
c Reverse stitches
d Beginning of stitching
e Basting stitching
5
CAUTION
● When sewing, be sure that the needle
does not touch the zipper, otherwise the
needle may bend or break.
When you are about 5 cm (2 inches) from the
o
end of the zipper, stop the sewing machine
with the needle lowered (in the fabric), and
then raise the presser foot lever.
Remove the basting stitching, open the zipper,
p
and then continue sewing.
98
Loading...
