BOSE PS18, PS28, PS48 Service Manual

Lifestyle® PS 18, 28 and 48
AMP PCB, Assebly 267332-0, Bare PCB - 267331-001
Digital Acoustimass
100V, 120V, 230V, Dual Voltage
®
Powered Speakers
Lifestyle® 28 Home Theater System
5 Double Cube Speakers
PS28 bass module
Lifestyle® 35 Home Theater System
5 Jewel Cube
PS48 bass module
®
Speakers
Power PCB, Assembly - 260327-001, Bare PCB - 266459-001 AMP PCB, Assembly - 266999-0, Bare PCB - 267083-001 DSP PCB, Assembly - 267391-0, Bare PCB - 267086-001
Service Manual
©2008 Bose Corporation
®
18 Home Theater System
5 Single Cube Speakers
PS18 bass module
Reference Number 268795-SM
Rev 13
Electronic copy only
PS18/28/48 Service Manual
Contents
Safety Information.............................................................................................................................2
Electrostatic Discharge Sensitive Device Handling (ESDS) .........................................................2
Specifications ....................................................................................................................................3
Part List Notes ...................................................................................................................................4
Part List Table of Contents ............................................................................................................... 4
Lifestyle® 18 Home Theater System Packaging.............................................................................. 5
Figure 1. LS18 System Packaging Exploded View ..............................................................................5
Lifestyle
Figure 2. LS28 System Packaging Exploded View ..............................................................................6
Lifestyle® 35 Home Theater System Packaging.............................................................................. 7
Figure 3. LS35 System Packaging Exploded View ..............................................................................7
Lifestyle® 18/28/35 Essentials Kit Part List ..................................................................................... 8
Figure 4. LS18, 28, 35 Essentials Kit Exploded View.......................................................................... 9
Lifestyle Lifestyle Lifestyle Lifestyle Lifestyle Lifestyle
Figure 5. LS18, 28 Cube Pack Exploded View ..................................................................................12
Figure 6. LS35 Cube Pack Exploded View ........................................................................................ 12
Jewel Cube Part List ....................................................................................................................... 13
Figure 7. Jewel Cube Exploded View ................................................................................................ 13
Single and Dual Cube Speaker Part List ....................................................................................... 14
Figure 8. Cube Exploded View .......................................................................................................... 14
PS18/28/48 Bass Module Assembly Part List ............................................................................... 15
Figure 9. Bass Module Exploded View.............................................................................................. 15
PS18/28/48 Amplifier Module Assembly Part List........................................................................16
Figure 10. Amplifier Module Exploded View...................................................................................... 16
PS18/28/48 Electrical Part List ................................................................................................. 17-31
Setting up a computer to issue TAP commands ..........................................................................32
Figure 11. Test cable part number 264564 ........................................................................................ 33
Placing the Bass Module into TAP Mode ......................................................................................34
Figure 12. DIP switch Up/Down orientation.......................................................................................34
Setting the Equalizer ...................................................................................................................... 34
Test Procedures ........................................................................................................................ 35-36
Bass Module Disassembly Procedures .................................................................................. 37-38
Cube Speaker Disassembly Procedures ......................................................................................39
Figure 13. PCB Part Number Identification .......................................................................................40
Figure 14. Date Of Manufacture (DOM) Identification.......................................................................40
®
28 Home Theater System Packaging.............................................................................. 6
®
18 Lit Kit Part List ..........................................................................................................10
®
28 Lit Kit Part List ..........................................................................................................10
®
35 Lit Kit Part List ..........................................................................................................10
®
18 Single Cube Speaker, 5 Pack Packaging List .........................................................11
®
28 Double Cube Speaker, 5 Pack Packaging List........................................................11
®
35 Jewel Cube® Speaker, 5 Pack Packaging List ........................................................ 11
Warranty
The Lifestyle®PS18/28/35 powered speaker system is covered by a limited 1-year transferable warranty.
