P/N: 000-6189 Rev B (10/03/2006)

SelectTech

5.1 Bench

Owner’s/Assembly Manual

Congratulations on your commitment to ﬁtness and your purchase of the Bowflex

SelectTech® 5.1 Bench. Before assembling your Bowflex® SelectTech® 5.1 Bench please read the Owner’s/Assembly Manual and follow the Important Safety Precautions.

Nautilus, Inc. 16400 S.E. Nautilus Drive Vancouver, Washington, USA 98683

1-800-NAUTILUS (1-800-628-8458) Fax (800) 898-9410 Nautilus.com Bowﬂex.com

Table of Contents

Important Safety Precautions . . . . . . . . . . . . . . . . . . . 1

Safety Warning Labels . . . . . . . . . . . . . . . . . . . . . . . . 2

Before You Assemble . . . . . . . . . . . . . . . . . . . . . . . . . 3

Hardware and Tool Guide . . . . . . . . . . . . . . . . . . . . 3

Parts Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Assembly Instructions . . . . . . . . . . . . . . . . . . . . . . . . . 5

Bench Positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Companion Exercise Equipment . . . . . . . . . . . . . . 11

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . 12

Bench Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . 12

Important Contact Numbers . . . . . . . . . . . . . . . . . . 16

Important Safety Precautions

7 ! 2 . ) . '

IMPORTANT SAFETY INSTRUCTIONS

The following deﬁnition applies to the word “WARNING” found throughout this manual:

Used to call attention to POTENTIAL hazards that could result in personal injury or loss of life.

WARNING!

Before beginning any exercise program consult your physician or health care professional.

Only he or she can determine the exercise program that is appropriate for your particular

age and condition. If you experience any light-headedness, dizziness, or shortness of

breath while exercising, stop the exercise and consult your physician.

Read all instructions and warning labels before using the equipment.

- It is your responsibility to read and understand all warnings and instructions. This is essential to safe operation.

- Keep your body weight centered on the bench while exercising.

- Never allow children on the bench. Teenagers should always have parental supervision when using this bench.

- Set up and operate bench only on a level surface.

- Make sure you have adequate room to use the equipment without interference with other objects or third party.

- Do not wear loose clothing while you are near the bench.

- Do not exceed the max. user weight of 300 lbs (136.1 kg).

- Do not exceed the maximum lifting load of 300 lbs (136.1 kg)

- The approxiamate weight of the bench is 62 lbs (28 kg)

- This bench is not intended for institutional use.

- Before exercising, make sure the back and seat supports are securely fastened and the bench is ﬁrmly in place.

- Inspect your bench before each workout. Periodically check all fasteners to make sure none have loosened with use.

- Never attempt to exercise with more resistance than you are physically able to handle.

- For safety, it is recommended that you exercise with a training partner or spotter.

- Do not use the bench if any component is found worn or damaged.

Safety Warning Labels

The following safety warnings are located on the Bowflex® SelectTech® 5.1 Bench. Please read all safety precautions and warning information prior to using your product. Be sure to replace any warning label if damaged, illegible, or missing. If you need replacement labels, please call a Bowﬂex® Representative at 1-800-864-1270.

Label 1: “Warning!: Use only genuine Bowﬂex® replacement parts. Failure to do so will void warranty and could

result in personal injury. There is a risk assumed by individuals who use this type of equipment. To minimize the risk always read your owner’s manual and follow these simple rules:

• Do not exceed max user weight - 300 lbs. (136.3 kg)

• Do not exceed maximum allowed lifting load 300 lbs. (136.3 kg)

• This machine is not intended for institutional use.

• Inspect equipment before each use. Replace all parts at the ﬁrst signs of wear or damage. If in doubt about a certain part, DO not use the equipment until the part is replaced. Failure to replace worn or damaged parts may result in injury.

CONSULT YOUR PHYSICIAN BEFORE STARTING ANY EXERCISE PROGRAM. Warm up properly before engaging in weight resistance training. Stop exercising if you feel faint or dizzy.

TO PREVENT THE POSSIBILITY OF SERIOUS INJURY, KEEP BODY AND CLOTHING CLEAR OF ALL MOVING PARTS.

