OWNER’S MANUAL
4-in-1 MULTI-USE Mixer
Model EP559V2
COPYRIGHT© EURO-PRO OPERATING LLC 2008
EURO-PRO Operating LLC
Boston, MA, 02465
1 (800) 798-7398
www.euro-pro.com
IMPORTANT SAFETY INSTRUCTIONS
When using your Bravetti Platinum Pro 4-in-1 Multi-Use Mixer, basic safety
precautions should always be observed, including the following:
1. Read all instructions before using the
appliance.
2. Use the appliance only for its intended use.
3. To protect against a risk of electric shock,
do not immerse cord, plug or unit (body of
mixer) in water or other liquids.
4. Never yank cord to disconnect from
outlet; instead, grasp plug and pull to
disconnect.
5. Unplug appliance from outlet when not in
use, before putting on or taking off parts
and before cleaning.
6. Avoid contact with moving parts at all times.
Keep hands, hair, clothing, as well as
spatulas and other utensils away from
beaters during operation to prevent
personal injury and/or damage to the mixer.
7. Do not operate any appliance with a
damaged cord or plug, or after the
appliance malfunctions, or is dropped or
damaged in any manner. To avoid the risk
of electric shock, do not disassemble or
attempt to repair the mixer. Return the
appliance to EURO-PRO Corporation (see
warranty) for examination and repair.
8. Close supervision is necessary for any
appliance being used by or near children.
Do not leave the mixer unattended while
connected.
9. The use of attachments not recommended
or sold by EURO-PRO Operating LLC may
cause fire, electric shock or injury.
10. Do not use outdoors.
11. Do not let cord hang over edge or table or
counter or touch hot surfaces, including the
stove.
12. To avoid injury by accidentally switching on
the appliance when inserting the dough
hooks, beaters, chopper and hand blender
attachment, always set the switch to
position “0” and unplug the appliance
before assembling or disassembling.
Remove beaters, dough hooks, whisk,
hand blender and chopper attachments
from mixer before cleaning.
13. DO NOT USE THIS APPLIANCE ON A
STOVE.
14. When mixing liquids, especially hot liquids,
use a tall container or make small quantities
at a time to reduce spillage.
15. Keep hands and utensils out of the
container while blending to prevent
possibility of severe injury to persons or
damage to the unit. A spatula may be
used but must be used ONLY when the
unit is not running.
16. WARNING! Blades are sharp. Handle
carefully. When handling the chopper
blade, always hold it by the spindle.
17. Make sure that the chopper bowl is
securely locked in place before operating
appliance.
18. Do not attempt to alter the chopper
cover interlock mechanism.
19. The unit is designed for intermittent use.
Do not press the switch down or tamper
with the switch to fix it down over 1
minute for blender or 15 seconds for
chopper to prevent overheating the unit.
20. The beaker may be used only with the
hand blender for processing small
quantities. It should not be used with the
beaters, whisk or dough hooks.
21. To avoid burns, place blender
attachment first in the food to be beaten
or chopped before pressing the switch
button. Always release the button before
removing the blender from the food.
22. Do not place containers in the
microwave.
23. Remove beaters, whisk or dough hooks
from mixer before washing.
IMPORTANT NOTICE
This appliance has a polarized plug (one
blade is wider than the other). To reduce
the risk of electric shock, this plug will fit in
a polarized outlet only one way. If the plug
does not fit fully in the outlet, reverse the
plug . If it still does not fit, contact a
qualified electrician. Do not modify the
plug in any way.
GETTING TO KNOW YOUR
4-IN-1 MULTI-USE MIXER
Congratulations! As the owner of a new Bravetti Platinum Pro ”4-in-1 Multi-Use",
you are about to use a very versatile and powerful kitchen mixing, chopping, and
blending tool. Bravetti Platinum Pro products are engineered to meet the highest
quality standards and are designed to offer the ultimate in ease of operation and
convenience.