PROPRIETARY INFORMATION THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF BOSE® CORPORATION WHICH IS BEING FURNISHED ONLY FOR THE PURPOSE OF SERVICING THE IDENTIFIED BOSE PRODUCT BY AN AUTHORIZED SERVICE CENTER OR OWNER OF THE BOSE PRODUCT, AND SHALL NOT BE REPRODUCED OR USED FOR ANY OTHER PURPOSE.
1
PS18/28/48 Service Manual
SAFETY INFORMATION
1. Parts that have special safety characteristics are identified by the symbol on schematics
or by special notes on the parts list. Use only replacement parts that have critical characteristics recommended by the manufacturer.
2. Make leakage current or resistance measurements to determine that exposed parts are accept­ably insulated from the supply circuit before returning the unit to the customer. Use the following checks to perform these measurements:
A. Leakage Current Hot Check-With the unit completely reassembled, plug the AC line cord directly into a 120V AC outlet. (Do not use an isolation transformer during this test.) Refer to UL6500 paragraph 9.1.1. Use a leakage current tester or a metering system that complies with American National Standards Institute (ANSI) C101.1 “Leakage Current for Appliances” and Underwriters Laboratories (UL) 6500, IEC 60065 paragraph 9.1.1. With the unit AC switch first in the ON position and then in OFF position, measure from a known earth ground (metal waterpipe, conduit, etc.) to all exposed metal parts of the unit (antennas, handle bracket, metal cabinet, screwheads, metallic overlays, control shafts, etc.), especially any exposed metal parts that offer an electrical return path to the chassis. Any current measured must not exceed 0.5 milliamp. Reverse the unit power cord plug in the outlet and repeat test. ANY MEASUREMENTS NOT WITHIN THE LIMITS SPECIFIED HEREIN INDICATE A POTENTIAL SHOCK HAZARD THAT MUST BE ELIMINATED BEFORE RETURNING THE UNIT TO THE CUSTOMER.
B. Insulation Resistance Test Cold Check-(1) Unplug the power supply and connect a jumper wire between the two prongs of the plug. (2) Turn on the power switch of the unit. (3) Measure the resistance with an ohmmeter between the jumpered AC plug and each exposed metallic cabinet part on the unit. When testing 3 wire products, the resistance measured to the product enclosure should be between 2 and infinite Meg ohms. Also, the resistance measured to exposed output/ input connectors should be between 4 and infinite Meg ohms. When testing 2 wire products, the resistance measured to exposed output/input connectors should be between 4 and infinite Meg ohms. If it is not within the limits specified, there is the possibility of a shock hazard, and the unit must be repaired and rechecked before it is RETURNED TO THE CUSTOMER.
ELECTROSTATIC DISCHARGE SENSITIVE (ESDS)
DEVICE HANDLING
This unit contains ESDS devices. We recommend the following precautions when repairing, replacing or transporting ESDS devices:
Perform work at an electrically grounded work station.
Wear wrist straps that connect to the station or heel straps that connect to conductive floor mats.
Avoid touching the leads or contacts of ESDS devices or PC boards even if properly grounded.
Handle boards by the edges only.
Transport or store ESDS devices in ESD protective bags, bins, or totes. Do not insert unpro­tected devices into materials such as plastic, polystyrene foam, clear plastic bags, bubble wrap or plastic trays.
CAUTION: THE BOSE®PS 28 AND PS 35 POWERED SPEAKERCONTAINS NO USER-SER­VICEABLE PARTS. TO PREVENT WARRANTY INFRACTIONS, REFER SERVICING TO WARRANTY SERVICE STATIONS OR FACTORY SERVICE.