CHILDREN SHOULD NOT BE ALLOWED TO USE THIS EQUIPMENT. To avoid possible injury children should be kept at a safe distance when this equipment is in use. Teenagers should not use this equipment without adult supervision.

CALL YOUR AUTHORIZED BOWFLEX DEALER if you have any questions on the proper use or maintenance of this equipment or BOWFLEX® CUSTOMER SERVICE AT: 1-800-605-3369 or www.bowﬂex.com

DO NOT REMOVE”

Location: On the rear Bench Frame.

Label 2: “Warning!: Keep hands clear of this area.”

Location: On the front Bench Frame.

Label 1

Label 2

Before You Assemble

Please take the time to read all assembly instructions before attempting to assemble your Bowflex® SelectTech® 5.1 Bench. The best place for your Bowflex® SelectTech® 5.1 Bench is on a hard, level surface.

Basic Assembly Principles

Here are a few basic tips that will make your assembly of the Bowflex® SelectTech® 5.1 Bench quick and easy. By using these principles, you can simplify each process and save yourself extra time and effort.

1. To make the assembly process go faster, gather the pieces you need for each step and thoroughly read the assembly instructions for that step prior to starting assembly for the step.

2. When tightening a locknut on a bolt, use a combination wrench to grip the locknut and ensure that it is fastened securely.

3. When attaching two pieces, gently lift and look through the bolt holes to help guide the bolt through the holes.

4. As a general rule, and for all bolts and nuts on your Bowflex® SelectTech® 5.1 Bench, turn bolts or nuts toward the right to tighten and left to loosen. Or you can remember the mnemonic: “Righty tighty, lefty loosey.”

Hardware and Tool Guide

Tools Required:

• 9/16 Socket

• 9/16 Wrench or Adjustable wrench

Hardware:

Descr: Flat Washer 3/8” Qty: 7

Descr: Flat Washer 5/16” Qty: 10

• 7/32 Allen Wrench (provided)

• 3/16 Allen Wrench (provided)

Descr: Allen Bolt - 3/8 x 3 Qty: 2

Descr: Allen Bolt - 5/16 x 2.5 Qty: 10

Descr: End Cap 3/4” Qty: 2

NOTE: Illustrations not to scale.

Descr: Lock Nut 3/8” Qty: 2

Descr: Allen Bolt - 3/8 x1 Qty: 3

Parts Guide

Item #: Qty: Description:

1 1 FRAME ASSY 2 1 STABILIZER, REAR 3 1 STABILIZER, FRONT 4 1 LEG HLD DOWN ASSY 5 1 TUBE, FOAM ROLLER 6 2 PAD, FOAM ROLLER 7 2 CAP, END 3/4”

Item #: Qty: Description:

10 1 PAD, HEAD 11 10 BHCS 0.3125-18 X 2.5 X.75 BLK 12 3 BHCS 0.375-16 X 1X1 BLK 13 2 BHCS 0.375-16 X 3X1 BLK 14 10 Flat Washer 5/16” 15 7 Flat Washer 3/8”

16 2 NUT, NYLOCK 3/8” 8 1 SEAT, BOTTOM 9 1 PAD, BACK

Assembly Instructions

STEP 1: Attaching Front and Rear Stabilizers

Parts:

Hardware:

Tools:

• (1) Bench Frame - Item 1

• (1) Rear Stabilizer - Item 2

• (1) Front Stabilizer - Item 3

• (2) 3/8 inch Allen Bolt, 3 inch long - Item 13

• (3) 3/8 inch Allen Bolt, 1 inch long - Item 12

• (7) Flat Washer 3/8 inch - Item 15

• (2) Lock Nut 3/8 inch - Item 16

• 7/32 Allen Wrench

• 9/16 Wrench

Assembly Steps:

1-1 Attach the Front Stabilizer (2) to the Bench Frame

(1) using the hardware shown.

1-2 Tighten hardware.

1-3 Attach the Rear Stabilizer (3) to the Bench Frame

(1) using the hardware shown.

1-4 Tighten hardware.

