Breville BOV670BSS Instruction Handbook

the Smart Oven

Instruction Book - BOV670

®

Compact Convection

Contents

BREVILLE
RECOMMENDS

2 Breville recommends safety first
8 Components
10 Quick Start Guide
14 Assembly

- Preparing the oven for use

- A note on cooking times

- A note on rack height positions

- A note on STANDBY mode

- A note on optional settings

18 Functions

- TOAST function

- BAGEL function

- BAKE function

- ROAST function

- BROIL function

- PIZZA function

- COOKIE function

- REHEAT function
35 Care and cleaning
37 Troubleshooting

SAFETY FIRST

At Breville we are very safety
conscious. We design and
manufacture consumer
products with the safety of you,
our valued customer, foremost
in mind. In addition we ask
that you exercise a degree of
care when using any electrical
appliance and adhere to the
following precautions.

IMPORTANT
SAFEGUARDS

READ ALL INSTRUCTIONS
BEFORE USE AND SAVE
FOR FUTURE REFERENCE

• Remove and safely discard
any packing materials and
promotional labels before
using the oven for the first time.

• To eliminate a choking hazard
for young children, remove and
safely discard the protective
cover fitted to the power plug
of this appliance.

2

• Do not place the oven near the
edge of a bench or table during
operation. Ensure the surface
is level, clean and free of water,
flour, etc.

• Always operate the oven on
a stable, heat resistant surface.
Do not use on a cloth-covered
surface, near curtains or other
flammable materials.

• A fire may occur if the oven is
covered or touches flammable
material, including curtains,
draperies, walls, and the like,
when in operation.

• Do not place the oven on
or near a hot gas or electric
burner, or where it could touch
another heated oven.

• Do not let the power cord hang
over the edge of a table or
counter, or touch hot surfaces.

• To protect against electric
shock do not immerse the oven,
power cord or power plug in
water or any other liquid.

• When operating the oven,
keep a minimum distance of
4" (10cm) of space on both
sides of the appliance.
This will allow for adequate
air circulation and help
prevent the possibility of wall
discoloration due to radiated
heat.

• Do not touch hot surfaces.
Appliance surfaces, including
the door and outer surface of
the oven are hot during and
after operation. To prevent
burns or personal injury, always
use protective hot pads or
insulated oven mitts, or use
handles and knobs where
available, when inserting,
removing or handling items
from the oven. Alternatively,
allow the oven to cool down
before handling.

• Extreme caution must be used
when removing pans, dishes
and accessories such as the
included broil rack and baking
pan, that contain hot oil or
other hot liquids.

• The glass of the oven door
has been specially treated to
make it stronger, more durable
and safer than ordinary glass,
however it is not unbreakable.
If struck extremely hard, it may
break or weaken, and could at
a later time, shatter into many
small pieces without apparent
cause.

• Do not leave the door standing
open for extended periods
of time when the oven is
turned ON.

3

• The top of the oven is very hot
during and after operation.
Do not store any item on top
of the oven when in operation.
The only exceptions are
described on Page 34 - one
layer of ceramic plates for
warming, and the any accessory
provided by Breville for use in
the ribbed section on top of the
oven. If the ribbed section is
used as a warming tray during
operation, protective hot pads
or insulated oven mitts should
be used when removing heated
items. Alternatively, allow
the oven to cool down before
handling.

• Do not place cardboard, plastic,
paper, or other flammable
materials in the oven.

• Caution should be exercised
when cooking foods with
high oil content such as pine
nuts and walnuts. Broiling
these foods, cooking them for
extended periods of time or at
high temperatures may create
a fire risk.

• In the event that any foods
catch fire in the oven, keep
the oven door closed. Turn the
oven off and unplug from the
power outlet. Wait until the fire
goes out before opening the
oven door.

• Caution should be exercised
when using pans and dishes
constructed of materials other
than metal. If using ceramic
or glass pans or dishes it is
important that they are oven
safe to prevent cracking.

• Caution should be exercised
when using lids in the oven, as
pressure build up in a covered
pan or dish may cause hot
ingredients to expel or the dish
to crack.