2
PS18/28/48 Service Manual
Specifications
Mechanical
Dimensions:
Weight: Module: 35.9 lb (16.3 kg)
Drivers: Bass module: Two woofers, 5 1/4", 2.33 Ohms,
Bass Module: 8.0" W x 23.0" D x 16.0" H
(20.32 x 58.42 x 40.64 cm)
Single Satellite: 3.1” W x 4.0” D x 3.1” H
(7.0 x 10.2 x 7.9 cm)
Double Satellite: 3.1" W x 4.0" D x 6.02" H
Jewel Cube
Single Satellite: 1.1 lb (0.5 kg) Double Satellite: 2.4 lb (1.1 kg) Jewel Cube speaker: 1 lb (0.5 kg)
speaker:
(7.8 x 10.2 x 15.7 cm)
2.2" W x 8.0" D x 2.6" H (39.4 x 20.3 x 6.6 cm)
Electrical
(wired in parallel) Single Satellite speaker: One Twiddler Double Satellite speaker: Two Twiddler speakers per cube, 50 mm, 4 Ohms
(wired in series) Jewel Cube speaker: Two Twiddler speakers per cube, 2 1/4", 3.2 Ohms
(wired in series)
TM
speakers per cube, 50 mm, 4 Ohms
Amplifier power: Bass Channel: 125W, <0.2% THD, 40 Hz-200 Hz,
120 Vrms AC mains L/R/C/LS/RS: 20W, <0.2% THD, 200 Hz-15 kHz,
120 Vrms AC mains
Input impedance: Bass Module: 1.16 Ohms (two 2.33 Ohm woofers
wired in parallel)
Single Satellite: 4 Ohms (one 4 Ohm Twiddler speaker) Double Satellite: 8 Ohms (two 4 Ohm Twiddler speakers
wired in series) Jewel Cube Speaker: 6.4 Ohms (two 3.2 Ohm Twiddler speakers
wired in series)
L/R/C/LS/RS output distortion: <0.1% THD at 0.5W
Bass distortion: <0.2% THD at 0.5W
L/R/C/LS/RS output noise: <500 uVrms, A weighted
Bass output noise: <2 mVrms, unweighted
L/R/C/LS/RS DC offset: <25 mVdc
L/R/C/LS/RS balance:
2.0 dB
±
Channel separation: >40 dB at 1 kHz
>30 dB at 10 kHz
Turn-on delay: 1.5 seconds maximum
Turn-off delay: 200 ms maximum
Main voltage:
Inrush current:
USA/Canada : 120 VAC, 60Hz Europe, UK, AUS : 230/240VAC, 50Hz Dual Voltage : 115/230VAC, 50/60Hz
20A peak for first 33.3 msec.
3
(stereo mode)
PS18/28/48 Service Manual
Part List Notes
1. This part is not normally available from customer service. Approval from the Field Service
Manager is required before ordering.
2. The individual parts located on the PCB are listed in the part list.
3. This part is critical for safety purposes. Failure to use a substitute replacement with the
same safety characteristics as the recommended replacement part might create shock, fire and/or other hazards.
4. This part is set to the Lifestyle
®
28/38 system equalization. To use this part on a Lifestyle® 18, 35 or 48 system, refer to the instructions located on page 31 for setting the Equalizer using TAP commands. Except for the Lifestyle® 18 system, in place of using TAP commands to set the EQ, the customer may use the Bose® AdaptIQTM audio calibration system to customize the EQ to their room. The Lifestyle® 18 system bass module is set to provide a lower outut to match the single cubes, which can only be set using TAP commands. The AdaptIQ audio calibration system is
®
shipped with the Lifestyle
18,28,35,38,48 system.
Part List Table of Contents
The part list is broken into sections relative to the way the system is packaged and built, starting from the system level and ending at the component level.
System Packaging - Console, bass module, cube pack, essentials kit. Essentials Kit - Remote, batteries, antennas, power pack, line cords, IR Blaster, TV sensor. Lit Kit - Feet, owner’s guide, installer’s guide. Cube Speaker Pack - Cubes, connection cables Bass Module Assembly - Amplifier module, woofer, grille Amplifier Module Assembly - Power PCB, amplifier PCB, DSP PCB Electrical Part List - Resistors, Capacitors, Diodes, Transistors, ICs, Misc.