STEP 2: Attaching Seat Pad to Main Frame

Parts:

• (1) Bench Frame Assembly from Step 1

• (1) Seat Pad Assembly - Item 8

Hardware:

• (4) 5/16 inch Allen Bolt, 2 1/2 inch long - Item 11

• (4) Flat Washer 5/16 inch - Item 14

Tools:

• 3/16 Allen Wrench

Assembly Steps:

2-1 Align the Seat Pad Assembly (1) to the Bench

Frame Assembly between the open holes as shown.

2-2 Secure with the hardware as shown.

STEP 3: Attaching Back Assembly to Main Frame

Parts:

• (1) Bench Frame Assembly from Step 2

• (1) Back Pad Assembly - Item 9

• (1) Head Pad Assembly - Item 10

Hardware:

• (6) 5/16 inch Allen Bolt, 2 1/2 inch long - Item 11

• (6) Flat Washer 5/16 inch - Item 14

Tools:

• 3/16 Allen Wrench

Assembly Steps:

3-1 Align the Back Pad Assembly (9) to the Bench

Frame Assembly between the open holes as shown.

3-2 Secure with the hardware as shown.

3-3 Align the Head Pad Assembly (10) to the Bench

Frame Assembly between the open holes as shown.

3-4 Secure with the hardware as shown.

STEP 4: Attaching Leg Hold Down Attachment

Parts:

• (1) Bench Frame Assembly from Step 3 - Item 1

• (1) Leg Hold Down Tube - Item 4

• (1) Leg Pad Bar - Item 5

• (2) Leg Pad - Item 6

• (2) Leg Pad End Cap - Item 7

Hardware:

• (1) Pull Pin

Assembly Steps:

4-1 Attach the Leg Hold Down attachment to the Bench

Frame Assembly (1).

Begin by inserting the Leg Pad Bar (5) through the hole in the Leg Hold Down Tube (4), leaving room on each side for the Leg Pads.

4-2 Slide both Leg Pads (6) onto the Leg Pad Bar (5)

so that the entire assembly is centered on the Leg Hold Down Tube (4).

Secure the Leg Pad End Caps (7) onto each end of the Leg Pads (6).

4-3 Attach the Leg Hold Down Assembly to the Bench

as shown in the ﬁgure, with the hook portion of the Leg Hold Down Tube (4) resting on the rubber stop of the bench and the top portion of the Leg Hold Down Tube aligning with the pull pin hole (20).

Secure the Leg Hold Down by inserting the pull pin through the Leg Hold Down Tube and the bench through the area shown (20).

STEP 5: Congratulations!

7 ! 2 . ) . '

You have successfully completed assembly of your Bowflex® SelectTech® 5.1 Bench! Please inspect your exercise bench to ensure that all fasteners are tight and components are properly assembled. Review all warnings affixed to machine.

Failure to visually check and test assembly before use can cause damage to the Bowﬂex® SelectTech® 5.1 Bench and serious injury to users and bystanders and can also compromise the effectiveness of your exercise program.

Bench Positions

90 degrees

Decline with Seat raised

45 degrees

60 degrees

Flat

30 degrees

Companion Exercise Equipment

The Bowﬂex® SelectTech® 3.1 and 5.1 benches are designed for use with Bowﬂex® SelectTech® dumbbell equipment. The SelectTech® Dumbbell features a patented locking mechanism designed to assure proper and complete selection of the weight plates for each exercise. The SelectTech® dumbbell line includes the following models:

• SelectTech® 552 dumbbell – weight range 5-52 lbs. (2.7 - 23.6 kg)

• SelectTech

220 dumbbell – weight range 2-20 lbs. (.9 - 9.0 kg)

1090 dumbbell – weight range 10-90 lbs. (4.5 - 40.8 kg)

Using the bench expands the variety of exercises that you can include in your workout routine. The Owner’s Manual for each dumbbell model describes the variety of exercises available to enhance your workout routine.

Dumbbell stands for the SelectTech® dumbbells are also available separately. These stands feature an ergonomic design to enhance the functionality of the SelectTech® Dumbbell. The dumbbell handles are positioned in a natural orientation providing a comfortable and secure lifting position. In addition, the stand’s V-shape “step-in” design allows

SelectTech® 552 Dumbbell with 2-in-1 Stand

the user to maintain proper upper body position while lifting or replacing the dumbbells in the base.