17
Main Components
1. Main Stand
2. Main Unit
3. Retractable Power Cord
4. Cord Rewind Button
5. Speed Control Switch
6. Beater Release Button
7. Blender Switch
8. Gear Box
9. Chopping Bowl With Cover
10. Chopper Blade
11. Stick Blender
12. Beaker and Cover
13. Safety Cover
14. Beaters (2)
15. Whisk (1)
16. Dough Hooks (2)
17. Blade Support
Technical Specifications
SAVE THESE INSTRUCTIONS
For Household Use Only
1
Rev. 0202C
Voltage: 120V~ 60Hz.
Power: 550 Watts
2
OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS cont.
Before using your Bravetti Platinum Pro
Multi-Use Mixer for the first time, wash
the beaters, dough hooks, whisk and
containers in warm, sudsy water. Rinse
and dry thoroughly.
Warning: To avoid injury when inserting
or removing beaters, dough hooks,
whisk, hand blender or chopper, always
set the speed selector on ”0" and unplug
the appliance.
Warning: The unit is designed for
intermittent use. The maximum operating
time on settings “0-Max” is 5 minutes
non-stop with beaters, dough hooks, or
whisk. Maximum running time with the
chopper is 3 minutes and with the hand
blender 2 minutes.
Beaters, Dough Hooks, Whisk:
Select the attachment according to the
type of mixing required. Make sure that
the mixer is unplugged from power
source and speed selector is set on ”0"
before inserting or removing beaters,
dough hooks or whisk
.
Beaters:
Use for liquid mixes such as creams,
egg-whites, confectionery doughs, etc.
insert stem end of beaters (one at a time)
into the openings in the mixer. Insert the
beater with the metal ring in the larger of
the two holes. The metal ring on the
beater must sit below the surface of the
mixer housing. To ease the inserting of
the beaters, a slight twisting motion will
aid in engaging the beater drive tabs.
Install the second beater in the same
manner as above. (If there is no ring on
one of your beaters, either beater can be
inserted into either hole of the mixer.)
Dough hooks:
Use for light doughs. Insert dough hooks
in the same way as beaters above. See
installing instructions for beaters above.
Always use both dough hooks. Never try
to work with one beater and one dough
hook at the same time. Do not use
dough hooks at low speeds as this may
cause motor to overheat. When using
dough hooks for heavy or thick dough,
use only high speed (MAX) from the
beginning to prevent the motor from
overheating (blocking).
Whisk:
The whisk is used to beat air into
mixtures such as egg whites, yolks or
cream. To insert whisk: There is only
one whisk provided. Hold whisk at stem
end and insert into one of the holes
until it clicks into place. DO NOT PUSH
WHISK IN FROM THE WIRE END AS
WIRES MAY BE DAMAGED.
Adjustable Speed Control:
The speed control switch provides
variable speed selection.
Please Note
speed ONLY -for
speed selector switch will not
function with the stick blender.
Warning: Never operate the appliance
without all the parts in place. Make sure
that all parts are properly assembled
before turning on the unit.
: The stick blender
operates on one
safety reasons the
Stick Blender:
1. Make sure that the unit is unplugged
from power source before attaching
or removing the stick blender.
2. Remove the unit from the main
stand and open the safety cover.
3. Align the arrow on the stick blender
with the arrow on the main unit.
Once fully inserted, turn clockwise
90º to lock.
Warning: This appliance is designed
for intermittent use. Maximum
running time with the hand blender is
2 minutes. After this time, allow the
unit to cool.
4. To avoid spattering, place the stick
blender first in the food to be beaten
or chopped and then press the
blender switch. Do not use the stick
blender in boiling or very hot
ingredients. Do not use on stove.
5. Always release the blender switch
before removing the stick blender
from the food, especially when using
the stick blender in liquids.
Always hold the unit with your hand
while processing. Never leave unit
unattended while plugged in .
Caution: Do not use the stick
blender on the stove. If you want to
use it in a saucepan while cooking,
you must first remove saucepan from
the stove and allow it to cool before
using the stick blender.
6. To remove the stick blender from
the main unit, first unplug the unit
from the power source and then turn
the stick blender 90º counter
clockwise and pull off.
Beaker:
Use the beaker with with the stick
blender or you can use any other
container.
Do not use the beaker in the microwave
oven.