Lifestyle® 18 Home Theater System Packaging ............................................................................................. 5
Figure 1. LS18 System Packaging Exploded View ............................................................................................. 5
Lifestyle® 28 Home Theater System Packaging ............................................................................................. 6
Figure 2. LS28 System Packaging Exploded View ............................................................................................. 6
Lifestyle® 35 Home Theater System Packaging ............................................................................................. 7
Figure 3. LS35 System Packaging Exploded View ............................................................................................. 7
Lifestyle® 18/28/35 Essentials Kit Part List .................................................................................................... 8
Figure 4. LS18, 28, 35 Essentials Kit Exploded View ......................................................................................... 9
Lifestyle® 18 Lit Kit Part List ......................................................................................................................... 10
Lifestyle® 28 Lit Kit Part List ......................................................................................................................... 10
Lifestyle® 35 Lit Kit Part List ......................................................................................................................... 10
Lifestyle® 18 Single Cube Speaker, 5 Pack Packaging List ......................................................................... 11
Lifestyle® 28 Double Cube Speaker, 5 Pack Packaging List .......................................................................11
Lifestyle® 35 Jewel Cube® Speaker, 5 Pack Packaging List ........................................................................ 11
Figure 5. LS18, 28 Cube Pack Exploded View ................................................................................................. 12
Figure 6. LS35 Cube Pack Exploded View ....................................................................................................... 12
Jewel Cube Part List...................................................................................................................................... 13
Figure 7. Jewel Cube Exploded View ............................................................................................................... 13
Single and Dual Cube Speaker Part List ...................................................................................................... 14
