Bosch TAS1253GB Instruction manual

TAS 12xxGB/CH
en Instruction manual de Gebrauchsanleitung fr Mode d’emploi it Istruzioni per l’uso
1
a
b
1 English 7 Deutsch 13 Français 19 Italiano
en Safety instructions de Sicherheitshinweise fr Consignes de sécurité it Avvertenze di sicurezza
en At a glance de Auf einen Blick fr Présentation it Panoramica
h
en Troubleshooting de Hilfe bei Problemen fr Aide en cas de problèmes it Soluzione di guasti
b
2 3 4
a
b
c
a
b c
d
e/f
1
a
b
c
6
a
b
5
a b
en Risk of electric shock! de Stromschlaggefahr! fr Risque de choc électrique ! it Pericolo di scossa elettrica!
en Risk of burns! de Verbrennungsgefahr! fr Risque de brûlure ! it Pericolo di ustioni!
T
U
V
Safety instructions
A
Instruction manuals
Please read parts 1 and 2 of these manuals carefully before using the product and keep them for future reference. Passthemon to all users.
Intended use
This appliance is designed for the preparation of small amounts of coffee for domestic use or for use in household-like, non-commercial environments. Household-like environments include, for example, use in staff areas in shops, offices, agricultural and other small businesses, as well as use by guests at bed-and-breakfast establishments, small hotels and similar residential facilities.
Children younger than 8 years may not operate the appliance. This appliance may be used by children aged 8 years and older and by persons with reduced physical, sensory or mental capabilities or who lack experience and / or knowledge if they are supervised or have been given instruction in the safe use of the appliance and have understood the dangers involved. Children may not play with the appliance. Cleaning and user maintenance may be carried out by children of 8 years and older under supervision. The appliance and its connection cable must be kept away from children younger than 8 years of age.
For optimum results, fill the tank only with cool, fresh, non-carbonated water each day. Do not use chemically softened water.
Ambient conditions
Only use the appliance indoors at room temperature and up to 2000 m above sea level.
1 en
a
Safety instructions
Power connection
Operate and connect the appliance only in accordance with theinstructions given on the nameplate.
Only use your TASSIMO appliance if the power cable and appliance show no signs of damage.
Repairs
Disconnect the appliance from the mains as soon as a fault is detected.
Any repairs, such as replacing a damaged power cable, may only be carried out by our Customer Services team in order to avoid potential danger.
Risk of burns!
Never attempt to open the brewing unit during operation. Pleasenote that any escaping liquids will be very hot. TheTDISC, the piercing unit and the beverage outlet may be very hot immediately after brewing. Allow to cool first. Do not use TDISCs that are damaged. Only use each TDISC once.
Risk of electric shock!
Before cleaning, switch off the appliance using the On / Off switch and disconnect from the mains. Never immerse the appliance or power cable in water.
Risk of injury!
Under no circumstances should you drink the descaling liquid.
Saving energy
You should switch off your TASSIMO appliance after every use in order to save energy.
2en
At a glance
B
Before reading on, please unfold the illustrations page at the start of the booklet.
1 On / Off switch 2 Start / Stop button with
display elements
a Status LED S b Fill water tank R c Descale Q
3 Brewing unit
a Lid b TDISC support c TDISC piercing unit d TDISC reading window e Beverage outlet f Splash guard
Disposal
g
Dispose of packaging in an environmen­tally-friendly manner. This appliance is labelled in accordance with European Directive 2012/19/EG concerning used electrical and electronic appli­ances (waste electrical and electronic equipment – WEEE). The guideline determines the framework for the return and recycling of used appliances as applicable throughout the EU.
Please ask your specialist retailer about current disposal facilities.
4 Removable water tank
a max mark b ”Descaling” Q mark c Float
5 Storage compartment
a Yellow Service TDISC b Brief cleaning / descaling
instructions
6 Cup stand
(removable and height adjustable)
a Drip grate b Drip tray
Info
I
Bosch is the manufacturer of the TASSIMO machine. Therefore, it cannot provide any delivery guarantee for the TASSIMO T DISCs.
TASSIMO TDISCs are available from specialist retailers.