• Oversized foods and metal
utensils must not be inserted in
the oven as they may create fire
or risk of electric shock.

• Metal utensils such as knives
should not be inserted in the
oven to remove food residue
from the quartz tube elements.
This can damage the elements
as well as lead to electrocution.

• It is recommended to use only
the accessories supplied with
this oven. When broiling, the
broil rack must be inserted into
the supplied baking pan.

• The use of any accessory
attachments not recommended
by Breville may cause injuries.

• Do not use the toast function
for purposes other than
toasting foods.

• Do not place hands inside the
oven during operation.

4

• This appliance is for household
use only.

• Do not use the appliance
for anything other than its
intended purpose as described
in this booklet. Do not use
outdoors. Do not use in moving
vehicles or boats.

• Do not attempt to operate the
oven by any method other than
those described in this booklet.

• Do not leave the appliance
unattended when in use.

• Close supervision is necessary
when the appliance is used by
or near children.

• This appliance is not
intended for use by persons
(including children) with
reduced physical, sensory
or mental capabilities or
lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning use
of the appliance by a person
responsible for their safety.

• To turn OFF the oven, press the
START/CANCEL button on
the control panel. The oven is
OFF when the button surround
illumination is OFF and LCD
is blue.

• To disconnect from the wall
outlet, first turn OFF the oven,
and then remove the power
plug from the wall outlet.

• When the oven is not in use
or when left unattended,
disconnect the oven from the
wall outlet.

• Before attempting to move the
oven, or before assembling or
disassembling parts, cleaning
or storing, turn OFF the oven,
allow to cool, and disconnect
from the wall outlet.

• Strictly follow the Care and
Cleaning instructions on Page

35. Do not clean with metal
scouring pads. Pieces can break
off the pad and touch electrical
parts, creating a risk of electric
shock.

• Regularly clean the crumb tray
to discard crumbs. Ensure to
turn OFF the oven, remove the
power plug from the wall outlet
and allow the oven to cool
before pulling the crumb tray
out.

• Always ensure the crumb
tray is thoroughly dried after
cleaning. Ensure to re-insert the
crumb tray before operating
the oven.

• Do not cover crumb tray or any
part of the oven with metal foil.
This will cause overheating of
the oven.

5

• Do not store any materials
other than the supplied
accessories in the oven when
not in use.

• This appliance is equipped
with a power cord having
a grounding wire with a
grounding plug. The appliance
must be grounded using
a 3-hole properly grounded
outlet. In the event of an
electrical short circuit,
grounding reduces the risk of
electrical shock.

• If the power outlet is a standard
2-prong wall outlet, it is your
personal responsibility and
obligation to have it replaced
with a properly grounded
3-prong wall outlet.

• Do not, under any
circumstances, cut or remove
the third (ground) prong from
the power cord or use an
adapter.

• Consult a qualified electrician
if the grounding instructions
are not completely understood,
or if doubt exists as to whether
the appliance is properly
grounded.

• The installation of a residual
current device (safety switch)
is recommended to provide
additional safety protection
when using electrical
appliances. It is advisable that
a safety switch with a rated
residual operation current
not exceeding 30mA be
installed in the electrical circuit
supplying the appliance.
See your electrician for
professional advice.

• Regularly inspect the
supply cord, plug and actual
appliance for any damage.
Do not operate if damaged in
anyway or after the appliance
malfunctions. Immediately
cease use of the appliance
and visit www.Breville.com
or call Breville Consumer
Support at 1-866-BREVILLE
for examination, repair or
adjustment.

• For any maintenance other
than cleaning, visit www.
Breville.com or call Breville
Consumer Support at
1-866-BREVILLE.

6

BREVILLE ASSIST PLUG™

• Your Breville appliance comes
with a unique Assist Plug™,
conveniently designed with
a finger hole in the power
plug for easy and safe removal
from the wall outlet. For safety
reasons it is recommended
you plug your Breville
appliance directly into its own
electrical outlet on a dedicated
circuit separate from other
appliances. If the electric
circuit is overloaded with other
appliances, your appliance
may not function properly.
Use in conjunction with
a power strip or extension
cord is not recommended.