Figure 8. Cube Exploded View ......................................................................................................................... 14
PS18/28/48 Bass Module Assembly Part List .............................................................................................. 15
Figure 9. Bass Module Exploded View ............................................................................................................. 15
PS18/28/48 Amplifier Module Assembly Part List ....................................................................................... 16
Figure 10. Amplifier Module Exploded View ..................................................................................................... 16
PS18/28/48 Electrical Part List ................................................................................................................. 17-31
4
PS18/28/48 Service Manual
Lifestyle® 18 Home Theater System Packaging
Item
Number
1 CARTON 268787-001 2 PACKING, INSERT, GRILL 258465 3 PACKING, END CAP, EPS, FRONT 258466 4 PACKING, END CAP, EPS, REAR 258475 5 BAG, POLY 196638 6 PACKING PAD, 29.38X21.38 258469 7 AV28, US TUNER, RC1
AV28, EURO TUNER, RC4 AV28, JAP, IR REMOTE, RC2
8 PS18 BASS MODULE, DUAL V, BLACK
PS18 BASS MODULE, DUAL V, WHITE
9 SINGLE SAT, 5 PK, BLACK
SINGLE SAT, 5 PK, WHITE
10 ESSENTIALS KIT, LS18, 120V, (US)
ESSENTIALS KIT, LS18, 220V, (EURO) ESSENTIALS KIT, LS18, 230V, (UK) ESSENTIALS KIT, LS18, 240V, (AUS)
ESSENTIALS KIT, LS18, DUAL 11 FOAM, SHT, ADHESIVE BACK 263426 12 GUIDE, QUICK SETUP 268796 13 COMMITMENT LETTER 251001
Description Part Number Note
266440-1019 266440-2049 266440-3029
278799-619 278799-629
268791-119 268791-129 269660-1 269660-2 269660-4 269660-5 269660-6
1, 4
1
1
1
13
12
7
10
23 4
811
9
6
1
5
Figure 1. LS18 System Packaging Exploded View
5
PS18/28/48 Service Manual
Lifestyle® 28 Home Theater System Packaging
Item
Number
1 CARTON, RSC 258474-002 2 PACKING INSERT GRILLE 258465 3 PACKING END CAP EPS FRONT 258466 4 PACKING END CAP EPS REAR 258475 5 BAG POLY 196638 6 PACKING PAD 29.38X21.38 258469 7 AV28, US TUNER, RC1
AV28, EURO TUNER, RC4 AV28, JAP, IR REMOTE, RC2
8 BASS MODULE, BLACK, DUAL V
BASS MODULE, WHITE, DUAL V
9 SAT ASSY, 5 PK, BLACK
SAT ASSY, 5 PK, WHITE
10 ESSENTIALS KIT, LS-35, 120V, (US)
ESSENTIALS KIT, LS-35, 220V, (EURO) ESSENTIALS KIT, LS-35, 230V, (UK) ESSENTIALS KIT, LS-35, 240V, (AUS)
ESSENTIALS KIT, LS-35, DUAL 11 FOAM, SHT, ADHESIVE BACK 263426 12 GUIDE, QUICK SETUP 266254 13 COMMITMENT LETTER 251001
Description Part Number Note
266440-1019 266440-2049 266440-3029
278799-619 278799-629
256815-113 OR -119 256815-123 OR -129 266217-1 266217-2 266217-4 266217-5 266217-6
1
1, 4
1
1
13
12
7
10
2
3 4
11
8
9
6
1
5
Figure 2. LS28 System Packaging Exploded View
6
PS18/28/48 Service Manual
Lifestyle® 35 Home Theater System Packaging
Item
Number