Or visit www.tassimo.com to discover the large variety of beverages available and to order your discs online.
3 en
h
Troubleshooting
The following table contains solutions to problems or faults which may occur during operation of the appliance and that can be easily rectified at home. If you are not satis­fied with the solutions provided here, please contact our Customer Service department. Further customer service information can also be found online: www.tassimo.com
Problem Cause Solution
The appliance is not working and none of the display elements (LEDs) are lighting.
The brewing starts, however there is no beverage dispensed.
The brewing will not start.
The brewing unit cannot be closed.
The appliance has no power supply.
The appliance is no switched on.
The water tank is not inserted correctly.
The water tank was removed during the brewing stage or there is air in the system.
The float in the water tank is stuck.
No TDISC inserted. Check that a TDISC has been inserted. The appliance does not
recognise the TDISC bar code.
The brewing unit is not closed properly.
The appliance was not switched on when inserting the TDISC.
The piercing unit and/ or the TDISC support have not been correctly inserted.
The TDISC has not been correctly inserted.
The brewing unit is not closed properly.
Check to see whether the appliance is con nected to the mains.
t
Make sure the appliance has been switched on.
Check that the water tank is correctly inserted.
Start the cleaning process with the yellow Service TDISC. Please refer here to the section âFirst Time Use, Steps 2 – 14.
Clean the water tank and free the float.
Clean the TDISC reading window with a soft, damp cloth.
Smooth out the foil of the TDISC with your finger so that the bar code can be read.
Use a new TDISC. If the problem persists, contact the TASSIMO
careline. Clean the brewing unit with a soft, damp cloth,
paying particular attention to the lid area. Switch on the appliance before inserting the
TDISC
Press the piercing unit into its holder using both thumbs and check the position of the TDISC support.
Replace the damaged TDISC with a new one. Place the TDISC with the printed side facing downwards so that the tab is resting in the intended slot.
Clean the brewing unit with a soft, damp cloth, paying particular attention to the lid area.
Press the lid down until it audibly clicks into place.
-
4en
Troubleshooting
Problem Cause Solution
The brewing unit cannot be opened.
Fill water tank R lightsup.
Fill water tankR lights up even though there is enough water in the water tank.
Fill water tank R and Descale Q are flashing simulta neously and it is not possible to prepare drinks.
Descale Q lights up or starts flashing.
Descale Q lights up or starts flashing even though decalcified water has been used.
The quality of the crema has deteriorated.
Water is dripping from the brewing unit.
On the surface below the cup stand there is water.
The brewing unit is still locked.
There is not enough water in the water tank.
The float in the water tank is stuck.
The water tank is not inserted correctly.
There is a fault on the machine.
The appliance needs to be descaled.
Even decalcified water contains low amounts of calcium carbonate.
The beverage outlet is sticky or dirty.
Build-up of limescale in the appliance.
The TDISC is damaged or leaky. The TDISC has not been pierced cor
The piercing unit has not been inserted correctly.
This is condensation. Condensation may appear and is not caused
rectly.
Wait until the Status LED S has stopped blink­ing before attempting to open the
If the brewing unit stays locked, contact the TASSIMO careline.
Fill the tank with cold, fresh water as far as the max mark. Reinsert the water tank.
Clean the water tank and free the float.
Check that the water tank has been correctly inserted.
Turn the machine off using the On / Off switch, wait approximately 5 minutes and turn the machine back on. If R and Q are still flashing, please contact the TASSIMO careline.
Descale the appliance. Please refer here to the section áDescaling.
Descale the appliance. Please refer here to the section áDescaling.
Clean the beverage outlet. Please refer here to the section àCleaning.
Clean the brewing unit with the yellow Service TDISC. Please refer here to the section àCleaning.
Descale the appliance. Please refer here to the section áDescaling.
Do not use TDISCs that are damaged. Only use each TDISC once.
ait until t
W an end and the appliance has cooled down. Remove the TDISC and clean the brewing unit. Please refer here to the section àCleaning.
Press the piercing unit into its holder using both thumbs (until an audible click is heard).
by any fault with the appliance. Wipe the water away with a cloth.
H
brewing unit.
he brewing stage has come to
5 en