• SelectTech® 220 Dumbbell Stand

• SelectTech® 2-in-1 Dumbbell Stand – for use with both the SelectTech® 552 and the SelectTech® 1090

dumbbell

Please contact Nautilus, Inc. or a Bowﬂex® Representative for information about other products, or go to www.nautilus.com

Warranty Information

What is Covered

Warrants to the original purchaser of this BOWFLEX® product that the equipment is free from defects in materials or workmanship, with the exceptions stated below. This warranty in not transferable or applicable to any person other than the original

purchaser.

Warranty

The frame and welds of this product are warranted to the original purchaser for thirty (30) years from date of original purchase. Upholstery, bushings and bearings are warranted for one (1) year to the original purchaser from the date of purchase. Parts are warranted to the original purchaser for a period of one (1) year

from the date of purchase.

Warranties Do Not Cover

- Damage due to use by persons who weigh more than 300 lbs

(136.1kg).

- Damage due to abuse, accident, failure to follow instructions or

warnings, misuse, mishandling, accident or Acts of God (such as ﬂoods or power surges).

- Use in any institutional or commercial settings such as health clubs, schools, or recreation centers. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to

you.

What We Will Repair

During your Warranty Coverage Period, Nautilus, Inc. will repair any BOWFLEX® equipment that proves to be defective in materials or workmanship. In the event repair is not possible, Nautilus, Inc., at its option, will either replace your equipment or refund your purchase price, less shipping and handling.

How To Obtain Service

To obtain service for a BOWFLEX® Fitness Product, contact an authorized BOWFLEX® Fitness Retailer. You may also contact a Nautilus representative at 800-864-1270 to help you locate a

dealer in your area.

How State Law Applies

This warranty gives you speciﬁc legal rights.You may also have other rights which vary from state-to-state.

- Consequential or incidental damage.

Bench Maintenance

Daily

After each use, wipe bench free of sweat with a clean, dry cloth. Upholstery can be cleaned with a mild

detergent or spray cleaner.

Weekly

If used often, your bench should be thoroughly cleaned using a clean cloth and an ammonia based

cleanser. Wipe bench down completely and be sure to touch up any scratches with touch up paint to prevent rusting.

Monthly

Check the frame of the bench for any sign of cracking or permanent bending. If you ﬁnd this situation, do

not use the bench and contact Bowﬂex Service immediately.

Bowflex® SelectTech® 5.1 Bench Warranty Registration Card

IMPORTANT! MAIL WITHIN 30 DAYS OF PURCHASE

PLEASE PRINT CLEARLY – THANK YOU

 Mr. 2.  Mrs. 3.  Ms. 4.  Miss Customer ID from Invoice:

Name:

Address: Apt. #:

City: State: Zip:

Phone number: -

( )

EXT.

E-Mail address:

Is this your primary address?  Yes  No

Place of purchase:

Date of purchase:

M M

D D

Y Y

Purchaser date of birth:

M M

D D Y Y

Gender:  Male  Female

Marital status:  Married  Single

Including yourself, total number of people living in your household: (Examples: 01, 02, 03 …)

Would you like to receive additional information on healthy lifestyle products?  Yes  No

Which best describes your family income: (US dollar figures)

 Under $15,000  $25,000 – $34,999  $50,000 – $74,999  $100,000 – $149,999

 $15,000 – $24,999  $35,000 – $49,999  $75,000 – $99,999  Over $150,000

What other types of exercise equipment do you own?

Did you receive this item as a gift?  Yes  No

Name of original purchaser:

Original purchaser customer ID number:

Please check here if you would prefer not to obtain information on new and interesting opportunities from other exciting companies.

Thanks for filling out this questionnaire. Your answers are important to us.

What Is Covered

Nautilus, Inc. warrants to the original purchaser of the Bowflex Bench that the machine is free from defects in materials or workmanship, with the exceptions stated below. This warranty is not transferable or applicable to any person other than the original purchaser and is only applicable for products sold and used in the United States or Canada. Tampering with the unit will void the warranty.