1 CARTON, RSC 258474-002 2 PACKING INSERT GRILLE 258465 3 PACKING END CAP EPS FRONT 258466 4 PACKING END CAP EPS REAR 258475 5 BAG POLY 196638 6 PACKING PAD 29.38X21.38 258469 7
8 PS18/28/35, BASS MODULE, BLACK, DUAL V
9 SAT ASSY, 5 PK, BLACK
10 ESSENTIALS KIT, LS-35, 120V, (US)
11 FOAM, SHT, ADHESIVE BACK 263426 12 GUIDE, QUICK SETUP 266255 13 COMMITMENT LETTER 251001
AV28, US TUNER, RC1 AV28, EURO TUNER, RC4 AV28, JAP, IR REMOTE, RC2
PS18/28/35, BASS MODULE, WHITE, DUAL V
SAT ASSY, 5 PK, WHITE
ESSENTIALS KIT, LS-35, 220V, (EURO) ESSENTIALS KIT, LS-35, 230V, (UK) ESSENTIALS KIT, LS-35, 240V, (AUS) ESSENTIALS KIT, LS-35, DUAL
Description Part Number Note
266440-1019 266440-2049 266440-3029
U278799-619 U278799-629
256816-013 OR -019 256816-023 OR -029 266218-1 266218-2 266218-4 266218-5 266218-6
1, 4
1
1
1
13
12
7
10
23 4
811
9
6
1
5
Figure 3. LS35 System Packaging Exploded View
7
PS18/28/48 Service Manual
Lifestyle® 18/28/35 Essentials Kit Part List
Refer to figure 4
Item
Description Part Number Variant Packaging QTY Note
Number
1
REMOTE CONTROL 256119-001
REMOTE, CONTROL EU, 40MHZ 256119-002
2 BATTERY, AAA SIZE 179223-01
ANTENNA, FM DIPOLE, F-CONN 148589
3
ANTENNA, FM DIPOLE, PAL CONN 143185
POWER PACK, 35W, 120V, DCS-91 294295-001
4
POWER PACK, 35W, 230V, DCS-92 294295-007
POWER PACK, 35W, DUAL-V, DCS-94 294295-004 5 ANTENNA, ASSY, AM 199824-002 6 TV POWER SENSOR 258359
LINE CORD, 120V, AV28 279101-0310
LINE CORD, 220V, AV28 148203 7
LINE CORD, 230V, AV28 134725
LINE CORD, 240V, AV28 134726
LINE CORD, 120V, PS18/28/48 263453-006
LINE CORD, 220V, PS18/28/48 264355-006 8
LINE CORD, 230V, PS18/28/48 264356-006
LINE CORD, 240V, PS18/28/48 284241-006 9 BAG, POLY, 3X3MIL 194392
10 IR BLASTER 260335 11 TRAY PACK INSERT 258471 12 CARTON, ACCY KIT 258470-001 13 KIT, ADAPTIQTM 258363 14 SCART ADAPTOR 266221-001
LIT KIT, LS18 268793-1
LIT KIT, LS18 268793-2
LIT KIT, LS18 268793-4
LIT KIT, LS28 266219-1
15
LIT KIT, LS28 266219-2
LIT KIT, LS28 266219-4
LIT KIT, LS35 266220-1
LIT KIT, LS35 266220-2
LIT KIT, LS35 266220-4
US, CAN, AUS, EU, UK, SE ASIA/EAST ASI A, SING S. AF, MID E, DUAL-V
ALL
US, CAN, DUAL-V
AUS, EU, UK, SE ASIA/EAST ASIA, SING, S. AF, MID E, DUAL-V
US, CAN
AUS, UK, SE ASIA/EAST ASIA, SING
EU, LATIN AMERICA, S. AF, MID E, DUAL-V
ALL
ALL
US, CAN, DUAL-V
EU, LATIN AMERICA, MID E, S. AF, SE ASIA/EAST ASIA, DUAL-V UK, SING
AUS
US, CAN, DUAL-V
EU, LATIN AMERICA, MID E, S. AF, SE ASIA/EAST ASIA, DUAL-V UK, SING
AUS
ALL
ALL
ALL
ALL
ALL
AUS, SING, EU, UK, SE ASIA/EAST ASIA, S. AF, MID E, DUAL-V US, CAN, LATIN AMERICA
EU, S. AF, MID E
AUS, UK, SING, SE ASIA/EAST ASIA
US, CAN, LATIN AMERICA
AUS, EU, S. AF, MID E
UK, SI NG, SE ASIA/EAST ASIA
US, CAN, LATIN AMERICA
AUS, EU, S. AF, MID E
UK, SI NG, SE ASIA/EAST ASIA
1
4 1
1 3
1 1 1 3
1 3
1 1 1 1 1 1
1
8
8
PS18/28/48 Service Manual
15
7
6
3
5
13
