Bridgestone B812A Users Manual

B-TAG

Bridgestone Intelligent Tag
MODEL B812

User’s Manual

System organization
About B-TAG

The B-TAG (Bridgestone Intelligent TAG system (below, it calls “the system” or “this system”), with the
sensor which is installed inside the tire, measures the tire pressure and temperature.

－ The organization and the function －

This system consists of the sensor, the receiver the ECU, the indicator, the hand-held reader and the
tag reader, uses with the kind of configuration which is shown in the figure.