Do not use the beaker with beaters,
whisk or dough hooks.
The beaker is intended only for
processing small quantities with the stick
blender.
Hand Mixer:
To avoid spattering, always put beaters,
dough hooks or whisk into the ingredients
to be mixed before starting the mixer.
Make sure that the rear safety cover is
properly closed, otherwise, for safety
reasons the unit will not operate.
1. Select the required speed using
your thumb to slide the speed
control switch to the required
position: “0 - Max”.
Low Speeds
starting and blending dry and liquid
ingredients, folding in egg whites or to
break up potatoes for mashing.
are suggested for
Medium speeds are suggested for
beating egg whites, yolks or whole
eggs and whipping cream.
Higher speeds are suggested for all
medium speed applications as well as
light cake batters,and whipping cream
or mashing potatoes. Also for mixing
bread doughs with the dough hooks.
We recommend that you start at low
speed and gradually increase the
speed as required. For difficult or thick
mixtures, use “MAX” speed from the
outset to prevent the motor from
overloading.
Caution: When using dough
hooks for heavy or thick dough, use
only MAX speed from the outset to
prevent the motor from overheating.
Always make sure that the beaters are
free to rotate properly in the container.
Warning: To avoid personal injury
and damage to beaters, do not
attempt to scrape bowl while mixer is
operating , turn mixer OFF. Should
scraper or other object drop into bowl,
turn motor OFF before removing.
To remove beaters, dough
hooks, or whisk
on ’0', unplug unit from power source,
and press the release button to
remove the beaters, dough hooks, or
whisk from the hand mixer. This
button only works if the speed control
switch is set on ’0'.
set speed selector
3
4
OPERATING INSTRUCTIONS cont.
OPERATING INSTRUCTIONS cont.
CHOPPER:
Make sure that the unit is unplugged
from power source and speed control
switch is on ”0" before inserting or
removing the chopper attachment.
Warning: Use extreme caution-
blades are sharp. Always hold the
chopper blade by the spindle.
1. Remove the blade cover from the
chopper blade.
2. Place the blade support into the
chopping bowl ensuring that the
locator pins are engaged.
3. Put the blade assembly on the
blade support of the chopper
bowl .
4. Place the chopper bowl on the antiskid base (bowl cover).
5. Place the food to be chopped in the
bowl.
6. Position the gear box on the
chopper bowl, fitting the grooves on
the gear box and bowl so that they
engage the bowl.
7. Insert the gear box drive shaft
into the corresponding opening on
the bottom of the hand mixer until
the gear box is securely locked in
place.
Drive Shaft
Insert drive
shaft in
small hole
Caution: Always hold the hand
mixer with your hand while
processing. Do not leave the
appliance unattended when plugged
in.
Do not use to chop very hard foods
such as coffee beans or nutmeg.
Use for hard cheese, carrots, onions,
tomatoes, parsley, etc.
Important: To mince meat, cut the
meat into 1" cubes and do not mince
more than 200 grams (7 ounces) at
once. Make sure the meat is fully
defrosted and all bones and gristle
have been removed.
Always allow cooked food to cool
before placing in the chopping bowl.
The anti-skid base can also be used as
a cover for the chopper bowl.
Note: The processing time required
depends upon the type and quantity of
food to be processed and on the
degree of fineness you require. Meat
(200 grams/7 ounces - 1 inch cubes),
hard cheese (100 grams/3 1/2 ounces 1 inch pieces) and carrots (150 grams/5
1/4 ounces - cut in pieces) usually
would require approximately 15
seconds. Onions (quartered) require
approximately 5-10 seconds. Parsley
(stems removed) approximately 15-20
seconds.
ICE CRUSHING:
Caution:
from power outlet before changing
or assembly of accessories.
1. Place the blade support and the
2. Add ice to be crushed. Do not
3. Install the gearbox as per chopping
4. Plug the unit into the power outlet.
5. Firmly hold the chopping bowl with
Always unplug the unit
chopping blade into the chopping
bowl.
attempt to chop more than four or
five ice cubes at a time.
instructions on page 4.
one hand while momentarily
depressing the power switch on the
main unit. Do not run the unit
continuously for more than 4
seconds at a time when crushing
ice. Use short bursts of power.