1
10
2
9
12
4
14
Figure 4. LS18, 28, 35 Essentials Kit Exploded View
9
11
Lifestyle® 18 Lit Kit Part List
Description Part Number Variant Packaging QTY Note
FOOT, CUBES 178321-04 FOOT, BASS MODULE 142839 OPERATING GUIDE, 3 LANG 269711 OPERATING GUIDE, 5 LANG 269713 INSTALL GUIDE, 3 LANG 269712
INSTALL GUIDE, 5 LANG 269714 BAG, POLY, 14.38x9.87x2 mil 103351 CARD, INFO, WARRANTY, MULTI LANG 181460
SHEET SLIP COMPONENT AUDIO 255805 ADDRESS PAGE 259434 CARD REGISTRATION AND
262933 WARRANTY CARD, LIFESTYLE UPDATE 268157 DEC OF CONF 268794
Lifestyle® 28 Lit Kit Part List
PS18/28/48 Service Manual
ALL
ALL
ALL
EU, S. AF, MID E, DUAL-V
US, CAN, AUS, UK, EU, S. AF, MID E, SING, SE ASIA/EAST ASIA, DUAL-V EU, S. AF, MID E, DUAL-V
ALL
EU, S. AF, MID E, DUAL-V, AUS, UK, SING, SE ASIA/EAST ASIA, DUAL-V
ALL
US, CAN, LATIN AMERICA
US, CAN, LATIN AMERICA
US, CAN, LATIN AMERICA
AUS, UK, SING, SE ASIA/EAST ASIA, DUAL-V
4 4 1
1
1
1 1 1
1 1
Description Part
Number
FOOT, CUBES 178321-04 FOOT, BASS MODULE 142839 OPERATING GUIDE, 3 LANG 264341 OPERATING GUIDE, 5 LANG 264342 INSTALL GUIDE, 3 LANG 264343 INSTALL GUIDE, 5 LANG 264344 BAG, POLY, 14.38x9.87x2 mil 103351 CARD, INFO, WARRANTY, MULTI LANG 181460
SHEET SLIP COMPONENT AUDIO 255805 ADDRESS PAGE, BOSE 259434 CARD REGISTRATION AND WARRANTY 262933 CARD, LIFESTYLE UPDATE 268157 DEC OF CONF 266994
Lifestyle® 35 Lit Kit Part List
Description Part
Number
FOOT, CUBES 183621 FOOT BASS MODULE 142839 OPERATING, GUIDE, 3 LANG 264341 OPERATING GUIDE, 5 LANG 264342 INSTALL GUIDE, 3 LANG 264343 INSTALL, GUIDE, 5 LANG 264344 BAG, POLY, 14.38x9.87x2 mil 103351 CARD, INFO, WARRANTY, MULTI LANG 181460
SHEET SLIP COMPONENT AUDIO 255805 ADDRESS PAGE, BOSE 259434 CARD REGISTRATION AND WARRANTY 262933 CARD, LIFESTYLE UPDATE 268157 DEC OF CONF 266994
Variant Packaging QTY NOTE
ALL
ALL
ALL
AUS, EU, S. AF, MID E.
ALL
AUS, EU, S. AF, MID E.
ALL
AUS, EU, S. AF, MID E., UK, SING, SE ASIA/EAST ASIA ALL
US, CAN, LATIN AMERICA
US, CAN, LATIN AMERICA
US, CAN, LATIN AMERICA
AUS, EU, S. AF, MID E., UK, SING, SE ASIA/EAST ASIA
Variant Packaging QTY NOTE
ALL
ALL
ALL
AUS, EU, S. AF, MID E.
ALL
AUS, EU, S. AF, MID E.
ALL
AUS, EU, S. AF, MID E., UK, SING, SE ASIA/EAST ASIA ALL
US, CAN, LATIN AMERICA
US, CAN, LATIN AMERICA
US, CAN, LATIN AMERICA
AUS, EU, S. AF, MID E., UK, SING, SE ASIA/EAST ASIA
4 4 1
1
1 1
1 1 1 1 1
4 4 1
1
1 1
1 1 1 1 1
10
PS18/28/48 Service Manual
Lifestyle® 18 Single Cube Speaker, 5 Pack Packaging List
Item
Number
1 SATELLITE ASSEMBLY, SINGLE, BLACK
SATELLITE ASSEMBLY, SINGLE, WHITE 2 CABLE, RJ-45/8 PIN DIN 260351-002 1 3 CABLE, AUDIO, DUAL RCA 185931-01 1 4 CABLE, VIDEO, 6', YL 183200 1 5 CABLE, S-VIDEO, 6’ 258369 1 6 CABLE, COMPONENT, VIDEO, ADAPTOR 260350 1 7 CABLES, SPKR, 18 AWG, L/C/R, BLACK
CABLES, SPKR, 18 AWG, L/C/R, WHITE 8 CABLE, SPEAKER, REAR, BLACK