Bowflex® SelectTech® 5.1 Bench

• 30 years on frame and welds

• 1 year on upholstery, bushings and bearings

• 1 year on parts

Warranties Do Not Cover

• A Bowf lex® SelectTech® 5.1 Bench

SelectTech® 5.1

purchased for commercial or institutional use.

• Damage due to use by persons who weigh more than 300 pounds (136 kg).

• Damage due to abuse, accident, failure to follow instructions or warnings in the Assembly Manual, misuse, mishandling, accident or Acts of God (such as floods or power surges).

• Damage due to normal wear and tear.

What We Will Do

During your Warranty Coverage Period, Nautilus, Inc. will repair any Bowflex SelectTech® 5.1 Bench that proves to be defective in materials or workmanship. In the event repair is not possible, Nautilus, Inc. will either replace your Bowflex SelectTech® 5.1 Bench or refund your

purchase price, less shipping and handling.

How To Get Service

Return the defective part, at your expense, to the address given to you by a Nautilus Representative at 1-800-864-1270. Include an explanation of the problem. Adequate protective packaging of the defective parts or unit and cost of shipping are your responsibility.

The repaired part or unit will be returned to you at the company’s expense.

How State Law Applies

This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

Please fold over and tape before mailing

Place

Stamp

Here

Nautilus, Inc.

World Headquarters

16400 S.E. Nautilus Drive

Vancouver, WA 98683

Important Contact Numbers

If you need assistance, please have both the serial number of your machine and the date of purchase available when you contact the appropriate Nautilus office listed below.

OFFICES IN THE UNITED STATES:

E-mail: customerservice@nautilus.com

• NAUTILUS INNOVATION CENTER

Nautilus, Inc. 1886 Prairie Way Louisville, Colorado, USA 80027 Phone: 800-NAUTILUS (800-628-8458) Email: customerservice@nautilus.com Fax: 800-898-9410

• TECHNICAL/CUSTOMER SERVICE

Nautilus, Inc. World Headquarters 16400 SE Nautilus Drive Vancouver, Washington, USA 98683 Phone: 800-NAUTILUS (800-628-8458) Email: customerservice@nautilus.com Fax: 877-686-6466

• CORPORATE HEADQUARTERS

Nautilus, Inc. World Headquarters 16400 SE Nautilus Drive Vancouver, Washington, USA 98683 Phone: 800-NAUTILUS (800-628-8458)

INTERNATIONAL OFFICES:

For technical assistance and a list of distributors in your area, please call or fax one of the following numbers.

• INTERNATIONAL CUSTOMER SERVICE

Nautilus International S.A. Rue Jean Prouvé 6 1762 Givisiez / Switzerland Tel: + 41-26-460-77-77 Fax: + 41-26-460-77-70 Email: technics@nautilus.com

INTERNATIONAL OFFICES:

• SWITZERLAND OFFICE Nautilus Switzerland S.A. Tel: + 41-26-460-77-66 Fax: + 41-26-460-77-60

• GERMANY and AUSTRIA OFFICE Nautilus GmbH Tel: +49-2203-20-20-0 Fax: +49-2203-20-20-45-45

• ITALY OFFICE Nautilus Italy s.r.l. Tel: +39-051-664-6201 Fax: +39-051-664-7461

• UNITED KINGDOM OFFICE Nautilus UK Ltd. Tel: +44-1908-267-345 Fax: +44-1908-267-346

• CHINA OFFICE Nautilus Representative Ofﬁce Tel: +86-21-523-707-00 Fax: +86-21-523-707-09

© 2006 Nautilus, Inc. All Rights Reserved. Nautilus, Inc. World Headquarters, 16400 S.E. Nautilus Drive, Vancouver, Washington, USA 98683 1-800-NAUTILUS SelectTech, Bowﬂex, and the Bow ﬂex logo are either registered trademarks or trademarks of Nautilus, Inc. All other trademarks are property of their respective entities.

Printed in China.

Bowflex SelectTech 5.1 Bench User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