CLEANING & MAINTENANCE:
• Make sure that the unit is switched
“OFF” and disconnected from
power outlet before cleaning.
• Never immerse the hand mixer or
power cord in water or any other
liquid.
• Beaters, Dough Hooks and
Whisk: Eject beaters, dough hooks
and whisk from mixer and wash in
warm soapy water as soon as
possible after use before foods set
and dry. Rinse and dry after
washing. Beaters, dough hooks and
whisk can be washed in dishwasher.
• Stick Blender Attachment:
caution - blade is sharp. Detach
stick blender from mixer and wash
with warm soapy water. Do not use
any sharp objects to clean residue
under the blade, as this may
damage the housing. Do not wash
in dishwasher.
• Chopper Attachment
caution when handling the chopping
blade. Always hold by the spindle.
Do not immerse the gear box in
water.
• Clean the stand with warm soapy
water.
• The hand mixer unit, power cord
and gear box should be wiped with
a damp cloth and then dried
thoroughly.
• Chopper blade, blade support,
chopper bowl, beaker and anti-skid
base/lids can be put in the
dishwaser.
Use
: Use extra
WARNING: This appliance is
designed for intermittent use.
Maximum running time with chopper is
3 minutes. After 3 minutes, allow the
unit to cool.
5
6
_
_
_
_
Model EP559V2
O N E (1 ) Y E AR L IMITED WAR R ANTY
EURO-PRO Operating LLC warrants this product to be free from defects in material and
wo rkm ansh ip for a perio d of on e (1) y ear fro m th e date of pu rcha se wh en ut ilized for norm al
household use.
If your appliance fails to operate properly while in use under normal household conditions
within the warranty period, return the complete appliance and accessories, freight prepaid. For
Customer Service support, call 1 (800) 798-7398 or visit our website www.euro-pro.com.
If the appliance is found by EURO-PRO Operating LLC to be defective in material or
workmanship, EURO-PRO Operating LLC will repair or replace it free of charge. Proof of
purchase date and $9.95 to cover the cost of return shipping and handling must be included.*
The liability of EURO-PRO Operating LLC is limited solely to the cost of the repair or
replacement of the unit at our option. This warranty does not cover normal wear of parts and
does not apply to any unit that has been tampered with or used for commercial purposes. This
limited warranty does not cover damage caused by misuse, abuse, negligent handling or
damage due to faulty packaging or mishandling in transit.
This warranty is extended to the original purchaser of the unit and excludes all other legal
and/or conventional warranties. The responsibility of EURO-PRO Operating LLC if any, is
limited to the specific obligations expressly assumed by it under the terms of the limited
warranty. In no event is EURO-PRO Operating LLC liable for incidental or consequential
damages of any nature whatsoever. Some states do not permit the exclusion or limitation of
incidental or consequential damages, so the above may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary
from s ta te to s tate .
*Important: Carefully pack item to avoid damage in shipping. Be sure to include proof of
purchase date and to attach tag to item before packing with your name, complete
address and phone number with a note giving purchase information, model number and
what you believe is the problem with item. We recomm end you insure the package (as
damage in shipping is not covered by your warranty). Mark the outside of your package
“ATTENTION CUSTOMER SERVICE”.
Please fill out and mail the product registration card within ten (10) days of purchase. The
reg is tra tio n w ill enable us to contact you in the unlikely event of a product safety notification. By
returning this card you acknowledge to have read and understood the instructions for use, and
warnings set forth in the accompanying instructions.
RETURN TO EURO-PRO O perating LLC, 4400 Bois Franc, St-Laurent, QC, H4S 1A 7
_______________________________________________________________
Model EP559V2
App lian c e mo d el
_______________________________________________________________
Da te p u rc h as e d Na me o f sto re
_______________________________________________________________
Owner’s name
_______________________________________________________________
Address City Prov Postal Code
OWNERSHIP REGISTRATION CARD
FOR CANADIAN CONSUMERS ONLY
Printed in China
Loading...