CABLE, SPEAKER, REAR, BLACK 9 BAG, POLY, 10X12X2mil 144677 5
10 PACKING, INSERT 258473 1 11 CARTON, CHIPBOARD, SATELLITE 250555-001 5 12 CARTON, D/C 258472-001 1
Description Part Number Qty Note
250490-119 250490-129
180643-4 176201-4 180644 176202
5
1
1
Lifestyle®28 Double Cube Speaker, 5 Pack Packaging List
Item
Number
1 SATELLITE ASSEMBLY, SINGLE, BLACK
SATELLITE ASSEMBLY, SINGLE, WHITE 2 CABLE, RJ-45/8 PIN DIN 260351-002 1 3 CABLE, AUDIO, DUAL RCA 185931-01 1 4 CABLE, VIDEO, 6', YL 183200 1 5 CABLE, S-VIDEO, 6' 258369 1 6 CABLE, COMPONENT, VIDEO ADAPTOR 260350 7 CABLES, SPKR, 18 AWG, L/C/R, BLACK
CABLES, SPKR, 18 AWG, L/C/R, WHITE 8 CABLE, SPEAKER, REAR, BLACK
CABLE, SPEAKER, REAR, WHITE 9 BAG, POLY, 10X12X2 mil 144677 5
10 PACKING, INSERT 258473 11 CARTON, CHIPBOARD, SATELLITE, BLUE 197330-002 5 12 CARTON, D/C, SAT KIT 258472-001 1
Description Part Number Qty Note
192420-149 149420-159
180643-4 176204-4
180644 176202
5
1
1
Lifestyle® 35 Jewel Cube® Speaker, 5 Pack Packaging List
Item
Number
1 JEWEL CUBE SPEAKER, BLACK
JEWEL CUBE SPEAKER, WHITE 2 CABLE, RJ-45/8 PIN DIN 260351-002 1 3 CABLE, AUDIO, DUAL RCA 185931-01 1 4 CABLE, VIDEO, 6', YL 183200 1 5 CABLE, S-VIDEO, 6' 258369 1 6 CABLE, COMPONENT, VIDEO ADAPTOR 260350 7 CABLESET, 3PK, L/C/R, BLACK
CABLESET, 3PK, L/C/R, WHITE 8 CABLESET, 2PK, LS/RS, BLACK
CABLESET, 2PK, LS/RS, WHITE 9 BAG, POLY, 3X3.5X.004 185214 5
10 SATELLITE TRAY 190211-001 1 11 CARTON, D/C, SAT KIT 258472-001 1 12 PACKING, INSERT 258473 1 13 PACKING, PULL TAB, 2.25X1.75 188029-001 5
Description Part Number Qty Note
289523-019 289523-029
193145-04 193145-14
193146-03 193146-13
5
1
1
11
PS18/28/48 Service Manual
3
10
4
8
6
5
12
Figure 5. LS18, 28 Cube Pack Exploded View
7
2
9
1
7
2
8
6
12
3
4
Figure 6. LS35 Cube Pack Exploded View
9
1
10
11
5
13
12
Jewel Cube®Part List
PS18/28/48 Service Manual
Item
Number
1 TWIDDLERTM ASSY, 50MM 273244-002 or 291636-001 2 2 GRILLE, CUBE, BLACK, W/O SLOT
GRILLE, CUBE, WHITE, W/O SLOT
3 GRILLE, CUBE, BLACK, W/SLOT
GRILLE, CUBE, WHITE, W/SLOT 4 SNAP RING 313536-001 1 5 H-RING, SEAL, BLACK
H-RING,SEAL NATURAL 6 HARNESS ASSY, TWIDDLER 196136-01 1 7 SCREW, HILO, 4-16x.375, PAN, XREC 181621-06 8 8 DAMPER, ANTI-BUZZ 185951 8 9 NAMEPLATE, BOSE, BLACK/PEWTER
NAMEPLATE, BOSE, WHITE/PEWTER
Description Part Number Qty Note
192935-01 192935-03 192935-02 192935-04
178710-01 178710-02
178725-01 178725-02
1
1
2
1
4
1
x2
5
2
8
x8
6
3
9
x8
7
Figure 7. Jewel Cube Exploded View
13
PS18/28/48 Service Manual
Single and Dual Cube Speaker Part List
Item
Number
1 GRILLE, BLACK
GRILLE, WHITE
2 LOGO, 1" DIAMOND CUT, BLACK
LOGO, 1" DIAMOND CUT, WHITE
Description Part Number Qty Note
192410-019 192410-029 193250-11 193250-12
Release the grille
from these catches
2
1
1
2
Figure 8. Cube Exploded View
14
Loading...
+ 32 hidden pages