CALIFORNIA
PROPOSITION 65:

(Applicable to California
residents only).

This product contains chemicals
known to the State of California
to cause cancer, birth defects or
other reproductive harm.

SHORT CORD
INSTRUCTIONS

• Your Breville appliance is fitted
with a short power supply
cord as a safety precaution
to prevent personal injury or
property damage resulting
from pulling, tripping or
becoming entangled with
a longer cord. Do not allow
children to use or be near this
appliance without close adult
supervision. If an extension
cord is used, (1) the marked
electrical rating of the cord set
or extension cord should be at
least as great as the electrical
rating of the appliance, (2) the
cord should be arranged so
that it will not drape over the
countertop or tabletop where
it can be pulled on by children
or tripped over unintentionally
and (3) the extension cord must
include a 3-prong grounding
plug.

FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS

7

Components

D

C

A

E
F

G

B

A. 10” x 10” enamel broil rack
B. 10” x 10” enamel baking pan
C. Door handle
D. Ribbed plate warming tray

IMPORTANT

The outer surface of the oven, including the
oven door, is hot during and after operation.
Always use protective hot pads or insulated
oven mitts when inserting, removing or
handling items from the oven.

NOTE

Only place items in the ribbed section on top
of the oven as described on Page 34.

J

K

J

H

I

E. Top rack height position:

BROIL function.

F. Middle rack height position:

TOAST, BAGEL, PIZZA and COOKIE
functions.

G. Bottom rack height position:

BAKE, ROAST and REHEAT functions.

H. Wire rack
I. Crumb tray
J. Ventilation slots
K. Breville Assist® Plug
L. LCD screen
M. START/CANCEL button
N. Function dial
O. CONVECTION Button
P. TEMPERATURE and TIME dial
Q. Temperature conversion button
R. Frozen foods button

(refer to page 17 for instructions)

8

Available accessories sold separately:

L

M

N

O

P

R

Q

IMPORTANT

Do not touch hot surfaces. The outer surface of
the oven, including the oven door, is hot during
and after operation. Allow the oven to cool
down before handling.

NOTE

When the oven is plugged into a power outlet,
the oven alert will sound twice and the LCD
screen will illuminate blue for 10 minutes
before entering STANDBY mode.

Bamboo Cutting Board
Part No: BOV650CB

Bamboo is the ideal material for a cutting
board, as it absorbs very little moisture and
has natural antibacterial properties. Bamboo
is harder than most hardwoods, leaving less
visible knife marks on the board surface.

12” Non-stick Pizza Pan
Part No: BOV650PP12

The non-stick coating is for easy release and
minimised abrasions while the dark color
absorbs heat and helps to effectively crisp the
pizza crust.

9

QUICK START GUIDE

This Quick Start Guide is designed for first time use.

For safety and more information, refer to rest of the Instruction
Booklet.

PREPARING THE OVEN
(A ONE-TIME PROCESS)

In order to remove any protective substances
on the heating elements, it is necessary to run
the oven empty for 15 minutes. Ensure the area
is well ventilated as the oven may emit vapors.
These are safe and not detrimental to the
performance of the oven.

1. Place the oven on a flat, dry surface. Ensure
there is 4” (10cm) of clear space on both
sides of the appliance, there are no items on
top, and the crumb tray has been inserted.

2. Unwind the power cord and insert the
power plug into a power outlet.

3. The oven alert will sound and the LCD
screen will illuminate.

4. Turn the FUNCTION dial until the
indicator reaches the PIZZA function.
The figure on the LCD screen indicates the
preset temperature of ‘400°F’. The preset
FROZEN FOODS setting will also be
displayed.

5. Press the START/CANCEL button
to activate. The button surround will
illuminate red, the oven alert will sound and
the LCD screen will illuminate orange.

6. The LCD screen will indicate a blinking
‘PREHEATING’. Once the oven has reached
the set temperature, the temperature alert
will sound.

7. The timer will be displayed and
automatically begin to count down in one
minute increments.

8. At the end of the cooking cycle, the oven
alert will sound three times.
The START/CANCEL button surround will
no longer illuminate red and LCD screen
will illuminate blue.

9. The oven is now ready to use.

NOTE

When the oven is turned on for the first time,
it may emit vapors. This is due to the protective
substances on the heating elements. These are
safe and not detrimental to the performance of
the oven.

10

OPERATING YOUR BREVILLE SMART
OVEN® COMPACT CONVECTION

The Breville Smart Oven® Compact
Convection features Element IQ® - a cooking
technology that adjusts the power of the
heating elements to cook food more evenly
and quickly. Each of the oven’s functions
are preset with our recommended settings,
however we suggest experimenting with these
depending on the recipe, amount of food and
your personal taste. Your customized setting
will remain in the memory of the oven until
changed or the oven is unplugged from the
power outlet.

1. Insert the wire rack into the recommended
rack height position. These are
conveniently printed on the right hand side
of the oven door’s glass window. The wire
rack should be positioned with the spokes
facing upwards.

2. Turn the FUNCTION dial until the
indicator reaches the desired setting.

3. To change the cooking temperature
or time, press the center of the TEMP/
TIME dial until the LCD screen displays
the corresponding temperature or time
screen. Turn the dial to the left to reduce the
temperature/time or to the right to increase
the temperature/time.

NOTE

The TEMP/TIME dial also functions as the
Darkness and Slice selection control on the
TOAST and BAGEL functions.

Center the food on the wire rack - either
placing directly on the rack or positioned
on the Breville baking pan and broil rack
(see Page 23 of the Instruction Book for
recommended cookware types and sizes).

NOTE

Some functions feature a preheating cycle.
When the START/CANCEL button is pressed,
the LCD screen will indicate a blinking
‘PREHEATING’. Only place food inside the
oven once the LCD screen no longer blinks
‘PREHEATING’ and the temperature alert has
sounded.

4. Close the oven door.

5. Press the START/CANCEL button
to activate. The button surround will
illuminate red, the oven alert will sound and
the LCD screen will illuminate orange.

6. The timer will be displayed and begin to
count down. The cooking temperature and
time can be adjusted during the cooking
cycle.

7. At the end of the cooking cycle, the oven
alert will sound three times. The START/
CANCEL button surround will no longer
illuminate red and LCD screen will
illuminate blue.

NOTE

The cooking cycle can be stopped at any time
by pressing the START/CANCEL button. This
will cancel the cycle and the button surround
illumination will go out.

11

OVEN FUNCTIONS

TOAST FUNCTION:

Evenly toasts bread so it’s crisp and crunchy on
the outside, while soft and moist on the inside.

BAKE FUNCTION:

Bakes cakes, muffins, brownies and pastries
evenly throughout.
Also is ideal for cooking pre-packaged frozen
meals including lasagna and pies.

Rack Position:

Middle

Optional Settings:

FROZEN FOODS button

NOTE

During the toasting cycle, condensation
may form on the oven door and steam may
be emitted. This is normal - caused by the
moisture content of the bread. Freshly baked
and frozen breads generally produce more
condensation and steam.

BAGEL FUNCTION:

Crisps the insides of your cut bagel while only
lightly toasting the outside.

Rack Position:

Middle

Optional Settings:

FROZEN FOODS button

NOTE

The upside of the bagel must always face
upwards towards the top heating elements - so
the top side becomes crisp while the crust is
only lightly toasted.

Rack Position:

Bottom

Optional Settings:

CONVECTION button
TEMPERATURE CONVERSION button

FROZEN FOODS button

ROAST FUNCTION:

Cooks a variety of meats and poultry that
are tender and juicy inside and roasted to
perfection outside.

Rack Position:

Bottom

Optional Settings:

CONVECTION Button

TEMPERATURE CONVERSION button

BROIL FUNCTION:

Ideal for open sandwiches, small cuts of
meat, poultry, fish, sausages and vegetables.
Broiling can also be used to brown the tops of
casseroles and gratins.

Rack Position:

Top

12

Optional Settings:

TEMPERATURE CONVERSION button
